Leica BOND RX
– Fully Automated IHC & ISH
Quality. Speed. Flexibility.
Research Use Only. Not for use in diagnostic procedures.
Quality
Clarity that enhances insight
Speed
More slides, more opportunities
Flexibility
The freedom of open research
Total Freedom
Choose the ideal reagents
There are no limits to the reagents
you can use on the truly open
Leica BOND RX . Freely select
Novocastra BOND reagents
or any other antibody, probe
or detection component.
•
Novocastra BOND reagents
• Novocastra manual reagents
Total Assistance
Receive unrivalled support
Call Leica Biosystems’ IHC and
ISH research experts for help with
instrument setup, applications
knowledge and responsive service.
•
Training and protocol development
• Applications advice
• Flexible maintenance contracts
Total Research
Create a total research solution
Because researchers need specialized
instruments and consumables,
Leica Biosystems supports you with
research-specific histology and
microscopy systems including:
•
Cryostats and microtomes
• Microscopes
• Scanning and imaging solutions
Leica BOND RX
Leica BOND RX
With over 12 million people diagnosed
with cancer every year*, new insights
that lead to better treatments will
significantly improve many lives.
The answers are there to be
discovered if the barriers to innovation
are removed.
You need the flexibility to explore new
possibilities, clear results to ensure
nothing is missed and rapid,
cost-effective systems that let you
perform more tests.
Clear the path to discovery and
life-changing breakthroughs become
closer than ever before.
Leica BOND RX is part of a complete research
solution that gives you the freedom to discover.
Research Use Only. Not for use in diagnostic procedures.
* GLOBOCAN 200 8
Cancer Incidence and Mortali ty Worldwide in 2008
Clarity and Accuracy Complete Consistency Total Tissue Care
Choose Novocastra BOND reagents to
make it easier to deliver high-quality
staining. Specifically developed for
Leica BOND using Leica’s in-house
Novocastra staining science,
these pre-optimized reagents
deliver exceptional performance
with minimal preparation.
No matter what reagents you choose,
the fully automated Leica BOND RX
will standardize your staining to
remove process variation and
deliver unrelenting consistency.
Leica BOND RX provides full onboard
IHC and ISH automation with both
Leica and laboratory protocols.
Protect valuable tissue. The unique
Leica BOND Covertile
™
system
provides the utmost care for valuable
specimens. Unlike other automated
stainers, Leica BOND has very gentle
reagent application and incubation
protection that minimizes the potential
for tissue damage and costly repeats.
Leica BOND RX
QUALITY
Make sure you see the whole picture. Leica BOND R X consis tently provides the high-quality
results that let you clearly analyze every stain so vital information is not overlooked, and
every section gets you one step closer to new insights.
Research Use Only. Not for use in diagnostic procedures.
Faster
Continuous
Ready for More
Finish slides earlier. Leica BOND RX
is 50% faster than previous
generation stainers. So you can
process more slides in a day,
gain a rapid understanding of the
possibilities of your latest trials, and
reach critical answers sooner.
Your work flows when you are
both flexible and organized. With
three independent slide trays, each
Leica BOND RX is effectively three
stainers in one instrument. So you
have the flexibility of continuous
processing while keeping your
slides together to reduce sorting.
As your research program grows, so
does Leica BOND. With the ability
to connect up to five Leica BOND RX
instruments to a single data collection
point, you are free to expand capacity
so your research never slows down.
Leica BOND RX
SPEED
Find answers sooner. With speed and organization, Leica BOND RX lets you stain more
slides daily. This gives you the freedom to explore more possibilities, test more theories,
and make that critical breakthrough sooner.
Research Use Only. Not for use in diagnostic procedures.
Truly Open
Fully Flexible
Cost Effective
Always use the antibodies, probes
and detection components that best
suit your research. Leica BOND RX
is a truly open system so you are
free to choose the reagents that
provide the most accurate results in
in the most cost-effective manner.
You are free to explore with the
easy-to-use Leica BOND RX software.
You can use Leica protocols for
pre-defined consistency, or freely
create your own custom protocols
when your research calls for
something special. New insights
require innovative thinking and with
Leica BOND RX you’re not locked
into conventional methods.
Control costs and do more
research with your existing budget.
Leica BOND RX requires virtually
no daily maintenance and has
extremely small reagent dispense
volumes so you can spend less time
and money on overheads, and more
on making critical discoveries.
Leica BOND RX
FLEXIBILITY
Eliminate barriers to discovery. Important research should never be held up by mandated
reagents. So Leica BOND RX has truly open reagents and allows protocol customization.
With Leica BOND RX dispensing your reagents in the sequence you choose, you are free
to uncover scientific breakthroughs faster, and more cost-efficiently.
Research Use Only. Not for use in diagnostic procedures.
System Specifications
Dimensions 775 mm (W) x 1359 mm (H) x 785 mm (D)
30.5 in (W) x 53.5 in (H) x 30.9 in (D)
Weight (dry) 246 kg
542 lb.
Slide capacity 30 slides
Finished trays (10 slides) may be replaced
continuously
Reagent container capacity 7 mL and 30 mL
Number of reagent containers 36 reagents
Bulk reagent container capacity 2 L or 5 L
Hazardous waste container capacity 5 L
Standard waste container capacity 2 x 5 L
Operating voltage 100 to 240 V~
Mains frequency 50/60 Hz
Power consumption 1200 VA
Maximum operating temperature 35 °C (95 °F)
Minimum operating temperature 5 °C (41 °F)
Temperature required to meet 18–26 °C (64–79 °F)
staining performance requirements
Operating humidity (noncondensing) 10 to 80% RH
Operating altitude 0 to 1600 m (5250 ft.) above sea level
Sound pressure level output (at 1 m) < 85 dBA maximum
< 65 dBA normal operation
Flexibility
1. Open Reagents
2. Custom Protocols
3. Covertile Technology
Quality
4. Continuous Processing
Leica BOND RX open containers
make loading and running your
reagents easy and cost-effective.
This truly open system lets you
choose antibodies, probes and
detection components from any
source.
Control dispense sequences,
incubation times and temperature
settings with the Leica BOND RX
protocol editor. This flexibility,
along with open reagents, gives
you complete freedom over your
IHC and ISH staining.
Unlike other systems,
Leica BOND RX is gentle on the
tissue and ensures total tissue
care with exceptionally low
dispense and waste volumes.
Leica BOND RX is effectively
three independent stainers in one
instrument - the ideal balance
of flexibility and organization.
Leica BOND RX
Speed
2
5
1
3
4
5. Parallel Automation
Inside Leica BOND RX there
are four very active robots
simultaneously moving, dispensing
and ensuring high throughput and
rapid turnaround.
Research Use Only. Not for use in diagnostic procedures.
www.LeicaBiosystems.com
TOTAL HISTOLOGY SOLUTIONS
High-quality IHC and ISH staining depends upon expert tissue preparation
and sectioning. With a broad range of histology instruments, consumables
and applications knowledge, Leica Biosystems offers research-specific
histology solutions that will help you efficiently prepare high-quality
sections for advanced staining.
· Tissue preparation
· Sample identification and tracking
· Tissue processors, cassettes and paraffin wax
· Embedding centers, accessories and paraffin wax
· Microtomes, blades and slides
· Coverslippers, mountants and coverslips
· Microscopy and imaging solutions
· Expert service and support
· Ongoing maintenance support
LEICA BIOSYSTEMS
Leica Biosystems is a global leader in workflow solutions bringing
histopathology laboratories and researchers the highest quality, most
comprehensive product range in anatomical pathology. With complete
histology systems featuring innovative automation, Novocastra
reagents and Surgipath
®
consumables, Leica Biosystems offers the ideal
TM
product for each histology step and high-productivity workflow solutions
for the entire laboratory.
Leica Biosystems – an international company with a strong network of
worldwide customer services:
Nor th America S ales and Customer S uppor t
Nor th America 80 0 248 012 3
Asia /Pacific Sales and Cus tomer Support
Australia 180 0 625 286
China +8 5 2 2564 66 99
Japan +81 3 5421 2804
South Korea +8 2 2 514 65 43
New Zealand 08 00 40 0 58 9
Singapore +6 5 6779 7 823
Europe Sales and Cus tomer Support
For de tailed contact infor mation abou t European sales of fices or distributors please
visi t our websit e.
Leica Biosystems brings
together products, quality and
support. Offering a complete
solution that helps you advance
workflows, enhance diagnostic clarity and
deliver what really matters – better patient care.
Use your smart phone to find out
more about Leica BOND RX .
Download the free mobile app at
http:/ /gettag.mobi, then scan this tag.
95.10599 Rev B - Order no. 1195.10599 · 09/2012 · Copyright © by Leica Biosystems
Melbourne Pty Ltd, Melbour ne, Australia, 2 012. Subject to modifications. L EICA and the
Leica L ogo are registered tr ademarks of Leica Microsystems IR GmbH.
