La Marzocco 3MP Installation Manual

MP

Operating & Software Manual

Strada

Table of Contents

Strada MP - Operating Manual

Table of Contents ...........................................................................................................................................................................1

General Warnings and Safety Specications........................................................................................................................ 2

Denition of Model .......................................................................................................................................................................4

Installation........................................................................................................................................................................................ 6

Operating the Espresso Machine and Preparing Coee.................................................................................................. 7

Preparing Other Hot Drinks.........................................................................................................................................................9

Preventative Maintenance and Weekly Cleaning...............................................................................................................10

De-Commissioning and Demolition......................................................................................................................................11

English

NOTE: The Software Programming Manual follows the Operating Manual

www.lamarzocco.com V1.0

*HQHUDO:DUQLQJVDQG6DIHW\6SHFL¿FDWLRQV

1) This operating manual is an integral and essential part of
the product and must be supplied to users. Users are asked
to read the enclosed warnings and cautions carefully, as
they provide valuable information concerning safety during

English

installation, operation and maintenance. This manual must
be kept in a safe place and be available for consultation to
new and experienced users alike.

2) Ensure product integrity by inspecting the packaging, making
sure it presents no signs of damage which might have affected
the enclosed machine.

3) Check the machine’s integrity after having carefully removed
the packaging.

Note:

In case of doubt, do not go on any further and contact your dealer
or retailer immediately. They will send out specialized personnel
authorized to perform service on the espresso machine.

4) Packaging (boxes, plastic bags, foam parts and whatever
else) must not be left around within easy reach of children,
due to the potential danger it represents, nor be discarded in
the environment.

5) Check to see that data on the rating plate corresponds to
those of the main electrical supply which the machine will be
hooked up to.

6) Installation must be performed according to local electrical
and plumbing codes and regulations. Installation must also
comply to manufacturer instructions, and must be performed
by Tuali¿ed and authorized personnel.

12) Using any electrical device requires that certain fundamental
rules be observed. In particular:

- do not touch the device with wet or humid hands and feet;

- do not use the device while having no shoes on your feet;

- do not use extension cords in bath or shower rooms;

- do not unplug the device from the power outlet by pulling on the power

supply cable;

- do not expose the device to atmospheric agents (rain, sun, etc.);

- do not allow children or untrained personnel to use this device.

13) Before carrying out any maintenance and/or cleaning
operation, turn the main switch, which is located on the front
left of the machine, to the “0” or OFF position, and disconnect
the machine from the electrical network by unplugging the
cord or by switching off the relative circuit breaker. For any
cleaning operation, follow the instructions contained in this
manual only.

14) In case the machine is operating in a faulty manner or breaks
down, disconnect it from the electrical network (as described
in the preceding point) and close the water supply valve. Do
not attempt to repair it. Contact a quali¿ed and authorized
professional to perform any repair. Any repairs must be
performed exclusively by the manufacturer or by an authorized
centre using only original parts. Non compliance with the
above could compromise the safe operation of the machine.

15) <ou should plan to make use of a speci¿c connector during
installation, as required by local, national, and international
electrical codes and regulations.

16) In order to avoid dangerous overheating problems, it is
recommended that the power supply cable be fully unfurled.

7) Incorrect installation may cause injury/damage to people,
animals or objects, for which the manufacturer shall not be
held responsible.

8) Safe electrical operation of this device will be achieved
only when the connection to the power outlet has been
completed correctly and in observance of all local, national,
and international electrical codes and safety regulations,
and particularly by grounding the unit. Make sure grounding
has been done properly as it represents a fundamental
safety reTuirement. Ensure Tuali¿ed personnel check such
connection.

9) Furthermore, you must ensure that the capacity of the
available electrical system is suitable for the maximum power
consumption indicated on the espresso machine.

10) We do not recommend using adapters, multiple plugs and/
or extension cords. If you cannot avoid using them, make
sure that they are exclusively of the kind which conforms to
local, national, and international electrical codes and safety
regulations, being careful not to exceed the power and current
ratings indicated on such adapters and extension cords.

11) This device must be used exclusively for the functions it
has been designed and built for. Any other application is
inappropriate and dangerous.

17) Do not obstruct air intake and exhaust grilles and, in particular,
do not cover the cup warmer tray with cloths or other items.

18) The machine’s power supply cable must not be replaced by
users. In case the power supply cable becomes damaged,
shut off the machine and disconnect the machine from the
electctrical network by switching off the relative circuit breaker
and close off the water supply; to replace the power supply
cord, contact quali¿ed professionals only.

WARNING

THIS EQUIPMENT MUST BE INSTALLED TO COMPLY WITH THE
APPLICABLE FEDERAL, STATE, OR LOCAL PLUMBING CODES

The manufacturer shall not be held responsible for any
damages caused by improper and/or irrational use.

2

La Marzocco, S.r.l. Scarperia, Firenze, ItaliaV1.0

Strada

'H¿QLWLRQRI0RGHO

This operating manual refers exclusively to the below model, of our own manufacture:

Strada 3 group Mechanical Paddle: 3MP

1) Common Dimensions, Weights, and Features

English

Weight: Kg. 90

5

2

9

8

1

4

12

4

Legend

1) Main Switch

2) Pressure Gauge (Steam Water)

3) Pressure Gauge (Brew Water)

4) Brew Groups

5) Encoder

6) Hot Water Switch

7) Digital Display

8) Steam Wand

9) Steam Knob

12

4

12

7

1

6

10

11

10) Hot Water Wand

11) Removable Drain Tray

12) Manual Brew Paddle Lever

13) Hot Water Mix Valve

For additional information on electronics, and software
programming, please see the section entitled Software
Programming.

9

13

8

www.lamarzocco.com V1.0

3

La Marzocco, S.r.l. Scarperia, Firenze, Italia

'H¿QLWLRQRI0RGHO

V

2)

c

:

)

3)

r

:

000

r

:

800

e

s

coff

cup(s) af

r

c

S

:

)

)

)

eleme

y

coffee is brewed

f

g:

T

y

g

.

General Description

The machine is built in a 3 group version and is essentially

omposed of the following parts

1) Steam Boiler (produces steam and hot water

English

2) 3 Coffee (“saturation”) boilers

3) Brewing groups

4) Exterior Cover
Water pump/s

Description of the various parts

team Boile

The Steam Boiler consists of a cylindrical tank made of AISI
300 series stainless steel. Each unit is subject to a hydraulic
test, at a pressure of 6 bar, and has an operating pressure
of 1.3-1.5 bar. The following is a list of effective volumes and

ower ratings according to the number of groups installed

3 groups11 liters 4

overs are installed at either end of the cylindrical tank and
on one of them there is housing for the water heating element,
which allows the steam boiler to reach operating pressure within
approximately 25 minutes. Operating pressure is maintained
by temperature probe. The steam boiler has various ¿ttings

sed for safety devices, for supplying hot water and steam,

and for the heating element.

offee Boile

The Coffee Boiler consists of a cylindrical tank made of AISI

series stainless steel. Each unit is subject to a hydraulic
test, at a pressure of 18 bar, and has an operating pressure
of 9 bar. The following is a list of effective volume and power

atings according to the number of groups installed

3 groups - 3 x 1,3 liters 3 x

overs are installed at either end of the cylindrical tank

and on one of them there is housing for the water heating

lements. The temperature of the coffee boiler is maintained
by an electronic temperature controller
accuracy of 0.2°C. The brewing groups are installed on the

iler.

Brewing Group

They consist of precision casting made of stainless steel. The
brewing group accepts the porta¿lter used to hold the ground

ee; the water Àows through the brewing group, through the

orta¿lter basket, through the porta¿lter spout, and into the

ter brewing has been activated.

Watts

Watts

PID capable) with an

Exterior Cove

It consists of a stainless sheet steel body. The structure has
been the object of speci¿c studies to provide good aesthetics,

ower ergonometric costs for the operator and reduce the

hance of damage to a minimum.

ater Pump

The water pump is a differential pressure, “positive­displacement” type installed on the water supply tubing and
is set-up to operate anytime the coffee groups are activated,
and through an electric level gauge whenever the steam boiler

eeds to be replenished.

ound Pressure

The weighted sound pressure level of the machine is lower
than 70dBA.

CONSTRUCTION DETAIL

They consist essentially of 2 small boilers, of which

1) Coffee Boiler (hot water generator for brewing coffee

2) Steam Boiler (steam generator for producing steam and hot
water for making tea and other hot drinks

1) Description of the Coffee Boiler (C.C.

omposed of an AISI 300 series stainless steel tube.
eating is accomplished through an immersion-type plated heating

nt.

-Operating temperature 95 (adjustable), controlled automaticall
by an electronic temperature controller with an accuracy of 0.2

perating pressure of 9 bar, developed mechanically by a special

ositive-displacement pump which is activated automatically every

time

-Pressure is displayed through a pressure gauge with a scale
rom 0 to 15 bar.

-Safety device, based on an expansion type mechanical valve,

with counteracting spring adjusted to 12 bar.

-Testin

-Hydraulic test at 18 bar performed on ready-to-use small boilers,

at our factory;

.

WARNING

his equipment must not be used by children, mentall

or physically challenged individuals or anyone lackin

necessary know-how unless supervised

specialized personnel

.

4

1.0

Strada

3. Installation

2) Description of the Steam Boiler (C.V.)

Composed of AISI 300 series stainless steel tube.
Heating is accomplished through an immersion-type plated
heating element.

-Operating pressure of 1.3-1.5 bar, controlled automatically
through a pressure switch or a temperature probe, adjusted to
open the heating element supply circuit at 1.5 bar and close it
at 1.3 bar.

-The pressure is displayed by means of a pressure gauge with
a scale of 0 to 2 bar.

-Safety device, based on an expansion type mechanical valve,
with counter-acting spring adjusted to 1.8 bar.

-Testing:
a) hydraulic test at 4.5 bar performed on ready-to-use small
boilers, at our factory;

WARNING

The Coffee Boiler and Steam Boiler contain water at elevated

temperature. Water temperature over 125° F / 52° C can

instantly cause severe burns or death from scalding.

(Coffee Boiler 200° F / 93.3° C - Steam Boiler 260° F / 127° C)

English

WASTE/DRAIN

ADDITIONAL
WATER PUMP
MOTOR POWER
CORD

WATER PUMP
MOTOR POWER
CORD

WATER PUMP

AND MOTOR

BRAIDED HOSE

OPTIONAL

WATER PUMP

AND MOTOR

MAIN SWITCH

AND ELECTRICAL

SUPPLY

CONNECTION

POWER SUPPLY

CORD

BRAIDED HOSE

MAIN WATER

SUPPLY VALVE

WATER

FILTRATION/

SOFTNER

WATER PUMP

AND MOTOR

www.lamarzocco.com V1.0

5

La Marzocco, S.r.l. Scarperia, Firenze, Italia

T

D

according to current local, national and

.

. Installation

are

uded:

t

ge

p

g

f

:

)

connectio

)

e

e

c)

f

c

°C

°C

y

2)

s

gppp ,

pp \ \

\ p g

in taps or YaOYes thus preYenting them from worNing properO\

p p g gp p \

s

c

3)

a)

e

.

e

connecto

3)

s

.

c

e

s

W

G

M

G

.

p

T

T

N

1) Acessories

WARNING

ARNIN

WARNING

At each installation, the machine should be equipped with a new set

English

heck the package to make sure that the following accessories

incl

 1 x SINGLE and 3 x DOUBLE porta¿lters
 2 x SINGLE and 4 x DOUBLE ¿lters
 1 x tamper
 1 x blind ¿lter
 1 x cleaning detergen
 3 x stainless steel braided hose for water connections
 1 x 1,5 mt of reinforced plastic tubing for draina
 1 x hose clam
 1 x TEE Fittin

In order to proceed with installation, it is necessary that the

ollowing are available

a

b

spresso machine purchased: 200/220/380/VAC - 50/60Hz
lectrical connection with ground, protected socket and

approved circuit breaker.

OTE:

The drinking water stopcock and the terminal switches

or the electrical system need to be located in the most

and quickly.
The machine should be placed on a Àat counter and must
be placed in settings with the following temperatures:

If the machine has been temporarily housed in settings with
a room temperature of less that 0°C, the machine must
be placed in a warmer environment in order to graduall
defrost the hydraulic system prior to use.
Water pressure supply must be between 2 and 6 bar.

ater Supply Connection

onnect the inlet of the water ¿lter/softener to the drinking water

upply using one of the supplied stainless steel braided hoses.

onnect the water supply connection of the espresso machine

to the water pump outlet using one of the supplied stainless

teel braided hoses. Then connect the water pump inlet to the

water ¿lter/softener outlet.

OTE: The water pump is a differential pressure, volumetric

ump and has been designed to be used exclusively with cold
water. Make sure that water is always present while the pump is
operating, otherwise air can be introduced into the brew boiler

ausing an undesirable condition.

of tubes for plumbing and related gaskets

Pipes carrying drinking water with a 3/8”G (BSP) end

n.

Electrical Supply according to the speci¿cation of the

Indirect waste water drain system.

onvenient position for the operator to access them easily

inimum room temperature: 5
aximum room temperature: 32

Electrical Connections

ower Supply Cord

This is the main power supply cable that provides power to the

ntire espresso machine. There are different types of cable

based upon the electrical requirements of the espresso machine

urchased.

CAUTION

Before making any electrical connections make sure that

WKHVWUDLQUHOLHIFRQQHFWRUVDUH¿UPO\VHFXUHGWRWKH

ody of the machine in order to prevent inadvertent

b)Water Pump Motor Power Cord

This is the power supply for the water pump motor. The internal

lectronics will switch the pump motor on when needed.

-core cable with 1.5 mm2 cross section (CE) or 3-core AWG 16
or UL version) secured to espresso machine via a strain relief

r.

stress on the power cables

WARNING

HE MOTOR PUMP MUST BE SITUATED

CLOSE TO THE MACHINE IN AN ACCESSIBLE

LACE FOR MAINTENANCE BUT NOT FOR

ACCIDENTAL INTEFERENCE AND WHERE

HERE IS OPTIMAL AIR CIRCULATIO

Waste Water Drain Connection

The espresso machine drain is to be connected by means of
the included reinforced plastic tubing. Connect one end of the
reinforced plastic tubing to the drain hose connection on the left

ide of the espresso machine. Secure with included hose clamp.

onnect the other end to a suitable waste water collection system

In case such a system is not available, drained liquids may be

ollected in a suitable bucket and any necessary drain pipe
xtensions should be made using steel-lined PVC tubing and
uitable hose clamps.

WARNING

he manufacturer declines any responsibility for any event

eading to liability suits whenever

BEEN COMPLETE

nternational regulations and electrical codes, and/or in lack of

roperly connected electrical parts

ROUNDING has NOT

WARNING

.S.A. and Canada Only-

o Not Connect To A Circuit Operating At More Than

150 V To Ground

WARNING

HAZARDOUS VOLTAGE! DISCONNECT FRO

OWER SUPPLY BEFORE SERVICIN

1.0

Strada

2SHUDWLQJWKH(VSUHVVR0DFKLQHDQG3UHSDULQJ&RIIHH

1) Starting the Espresso Machine

Filling the Boilers with Water

Once the installation procedures have been completed, it is
necessary to ¿ll the boiler tanks with water. Complete the following
procedure to properly ¿ll the boiler tanks:

 Coffee Boiler

The water Àows inside the coffee boiler directly, as soon as the
water system and water ¿lter/softener valves are opened.
Since the inÀow of water will compress the air in the boiler, it
will be necessary to remove or “bleed” the air from the coffee
boiler. All air must be removed in order to completely “saturate”
the coffee boiler/group assemblies.
To remove the air from the boiler, or “bleed the groups”, it will be
necessary to remove the plastic cap from the top of the group.

Loosen the bleed screws one at a time (see picture above) to
allow air to escape until water Àows from below the screw head.
Tighten the screw to stop the water from Àowing. Over tightening
can cause damage to the sealing washer and the group cover.
Repeat this procedure on all groups.

2) Waiting for the Espresso Machine to Heat to Operating
Temperature

During this time, it may happen that the pointer of the coffee boiler
pressure gauges reaches as high as 14-15 bar. This may happen
anytime that the heating element is in the “on” condition. In this
case, it is necessary to adjust the expansion valve in such a way
that the pressure never exceeds 11-12 bar. In normal operating
conditions, the coffee boiler pressure gauges can read anywhere
from 0-12 bar. When brewing, the pressure should be set to 9 bar.
When the steam boiler reaches operating temperature, the light
on the Tea dispense button will switch on.

English

 Steam Boiler

Turn the main switch to position “1” or ON, then push the encoder
knob for three seconds and the automatic steam boiler level
function will be switched on, activating the auto-¿ll solenoid
valve and the motor pump. This will ¿ll the steam boiler to a
predetermined level and will shut off when full.

Note: Air inside the steam boiler may build up pressure (which
may be detected through the pressure gauge).
Once the pump stops, check the display, the message “Coffee
Boiler Filled?” should be displayed. Push the Encoder Knob to
con¿rm that the preceding procedures are complete.
The installation is now complete and the espresso machine should
be heating to operating temperatures.

Expansion Valve

,QVWDOOLQJWKH3RUWD¿OWHUV

Install the porta¿lter(s) by inserting them into the group and rotate
the handle from left to right. When the porta¿lters are inserted
properly, you can press any of the brew buttons to start the Àow of
water through the porta¿lter. You should allow hot water to pass
through the porta¿lter(s) for a few seconds each time, in order to
pre-heat the porta¿lter.

Filter
Basket

Basket

Spring

Portafilter

O-ring

Double
Spout

Encoder

Display

www.lamarzocco.com V1.0

Note: It is important to leave the porta¿lters installed in the
espresso machine when not in use. The porta¿lter must remain
heated for the brew process to function correctly.

7

La Marzocco, S.r.l. Scarperia, Firenze, Italia

2SHUDWLQJWKH(VSUHVVR0DFKLQHDQG3UHSDULQJ&RIIHH

4)

q

sof

g

g

:

f

s

e

T

g.

Brewing Coffee with/out Pre-Infusion

It is now possible to remove one of the porta¿lters to make
an espresso beverage. Place some ground coffee in the ¿lter
itself: 1 dose (approximately 7 g) for the small ¿lter, 2 doses

English

approximately 14 g) for the larger ¿lter.

Press down on the ground coffee with the supplied tamper and
install the ¿lter holder to the bottom of the group. Move the paddle
to begin the brewing process. Mechanically control water and

ressure Àow through an internal valve to obtain superior cup

uality traditionally achieved with “lever” machines. Manual pre­infusion allows you to bring out different Àavor components which
affect the balance and body of the shot, and produce rounder,

ter espresso that highlights brightness, sweetness and delicates

te.

WARNING

RQRWUHPRYHWKHSRUWD¿OWHUZKHQLWVUHDOWLYHJURXSLVEUHZLQJKRW

iquids. The Coffee Boiler contains water at elevated temperature.

Water temperature over 125° F / 52° C can instantly cause severe

urns or death from scaldin

off pre-brewin

Note

ome baristas suggest Àushing the group with water to remove

emaining coffee oil or particles. Some Àush after every shot.

Experimentation and practice is suggested to establish the best

ossible procedure for brewing coffee.

5)eneral Notes for Coffee Preparation

The pota¿lters must remain heated since they are partially isolated

rom the group due to the rubber gasket between them. This can be
accomplished by leaving the porta¿lters installed on the machine
when not in use. The porta¿lters may also be actively heated.
This procedure may be carried out by activating one of the brew
buttons to Àush hot water through the porta¿lter then turning off
the water Àow.

ther than the type of coffee blend being used, naturally, the size
of the coffee granules is extremely important in the preparation of
a good cup of coffee. Ideal grinding can be determined by making
various coffees using the amount of ground coffee that you would

ormally use for each cup (we recommend at least 6g). The most
uitable grinding allows coffee to Àow gradually from the ¿lter
older spout - neither too slowly, nor too quickly. A general rule is

that a double dose should dispense approximately 2 Àuid oz. of

spresso in approximately 25 seconds.

brewin

IMPORTAN

To improve Àavor, the temperature of water in the coffee boiler,
which has a direct impact on the groups, may eventually be
increased or reduced via the digital display (please consult the

oftware Programming Manual for detailed instructions).

1.0

Strada

1) Steaming Milk or Other Liquids

Dip one of the 2 steam wands (part 8, page 3) which are connected
to the steam valve, into the liquid to be heated. Turn the steam
lever on gradually until steam is released at the end of the wand.
The steam will heat the liquid and raise its temperature.
To avoid severe burns, do not allow any liquid to overÀow.

In order to successfully foam milk , please follow these steps:
 Place the pitcher that is partially ¿lled with milk under the steam
wand. Open the steam valve and bring the temperature of the milk
to nearly 149/158° F 65/70° C.
 Lower the pitcher so that the wand tip is just below the surface
of the milk; at this point, move the container up and down just
enough to dip the nozzle end in and out of the milk until you get
the right amount of foam. Gradually pour the foamed milk over
warm espresso for a fresh cup of cappuccino.

In order to prevent heated liquid from being sucked back
into the steam boiler, it is recommended that the steam
valve and steam wand be purged by opening the valve for
a few seconds to allow steam to escape from the end of
the steam wand. Failure to do so can cause heated liquid
to be transferred from the pitcher to the steam boiler (due
to a vacuum created by cooling parts). This condition is
undesirable and can contaminate the steam boiler.

5. Preparing Other Hot Drinks

English

2) Preparing Tea and Other hot Drinks.

You may dispense hot water by using the ¿xed nozzle (part 10,
page 3). To dispense hot water, press the tea water button.

This button commands hot water delivery.
The temperature of the water may be adjusted by adjusting the
mixing valve.

www.lamarzocco.com V1.0

9

0

La Marzocco, S.r.l. Scarperia, Firenze, Italia

c

p

diffuser scree

8) Water Filter/Softener

)

/

sof

g

3UHYHQWDWLYH0DLQWHQDQFHDQG:HHNO\&OHDQLQ

J

7

c

.

T

f

y.

g.

s



f

g

3)

4)

y

Àavor of other d

be

WARNING

KHPDFKLQHPXVWEHLQVWDOOHGVRWKDWTXDOL¿HGWHFKQLFDOSHUVRQQHO

an easily access it for eventual maintenance

English

CAUTION

he machine must not be dipped in, nor splashed with

water while cleaning. For cleaning operations, please

ollow the instructions listed below very carefull

1) Cleaning groups and drain wells

- Put a tablespoon of detergent powder for coffee machines into
the blind ¿lter, supplied with the machine, and attach it on the

roup to be cleaned.

WARNING

RQRWUHPRYHWKHSRUWD¿OWHUZKHQLWVUHDOWLYHJURXSLVEUHZLQJKRW

iquids. The Coffee Boiler contains water at elevated temperature.

Water temperature over 125° F / 52° C can instantly cause severe

urns or death from scaldin

- Turn the Paddle Valve on and off approximately 10 times (10

econds intervals) on each group.

- Rinse the group using a normal ¿lter by running hot water through
it several times.

&OHDQLQJ¿OWHUVDQG¿OWHUKROGHUV

- Put 2 or 3 teaspoons of detergent powder for coffee machines
in about 1/2 a litre of VERY HOT water.

- Dip ¿lters and ¿lter holders in the heated solution and leave them

ully submerged for about 10 minutes.

- Rinse thoroughly with clean water and run hot water through one

roup several times with the ¿lters in place.

- Make one cup of coffee and discard in order to remove any

npleasant Àavor.

leaned periodically with a damp cloth.

6) Cleaning the Diffuser Screen

Due to porta¿lter discharge operations (subsequent to coffee
brewing), a certain amount of coffee grounds may slowly build-u

GROUP

ASSEMBLY

DIFFUSER

SCREEN

DIFFUSER

SCREW

and even partially obstruct the diffuser screen.
To clean it, ¿rst unscrew the diffuser screw, then remove the

n.
Put 2 or 3 teaspoons of cleaning detergent for coffee machines in
about 1/2 a litre of water inside a heat-resistant container and heat.
Place the diffuser screen(s) and diffuser screw(s) in the solution
and leave them fully submerged for about 10 minutes.

inse thoroughly with clean water. Install and run hot water

through each group several times with the screen installed.

7) Water Pump

When brewing coffee, and you can adjust pump pressure by turning
the by-pass screw clockwise to increase and counter-clockwise to

educe pressure. Adjust pressure only when one or more groups

are brewing coffee.

Please see the documentation accompanying the water ¿lter

tener for proper operating and cleaning instructions.

Cleaning the drain collector

emove the drain tray daily and clean.

Inspect the drain well also, and wash away any leftover grounds.

Cleaning the bod

Wipe the stainless steel surfaces with a soft, non abrasive cloth.
Do not use any alcohol or solvents whatsoever on painted or
decorative parts to avoid damage.

5) Cleaning the hot water and steam nozzles

team nozzles must be cleaned immediately after use with a
damp cloth and by producing a short burst of steam to prevent
the formation of deposits inside the nozzles, which may alter the

rinks to be heated. Hot water nozzles must

1

1.0

Strada

1) De-Commissioning and Demolition

Start by setting the main switch to the “0” or OFF position.

Disconnecting from the power outlet

Disconnect the espresso machine from the electrical network by
switching off the associated circuit breaker or circuit protection
device. Remove the power supply cord from the power connection.
Remove the Pump Motor Power Cord from the water pump motor.

Disconnecting from the water system

Shut off the water supply by closing the speci¿c valve located
upstream of the water ¿lter/softener inlet. Disconnect the water
pipe at the water ¿lter/softener inlet. Remove the hose connecting
the espresso machine to the water pump. Remove the reinforced
plastic tubing on the drain connection.

At this point, the machine may be removed from the bar, being
very careful not to drop it or crush your ¿ngers.

The machine is made out of various materials and therefore, if
not intended for further service, should be delivered to a recycling
center which will select materials to be recycled or discarded.

7. De-Commissioning and Demolition

English

Current regulations make it illegal to discard the machine by leaving
it on public grounds or on any private property.

Recycling notice:
Warning for the protection of the environment.

Old electrical equipment is made of valuable materials, it is not
normal domestic waste! We kindly ask that our clients contribute

to the protection of the environment
and natural resources by delivering this
equipment to a recycling center, if such
centers are present in any one speci¿c
territory.

www.lamarzocco.com V1.0

11

Strada

Strada MP - Software Programming Manual

Table of Contents ............................................................................................................................................................................1

Strada Programming Introduction .......................................................................................................................................... 2

Accessing Programming Mode ................................................................................................................................................ 3

Description of the Programming Levels ............................................................................................................................... 4

Start Up Procedure ....................................................................................................................................................................... 6

English

www.lamarzocco.com V1.0

Strada Programming Introduction

Description

 The 6trada espresso machine has a very functional

English

CPU with many programmable settings.

 Additionally, there are many feedback controls to

troubleshoot problems that may occur.

 The following is a brief introduction to the controls

and display and how they interact with the operator.

Digital Display

The digital display is a backlit screen capable of displaying 2 lines with 16 characters each. The display
enables the operator to interact with the espresso machine to change parameter values. The display also
provides valuable information to the operator. There are several warnings that can be displayed to alert
the operator of an unusual condition or fault. Additionally, simple messages are displayed alerting the
operator that an action has been started or that a process needs to begin.

Programming Encoder

The encoder knob is always located on the left of group one. By turning it to the right it is possible to
increase the value. By turning it left, it is possible to decrease the value and by pushing it down, it
is possible to scroll through the software menu, enter functions or con¿rm ¿rst installation.

It is possible to turn on/off the Strada coffee machine by pushing and holding the Encoder
knob for 3 seconds.

2

La Marzocco, S.r.l. Firenze, Scarperia, ItaliaV1.0

Strada

Description

Accessing Programming Mode

Programming Mode

English

 To change any con¿gurable parameter the operator

must ¿rst enter the programming mode.

 There are three levels of the programming mode that

allow modi¿cation to speci¿c parameters, depending on
the sequence that is followed

The three programming levels are as follows:

 Barista /evel  1o Password 1ecessary. /imited

parameters are available.

 Technical /evel  Barista level parameters plus

additional parameters are available.

 )actory /evel  )actory password needed. Barista

/evel and Technician level parameters plus additional

parameters are available.

www.lamarzocco.com V1.0

3

Description of the Levels

English

Programming sequence

Barista Menu

Operating Procedure: with the coffee machine on,

press and hold the encoder knob for 5 seconds and
the Barista /evel menu will appear.

Technical Menu

Programming 6equence

Operating Procedure: )irst hold the knob for 3 seconds

to achieve the O)) status, then realease it and press
and hold it again for an additional 5 seconds. The
Technician /evel menu will appear.

t Coffee Boiler 1 6witching onoff
t Coffee Boiler 2 6witching onoff
t Coffee Boiler 3 6witching onoff
t Coffee Boiler 1 Temperature
t Coffee Boiler 2 Temperature
t Coffee Boiler 3 Temperature
t 6team Boiler Temperature
t Clock Adjust
t Auto 2n2ff

t /anguage
t Temperature 0easurement Units )  C
t User name
t Coffee Boiler 1 Temperature
t Coffee Boiler 2 Temperature
t Coffee Boiler 3 Temperature
t 6team Boiler Temperature
t Clock Adjust
t Auto 2n2ff
t Cup Heating
t Pumps 6etting for Automatic )ill
t 6team Boiler Automatic )ill
t Pump 6etting for Tea :ater
t Coffee Boiler 1 Temperature Offset
t Coffee Boiler 2 Temperature Offset
t Coffee Boiler 3 Temperature Offset
t Total Doses
t )ilter Alarm

4

La Marzocco, S.r.l. Firenze, Scarperia, ItaliaV1.0

Strada

Programming 6equence

Description of the Levels

Factory Menu

Operating Procedure: )irst hold the knob for 3 seconds

to achieve the O)) status, then realease it and press
and hold it again for 15 additional seconds. The
)actory /evel menu will appear.

t 0achine *roup 1umber
t Coffee Boilers Proportional, ,ntegral, derivative P,D 6etting
t Coffee Boilers P,D 6tart
t Coffee Boiler 1 Heating Timeout
t Coffee Boiler 2 Heating Timeout
t Coffee Boiler 3 Heating Timeout
t 6team Boiler Heating Timeout
t 6team Boilers Proportional, ,ntegral, derivative P,D 6etting
t 6team Boiler P,D 6tart
t 6team Boiler /evel Probe 6ensitivity
t 6team Boiler /evel Probe Delay
t 6team Boiler /evel Timeout
t /anguage
t Temperature 0easurement Units )  C
t User 1ame
t Coffee Boiler 1 Temperature
t Coffee Boiler 2 Temperature
t Coffee Boiler 3 Temperature
t 6team Boiler Temperature
t Clock Adjust
t Auto OnOff
t Cup Heating
t Pumps 6etting
t 6team Boiler Automatic )ill
t Pump setting for Tea :ater
t Coffee Boiler 1 Temperature Offset
t Coffee Boiler 2 Temperature Offset
t Coffee Boiler 3 Temperature Offset
t Total Doses
t )ilter Alarm

English

www.lamarzocco.com V1.0

5

Start Up Procedures

English

Description

 The following is the procedure for turning on the

espresso machine.

 Please follow the procedures carefully to avoid any

damage.

Turning the Espresso Machine On!

Display Operating Procedure

Turn the 0ain 6witch to the On position. O1 1, Off 

1

The message at left will be displayed brieÀy. This message indicates the revision level of the
software installed in this espresso machine.

The espresso machine is now O1 and information concerning the boiler and heating elements
will appear..

! !

WARNING

HAZARDOUS VOLTAGE! DISCONNECT FROM

POWER SUPPLY BEFORE SERVICING

6

La Marzocco, S.r.l. Firenze, Scarperia, ItaliaV1.0

Strada

Description

Start Up Procedures

Turning the Espresso Machine Off

 The following is the procedure for turning off the

espresso machine.

 Please follow the procedure carefully to avoid any

damage.

 This machine has two off settings. One setting turns

off all components of the espresso machine and the
other turns off power to the entire espresso machine.

Display Operating Procedure

The following is the procedure for safely turn off the espresso machine.

1

Press and hold the Encoder Knob for 3 seconds. The display changes to the following:

2

English

This is the O)) setting used in normal operating conditions.

3

The main switch should be turned to the O)) position during servicing or other conditions

4

requiring the O)) position.

! !

HAZARDOUS VOLTAGE DISCONNECT FROM

POWER SUPPLY BEFORE SERVICING

www.lamarzocco.com V1.0

WARNING

7

LA MARZOCCO SRL
Via La Torre, 14/H
Località La Torre
50038 Scarperia
(Florence) - ITALY
T. [phone]
F. [phone]
[e-mail]
www.lamarzocco.com
