La Crosse Technology WS-9004U User Manual
WS-9004U
915MHz
WIRELESS RAIN GAUGE
INSTRUCTION MANUAL
CONTENTS
03 introduction
03 features
04 setting up
06 function keys
07 operations
08 maintenance
09 specifications
09 liability disclaimer
10 warranty information
2
INTRODUCTION
r
r
Thank You and Congratulations on your purchase of this innovative Wireless
Rain Gauge for display of rainfall data through a wireless rainfall sensor. With
2 easy to use function keys, this unique product is perfect for gardeners and
weather buffs alike.
This product offers:
INSTANT TRANSMISSION is the state-of-theart new wireless transmission technology,
exclusively designed and developed by
LA CROSSE TECHNOLOGY. INSTANT
TRANSMISSION offers you an immediate
update (every 6 seconds!) of all your
outdoor data measured from the
transmitters: follow your climatic variations
in real-time!
Wireless Rain Gauge (Receiver)
Total
Rainfall
Light Rain &
Heavy Rain (shown)
Indicators
User Defined
Rainfall Alarm
Rainfall for
Past 24 Hours
Reset Total
Rainfall, Set Ala
m
Low Battery Indicato
View Alarm,
Enter Alarm
Setting
FEATURES
• 915 MHz Instant Data Transfer: Updates every 6 seconds
• Rainfall for Last 24 Hours
• User Defined Alarm for the past 24H Rainfall
• Current Rainfall Indicator, Light Rain & Heavy Rain Indicators
• Low Battery Indicator for Both Receiver & Rain Sensor
• Wall Hanging or Free Standing
3
SETTING UP
r
Hint: Use good quality Alkaline Batteries; avoid rechargeable
batteries.
1. Have the receiver and the rain gauge 3 to 5 feet apart.
2. Place the batteries into the rain gauge FIRST and next into
the receiver. Observing the correct polarization, insert 2 “AAA”
Alkaline Batteries into the compartment at the back of the rain
gauge and replace the cover. Follow the same guidelines for
the receiver.
Rain Gauge
Rain Gauge
Cove
Press tabs back to
unlock Rain Gauge cover
Lift Rain Gauge cover to
access battery compartment
Remove battery cover
and insert batteries
4
