WS-7034U-IT
Wireless 915 MHz
Temperature Station
Instruction Manual
TABLE OF CONTENTS
Topic Page
Quick Setup 3-5
Inventory of Contents 6
Detailed Setup Guide
Battery Installation 7
Setting the Time 7-8
Selecting Units of
Measurement
Features
Minimum and Maximum
Temperatures
Resetting Minimum and
Maximum Temperatures
Adding additional remote
temperature sensors
(optional)
Mounting 12-13
Troubleshooting 14-15
Maintenance and Care 16
Specifications 17-18
Warranty Information 19-24
9
9-10
10
11-12
2
QUICK SETUP
Hint: Use good quality Alkaline
Batteries and avoid rechargeable
batteries.
1. Have the indoor temperature station
and remote temperature sensor 3 to
5 feet apart.
2. Batteries should be out of both
units for 10 minutes.
3. Place the batteries into the remote
temperature sensor first then into
the indoor temperature station.
(All remote temperature sensors must be
started before the indoor temperature
station)
4. DO NOT PRESS ANY BUTTONS
FOR 10 MINUTES.
In this time the indoor temperature
station and remote temperature sensor
will start to talk to each other and the
3
display will show both the indoor
temperature and an outdoor temperature.
If the indoor temperature station does
not display both temperatures after the
10 minutes please retry the set up as
stated above. After both indoor and
outdoor temperatures are displayed for
10 minutes you can place your remote
temperature sensor outdoors and set
your time.
The remote temperature sensor should
be placed in a dry, shaded area. The
remote temperature sensor has a range
of 330 feet. Any walls that the signal
will have to pass through will reduce
distance. An outdoor wall or window
will have 20 to 30 feet of resistance and
an interior wall will have 10 to 20 feet
of resistance. Your distance plus
resistance should not exceed 330 ft. in a
straight line.
4
NOTE: Fog and mist will not harm
your remote temperature sensor but
direct rain must be avoided.
To complete the set up of your indoor
temperature station after the 10 minutes
have passed please follow the steps on
pages 8-9.
INVENTORY OF CONTENTS
1.
2.
3.
4.
5.
The indoor temperature station (Figure
1)
The remote temperature sensor
(TX29U) and mounting bracket.
3 each, 1/2” Philips screws.
One strip of double sided adhesive tape.
Instruction Manual and Warranty Card.
5
ADDITIONAL EQUIPMENT
(not included)
1.
1 Philips screwdriver.
2.
2 Fresh AAA Alkaline batteries.
3.
2 Fresh AA Alkaline batteries
DETAILED SETUP GUIDE
Battery Installation
1. Install 2 AA
batteries in the
remote temperature
sensor. Make sure
they do not spring
free, or start-up
Figure 1
6
problems may occur.
2.
Install 2 AAA
batteries in the
indoor temperature
station. Do not
press any buttons
for at least ten
minutes.
Setting the Time
1.
Press and hold the
“SET” button for 5
second, “12h” will
appear in the TIME
LCD.
2.
Press and release the “MIN/MAX”
button to select either 12h time
(am/pm) or 24h time
3.
Press and release the “SET” button 2
times, the hour will flash in the upper
left corner.
4.
Press and release the “MIN/MAX”
button to set the hours
Battery
Cover
7
Press and release the “SET” button to
5.
move to the minute setting
6.
Press and release the “MIN/MAX”
button to set the minutes.
7.
Press and release the “SET” button to
activate the clock.
Note: When in 12h mode, there is only a
“PM” display, which appears under “TIME.”
If there is no display here it is AM. Make
sure you set the time accordingly.
Selecting Units of Measurement
1.
Press and hold the “SET” button for 5
second until “12h” or “24h” appears
in the TIME LCD.
2.
Press and release the “SET” button
again, “°F” will appear in the TIME
LCD.
3.
Press and release the “MIN/MAX”
button to shift between °F and °C.
4.
Press and release the “SET” button
twice to activate settings.
8
FEATURES
Minimum and Maximum Temperatures
1.
Press and release the “MIN/MAX”
button, “MIN” appears next to the
indoor and remote temperatures.
2.
The recorded minimum temperature is
displayed. The time of the minimum
outdoor temperature will also flash.
3.
Press the “MIN/MAX” button,
“MAX” appears next to the indoor
and remote temperatures.
4.
The recorded maximum temperature
is displayed. The time of the
maximum outdoor temperature will
also flash.
5.
Press and release the “MIN/MAX”
button to exit min/max mode.
6.
To view optional additional sensors,
press and release the “SET” button
while viewing the minimum or
maximum.
9
Resetting Min and Max Temperatures
To reset both the minimum and maximum
temperatures—press and hold the
“RESET/+” button for 4 seconds.
Adding Additional Remote
Temperature Sensors (optional)
The WS-7034U-IT is able to receive
signals from 3 different remote
temperature sensors. Following are some
brief instructions for the basic set-up of
remote temperature sensor units with the
WS-7034U-IT. These extra remote
temperature sensors can be purchased
through the same dealer as this unit, or
by contacting La Crosse Technology
directly.
When setting up multiple remote
temperature sensors, it is important to
remove the batteries from all existing
units in operation, then to insert batteries
10
first into all the remote temperature
sensors. Second install batteries into the
indoor temperature station and do not
press any buttons for ten minutes.
Transmission problems will arise if this
is not done correctly.
To view the temperature of a different
remote temperature sensor unit, press
and release the “SET/CH” button. A
shift from one number to the next should
be observed in the OUTDOOR LCD.
MOUNTING
Note:
To achieve a true temperature
reading, avoid mounting in direct sunlight.
We recommend that you mount the remote
temperature sensor on a North-facing wall.
The sending range is 330ft; obstacles such as
walls, concrete, and large metal objects will
reduce the range. Place both units in their
desired location before permanently
mounting.
11
Remote Temperature Sensor
1. Remove the mounting bracket from the
remote temperature sensor.
2. Mount the bracket in the desired
location with either screws or adhesive
tape.
3. Reattach the remote temperature sensor
into mounting bracket.
Indoor Temperature Station
The indoor temperature station comes with
the table stand already mounted. If you wish
to use the table-stand all that is required is to
place the indoor temperature station in an
appropriate location.
1. To wall mount the indoor temperature
station first remove the table stand.
2. Next insert an appropriate screw in
your desired location.
3. Using the integrated hanging hole on
the back of the unit, slip indoor
12
temperature station over the screw and
pull down to secure.
TROUBLESHOOTING
NOTE: For problems not solved, please
contact La Crosse Technology via e-mail or
phone, or visit our website,
www.lacrossetechnology.com
Problem: The LCD is faint
Solution: Replace batteries
Problem: No outdoor temperature is
displayed.
Solution:
1. Remove all batteries, reinsert into
remote temperature sensor first, then
into the indoor temperature station.
2. Place remote temperature sensor closer
to the indoor temperature station.
3. Be sure all batteries are fresh.
4. Place remote temperature sensor and
indoor temperature station in position
13
so the straight-line signal is not passing
through more than two or three walls.
Problem: Temperatures do not match if
units are placed next to each other.
Solution:
Each temperature sensor is manufactured to
be accurate to within 1 degree plus or minus
and under normal conditions, so two sensors
could be as much as 2 degrees different.
However, the difference can be exaggerated
further because the sensors are designed for
different working environments. The indoor
sensor is less responsive to ambient air
currents because of the shielding effect of
the display's case. In addition, the case can
act as a heat sink to absorb and store heat
from external sources (i.e. handling of the
case or radiant heat). Also, the much greater
range of the outdoor temperature sensor
requires a different calibration curve than the
indoor range. Error is usually greater at the
extreme ends of a range, making it harder to
compare different ranges with different
curves. Under non-laboratory conditions, it
14
is difficult to compensate for the above
factors and obtain an accurate comparison.
MAINTENANCE AND CARE
INSTRUCTIONS
• Extreme temperatures, vibration, and
shock should be avoided to prevent
damage to the units.
• Clean displays and units with a soft,
damp cloth. Do not use solvents or
scouring agents; they may mark the
displays and casings.
• Do not submerge in water.
• Do not subject the units to unnecessary
heat or cold by placing them in the
oven or freezer.
• Opening the casings invalidates the
warranty. Do not try to repair the unit.
Contact La Crosse Technology repairs.
SPECIFICATIONS
Transmitting
Frequency
915MHz
15
Measuring Temperatures
Indoor
Temperature
Station
Remote
Temperature
Sensor
Temp accuracy
Transmitting
range
Temperature check
Indoor Every 10 seconds.
Outdoor Every 4 seconds
Batteries—(Alkaline recommended)
Remote
Temperature
Sensor
Indoor
Temperature
Station
14.1°F to 139.82°F with
0.2 °F resolution.
(-9.9°C to 59.9°C with
0.1°C resolution).
-39.8 °F to 139.8°F with
0.2°F resolution.
(-39.8°C to 59.9°C with
0.1°C resolution).
+/- 1°F (+/- .5°C).
Maximum 330 feet
(100m) open space.
2 x AA, 1.5V
2 x AAA, 1.5V
16
Dimensions: (L x W x H)
Indoor
Temperature
Station
Remote
Temperature
2.36 x .88 x 5.90 in.
(excluding table stand)
(60 x 22.5 x 150 mm).
2.32 x 0.86 x 2.55 in.
(59 x 22 x 65 mm).
Sensor
Battery life Up to 24 months.
WARRANTY INFORMATION
La Crosse Technology, Ltd provides a 1-year
limited warranty on this product against
manufacturing defects in materials and
workmanship.
This limited warranty begins on the original date
of purchase, is valid only on products purchased
and used in North America and only to the original
purchaser of this product. To receive warranty
service, the purchaser must contact La Crosse
Technology, Ltd for problem determination and
service procedures. Warranty service can only be
performed by a La Crosse Technology, Ltd
authorized service center. The original dated bill
17
of sale must be presented upon request as proof of
purchase to La Crosse Technology, Ltd or La
Crosse Technology, Ltd’s authorized service
center.
La Crosse Technology, Ltd will repair or replace
this product, at our option and at no charge as
stipulated herein, with new or reconditioned parts
or products if found to be defective during the
limited warranty period specified above. All
replaced parts and products become the property
of La Crosse Technology, Ltd and must be
returned to La Crosse Technology, Ltd.
Replacement parts and products assume the
remaining original warranty, or ninety (90) days,
whichever is longer. La Crosse Technology, Ltd
will pay all expenses for labor and materials for all
repairs covered by this warranty. If necessary
repairs are not covered by this warranty, or if a
product is examined which is not in need or repair,
you will be charged for the repairs or examination.
The owner must pay any shipping charges incurred
in getting your La Crosse Technology, Ltd product
to a La Crosse Technology, Ltd authorized service
center. La Crosse Technology, Ltd will pay
ground return shipping charges to the owner of the
product to a USA address only.
18
Your La Crosse Technology, Ltd warranty covers
all defects in material and workmanship with the
following specified exceptions: (1) damage caused
by accident, unreasonable use or neglect
(including the lack of reasonable and necessary
maintenance); (2) damage occurring during
shipment (claims must be presented to the carrier);
(3) damage to, or deterioration of, any accessory
or decorative surface; (4) damage resulting from
failure to follow instructions contained in your
owner’s manual; (5) damage resulting from the
performance of repairs or alterations by someone
other than an authorized La Crosse Technology,
Ltd authorized service center; (6) units used for
other than home use (7) applications and uses that
this product was not intended or (8) the products
inability to receive a signal due to any source of
interference.. This warranty covers only actual
defects within the product itself, and does not
cover the cost of installation or removal from a
fixed installation, normal set-up or adjustments,
claims based on misrepresentation by the seller or
performance variations resulting from installationrelated circumstances.
LA CROSSE TECHNOLOGY, LTD WILL NOT
ASSUME LIABILITY FOR INCIDENTAL,
CONSEQUENTIAL, PUNITIVE, OR OTHER
19
SIMILAR DAMAGES ASSOCIATED WITH
THE OPERATION OR MALFUNCTION OF
THIS PRODUCT. THIS PRODUCT IS NOT TO
BE USED FOR MEDICAL PURPOSES OR FOR
PUBLIC INFORMATION. THIS PRODUCT IS
NOT A TOY. KEEP OUT OF CHILDREN’S
REACH.
This warranty gives you specific legal rights. You
may also have other rights specific to your State.
Some States do no allow the exclusion of
consequential or incidental damages therefore the
above exclusion of limitation may not apply to
you.
For warranty work, technical support, or
information contact:
La Crosse Technology
2809 Losey Blvd. S.
La Crosse, WI 54601
Phone: 608.782.1610
Fax: 608.796.1020
e-mail:
support@lacrossetechnology.com
(warranty work)
20
sales@lacrossetechnology.com
(information on other products)
www.lacrossetechnology.com
FCC DISCLAIMER
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference.
(2) This device must accept any
interference received, including
interference that may cause undesired
operation.
FCC ID: OMO-01RX (Receiver), OMO-01TX
All rights reserved. This handbook must not be
reproduced in any form, even in excerpts, or
web:
(sensor)
Freq. 915 MHz
La Crosse Technology
Made in China
WS-7034it
21
duplicated or processed using electronic,
mechanical or chemical procedures without
written permission of the publisher.
This handbook may contain mistakes and printing
errors. The information in this handbook is
regularly checked and corrections made in the next
issue. We accept no liability for technical
mistakes or printing errors, or their consequences.
All trademarks and patents are acknowledged.
1. THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND
2. THIS DEVICE MUST ACCEPT
INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
22
Loading...
