KM-F650
PARTS LIST
Published in Jan.’02
5GW70770
CONTENTS
FIG. 1 COVER ASSEMBLY · · · · · · · · · · · · · · · · · · · · · · · · · · 2
FIG. 2 CONTROL PANEL UNIT· · · · · · · · · · · · · · · · · · · · · · · 4
FIG. 3 TRANSMITTER ASSEMBLY· · · · · · · · · · · · · · · · · · · · 6
FIG. 4 ELECTRICAL PARTS · · · · · · · · · · · · · · · · · · · · · · · · · 8
FIG. 5 BASE UNIT · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 10
FIG. 6 PAPER TRANSPORTATION· · · · · · · · · · · · · · · · · · · · 12
FIG. 7 FUSER UNIT· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 14
FIG. 8 CASSETTE · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 16
FIG. 9 OPTION CASSETTE · · · · · · · · · · · · · · · · · · · · · · · · · 18
FIG. 10 PC BOARD / HARNESS · · · · · · · · · · · · · · · · · · · · · · 20
FIG. 11 PACKING AND ACCESSORIES · · · · · · · · · · · · · · · · 22
• INDEX· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 24
– 1 –
FIG. 1 COVER ASSEMBLY
120
121
(OPTIONAL)
SC
CN14
128
118
108
107
5GW
KA CDEFGHI JB
109
112
1
116
125
122
123
130
106
1011
19
SC
CN9
B1
B1
114
103
117
1016
1Y
C2
C2
127
129
119
101
B1
105
B1
111
222
3
4
5
6
7
104
– 2 –
102
B1
Fig. 1: Cover Assembly
8
FIG. 1 COVER ASSEMBLY
Ref.
Part. No. Description
No.
101 5GW08320 SPRING 1
102 5GW08900 SIDE COVER 1
103 5GW08940 COVER,LEFT 1
104 5GW08910 FRONT COVER 1
105 5GW08930 COVER,REAR 1
106 5GW09010 TOP COVER 1
107 5GW09020 GUIDE 1
108 5GW09030 GUIDE 1
109 5GW09040 TRAY 1
111 5GW09050 TRAY 1
112 5GW09060 TRAY 1
114 5GW08920 COVER,CONNECT OR ACCESS 1
116 5GW09150 LABEL 1
117 5GW07030 SPEAKER 1
118 5GW09250 EPA LABEL 1
119 5GW08580 GEAR 1
120 5GW09410 HANDSET 1
121 5GV10740 CONNECT CORD W/PLUG,24V 1
122 5GW09440 CRADLE 1
123 5GW09450 CONNECT CORD W/PLUG 1
125 5GW09460 CRADLE 1
127 5GW09140 LABEL 1
128 5GW09130 LABEL 1
129 5GW07450 TAPE 1
1011 5GV10470 PC BOARD W/COMPONENT,SRU 1
1016 5GW07170 CONNECTOR CORD W/PLUG,5V 1
19 5GV10590 TAPPING SCREW,DURALUMIN –
1Y 5GV10580 TAPPING SCREW,STEEL –
B1 5GV10260 SET SCREWDURALUMIN –
C2 5GW09170 SET SCREW,STEEL –
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
– 3 –
FIG. 2 CONTROL PANEL UNIT
5GW
KA CDEFGHI JB
217
216
218
219
218
220
SC
CN14
214
1026
212
215
213
236
211
235
205
239
221
242
222
205
210
237
241
204
202
207
204
243
203
1
222
3
4
5
6
201
226
229
224
227
225
228
206
1004
7B
238
242
209
239
19
Fig. 2: Control Panel Unit
208
19
7
8
– 4 –
FIG. 2 CONTROL PANEL UNIT
Ref.
Part. No. Description
No.
201 5GW07660 CHASSIS 1
202 5GW07740 HOLDER 1
203 5GW08210 LEVER 1
204 5GW08310 SPRING 2
205 5GW08410 SPRING 2
206 5GW08530 ROLLER 1
207 5GW08070 SEPARATOR RUBBER 1
208 5GW08340 PLATE,STAINLESS 1
209 5GW07430 ANTISTATIC BRUSH 1
210 5GW08990 LATCH 1
211 5GW09290 COVER,PANEL 1
212 5GW08080 PUSH BUTTON 1
213 5GW08090 PUSH BUTTON 1
214 5GW08100 PUSH BUTTON 1
215 5GW08110 PUSH BUTTON 1
216 5GW08120 PUSH BUTTON 1
217 5GW08130 PUSH BUTTON 1
218 5GW08140 PUSH BUTTON 2
219 5GW08150 PUSH BUTTON 1
220 5GW09470 PLATE,PLASTC 1
221 5GW09550 SHEET 1
222 5GW09090 SHEET 1
224 5GW07480 ACTUATOR 1
225 5GW07490 ACTUATOR 1
226 5GW07500 ACTUATOR 1
227 5GW07790 HOLDER 1
228 5GW07800 HOLDER 1
229 5GW07810 HOLDER 1
235 5GW08160 SHAFT 1
236 5GW08440 ROLLER 1
237 5GW07720 SEPARATOR 1
238 5GW08020 SEAL 1
239 5GV10100 LATCH 2
241 5GW08400 SPRING 1
242 5GW08430 SPRING 2
243 5GW09520 SHEET,PET 2
1004 5GW07100 PC BOARD W/CONPONENT,PNL A4 1
1026 5GW07280 CONNECTOR CORD W/PLUG 1
19 5GV10590 TAPPING SCREW,DURALUMIN –
7B 5GV10570 TAPPING SCREW,STEEL –
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
– 5 –
FIG. 3 TRANSMITTER ASSEMBLY
5GW
KA CDEFGHI JB
330
322
330
335
334
330
321
330
336
SC
CN7
330
1019
325
326
327
308
341
301
316
19
1014
19
SC
CN3
4N
303
316
307
307
316
329
302
342
318
307
CN5
314
333
331
319
324
1020
SC
309
310
311
313
343
316
342
332
1022
SC
CN1
304
315
338
312
317
332
1
222
320
3
19
4
305
5
6
7
330
– 6 –
344
306
19
19
Fig. 3: Transmitter Assembly
8
FIG. 3 TRANSMITTER ASSEMBLY
Ref.
Part. No. Description
No.
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
301 5GW07650 CHASSIS 1
302 5GW08470 ROLLER 1
303 5GW08480 ROLLER 1
304 5GW08170 SHAFT 1
305 5GW08640 GEAR 1
306 5GW07570 BRACKET 1
307 5GW07580 CLIP 3
308 5GW09240 GLASS 1
309 5GW07640 BRACKET 1
310 5GW08650 GEAR 1
311 5GW08660 GEAR 1
312 5GW08670 GEAR 1
313 5GW08680 GEAR 1
314 5GW08690 GEAR 1
315 5GW08830 BUSHING 1
316 5GW08840 BUSHING 4
317 5GW08300 PLATE,FE 1
318 5GW08850 BUSHING 1
319 5GW08560 CLUTCH 1
320 5GW08330 SPRING 1
321 5GW07510 SCANNER 1
322 5GW07670 CHASSIS 1
324 5GW07010 DC MOTOR 1
325 5GV07790 VERIFICATION STAMP HEAD 1
326 5GW07710 STAMP HOLDER 1
327 5GW07540 SOLENOID 1
329 5GW09270 LED ARRA Y 1
330 5GV09110 SPRING 6
331 5GV09390 ROLLER 1
332 5GW08570 GEAR 2
333 5GW08360 SPRING 1
334 5GW09210 MIRROR 1
335 5GW09220 MIRROR 1
336 5GW09230 MIRROR 1
338 5GW07730 SHAFT 1
341 5GW08040 FILM 1
342 5GW08870 BUSHING 2
343 5GW08420 SPRING 1
344 5GW09000 STAY 1
1014 5GW09560 PC BOARD W/COMPONENT,CCD 1
1019 5GW07380 CONNECTOR CORD W/PLUG 1
1020 5GW07290 CONNECTOR CORD W/PLUG 1
1022 5GW07260 CONNECTOR CORD W/PLUG 1
19 5GV10590 TAPPING SCREW,DURALUMIN –
4N 5GV10560 THERMINAL SCREW,STEEL –
– 7 –
FIG. 4 ELECTRICAL PARTS
5GW
KA CDEFGHI JB
SC
CN57
1021
428
406
1006
19
1001
407
426
427
427
19
403
19
19
19
1005
401
19
1003
19
G8
402
G8
19
19
404
405
1002
1
222
3
4
5
6
– 8 –
Fig. 4: Electrical Parts
7
8
FIG. 4 ELECTRICAL PARTS
Ref.
Part. No. Description
No.
401 5GW07630 PLATE 1
402 5GW08970 BRACKET 1
403 5GW07840 BRACKET 1
404 5GW07990 SPACER 1
405 5GW07980 SPACER,LOCKING CARD 1
406 5GW08980 COVER 1
407 5GW07830 HOLDER 1
426 5GW09530 GUIDE 1
427 5GV08600 BINDER 2
428 5GW09260 FROM LABEL 1
1001 5GW09300 PC BOARD W/COMPONENT,SC 1
1002 5GW07050 POWER SUPPLY 1
1003 5GW07110 PC BOARD W/CONPONENT,MJR 1
1005 5GW07120 PC BOARD W/CONPONENT,ACI 1
1006 5GV07200 PC BOARD W/COMPONENT,ILS 1
1021 5GW07310 CONNECTOR CORD W/PLUG 1
19 5GV10590 TAPPING SCREW,DURALUMIN –
G8 5GV10640 WASHAR –
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
– 9 –
FIG. 5 BASE UNIT
19
515
5GW
KA CDEFGHI JB
19
19
511
19
19
19
516
1
19
1031
A
19
527
506
505
19
19
222
513
19
CN59
525
503
SC
1018
A
19
19
1009
SC
CN68
504
1024
1Y
1Y
B9
to Fig.6
B
526
3
19
542
533
B9
528
4
529
1Y
PSU
CN202
1032
5
6
543
19
7
8
512
1Y
1023
CN69
501
514
514
517
19
518
4N
1010
507
SNS1
CN80
1030
19
19
B9
502
19
520
4N
518
SC
519
19
519
19
521
522
19
SC
CN56
508
510
508
523
Fig. 5: Base Unit
B9
531
19
– 10 –
FIG. 5 BASE UNIT
Ref.
Part. No. Description
No.
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
501 5GW07590 CHASSIS 1
502 5GW07600 ACTUATOR 1
503 5GW07900 CHASSIS 1
504 5GW08950 PLATE 1
505 5GW08960 CHASSIS 1
506 5GW08350 SPRING 1
507 5GW07850 PLATE,FE 1
508 5GW08220 SPRING 2
510 5GW08370 SPRING 1
511 5GW08380 SPRING 1
512 5GW09280 LASER UNIT 1
513 5GV07040 TONER SENSOR 1
514 5GW09080 RUBBER CUSHION 2
515 5GW08250 SPRING 1
516 5GW08010 PLATE 1
517 5GW08180 SHAFT 1
518 5GV09320 ROLLER 2
519 5GV09900 BUSHING 2
520 5GV09620 GEAR 1
521 5GV09040 SPRING 1
522 5GV08100 SLEEVE 1
523 5GW08030 DRUM 1
525 5GW07470 ACTUATOR 1
526 5GW08520 ROLLER 1
527 5GV09920 BUSHING 1
528 5GV09800 BUSHING 1
529 5GW08620 GEAR 1
531 5GW07400 SOLENOID 1
533 5GW08890 PLATE,STAINLESS 1
542 5GW07240 CONNECTOR CORD W/OUT PLUG,0V 1
543 5GW07820 HOLDER 1
1009 5GW07080 PC BOARD W/CONPONENT,SNS3 1
1010 5GW07070 PC BOARD W/CONPONENT,SNS2 1
1018 5GW07200 CONNECTOR CORD W/PLUG,5V 1
1023 5GW07360 CONNECTOR CORD W/PLUG 1
1024 5GW07350 CONNECTOR CORD W/PLUG 1
1030 5GW07210 CONNECTOR CORD W/PLUG,5V 1
1031 5GW07370 CONNECTOR CORD W/PLUG 1
1032 5GW07320 CONNECTOR CORD W/PLUG 1
19 5GV10590 TAPPING SCREW,DURALUMIN –
1Y 5GV10580 TAPPING SCREW,STEEL –
4N 5GV10560 THERMINAL SCREW,STEEL –
B9 5GV08710 C–RING –
– 11 –
FIG. 6 PAPER TRANSPORTATION
617
605
5GW
KA CDEFGHI JB
19
614
C8
606
608
607
604
19
19
618
603
602
613
609
629
607
610
19
C
to Fig.7
606
611
19
1030
19
1008
608
601
SNS2
CN82
SNS4
CN85
1029
612
C8
PSU
CN201
1033
1
222
3
4
625
623
620
621
624
619
622
– 12 –
5
4N
19
616
19
19
19
SC
CN54
1025
626
628
to Fig.5
B
19
Fig. 6: Paper Transportation
6
7
8
FIG. 6 PAPER TRANSPORTATION
Ref.
Part. No. Description
No.
601 5GW07870 GUIDE 1
602 5GW07890 GUIDE 1
603 5GW07440 SHEET,PET 1
604 5GW08510 ROLLER 1
605 5GW08860 BUSHING 1
606 5GV08990 SPRING 2
607 5GV09310 ROLLER 2
608 5GW08390 SPRING 2
609 5GW07460 ACTUATOR 1
610 5GW08820 BUSHING 1
611 5GW08630 GEAR 1
612 5GW08000 PLATE,STAINLESS 1
613 5GW07230 METAL GLAZE RESISTOR,0.5W 1
614 5GW08280 SPRING 1
616 5GW07610 BRACKET 1
617 5GW08750 GEAR 1
618 5GW08740 GEAR 1
619 5GW08720 GEAR 1
620 5GW08730 GEAR 1
621 5GW08710 GEAR 1
622 5GW08700 GEAR 1
623 5GW08760 GEAR 1
624 5GW08770 GEAR 1
625 5GW08780 GEAR 1
626 5GW07020 DC MOTOR,14.9W 1
628 5GW08290 SPRING 1
629 5GW07220 CONNECTOR CORD W/PLUG,5V 1
1008 5GW07060 PC BOARD W/CONPONENT,SNS1 1
1025 5GW07180 CONNECTOR CORD W/PLUG,24V 1
1029 5GW07190 CONNECTOR CORD W/PLUG,5V 1
1030 5GW07210 CONNECTOR CORD W/PLUG,5V 1
1033 5GW07340 CONNECTOR CORD W/PLUG 1
19 5GV10590 TAPPING SCREW,DURALUMIN –
4N 5GV10560 THERMINAL SCREW,STEEL –
C8 5GV10610 THERMINAL SCREW,STEEL –
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
– 13 –
FIG. 7 FUSER UNIT
5GW
KA CDEFGHI JB
734
735
737
SC
19
SNS1
CN81
CN58
1029
4N
1007
724
732
1017
725
1
730
4N
23
1Q
SC
CN52
721
4N
PSU
CN102
728
726
23
19
712
710
19
1028
731
723
to Fig.6
C
709
719
4N
708
705
4N
702
707
706
701
718
716
717
720
722
703
707
19
713
714
711
19
713
710
718
716
717
715
715
704
4N
708
705
712
222
3
4
5
6
7
19
733
– 14 –
Fig. 7: Fuser Unit
8
FIG. 7 FUSER UNIT
Ref.
Part. No. Description
No.
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
701 5GW07530 FUSER UNIT 1
702 5GW07690 FRAME 1
703 5GW07880 GUIDE 1
704 5GW07410 ANTISTATIC BRUSH 1
705 5GW08200 PLATE,FE 2
706 5GW08460 ROLLER 1
707 5GV09830 BUSHING 2
708 5GW08240 SPRING 2
709 5GV09290 ROLLER 1
710 5GV09890 BUSHING 2
711 5GV09700 GEAR 1
712 5GV10280 C–RING,FE 2
713 5GW08590 GEAR 2
714 5GW08600 GEAR 1
715 5GW08270 PLATE,STAINLESS 2
716 5GW07560 HOLDER 2
717 5GW08490 ROLLER 2
718 5GW08550 ROLLER 2
719 5GW08500 ROLLER 1
720 5GV09810 BUSHING 1
721 5GV09820 BUSHING 1
722 5GW08610 GEAR 1
723 5GW07680 TOP COVER 1
724 5GW07750 PLATE,CU 1
725 5GW07040 THERMOSTAT 1
726 5GV07590 THERMAL FUSE 1
728 5GW07420 THERMISTOR 1
730 5GW08190 ACTUATOR 1
731 5GW07760 PLATE,CU 1
732 5GV07540 FUSER LAMP 1
733 5GW07860 COVER,TOP 1
734 5GV10190 LABEL 1
735 5GW09120 LABEL 1
737 5GW08050 SHEET,POLYESTER 1
1007 5GW07130 PC BOARD W/CONPONENT,SNS4 2
1017 5GW07300 CONNECTOR CORD W/PLUG 1
1028 5GW07330 CONNECTOR CORD W/PLUG 1
1029 5GW07190 CONNECTOR CORD W/PLUG,5V 1
19 5GV10590 TAPPING SCREW,DURALUMIN –
1Q 5GV10660 SCREW W/WASHAR,STEEL –
23 5GV10690 SCREW W/WASHAR,STEEL –
4N 5GV10560 THERMINAL SCREW,STEEL –
– 15 –
FIG. 8 CASSETTE
5GW
KA CDEFGHI JB
805
804
808
803
809
807
1
807
222
806
3
810
810
4
811
5
6
802
– 16 –
801
Fig. 8: Cassette
7
8
FIG. 8 CASSETTE
Ref.
Part. No. Description
No.
801 5GW07910 CASSETTE BASE 1
802 5GW07920 GUIDE 1
803 5GW07940 GUIDE 1
804 5GW07930 TOP COVER 1
805 5GW07950 TRAY 1
806 5GW09510 PLATE,FE 1
807 5GV08780 PAD 2
808 5GW09110 LABEL 1
809 5GW07770 CLIP 1
810 5GW08230 SPRING 2
811 5GW07780 CLIP 1
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
– 17 –
FIG. 9 OPTION CASSETTE
5GW
19
931
19
19
19
930
19
902
901
19
1034
1012
4N
19
SC
CN66
D
E
19
922
911
19
912
911
19
912
919
4N
910
912
904
920
19
19
920
919
19
B9
914
916
917
5Y
915
905
907
B9
19
KA CDEFGHI JB
L5_H11/3/19
1
222
912
918
3
4
5
903
926
925
1013
19
924
– 18 –
5Y
906
D
1035
19
925
E
Fig. 9: Option Cassette
909
6
19
908
19
7
8
FIG. 9 OPTION CASSETTE
Ref.
Part. No. Description
No.
901 5GW07700 BOTTOM BASE 1
902 5GW08880 PLATE,FE 1
903 5GW07620 BRACKET 1
904 5GW08540 ROLLER 1
905 5GW08760 GEAR 1
906 5GW08770 GEAR 1
907 5GW08780 GEAR 1
908 5GW07390 SOLENOID 1
909 5GW08290 SPRING 1
910 5GW08180 SHAFT 1
911 5GV09320 ROLLER 2
912 5GV09900 BUSHING 2
914 5GV09620 GEAR 1
915 5GV09040 SPRING 1
916 5GV08100 SLEEVE 1
917 5GW08030 DRUM 1
918 5GW08620 GEAR 1
919 5GV09310 ROLLER 2
920 5GW08260 SPRING 1
922 5GW07470 ACTUATOR 1
924 5GW07850 PLATE,FE 1
925 5GW09080 RUBBER CUSHION 2
926 5GW07520 COVER,CASSETTE 1
930 5GW07960 GUIDE 1
931 5GW08060 SPONGE 1
1012 5GW07090 PC BOARD W/CONPONENT,CST2 1
1013 5GW07070 PC BOARD W/CONPONENT,SNS2 1
1034 5GW07150 CONNECTOR CORD W/PLUG,5V 1
1035 5GW07160 CONNECTOR CORD W/PLUG,5V 1
19 5GV10590 TAPPING SCREW,DURALUMIN –
4N 5GV10560 THERMINAL SCREW,STEEL –
5Y 5GV10620 E–RING –
B9 5GV08710 C–RING –
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
– 19 –
FIG. 10 PC BOARD / HARNESS
CN6
CN52
1015
728
SC
1001
CN9
1016
CN58
1017
CN59
1018
CN7
1019
CN5
1020
CN14
1026
CN57
1021
CN53
1015
CN1
1022
CN3
327
CN69
1023
CN68
1024
CN56
531
CN54
1025
CN50
1026
PNL
1004
5GW
KA CDEFGHI JB
1
222
3
CN202
1032
CN201
1033
1027
CN18
CN103
1015
Power Supply Unit
1002
1028
CN102
1005
CN101
1034
CN66
CN28
1027
CN29
1027
CN81
1029
SNS1
1008
SRU (Optional)
– 20 –
MJR
1003
1011
CN80
1030
CN20
1109
CN91
121
123
CN90
CN83
1018
ACI
1005
SNS3
1009
CST2 (Optional)
1034
CN70
CN73
1021
CN84
1031
1012
1035
CN74
ILS
1006
SNS2
1010
1017
CN87
1007
CN85
CN82
1030
SNS2 (Optional)
SNS4
1013
908
CN71
Fig. 10: PC Board / Harness
1029
CN82
1035
4
5
6
7
8
FIG. 10 PC BOARD / HARNESS
Ref.
Part. No. Description
No.
1001 5GW09300 PC BOARD W/COMPONENT,SC 1
1002 5GW07050 POWER SUPPLY 1
1003 5GW07110 PC BOARD W/CONPONENT,MJR 1
1004 5GW07100 PC BOARD W/CONPONENT,PNL A4 1
1005 5GW07120 PC BOARD W/CONPONENT,ACI 1
1006 5GV07200 PC BOARD W/COMPONENT,ILS 1
1007 5GW07130 PC BOARD W/CONPONENT,SNS4 2
1008 5GW07060 PC BOARD W/CONPONENT,SNS1 1
1009 5GW07080 PC BOARD W/CONPONENT,SNS3 1
1010 5GW07070 PC BOARD W/CONPONENT,SNS2 1
1011 5GV10470 PC BOARD W/COMPONENT,SRU 1
1012 5GW07090 PC BOARD W/CONPONENT,CST2 1
1013 5GW07070 PC BOARD W/CONPONENT,SNS2 1
1015 5GW07250 CONNECTOR CORD W/PLUG 1
1016 5GW07170 CONNECTOR CORD W/PLUG,5V 1
1017 5GW07300 CONNECTOR CORD W/PLUG 1
1018 5GW07200 CONNECTOR CORD W/PLUG,5V 1
1019 5GW07380 CONNECTOR CORD W/PLUG 1
1020 5GW07290 CONNECTOR CORD W/PLUG 1
1021 5GW07310 CONNECTOR CORD W/PLUG 1
1022 5GW07260 CONNECTOR CORD W/PLUG 1
1023 5GW07360 CONNECTOR CORD W/PLUG 1
1024 5GW07350 CONNECTOR CORD W/PLUG 1
1025 5GW07180 CONNECTOR CORD W/PLUG,24V 1
1026 5GW07280 CONNECTOR CORD W/PLUG 1
1027 5GW07270 CONNECTOR CORD W/PLUG 1
1028 5GW07330 CONNECTOR CORD W/PLUG 1
1029 5GW07190 CONNECTOR CORD W/PLUG,5V 1
1030 5GW07210 CONNECTOR CORD W/PLUG,5V 1
1031 5GW07370 CONNECTOR CORD W/PLUG 1
1032 5GW07320 CONNECTOR CORD W/PLUG 1
1033 5GW07340 CONNECTOR CORD W/PLUG 1
1034 5GW07150 CONNECTOR CORD W/PLUG,5V 1
1035 5GW07160 CONNECTOR CORD W/PLUG,5V 1
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
– 21 –
FIG. 11 PACKING AND ACCESSORIES
5GW
KA CDEFGHI JB
1105
1102
1102
1109
1108
1107
1110
1113
1101
1
222
3
4
5
6
1103
1102
1102
– 22 –
Fig. 11: Packing and Accessories
7
8
FIG. 11 PACKING AND A CCESSORIES
Ref.
Part. No. Description
No.
1101 5GW09320 CARTON BOX,PAPER 1
1102 5GW09190 CUSHION,STYROFOAM 1
1103 5GW09180 CASSETTE PAD,PAPER 2
1105 5GV10300 ACCESSORY BOX,PAPER 1
1107 5GW09070 TRAY 1
1108 5GV10840 POWER CORD W/PLUG,120V 1
1109 5GW07140 CONNECTOR CORD W/PLUG,60V 1
1110 5GW09200 USER’S GUIDE 1
1113 5GW09390 CD–ROM 1
Quantity
120V
Ref.
Part. No. Description
No.
5GW
Quantity
120V
– 23 –
INDEX
Part. No. Description
Quantity
120V
Fig. No.
Part. No. Description
Quantity
120V
5GW
Fig. No.
5GV07040 TONER SENSOR 1 5
5GV07200 PC BOARD W/COMPONENT,ILS 2 4,10
5GV07540 FUSER LAMP 1 7
5GV07590 THERMAL FUSE 1 7
5GV07790 VERIFICATION STAMP HEAD 1 3
5GV08100 SLEEVE 2 5,9
5GV08600 BINDER 24
5GV08710 C-RING – 5,9
5GV08780 PAD 28
5GV08990 SPRING 26
5GV09040 SPRING 2 5,9
5GV09110 SPRING 63
5GV09290 ROLLER 17
5GV09310 ROLLER 4 6,9
5GV09320 ROLLER 4 5,9
5GV09390 ROLLER 13
5GV09620 GEAR 2 5,9
5GV09700 GEAR 17
5GV09800 BUSHING 15
5GV09810 BUSHING 17
5GV09820 BUSHING 17
5GV09830 BUSHING 27
5GV09890 BUSHING 27
5GV09900 BUSHING 4 5,9
5GV09920 BUSHING 15
5GV10100 LATCH 22
5GV10190 LABEL 17
5GV10260 SET SCREWDURALUMIN – 1
5GV10280 C-RING,FE 2 7
5GV10300 ACCESSORY BOX,PAPER 1 11
5GV10470 PC BOARD W/COMPONENT,SRU 2 1,10
5GV10560 THERMINAL SCREW,STEEL – 3,5,6,7,9
5GV10570 TAPPING SCREW,STEEL – 2
5GV10580 TAPPING SCREW,STEEL – 1,5
5GV10590 TAPPING SCREW,DURALUMIN – 1,2,3,4,5
6,7,9
5GV10610 THERMINAL SCREW,STEEL – 6
5GV10620 E-RING – 9
5GV10640 WASHAR – 4
5GV10660 SCREW W/WASHAR,STEEL – 7
5GV10690 SCREW W/WASHAR,STEEL – 7
5GV10740 CONNECT CORD W/PLUG,24V 1 1
5GV10840 POWER CORD W/PLUG,120V 1 11
5GW07010 DC MOTOR 1 3
5GW07020 DC MOTOR,14.9W 1 6
5GW07030 SPEAKER 11
5GW07040 THERMOSTAT 1 7
5GW07050 POWER SUPPLY 2 4,10
5GW07060 PC BOARD W/CONPONENT,SNS1 2 6,10
5GW07070 PC BOARD W/CONPONENT,SNS2 4 5,9,10
5GW07080 PC BOARD W/CONPONENT,SNS3 2 5,10
5GW07090 PC BOARD W/CONPONENT,CST2 2 9,10
5GW07100 PC BOARD W/CONPONENT,PNL A4 2 2,10
5GW07110 PC BOARD W/CONPONENT,MJR 2 4,10
5GW07120 PC BOARD W/CONPONENT,ACI 2 4,10
5GW07130 PC BOARD W/CONPONENT,SNS4 4 7,10
5GW07140 CONNECTOR CORD W/PLUG,60V 1 11
5GW07150 CONNECTOR CORD W/PLUG,5V 2 9,10
5GW07160 CONNECTOR CORD W/PLUG,5V 2 9,10
5GW07170 CONNECTOR CORD W/PLUG,5V 2 1,10
5GW07180 CONNECTOR CORD W/PLUG,24V 2 6,10
5GW07190 CONNECTOR CORD W/PLUG,5V 3 6,7,10
5GW07200 CONNECTOR CORD W/PLUG,5V 2 5,10
5GW07210 CONNECTOR CORD W/PLUG,5V 3 5,6,10
5GW07220 CONNECTOR CORD W/PLUG,5V 1 6
5GW07230 METAL GLAZE RESISTOR,0.5W 1 6
5GW07240 CONNECTOR CORD W/OUT PLUG,0V 1 5
5GW07250 CONNECTOR CORD W/PLUG 1 10
5GW07260 CONNECTOR CORD W/PLUG 2 3,10
5GW07270 CONNECTOR CORD W/PLUG 1 10
5GW07280 CONNECTOR CORD W/PLUG 2 2,10
5GW07290 CONNECTOR CORD W/PLUG 2 3,10
5GW07300 CONNECTOR CORD W/PLUG 2 7,10
5GW07310 CONNECTOR CORD W/PLUG 2 4,10
5GW07320 CONNECTOR CORD W/PLUG 2 5,10
5GW07330 CONNECTOR CORD W/PLUG 2 7,10
5GW07340 CONNECTOR CORD W/PLUG 2 6,10
5GW07350 CONNECTOR CORD W/PLUG 2 5,10
5GW07360 CONNECTOR CORD W/PLUG 2 5,10
5GW07370 CONNECTOR CORD W/PLUG 2 5,10
– 24 –
Part. No. Description
Quantity
120V
Fig. No.
Part. No. Description
Quantity
120V
5GW
Fig. No.
5GW07380 CONNECTOR CORD W/PLUG 2 3,10
5GW07390 SOLENOID 1 9
5GW07400 SOLENOID 1 5
5GW07410 ANTISTATIC BRUSH 1 7
5GW07420 THERMISTOR 1 7
5GW07430 ANTISTATIC BRUSH 1 2
5GW07440 SHEET,PET 1 6
5GW07450 TAPE 11
5GW07460 ACTUATOR 1 6
5GW07470 ACTUATOR 2 5,9
5GW07480 ACTUATOR 1 2
5GW07490 ACTUATOR 1 2
5GW07500 ACTUATOR 1 2
5GW07510 SCANNER 1 3
5GW07520 COVER,CASSETTE 1 9
5GW07530 FUSER UNIT 1 7
5GW07540 SOLENOID 1 3
5GW07560 HOLDER 27
5GW07570 BRACKET 13
5GW07580 CLIP 33
5GW07590 CHASSIS 15
5GW07600 ACTUATOR 1 5
5GW07610 BRACKET 16
5GW07620 BRACKET 19
5GW07630 PLATE 14
5GW07640 BRACKET 13
5GW07650 CHASSIS 13
5GW07660 CHASSIS 12
5GW07670 CHASSIS 13
5GW07680 TOP COVER 1 7
5GW07690 FRAME 17
5GW07700 BOTTOM BASE 1 9
5GW07710 STAMP HOLDER 1 3
5GW07720 SEPARATOR 1 2
5GW07730 SHAFT 13
5GW07740 HOLDER 12
5GW07750 PLATE,CU 17
5GW07760 PLATE,CU 17
5GW07770 CLIP 18
5GW07780 CLIP 18
5GW07790 HOLDER 12
5GW07800 HOLDER 12
5GW07810 HOLDER 12
5GW07820 HOLDER 15
5GW07830 HOLDER 14
5GW07840 BRACKET 14
5GW07850 PLATE,FE 2 5,9
5GW07860 COVER,TOP 1 7
5GW07870 GUIDE 16
5GW07880 GUIDE 17
5GW07890 GUIDE 16
5GW07900 CHASSIS 15
5GW07910 CASSETTE BASE 1 8
5GW07920 GUIDE 18
5GW07930 TOP COVER 1 8
5GW07940 GUIDE 18
5GW07950 TRAY 18
5GW07960 GUIDE 19
5GW07980 SP ACER,LOCKING CARD 1 4
5GW07990 SPACER 14
5GW08000 PLATE,STAINLESS 1 6
5GW08010 PLATE 15
5GW08020 SEAL 12
5GW08030 DRUM 2 5,9
5GW08040 FILM 13
5GW08050 SHEET,POLYESTER 1 7
5GW08060 SPONGE 19
5GW08070 SEPARATOR RUBBER 1 2
5GW08080 PUSH BUTTON 1 2
5GW08090 PUSH BUTTON 1 2
5GW08100 PUSH BUTTON 1 2
5GW08110 PUSH BUTTON 1 2
5GW08120 PUSH BUTTON 1 2
5GW08130 PUSH BUTTON 1 2
5GW08140 PUSH BUTTON 2 2
5GW08150 PUSH BUTTON 1 2
5GW08160 SHAFT 12
5GW08170 SHAFT 13
5GW08180 SHAFT 2 5,9
5GW08190 ACTUATOR 1 7
– 25 –
Part. No. Description
Quantity
120V
Fig. No.
Part. No. Description
Quantity
120V
5GW
Fig. No.
5GW08200 PLATE,FE 27
5GW08210 LEVER 12
5GW08220 SPRING 25
5GW08230 SPRING 28
5GW08240 SPRING 27
5GW08250 SPRING 15
5GW08260 SPRING 19
5GW08270 PLATE,STAINLESS 2 7
5GW08280 SPRING 16
5GW08290 SPRING 2 6,9
5GW08300 PLATE,FE 13
5GW08310 SPRING 22
5GW08320 SPRING 11
5GW08330 SPRING 13
5GW08340 PLATE,STAINLESS 1 2
5GW08350 SPRING 15
5GW08360 SPRING 13
5GW08370 SPRING 15
5GW08380 SPRING 15
5GW08390 SPRING 26
5GW08400 SPRING 12
5GW08410 SPRING 22
5GW08420 SPRING 13
5GW08430 SPRING 22
5GW08440 ROLLER 12
5GW08460 ROLLER 17
5GW08470 ROLLER 13
5GW08480 ROLLER 13
5GW08490 ROLLER 27
5GW08500 ROLLER 17
5GW08510 ROLLER 16
5GW08520 ROLLER 15
5GW08530 ROLLER 12
5GW08540 ROLLER 19
5GW08550 ROLLER 27
5GW08560 CLUTCH 13
5GW08570 GEAR 23
5GW08580 GEAR 11
5GW08590 GEAR 27
5GW08600 GEAR 17
5GW08610 GEAR 17
5GW08620 GEAR 2 5,9
5GW08630 GEAR 16
5GW08640 GEAR 13
5GW08650 GEAR 13
5GW08660 GEAR 13
5GW08670 GEAR 13
5GW08680 GEAR 13
5GW08690 GEAR 13
5GW08700 GEAR 16
5GW08710 GEAR 16
5GW08720 GEAR 16
5GW08730 GEAR 16
5GW08740 GEAR 16
5GW08750 GEAR 16
5GW08760 GEAR 2 6,9
5GW08770 GEAR 2 6,9
5GW08780 GEAR 2 6,9
5GW08820 BUSHING 16
5GW08830 BUSHING 13
5GW08840 BUSHING 43
5GW08850 BUSHING 13
5GW08860 BUSHING 16
5GW08870 BUSHING 23
5GW08880 PLATE,FE 19
5GW08890 PLATE,STAINLESS 1 5
5GW08900 SIDE COVER 1 1
5GW08910 FRONT COVER 1 1
5GW08920 COVER,CONNECTOR ACCESS 1 1
5GW08930 COVER,REAR 1 1
5GW08940 COVER,LEFT 1 1
5GW08950 PLATE 15
5GW08960 CHASSIS 15
5GW08970 BRACKET 14
5GW08980 COVER 14
5GW08990 LA TCH 12
5GW09000 STAY 13
5GW09010 TOP COVER 1 1
5GW09020 GUIDE 11
5GW09030 GUIDE 11
– 26 –
Part. No. Description
5GW09040 TRAY 11
5GW09050 TRAY 11
5GW09060 TRAY 11
5GW09070 TRAY 111
5GW09080 RUBBER CUSHION 4 5,9
5GW09090 SHEET 12
5GW09110 LABEL 18
5GW09120 LABEL 17
5GW09130 LABEL 11
5GW09140 LABEL 11
5GW09150 LABEL 11
5GW09170 SET SCREW,STEEL – 1
5GW09180 CASSETTE PAD,PAPER 2 11
5GW09190 CUSHION,STYROFOAM 1 11
5GW09200 USER’S GUIDE 1 11
5GW09210 MIRROR 13
5GW09220 MIRROR 13
5GW09230 MIRROR 13
5GW09240 GLASS 13
5GW09250 EPA LABEL 1 1
5GW09260 FROM LABEL 1 4
5GW09270 LED ARRAY 1 3
5GW09280 LASER UNIT 1 5
5GW09290 COVER,PANEL 1 2
5GW09300 PC BOARD W/COMPONENT,SC 2 4,10
5GW09320 CARTON BOX,PAPER 1 11
5GW09390 CD-ROM 111
5GW09410 HANDSET 11
5GW09440 CRADLE 11
5GW09450 CONNECT CORD W/PLUG 1 1
5GW09460 CRADLE 11
5GW09470 PLATE,PLASTC 1 2
5GW09510 PLATE,FE 18
5GW09520 SHEET,PET 2 2
5GW09530 GUIDE 14
5GW09550 SHEET 12
5GW09560 PC BOARD W/COMPONENT,CCD 1 3
Quantity
120V
Fig. No.
Part. No. Description
Quantity
120V
5GW
Fig. No.
– 27 –
KYOCERA MITA AMERICA, INC.
Headquarters:
225 Sand Road, P.O. Box 40008
Fairfield, New Jersey 07004-0008
TEL : (973) 808-8444
FAX : (973) 882-6000
New York Show Room:
149 West 51st street,
New York, NY 10019
TEL : (212) 554-2679
FAX : (212) 554-2625
Northeastern Region:
225 Sand Road, P.O. Box 40008
Fairfield, New Jersey 07004-0008
TEL : (973) 808-8444
FAX : (973) 882-4401
Midwestern Region:
201 Hansen Court Suite 119
Wood Dale, Illinois 60179
TEL : (630) 238-9982
FAX : (630) 238-9487
KYOCERA MITA CANADA, LTD.
6120 Kestrel Road,
Mississauga, Ontario L5T 1S8, Canada
TEL : (905) 670-4425
FAX : (905) 670-8116
Western Region:
14101 Alton Parkway,
Irvine, California 92618-7006
TEL : (949) 457-9000
FAX : (949) 457-9119
Southeastern Region:
1500 Oakbrook Drive,
Norcross, Georgia 30093
TEL : (770) 729-9786
FAX : (770) 729-9873
Southwestern Region:
2825 West Story Road,
Irving, Texas 75038-5299
TEL : (972) 550-8987
FAX : (972) 570-4704
Dallas Parts Distribution Center
& National Training Center:
2825 West Story Road,
Irving, Texas 75038-5299
TEL : (972) 659-0055
FAX : (972) 570-5816
KYOCERA MITA MEXICO, S.A. DE C.V.
Av. 16 de Septiembre #407
Col. Santa Inés,
02130 Azcapotzalco
México, D.F. Mexico
TEL : (5) 383-2741
FAX : (5) 383-7804
© 2002 KYOCERA MITA CORPORATION
is a trademark of Kyocera Corporation
is a registered trademark of KYOCERA MITA CORPORATION
Printed in U.S.A.
Loading...
