Kyocera FS-1030MFP, FS-1035MFP, FS-1130, FS-1135 Service Bulletin 2MH 0003 C006
The explanation
was added to the
Operation Guide
.
China
(KM version only
)
Chinese, Traditional Chinese
←←←←
←←←←
BR
Portuguese
KR
(
For
KMKR)
Service Bulletin Ref. No.
Subject
(Page.1/3)
2MH-0003 (C006)
<Date> January 19, 2012
Firmware Upgrade (Main: Ver.002.005); DVD-ROM Upgrade
(Ver.2.0 KM Version, UTAX/TA Version); Change to the Quick
Installation Guide
FS-1x30MFP-1x35MFP_v02.00.0010_(2012-01-11)
Model
FS-1030MFP, FS-1130MFP, FS-1035MFP, FS-1135MFP
Topic
The main firmware, the DVD-ROM (KM version, UTAX/TA version) and the Quick Installation Guide were changed
for the Network TWAIN/WIA support.
Content of Changes
<Firmware>
No.
Change Details
OEM support for Olivetti OEM settings are now supported for Olivetti.
1
Network TWAIN/WIA
support
2
The Network TWAIN/WIA is now supported.
*Please use DVD Ver.2.0 or later to enable the Network TWAIN/WIA
functions.
<DVD-ROM Ver.1.1/2.0>
No
Change Details
.
Korean support
1
(KM version only)
Network TWAIN/W IA
driver support
2
Support for South
3
America, Taiwan and
Korean Operation Guide and the FAX Operation Guide were added.
The TWAIN/WIA drivers were implemented and upgraded.
・TWAIN Driver 2.0.1114
・WIA Driver (Network) 2.0.1114
The Operation Guide and the FAX Operation Guide for these countries were added:
Spanish (South America) Brazilian Portuguese (Brazil) French (Canada), Simplified
CTL FW
575416
575070
MAIN
MAIN
Ver.
1.1
2.0
2.0
For more details on other changes, please refer to the next pages.
Program No.
MAIN 2MH_2F00002005 - 002.005 2011/11/1 001.100 *1
MAIN 2MJ_2F00002005 - 002.005 2011/11/1 001.100 *2
ENGINE 2MH_1000001011 - 001.011 - - *3
ENGINE 2MK_1000001011 - 001.011 - - *4
SCANNER 2MH_1200001008 - 001.008 - -
Optional language
Optional language
FAX BOOT/APL 2H9_5500008001 - 008.001 - - *5
Supported models:
*1 FS-1030MFP, FS-1035MFP *2 FS-1130MFP, FS-1135MFP
*3 FS-1030MFP, FS-1130MFP *4 FS-1035MFP, FS-1135MFP
*5 FS-1130MFP, FS-1135MFP
2MH_81BR001004 - 001.004 - -
2MH_81KR001001 - 001.001 - -
Check
SUM
Ver.
Status
Date
Current
Ver.
Remark
Brazilian
Korean
New upgrade
New upgrade
For the KM sales companies, it is possible to download the firmware at the download center on the ESDC.net.
When upgrading the firmware or replacing a board, please upgrade all kinds of the firmware to the latest version at the same
time.
European Service & Development Center (ESDC)
KYOCERA MITA Europe B.V.
display
corrected.
Service Bulletin Ref. No.
(Page.2/3)
2MH-0003 (C006)
<Date> January 19, 2012
KMC’s Classification Entire Stock Rework In-Field modification at next visit
In-Field modification by case No modification necessary
Field Measure: Please upgrade the firmware when the phenomenon described above arises.
Serial Nos. of the Affected Machines:
Firmware: From the first production for Olivetti in December 2011
DVD-ROM VER1.1: From the first production for KMKR
DVD-ROM and Quick Installation Guide: From the December 2011 production for KMA South America*
*The above is the plan at the present moment. Please note that this information is subject to change.
<Firmware>
No.
Change Details
Measures against the
illegible Korean
3
Command Center
Measures against the
4
system error (CF248)
Prevention of the
5
prescribe mode entry
with a certain file
Hangul fonts in Korean Command Center looked corrupted.
Therefore, the magnification of the browser was set to 120% for
Korean only.
The CF248 error occurred with a certain data. Therefore, this was
corrected.
If the character codes 0x21, 0x52 and 0x21 (!R!) exist in
series in the PCL5 data, the prescribe mode was unintentionally
entered and no data was printed after that. Therefore, this was
CTL FW
578067
TO-11-051
608881
TP-11-166
#1316019
608887
TP-11-046
NP-Z11006
MAIN
MAIN
MAIN
Measures against the
6
print range adjustment
failure
<DVD-ROM Ver.2.0>
No.
Change Details
Drivers/Utilities
1
upgrade
Depending on the type of the report, print range adjustment might be
reflected to the report. Therefore, this was corrected.
The following drivers and utilities were upgraded in addition to the TWAIN/WIA driver as
explained on the page 1.
[For KM]
KX Printer Driver 5.3.1103
KM (XPS) Driver 1.2.2301
Novell NDPS 5.3.1103
KPDL mini-driver XP and later (Overseas) 8.1111 [11-11-2011]
KPDL mini-driver XP and later (Japanese) 8.1111 [2011-11-11]
Macintosh 10.4 and lower (Overseas) 8.1111 [11-11-2011]
Macintosh 10.5 and up (Overseas) 8.1111 [11-11-2011]
Macintosh 10.4 and lower (Japanese) 8.1111 [2011-11-11]
Macintosh 10.5 and up (Japanese) 8.1111 [2011-11-11]
KMnet Viewer 5.3.2329a
[For UTAX/TA]
KX Printer Driver 5.3.1103
KM (XPS) Driver 1.2.2301
KPDL mini-driver XP and later 8.1111 [11-11-2011]
Linux 8.1111 [11-11-2011]
Macintosh 10.4 and lower 8.1111 [11-11-2011]
Macintosh 10.5 and up 8.1111 [11-11-2011]
NETWORK PRINT MONITOR 5.3.2329a
576987
TP-090318
NP-Z09067
MAIN
European Service & Development Center (ESDC)
KYOCERA MITA Europe B.V.
