Krups VB2158 User Manual
12
7
6
8
1
11
3
2
4
5
9
10
14
13
EN ............................................ P. 1
ES ............................................ P. 13
FR ............................................ P. 25
www.krups.com
RÉF. NC00018209
WWW.KRUPS.COM
EN
FR
ES
VB2158
notice_krups_beertender_nafta.indd 1-3 10/08/10 11:48:11
1
2
4 inches
54°F
86°F
2,5 inches2,5 inches
fig. 1 fig. 2 fig. 3
fig. 4 fig. 5 fig. 6
fig. 16 fig. 17 fig. 18
fig. 19 fig. 20 fig. 21
fig. 7 fig. 8 fig. 9
fig. 10 fig. 11 fig. 12
fig. 13 fig. 14 fig. 15 fig. 22 fig. 23
DO NOT - CUIDAR PARA EVITAR RIESGOS - À NE PAS FAIRE
notice_krups_beertender_nafta.indd 4-6 10/08/10 11:48:12
English
1
Important safeguards ............................................................................................................................ 2
General Information
................................................................................................................................ 3
Product description
.................................................................................................................................. 4
Before use
..........................................................................................................................................................4
Using the BeerTender
®
......................................................................................................................... 5
Troubleshooting
........................................................................................................................................... 8
Disposal
..............................................................................................................................................................10
Consumer service
....................................................................................................................................10
Limited warranty
.......................................................................................................................................11
English
2
IMPORTANT SAFEGUARDS
n When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and/or injury to persons
including the following:
1. Read all instructions.
2. To protect against fire, electric shock and injury to persons, do not place
cord, plugs or appliance in water or other liquid.
3. Close supervision is necessary when any appliance is used near children.
Keep appliance out of reach of children. Product not intended for use by
children.
4. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning the rest of the
appliance.
5. Do not operate any appliance with a damaged cord or plug or after
the appliance malfunctions, or has been damaged in any manner.
Return appliance to your nearest authorized Krups Service Center for
examination, repair or adjustment (see Limited Warranty).
6. The use of an accessory not evaluated for use with this appliance by
Krups may result in fire, electric shock or injury to persons.
7. Do not use outdoors.
8. Do not let cord hang over edge of table or counter, or touch hot
surfaces.
9. Do not place on or near a hot gas or electric burner, or in a heated oven.
10. To disconnect, turn the control to «off» then remove plug from wall
outlet.
11. Do not use appliance for other than intended use.
12. Appliance for household indoor use only.
13. Do not immerse in water.
English
3
SAVE THESE INSTRUCTIONS
CAUTION: This appliance is for household use only. Any servicing other
than cleaning and user maintenance should be performed by an authorized
service representative.
n To reduce the risk of fire or electric shock, do not remove the base. No
user serviceable parts inside. Repair should be done by authorized service
personnel only.
n Check voltage to be sure that the voltage indicated on the name plate is
compatible with your voltage.
n Never clean with scouring powders or harsh chemicals.
n Never make technical changes or use the appliance in any manner other
than as directed.
SHORT CORD INSTRUCTIONS
A. We do not recommend using an extension cord with this device.
B. If an extension cord is absolutely necessary:
1 - The marked electrical rating of the extension cord should be at least as
great as the electrical rating of the appliance.
2 - To reduce the risk of injury, do not drape cord over the counter top or table
top where it can be pulled on by children or tripped over unintentionally.
3 - The extension cord should be at least 18 AWG.
GENERAL INFORMATION
The BeerTender® is designed to dispense chilled beer in a domestic setting.
Only a Heineken® DraughtKegTM, Heineken Premium Light® DraughtKegTM
and Newcastle Brown Ale® DraughtKeg™ can be used with the BeerTender®.
You should not use any other commercially available beer containers or
kegs. Do not introduce any materials other than the DraughtKegTM inside the
appliance.
BeerTender® is designed for use by responsible adults of legal
drinking age.
GUIDELINES FOR READING THESE INSTRUCTIONS
THE WARNING INDICATES INSTRUCTIONS THAT ARE
IMPORTANT FOR THE USER’S SAFETY.
n Please adhere strictly to these directions to ensure proper use and avoid
serious injury!
This symbol highlights information that is especially important for making the
best use of the machine.
English
4
PRODUCT DESCRIPTION
BeerTender® components
1. BeerTender® at home draughting system
2. Refrigerating chamber
3. Lid
4. Lid opening handle
5. Control panel
6. Tap cover
7. Dispensing spout
8. Beer tap handle
9. Drip grate
10. Drip tray
11. Main power switch
12. Power cord with plug
Other Components
13. 5 Liter DraughtKegTM (not included)
14. Replaceable Draught Beer tube (Should be changed with each new
DraughtKegTM) (5 included with purchase)
BEFORE USE
CHILD SAFETY LOCK
n Make sure that children can not play with the appliance.
n Do not leave the materials used to pack the appliance within children’s
reach.
n To prevent children from using the appliance, you can remove the tap
handle. To remove the handle, make sure that it is in an upright position and
pull upward - fig. 1.
FIRE PREVENTION
n In the event of a fire, use carbon dioxide (CO2) extinguishers.
n Do not use water or powder extinguishers.
English
5
SETUP AND MAINTENANCE
n Install the BeerTender
®
in an upright position in a safe place.
To ensure that the BeerTender
®
works correctly and efficiently, the following
is strongly advised:
n Place it on a perfectly level and stable surface.
n Choose a clean, well-lit area with an easily accessible electric socket.
n Keep the appliance at a minimum distance (4 inches) from the stove as
shown in the diagram - fig. 2.
n Keep the appliance at a minimum distance (2 ½ inches) from the walls.
n Store the DraughtKeg
TM
at room temperature or in the refrigerator.
n Make sure the BeerTender
®
is not exposed to direct sunlight.
n Do not use the BeerTender
®
outdoors.
n Do not place the BeerTender
®
on very hot surfaces or near open flames, as
these may melt or damage the casing.
n Your BeerTender
®
uses a technology that delivers ultimate cooling results
when the ambient temperature is between 54°F and 86°F. At colder
temperatures, the appliance cooling system could be damaged. At
warmer temperatures, the cooling system will not be able to reach the preprogrammed temperature - fig. 3.
WARNING! To avoid overheating, always keep the BeerTender® appliance
out of direct sunlight. To obtain good cooling performance, never install your
machine in a room with an ambient temperature above 86°F.
USING THE BEERTENDER® SYSTEM
n Always hold the appliance by the bottom edge when lifting - fig. 4.
n To obtain draught beer of optimal quality you should keep two basic factors
in mind, the temperature of the beer and hygienic conditions. Follow these
few simple steps for the ideal use of BeerTender®.
A new draught beer tube should be used with each DraughtKeg
TM
.
A bag of 5 tubes is included with the BeerTender® appliance. To order
additional beer tubes, please contact www.beertender.com or call
1-888-KRUPS.
English
6
CHILLING THE DRAUGHTKEG
TM
1. Before pouring a draught beer, it is very important that the Heineken®,
Heineken Premium Light® DraughtKegTM and Newcastle Brown Ale®
DraughtKeg™ reach the correct temperature.
2. Ensure DraughtKegTM is sufficiently chilled before pouring a draught beer.
Insufficiently chilled DraughtKegsTM will produce too much foam. It is ideal
to purchase the DraughtKegTM pre-chilled or pre-chill over night before
intended use.
If the DraughtKegTM needs additional chilling, there are 2 recommended
options:
a. Inside the BeerTender® – Depending on the temperature of the DraughtKegTM,
it will take up to 18 hours to chill to the ideal serving temperature.
b. In a refrigerator – Depending on the temperature of your refrigerator, it will
take up to 12 hours to chill to the ideal serving temperature.
Tip: We recommend that you always keep an extra DraughtKegTM in your
refrigerator to always have a chilled keg available.
PREPARING THE BEERTENDER
®
IMPORTANT: It is important that the BeerTender® power switch is turned
on before inserting the DraughtKegTM.
n After setting up the BeerTender
®
and before use, it is vital to clean the
detachable pour spout – this is the only part of the appliance that will
come into contact with the beer. The spout should be rinsed by hand. After
cleaning, screw back into place - fig. 5.
n Before inserting the DraughtKeg
TM
into the BeerTender®, simply snap
the patented disposable draught beer tube (5 tubes included) onto the
DraughtKegTM - fig. 6.
n Open the BeerTender
®
cover by pressing in the release panel on the top of
the machine and remove the tap spout cover - fig. 7-8-9.
n Place DraughtKeg
TM
into BeerTender® - fig. 10.
n Position the draught beer tube as shown in drawing - fig. 11-12.
n Put the tap spout cover back into place - fig. 13.
n Carefully close the lid - fig. 14.
n Set the drip tray and grate in place at the front of the appliance. Make sure
the drip tray is properly fitted and positioned.
WARNING! The drip tray must be positioned on a level surface and must
not jut out from the surface it is resting on.
English
7
CONTROL PANEL
n Your appliance features a display providing you with important and useful
information.
n Two LEDs on the top of the lid provide important indications:
- Green (ON/OFF) LED on the left of the panel: when lit, it indicates that the
appliance is operating - fig. 15.
- Green beer-temperature LED on the right side of the panel: when the
DraughtKegTM has reached the ideal temperature the LED switches on and
the appliance goes into “stand-by” cooling mode - fig. 16.
WARNING: never use your BeerTender® with ambient temperature above
86°F. Above that level, the ideal serving temperature can not be attained.
POURING A BEER FROM THE BEERTENDER
®
n Before pouring a beer, rinse a clean glass in cold water which chills the
glass and wets the inside to enable a perfectly smooth draught pour. Use
of 8 oz glasses is recommended to maintain the ideal serving temperature
- fig. 17.
DRAUGHT AND DRINK
n Be aware that the first glass you pour from every new DraughtKeg
TM
will
contain mostly foam. This is typical of draught beer. Allow the foam to settle
and continue to pour.
n Tilt and pour: Tilt your glass at a 45 degree angle as you pour and adjust
upright as the glass fills - fig. 18.
n Ensure you pull the tap handle all the way down. Not opening the handle all
the way will result in excessive foam.
n For the optimal draught beer drinking experience, serve your beer with a
foam head of 2 fingers in height (approximately 1.5”).
PROPER CARE AND CLEANING OF YOUR BEERTENDER
®
n The drip tray and grate should be emptied and cleaned after each use
- fig. 19.
n Before cleaning the appliance, it is essential to turn off the ON/OFF switch
and then pull the plug out of the socket.
n Keep in mind that during use the drip tray will have to be emptied and rinsed
regularly. The tray and grate are dishwasher safe or can be washed by hand
with a mild detergent. Dry completely.
n Always wipe down the interior of the BeerTender
®
after use - fig. 20. Beer
is a natural product that can spoil. Therefore, you should always keep the
appliance clean to maintain the quality of the beer dispensed and avoid
unpleasant odors.
English
8
n Rinse the pour spout between uses for optimal results. Handwash with
warm soapy water. Do not wash in dishwasher - fig. 21.
n To remove, unscrew turning counterclockwise from main unit. To re-attach,
simply screw back in place turning clockwise.
n You should never attempt to access internal parts of the appliance.
IMPORTANT: After cleaning, ensure all parts of your BeerTender® have
completely dried before closing the lid.
STORING THE BEERTENDER
®
n When the BeerTender
®
is not being used for a long period of time, remove
the DraughtKegTM and turn the control to “off”.
n Remove the plug from the power outlet.
n Store the BeerTender
®
at room temperature in a dry place out of children’s
reach.
n Protect from dust and dirt.
TROUBLESHOOTING
Problem Possible causes Remedies
The appliance does not
come on.
The appliance is not
connected to the outlet.
Connect the appliance
to the outlet.
You cannot position the
tap cover correctly.
You may have opened
the draught beer tube
(white plastic part at
the end of the serving
tube) by hand. If so, the
tap cover will not close
correctly and there is
a risk for the beer to
flow out.
Before installing the
draught beer tube
onto the BeerTender
®
tapping mechanism,
make sure that the
draught beer tube is
closed.
The DraughtKeg
TM
tap
or tube is not inserted
correctly.
If the draught beer
tube is not installed
properly in the tapping
mechanism or if the
tube is pinched, this
will affect the beer flow.
Please refer to Section:
Using the BeerTender®
System to check that
you have properly set
up the BeerTender®.
English
9
No beer is being
dispensed.
The DraughtKegTM is
empty.
Replace the
DraughtKegTM with a
new one.
There is no
DraughtKegTM inside
the BeerTender
®
appliance.
Install a DraughtKegTM
inside the BeerTender
®
appliance.
The BeerTender
®
appliance tap handle is
not correctly
installed/positioned.
Install/position the
tap cover correctly.
You cannot close the
lid.
The tap cover has
not been positioned
correctly.
Position the tap cover
correctly.
The DraughtKeg
TM
has not been correctly
installed.
Install the tap correctly.
Ensure the draught
tube has been installed
completely and is not
preventing the lid from
closing.
The BeerTender
®
appliance produces too
much foam when
dispensing beer.
The DraughtKegTM has
not reached the right
dispensing
temperature.
Allow the DraughtKegTM
to cool to the right
temperature. You can
rely on the temperature
indicator on the
control panel of your
BeerTender® appliance.
The DraughtKeg
TM
has been shaken.
Wait 4 hours before
dispensing beer.
The tap handle is being
moved too slowly.
Firmly and quickly pull
the handle down and
forward as far as it
will go.
Beer flows out too
slowly.
The tap handle is not
open all the way.
Open the tap
completely.
English
10
The BeerTender®
appliance is dispensing
warm beer.
The DraughtKegTM has
not been chilled long
enough and is thus
not at the right serving
temperature.
Allow the DraughtKegTM
to cool long enough in
the appliance.
The temperature
indicator on the control
panel does not light up.
The BeerTender
®
appliance is exposed to
too hot a temperature
or direct sunlight (see
section: Cooling the
keg and Installing the
BeerTender®).
Use the appliance
indoors and move it
to a room where the
ambient temperature
does not exceed 86°F.
Ice forms in the cooling
chamber.
The BeerTender
®
has
been installed in a
humid environment.
Move the BeerTender®
to a dry place.
A fault has occurred in
the cooling system.
Have the BeerTender
®
repaired by an
authorized service
center.
It is normal for a small
patch of ice to form on
the rear of the cooling
chamber (near the
screws).
DISPOSAL
n Check your local ordinances for disposal of BeerTender
®
.
Loading...
