komatsu PC450-8R SPECIFICATIONS
www.Komatsu.com
CEN00274-00 Materials and specifications are subject to change without notice.
is a trademark of Komatsu Ltd. Japan.
Printed in Japan 200705 IP.As(10)
Photo may include optional equipment.
PC450-8R
PC450LC-8R
PC
450
HYDRAULIC EXCAVATOR
FLYWHEEL HORSEPOWER
Gross: 270 kW 362 HP @ 1900 rpm
Net: 257 kW 345 HP @ 1900 rpm
OPERATING WEIGHT
PC450-8R: 43320– 43740 kg
95,500– 96,430 lb
PC450LC-8R: 44320– 44770 kg
97,710– 98,700 lb
3
Photo may include optional equipment.
2
Easy Maintenance
• Long replacement interval of engine oil,
engine oil filter, hydraulic oil and
hydraulic filter.
• Side-by-side radiator and oil cooler
configuration enables independent removal
and installation of those two components.
• Equipped with the EMMS monitoring
system.
• Easy access to engine oil filter and fuel
drain valve
• Large fuel tank capacity
• Electric priming pump installed.
• Equipped with large size steps for easier
maintenance.
See page 9.
Ecology and Economy Features
• High power Komatsu SAA6D125E engine
A powerful turbocharged and air to air aftercooled Komatsu SAA6D125E-5
engine provides 257 kW 345 HP.
• Economy mode saves fuel consumption.
• Low operation noise
See pages 4 and 5.
● High Production and
Low Fuel Consumption
High power, working performance and
fuel efficiency improve production and
fuel costs.
● Excellent Machine Stability
Large counterweight offers superior
machine stability and balance.
● Large Digging Force
Pressing the Power Max function
button temporarily increases the
digging force 7%.
● Two-mode Setting for Boom
Switch selection allows either powerful
digging or smooth boom operation.
See page 5.
Productivity Features
WALK-AROUND
H YDRAULIC E XCAVATOR
HYDRAULIC EXCAVATOR
PC450-8R
PC450-8R 0
Genuine Answers for Land
and
Environment Optimization
Large Comfortable Cab
• Low-noise cab
• Low vibration with cab damper mounting
• Highly pressurized cab with optional air conditioner
• Operator seat and console with armrest that enables
operations in the appropriate operational posture.
See page 6.
HORSEPOWER
Gross: 270 kW 362 HP @ 1900 rpm
Net: 257 kW 345 HP @ 1900 rpm
OPERATING WEIGHT
PC450-8R: 43320 – 43740 kg
95,500 – 96,430 lb
PC450LC-8R: 44320 – 44770 kg
97,710 – 98,700 lb
BUCKET CAPACITY
1.90 – 2.10 m
3
2.49 – 2.75 yd
3
Variable Track Gauge (optional)
• Greatly increases lateral stability
• Compliant with transportation regulations
See page 5.
Quarry Bucket
Quarry Cab
Strengthened
Revolving Frame
with Deck Guard
Full Roller Guards and
Double-flange Track Rollers
Heavy-duty Arm
Heavy-duty Boom
Safety Design
• Cab dedicated to hydraulic excavator for protecting
the operator if the event of machine rolls over.
• Anti-slip plates for safe work on machine
• Rear view monitoring system for easy checking
behind the machine (optional)
See page 7.
Large TFT LCD Monitor
• Easy-to-see and use 7" large
multi-function color monitor
• Can be displayed in 12 languages
for global support.
TFT : Thin Film Transistor
LCD : Liquid Crystal Display
See page 8.
Excellent Reliability and Durability
• The fuel reliability is improved by adding fuel
main-filter and water separator working against
low grade fuel.
• Equipped with fuel pre-filter as standard (with
water separator).
• High pressure in-line filter
See page 10.
54
PRODUCTIVITY & ECOLOGY FEATURES
High Power Komatsu SAA6D125E Engine
The PC450-8R gets its exceptional power and work capacity
from a Komatsu SAA6D125E-5 engine. Output is 257 kW
345 HP, providing increased hydraulic power and improved
fuel efficiency.
The SAA6D125E-5 engine adopts the electronically
controlled Heavy Duty HPCR* fuel injection system.
*HPCR : High Pressure Common Rail
Low Operation Noise
Enables a low noise operation using the low-noise engine
and methods to cut noise at source. Ambient noise meets
the EU Stage 2 noise regulation.
Excellent Machine Stability
Large counterweight offers superior machine stability and
balance.
Komatsu Technology
Komatsu develops and produces all major
components, such as engines, electronics
and hydraulic components, in house.
With this “Komatsu Technology,” and adding
customer feedback, Komatsu is achieving
great advancements in technology.
To achieve both high levels of productivity
and economical performance, Komatsu has
developed the main components with a total
control system. The result is a new genera-
tion of high performance and environment
friendly excavators.
Large Digging Force
With the one-touch Power Max. function digging force has
been further increased. (8.5 seconds of operation)
Maximum arm crowd force (ISO):
218 kN (22.2t) 233 kN (23.8t)
(with Power Max.)
Maximum bucket digging force (ISO):
259 kN (26.4t) 278 kN (28.3t)
(with Power Max.)
*Measured with Power Max function, 3380 mm 11'1" arm and ISO rating
7%
UP
7%
UP
HYDRAULIC EXCAVATOR
PC450-8R 0
PC450-8R
Working Modes Selectable
Two established work modes are further improved.
P mode – Power or
work priority mode has
low fuel consumption,
but fast equipment
speed and maximum
production and power
are maintained.
E mode – Economy or
fuel priority mode
further reduces fuel
consumption, but
maintains the P-mode-like working equipment speed for light
duty work.
You can select Power or Economy modes using a one-touch
operation on the monitor panel depending on workloads.
E
P
Fuel priority
E mode
Work priority
P mode
Idling Caution
To prevent unnecessary
fuel consumption, an idling
caution is displayed on the
monitor, if the engine idles
for 5 minutes or more.
Eco-gauge that Assists Energy-saving Operations
Equipped with the Eco-gauge that can be recognized at a
glance on the right of the multi-function color monitor for
environment-friendly
energy-saving opera-
tions. Allows focus on
operation in the green
range with reduced CO
2
emissions and efficient
fuel consumption.
Eco-gauge
Smooth Loading Operation
Two return hoses improve
hydraulic performance. In the arm
out function, a portion of the oil is
returned directly to the tank
providing smooth operation.
Boom floats upward, reducing
lifting of machine front. This
facilitates gathering blasted rock
and scraping down operations.
Boom pushing force is
increased, ditch digging and
box digging operation on hard
ground are improved.
Two-mode Setting for Boom
Smooth mode provides easy operation for gathering blasted
rock or scraping down operation. When maximum digging
force is needed, switch to Power mode for more effective
excavating.
Smooth mode Power mode
Return hoses
Variable Track Gauge (optional)
● Lateral stability is significantly improved when operating
with the gauge extended.
● Lateral stability is increased by 30% (compared with the
fixed gauge version).
● With trackframes retracted, overall width complies with
many local transportation regulations.
H YDRAULIC E XCAVATOR
Hydraulic control valve
Hydraulic system
controller
Main pump
Electronic control
unit for engine
Seven-inch TFT
liquid crystal display
Engine
Heavy duty HPCR (High Pressure
Common Rail) system
