Kodak ESP 5200, ESP 5250 - All-in-one Printer, ESP 5200 Series User Manual
User Guide • Guide d'utilisation
MS SD/HC MMC
All-in-One Printers • Imprimantes tout-en-un
5200 Series
KODAK ESP 5200 Series All-in-One Printers
Your KODAK All-in-One Printer combines ease-of-use and affordable inks to provide high-quality
pictures and documents.
Resources
Support is available! Go to www.kodak.com/go/aiosupport, and select your printer model for:
• Frequently Asked Questions (FAQs)
• software or firmware upgrades
• Extended User Guide
•and more!
If you prefer, you can chat online, send us an e-mail, or call for technical support. Go to
www.kodak.com/go/contact.
Table of Contents
www.kodak.com/go/aiosupport3
1 Printer Overview
Components...........................................................................................................................................4
Control panel .........................................................................................................................................5
Home Center Software ......................................................................................................................6
Paper ........................................................................................................................................................6
Paper types ......................................................................................................................................6
Paper sizes .......................................................................................................................................6
Loading plain paper........................................................................................................................7
Loading photo paper .....................................................................................................................8
2 Basic Functions
Printing ....................................................................................................................................................9
Printing documents........................................................................................................................9
Printing pictures..............................................................................................................................9
Copying .................................................................................................................................................. 11
Scanning................................................................................................................................................ 12
Ordering supplies ............................................................................................................................... 12
3 Troubleshooting
Basic troubleshooting ........................................................................................................................ 13
Getting help on the Web ..................................................................................................................14
4 Safety and Warranty Information
Safety Information.............................................................................................................................. 15
LCD Screen Safety........................................................................................................................ 15
Ink Cartridge Safety ..................................................................................................................... 15
Warranty Information .......................................................................................................................16
Limited Warranty ......................................................................................................................... 16
Limited Warranty Coverage ...................................................................................................... 16
Limitations......................................................................................................................................16
Your Rights..................................................................................................................................... 17
Outside the United States and Canada .................................................................................. 17
Declaration of Conformity................................................................................................................ 17
4 www.kodak.com/go/aiosupport
1
Printer Overview
This printer lets you print, copy, and scan pictures and documents.
Components
1 Wi-Fi connectivity LED 9 Printhead with ink cartridges installed
2 Memory card slot 10 Right paper-edge guide
3 Control panel 11 Paper tray
4 LCD 12 Paper tray extender / paper stop
5 USB port 13 Left paper-edge guide
6 Power cord connection port 14 Scanner glass
7 Rear-access cleanout area 15 Scanner lid
8 Printer access door
5 6 7
8
14
4
1
3
2
13
12
11
10
15
9
www.kodak.com/go/aiosupport 5
KODAK ESP 5200 Series All-in-One Printer
Control panel
Feature Description
1 LCD Displays pictures, messages, and menus; lifts for easy viewing
2 On/Off button Turns the printer on or off
3 Home button Displays the main menu, and toggles between screens
4 Navigation buttons Used to navigate menus, scroll through pictures
5 Zoom buttons Enlarge or reduce the size of the displayed picture
6 Start button Begins copying, scanning, printing, maintenance task, and file transfer
7 Cancel button Stops the current operation and returns to the menu
8 Rotate button Changes the orientation of the displayed picture
9 OK button Selects a menu item, accepts a zoom setting, and allows you to continue with the
current operation
10 Back button Displays the previous screen
1
2
3
4
5
6
7
9
10
8
Printer Overview
6 www.kodak.com/go/aiosupport
Home Center Software
The KODAK Home Center Software is installed with your KODAK All-in-One
Printer Software. The Home Center icon will appear on your desktop.
On a computer with WINDOWS Operating System (OS), you can use Home
Center Software to browse and edit pictures, print, copy, scan, order supplies,
access the Extended User Guide, and configure your all-in-one printer from your
computer.
On a computer with MAC OS, you can use Home Center Software to order
supplies and configure your printer from your computer.
Paper
For the best photo printing results, use KODAK Photo Papers, which are
optimized to work with KODAK All-in-One Printers.
For the best document printing results, use KODAK Document Papers or a paper
with the COLORLOK Technology logo on the package. Use only paper that is
designed for inkjet printers.
Paper types
You can use:
• Plain paper — 20 to 24 lb / 75 to 90 gsm
• Photo paper — 10 mils
• Card stock — 110 lb / 200 gsm, max
• Envelopes — most standard types
• Transparencies — inkjet variety with white stripe
• Labels — all commercially available inkjet varieties on 8.5 x 11-in. or A4
sheets
• Iron-on transfers — all inkjet varieties on 8.5 x 11-in. or A4 sheets
Paper sizes
4 x 6 in. / 10 x 15 cm to 8.5 x 14 in. / 22 x 36 cm
For more information about paper types and sizes, see the Extended User Guide
at www.kodak.com/go/esp5250support or
www.kodak.com/go/esp5210support.
