KLIM DOMINATION
USER MANUAL
KLIM Domination User Manual www.klimtechs.com
2
Dimensions
467 x 158 x 36.5 mm
Actuation force
60 g
Weight
1260 g
Keystrokes
60 million
Cable length
180 cm
Current
0.4 A ± 10 %
Switches
Outemu blue
Voltage
5 V
0. INTRODUCTION
On behalf of the entire KLIM Team, thank you for purchasing our KLIM Domination
mechanical keyboard. We hope it meets your expectations and that you enjoy using this
device.
Featuring
Outemu blue mechanical switches
Anti-ghosting and 6-keyrollover
High durability (60 million key presses)
Fully customizable RGB lighting
Multimedia and function keys
Compatible with Windows, MacOS & PS4
I. PRODUCT DESCRIPTION
The diagram below shows the special keys used to customize the keyboard's lighting effects,
as well as the multimedia keys at the top.
Technical specifications
KLIM Domination User Manual www.klimtechs.com
3
II. USING THE KEYBOARD
The KLIM Domination features a Function key (FN) which can be combined with certain
keys to change lighting effects or activate different functions on your computer. It has 21
different lighting effects and 8 colors for each key, giving you total freedom to customize
its appearance. There are about 16 million possible combinations at your disposal!
Brightness, speed and direction
FN + : increases brightness (5 levels)
FN + : decreases brightness (5 levels)
FN + : increases speed. Hold to increase it significantly
FN + : decreases speed. Hold to decrease it significantly
FN + : switches effect direction
FN + : changes colors
NOTE: The 3 top-right LEDs will flash when the maximum or minimum values have been
reached. Speed and direction settings available for certain effects only.
Lighting effects
You can select the desired lighting effect by pressing the following combinations. Each key
has 3 different modes; you can cycle through them by pressing it repeatedly:
FN + : Neon / Breathing mode / Vertical Stripes
FN + : Reactive wave / Reactive key / Reactive Row
FN + : Wave / Blast / Waterfall
FN + : Horizontal flow / Arrow / Radar mode
FN + : Multicolor / Raindrops / Vertical flow
FN + : Wiper / Fixed color / Pulse
Advanced color customization
Customize each key individually using the advanced color customization mode:
1. Press FN + to select your custom mode. Press it again to start editing keys. The
3 top-right LEDs will flash, indicating that the customization mode is active
2. Press FN + to cycle through the available colors. The key will start blinking
3. Press any key on the keyboard to change it to the color shown on the key
4. You can turn off specific keys by pressing FN + until the key is off
5. When you are done editing your key colors, press FN + again to save the changes
You can recall this color scheme at any time after using any of the default lighting effects
by pressing FN + .
KLIM Domination User Manual www.klimtechs.com
4
Multimedia keys
The Function key (FN) does not only allow for color customization, it also gives access to
a wide range of useful shortcuts:
FN + F1: Media player
FN + F2: Volume -
FN + F3: Volume +
FN + F4: Mute sound
NOTE: Some function shortcuts are not available on MacOS.
FN + F5: Stop
FN + F6: Previous track
FN + F7: Play/Pause
FN + F8: Next track
FN + F9: E-mail client
FN + F10: Home (browser)
FN + F11: Calculator
FN + F12: Search (browser)
Reset keyboard & Win Lock key
Press FN + Esc + F1 + F3 + F5 to restore the keyboard's factory settings.
Press FN + WIN to deactivate the Windows key.
IV. TROUBLESHOOTING
If you ever encounter any problems, remember that we remain at your disposal to help you
with any issues. Do not hesitate to contact us at support@klimtechnologies.com for
additional support.
The computer is typing more than one character with a single press
This effect is known as "key chattering" and can sometimes happen due to the nature of
mechanical keyboards. Here is how you can fix it:
1) Remove the keycap of the affected key (use your fingers or the removal tool included)
2) Take a thin, blunt object such as a ballpen and push the blue switch down until it "clicks"
3) Repeat this for each of the 4 sides of the switch
4) Place the keycap back on the switch and try the affected key
For a video demonstrating the above procedure or for any additional help, contact us
directly via e-mail.
It is also recommended that you clean your keyboard regularly to remove any excess dust
on the switches and avoid further problems.
We thank you again for your purchase and hope that you enjoy using our KLIM Domination
keyboard. Do not hesitate to leave a comment on the site you purchased it from, it will
help us tremendously :)
The KLIM team
