96M13984

Handheld Mobile Computer

BT-W70GA/W75GA

Instruction Manual

Introduction

Read this instruction manual before using the product in order to achieve maximum performance. Keep this instruction manual in a safe place after reading it so that it can be used at any time. In this instruction manual, the BT-W70GA Series means the BT-W70GA and BT-W75GA.

Symbols

The following symbols alert you to important messages. Be sure to read these messages carefully.

It indicates a hazardous situation which, if not avoided, will result in death or serious injury.

It indicates a hazardous situation which, if not avoided, could result in death or serious injury.

It indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

It indicates a situation which, if not avoided, could result in product damage as well as property damage.

It indicates cautions and limitations that must be followed during operation.

It indicates additional information on proper operation.

It indicates tips for better understanding or useful information.

• IEEE802.11a/b/g/n: Wireless LAN standards established by 802 committee which has designed standards of LAN technology in IEEE (Institute of Electrical and Electronics Engineers).

• Bluetooth

•microSD

• Microsoft, Windows, Internet Explorer and Visual Studio are registered trademarks or trademarks

• The official name for Windows is "Windows

• ARM Cor tex is a trademark and registered trademark of ARM Limited in EU and other

• Other company names or product names described in this manual are registered

• It is prohibited to use or copy all or any par t of this manual without prior approval.

• The infor mation contained in this manual is subject to change without notice.

under license. Other trademarks or trade names belong to each owner.

of Microsoft Corporation in the United States and other countries.

countries.

trademarks or trademarks of each company.

wordmark and logo belong to Bluetooth SIG, Inc. and KEYENCE uses them

is a trademark of SD Card Association.

operating system".

Safety Precautions on Laser Product

This product employs a semiconductor laser for its light source.

Item

Wavelength 655 nm 655 nm

Output 1.0 mW 390 ¦W

Laser Class

* The laser classification for FDA(CDRH) is implemented based on IEC60825-1 in

accordance with the requirements of Laser Notice No.50.

Follow the instructions mentioned in this manual. Otherwise, injury to the human body (eyes and skin) may result.

Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

• Do not disassemble this product. Laser emission from this product is not automatically stopped when it is disassembled.

Class 1 Laser Product

• Do not stare into the direct or specularly reflected beam.

Class 2 Laser Product

• Do not stare into the direct or specularly reflected beam.

• Do not direct the beam at other people or into areas where other people unconnected with the laser work might be present.

• Be careful of the path of the laser beam. If there is a possibility that the operator may be exposed to the specular or diffuse reflections, block the beam by installing a protective enclosure.

• Install this product so that the path of the laser beam is not as the same height as that of human eye.

BT-W70GA

Class 2 laser product

(IEC60825-1,

FDA(CDRH) Part 1040.10*)

BT-W75GA

Class 1 laser product

(IEC60825-1,

FDA(CDRH) Part 1040.10*)

Safety Precautions on LED Product

• Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

• Follow the instructions mentioned in this manual. Otherwise, injury to the human body (eyes and skin) may result.

• Do not stare into the beam.

• Do not disassemble this product.

LED emission from this product is not automatically stopped when it is disassembled.

• Do not view directly with optical instruments. Viewing the LED

output with certain optical instruments (for example, eye loupes, magnifiers and microscopes) within a distance of 100 mm may pose an eye hazard.

Locations of warning / explanation labels

BT-W70GA BT-W75GA

Safety Information for the BT-W70GA Series

General cautions

• Do not use this product for the purpose of protecting a human body or a part of human body.

• This product is not intended for use as an explosion-proof product. Do not use this product in a hazardous location and/or potentially explosive atmosphere.

• Suffocation may result from wrapping the lanyard around the neck. Be careful to use BT-W70GA around a power-driven machine on work.

• Verify that this device is operating normally in terms of functionality and performance before the start of work and when operating the device.

• We recommend that you take substantial safety measures to avoid any damage in the event that a problem occurs.

• If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.

• Do not throw, drop or trample down the BT-W70GA Series and accessories to strong physical shock.

• Keep BT-W70GA Series or accessories out of the reach of children. Children may swallow batteries, batteries attachment covers and straps around themselves.

• When the BT-W70GA Series is used in combination with other instruments, functions and performance may be degraded, depending on operating conditions and the surrounding environment.

• The LCD panel may generate microscopic spots (black/bright spot),

NOTICE

uneven brightness or crosstalk (phenomenon that non-existent lines or patterns are displayed), depending on the conditions.

• If the same display remains on the screen for a long time, afterimage may occur due to the characteristics of LCD.

The warning labels are only affixed to and included with the class 2 laser product.

E BT-W70GA/W75GA-IM



Precautions on Regulations and Standards

CAUTION

FCC Regulations

• This device complies with par t 15 of the FCC Rules. Operation is subject to the following two conditions; (1) This device may not cause harmful interface, and (2) this device must accept any interference received, including interference that may cause undesired operation.

• Application regulation

FCC Part 15 Subpart B ClassA FCC Part 15 Subpart C FCC Part 15 Subpart E

• The available scientific evidence does not show that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power Wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure of low-level RF that does not produce heating effects causes no known adverse health effects. Many studies of low-level RF exposures have not found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research. The BT-W70GA Series has been tested and found to comply with FCC radiation exposure limits set forth for an Controlled environment and meets the FCC radio frequency (RF) Exposure Guidelines.

• Compliance with FCC requirement 15.407(c) Data transmission is always initiated by software, which is the passed down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In other words, this device automatically discontinue transmission in case of either absence of information to transmit or operational failure.

• 5.15-5.35GHz band is restricted to indoor operations only.

• Frequency Tolerance: ±25ppm

Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

• FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

• This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.

IC Regulations

The BT-W70GA Series complies with the following regulations specified by the IC.

• Applicable regulation ICES-003 RSS-247

• The available scientific evidence does not show that any health problems are

associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power Wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure of low-level RF that does not produce heating effects causes no known adverse health effects. Many studies of low-level RF exposures have not found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research. The BT-W70GA Series has been tested and found to comply with IC radiation exposure limits set forth for an uncontrolled environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules.

• 5150-5350 MHz band is restricted to indoor operation only.

High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.

• Data transmission is always initiated by software, which is the passed down through the

MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In other words, this device automatically discontinue transmission in case of either absence of information to transmit or operational failure.

• Les connaissances scientifiques dont nous disposons n’ont mis en évidence aucun

problème de santé associé à l’usage des appareils sans fil à faible puissance. Nous ne sommes cependant pas en mesure de prouver que ces appareils sans fil à faible puissance sont entièrement sans danger. Les appareils sans fil à faible puissance émettent une énergie radioélectrique (RF) très faible dans le spectre des micro-ondes lorsqu’ils sont utilisés. Alors qu’une dose élevée de RF peut avoir des effets sur la santé (en chauffant les tissus), l’exposition à de faibles RF qui ne produisent pas de chaleur n’a pas de mauvais effets connus sur la santé. De nombreuses études ont été menées sur les expositions aux RF faibles et n’ont découvert aucun effet biologique. Certaines études ont suggéré qu’il pouvait y avoir certains effets biologiques, mais ces résultats n’ont pas été confirmés par des recherches supplémentaires. Le BT-W70GA série a été testé et jugé conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les règles d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC.

• La bande 5150-5350 MHz est restreinte à une utilisation à l’intérieur seulement. Les

radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu'ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz, et ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.

• Conformité à la norme CNR-210 A9.4.4

La transmission des données est toujours initiée par le logiciel, puis les données sont transmises par l'intermédiaire du MAC, par la bande de base numérique et analogique et, enfin, à la puce RF. Plusieurs paquets spéciaux sont initiés par le MAC. Ce sont les seuls moyens pour qu'une partie de la bande de base numérique active l'émetteur RF, puis désactive celui-ci à la fin du paquet. En conséquence, l'émetteur reste uniquement activé lors de la transmission d'un des paquets susmentionnés. En d'autres termes, ce dispositif interrompt automatiquement toute transmission en cas d'absence d'information à transmettre ou de défaillance.

• This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

• Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

E BT-W70GA/W75GA-IM

UL certification

The BT-W70GA Series complies with the following UL/CSA standards and has obtaied the UL/C-UL certifications.

• Applicable standards UL60950-1

• UL File No. E167973

• UL category NWGQ/NWGQ7

BT-WB2GA means the BT-LIBS standard battery and the battery attachment cover.

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

Mexico(Méjico)

La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
