Owner’s m a nual

Platinum Plus B79 Keurig® Brewer

IMPORTANT SAFEGUARDS Safe Operation & Use

When using electrical appliances, basic safety precautions should be followed, including the following:

1. Read all instructions before using.

2. Do not touch hot surfaces. Use handles

and knobs when available.

3. This appliance must be properly installed and located in accordance with these instructions before it is used.

4. The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electrical shock or injury to persons.

5. Do not place on or near a hot gas or electric burner, or in a heated oven.

6. Do not use outdoors.

7. To protect against fire, electric shock and

injury do not immerse cords, plugs, or the appliance in water or any other liquid.

8. Do not overfill the Water Reservoir

with water.

9. Use only water in this appliance! Do not put

any other liquids or foods in the Water Reservoir except as instructed in the Cleaning Instructions in this guide.

10. Turn off and unplug the Brewer before

cleaning or maintenance. Allow to cool

before putting on or taking off parts and before cleaning the appliance.

11. For best operation, plug the appliance into its own electrical outlet on a dedicated circuit to prevent flickering of lights, blowing of fuses or tripping a circuit breaker.

12. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or is damaged in any manner. Contact Keurig

Customer Service to report any malfunction of or damage to the Brewer.

13. Do not let the cord hang over the edge of the table or counter, or touch hot surfaces.

14. To disconnect, press the Power Button on

the Brewer to ‘OFF’ status and then remove the plug from the wall outlet.

15. Close supervision is necessary when any appliance is used by or near children.

16. Do not lift the Handle to open the Lid of the Brewer while brewing is in progress.

17. Always keep the Water Reservoir Lid

on the Water Reservoir unless you are refilling it.

18. This appliance is equipped with a power

cord having a grounding wire with a grounding plug. The appliance must be grounded using a 3-hole properly grounded outlet. In the event of an electrical short

circuit, grounding reduces the risk of electrical shock.

19. If the outlet is a standard 2-prong wall outlet, it is your personal responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet.

20. Do not, under any circumstances, cut or remove the third (ground) prong from the power cord or use an adapter.

21. Consult a qualified electrician if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded.

22. Do not use the appliance for other than its intended use.

INSTRUCTIONS.

WARNING TO USERS AND PARENTS

1. DO NOT permit children to use Brewer

unless there is adult supervision. Brewer dispenses very hot water.

2. SPECIAL NOTICE FOR HOT COCOA USERS: IMMEDIATELY AFTER USING A HOT COCOA K-CUP Brew Cycle without a portion pack to avoid

the possibility of clogging the exit needle.

DO NOT assume the next user will do this.

SAVE THESE

PORTION PACK, RUN a Hot Water

CAUTIO N: There are two sharp needles that puncture the K-Cup® portion pack, one above the K-Cup To avoid risk of injury, do not put your fingers in the K-Cup

CAUTIO N: There is extremely hot water in the K-Cup brew process. To avoid risk of injury, do not lift the Handle or open the K-Cup Assembly Housing during the brewing process.

SHORT C ORD INSTR UCTIONS :

reduce the risk of becoming entangled in or tripping over a longer cord.

If an extension cord is used, (1) the marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance; (2) the cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally; and (3) the extension cord must include a 3-prong grounding plug.

THIS PRODUCT IS FOR HOUSEHOLD USE ONLY.

Holder and the other in the bottom of the K-Cup® Holder.

A short power supply cord is provided to

Assembly Housing.

Holder during the

WARNING THIS PRODUCT CONTAINS CHEMICALS, INCLUDING

LEAD, WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.

WARNING: TO REDUCE THE RISK OF FIRE OR

WARNING

RISK OF FIRE OR ELECTRIC SHOCK

DO NOT OPEN

ELECTRIC SHOCK, DO NOT REMOVE THE BOTTOM COVER. NO USER SERV ICEABLE PARTS ARE INSIDE. REPA IR SHOULD BE DONE

BY AUTHORIZED SERVICE PERSONNEL ONLY.

TABLE OF CONTENTS

KEURIG® GOURMET SINGLE CUP HOME BREWING SYSTEM

Platinum Plus B79 — Using Your Brewer

SET-UP

Helpful Hints ........................................................................................ 4

Unpacking ............................................................................................4

Features ...............................................................................................5

SECTION 1 — SET-UP & FIRST BREW

Set-Up & First Brew ...........................................................................6

SECTION 2 — CONTROLS & INDICATORS

Setting the Clock ............................................................................... 11

Programming On/Off Features ...................................................... 11

Programming Brew Temperature .................................................13

Programming Brew Size .................................................................14

SECTION 3 — CLEANING & MAINTENANCE

Cleaning .............................................................................................. 14

De-Scaling.......................................................................................... 15

Storage ...............................................................................................16

SECTION 4 — TROUBLESHOOTING .................................................. 17

SECTION 5 — WARRANTY ................................................................ 18

Record your Brewer Serial Number here.

See Unpacking Instructions on page 4 for serial number location.

Removing the serial number label from the Brewer will void warranty.

Set-Up

Features Platinum Plus — Model B79 Brewer

Helpful Hints

1. Plug Brewer into its own grounded outlet.

If the electric circuit is overloaded with other appliances, your Brewer may not function properly. The Brewer should be operated on its own circuit, separate from other appliances.

2. Keep your Brewer turned “ON”.

To brew a fresh cup of coffee, tea or hot cocoa

anytime you want, keep your Brewer turned

“ON” all the time. However, the Brewer is fully

programmable so you can set it to turn on and off automatically to match your schedule. Or, if you prefer, set the Brewer to automatically turn off after a period of time. Follow the simple instructions on pages 11–14 to find the settings that are most convenient for you.

3. For the best tasting gourmet coffee, tea or hot cocoa, Keurig recommends using bottled or filtered water.

Water quality varies from place to place. If you notice an undesirable taste in your cup of coffee, such as chlorine or other mineral tastes, we recommend you consider using bottled water or water from a filtration system. For best results, carefully follow manufacturer’s instructions when using any water filtration system.

4. Customize the size, flavor & brew that’s perfect for you.

With the choice of over 200 varieties of K-Cup® portion packs and 5 brew sizes (Extra-Small Cup-3.25 oz., Small Cup-5.25 oz., Small Mug-

7.25 oz., Large Mug-9.25 oz., and Travel Mug-

11.25 oz.) your Keurig® Brewer gives you endless options to customize the size, flavor and brew that’s perfect for you. For a strong, intense cup, select an Extra Bold portion pack (with up to 30% more ground coffee than regular varieties) and brew size that’s right for you. The smaller the brew size, the more intense flavor in your cup. The larger the brew size, the less intense flavor in your cup.

5. Remove K-Cup® portion pack after use.

Please see page 7 for brewing instructions.

6. Brewing into a travel mug.

To brew into a travel mug, simply remove the Drip Tray Assembly and place the travel mug

on the Drip Tray Base.

7. De-scale Brewer regularly.

Please see pages 15 and 16 for instructions.

Unpacking Instructions

1. Place Brewer box on a large steady surface

(such as a table or countertop) or on the floor. Open the box.

2. Remove enclosed literature.

3. Turn the box on its side with front of box

face down.

4. Reach into the box and grasp the plastic bag

that contains the Brewer.

5. Carefully pull the plastic bag (and packaging

materials) toward you and out of the box. The Brewer will still be encased in the polyfoam and be on its side.

6. Remove the top polyfoam packaging material.

7. Carefully lift Brewer off of the bottom polyfoam

and place it upright on a flat, steady surface.

8. Lift plastic bag off of Brewer.

9. Record the serial number for this Brewer on

page 3 of this guide. The serial number can be found on the bottom of the Brewer box or on the Brewer behind the Drip Tray (when removed).

10. Place the Brewer upright on a flat, steady

surface. Remove tape holding Water Reservoir in place.

We recommend you save all packing materials in case future shipping of the product is necessary.

WARNING:

Keep all plastic bags away

from children.

Platinum Plus B79 Brewer

A. Water Reservoir Lid B. Water Reservoir C. Water Reservoir

Lock Tab Slot

D. Handle E. Funnel

F. K-Cup

Holder (E and F are the K-Cup® Holder Assembly)

G. Lid H. K-Cup

Assembly Housing

Portion Pack

Controls and Indicators

I. Housing J. Drip Tray Plate K. Drip Tray L. Drip Tray Base M. Vent

N. Power Cord O. Power Switch (Not

shown) Located Rear Right Side of Brewer

P. LCD Control Center Q. Left Button R. Right Button S. MENU Button T. BREW Button U. RINSE Button V. HOT WATER Button

SECTION 1 Set-Up & First Brew

IMPORTANT: You cannot use your Keurig® Brewer until it has been set up for its ﬁrst use as set forth below.

NOTE: If Brewer has been exposed to temperatures below freezing, allow Brewer at least two hours to reach room temperature before brewing. A frozen or extremely cold Brewer will not operate.

Setting Up Your Brewer

ﬁg.

5. Place Water Reservoir base into the left side of the Brewer and be sure the

Water Reservoir Lock Tab engages with the Brewer. Replace Lid on Water Reservoir. NOTE : Please ensure the Water Reservoir is seated properly, so

that the back of the Water Reservoir is flush with the Brewer (fig. 2 B and C).

1. Unwrap cord and plug the Brewer into a

grounded outlet. Remove all pieces of packing tape and clear plastic sticker from LCD display.

2. Place a large mug (10 oz. minimum) on the

Drip Tray Plate.

3. Remove the Water Reservoir from Brewer by

first removing Lid from the Water Reservoir (fig. 1), then lifting the Water Reservoir straight up and toward front of Brewer (may be tight), (fig. 2 A). Rinse with fresh water.

4. Fill Water Reservoir with bottled or filtered

water so that the water level is just below the top edge of the Water Reservoir.

ﬁg.

Lock Tab

A B

ﬁg.

REA DY

NOT

Seated Properly

Press and release the Power Switch found

directly behind the right side of the Brewer. Switch is spring loaded and will return to original position.

7. The Blue LCD Control Center will come on and

indicate “NOT READY.” NOTE: A K-Cup

pack should not be used for this sequence

8. The Brewer will automatically fill the internal

tank with water and then the water will be heated. This will take about 4 minutes. During the heating period, “NOT READY” is displayed on the LCD Control Center (fig. 3).

Do not lift Brewer Handle during this ‘heating period.’ Once the water is heated, “READY TO

BREW” will be displayed (fig. 4).

Not Seated Properly

portion

REA DY

TO BRE W

BREW

ﬁg.

NOTE: You may see small amounts of water coming

from the Vent and dripping into the Water Reservoir during this and subsequent heating — this is normal.

Lift and lower the Handle. Press the BREW

Button to start a cleansing brew without a K-Cup® portion pack. Pour the hot water into the sink.

NOTE: A portion pack should not be used for this Sequence

10. The one-time set-up process is now

complete and you are ready to brew!

NOTE: The Brewer may take 15-30 seconds between brews and then “READY TO BREW” will be displayed.

Ready to Brew Your First Cup

1. LCD Control Center will indicate

“READY TO BREW.”

2. Place a cup or mug on the Drip Tray Plate.

3. Lift the Handle and the K-Cup

will open toward you (fig. 5).

4. Select a portion pack.

NOTE: Do not remove the foil lid or puncture the portion pack.

Holder

ﬁg.

5. Place a portion pack in the K-Cup

CAUTIO N: There are two sharp needles that puncture the portion pack, one above the K-Cup Holder and the other in the bottom of the K-Cup

Holder. To avoid risk of injury, do not put your fingers in the K-Cup

6. Lower the Handle to close the Lid over the

Assembly Housing.

K-Cup® Holder. (When it is closed completely, the LCD Control Center will indicate “READY

TO BREW.” The Left and Right Buttons and

the BREW Button will be illuminated up to

60 seconds.)

a. All brew size icons are lit with the default

size flashing (fig. 7). To choose a different size, press Left Button to go down in size or Right Button to go up in size.

NOTE: The Small Mug is the factory set default brew size. To program your favorite brew size see page 14 “Programming Your Brew Size”.

Your choices are a stronger Extra-Small

Cup (3.25 oz. serving), a Small Cup (5.25 oz. serving), a Small Mug (7.25 oz. serving), a Large Mug (9.25 oz. serving) or a Travel Mug (11.25 oz. serving).

Holder (fig. 6).

6 7
