Keurig B70 User Manual 2

USE & CARE GUIDE

Gourmet Single Cup Home Brewing System

PLATINUM B70

Please read and save these instructions.

Pour des directives en français, veuillez vous reporter à la page 17

SAFE OPERATION & USE

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should be followed, including the following:

1. Read all instructions before using.

2. Do not touch hot surfaces. Use handles and knobs when available.

3. This appliance must be properly installed and located in accordance with these instructions before it is used.

4. The use of an accessory not approved for use with this appliance may cause injuries.

5. Do not place on or near a hot gas or electric burner, or in a heated oven.

6. Do not use outdoors.

7. To protect against electric shock, do not immerse cords, plugs, or the appliance in water or any other liquid.

8. Do not overfill the Water Reservoir with water.

only water

9. Use put any other liquids or foods in the Water Reservoir except as instructed in the Cleaning Instructions in this guide.

10. Unplug the coffee brewer before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.

11. For best operation, plug the appliance into its own electrical outlet on a dedicated circuit to prevent flickering of lights, blowing of fuses or tripping a circuit breaker.

12. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or is damaged in any manner. Contact Keurig Customer Service for assistance.

in this appliance! Do not

13. Do not let the cord hang over the edge of the table or counter, or touch hot surfaces.

14. To disconnect, press and release the Power Button on the back of the Brewer to ‘OFF’ status and then remove the plug from the wall outlet.

15. Close supervision is necessary when any appliance is used by or near children.

16. Do not lift the Handle to open the Lid of the Brewer while brewing is in progress.

17. Always keep the Water Reservoir Cover on the Water Reservoir unless you are refilling it.

18. This appliance is equipped with a power cord having a grounding wire with a grounding plug. The appliance must be grounded using a 3-hole properly grounded outlet. In the event of an electrical short circuit, grounding reduces the risk of electrical shock.

19. If the outlet is a standard 2-prong wall outlet, it is your personal responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet.

20. Do not, under any circumstances, cut or remove the third (ground) prong from the power cord or use an adapter.

21. Consult a qualified electrician if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded.

22. Do not use the appliance for other than its intended use.

SAVE THESE

INSTRUCTIONS.

CAUTION: There are two sharp needles that puncture the K-Cup above the K-Cup Holder and the other in the bottom of the K-Cup Holder T

o avoid risk of injury, do not put your

fingers in the K-Cup Chamber.

portion pack, one

KEURIG®GOURMET SINGLE CUP HOME BREWING SYSTEM

Platinum B70 Use & Care Guide

TABLE OF CONTENTS

CAUTION: There is extremely hot water in the K-Cup Holder during the brew process. T

o avoid risk of injury, do not lift the Handle or open the K-Cup Chamber during the brew process.

SHORT CORD INSTRUCTIONS: supply cord is provided to reduce the risk of becoming entangled in or tripping over a longer cord.

If an extension cord is used, (1) the marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance, (2) the cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally and (3) the extension cord must include a 3-prong grounding plug.

THIS PRODUCT IS FOR

A short power

HOUSEHOLD USE ONLY.

WARNING: This product contains chemicals, including lead, known to the State of California to cause c

cancer, birth def

ects or

other reproductive harm.

SECTION 1

SET-UP & OPERATION

Helpful Hints Unpacking Features Set-Up & First Brew

. . . . . . . . . . . . . . . . . . . . . . . . 4

. . . . . . . . . . . . . . . . . . . . . . . . . . . 4

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

. . . . . . . . . . . . . . . . . . 6

SECTION 2

CONTROLS & INDICATORS

LCD Control Center

. . . . . . . . . . . . . . . . . . . 9

SECTION 3

CLEANING & MAINTENANCE

Cleaning

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

De-Scaling Storage

. . . . . . . . . . . . . . . . . . . . . . . . . . 13

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

SECTION 4

TROUBLESHOOTING

. . . . . . . . . . . . . . . . . 15

SECTION 5

WARRANTY

Pour des directives en français, veuillez vous reporter à la page 17.

. . . . . . . . . . . . . . . . . . . . . . . . . . 16

WARNING

RISKOF FIRE OR ELECTRIC SHOCK

DO NOT OPEN

WARNING:

OR ELECTRIC SHOCK, DO NOT REMOVE

SERVICEABLE PARTS ARE INSIDE. REPAIR

TO REDUCE THE RISK OF FIRE

THE BOTTOM COVER. NO USER

SHOULD BE DONE BY AUTHORIZED

SERVICE PERSONNEL ONLY.

Record your Brewer Serial Number here. The Serial Number is located on the bottom of the Brewer on aa white sticker.

_________________________________

SECTION 1

SET-UP & OPERATION

Helpful Hints

1. Keep your Brewer turned ‘ON’ at all times.

To brew a fresh cup of coffee, tea or hot cocoa anytime you want, we suggest you keep your Brewer turned ‘ON’ all the time.

However, the Brewer is fully programmable so you can set it to turn on and/or off automatically to match your schedule. Or, if you prefer, set the Brewer to automatically turn off after a period of time.

Follow the simple instructions on page 9 and 10 to make using the Brewer convenient for you.

2. For the best tasting gourmet coffee, tea or hot

t cocoa, Keurig recommends using bottled

or filtered water.

Water quality varies from place to place. If you notice an undesirable taste in your cup of coffee such as chlorine or other mineral taste, we recommend you consider using bottled water or water from a filtration system.

3. Choose from four serving sizes. The perfect cup of coffee, tea or hot cocoa means something different to each coffee lover. Because your Keurig Brewer has a wide variety of coffees to choose from it’s easy to find your favorite taste profile. Your Brewer has five size options: a stronger small cup (5.25 oz. serving), a small mug (7.25 oz. serving), a large mug (9.25 oz. serving), a travel mug (11.25 oz. serving) and an iced beverage setting (3.25 oz. serving). Follow the simple instructions on page 7.

NOTE:

If you are searching for a "stronger" tasting cup of coffee, try our Extra Bold K-Cups. They have 30% more ground coffee in each K-Cup www.keurig.com for over 200 varieties of K-Cups.

portion pack. See

function properly. The Brewer should be operated on its own circuit, separate from other appliances.

5. Brewing into a travel mug. To brew into a travel mug, simply remove the

Drip Tray Assembly and place the travel mug on the Drip Tray Base.

Unpacking Instructions

1. Place Brewer box on a large steady surface (such as a table or countertop) or on the floor. Open the box.

2. Remove the Quick Start Guide, Use & Care Guide and other literature.

3. Remove the package of complimentary

4. Turn the box on its side with front of box

5. Reach into the box and grasp the plastic

6. Carefully pull the plastic bag (and

7. Remove the top polyfoam packaging

8. Carefully lift Brewer off the bottom

9. Lift plastic bag off Brewer.

10. Carefully turn the Brewer on its side and

11. Place the Brewer upright on a flat,

We recommend you save all packing materials in case future shipping of the product is necessary.

K-Cup

portion packs.

face down.

bag that contains the Brewer.

packaging materials) toward you and out of the box. The Brewer will still be encased in the polyfoam and be on its side.

material.

polyfoam and place it upright on a flat, steady surface.

record on page 3 of this book the Serial Number located on the white sticker on the bottom of the Brewer. The Serial Number is also located on the bottom of the Brewer box.

steady surface. Remove tape holding Water Reservoir in place.

4. P

Plug Brewer into its own grounded outlet.

If the electric circuit is overloaded with other appliances, your Brewer may not

WARNING: from children.

Keep all plastic bags away

Model B70 Brewer

Features

Water Reservoir Lid

Water Reservoir

Water Reservoir Lock Tab Slot

Handle

Portion Pack Holder (E and F are the K-Cup

K-Cup

Holder Assembly)

Funnel

K-Cup®Portion Pack Assembly Chamber Housing Lid

K-Cup®Portion Pack Assembly Chamber Housing

Housing

Drip Tray Plate

Drip Tray

Drip Tray Base

Vent

Power Cord

Power Switch (Not shown)

Located Rear Right Side of Brewer

Controls and Indicators

LCD Control Center

LEFT Button

RIGHT Button

MENU Button

BREW Button

LCD Control Center

Set-Up & First Brew

IMPORTANT: Brewer until it has been primed for its first use as set forth below.

NOTE: tures below freezing, allow Brewer at least two hours to reach room temperature before priming. A frozen or extremely cold Brewer will not prime properly and can cause damage.

You cannot use your Keurig

If Brewer has been exposed to tempera-

Priming Your Brewer

1. Unwrap cord and plug the Brewer into a grounded outlet.

2. Place a 12 oz. mug on the Drip Tray Plate.

3. Remove the Water Reservoir from Brewer by first removing Lid from Reservoir, then lifting Reservoir straight up and toward front of Brewer. Rinse with fresh water.

4. Fill Water Reservoir with bottled or filtered water so that the water level is just below the top edge of the reservoir.

5. Place Water Reservoir into the left side of the Brewer and be sure the Water Reservoir Lock Tab engages with the Brewer. Replace Lid on Water Reservoir.

NOTE:

If the Water Reservoir is empty or not in place on the Brewer, then the LCD Control Center will indicate ‘ADD WATER’ and tank LED’s will flash. None of the Buttons will be active until water is added to the Water Reservoir.

8. Press the ‘BREW’ Button.

9. The Brewer will automatically fill with water (priming it) and then the water will be heated. This will take about 4 minutes. During the heating period ‘NOT READY’ is displayed on the LCD Control Center. Once the water is heated, ‘READY TO BREW’ will be displayed and the ‘BREW’ Button will flash.

NOTE:

You may see small amounts of water coming from the Vent and dripping into the Water Reservoir during this and subsequent heating – this is normal.

6. Press and release the Power Switch found directly behind the Brewer. Switch is spring loaded and will return to original position.

7. The Blue LCD Control Center will come on and indicate ‘PRIME’ and the ‘BREW’ Button will flash. Please note, a K-Cup should NOT be used for the Priming Sequence.

10. Press the ‘BREW’ Button to start a cleansing brew, during which hot water will flow into your mug. When the flow stops, discard the hot water.

11. The one-time priming process is now complete and you are ready to brew your first cup!

NOTE:

The Brewer may take 15-30 seconds to reheat water between brews and then ‘READY TO BREW’ will be displayed.

Ready to Brew Your First Cup

K-Cup portion pack

K-Cup Chamber

1. LCD Control Center will indicate ‘READY TO BREW’.

2. Place a cup or mug on the Drip Tray Plate.

3. Lift the Handle and the K-Cup chamber will open toward you.

CAUTION: There are two sharp needles that

puncture the K-Cup the K-Cup Holder and the other in the bottom of the K-Cup Holder. do not put your fingers in the K-Cup Chamber.

4. Select a K-Cup

NOTE: puncture the K-Cup

5. Place a K-Cup®portion pack in the K-Cup Holder (as shown in exhibit at top of page).

6. Lower the Handle to close the Lid over the K-Cup Holder. (When it is closed completely, the LCD Control Center will indicate ‘READY TO BREW’. The ‘LEFT’ and ‘RIGHT’ Buttons will be lit and the ’BREW’ Button will flash up to 60 seconds.)

Handle

portion pack, one above

o avoid risk of injury,

portion pack.

Do not remove the foil lid or

portion pack.

b. Your choices are a stronger small cup (5.25

oz. serving), a small mug (7.25 oz. serving), a large mug (9.25 oz. serving), a travel mug (11.25 oz. serving) or iced beverage setting (3.25 oz. serving).

c. To use the iced beverage setting, place a tall

glass filled with ice on the drip tray. Use your favorite K-Cup, select the iced beverage brew size and press the brew button. Add more ice once brewing is complete, add cream and sugar if desired.

d. Once size is chosen, press ‘BREW’ Button.

BREW Button will stop flashing, LEFT and RIGHT Buttons will no longer be lit and icon of brew size will be lit.

NOTE:

If you do not push the Brew Button in 60 seconds, the LCD Control Center will return to ’READY TO BREW’ and the Brew Buttons will be disabled to prevent accidental activation. Re-activate the Brew sequence by raising and lowering the Handle completely.

7. The LCD Control Center will now display the word ‘BREWING’ and the serving size you selected will be illuminated on LCD.

a. All brew size icons are lit with the default

size flashing. To choose a different size, press ‘LEFT’ Button to go down in size or ‘RIGHT’ Button to go up in size.

NOTE:

The small mug (7.25 oz. serving) is the factory set default brew size. To program your favorite brew size see page 11 “Programming Your Brew Size”.

CAUTION: There is extremely hot water in the K-Cup Holder during the brew process.

o avoid risk of injury, do not lift the

T Handle or open the K-Cup Chamber during the brew process.

8. There may be a short pause before the brewing process begins. The process lasts about 60 seconds and ends with a burst of air to remove all liquid from the K-Cup.

9. Lift the Handle and remove and dispose of the used K-Cup.

10. Enjoy your first cup of Keurig Brewed

CAUTION: K-Cup will be hot.

gourmet coffee, tea or hot cocoa!

11. Your Brewer will display ‘NOT READY’ as it heats water for the next brew cycle. The ‘READY TO BREW’ indication will return to the LCD Control Center in about 15-30 sec.

NOTE:

Following the brew, your Brewer will fill in preparation for the next brew. The pump will make a vibrating sound. This is normal.

Reservoir, then lifting the Water Reservoir straight up and toward front of Brewer. Fill with water. Place the Water Reservoir back on the Brewer and replace the Lid.

IMPORTANT: Reservoir during the brewing process.

Do not remove the Water

Stopping the Brew Process

If you need to stop the brewing after the process has started, press and release the Power Switch to turn the Brewer ‘OFF’. The flow of coffee, tea or hot cocoa will stop, the heating element will shut off and the blue lights illuminating the LCD Control Center and Water Reservoir will disappear.

NOTE:

You may get less coffee, tea or hot cocoa in your cup during your next brew. We recommend that you perform a cleansing brew with water only after a terminated brew. Then your NEXT brew will be the volume you have selected.

Adding Water

The LCD Control Center of your Brewer will indicate when the water level in the tank is low or if the Water Reservoir has been removed by displaying the words ‘ADD WATER’. The Brewer will not allow you to initiate a brew when ‘ADD WATER’ is displayed.

The Water Reservoir can be filled in two ways.

1. Lift off the Water Reservoir Lid and pour water directly into the Water Reservoir while it is still attached to the Brewer, then replace the Lid.

2. Remove the Water Reservoir from Brewer

by first removing Lid from the Water

Brewing Hot Water

Your Brewer is able to produce a cup of hot water for making hot chocolate in a packet, for use in cooking, for making soups, etc. Simply follow the instructions on page 7 - “Ready To Brew Your First Cup” without adding a K-Cup Portion Pack.

NOTE:

After brewing a hot cocoa K-Cup, we recommend running a hot water brew cycle without a K-Cup.

Purging the Brewer

If your Brewer has not been used for more than one week, you should purge the water from the inner tank.

1. If there is water in the Water Reservoir, remove the Lid, then lift the Water Reservoir straight up and toward front of the Brewer. Discard water, rinse and refill with bottled or filtered water. Place the Water Reservoir back on the Brewer and replace the Lid. (If there is no water in the Water Reservoir, simply refill.)

2. Be sure the Brewer is turned on. Raise and lower the handle on the Brewer without inserting a K-Cup

3. The LCD Control Center will display ‘READY TO BREW’ and the ‘LEFT’, ‘RIGHT’ and ‘BREW’ Buttons will flash. Be sure to have a 12 oz. mug on the Drip Tray and then select the Travel Mug size brew.

4. Repeat steps 2 and 3 two more times to completely purge water from inner tank.

If you are experiencing any problems with your Brewer, please contact Customer Service at 1-866

portion pack.

6-901-BREW (273

9).

SECTION 2

CONTROLS & INDICATORS

LCD Control Center

Setting the Clock

Setting the clock is optional. When the clock is set, the time will appear on the LCD Control Center. NOTE: You must set the clock if you will be using the Auto On/Off Time programming feature.

a. Press the ‘MENU’ Button.

b. The word ‘OFF’ will appear at the top of the

LCD Control Center to indicate that the clock is not set. The programming options will appear on the LCD Control Center with a small arrow pointing to ‘SET CLOCK’. H (Hour) will appear above the ‘LEFT’ Button and M (Minute) will appear above the ‘RIGHT’ Button. The ‘H’ and ‘M’ icons and ‘LEFT’ and ‘RIGHT’ Buttons will flash.

Programing On/Off Features

The Brewer provides three modes so that you can enjoy gourmet coffee, tea or hot cocoa on your own schedule. By programming your Brewer to turn on each morning, you will never have to wait for the Brewer to warm up. It will take the Brewer approximately 3 1/2 minutes to warm up from room temperate.

1. Leave Brewer ON All the Time (recomm

mende

d). The Brewer can be left on all the time so that it is always ready to brew a fresh cup of gourmet coffee, tea or hot cocoa. To turn the Brewer off at any time, simply press and release the Power Switch. (Note: Although the clock remains on, if set, you can not brew a cup of coffee, tea or hot cocoa). Press and release the Power Button again to restore power to the Brewer. You will have to wait for the water to heat up before the Brewer is ready to brew.

c. Press or hold the ‘LEFT’ Button under the

flashing H until you have reached the appropriate hour. If the hour has passed 12, the indicator switches from AM to PM.

d. Press or hold the ‘RIGHT’ Button under the

flashing M to set the minutes.

e. When you have reached the correct time,

press the menu Button six times to scroll through the remaining programming options and exit the programming mode.

f. The correct time should now be displayed

on the LCD Control Center.

NOTE:

If power is interrupted to the Brewer follow the procedure above to reset the time as the clock will not be visible until the time is set. Brew size and brew temperature menu settings are remembered and restored automatically. All other settings will be restored automatically after clock is set.

2. Set the Brewer to Turn Off at a Specified Period of Time After the Last Brew.

a. Press the MENU Button twice to pro-

gram the AUTO OFF feature. The LCD Control Center will now display the programming options with a small arrow next to ‘SET AUTO OFF’.

b.Press or hold the ‘LEFT’ Button under

the flashing H to advance 1 hour at a time, up to 9 hours.

c. After setting the desired AUTO-OFF time,

press the MENU Button five times to scroll through the remaining programming options and exit the programming mode. ‘AUTO OFF SET’ will now be displayed to indicate that it has been set.

d.To cancel the AUTO-OFF feature, press

the MENU Button twice to reach the AUTO-OFF programming mode. Press and release the Button under the flash ing H to advance one hour at a time until ‘OFF’ is displayed. Press menu 5 times to exit programming.

3. Program Your Brewer to Turn ON and/or OFF at a Specific Time.

b. Press or hold the ‘LEFT’ Button under

the H to scroll through the hours to your desired ON time hour.

c. Press or hold the ‘RIGHT’ Button under

the M to scroll through the minutes to your desired ON time minutes.

d. After setting the desired time, press the

Menu Button to save the On Time and move to the ‘SET OFF TIME’.

NNOTE:

To use this programming feature, the clock must be set to the correct time. The clock will not be displayed unless the time is set.

EXAMPLE:

If you chose to set the On Time at 6:15 AM and the Off Time for 10:00 PM, then the Brewer will be ‘ON’ and maintain hot water in the tank during that time so that it is always ready for you to brew. If you wanted to brew outside this window, simply press and release the Power Button and you can brew as soon as the water is heated and the ‘READY TO BREW’ indicator is displayed on the LCD Control Center.

a. After setting the correct time (required),

press the Menu Button three times to program the Auto On time feature. The LCD Control Center will show the programming options with a small arrow next to ‘SET ON TIME’.

e. If you want to set an OFF time, repeat

the procedure above in steps b & c to set your desired OFF time.

f. To complete the process, press the

Menu Button three more times to exit the programming mode. The Control Center will now indicate the options you have set.

NOTE:

The AUTO ON time and AUTO OFF time functions operate independently from one another. To cancel either function, follow the steps above and use the H and M Buttons to advance to 12:00 AM. When you reach 12:00 AM, the Control Center will display ‘OFF’ and the function will be disabled.

+ 22 hidden pages
