Keurig B70 User Manual

USING YOUR BREWER

OWNER’S MANUAL: Getting the most from your new Platinum B70 Keurig® Brewer

COMMENT UTILISER VOTRE CAFETIÈRE

MANUEL D’UTILISATION : Tirez le meilleur de votre nouvelle cafetière Platinum B70 de Keurig

IMPORTANT SAFEGUARDS Safe Operation & Use

When using electrical appliances, basic safety precautions should be followed, including the following:

1. Read all instructions before using.

2. Do not touch hot surfaces. Use handles and

knobs when available.

3. This appliance must be properly installed and

located in accordance with these instructions before it is used.

4. The use of accessory attachments not recom-

mended by the appliance manufacturer may result in fire, electrical shock or injury to persons.

5. Do not place on or near a hot gas or electric

burner, or in a heated oven.

6. Do not use outdoors.

7. To protect against fire, electric shock and injury

do not immerse cords, plugs, or the appliance in water or any other liquid.

8. Do not overfill the Water Reservoir with water.

9. Use only water in this appliance! Do not put any

other liquids or foods in the Water Reservoir except as instructed in the Cleaning Instructions in this guide.

10. Turn off and unplug the Brewer before

cleaning or maintenance. Allow to cool

before putting on or taking off parts and before cleaning the appliance.

11. For best operation, plug the appliance into its

own electrical outlet on a dedicated circuit to prevent flickering of lights, blowing of fuses or tripping a circuit breaker.

12. Do not operate any appliance with a damaged

cord or plug or after the appliance malfunctions or is damaged in any manner. Contact Keurig® Customer Service to report any malfunction of or damage to the Brewer.

13. Do not let the cord hang over the edge of

the table or counter, or touch hot surfaces.

14. To disconnect, press the Power Button on the

Brewer to ‘OFF’ status and then remove the plug from the wall outlet.

15. Close supervision is necessary when any

appliance is used by or near children.

16. Do not lift the Handle to open the Lid of

the Brewer while brewing is in progress.

17. Always keep the Water Reservoir Lid on

the Water Reservoir unless you are refilling it.

18. This appliance is equipped with a power cord

having a grounding wire with a grounding plug. The appliance must be grounded using a 3-hole properly grounded outlet. In the

event of an electrical short circuit, grounding reduces the risk of electrical shock.

19. If the outlet is a standard 2-prong wall outlet,

it is your personal responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet.

20. Do not, under any circumstances, cut or

remove the third (ground) prong from the power cord or use an adapter.

21. Consult a qualified electrician if the grounding

instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded.

22. Do not use the appliance for other than

its intended use.

INSTRUCTIONS.

WARNING TO USERS AND PARENTS

1. DO NOT permit children to use brewer unless there

is adult supervision. Brewer dispenses very hot water.

2. SPECIAL NOTICE FOR HOT COCOA USERS: IMMEDIATELY AFTER USING A HOT COCOA K-CUP, RUN a Hot Water Brew Cycle without a K-Cup to avoid

the possibility of clogging the exit needle. DO NOT assume the next user will do this.

SAVE THESE

CAUTION: There are two sharp needles that puncture the K-Cup® portion pack, one above the K-Cup Holder and the other in the bottom of the K-Cup Holder. To avoid risk of injury, do not put your fingers in the K-Cup Assembly Housing.

CAUTION: There is extremely hot water in the K-Cup Holder during the brew process. To avoid risk of injury, do not lift the Handle or open the K-Cup Assembly Housing during the brewing process.

SHORT CORD INSTRUCTIONS:

reduce the risk of becoming entangled in or tripping over a longer cord.

If an extension cord is used, (1) the marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance; (2) the cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally; and (3) the extension cord must include a 3-prong grounding plug.

THIS PRODUCT IS FOR HOUSEHOLD USE ONLY.

A short power supply cord is provided to

WARNING THIS PRODUCT CONTAINS CHEMICALS, INCLUDING

LEAD, WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.

WARNING: TO REDUCE THE RISK OF FIRE OR

WARNING

RISK OF FIRE OR ELECTRIC SHOCK

DO NOT OPEN

ELECTRIC SHOCK, DO NOT REMOVE THE BOTTOM COVER. NO USER SERVICEABLE PARTS ARE INSIDE. REPAIR SHOULD BE DONE

BY AUTHORIZED SERVICE PERSONNEL ONLY.

TABLE OF CONTENTS

KEURIG® GOURMET SINGLE CUP HOME BREWING SYSTEM

Platinum B70 — Using Your Brewer

SET-UP

Helpful Hints ........................................................................................4

Unpacking ............................................................................................4

Features ...............................................................................................5

SECTION 1 — SET-UP & FIRST BREW

Set-Up & First Brew ...........................................................................6

SECTION 2 — CONTROLS & INDICATORS

Setting the Clock ...............................................................................10

Programming On/Off Features ......................................................10

Programming Brew Temperature .................................................12

Programming Brew Size .................................................................13

SECTION 3 — CLEANING & MAINTENANCE

Cleaning ..............................................................................................13

De-Scaling..........................................................................................14

Storage ...............................................................................................15

SECTION 4 — TROUBLESHOOTING ..................................................16

SECTION 5 — WARRANTY ................................................................17

Pour des directives en français, veuillez vous reporter à la page 18.

Record your Brewer Serial Number here.

Removing the serial number label from the Brewer will void warranty.

Set-up

Features Platinum — Model B70 Brewer

Helpful Hints

1. Keep your Brewer turned “ON” at all times.

To brew a fresh cup of coffee, tea or hot cocoa

anytime you want, we suggest you keep your Brewer turned “ON” all the time. However, the Brewer is fully programmable so you can set it to turn on and off automatically to match your schedule. Or, if you prefer, set the Brewer to automatically turn off after a period of time. Follow the simple instructions on pages 10–13 to make using the Brewer convenient for you.

2. For the best tasting gourmet coffee, tea or hot cocoa, Keurig recommends using bottled water or the Keurig (available at www.keurig.com).

Water quality varies from place to place. If you notice an undesirable taste in your cup of coffee, such as chlorine or other mineral tastes, we recommend you consider using bottled water or water from a filtration system.

3. Customize the Size, Flavor & Brew That’s Perfect for You.™

With the choice of over 200 varieties of K-Cups and 5 brew sizes (Iced Beverage-3.25 oz., Small Cup-5.25 oz., Small Mug-7.25 oz., Large Mug-

9.25 oz., and Travel Mug-11.25 oz.) your Keurig

Water Filter Starter Kit

Brewer gives you endless options to customize the size, flavor and brew that’s perfect for you. For a strong, intense cup, select an Extra Bold

(with up to 30% more ground coffee

K-Cup than regular varieties) and brew the size that’s right for you. The smaller the brew size, the more intense flavor in your cup. The larger the brew size, the less intense flavor in your cup.

4. Plug Brewer into its own grounded outlet.

If the electric circuit is overloaded with other appliances, your Brewer may not function properly. The Brewer should be operated on its own circuit, separate from other appliances.

5. Brewing into a travel mug.

To brew into a travel mug, simply remove the

Drip Tray Assembly and place the travel mug on the Drip Tray Base.

6. De-scale Brewer regularly.

Please see pages 14 and 15 for instructions.

Unpacking Instructions

1. Place Brewer box on a large steady surface

(such as a table or countertop) or on the floor. Open the box.

2. Remove enclosed literature.

3. Turn the box on its side with front of box face down.

4. Reach into the box and grasp the plastic bag

that contains the Brewer.

5. Carefully pull the plastic bag (and packaging

materials) toward you and out of the box. The Brewer will still be encased in the polyfoam and be on its side.

6. Remove the top polyfoam packaging material.

7. Carefully lift Brewer off of the bottom polyfoam

and place it upright on a flat, steady surface.

8. Lift plastic bag off of Brewer.

9. Record the serial number for this Brewer on

page 3 of this guide. The serial number can be found on the bottom of the Brewer box or on the Brewer behind the Drip Tray (when removed).

10. Place the Brewer upright on a flat, steady

surface. Remove tape holding Water Reservoir in place.

We recommend you save all packing materials in case future shipping of the product is necessary.

WARNING:

Keep all plastic bags away

from children.

Platinum B70 Brewer

A. Water Reservoir Lid B. Water Reservoir C. Water Reservoir

Lock Tab Slot

D. Handle E. Funnel

F. K-Cup

G. Lid H. K-Cup

Portion Pack Holder (E and F are the K-Cup Holder Assembly)

Portion Pack

Assembly Housing

RE ADY

TO BRE W

MEN U

BRE W

Controls and Indicators

I. Housing J. Drip Tray Plate K. Drip Tray L. Drip Tray Base M. Vent

N. Power Cord O. Power Switch (Not

shown) Located Rear Right Side of Brewer

P. LCD Control Center Q. Left Button R. Right Button S. MENU Button T. BREW Button

SECTION 1 Set-Up & First Brew

IMPORTANT: You cannot use your Keurig

Brewer until

it has been set up for its ﬁrst use.

NOTE: If Brewer has been exposed to temperatures

below freezing, allow Brewer at least two hours to reach room temperature before brewing. A frozen or extremely cold Brewer will not operate.

ﬁg.

Setting Up Your Brewer

1. Unwrap cord and plug the Brewer into

a grounded outlet. Remove all pieces of packing tape and clear plastic sticker from LCD display.

2. Place a large mug (10 oz. minimum) on the

Drip Tray Plate.

3. Remove the Water Reservoir from Brewer

by first removing Lid from the Water Reservoir (fig. 1), then lifting the Water Reservoir straight up and toward front of Brewer. (may be tight), (fig. 2). Rinse with fresh water.

4. Fill Water Reservoir with bottled or filtered

water so that the water level is just below the top edge of the Water Reservoir.

ﬁg.

Lock Tab

5. Place Water Reservoir base into

the left side of the Brewer and be

ﬁg.

sure the Water Reservoir Lock

Tab engages with the Brewer.

Replace Lid on Water Reservoir.

6. Press and release the Power

Switch found directly behind the right side of the Brewer. Switch is spring loaded and will return to original position.

7. The Blue LCD Control Center

REA DY

TO BRE W

BREW

the Water Reservoir during this and subsequent

heating — this is normal.

Press the BREW Button to start a cleansing

brew without a K-Cup. Pour the hot water into the sink.

NOTE: A K-Cup should not be used for this Sequence

10. The one-time set-up process is now

complete and you are ready to brew!

NOTE: The Brewer may take 15-30 seconds between brews and then “READY TO BREW” will be displayed.

will come on and indicate “NOT

NOT

REA DY

BREW

ﬁg.

READY” and the BREW Button

8. The Brewer will automatically fill the internal

will flash. NOTE: A K-Cup should

not be used for this sequence

tank with water and then the water will be heated. This will take about 4 minutes. During the heating period, “NOT READY” (fig. 3) is displayed on the LCD Control Center.

Do not lift Brewer Handle during this

‘heating period’. Once the water is heated,

“READY TO BREW” will be displayed and the

BREW Button will flash (fig. 4).

NOTE: You may see small amounts of water

coming from the Vent and dripping into

ﬁg.

Ready to Brew Your First Cup

1. LCD Control Center will indicate

“READY TO BREW”.

2. Place a cup or mug on the Drip Tray Plate.

3. Lift the Handle and the K-Cup

will open toward you (fig. 5).

4. Select a K-Cup portion pack.

NOTE: Do not remove the foil lid

or puncture the K-Cup.

Holder

6 7

REA DY

TO BRE W

BREW

ﬁg.

5. Place a K-Cup portion pack

in the K-Cup Holder (fig. 6).

CAUTION: There are two sharp needles that puncture the K-Cup, one above the K-Cup Holder

and the other in the bottom of the K-Cup Holder. To avoid risk of injury, do not put your fingers in the K-Cup Assembly Housing.

Lower the Handle to close the Lid over the

K-Cup Holder. (When it is closed completely, the LCD Control Center will indicate “READY

TO BREW”. The Left and Right Buttons will

be lit and the BREW Button will flash up to 60

seconds.)

a. All brew size icons are lit with the default

size flashing (fig. 7). To choose a different size, press Left Button to go down in size or Right

Button to go up in size.

NOTE: The Small Mug (7.25 oz. serving) is the factory set default brew size. To program your favorite brew size see page 13 “Programming Your Brew Size”.

Your choices are a stronger Small Cup (5.25

oz. serving), a Small Mug (7.25 oz. serving), a Large Mug (9.25 oz. serving), a Travel Mug (11.25 oz. serving) or Iced Beverage setting (3.25 oz. serving).

SECTION 1

Travel Mug

Set-Up & First Brew (continued)

Iced Beverage

(3.25 oz.)

Small Cup

(5.25 oz.)

Small Mug

(7.25 oz.)

BRE WING

BREW

Large Mug

(9.25 oz.)

(11.25 oz.)

fig.

c. To use the Iced Beverage setting, place a tall

glass filled with ice on the Drip Tray Plate. Use your favorite K-Cup®, select the Iced Beverage brew size and press the BREW Button. Add more ice once brewing is complete, add cream and sugar if desired.

d. Once size is chosen, press BREW Button.

BREW Button will stop flashing, Left and Right Buttons will no longer be lit and icon of brew size will be lit.

7. The LCD Control Center will now display the

word ‘BREWING’ and the serving size you

selected will be illuminated on LCD (fig. 8).

CAUTION: There is extremely hot water in the KCup Holder during the brew process. To avoid risk

of injury, do not lift the Handle or open the

K-Cup Assembly Housing during the brew process.

There may be a short pause prior to coffee

being dispensed. The entire brew process lasts for approximately 1 minute and ends with a burst of air to remove all liquid from the K-Cup.

9. Lift the Handle, remove and dispose

of the used K-Cup.

CAUTION: K-Cup will be hot.

10. Enjoy your first cup of Keurig Brewed

gourmet coffee, tea or hot cocoa!

11. Your Brewer may display “NOT READY” as

it heats water for the next brew cycle. The

“READY TO BREW” indication will return to

the LCD Control Center in about 15 seconds.

Stopping the Brew Process

If you need to stop the brewing after the process has started, press and release the Power Switch to turn the Brewer ‘OFF’. The flow of coffee, tea or hot cocoa will stop, the heating element will shut off and the blue lights illuminating the LCD Control Center and Water Reservoir will disappear.

NOTE: You may get more coffee, tea or hot cocoa in your cup during your next brew. We recommend that you perform a cleansing brew with water-only after a terminated brew. Then your NEXT brew will be the volume you have selected.

Adding Water

The LCD Control Center of your Brewer will indicate when the water level

in the tank is low or if the Water Reservoir has been removed by displaying the words “ADD WATER” (fig. 9). The blue light in the Water Reservoir will also blink when water needs to be added. The Brewer will not allow you to brew when “ADD WATER” is displayed (fig. 9).

fig.

The Water Reservoir can be filled in two ways.

1. Lift off the Water Reservoir Lid and pour

water directly into the Water Reservoir

NOT

ADD

WATER

REA DY

BREW

while it is still attached to the Brewer, then replace the Lid.

2. Remove the Water Reservoir from Brewer by

first removing Lid from the Water Reservoir, then lifting the Water Reservoir straight up and toward front of Brewer. Fill with water. Place the Water

Reservoir back on the Brewer and replace the Lid.

IMPORTANT: Do not remove the Water Reservoir during the brewing process.

Brewing Hot Water

Your Brewer is able to produce hot water for making hot cocoa from a packet,

for use in cooking, for making soups, etc. Simply follow the instructions on page 7 — “Ready To Brew Your First Cup” without adding a K-Cup.

NOTE: After brewing a hot cocoa K-Cup, we recommend running a hot water

brew cycle without a K-Cup.

Purging the Brewer

If your Brewer has not been used for more than one week, you should purge the water from the inner tank.

1. If there is water in the Water Reservoir, remove the Lid, then lift the

Water Reservoir straight up and away from Brewer. Discard water, rinse and refill with water. Place the Water Reservoir back on the Brewer and replace the Lid. (If there is no water in the Water Reservoir, simply refill.)

2. Be sure the Brewer is turned on. Raise and lower the Handle on the

Brewer without inserting a K-Cup.

3. The LCD Control Center will display “READY TO BREW”.

Brew a Travel Mug (11.25 oz. serving) of water (do not use a K-Cup).

4. Repeat steps 2 and 3 two more times to completely purge water from

inner tank.

If you are experiencing any problems with your Brewer, please contact Customer Service at 1.866.901.BREW (2739).

8 9

SECTION 2 Controls & Indicators (LCD Control Center)

Setting the Clock

Setting the clock is optional. When the clock is set, the time will appear in the LCD Control Center. NOTE: You must set the clock if you will be using the

Auto On/Off Time programming feature.

Press the MENU Button.

fig.

RE ADY

NOT

SET CLOCK

AUTO OFF

ONOFF TIME

BREW TEMP

BREW SIZE

MEN U

BRE W

Set

Hours

Minutes

5. When you have reached the correct time, press the MENU Button six

times to scroll through the remaining programming steps.

2. The word ‘OFF’ will appear at the top of the

LCD Control Center to indicate that the clock is not set (fig. 10). The programming options will appear on the LCD Control Center with a small arrow pointing to ‘SET CLOCK’. “H” (Hour) will appear above the Left Button and “M” (Minute) will appear above the Right Button. The “H” and “M” icons and Left and Right Buttons will flash.

3. Press or hold the Left Button under the

flashing “H” until you have reached the appropriate hour. If the hour has passed 12

Set

“PM” will be shown.

4. Press or hold the Right Button under the

flashing “M” to set the minutes.

6. The correct time should now be displayed in the LCD Control Center.

NOTE: If power is interrupted to the Brewer by unplugging it, or if power is lost, follow the procedure above to reset the time as the clock will not be visible until the time is set. Brew size and brew temperature menu settings are remembered and restored automatically. All other settings will be restored automatically after clock is set.

Programming On/Off Features

The Brewer provides three modes so that you can enjoy gourmet coffee, tea or hot cocoa on your own schedule. By programming your Brewer to turn on each morning, you will never have to wait for the Brewer to warm up to brew

a gourmet cup of coffee. It will take the Brewer approximately 4 minutes to warm up from room temperate.

1. Leave it ON all the time. The Brewer can be left on all the time so that it is

always ready to brew a fresh cup of gourmet coffee, tea or hot cocoa. To turn the Brewer off at any time, simply press and release the Power Switch.

(NOTE: Although the clock remains on, if set, you can not brew a cup of coffee, tea or hot cocoa.)

power to the Brewer. You will have to wait for the water to heat up before the Brewer is ready to brew.

2. Set the Brewer to “AUTO OFF” following a specified period of time after the

last brew.

a. Press the MENU Button twice to program the Auto Off feature. The LCD

Control Center will now display the programming options with a small arrow next to “SET AUTO OFF” (fig. 11).

10 11

Press and release the Power Switch again to restore

RE ADY

TO BRE W

AUTO OFF SET

MEN U

BRE W

fig.

b. Press or hold the Left Button under the

blinking “H” to advance 1 hour at a time, up to 9 hours.

c. After setting the desired Auto Off time, press

the MENU Button five times to scroll through the remaining programming options and exit the programming mode. “AUTO OFF SET” (fig. 12) will now be displayed to indicate that it has been set.

d. To cancel the Auto Off feature, press the

MENU Button twice to reach the “AUTO OFF” programming mode. Press and release the blue Left Button under the blinking “H” to advance one hour at a time until “OFF” is displayed.

3. Program your Brewer for a specific On/Off

Time. NOTE: To use this programming feature,

the clock must be set to the correct time. The clock will not be displayed unless the time is set.

a. After setting the correct time (required), press

the MENU Button three times to program On Time feature . The LCD Control Center will show the programming options with a small arrow next to “SET ON TIME” (fig. 13).

b. Press or hold the Left Button under the “H” to

scroll through the hours to your desired “ON TIME” hour.

NOT

Set

Hours

NOT

Set

Hours

RE ADY

CLOCK

AUTO OFF

SET ON TIME

BREW TEMP

BREW SIZE

MEN U

BRE W

RE ADY

CLOCK

AUTO OFF

SET OFF TIME

BREW TEMP

BREW SIZE

MEN U

BRE W

fig.

Set

Minutes

fig.

Set

Minutes

c. Press or hold the Right Button under the

“M” to scroll through the minutes to your

desired “ON TIME” minutes.

d. After setting the desired time, press the

MENU Button to save the “ON TIME” and move to the “SET OFF TIME” (fig. 14).

e. If you want to set an “OFF TIME”, repeat the

procedure above in steps b & c to set your desired “OFF TIME” (fig. 14).

f. To complete the process, press the MENU

Button three more times to exit the programming mode. The Control Center will now indicate the options you have set.

g. The Auto On time and Auto Off time functions

operate independently from one another. To cancel either set function, follow the steps above and use the “H” and “M” Buttons to advance to 12:00 AM. Make sure the “M”

Button is set to :00, then change the “H” Button. When you reach 12:00 AM, the Control Center will display ‘OFF’ and the function will be disabled.

EXAMPLE

If you chose to set the On Time at 6:55 AM and the Off Time for 10:00 PM, then the Brewer will be “READY TO BREW” and maintain hot water in the tank during that time so that it is always ready for you to brew. If you wanted to brew outside this window,

+ 13 hidden pages
