USING YOUR BREWER

OWNER’S MANUAL: Getting the most from your new B31 MINI PLUS Keurig® Brewer

Important Safeguards Safe Operation & Use

When using electrical appliances, basic safety precautions should be followed, including the following:

1.Read all instructions before using.

2.Do not touch hot surfaces. Use handle and knobs when available.

3.This appliance must be properly installed and located in accordance with these instructions before it is used.

4.The use of accessory attachments is not recommended by the appliance manufacturer and may result in fire, electrical shock or injury to persons.

5.Do not place on or near a hot gas or electric burner, or in a heated oven.

6.Do not use outdoors.

7.To protect against fire, electric shock and injury, do not immerse cords, plugs or the appliance in water or any other liquid.

8.Do not overfill the Cold Water Reservoir.

9.Use only water in this appliance! Do not put any other liquids or foods in the Cold Water Reservoir, except as instructed in the Cleaning Instructions in this guide.

10.Turn off and unplug the Brewer before cleaning or maintenance. Allow to cool before putting on or taking off parts and before cleaning the appliance.

11.For best operation, plug the appliance into its own electrical outlet on a dedicated circuit to prevent flickering of lights, blowing of fuses or tripping a circuit breaker.

12.Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or is damaged in any manner. Contact Keurig Customer Service to report any malfunction of or damage to the Brewer.

13.Do not let the cord hang over the edge of the table or counter, or touch hot surfaces.

14.To disconnect, press the Power Button on the front right side of the Brewer–­this will turn the power off. Then, remove the plug from the wall outlet.

15.Close supervision is necessary when any appliance is used by or near children.

16.Do not lift the Brewer Handle while brewing is in progress, scalding may occur.

2

17.Always keep the Cold Water Reservoir Lid closed unless you are refilling it.

18.This appliance is equipped with a power cord having a grounding wire with a grounding plug. The appliance must be grounded using a 3-hole, properly grounded outlet. In the event of an electrical short circuit, grounding reduces the risk of electrical shock.

19.If the outlet is a standard 2-prong wall outlet, it is your personal responsibility and obligation to have it replaced with a properly grounded 3-prong wall outlet.

20.Do not, under any circumstances, cut or remove the third (ground) prong from the power cord or use an adapter.

21.Consult a qualified electrician if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded.

22.Do not use the appliance for any reason other than its intended use.

Save These

Instructions.

CAUTION: There are two sharp needles that puncture the K-Cup® portion pack, one above the

K-Cup Holder and the other in the bottom of the

K-Cup Holder. To avoid risk of injury, do not put your fingers in the K-Cup Assembly Housing.

CAUTION: There is extremely hot water in the K-Cup Holder during the brew process. To avoid risk of injury, do not lift the Brewer Handle or open the K-Cup Assembly Housing during the brewing process.

SHORT CORD INSTRUCTIONS: A short power supply cord is provided to reduce the risk of becoming entangled in or tripping over a longer cord.

If an extension cord is used, (1) the marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance; (2) the cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally; and (3) the extension cord must include a 3-prong grounding plug.

THIS PRODUCT IS FOR HOUSEHOLD USE ONLY.

WARNING Keep all plastic bags away from children.

WARNINGTHIS PRODUCT CONTAINS CHEMICALS, INCLUDING LEAD, WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.

WARNING TO USERS AND PARENTS

1. DO NOT permit children to use Brewer without adult supervision. Brewer dispenses very hot water.

2.SPECIAL NOTICE FOR HOT COCOA USERS: IMMEDIATELY AFTER USING A HOT COCOA K-CUP, RUN a Hot Water Brew Cycle without a K-Cup to avoid the possibility of clogging the exit needle. DO NOT assume the next user will do this.

WARNING

RISK OF FIRE OR !

ELECTRIC SHOCK

DO NOT OPEN

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT REMOVE THE BOTTOM COVER. NO USER SERVICEABLE PARTS ARE INSIDE. REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY.

3

Table of Contents

KEURIG® GOURMET SINGLE CUP HOME BREWING SYSTEM Model B31 MINI PLUS Using Your Brewer

Section 1—Brewer Overview...........................................................

4

Section 2—Helpful Hints..................................................................

6

Section 3—Buttons & Indicators..........................................................

7

Section 4—Set-up & Operation



Initial Cleansing & First Brew...........................................................

8

Section 5—Cleaning & Maintenance



Cleaning External Parts ..................................................................

12

Cleaning the K-Cup® Portion Pack Holder Assembly ................

12

Cleaning the Cold Water Reservoir................................................

14

Emptying the Internal Hot Water Tank...........................................

14

Storage................................................................................................

14

Storing the Power Cord....................................................................

14

De-Scaling Your Brewer...................................................................

15

Section 6—Troubleshooting...........................................................

16

Section 7—Warranty.......................................................................

18

Record your Brewer Serial Number here.

Removing the serial number label from the Brewer will void warranty.

SECTION 1 Brewer Overview

ACold Water Reservoir Lid

BCold Water Reservoir

CBREW Button

DAdd Water/Brewer Handle Indicator

EPower Button

FPower Cord

GDrip Tray Base

HDrip Tray

I Drip Tray Plate

J Drip Tray Overfill Indicator

KK-Cup Portion Pack Assembly Housing

LBrewer Handle

MWater Level Guide (Inside Cold Water Reservoir)

NK-Cup Portion Pack Holder

OFunnel

PK-Cup Portion Pack Holder Assembly

4

N

P

O

J

I

H

For replacement parts, please call 1.866.901.BREW (2739).

MAX

M

MIN

L

K

G

5

A

B

C

D

E

F

section 2 Helpful Hints

Plug Brewer into its own grounded outlet — If the electric circuit is overloaded with other appliances, your Brewer may not function properly. The Brewer should be operated on its own circuit, separate from other appliances.

Initial Cleansing Brew — Before you use your Brewer for the first time, perform an initial cleansing brew by running clean water through the brew cycle without using a K-Cup® portion pack.

One Cup at a Time — Your new Brewer makes one fresh beverage at a time. You’ll need to add fresh water each time you brew. Unlike other Keurig Brewers, the B31 does not store water in the reservoir.

The Right Water Makes a Difference — For the best tasting gourmet coffee, tea or hot cocoa, Keurig recommends using bottled or filtered water. We do not recommend using distilled or reverse osmosis water. Water quality varies from place to place. If you notice an undesirable taste in your cup of coffee such as chlorine or other mineral taste, we recommend you consider using bottled water or water from a filtration system.

Customize your Size, Flavor & Brew — With the choice of over 200 varieties of K-Cups and multiple fill levels, your Brewer gives you endless options to customize the size, flavor and strength that’s perfect for you. For a strong, intense cup, select an Extra Bold K-Cup (with up to 30% more ground coffee than regular varieties) and brew size that’s right for you. The less water you use, the more intense flavor in your cup. The more water you use, the less intense flavor in your cup.

To guide you, the Brewer includes a Water Level Guide located inside the Cold Water Reservoir. The Water Level Guide is removable to make cleaning easy.

Brewing into a tall mug — To brew into a tall mug, simply remove the Drip Tray Assembly and place the tall mug on the Drip Tray Base.

The Drip Tray — Any liquid overflow (from your cup or the Cold Water Reservoir) will be caught in the Drip Tray. Be sure to empty the Drip Tray when the red Drip Tray Overflow Indicator pops up. The Drip Tray has a snug fit to ensure it stays put in transit.

Automatic Shut Off — Your Brewer will shut off automatically when it is idle for longer than 90 seconds. Simply press the Power Button to restart.

Clean Your Brewer Regularly — To keep your Brewer looking and performing its best, be sure to clean the external and internal components on a regular basis. See page 12 for more information.

De-Scaling — Mineral content in water varies from place to place. Depending on the mineral content of the water in your area, calcium deposits or scale may build up in your Brewer. Scale is non-toxic, but left unattended, it can hinder Brewer performance. De-scaling your Brewer helps maintain the heating element and other internal parts of the Brewer that come in contact with water. See page 15 for more information.

Storing — When storing your Brewer, carefully empty the Drip Tray and make sure both the Cold Water Reservoir and Internal Hot Water Tank are empty. Store your Brewer upright in a safe, dry, frost-free environment. See page 14 for more information.

6
