AUDIO/VIDEO CONTROL RECEIVER
RX-7012VSL
CATV/DBS VCR TV AUDIO
DVD MUILTIDVD
CD
FM/AM
TAPE/CDR
TV/DBS VCR PHONO
TREBLE
BASS
++−−
ANALOG/DIGITAL
DSP
MODE INPUTON/OFF
+ CENTER –
231
TEST + REAR•L –
564
– REAR•R +
897/P
– SUB WOOFER +
0
RETURN FM MODE 100
+−+−+
CH TV VOL
PLAY
/REW FF/
PAUSE
STOP
RM-SRX7012U
A/V CONTROL RECEIVER
SLEEP
MENU
ENTER
+1010
+
VOLUME
−
CONTROL
PHONES
STANDBY
STANDBY/ON
FM/AM TUNING
DIGITAL
SURROUND
SURROUND ON/OFF
DSP MODE
FM/AM PRESET FM MODE
DIGITAL
INPUT
ANALOG/DIGITAL
INPUT ATT
12
MEMORY
BASS BOOST
SPEAKERS ON/OFF
RX-7012V
AUDIO/VIDEO CONTROL RECEIVER
DVD VCR
DVD MULTI
PHONO
CD TAPE/CDR
SOURCE NAME
TV SOUND/DBS
SOURCE NAME
FM/AM
ADJUST
DOWN UP
CONTROL
COMPULINK
MASTER VOLUME
SETTING
Remote
SURROUND
BASS BOOST EFFECT
SOUND
MUTING
CATV/DBS
CONTROL
CONTROL
TV/VIDEO
+
TUNING
−
REC
PAUSE
DIGITAL
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT0579-007A
[A]
Warnings, Cautions and Others
Caution –– switch!
Disconnect the mains plug to shut the power off completely. The
switch in any position does not disconnect the mains line. The power
can be remote controlled.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a newspaper
or cloth, etc., the heat may not be able to get out.)
• Do not place any naked flame sources, such as lighted candles,
on the apparatus.
• When discarding batteries, environmental problems must be
considered and local rules or laws governing the disposal of
these batteries must be followed strictly.
• Do not use this apparatus in a bathroom or places with water.
Also do not place any containers filled with water or liquids (such
as cosmetics or medicines, flower vases, potted plants, cups,
etc.) on top of this apparatus.
G-1
Wall or obstructions
Caution: Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage.
Locate the apparatus as follows:
Front: No obstructions open spacing.
Sides: No obstructions in 10 cm from the sides.
Top: No obstructions in 10 cm from the top.
Back: No obstructions in 15 cm from the back
Bottom: No obstructions, place on the level surface.
In addition, maintain the best possible air circulation as illustrated.
Spacing 15 cm or more
Front
RX-7012VSL
Stand height 15 cm or more
Floor
G-2
Table of Contents
Parts Identification ...................................... 2
Getting Started ........................................... 3
Before Installation ...................................................................... 3
Checking the Supplied Accessories ........................................... 3
Connecting the FM and AM Antennas ....................................... 3
Connecting the Speakers ............................................................ 4
Connecting Audio/Video Components....................................... 5
Connecting the Power Cord ....................................................... 9
Putting Batteries in the Remote Control .................................... 9
Basic Operations ....................................... 10
Turning the Power On and Off (Standby) ................................ 10
Selecting the Source to Play..................................................... 10
Adjusting the Volume ............................................................... 11
Selecting the Front Speakers .................................................... 11
Muting the Sound ..................................................................... 12
Reinforcing the Bass ................................................................ 12
Adjusting the Tone ................................................................... 12
Attenuating the Input Signal .................................................... 12
Adjusting the Subwoofer Output Level.................................... 12
Basic Settings ........................................... 13
Recording a Source .................................................................. 13
Adjusting the Front Speaker Output Balance........................... 13
Changing the Source Name...................................................... 13
Setting the Subwoofer Information .......................................... 14
Setting the Speakers for the DSP Modes ................................. 14
Digital Input (DIGITAL IN) Terminal Setting......................... 16
Selecting the Analog or Digital Input Mode ............................ 16
Storing the Basic Settings and Adjustments............................. 17
Using the Sleep Timer.............................................................. 17
Using the DVD MULTI Playback Mode .......... 27
Activating the DVD MULTI Playback Mode .......................... 27
COMPU LINK Remote Control System ......... 28
AV COMPU LINK Remote Control System .... 29
Operating JVC’s Audio/Video Components ... 31
Operating Audio Components .................................................. 31
Operating Video Components .................................................. 33
Operating Other Manufacturers’ Video
Equipment ............................................ 34
Troubleshooting ......................................... 38
Specifications ............................................ 39
Receiving Radio Broadcasts ........................ 18
Tuning in Stations Manually .................................................... 18
Using Preset T uning ................................................................. 18
Selecting the FM Reception Mode........................................... 19
Using the DSP Modes ................................ 20
What are the DSP Modes? ........................................................ 20
Reproducing the Sound Field .................................................... 21
A vailable DSP Modes According to the Speaker Arrangement .. 22
Adjusting the Surround Modes ................................................ 23
Adjusting the DAP Modes ....................................................... 25
Activating the DSP Modes....................................................... 26
1
Parts Identification
Become familiar with the buttons and controls on the receiver before use.
Refer to the pages in parentheses for details.
61 2 345 7
RX-7012V
AUDIO/VIDEO CONTROL RECEIVER
FM/AM TUNING
DIGITAL
SURROUND
SURROUND ON/OFF
DSP MODE
FM/AM PRESET FM MODE
DIGITAL
INPUT
ANALOG/DIGITAL
INPUT ATT
SPEAKERS ON/OFF
12
MEMORY
BASS BOOST
DVD MULTI
PHONO
DVD
CD TAPE/CDR
SOURCE NAME
VCR
STANDBY
STANDBY/ON
PHONES
q9
Remote Control
1 Display window (See below) *
1
a
2
3
4t
5
6
7
8
9
p
q
w
e
r
CATV/DBS VCR TV AUDIO
DVD MUILTIDVD
CD
FM/AM
TV/DBS VCR PHONO
−−++
SURROUND
BASS BOOST EFFECT
SOUND
MUTING
CATV/DBS
CONTROL
CONTROL
TV/VIDEO
+
TUNING
−
REC
PA USE
TAPE/CDR
BASS
ANALOG/DIGITAL
DSP
MODE INPUTON/OFF
TEST
RETURN FM MODE 100
+−+−+
CH TV VOL
PLAY
/REW FF/
PA USE
STOP
RM-SRX7012U
A/V CONTROL RECEIVER
TREBLE
SLEEP
– CENTER +
231
MENU
– REAR • L +
564
ENTER
– REAR • R +
897/P
– SUB WOOFER +
0
VOLUME
CONTROL
b
y
u
i
+1010
+
o
−
;
a
s
a: Remote control operation mode indicator
b: Signal transmission indicator
Lights up when transmitting the remote
control signal.
2
buttons (10, 33 – 37)
CA TV/DBS, VCR, TV, A UDIO
3 Source selecting buttons (10, 17) *
DVD, D VD MUL TI, CD, FM/AM, TV/DBS, VCR,
TAPE/CDR, PHONO
4 BASS +/– buttons (12)
5 SURROUND ON/OFF button (22, 23, 26)
6 DSP MODE button (24 – 26)
7 BASS BOOST button (12)
8 SOUND button (12, 23 – 25, 27) *
9 MUTING button (12)
p CATV/DBS CONTROL button (35) *
q TV/VIDEO button (33, 34)
w CH(annel) +/– buttons (33 – 36)
e TUNING +/– buttons (18)
r REC PAUSE button (32, 33, 36)
t TREBLE +/– buttons (12)
y SLEEP button (17)
u ANALOG/DIGITAL INPUT button (17)
i • 10 keys for selecting preset channels (19)
• 10 keys for adjusting sound (12, 19, 23 – 25, 27)
• 10 keys for operating audio/video components
(31 – 37)
o TV VOL(ume) +/– buttons (33, 34)
; VOLUME +/– buttons (11)
a Operating buttons for audio/video components
(31 – 33, 36, 37)
s CONTROL button (32, 33) *
TV SOUND/DBS
SOURCE NAME
FM/AM
y
8
COMPULINK
Remote
ADJUST
CONTROL
DOWN UP
MASTER VOLUME
SETTING
ouite rwp
Front Panel
1 STANDBY/ON button and STANDBY
lamp (10)
2 FM/AM TUNING 5/∞ buttons (18)
3 FM/AM PRESET 5/∞ buttons (18)
4 FM MODE button (19)
5 MEMORY button (18)
6 Display (10)
7 Remote sensor (9)
8 MASTER VOLUME control (11)
9 PHONES jack (11)
p SURROUND ON/OFF button (22, 23, 26)
q DSP MODE button (24 – 26)
w INPUT ANALOG/DIGITAL button (17)
INPUT ATT button (12)
e SPEAKERS ON/OFF 1 button (11)
SPEAKERS ON/OFF 2 button (11)
r BASS BOOST button (12)
t Source selecting buttons (10, 16)
DVD MULTI, DVD, VCR, TV SOUND/DBS,
PHONO, CD, TAPE/CDR, FM/AM
y SOURCE NAME buttons (13)
•
The TV SOUND/DBS button and TAPE/CDR
button also function as the SOURCE NAME
button.
u ADJUST button (12, 13, 23 – 25, 27)
i CONTROL UP 5/DOWN ∞ buttons
o SETTING button (14 – 16)
* When you press one of these buttons, the remote control operation mode appears on
the display window for about 10 seconds.
Ex.: When you press CD button
Buttons on the Remote Control Remote Control Operation Mode
FM/AM TUNER
CD CD
PHONO PHONO
T APE/CDR T APE
DVD DVD
DVD MUL TI DVD
Buttons on the Remote Control Remote Control Operation Mode
TV/DBS TV
VCR VCR
CATV/DBS CONTROL DBS
CONTROL Current setting or VCR or TAPE
or CDDSC
SOUND SOUND
2
Getting Started
This section explains how to connect audio/video components and speakers to the receiver, and how to connect the
power supply.
Before Installation
General
• Be sure your hands are dry.
• Turn the power off to all components.
• Read the manuals supplied with the components you are going to
connect.
Locations
• Install the receiver in a location that is level and protected from
moisture.
• The temperature around the receiver must be between –5˚C and
35˚C (23˚F and 95˚F).
• Make sure there is good ventilation around the receiver. Poor
ventilation could cause overheating and damage the receiver.
Handling the receiver
• Do not insert any metal object into the receiver.
• Do not disassemble the receiver or remove screws, covers, or
cabinet.
• Do not expose the receiver to rain or moisture.
Checking the Supplied Accessories
Check to be sure you have all of the following items, which are
supplied with the receiver.
The number in the parentheses indicates quantity of the pieces
supplied.
• Remote Control (1)
• Batteries (2)
• AM Loop Antenna (1)
• FM Antenna (1)
If anything is missing, contact your dealer immediately.
Connecting the FM and AM Antennas
FM Antenna Connections
A
ANTENNA
AM
LOOP
FM 75
COAXIAL
AM
EXT
FM Antenna
AM
LOOP
ANTENNA
Extend the supplied FM antenna horizontally.
FM 75
COAXIAL
Outdoor FM Antenna Cable
AM
EXT
A. Using the Supplied FM Antenna
The FM antenna provided can be connected to the FM 75 Ω
COAXIAL terminal as temporary measure.
B. Using the Standard Type Connector (Not Supplied)
A standard type connector (IEC or DIN45325) should be
connected to the FM 75 Ω COAXIAL terminal.
Note:
If reception is poor, connect the outdoor antenna.
Before attaching a 75
going to an outdoor antenna), disconnect the supplied FM antenna.
Ω
coaxial cable (the kind with a round wire
B
AM
LOOP
ANTENNA
FM 75
COAXIAL
AM
EXT
3
AM Antenna Connections
ANTENNA
FM 75
COAXIAL
Snap the tabs on the loop into the
slots of the base to assemble the
AM loop.
Basic connecting procedure
1
2
1
RIGHT
3
4
1
RIGHT
1
RIGHT
AM
LOOP
AM
EXT
1
AM Loop Antenna
2
3
Outdoor single vinyl-covered wire (not supplied)
Turn the loop until you have the best reception.
Notes:
• If the AM loop antenna wire is covered with vinyl,
remove the vinyl by twisting it as shown in the diagram.
• Make sure the antenna conductors do not touch any
other terminals, connecting cords and power cord. This
could cause poor reception.
• If reception is poor, connect an outdoor single vinyl-covered wire to
the AM EXT terminal. (Keep the AM loop antenna connected.)
1 Cut, twist and remove the insulation at the end of
each speaker signal cable (not supplied).
2 Turn the knob counterclockwise.
3 Insert the speaker signal cable.
4 Turn the knob clockwise.
Connecting the front speakers
You can connect two pairs of front speakers (one pair to the FRONT
SPEAKERS 1 terminals, and another pair to the FRONT
SPEAKERS 2 terminals).
1
Right speaker
2
Right speaker
Connecting the Speakers
You can connect the following speakers:
• Two pairs of front speakers to produce normal stereo sound.
• One pair of rear speakers to enjoy the surround effect.
• One center speaker to produce more effective surround effect (to
emphasize human voices).
• One subwoofer to enhance the bass.
IMPORTANT:
After connecting the speakers listed above, set the speaker
setting information properly to obtain the best possible DSP
effect. For details, see page 14.
For each speaker (except for a subwoofer), connect the (+) and (–)
terminals on the rear panel to the (+) and (–) terminals marked on
the speakers. For connecting a subwoofer, see page 5.
CAUTION:
Use speakers with the SPEAKER IMPEDANCE indicated by the
speaker terminals.
FRONT
SPEAKERS
1
Left speaker
1
RIGHT LEFT
FRONT
SPEAKERS
+
–
RIGHT LEFT
2
+
FRONT
SPEAKERS
–
Left speaker
2
4
About the speaker impedance
The required speaker impedance of the front speakers does differ
depending on whether both the FRONT SPEAKERS 1 and FRONT
SPEAKERS 2 terminals are used or only one of them is used.
CASE 1 When you connect only one pair of front speakers
Connecting the subwoofer speaker
You can enhance the bass by connecting a subwoofer.
Connect the input jack of a powered subwoofer to the
SUBWOOFER OUT jack on the rear panel, using a cable with RCA
pin plugs (not supplied).
Front
speaker
1
Front
speaker
1
Use front speakers with 8 Ω – 16 Ω impedance.
CASE 2 When you connect two pairs of front speakers
Front
speaker
2
Front
speaker
1
Front
speaker
2
Front
speaker
1
Use front speakers 16 Ω – 32 Ω impedance.
Connecting the rear and center speakers
Connect rear speakers to the REAR SPEAKERS terminals and a
center speaker to the CENTER SPEAKER terminals.
Center
speaker
SUBWOOFER
Powered subwoofer
OUT
Connecting Audio/Video Components
You can connect the following audio/video components to this
receiver. Refer also to the manuals supplied with your components.
Audio Components Video Components
• Turntable • DVD player*
• CD player* • TV*
• Cassette deck • DBS tuner*
or CD recorder* • VCR
*
You can connect these components using the methods described in
“Analog connections” (below) or in “Digital connections” (see page
8).
Analog connections
Audio component connections
Use the cables with RCA pin plugs (not supplied).
Connect the white plug to the audio left jack, and the red plug to the
audio right jack.
CAUTION:
If you connect a sound-enhancing device such as a graphic equalizer
between the source components and this receiver, the sound output
through this receiver may be distorted.
Turntable
If an earth cable is provided for your
turntable, connect the cable to the
AM (H) terminal on the rear panel.
5
Left rear
speaker
Right rear
speaker
CENTER
SPEAKER
+
–
REAR
SPEAKERS
RIGHT LEFT
Turntable
PHONO
CD
To audio
output
Ex.: This connection is for the
turntable with an MM (movingmagnet) type cartridge.
Note:
Any turntables incorporating a small-output cartridge such as an MC
(moving-coil) type must be connected to this receiver through a
commercial head amplifier or step-up transformer. Direct connection
may result in insufficient volume.
OUT
(REC)
TAPE
CDR
IN
(PLAY)
OUT
(REC)
VCR
IN
(PLAY)
TV
SOUND
DBS
RIGHT LEFT
AUDIO
CD player
PHONO
CD player
CD
OUT
(REC)
To audio output
TAPE
CDR
IN
(PLAY)
OUT
(REC)
VCR
Cassette deck or CD recorder
Cassette deck
To audio input
To audio input
PHONO
CD
OUT
(REC)
TAPE
CDR
IN
(PLAY)
OUT
(REC)
VCR
IN
(PLAY)
TV
SOUND
DBS
CD recorder
RIGHT LEFT
AUDIO
To audio output
To audio output
Note:
You can connect either a cassette deck or a CD recorder to the TAPE/
CDR jacks. When connecting a CD recorder to the TAPE/CDR jacks,
change the source name, which will be shown on the display when
selected as the source, to “CDR.” See page 13 for details.
If your audio components have a COMPU LINK jack
See also page 28 for detailed information about the connection and
the COMPU LINK remote control system.
Video component connections
Use the cables with RCA pin plugs (not supplied).
Connect the white plug to the audio left jack, the red plug to the
audio right jack, and the yellow plug to the video jack.
If your video components have S-video (Y/C-separation) terminals,
connect them using S-video cables (not supplied). Connecting these
video components through the S-video input/output terminals will
give you better picture playback (or recording) quality.
IMPORTANT:
This receiver is equipped with both the composite video and S-video
input/output terminals for connecting video components.
You do not have to connect both the composite video and S-video
terminals.
However, remember that the video signals from the composite
video input terminals are output only through the composite
video output terminals, while the ones from the S-video input
terminals are output only through the S-video output terminals.
Therefore, if a recording video component and a playing video
component are connected to the receiver through the different video
terminals, you cannot record the picture from the playing component
on the recording component. In addition, if the TV and a playing video
component are connected to the receiver through the different video
terminals, you cannot view the playback picture from the playing
component on the TV.
VCR
S-VHS (or VHS) VCR
B
AUDIO
MONITOR
OUT
DVD
OUT
(REC)
VCR
IN
(PLAY)
DBS
VIDEO
DC
F
E
PHONO
CD
OUT
(REC)
TAPE
CDR
IN
(PLAY)
OUT
(REC)
VCR
IN
(PLAY)
TV
SOUND
DBS
A
RIGHT LEFT
Å To left/right channel audio output
ı To left/right channel audio input
Ç To S-video output
Î To composite video output
‰ To composite video input
Ï To S-video input
6
TV and/or DBS tuner
To S-video input
To composite video input
Connect the TV to the MONITOR
OUT jack to view the playback
picture from the other connected
video components.
TV
To audio
output
PHONO
CD
OUT
(REC)
TAPE
CDR
IN
(PLAY)
OUT
(REC)
VCR
IN
(PLAY)
TV
SOUND
DBS
RIGHT LEFT
AUDIO
MONITOR
OUT
DVD
OUT
(REC)
VCR
IN
(PLAY)
DBS
VIDEO
DVD player
• When you connect the DVD player with stereo output jacks:
B
A
RIGHT LEFT
FRONT
CENTER
REAR
RIGHT
SUBWOOFER
OUT
AUDIO
DVD player
DVD
DVD
SUB
WOOFER
LEFT
MONITOR
OUT
DVD
OUT
(REC)
VCR
IN
(PLAY)
DBS
VIDEO
C
Å To front left/right channel audio output (or to audio mixed
output if necessary)
ı To S-video output
Ç To composite video output
When connecting the TV to the AUDIO jacks (TV
SOUND/DBS), DO NOT connect the TV’s video
output to these video input terminals.
Note:
When using AV COMPU LINK remote control system, you can only
connect the TV with AV COMPU LINK EX to the AV COMPU LINK
terminal. See page 29 for details.
VCR
IN
(PLAY)
DBS
VIDEO
To audio
output
DBS tuner
DBS
VCR
IN
(PLAY)
TV
SOUND
DBS
RIGHT LEFT
AUDIO
To composite video output
To S-video output
Note:
When connecting the DBS tuner to the TV SOUND/DBS jacks,
change the source name, which will be shown on the display when
selected as the source, to “DBS.” See page 13 for details.
• When you connect the DVD player with its analog discrete output
(5.1 CH reproduction) jacks:
E
A
DVD player
DVD
C
B
D
RIGHT LEFT
FRONT
CENTER
REAR
RIGHT
SUBWOOFER
OUT
AUDIO
DVD
SUB
WOOFER
LEFT
MONITOR
OUT
DVD
OUT
(REC)
VCR
IN
(PLAY)
DBS
VIDEO
F
Å To center channel audio output
ı To subwoofer audio output
Ç To S-video output
Î To front left/right channel audio output
‰ To rear left/right channel audio output
Ï To composite video output
7
Digital connections
DIGITAL OUT
PCM/DOLBY DIGITAL
DTS
This receiver is equipped with four DIGITAL IN terminals — one
digital coaxial terminal and three digital optical terminals, and one
DIGITAL OUT terminal.
You can connect any digital equipment such as —
• DBS tuner,
• Digital TV broadcast tuner,
• DVD player,
• CD player, and
• CD recorder.
IMPORTANT:
• When connecting the DVD player, digital TV broadcast tuner or DBS
tuner using the digital terminals, you also need to connect it to the
video jack (either composite video terminal or S-video terminal) on
the rear. Without connecting it to the video jack, you can view no
playback picture.
• After connecting the components using the DIGITAL IN terminals,
set the following correctly if necessary.
– Set the digital input (DIGITAL IN) terminal setting correctly. For
details, see “Digital Input (DIGITAL IN) Terminal Setting” on page
16.
– Select the digital input mode correctly. For details, see “Selecting
the Analog or Digital Input Mode” on page 16.
Digital input terminals
Notes:
• When shipped from the factory, the DIGITAL IN terminals have
been set for use with the following components.
– DIGITAL 1 (coaxial): For DVD player
– DIGITAL 2 (optical): For CD player
– DIGITAL 3 (optical): For digital TV broadcast tuner
– DIGITAL 4 (optical): For CD recorder
• When you want to operate the CD player or CD recorder using the
COMPU LINK remote control system, connect the target
component also as described in “Analog connections” (see page 6).
• When you want to operate the DVD player using the AV COMPU
LINK remote control system, connect the DVD player also as
described in “Analog connections” (see page 7).
Digital output terminal
CD recorder, etc.
Digital optical cable (not supplied)
between digital optical terminals
Digital TV
CD player
Digital coaxial cable (not supplied)
between digital coaxial terminals
Digital optical cable (not supplied)
between digital optical terminals
When the component has a digital
coaxial output terminal, connect it to the
DIGITAL 1 (DVD) terminal, using the
digital coaxial cable (not supplied).
DVD player
DVD
CD recorder
DIGITAL 1
(DVD)
When the digital recording
equipment such as a CD recorder
has a digital optical input terminal,
connecting it to the DIGITAL OUT
terminal enables you to perform
digital-to-digital recording.
When the component has a digital
optical output terminal, connect it to the
DIGITAL 2 (CD), DIGITAL 3 (TV), or
DIGITAL 4 (CDR) terminal, using the
digital optical cable (not supplied).
Before connecting a digital
optical cable, unplug the
protective plug.
DIGITAL 2 ( CD )
DIGITAL 3 ( TV )
DIGITAL 4 (CDR)
DIGITAL IN
8
Connecting the Power Cord
Putting Batteries in the Remote Control
Before plugging the receiver into an AC outlet, make sure that all
connections have been made.
Plug the power cord into an AC outlet.
Keep the power cord away from the connecting cables and the
antenna. The power cord may cause noise or screen interference. We
recommend that you use a coaxial cable to connect the antenna,
since it is well-shielded against interference.
Note:
The preset settings such as preset channels and sound adjustment
may be erased in a few days in the following cases:
–When you unplug the power cord.
–When a power failure occurs.
CAUTIONS:
• Do not touch the power cord with wet hands.
• Do not pull on the power cord to unplug the cord. When
unplugging the cord, always grasp the plug so as not to damage
the cord.
Before using the remote control, put two supplied batteries first.
When using the remote control, aim the remote control directly at
the remote sensor on the receiver.
1
2
R6P(SUM-3)/AA(15F)
3
1. On the back of the remote control, remove the
battery cover.
2. Insert batteries. Make sure to match the polarity:
(+) to (+) and (–) to (–).
3. Replace the cover.
If the range or effectiveness of the remote control decreases, replace
the batteries. Use two R6P(SUM-3)/AA(15F) type dry-cell batteries.
CAUTION:
Follow these precautions to avoid leaking or cracking cells:
• Place batteries in the remote control so they match the polarity:
(+) to (+) and (–) to (–).
• Use the correct type of batteries. Batteries that look similar may
differ in voltage.
• Always replace both batteries at the same time.
• Do not expose batteries to heat or flame.
9
Basic Operations
The following operations are commonly used when you play any sound source.
Turning the Power On and Off (Standby)
On the front panel:
To turn on the power, press STANDBY/ON
STANDBY
. The STANDBY lamp goes off. The name
of the current source (or station frequency)
STANDBY/ON
appears on the display.
Current source name appears
1
SPK
L
ANALOG
R
VOLUME
Current volume level is shown here
To turn off the power (into standby mode),
press STANDBY/ON again.
STANDBY
The STANDBY lamp lights up. A small amount
of power is consumed in standby mode. To turn
STANDBY/ON
the power off completely, unplug the AC power
cord.
From the remote control:
To turn on the power, press AUDIO .
AUDIO
The STANDBY lamp goes off. The name of
the current source (or station frequency)
appears on the display.
To turn off the power (into standby mode), press
AUDIO
again. The STANDBY lamp lights up.
Selecting the Source to Play
Press one of the source selecting buttons.
DVD MULTI Select the DVD player for viewing the digital
video disc using the analog discrete output mode
(5.1 CH reproduction).
To enjoy the DVD MULTI playback, see page
27.
DVD Select the DVD player.
VCR Select the video component connected to the
VCR jacks.
TV SOUND/DBS Select TV sounds (or the DBS tuner).
PHONO* Select the turntable.
CD* Select the CD player.
TAPE/CDR* Select the cassette deck (or the CD recorder).
FM/AM* Select an FM or AM broadcast.
• Each time you press the button, the band
alternates between FM and AM.
Notes:
• When connecting a CD recorder (to the TAPE/CDR jacks), and a
DBS tuner (to the TV SOUND/DBS jacks), change the source name
shown on the display. For details, see page 13.
• When you press one of the source selecting buttons on the remote
control marked above with an asterisk (*), the receiver
automatically turns on.
Signal and speaker indicators on the display
The signal indicators light up in the following cases:
• Only the indicators for the incoming signals light up.
• When analog input is selected, “L” and “R” always light up.
• When “DVD MULTI” is selected as the source, “L,” “C,” “R,”
“LFE,” “LS” and “RS” light up.
The speaker indicators light up only —:
• When the corresponding speaker is activated.
AND
• When the corresponding speaker is required for the DSP mode
selected currently.
Signal indicators light up in
red:
Speaker indicators light up
in white:
On the front panel:
DVD MULTI
PHONO
DVD VCR
CD TAPE/CDR
From the remote control:
DVD MUIL TIDVD
Selected source name appears
12
ANALOG
DIGITAL
SPK
LC
R
PRO LOGIC DSP H.PHONE AUTO MUTING TUNED STEREO
S.WFR
LFE
LS RS
S
CH-
DIGITAL AUT O
LINEAR PCM
TV SOUND/DBS
SOURCE NAME
FM/AM
SOURCE NAME
CD
FM/AM
TAPE/CDRTV/DBS VCR PHONO
BASS BOOST INPUT ATT SLEEP
VOLUME
RCL
LFE
S.WFR
LS RSS
RCL
LFE
S.WFR
LS RSS
L:•When digital input is selected: Lights up when the left
channel signal comes in.
• When analog input is selected: Always lights up.
R:•When digital input is selected: Lights up when the right
channel signal comes in.
• When analog input is selected: Always lights up.
C: Lights up when the center channel signal comes in.
LS: Lights up when the left rear channel signal comes in.
RS: Lights up when the right rear channel signal comes in.
S: Lights up when the monaural rear channel signal comes in.
LFE: Lights up when the LFE channel signal comes in.
Notes:
• When “SUBWOOFER” is set to “YES,”
• When you select “DVD MULTI,” all the signal indicators except “S”
light up.
S.WFR
lights up.
10
Selecting different sources for picture and
sound
You can watch picture from a video component while listening to
sound from another component.
Press one of the audio source selecting buttons — PHONO, CD,
TAPE/CDR, FM/AM, TV SOUND/DBS* (or TV/DBS on the
remote control), while viewing the picture from a video component
such as the VCR, DVD player, or DBS tuner, etc.
Selecting the Front Speakers
On the front panel ONLY:
When you have connected two pairs of the front speakers, you can
select which to use.
SPEAKERS ON/OFF
1
2
Notes:
• Once you have selected a video source, pictures of the selected
source are sent to the TV until you select another video source.
* The TV SOUND/DBS (or TV/DBS on the remote control) only
works for selecting “DBS” as the source but not for selecting “TV
SOUND (or TV on the remote control).” When you use the DBS
tuner, change the source name correctly (see page 13).
Adjusting the Volume
On the front panel:
To increase the volume, turn MASTER
VOLUME clockwise.
To decrease the volume, turn it
counterclockwise.
• When you turn MASTER VOLUME
rapidly, the volume level also changes
rapidly.
• When you turn MASTER VOLUME slowly,
the volume level also changes slowly.
From the remote control:
To increase the volume, press VOLUME +.
To decrease the volume, press VOLUME –.
CAUTION:
Always set the volume to the minimum before starting any source. If
the volume is set at its high level, the sudden blast of sound energy
can permanently damage your hearing and/or ruin your speakers.
Note:
The volume level can be adjusted within the range of “0” (minimum) to
“80” (maximum).
MASTER VOLUME
+
VOLUME
−
To use the speakers connected to the FRONT SPEAKERS 1
terminals, press SPEAKERS ON/OFF 1 so that the SPK 1 indicator
lights up on the display. (Make sure that the SPK 2 is not on the
display.)
To use the speakers connected to the FRONT SPEAKERS 2
terminals, press SPEAKERS ON/OFF 2 so that the SPK 2 indicator
lights up on the display. (Make sure that the SPK 1 is not on the
display.)
To use both sets of the speakers, press SPEAKERS ON/OFF 1 and
2 so that the SPK 1 and SPK 2 indicators light up on the display.
To use neither sets of the speakers, press SPEAKERS ON/OFF 1
and 2 so that the SPK 1 and SPK 2 indicators disappear from the
display.
Notes:
• If you select any of the DSP modes while using both the speakers
connected to the FRONT SPEAKERS 1 and 2 terminals, the
speakers connected to the FRONT SPEAKERS 2 terminals are
deactivated.
• While the DSP MODE is in use, you can only select either the
speakers connected to the FRONT SPEAKERS 1 or 2 terminals.
Listening only with headphones
You must turn off both pairs of speakers when you listen with
headphones.
1. Connect a pair of headphones to the PHONES jack on the front
panel.
2. Press SPEAKERS ON/OFF 1 and SPEAKERS ON/OFF 2 so
that neither the SPK 1 nor SPK 2 indicator appears on the
display.
This cancels the DSP mode currently selected, and activates the
HEADPHONE mode (see below).
• “HEADPHONE” appears and H. PHONE indicator lights up
on the display.
11
HEADPHONE mode:
This mode can reproduce the LFE channel signals, mixing them
with the front channel signals. So you will not miss the
subwoofer sounds even if you listen to a source using the
headphones.
Notes:
• While in the HEADPHONE mode, you cannot use any DSP modes
(see page 20.)
• Activating the speaker cancels the HEADPHONE mode and turns
on the DSP mode previously selected.
CAUTION:
Be sure to turn down the volume before connecting or putting on
headphones, as high volume can damage both the headphones and
your hearing.
Loading...
