Thank you for purchasing a JVC product.

Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best

possible performance from the unit.

IMPORTANT FOR LASER PRODUCTS

ENGLISH

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel.

3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical instruments.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.

WARNINGS:

This symbol is only valid in the European Union.

Information for Users on Disposal of Old Equipment

This symbol indicates that the product with this symbol should not be disposed as general household waste at its end-of-life. If you wish to dispose of this product, please do so in accordance with applicable national legislation or other rules in your country and municipality. By disposing of this product correctly, you will help to conserve natural resources and will help prevent potential negative effects on the environment and human health.

To prevent accidents and damage

• DO NOT install any unit and wire any cable in locations where;

– it may obstruct the steering wheel and

gearshift lever operations.

– it may obstruct the operation of safety devices

such as air bags.

– it may obstruct visibility.

• DO NOT operate the unit while driving.

If you need to operate the unit while driving, be

sure to look around carefully.

• The driver must not watch the monitor while driving.

• The driver must not put on the headphones while driving.

Cautions on the monitor:

• The monitor built in this unit has been produced with high precision, but it may have some ineffective dots. This is inevitable and is not malfunction.

• Do not expose the monitor to direct sunlight.

• Do not operate the touch panel using a ball-point pen or similar tool with the sharp tip.

Touch the buttons on the touch panel with your

finger directly (if you wear a glove, take it off).

• When the temperature is very cold or very hot... – Chemical changes occur inside, causing

malfunction.

– Pictures may not appear clearly or may move

slowly. Pictures may not be synchronized with the sound or picture quality may decline in such environments.

How to reset your unit

• Your preset adjustments will also be erased.

How to forcibly eject a disc

ENTER

NO EJECT?

EMERGENCY EJECT?

Back

at the same time

• If this does not work, reset the unit.

For safety...

• Do not raise the volume level too much, as this will block outside sounds, making driving dangerous.

• Stop the car before performing any complicated operations.

Temperature inside the car...

If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car becomes normal before operating the unit.

Exit

INTRODUCTION

Playable disc type ............................ 4

Basic operations—

Monitor panel/touch panel ............ 5

Basic operations—

Remote controller (RM-RK251) ...... 6

OPERATIONS

Before operating the unit ................ 8

Common operations ........................ 9

Listening to the radio ...................... 10

Disc operations ................................ 16

Dual Zone operations ....................... 30

SD operations .................................. 33

USB operations ................................ 35

EXTERNAL DEVICES

Bluetooth® operations—

Cellular phone/audio player .......... 37

Listening to the CD changer .............. 44

Listening to the DAB tuner ............... 46

Listening to the iPod/D. Player ......... 50

Using other external components ..... 52

ENGLISH

For security reasons, a numbered ID card is provided with this unit, and the same ID number is imprinted on the unit’s chassis. Keep the card in a safe place, as it will help the authorities to identify your unit if stolen.

SETTINGS

Sound equalization .......................... 55

Assigning titles to the sources .......... 56

Menu operations ............................. 57

REFERENCES

Maintenance ................................... 68

More about this unit ........................ 69

Troubleshooting .............................. 75

Specifications .................................. 80

INTRODUCTION

Playable disc type

Disc type Recording format, file type, etc. Playable

DVD DVD Video (Region Code: 2)*

ENGLISH

DVD Audio

DVD-ROM

DVD Recordable/Rewritable (DVD-R*2/-RW, +R/+RW*3)

• DVD Video: UDF bridge

• DVD-VR

• DivX/MPEG1/MPEG2/JPEG/MP3/ WMA/WAV/AAC: ISO 9660 level 1, level 2, Romeo, Joliet

• DVD-RAM cannot be played.

DVD Video

DVD-VR (non-CPRM only)

DivX/MPEG1/MPEG2

JPEG

MP3/WMA/WAV/AAC*

MPEG4

DVD+VR

Dual Disc DVD side

Non-DVD side

CD/VCD Audio CD/CD Text (CD-DA)/DTS-CD

VCD (Video CD)

CD-ROM

CD-I (CD-I Ready)

CD Recordable/Rewritable (CD-R/-RW)

• ISO 9660 level 1, level 2, Romeo, Joliet

CD-DA

MP3/WMA/WAV/AAC*

JPEG

DivX/MPEG1/MPEG2

MPEG4

*1 If you insert a DVD Video disc of an incorrect Region Code, “Region code error” appears on the monitor. *2 DVD-R recorded in multi-border format is also playable (except for dual layer discs). *3 It is possible to play back finalized +R/+RW (Video format only) discs. However, the use of +R double layer disc is

not recommended.

*4 This unit can play back AAC files encoded using iTunes.

Caution for DualDisc playback

The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Audio” standard. Therefore, the use of Non-DVD side of a DualDisc on this product may not be recommended.

Basic operations — Monitor panel/touch panel

Display <AV Menu>.

• ☞ page 57.

Display <Source Menu>.

• ☞ pages 9 and 30.

Display and erase the Short Cut windows.

Available functions vary among the sources. For details, see each source operation section.

ENGLISH

Change the display information.

Change the sources.

• ☞ page 9.

• Activate/deactivate TA Standby Reception.

• Display <PTy Search> [Hold].

• ☞ page 12.

• Turn on the power.

• Turn off the power [Hold].

• Attenuate the sound (if the power is on).

Reset the unit.

• Use only when the internal system malfunctions.

• For details on the touch panel operations,

see each source operation sections.

Adjust the volume.

• Display the <Open/Tilt> screen

• Eject the disc and display the <Open/Tilt> screen [Hold].

• Close the monitor panel when the <Open/Tilt> screen is displayed.

• [OPEN]: Open the monitor panel.

• [EJECT]: Eject the disc.

• [CLOSE]: Close the monitor panel.

• [TILT +/–]: Tilt the monitor panel.

• [Exit]: Erase this screen.

• Shaded icons cannot be used at that time.

Remote sensor

INTRODUCTION

Basic operations — Remote controller (RM-RK251)

Installing the battery

ENGLISH

If the range or effectiveness of the remote controller decreases, replace both batteries.

Before using the remote controller:

• Aim the remote controller directly at the remote sensor on the unit.

• DO NOT expose the remote sensor to bright light (direct sunlight or artificial lighting).

The unit is equipped with the steering wheel remote control function.

• See the Installation/Connection Manual (separate volume) for connection.

R03/LR03/AAA

Caution:

• Do not expose batteries to heat or flame.

Main elements and features

;

a s

IMPORTANT:

If Dual Zone is activated (☞ page 30), the remote controller functions only for operating the DVD/CD player.

1*1 • Turns on the power.

• Attenuates the sound if the power is on.

• Turns off the power if pressed and held (while the power is on).

2*1 Selects the source. 3*1 • Displays <Dial Menu>.

• Displays <Redial> list if pressed and held.

• Answers incoming calls.

1,2

Adjusts the volume level.

1,2

Selects surround mode.

6 • DVD/DivX 6: Shows the disc menu.

• VCD: Resumes PBC playback.

• DVD-VR: Shows the Original Program screen.

7 • Makes selection/settings.

• ~: Skips back or forward by 5 minutes for DivX/MPEG1/MPEG2.

• DISC +/– buttons: Changes discs for “CD-CH.”

8 Shows the on-screen bar.

Changes the display information.

9* p Display or erase <AV Menu>. q For disc/SD/USB operations:

• 6: Plays/pauses.

• 5 / ∞:

DVD: Selects the title/group. DVD-VR: Selects the program/playlist. SD/USB/other discs (except VCD/CD): Selects

the folders.

• 4 / ¢:

– Press briefly: reverse skip/forward skip. – Press and hold: reverse search/forward

search.

For FM/AM operations:

• 5 / ∞: Selects the preset stations.

• 4 / ¢: Functions to search for stations.

– Press briefly: Auto Search – Press and hold: Manual Search

For DAB tuner operations:

• 5 / ∞: Select the services.

• 4 / ¢: Functions to search for ensembles.

– Press briefly: Auto Search. – Press and hold: Manual Search.

For Apple iPod/JVC D. player operations:

• ∞: Pauses/stops or resumes playback.

• 5: Enters the main menu (then 5 / ∞ / 4 / ¢ work as the menu selecting

buttons).*

• 4 / ¢ (in menu selecting mode)

– Selects an item if pressed briefly. (Then,

press ∞ to confirm the selection.)

– Skips 10 items at a time if pressed and held.

For Bluetooth operations:

• 4 / ¢: reverse skip/forward skip (for audio operation)

• 6: Answers incoming calls (for “Bluetooth PHONE”), plays/pauses (for “Bluetooth AUDIO”).

w TUNER/DAB: Selects the bands. DISC/SD/USB: Stops play. Bluetooth PHONE: Ends the call. Bluetooth AUDIO: Plays/pauses.

• This button does not function as the BACK button for this model.

Adjusts the volume level through the 2nd AUDIO

OUT plug.

r*2 Activates or deactivates Dual Zone.

1,2

Selects the sound mode.

t* y • DVD Video/DivX 6: Shows the disc menu.

• VCD: Resumes PBC playback.

• DVD-VR: Shows the Play List screen.

u RETURN button

• For VCD: Returns to the PBC menu.

i DISC/SD/USB: Switches number entry mode.

• Also functions as CLEAR button to erase the misentry after entering the wrong number.

o • Enter the numbers.

• FM/AM/DAB: Selects the preset station/ service directly.

• CD changer: Selects the disc directly.

;*1 Changes the aspect ratio of the playback

pictures.

a Reverse search/forward search for disc/SD/USB

operations.

s • DVD Video: Selects audio language ( ),

subtitles (

• DVD Audio: Selects audio stream (

), angle ( ).

• DVD-VR: Turn on/off subtitles ( ), and selects audio channel ( )

• DivX: Selects audio language ( ), subtitles ( ).

• VCD: Selects audio channel ( ).

*1 If Dual Zone is activated, these buttons cannot be

used.

*2 These buttons can be used only when the slide cover is

closed.

*3 5 : Returns to the previous menu. ∞ : Confirms the selection.

ENGLISH

INTRODUCTION

Before operating the unit

Cancel the display demonstration and set the clock (☞ pages 58 and 59 for details).

• Non-available items will be displayed being shaded

ENGLISH

on the AV Menu screens.

Indication language:

In this manual, English indications are used for purpose of explanation. You can select the indication language on the monitor. (☞ page 59)

~ Turn on the power.

Ÿ Display <AV Menu>.

! Display the <Setup> menu.

@ Set the clock settings.

Moves to the preceding menu page

Moves to the succeeding menu page

¤ Finish the procedure.

⁄ Cancel the display demonstrations.

Select <Off>.

Return to the previous screen.

Common operations

Selecting the playback source

• Available sources depend on the external components you have connected, media you have attached, and the <Input> settings you have made (☞ pages 62 and 63).

On the touch panel:

☞ page 30

On the monitor panel:

Exit

Changing the display information

• Available display information varies among the playback sources.

On the monitor panel only:

• Each time you press DISP, the display changes to show the various information.

Ex. When the playback source is a DivX disc.

Playback picture screen (only for video sources)

Source information screen

Preset station (service) list, track (file) list, or phone number list

ENGLISH

TUNER = DAB = DISC (DVD/VCD/CD) = SD = USB =CD-CH, iPod, D.PLAYER, or EXT-IN = Bluetooth PHONE = Bluetooth AUDIO = AV-IN = (back to the beginning)

• You cannot select these sources if they are not ready.

Back to the beginning

Animation screen

Navigation screen (When <

Navigation> is

selected for < (

☞ page 62).

AV Input>):

OPERATIONS

Listening to the radio

Preset No.

PS (station name) for FM RDS. If no PS signal is coming in, the tuned frequency appears.

ENGLISH

Band

Sound mode

☞ page 55)

(

Tuner/Standby

Reception indicators

☞ page 9

Press [SOURCE], then press [TUNER]. ] (☞ page 9)

• You can also use SOURCE on the monitor panel. Press it repeatedly.

Ÿ Press [BAND]. ! Press [4] or [¢] to search for a station—Auto Search.

• Manual Search: Hold either [4]or [¢] until “Manual Search” appears on the display, then press it repeatedly.

• The ST indicator lights up when receiving an FM stereo broadcast with sufficient signal strength.

When an FM stereo broadcast is hard to receive

1 Press [AV MENU].

PTY code for FM RDS

☞ page 12

: Buttons on the

touch panel. In the explanation, they are indicated inside [ ].

2 Press [Mode].

Reception improves, but stereo effect will be lost.

• The MONO indicator lights up.

To restore stereo effect, select <Off>.

Tuning in to stations with sufficient signal strength

This function works only for FM bands. Once you have activated this function (selected <Local>), it always works when searching for FM stations.

1 Press [AV MENU]. 2 Press [Mode]. 3

Manual presetting

Ex.: Storing FM station of 92.5 MHz into preset

number 4 of the FM1 band.

1 Display the Preset List.

ENGLISH

Only stations with sufficient signal strength will be detected.

• The DX indicator goes off, then the LO indicator lights up.

FM station automatic presetting —SSM (Strong-station Sequential Memory)

This function works only for FM bands. You can preset six stations for each band.

1 Press [AV MENU]. 2 Press [Mode]. 3

Local FM stations with the strongest signals are searched and stored automatically in the FM band.

2 Tune in to a station you want to preset.

3 Select a preset number.

The station selected in step 2 is now stored in preset number 4.

OPERATIONS

Selecting preset stations

On the remote:

ENGLISH

On the unit:

To select directly on the touch panel

To select from the Preset List

The following features are available only for FM RDS stations.

Searching for FM RDS programme—PTY Search

You can search for your favorite programmes being broadcast by selecting the PTY code for your favorite programmes.

1 Display <PTy Search> menu.

• <PTy Search> menu can also be accessed by pressing [SHORT CUT] on the touch panel, then...

☞ page 55 ☞ page 14

2 Select a PTY code.

• In the example below, a PTY code is selected from the Preset List.

If you enter <PTy Code> below, you can select

one from 29 PTY codes.

PTY Search starts. If there is a station broadcasting a programme of the same PTY code as you have selected, that station is tuned in.

Available PTY codes:

News, Current Affairs, Information, Sport, Education, Drama, Cultures, Science, Varied Speech, Pop Music, Rock Music, Easy Listening, Light Classics M, Serious Classics, Other Music, Weather & Metr, Finance, Children’s Progs, Social Affairs, Religion, Phone In, Travel & Touring, Leisure & Hobby, Jazz Music, Country Music, National Music, Oldies Music, Folk Music, Documentary

Storing your favorite programme types

You can store your favorite PTY codes into the PTY Preset List. Ex.: Storing <Drama> into <Preset 1>.

ENGLISH

OPERATIONS

Activating/deactivating TA/PTY Standby Reception

TA Standby Reception Indicator

Press

ENGLISH

on the monitor panel to

activate.

The unit will temporarily switch to Traffic Announcement (TA), if available, from any source other than AM. The volume changes to the preset TA volume level if the current level is lower than the preset level (☞ page

62).

Not yet activated. Tune in to another station providing the RDS signals.

to deactivate.

Press

PTY Standby Reception Indicator

To activate, display <AV Menu>, then select <Mode>, press [On] for <PTy Standby> (☞ next column).

The unit will temporarily switch to your favorite PTY programme from any source other than AM.

Not yet activated. Tune in to another station providing the RDS signals.

To deactivate, press [Off] for <PTy Standby> in step 3 (☞ next column).

Lights up

Flashes

Goes off

PTY

Lights up

Flashes

Goes off

To activate PTY Standby Reception

1 Press [AV MENU]. 2 Press [Mode]. 3

PTY Standby Reception is now activated for PTY code <News>: the initial setting.

• PTY Standby Reception can be easily activated or deactivated by pressing [SHORT CUT] on the touch panel, then...

☞ page 55

☞ page 12

• When a DAB tuner is connected, TA Standby/PTY Standby Reception also works for the DAB tuner and searches for the services.

To change the PTY code for PTY Standby Reception

1 Press [AV MENU]. 2 Press [Mode]. 3

Select your favorite PTY code.

Tracing the same programme— Network-Tracking Reception

When driving in an area where FM reception is not sufficient enough, this unit automatically tunes in to another FM RDS station of the same network, possibly broadcasting the same programme with stronger signals.

Programme A broadcasting on different frequency areas (01 – 05)

When shipped from the factory, Network-Tracking Reception is activated.

To change the Network-Tracking Reception setting, see <AF Regional> on page 62.

• When the DAB tuner is connected, refer also to “Tracing the same programme—Alternative Frequency Reception (DAB AF).” (☞ page 49)

ENGLISH

Automatic station selection— Programme Search

Usually when you select preset stations, the preset station is tuned in. If the signals from the FM RDS preset station are not sufficient for good reception, this unit, using the AF data, tunes in to another frequency broadcasting the same programme as the original preset station is broadcasting. (☞ page 62)

• The unit takes some time to tune in to another station using programme search.

OPERATIONS

Disc operations

The disc type is automatically detected, and playback starts automatically (for some discs: automatic start depends on its internal program).

ENGLISH

If a disc does not have any disc menu, all tracks in it will be played repeatedly until you change the source or eject the disc.

” appears on the monitor, the unit cannot accept the operation you have tried to do.

If “

• In some cases, without showing “ ,” operations will not be accepted.

~ Open the monitor panel.

<Open/Tilt> menu appears.

• Shaded icons cannot be used at that time.

• By pressing and holding the button, you can open the monitor panel and eject the disc.

Ÿ Press [OPEN].

Caution on volume setting:

Discs produce very little noise compared with other sources. Lower the volume before playing a disc to avoid damaging the speakers by the sudden increase of the output level.

! Insert a disc.

Label side

Monitor panel closes automatically. If not, press [CLOSE].

Caution:

Do not place your finger behind the monitor panel.

• [OPEN]: Open the monitor panel.

• [EJECT]: Eject the disc.

• [CLOSE]: Close the monitor panel.

• [TILT +/–]: Tilt the monitor panel.

• [Exit]: Erase this screen.

While playing the following discs, press .

• Each time you press the button, the display changes to show the different information (☞ page 9).

DVD Video: Title no./Chapter no./Playing time

DVD-VR: Program no. (or Playlist no.)/Chapter no./Play time

Disc type *

Audio format

Playback mode

Speaker/signal

indicators

(

☞ page 69)

: Buttons on the touch panel. In the explanation,

they are indicated inside [ ].

These buttons also work when they are not

shown on the touch panel (while watching pictures on the screen).

BONUS indicator

(

☞ page 26)

[3 / 8] Start and pause playback [

7] Stop playback

[

4 ¢] Press: Select track

Hold: Reverse/forward search [5 ∞] Select group

3 / 8] Start and pause playback

[ [

7] Stop playback

[

4 ¢] Press: Select chapter

Hold: Reverse/forward search [5 ∞] Select title/program/playlist

Group no./Track no./Playing time

Sampling frequency/Bit rate/Recorded signal channel no.

Surround mode (

☞ page 27)

☞ page 22

Reproduced sound indicator— MULTI CH/LR ONLY (

☞ page 70)

B.S.P indicator (

☞ page 26)

☞ page 22

ENGLISH

*1 DVD-VR also indicates either PRG (program) or PLAY (playlist) playback. *2 Search speed: x2 ] x10.

OPERATIONS

While playing the following discs, press .

• Each time you press the button, the display changes to show the different information (☞ page 9).

For DivX/MPEG1/MPEG2: Folder no./Track no./Playing time

ENGLISH

Surround mode *

Disc type

(☞ page 27)

For JPEG: Folder no./Track no.

Total track no. included in the disc

[

3 / 8] Start and pause playback

[

7] Stop playback

[

4 ¢] Press: Select track

Hold: Reverse/forward search for DivX/MPEG1/MPEG2 [5 ∞] Press: Select folder Hold: Display Folder list

Track no./Playing time

PBC indicator

lights up when PBC is

in use.

[3 / 8] Start and pause playback [

7] Stop playback

[

4 ¢] Press: Select track

Hold: Reverse/forward search

*2 Search speed: x2 ] x10. *3 Surround mode and sound mode cannot be used at the same time. *4 Search speed: ¡1 ] ¡2.

☞ page 22

Total track no. included in the disc

Total play time

☞ page 22

Track no./Playing time

Only for CD Text

ENGLISH

Sound mode *

(☞ page 55)

☞ page 22

[

3 / 8] Start and pause playback

[

7] Stop playback

[

4 ¢] Press: Select track

Hold: Reverse/forward search

Audio format

(MP3/WMA/WAV/AAC)

☞ page 22

3 / 8] Start and pause playback

[ [

7] Stop playback

[4 ¢] Press: Select track Hold: Reverse/forward search [5 ∞] Press: Select folder Hold: Display Folder list

• While playing a DTS-CD

DTS indicator

Speaker/signal

indicators

(

☞ page 69)

Folder no./Track no./Playing time

Total track no. included in the disc

Total play time

Tag data appears only when it is recorded

*2 Search speed: x2 ] x10. *5 “No Name” appears for conventional CDs.

OPERATIONS

Operation buttons on the monitor screen

You can display the following operation buttons while watching the playback pictures on the monitor.

• While the operation buttons are displayed, aspect ratio is fixed to <Full> (☞ page 59).

• If no operation is done for about 5 seconds, the operation buttons disappears (except when a disc menu is displayed).

ENGLISH

☞ pages 23 to 25 on how the operation buttons particularly work for a variety of the discs

To erase the operations, touch the screen again.

Touch the screen (center portion).

Touch [KEY].

[SOURCE] Display the <Source Menu> [

AV MENU] Display the <AV Menu>

[

SHORT CUT] Display the Short Cut buttons

[

3 / 8] Start and pause playback

[

7] Stop playback

[

4 ¢] Press: Select track

Hold: Reverse/forward search [

5 ∞] Select folders

• The above buttons also work when they are not shown on the touch panel (while watching pictures on the screen).

* While a disc menu is played back for DVD, [KEY] is

automatically displayed. On the disc menu, you can select a menu item directly by touching it on the screen.

For DVD/VCD/DivX menu operation playback [

2 3 5 ∞] Select the menu items

[

ENT] Confirm the selection

[

TOP MENU] Display the disc menu

[

MENU] Display the disc menu

[

RETURN] Return to the previous menu or display the

menu (only for VCD with PBC)

For entering the numbers [

DIRECT CLR] Switch between chapter/track entry and

Erase the last entry when you enter a wrong

[

0]–[9]=[ENT] Enter the number

Ex. To enter “105”: press [

title/group/folder entry

number

1], [0], [5], then [ENT]

Selecting playback modes

You can use only one of the following playback modes—Intro/Repeat/Random. Ex. To select Track Repeat

Disc type Intro Repeat Random

—

— Track: Repeats current track —

—

Track: Plays the first 15

seconds of each track (for VCD: PBC not in use)

When one of the playback modes is selected, the corresponding indicator lights up on the source information screen.

To cancel, select <Off>.

Chapter: Repeats current

chapter

Title: Repeats current title

Chapter: Repeats current

chapter

Program: Repeats current

program (not available for Playlist playback).

Track: Repeats current track*

(for VCD: PBC not in use)

Disc (All): Randomly plays all

tracks (for VCD: PBC not in use)

ENGLISH

—

Track: Plays the first 15

seconds of each track

Folder: Plays the first 15

seconds of the first track of each folder

—

You can also use [SHORT CUT] to turn on and off Track Repeat

Track: Repeats current track* Folder: Repeats all tracks of

the current folder

Track: Repeats current track Folder: Repeats current folder

Folder: Repeats current folder

Folder: Randomly plays all

tracks of current folder, then tracks of next folders

Disc (All): Randomly plays all

tracks

—

OPERATIONS

Selecting tracks on the list

If a disc includes folders, you can display the Folder/ Track (File) Lists, then start playback.

ENGLISH

Prohibiting disc ejection

You can lock a disc in the loading slot.

at the same time

Select a folder (1), then a track (2).

Selected track starts playing. (* Press to move to the previous/next pages of the list) 1 Current folder list number/total folder list

number

2 Current track list number/total track list

number of the current folder

• Track List can also be accessed by pressing DISP on the monitor panel.

To cancel the prohibition, repeat the same procedure to select <EJECT OK?>.

Using Short Cut Icons

You can easily access the some frequently used functions by using [SHORT CUT] on the touch panel.

• For video software:

Aspect ratio

☞ page 59)

( Surround (

☞ page 27)

Sound mode (

☞ page 55)

• For audio software:

Turn on or off Track Repeat (Repeat play:

☞ page 21)

Selected track starts playing.

Operations using the remote controller—RM-RK251

: Stop playback.

: Start playback/pause (if pressed during playback).

: Reverse/forward search*2. (No sound can be heard.)

(Slow motion*3 during pause. No sound can be heard.)

: Press: Select chapter (during playback or pause).

Hold: Reverse/forward search*4.

: Select title (during playback or pause).

ENGLISH

*1 Erases the misentry of the

number.

*2 Search speed: x2 ] x5 ]

x10 ] x20 ] x60

*3 Slow motion speed: 1/32 ]

1/16 ] 1/8 ] 1/4 ] 1/2

*4 Search speed: x2 ] x10

= = :

Select chapter. Select title (when not playing).

(twice) = = :

Select title (during playback or pause).

: Select aspect ratio.

: Select audio language.

: Select subtitle language.

: Select view angle.

: Stop playback.

: Start playback/pause (if pressed during playback).

: Reverse/forward search*2.

: Press: Select track.

Hold: Reverse/forward search*4.

: Select group.

= = :

Select track.

(twice) = = :

Select group.

: Select aspect ratio.

: Select audio stream.

Using menu driven features

1 2 Select an item you want

to start play.

Using menu driven features

1 2 Select an item you want

to start play.

OPERATIONS

ENGLISH

: Stop playback.

: Start playback/pause (if pressed during playback).

: Reverse/forward search*5. (No sound can be heard.)

: Press: Select track.

Hold: Reverse/forward search*

. (No sound can be heard.)

: Select folder.

= = :

Select track (within the same folder).

(twice) = = :

Select folder.

Current playback position

While playing...

Back/advance the scenes by 5 minutes.

2nd press

1st press

For DivX6: Using menu driven features

1 2 Select an item you want to start play.

: Select aspect ratio.

: Select audio language.

(DivX only)

: Select subtitle language.

(DivX only)

3rd press

2nd press

: Stop playback.

: Start playback/pause (if pressed during

playback).

: Reverse/forward search*2. (No sound can be

heard.)

(Slow motion*3 during pause. No sound can

be heard.)

• Reverse slow motion does not work. : Press: Select chapter (during playback or

pause).

Hold: Reverse/forward search*4.

: Select program.

Select playlist (during playback or pause).

: Select aspect ratio. : Select audio channel (ST: stereo, L: left, R:

Right).

: Turn on/off subtitle.

= = : Select chapter. Select program (when not playing).

(twice) = = : Select program/playlist (during playback or

pause).

Using Original Program/Play List screens

( ☞ page 26)

1 : For Original Program

: For Play List

2 Select an item you want to start playing.

3 To erase the screen.

: Stop playback.

: Start playback. (Slide show: each file is

shown for a few seconds.) Shows the current file until you change it if pressed during Slide show.

: Select track.

: Stop playback.

: Start playback/pause (if

pressed during playback).

: Reverse/forward search*2.

: Press: Select track.

Hold: Reverse/forward search*4.

ENGLISH

: Select folder.

: Select aspect ratio.

= = :

Select track (within the same folder).

(twice) = = :

Select folder.

: Stop playback.

: Start playback/pause (if pressed during

playback).

: Reverse/forward search*2.

(Forward slow motion*3 during pause. No

sound can be heard.)

• Reverse slow motion does not work.

: Press: Select track.

Hold: Reverse/forward search*4 (No

sound can be heard.) : Select aspect ratio. : Select audio channel (ST: stereo, L: left, R:

Right).

: Stop playback.

: Start playback/pause (if pressed during playback).

: Reverse/forward search*2.

: Press: Select track.

Hold: Reverse/forward search*

= = :

Select track.

: Select folder.

= = :

Select track (within the same folder).

(twice) = = :

Select folder.

= = :

Select track.

During PBC playback...

= = :

Select an item on the menu. To return to the previous menu, press

To cancel PBC playback

2 Start the desired track.

= =

• To resume PBC, press / .

*1 Erases the misentry of the number. *2 Search speed: x2 ] x5 ] x10 ] x20 ] x60 *3 Slow motion speed: 1/32 ] 1/16 ] 1/8 ]

1/4 ] 1/2

*4 Search speed: x2 ] x10 *5 Search speed: ¡1 ] ¡2 ] ¡3 *6 Search speed: ¡1 ] ¡2

OPERATIONS

Playing back a bonus group

If a DVD Audio including a “bonus group” is detected, the BONUS indicator lights up on the source information screen.

ENGLISH

To play a bonus group...

1 Select the bonus group.

• The bonus group is usually recorded as the last

group.

2 Enter the key number.

: Move the entry position

: Select a number

• “key number” (a kind of password) for the bonus

group is not open to public. The way of getting the key number depends on the disc.

3 Follow the interactive instructions shown on

the monitor.

Using the list screens

You can use Original Program and Play List screen anytime while playing DVD-VR with its data recorded.

1 Display the Original Program/Play List

screen.

2 Select an item you want.

Selecting browsable still picture

When a disc including browsable still pictures is detected, the B.S.P indicator lights up on the source information screen.

When disc shows the BSP selecting icons such as @ or # on the screen...

1 Select an item you want to display.

To erase the screen

1 Program/Play list number 2 Recording date 3 Recording source (TV station, the input terminal of

the recording equipment, etc.)

4 Start time of recording 5 Title of the program/play list* 6 Highlight bar (current selection) 7 Creating date of play lists 8 Total number of chapters included in the playlist 9 Playback time

* The title of the original program or play list may not be

displayed depending on the recording equipment.

Enjoying surround sounds

You can enjoy multi-channel surround playback through the front, center, surround speakers.

• After connecting the center speaker, make

sure to activate the center speaker; otherwise, no sound comes out of the center speaker (☞

page 61).

• Surround mode can also be used for “USB” and “SD.”

ENGLISH

MULTI: For multi-channel encoded sources such as

Dolby Digital* activated, “MULTI” is shown on the source information screen.)

Dolby Pro Logic II (Movie/Music): For 2 channel

sources except for DivX/MPEG1/MPEG2 discs.

To turn on the surround...

, DTS*2, and DVD Audio. (When

• Off: Deactivates surround.

• On: Activates surround = go to the following steps.

• Auto: When multi-channel digital signals come in, “MULTI” surround is activated.

When 2-channel or 2.1-channel signals come in,

“4CH STEREO” is activated.

• Through: All incoming channel signals are sent to the corresponding speakers.

• Dolby PL II Movie: Activates Dolby Pro Logic Movie.

• Dolby PL II Music: Activates Dolby Pro Logic

II Music. You can adjust <Panorama> and

<Center Width> setting (☞below).

Only when selecting <Dolby PL II Music>

After step 4 above...

1 Activate <Panorama>.

• Panorama: Select <On> to add wraparound sound effect.

Continued on the next page

OPERATIONS

2 Adjust <Center Width>.

ENGLISH

Operations using the on-screen bar

These operations are possible on the monitor using the remote controller, while playing the following discs—DVD/VCD/DivX/MPEG1/MPEG2/JPEG.

1 Display the on-screen bar. (☞page 29)

• Center Width: Adjust the center image so it may be heard only from the center speaker, only form the left/right front speaker as a “phantom” center image, or various combination of these speakers. As the number increases, the “phantom” effect becomes stronger (normally select <04>).

On the remote controller:

• You cannot change the <Dolby PL II Music> settings using the remote controller.

*1 Manufactured under license from Dolby Laboratories.

Dolby, Pro Logic, and the double-D symbol are trademarks of Dolby Laboratories.

*2 “DTS” and “DTS Digital Surround” are registered

trademarks of DTS, Inc.

2 Select an item.

3 Make a selection.

If a pop-up menu appears...

• For entering time/numbers...

To remove the on-screen bar

: Move the entry position

: Select a number

On-screen bar

Information

Operation

Above example is of DVD Video. Items shown on the bar vary due to the disc type.

ENGLISH

1 Disc type 2 • DVD: Audio signal format

• VCD: PBC

3 Playback mode *

DVD Video: T. RPT: Title repeat C. RPT: Chapter repeat DVD Audio: T. RPT: Track repeat DVD-VR: C. RPT: Chapter repeat PG. RPT: Program repeat DivX/MPEG1/MPEG2: T. RPT: Track repeat F. RPT: Folder repeat JPEG: F. RPT: Folder repeat VCD: T. RPT: Track repeat A. RND: All (Disc) random T. INT: Track intro 4 Playback information Current title/chapter Current group/track

Current program/chapter

Current playlist/chapter Current track Current folder/track Current folder/file

☞ page 21

* *2 Not applicable for DVD-VR

5 Time indication

Elapsed playing time of the disc Remaining title time (for DVD)

Remaining disc time (for others)

Elapsed playing time of the current

chapter/track *

Remaining time of the current

chapter/track *

6 Playback status

Play

Reverse/forward search

Reverse/forward slow-motion Pause Stop

7 Operation icons

Change time indication (see 5)

Time Search (Specify a certain scene

by entering time.) Title Search (by its number) Chapter Search (by its number)

Group Search (by its number)

Track Search (by its number) Repeat play * Intro play * Random play *

Change the audio language, audio

stream, or audio channel Change or erase the subtitle language Change the view angle

Change the browsable still pictures

(pages). The numbers in the indicator

shows the current page/total page

number

OPERATIONS

Dual Zone operations

You can enjoy a disc playback on the external monitor connected to the VIDEO OUT and 2nd AUDIO OUT plugs, while listening to any other source than “SD” and “USB”

ENGLISH

through the speakers.

• When Dual Zone is in use, you can only operate the DVD/CD player using the remote controller.

When the main source is “SD” or “USB,” “DISC” and “DISC SURROUND” cannot be displayed.

• OFF: Deactivates Dual Zone.

• DISC: Activates Dual Zone without applying Headphone Surround*.

• DISC SURROUND: Activates Dual Zone and applies Headphone Surround*.

To select a different source (main source) to listen through the speakers:

Press SOURCE on the monitor panel.

• You cannot select “SD” and “USB” for the main source.

• By using the buttons on the monitor panel, you can operate the newly selected main source without affecting Dual Zone (DISC) operations.

On the remote controller:

• When the main source is “SD” or “USB,” the DUAL button does not work.

2 Adjust the volume through the 2nd AUDIO

OUT plug.

Operate the DVD/CD player.

* JVC original headphone virtual surround system. This

surround will also work for the main source “DISC” if “DISC SURROUND” is selected as the sub-source. This surround does not work for DivX/MPEG1/MPEG2 discs.

Ex. When [DISC SURROUND] is selected.

+ 293 hidden pages

JVC KW-AVX800 User Manual [en, de, fr]

KW-AVX800

ENGLISH

Contents

Playable disc type

Basic operations — Monitor panel/touch panel

Basic operations — Remote controller (RM-RK251)

Before operating the unit

Common operations

Listening to the radio

Disc operations

Dual Zone operations
