PARTS LIST
[ KD-G414 ] [ KD-G413 ]
* All printed circuit boards and its assemblies are not available as service parts.
Area suffix
UI ---------------------------- India
MA178
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
CD mechanism assembly and parts list (Block No.MB)
Electrical parts list (Block No.01~02)(KD-G414,KD-G413_UI2)
Electrical parts list (Block No.03~04)(KD-G414,KD-G413_UI3)
Packing materials and accessories parts list (Block No.M3)
3-2
3-5
3-7
3-10
3-16
3-1
Exploded view of general assembly and parts list
Block No.
5
8
1
5
C
M
M
1
M
A
27
29
B
4
Switch
board
28
2
51
33
9
18
16
15
14
13
33
32
3
4
4
25
23
20
3-2
30
31
19
21
26
22
24
34
17
6
43
48
C
42
50
49
B
Main board
47
6
44
46
6
45
A
7
12
7
13
14
34
10
40
9
37
11
36
41
35
39
38
52
3-3
General Assembly
Symbol No. Part No. Part Name Description Local
1 GE10104-001A TOP CHASSIS
2 GE40135-001A EARTH PLATE
3 GE30938-003A SIDE PANEL
4 QYSDST2604ZA TAP SCREW M2.6 x 4mm(x3)
5 GE40235-001A SCREW (x2)
6 QYSDST2604ZA TAP SCREW M2.6 x 4mm(x3)
7 GE40235-004A SCREW (x2)
8 QYSDST2610ZA TAP SCREW M2.6 x 10mm
9 QYSDST2004ZA TAP SCREW M2 x 4mm(x2)
10 GE10103-001A FRONT CHASSIS
11 GE31569-002A LOCK LEVER
12 GE40269-001A TORSION SPRING
13 GE31568-001A RLS KNOB
14 GE40202-011A COMP.SPRING
15 GE40250-001A PANEL STOPPER
16 GE40202-009A COMP.SPRING
17 GE40257-001A BLIND
18 FSYH4036-098 SHEET
19 GE20172-017A FRONT PANEL ASSY G413UI2,G413UI3
19 GE20172-016A FRONT PANEL ASSY G414UI2,G414UI3
20 GE31561-008A POWER/SEL BTN G413UI2,G413UI3
20 GE31561-007A POWER/SEL BTN G414UI2,G414UI3
21 GE31572-015A EQ BUTTON G413UI2,G413UI3
21 GE31572-013A EQ BUTTON G414UI2,G414UI3
22 GE31562-001A MODE BUTTON
23 GE31563-001A DISP BUTTON
24 GE31564-001A EJECT BUTTON
25 GE31560-008A VOL BUTTON G413UI2,G413UI3
25 GE31560-007A VOL BUTTON G414UI2,G414UI3
26 GE31559-008A SEARCH BUTTON G413UI2,G413UI3
26 GE31559-007A SEARCH BUTTON G414UI2,G414UI3
27 GE31555-005A PRESET BTN (L) G413UI2,G413UI3
27 GE31555-001A PRESET BTN (L) G414UI2,G414UI3
28 GE31556-005A PRESET BTN (R) G413UI2,G413UI3
28 GE31556-001A PRESET BTN (R) G414UI2,G414UI3
29 GE31557-007A D.FUNC BUTTON
30 GE31558-005A DETACH BUTTON G413UI2,G413UI3
30 GE31558-003A DETACH BUTTON G414UI2,G414UI3
31 GE40202-010A COMP.SPRING
32 GE10102-001A REAR COVER
33 VKZ4777-010 MINI SCREW (x5)
34 GE31565-001A LCD CASE
35 GE31566-001A LENS CASE
36 GE31567-001A LCD LENS
37 GE40248-001A LIGHTING SHEET
38 GE31570-001A BOTTOM COVER
39 FSMA3004-203 INSULATOR
40 QLD0355-001 LCD MODULE
41 QNZ0442-001 LCD CONNECTOR
42 QMFZ047-150-T FUSE 15A
43 GE31571-005A REAR BRACKET
44 QYSDST2606ZA TAP SCREW M2.6 x 6mm
45 QYSDST2606ZA TAP SCREW M2.6 x 6mm
46 QYSDSF2606ZA TAP SCREW M2.6 x 6mm
47 QYSDSF2606ZA TAP SCREW M2.6 x 6mm(x2)
48 GE40172-004A IC BRACKET
49 GE40103-003A REG BRACKET
50 GE40107-002A HEAT SINK
51 GE30854-001A LED HOLDER
52 GE31702-002A NAME PLATE G413UI2
52 GE31702-003A NAME PLATE G413UI3
52 GE31699-002A NAME PLATE G414UI2
52 GE31699-003A NAME PLATE G414UI3
Block No. [M][1][M][M]
3-4
CD mechanism assembly and parts list
Grease
TNG-87
GP-501MK
CFD-005Z
GP-305T
72
26
74
35
TN-2001-1011
34
33
111
Block No.
M
2
M
B
M
C
101
93
112
24
76
94
31
22
122
61
36
29
100
116
111
25
73
85
15
111
37
A
19
B
21
62
D
75
38
95
14
100
112
96
97
123
11
32
a
114
D
90
89
113
38
30
A
C
B
92
18
82
115
87
88
20
13
23
125
32
99
12
121
16
17
124
86
27
28
83
98
83
4
84
73
74
94
81
75
77
a
111
91
111
93
71
3
111
3
1
The parts without symbol number are not service.
3-5
CD mechanism
Symbol No. Part No. Part Name Description Local
1 30320101T FRAME
2 30320102T TOP COVER
3 30320115T DANPER F
4 30320116T DANPER R
11 303205505T CHASSIS RIVET
12 303205503T CHANGE P. RVT A
13 303205301T CLAMPER ASS'Y
14 303205302T SPINDLE MOTOR A
15 30320502T CLAMPER ARM
16 30320503T CHANGE GEAR SPG
17 30320505T CHANGE GEAR 2
18 30320506T FEED GEAR
19 30320507T FEED RACK
20 30320509T CHANGE LOCK RAR
21 30320510T FEED SW HOLDER
22 30320511T PU SHAFT HOLDER
23 30320513T CLAMPER SUB SPG
24 30320514T FD SUB HOLDER
25 30320518T TOP PLATE
26 30320519T SELECT LOCK ARM
27 30320520T TRIGGER ARM
28 30320521T SLIDE HOOK
29 30320522T PU SHAFT
30 30320525T CLAMPER ARM SPG
31 30320526T SELECT L ARM SP
32 30320538T SUSPENSION SP R
33 30320529T SELECT ARM R
34 30320530T LINK PLATE
35 30320531T LINK PLATE SPG
36 30320523T CUSHION F
37 30320524T CUSHION R
38 30320539T SUSPENSION SP L
61 69011614T PICKUP OPT-725
62 64180406T DET SW ESE22
71 303210301T CONN PWB ASS'Y
72 30321002T MODE SW
73 30321003T LOAD MOTOR WIRE
74 30321005T MODE SW WIRE
75 30321009T SL WIRE
76 30321011T WIRE HOLDER
77 19501403T WIRE CLUMPER
81 303211301T ROLLER SHAFT AS
82 303211501T L GEAR PLATE RV
83 303211302T LOADING PLATE A
84 303211502T LOCK ARM RV ASS
85 303211303T L/F MOTOR ASS'Y
86 30321101T LOADING GEAR 1
87 30321102T LOADING GEAR 2
88 30321103T LOADING GEAR 3
89 30321104T LOADING GEAR 4
90 30321105T LOADING GEAR 5
91 30321106T LOADING GEAR 6
92 30321107T LOADING GEAR 7
93 30321149T ROLLER GUIDE
94 30321114T ROLLER GUIDE SP
95 30321116T DISC STOPPER AR
96 30321117T DISC ST ARM SPG
97 30321118T LD GEAR BRACKET
98 30321125T L SIDE PLATE
99 30321131T LOAD PLATE SPG
100 30321133T LDG ROLLER
101 18211223T COLLAR SCREW
111 9P0420031T SCREW
112 9P0420041T TAP.SCREW
113 9B0320041T SCREW
114 9C0117183T SCREW
115 9C0120203T SCREW
116 9C0317503T SCREW
121 9W0130170T PW 3.5X8X0.3
122 9W0513060T HL WASHER
123 9W0710070T L WASHER
124 9E0100152T E RING
125 9W0113020T PW 2.1X4X0.13
Block No. [M][B][M][M]
3-6
Electrical parts list
Main board (UI2)
Block No. [0][1]
Symbol No.
IC161 TEA6320T-X IC
IC301 LA47516 POWER IC
IC501 AN41012A-W IC
IC521 MN6627945ECUC IC
IC523 SN74LVC07ANS-X LOGIC IC
IC581 NJM4565M-WE IC
IC701 LC723784-9C90 IC
IC901 AN80T71 REGULATOR IC
IC981 NJU7772F15-X IC
Q1 UN2211-X TRANSISTOR
Q2 UN2211-X TRANSISTOR
Q4 UN2211-X TRANSISTOR
Q5 2SB1197K/QR/-X TRANSISTOR
Q6 2SB709A/QR/-X TRANSISTOR
Q31 2SD601A/QR/-X TRANSISTOR
Q32 2SD601A/QR/-X TRANSISTOR
Q301 2SD601A/QR/-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q501 2SB1322/RS/-T TRANSISTOR
Q521 2SB709A/QR/-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2111-X TRANSISTOR
Q902 2SD601A/QR/-X TRANSISTOR
Q903 2SB709A/QR/-X TRANSISTOR
D1 MA 111- X S I D IO DE
D2 MA 111- X S I D IO DE
D3 MA 111- X S I D IO DE
D4 MA 111- X S I D IO DE
D6 MA 111- X S I D IO DE
D301 UDZS3.3B-X Z DIODE
D341 MA111-X SI DIODE
D351 MA111-X SI DIODE
D501 1A3G-T1 SI DIODE
D703 MA111-X SI DIODE
D706 MA111-X SI DIODE
D711 MA8062/M/-X Z DIODE
D712 MA8062/M/-X Z DIODE
D713 MA8062/M/-X Z DIODE
D714 MA8062/M/-X Z DIODE
D715 MA8062/M/-X Z DIODE
D716 MA8062/M/-X Z DIODE
D717 MA8062/M/-X Z DIODE
D718 MA8062/M/-X Z DIODE
D719 MA8062/M/-X Z DIODE
D720 MA8062/M/-X Z DIODE
D721 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 MA8110/M/-X Z DIODE
D901 1N5401-F64 DIODE
D903 MA111-X SI DIODE
D904 RB160M-30-X SB DIODE
D905 RB160M-30-X SB DIODE
D906 RB160M-30-X SB DIODE
D907 RB160M-30-X SB DIODE
C1 NDC31HJ-221X C CAPACITOR 220pF 50V J
C2 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C3 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C4 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C6 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C7 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C8 NDC31HJ-121X C CAPACITOR 120pF 50V J
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C10 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C11 NCB31HK-331X C CAPACITOR 330pF 50V K
C31 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C32 NCB31HK-102X C CAPACITOR 1000pF 50V K
C33 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C81 NCB31EK-153X C CAPACITOR 0.015uF 25V K
Part No. Part Name Description Local
Symbol No.
C82 NCB31HK-562X C CAPACITOR 5600pF 50V K
C83 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C91 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C92 NCB31HK-562X C CAPACITOR 5600pF 50V K
C93 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C96 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C99 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C161 NCB31HK-822X C CAPACITOR 8200pF 50V K
C162 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C163 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C164 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C165 NCB31HK-562X C CAPACITOR 5600pF 50V K
C166 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C167 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C168 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C169 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C171 NCB31HK-822X C CAPACITOR 8200pF 50V K
C172 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C173 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C174 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C175 NCB31HK-562X C CAPACITOR 5600pF 50V K
C176 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C177 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C178 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C179 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C181 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C182 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C183 QTE1H54-225Z E CAPACITOR 2.2uF 50V
C184 QTE1H54-225Z E CAPACITOR 2.2uF 50V
C191 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C192 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C193 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C194 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C195 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C301 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C302 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C303 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C304 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C305 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C306 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C307 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C308 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C309 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C310 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C311 QERF1CM-226Z E CAPACITOR 22uF 16V M
C312 NDC31HJ-101X C CAPACITOR 100pF 50V J
C313 NDC31HJ-101X C CAPACITOR 100pF 50V J
C314 NDC31HJ-101X C CAPACITOR 100pF 50V J
C315 NDC31HJ-101X C CAPACITOR 100pF 50V J
C317 QERF1HM-105Z E CAPACITOR 1uF 50V M
C318 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C319 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C341 NDC31HJ-101X C CAPACITOR 100pF 50V J
C351 NDC31HJ-101X C CAPACITOR 100pF 50V J
C501 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C502 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C503 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C504 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C505 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C506 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C511 NCB31HK-222X C CAPACITOR 2200pF 50V K
C513 NCB31HK-682X C CAPACITOR 6800pF 50V K
C515 NCB31HK-122X C CAPACITOR 1200pF 50V K
C517 NCB31HK-182X C CAPACITOR 1800pF 50V K
C518 NDC31HJ-680X C CAPACITOR 68pF 50V J
C521 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C522 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C523 NDC31HJ-101X C CAPACITOR 100pF 50V J
C524 NDC31HJ-561X C CAPACITOR 560pF 50V J
C525 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C526 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C527 NCB31EK-332X C CAPACITOR 3300pF 25V K
C528 NDC31HJ-331X C CAPACITOR 330pF 50V J
C531 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C532 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C533 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
Part No. Part Name Description Local
3-7
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C534 NCB31EK-332X C CAPACITOR 3300pF 25V K
C535 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C536 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C537 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C538 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C539 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C540 NCS31HJ-681X C CAPACITOR 680pF 50V J
C541 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C542 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C543 NCB31HK-102X C CAPACITOR 1000pF 50V K
C544 NCB31EK-823X C CAPACITOR 0.082uF 25V K
C545 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C546 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C547 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C548 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C549 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C550 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C551 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C552 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C553 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C554 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C571 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C572 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C573 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C574 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C583 NDC31HJ-821X C CAPACITOR 820pF 50V J
C584 NDC31HJ-821X C CAPACITOR 820pF 50V J
C585 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C586 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C587 NDC31HJ-101X C CAPACITOR 100pF 50V J
C588 NDC31HJ-101X C CAPACITOR 100pF 50V J
C589 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C590 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C591 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C592 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C701 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C702 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C703 NDC31HJ-220X C CAPACITOR 22pF 50V J
C704 NDC31HJ-270X C CAPACITOR 27pF 50V J
C705 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C706 NDC31HJ-221X C CAPACITOR 220pF 50V J
C711 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C712 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C713 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C715 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C716 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C781 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C782 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C783 NCB31EK-823X C CAPACITOR 0.082uF 25V K
C801 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C901 QEZ0676-338 E CAPACITOR 3300uF
C902 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C903 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C904 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C905 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C906 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C907 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C908 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C909 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C910 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C911 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C913 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C914 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C915 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C916 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C919 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C971 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C972 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C983 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C984 NCB31EK-104X C CAPACITOR 0.1uF 25V K
R1 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R2 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R3 NRS181J-100X MG RESISTOR 10
R4 NRSA63J-103X MG RESISTOR 10k
R5 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R6 NRSA63J-822X MG RESISTOR 8.2k
R9 NRSA02J-220X MG RESISTOR 22
Ω
1/8W J
Ω
1/16W J
Ω
1/16W J
Ω
1/10W J
R10 NRSA02J-220X MG RESISTOR 22Ω 1/10W J
R11 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R12 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R13 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R14 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R16 NRSA63J-104X MG RESISTOR 100k
R31 NRSA63J-102X MG RESISTOR 1k
R32 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R33 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R34 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R35 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R36 NRS181J-471X MG RESISTOR 470Ω 1/8W J
R37 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R81 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R82 NRSA63J-912X MG RESISTOR 9.1kΩ 1/16W J
R91 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R92 NRSA63J-912X MG RESISTOR 9.1kΩ 1/16W J
R162 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R163 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R164 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R165 NRSA63J-473X MG RESISTOR 47k
R166 NRSA63J-273X MG RESISTOR 27k
R167 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R172 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R173 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R174 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R175 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R176 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R177 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R191 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R301 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R302 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R303 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R304 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R341 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R342 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R345 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R351 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R352 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R355 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R501 NRSA02J-822X MG RESISTOR 8.2kΩ 1/10W J
R502 NRSA02J-562X MG RESISTOR 5.6kΩ 1/10W J
R503 NRSA02J-332X MG RESISTOR 3.3kΩ 1/10W J
R504 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R505 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R506 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R507 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R508 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R509 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R510 NRSA63J-273X MG RESISTOR 27k
R511 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R512 NRSA63J-562X MG RESISTOR 5.6k
R513 NRSA63J-103X MG RESISTOR 10k
R514 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R515 NRSA63J-153X MG RESISTOR 15k
R516 NRSA63J-102X MG RESISTOR 1k
R517 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R518 NRSA63J-562X MG RESISTOR 5.6k
R519 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R521 NRSA63J-105X MG RESISTOR 1M
R522 NRSA63J-221X MG RESISTOR 220
R523 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R524 NRSA63J-222X MG RESISTOR 2.2k
R525 NRSA63J-102X MG RESISTOR 1k
R526 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R527 NRSA63J-222X MG RESISTOR 2.2k
R528 NRSA63J-222X MG RESISTOR 2.2k
R529 NRSA63J-222X MG RESISTOR 2.2k
R530 NRSA63J-472X MG RESISTOR 4.7k
R531 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R532 NRSA63J-472X MG RESISTOR 4.7k
R533 NRSA63J-273X MG RESISTOR 27k
R534 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R535 NRSA63J-103X MG RESISTOR 10k
R537 NRSA63J-155X MG RESISTOR 1.5M
R538 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R539 NRS181J-0R0X MG RESISTOR 0
R540 NRSA63J-333X MG RESISTOR 33k
Ω
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
Ω
Ω
Ω
Ω
Ω
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/8W J
Ω
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
3-8
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R541 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R542 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R543 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R544 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R545 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R547 NRSA63J-0R0X MG RESISTOR 0
R548 NRSA63J-332X MG RESISTOR 3.3k
R550 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R551 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R553 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R554 NRSA63J-4R7X MG RESISTOR 4.7Ω 1/16W J
R555 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R556 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R557 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R558 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R559 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R560 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R561 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R562 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R565 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R566 NRSA02J-100X MG RESISTOR 10
R581 NRSA63J-0R0X MG RESISTOR 0
R582 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R583 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R584 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R585 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R586 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R587 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J
R588 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J
R589 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R590 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R591 NRS181J-223X MG RESISTOR 22kΩ 1/8W J
R592 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R593 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R594 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R701 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R703 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R704 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R705 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R706 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R707 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R708 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R709 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R710 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R711 NRS181J-103X MG RESISTOR 10kΩ 1/8W J
R712 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R713 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R715 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R716 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R717 NRSA63J-473X MG RESISTOR 47k
R718 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R719 NRSA63J-0R0X MG RESISTOR 0
R727 NRSA63J-472X MG RESISTOR 4.7k
R728 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R729 NRSA63J-473X MG RESISTOR 47k
R730 NRSA63J-103X MG RESISTOR 10k
R731 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R732 NRSA63J-102X MG RESISTOR 1k
R733 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R735 NRSA63J-472X MG RESISTOR 4.7k
R736 NRSA63J-103X MG RESISTOR 10k
R737 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R738 NRSA63J-472X MG RESISTOR 4.7k
R739 NRSA63J-103X MG RESISTOR 10k
R740 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R741 NRSA63J-473X MG RESISTOR 47k
R742 NRSA63J-512X MG RESISTOR 5.1k
R743 NRSA63J-473X MG RESISTOR 47k
R745 NRSA63J-473X MG RESISTOR 47k
R749 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R751 NRSA63J-103X MG RESISTOR 10k
R752 NRSA63J-103X MG RESISTOR 10k
R753 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R754 NRSA63J-103X MG RESISTOR 10k
R755 NRSA63J-473X MG RESISTOR 47k
R756 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R804 NRSA63J-334X MG RESISTOR 330k
R811 NRSA63J-4R7X MG RESISTOR 4.7
Ω
1/16W J
Ω
1/16W J
Ω
1/10W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
1/16W J
R901 NRSA63J-912X MG RESISTOR 9.1kΩ 1/16W J
R902 QRE142J-102X C RESISTOR 1kΩ 1/4W J
R903 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R905 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R906 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R907 NRSA63J-123X MG RESISTOR 12k
R908 NRSA63J-273X MG RESISTOR 27k
R909 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R910 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R911 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
R912 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
R918 NRSA02J-103X MG RESISTOR 10kΩ 1/10W J
R971 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R972 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
L1 QQL244J-4R7Z COIL 4.7uH J
L571 QQL244K-4R7Z COIL 4.7uH K
L701 QQL244K-4R7Z COIL 4.7uH K
L901 QQR0703-001 CHOKE COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0190-001 CAR ANT JACK
J321 QNN0519-001 PIN JACK
TU1 QAU0394-001 TUNER PACK
X521 QAX0714-001Z C RESONATOR 16.000MHz
X701 QAX0406-001Z CRYSTAL 4.500MHz
Ω
1/16W J
Ω
1/16W J
Switch board (UI2)
Block No. [0][2]
Symbol No.
IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER
Q671 2SB624/4/-X TRANSISTOR
Q672 UN2211-X TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310LT/MN/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310LT/MN/-X LED
D618 SML-310LT/MN/-X LED
D631 NSPW310BS/BRS/ LED
D632 NSPW310BS/BRS/ LED
D641 MA8051/M/-X Z DIODE
D643 MA111-X SI DIODE
D644 MA8062/M/-X Z DIODE
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
R602 NRSA63J-821X MG RESISTOR 820
R603 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
R605 NRSA63J-821X MG RESISTOR 820
Part No. Part Name Description Local
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
3-9
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R606 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R607 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R608 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R609 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R610 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R611 NRSA63J-821X MG RESISTOR 820
R612 NRSA63J-821X MG RESISTOR 820
R613 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R614 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R615 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R627 NRSA02J-391X MG RESISTOR 390Ω 1/10W J
R628 NRSA02J-391X MG RESISTOR 390Ω 1/10W J
R629 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R630 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R632 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R634 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R636 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R638 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R640 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R642 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R644 NRSA63J-331X MG RESISTOR 330
R651 NRSA63J-222X MG RESISTOR 2.2k
R652 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R653 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R654 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R655 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R656 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R657 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R658 NRSA63J-184X MG RESISTOR 180kΩ 1/16W J
R661 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R662 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R671 NRSA02J-471X MG RESISTOR 470Ω 1/10W J
R672 NRSA02J-473X MG RESISTOR 47kΩ 1/10W J
R673 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Main board (UI3)
Block No. [0][3]
Symbol No.
IC31 TB2118F-X PLL IC
IC161 TEA6320T-X IC
IC301 LA47516 POWER IC
IC401 TC94A34FG-002 IC
IC461 NJU7772F15-X IC
IC481 AK4385ET-X IC
IC501 LA6242H-X IC
IC521 TA2157FN-X RF AMP IC
IC541 TC94A14FA CD LSI IC
IC581 NJM4565M-WE IC
IC701 UPD784217AGC302 IC
IC702 IC-PST3433U-X IC
IC901 AN80T07A REGULATOR IC
Part No. Part Name Description Local
Q1 2SD601A/QR/-X TRANSISTOR
Q5 2SB709A/R/-X TRANSISTOR
Q6 2SB624/4/-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q10 UN2211-X TRANSISTOR
Q31 UN2211-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q401 2SB624/4/-X TRANSISTOR
Q402 UN2211-X TRANSISTOR
Q430 2SD601A/QR/-X TRANSISTOR
Q440 UN2211-X TRANSISTOR
Q501 2SB1322/RS/-T TRANSISTOR
Q502 2SB1132/QR/-W TRANSISTOR
Q521 2SB1241/QR/-T TRANSISTOR
Q541 UN2111-X TRANSISTOR
Q542 UN2211-X TRANSISTOR
Q543 UN2111-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2211-X TRANSISTOR
Q784 UN2111-X TRANSISTOR
Q976 UN2211-X TRANSISTOR
Q977 2SB709A/QR/-X TRANSISTOR
D1 MA 111- X S I D IO DE
D2 MA 111- X S I D IO DE
D4 MA 111- X S I D IO DE
D5 MA 111- X S I D IO DE
D5 1 MA111-X SI DIODE
D341 MA111-X SI DIODE
D351 MA111-X SI DIODE
D481 MA8051/M/-X Z DIODE
D701 MA8062/M/-X Z DIODE
D702 MA8062/M/-X Z DIODE
D703 MA8062/M/-X Z DIODE
D704 MA8062/M/-X Z DIODE
D705 MA8062/M/-X Z DIODE
D706 MA8062/M/-X Z DIODE
D707 MA8062/M/-X Z DIODE
D708 MA8062/M/-X Z DIODE
D709 MA8062/M/-X Z DIODE
D710 MA111-X SI DIODE
D712 MA8062/M/-X Z DIODE
D713 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 MA111-X SI DIODE
D784 MA8110/M/-X Z DIODE
D851 RB160M-30-X SB DIODE
D852 RB160M-30-X SB DIODE
D901 1N5401-F64 DIODE
D902 MA111-X SI DIODE
D971 RB160M-30-X SB DIODE
D972 RB160M-30-X SB DIODE
C1 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C2 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C3 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C4 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C5 QERF1HM-104Z E CAPACITOR 0.1uF 50V M
C6 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C31 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C32 NDC31HJ-470X C CAPACITOR 47pF 50V J
C33 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C34 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C35 NDC31HJ-100X C CAPACITOR 10pF 50V J
C36 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C37 NDC31HJ-100X C CAPACITOR 10pF 50V J
C38 NCB31HK-102X C CAPACITOR 1000pF 50V K
C39 NCB31HK-102X C CAPACITOR 1000pF 50V K
C40 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C41 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C42 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C43 QFV61HJ-473Z MF CAPACITOR 0.047uF 50V J
C44 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C45 NCB31HK-272X C CAPACITOR 2700pF 50V K
C46 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C47 NCB31HK-103X C CAPACITOR 0.01uF 50V K
3-10
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C48 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C49 NCB31HK-102X C CAPACITOR 1000pF 50V K
C50 NDC31HJ-101X C CAPACITOR 100pF 50V J
C51 NDC31HJ-331X C CAPACITOR 330pF 50V J
C81 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C82 NCB31HK-332X C CAPACITOR 3300pF 50V K
C84 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C91 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C92 NCB31HK-332X C CAPACITOR 3300pF 50V K
C94 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C95 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C161 QTE1H54-225Z E CAPACITOR 2.2uF 50V
C162 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C164 NCB31HK-822X C CAPACITOR 8200pF 50V K
C165 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C166 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C167 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C168 NCB31HK-562X C CAPACITOR 5600pF 50V K
C169 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C170 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C171 QTE1H54-225Z E CAPACITOR 2.2uF 50V
C172 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C174 NCB31HK-822X C CAPACITOR 8200pF 50V K
C175 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C176 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C177 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C178 NCB31HK-562X C CAPACITOR 5600pF 50V K
C179 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C180 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C191 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C192 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C193 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C194 NCB31EK-823X C CAPACITOR 0.082uF 25V K
C301 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C302 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C303 NDC31HJ-101X C CAPACITOR 100pF 50V J
C304 NDC31HJ-101X C CAPACITOR 100pF 50V J
C307 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C308 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C311 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C312 QFV91HJ-474Z MF CAPACITOR 0.47uF 50V J
C313 NDC31HJ-101X C CAPACITOR 100pF 50V J
C314 NDC31HJ-101X C CAPACITOR 100pF 50V J
C315 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C316 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C317 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C318 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C319 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C320 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C322 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C323 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C324 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C325 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C341 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C355 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C357 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C403 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C404 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C405 QERF1HM-105Z E CAPACITOR 1uF 50V M
C406 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C407 QERF1AM-107Z E CAPACITOR 100uF 10V M
C408 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C411 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C412 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C413 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C414 NCB31HK-222X C CAPACITOR 2200pF 50V K
C415 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C416 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C418 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C419 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C420 NDC31HJ-8R0X C CAPACITOR 8pF 50V J
C421 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C422 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C430 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C431 NDC31HJ-101X C CAPACITOR 100pF 50V J
C440 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C461 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C462 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C463 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C464 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C481 QERF1CM-476Z E CAPACITOR 47uF 16V M
C482 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C483 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C501 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C502 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C503 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C504 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C505 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C506 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C507 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C510 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C512 QERF1CM-476Z E CAPACITOR 47uF 16V M
C513 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C514 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C521 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C522 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C523 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C524 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C525 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C527 NCB31HK-682X C CAPACITOR 6800pF 50V K
C528 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C529 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C530 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C531 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C532 NDC31HJ-680X C CAPACITOR 68pF 50V J
C533 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C534 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C541 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C542 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C543 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C544 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C545 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C546 NDC31HJ-470X C CAPACITOR 47pF 50V J
C547 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C548 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C549 NCB31HK-272X C CAPACITOR 2700pF 50V K
C550 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C551 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C552 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C553 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C554 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C555 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C556 NCB31HK-471X C CAPACITOR 470pF 50V K
C557 NCB31HK-471X C CAPACITOR 470pF 50V K
C558 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C559 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C560 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C561 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C562 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C565 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C566 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C568 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C570 QERF1AM-476Z E CAPACITOR 47uF 10V M
C571 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C572 QERF1AM-107Z E CAPACITOR 100uF 10V M
C580 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C581 NCB31HK-332X C CAPACITOR 3300pF 50V K
C582 NDC31HJ-271X C CAPACITOR 270pF 50V J
C583 NDC31HJ-271X C CAPACITOR 270pF 50V J
C584 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C585 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C589 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C590 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C591 NCB31HK-332X C CAPACITOR 3300pF 50V K
C592 NDC31HJ-271X C CAPACITOR 270pF 50V J
C593 NDC31HJ-271X C CAPACITOR 270pF 50V J
C594 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C595 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C596 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C597 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C599 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C701 NDC31HJ-220X C CAPACITOR 22pF 50V J
C702 NDC31HJ-270X C CAPACITOR 27pF 50V J
C703 NDC31HJ-270X C CAPACITOR 27pF 50V J
C704 NDC31HJ-8R0X C CAPACITOR 8pF 50V J
C705 NCB31EK-473X C CAPACITOR 0.047uF 25V K
3-11
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C706 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C707 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C708 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C709 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C710 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C711 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C712 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C713 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C716 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C717 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C718 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C770 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C771 NDC31HJ-101X C CAPACITOR 100pF 50V J
C772 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C781 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C783 NCB31EK-823X C CAPACITOR 0.082uF 25V K
C784 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C801 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C851 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C852 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C901 QEZ0676-338 E CAPACITOR 3300uF
C902 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C903 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C904 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C905 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C906 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C907 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C908 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C909 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C910 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C911 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C912 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C913 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C914 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C915 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C919 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C961 NDC31HJ-101X C CAPACITOR 100pF 50V J
C962 NDC31HJ-101X C CAPACITOR 100pF 50V J
C963 NDC31HJ-101X C CAPACITOR 100pF 50V J
C964 NDC31HJ-101X C CAPACITOR 100pF 50V J
C965 NDC31HJ-101X C CAPACITOR 100pF 50V J
C966 NDC31HJ-101X C CAPACITOR 100pF 50V J
C967 NDC31HJ-101X C CAPACITOR 100pF 50V J
C968 NDC31HJ-101X C CAPACITOR 100pF 50V J
C971 NCB31EK-104X C CAPACITOR 0.1uF 25V K
R1 NRS181J-120X MG RESISTOR 12Ω 1/8W J
R2 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R4 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R5 NRSA63J-473X MG RESISTOR 47k
R6 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R7 NRSA63J-472X MG RESISTOR 4.7k
R9 NRSA63J-470X MG RESISTOR 47
R10 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R31 NRS181J-100X MG RESISTOR 10
R32 NRSA63J-622X MG RESISTOR 6.2k
R33 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R34 NRSA63J-222X MG RESISTOR 2.2k
R35 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R36 NRSA63J-222X MG RESISTOR 2.2k
R37 NRSA63J-222X MG RESISTOR 2.2k
R38 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R39 NRSA63J-0R0X MG RESISTOR 0
R40 NRSA63J-393X MG RESISTOR 39k
R41 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R42 NRSA02J-100X MG RESISTOR 10
R43 NRSA63J-471X MG RESISTOR 470
R44 NRSA63J-221X MG RESISTOR 220
R51 NRSA63J-223X MG RESISTOR 22k
R52 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R81 NRSA63J-332X MG RESISTOR 3.3k
R82 NRSA63J-133X MG RESISTOR 13k
R91 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R92 NRSA63J-133X MG RESISTOR 13k
R162 NRSA63J-223X MG RESISTOR 22k
R163 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R164 NRSA63J-473X MG RESISTOR 47k
R165 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/8W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/10W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R172 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R173 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R174 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R175 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R181 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R182 NRSA63J-271X MG RESISTOR 270
R301 NRSA63J-273X MG RESISTOR 27k
R302 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R311 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R312 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R341 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R342 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R343 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R351 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R352 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R353 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R402 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R404 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R405 NRSA63J-225X MG RESISTOR 2.2MΩ 1/16W J
R406 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R407 NRSA63J-222X MG RESISTOR 2.2k
R408 NRSA63J-222X MG RESISTOR 2.2k
R409 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R412 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R413 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R414 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R415 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R416 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R423 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R424 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R430 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R431 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R432 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R433 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R440 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R451 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R452 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R453 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R454 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R455 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R456 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R457 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R458 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R461 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R462 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R481 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R501 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R502 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R503 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R504 NRSA63J-153X MG RESISTOR 15k
R507 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R508 NRSA63J-302X MG RESISTOR 3k
R509 NRSA63J-123X MG RESISTOR 12k
R510 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R511 NRSA63J-152X MG RESISTOR 1.5k
R512 NRSA63J-152X MG RESISTOR 1.5k
R513 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R514 NRSA02J-0R0X MG RESISTOR 0
R515 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R516 NRSA63J-331X MG RESISTOR 330
R517 NRSA63J-512X MG RESISTOR 5.1k
R518 NRSA02J-822X MG RESISTOR 8.2kΩ 1/10W J
R523 NRSA63J-823X MG RESISTOR 82k
R524 NRSA63J-823X MG RESISTOR 82k
R525 NRSA63J-334X MG RESISTOR 330kΩ 1/16W J
R526 NRSA63J-334X MG RESISTOR 330k
R527 NRSA02J-220X MG RESISTOR 22
R528 NRSA02J-220X MG RESISTOR 22
R529 NRSA63J-823X MG RESISTOR 82k
R530 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R531 NRSA63J-103X MG RESISTOR 10k
R532 NRSA63J-202X MG RESISTOR 2k
R533 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R534 NRSA63J-153X MG RESISTOR 15k
R535 NRSA63J-101X MG RESISTOR 100
R536 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R537 NRSA63J-0R0X MG RESISTOR 0
R539 NRSA02J-151X MG RESISTOR 150
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/10W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/10W J
Ω
1/10W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/10W J
3-12
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R541 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R542 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R543 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J
R544 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R545 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R546 NRSA63J-0R0X MG RESISTOR 0
R547 NRSA63J-0R0X MG RESISTOR 0
R548 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R549 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R550 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R551 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R552 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R553 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R554 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R555 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R556 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R557 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R558 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R559 NRSA63J-155X MG RESISTOR 1.5MΩ 1/16W J
R581 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R582 NRSA63J-822X MG RESISTOR 8.2k
R583 NRSA63J-822X MG RESISTOR 8.2k
R584 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R585 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R586 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R587 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R588 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R591 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R592 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R593 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R594 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R595 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R596 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R597 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R598 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R701 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R702 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R703 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R704 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R705 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R708 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R709 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R710 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R711 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R712 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R713 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R714 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R715 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R716 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R717 NRSA63J-471X MG RESISTOR 470
R719 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R720 NRSA63J-122X MG RESISTOR 1.2k
R721 NRSA63J-102X MG RESISTOR 1k
R722 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R723 NRSA63J-103X MG RESISTOR 10k
R725 NRSA63J-103X MG RESISTOR 10k
R726 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R728 NRSA63J-103X MG RESISTOR 10k
R729 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R734 NRSA63J-222X MG RESISTOR 2.2k
R735 NRSA63J-222X MG RESISTOR 2.2k
R736 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R741 NRSA63J-103X MG RESISTOR 10k
R743 NRSA63J-103X MG RESISTOR 10k
R744 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R745 NRSA63J-103X MG RESISTOR 10k
R746 NRSA63J-103X MG RESISTOR 10k
R747 NRSA63J-472X MG RESISTOR 4.7k
R748 NRSA63J-472X MG RESISTOR 4.7k
R749 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R750 NRSA63J-103X MG RESISTOR 10k
R751 NRSA63J-103X MG RESISTOR 10k
R752 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R753 NRSA63J-473X MG RESISTOR 47k
R754 NRSA63J-821X MG RESISTOR 820
R755 NRSA63J-106X MG RESISTOR 10MΩ 1/16W J
R756 NRSA63J-473X MG RESISTOR 47k
R757 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R758 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R759 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R763 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R765 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R771 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R772 NRSA63J-103X MG RESISTOR 10k
R774 NRSA63J-473X MG RESISTOR 47k
R776 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R783 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R804 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R811 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R851 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R901 QRE142J-102X C RESISTOR 1kΩ 1/4W J
R902 NRSA02J-912X MG RESISTOR 9.1kΩ 1/10W J
R903 NRSA02J-472X MG RESISTOR 4.7kΩ 1/10W J
R971 NRS181J-222X MG RESISTOR 2.2kΩ 1/8W J
R972 NRS181J-222X MG RESISTOR 2.2kΩ 1/8W J
R976 NRSA02J-273X MG RESISTOR 27kΩ 1/10W J
R977 NRSA02J-123X MG RESISTOR 12kΩ 1/10W J
L1 QQL244J-4R7Z COIL 4.7uH J
L401 NQL114K-470X INDUCITOR 47uH K
L402 NQL114K-470X INDUCITOR 47uH K
L404 NQL114K-470X INDUCITOR 47uH K
L541 NQL114K-470X INDUCITOR 47uH K
L543 NQL114K-470X INDUCITOR 47uH K
L544 NQL114K-470X INDUCITOR 47uH K
L701 QQL244J-4R7Z COIL 4.7uH J
L702 NQL79GM-4R7X COIL 4.7uH M
L901 QQR0703-001 CHOKE COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J321 QNN0519-001 PIN JACK
TU1 QAU0223-001 TUNER
X31 QAX0616-001Z CRYSTAL 10.250MHz
X401 QAX0413-001Z CRYSTAL 16.9344MHz
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Ω
1/16W J
Ω
1/16W J
Switch board (UI3)
Block No. [0][4]
Symbol No.
IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER
Q671 2SB624/4/-X TRANSISTOR
Q672 UN2211-X TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310LT/MN/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310LT/MN/-X LED
D618 SML-310LT/MN/-X LED
D631 NSPW310BS/BRST/ WHITE LED
D632 NSPW310BS/BRST/ WHITE LED
D641 MA8051/M/-X Z DIODE
Part No. Part Name Description Local
3-13
Symbol No.
D643 MA111-X SI DIODE
D644 MA8062/M/-X Z DIODE
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R605 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R606 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R607 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R608 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R609 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R610 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R611 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R612 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R613 NRSA63J-122X MG RESISTOR 1.2k
R614 NRSA63J-182X MG RESISTOR 1.8k
R615 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R627 NRSA02J-391X MG RESISTOR 390Ω 1/10W J
R628 NRSA02J-391X MG RESISTOR 390Ω 1/10W J
R629 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R630 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R632 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R634 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R636 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R638 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R640 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R642 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R644 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R651 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R653 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R654 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R655 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R656 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R657 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R658 NRSA63J-184X MG RESISTOR 180kΩ 1/16W J
R661 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R662 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R671 NRSA02J-471X MG RESISTOR 470Ω 1/10W J
R672 NRSA02J-473X MG RESISTOR 47kΩ 1/10W J
R673 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
Part No. Part Name Description Local
Ω
1/16W J
Ω
1/16W J
3-14
<MEMO>
XXXXX
3-15
Packing materials and accessories parts list
P3
A1 A4
Block No.
M
3
M
M
P1
P5
A3
KIT:
P5
P2
A2
A13
A5 A6 A7
A8 A9
P4
A11
A12
P6
3-16
P7
A10
Packing and Accessories
Symbol No. Part No. Part Name Description Local
A 1 GET0303-001A INST BOOK ENG
A 2 GE20137-003A MOUNTING SLEEVE
A 3 GE20135-003A TRIM PLATE G413UI2,G413UI3
A 3 GE20135-001A TRIM PLATE G414UI2,G414UI3
A 4 GET0303-002A INSTALL MANUAL
A 5 VKZ4027-202 PLUG NUT
A 6 VKH4871-003 MOUNT BOLT
A 7 VKZ4328-003 LOCK NUT
A 8 QYWWS53A008ZA WASHER 0mm/5.3mm x
A 9 GE40130-002A HOOK (x2)
A 10 FSJB3002-00C HARD CASE G413UI2,G414UI2
A 10 FSJB3002-00C-N HARD CASE G413UI3,G414UI3
A 11 RM-RK50 REMOCON UNIT
A 12 ------------ BATTERY
A 13 QAM0390-004 16P CORD ASSY
KIT SRW-385U SCREW PARTS KIT A5 A6 A7 A8 A9
P 1 GE31703-001A CARTON G413UI2,G413UI3
P 1 GE31700-001A CARTON G414UI2,G414UI3
P 2 QPC03004315P POLY BAG 30cm x 43cm
P 3 FSPG4002-001 POLY BAG
P 4 QPA00801205 POLY BAG 8cm x 12cm
P 5 GE10070-003A EPS CUSHION
P 6 QPA01003003 POLY BAG 10cm x 30cm
P 7 FSYH4036-068 SHEET
Block No. [M][3][M][M]
3-17
Loading...
