JVC KD-ABT22 User Manual
CD RECEIVER KD-ABT22
RECEPTOR CON CD KD-ABT22
RÉCEPTEUR CD KD-ABT22
For canceling the display demonstration, see page 5.
Para cancelar la demostración en pantalla, consulte la página 5.
Pour annuler la démonstration des affichages, référez-vous à la page 5.
ENGLISHESPAÑOLFRANÇAIS
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l’installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
For customer Use:
Enter below the Model
No. and Serial No. which
are located on the top or
bottom of the cabinet. Retain
this information for future
reference.
Model No.
Serial No.
GET0527-001B
[J]
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
INFORMATION (For U.S.A.)
ENGLISH
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Caution:
Changes or modifications not approved by JVC could void the user’s authority to operate the equipment.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: (For U.S.A.) Visible and/or invisible class II laser radiation when open. Do not stare into beam.
(For Canada) Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
This unit is equipped with the steering wheel
[European Union only]
remote control function.
• See the Installation/Connection Manual (separate
volume) for connection.
2
How to reset your unit
• Your preset adjustments will also be erased (except the
registered Bluetooth device, see pages 13 and 14).
How to forcibly eject a disc
“Please Eject” appears on the display.
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
CONTENTS
INTRODUCTIONS
Preparation .................................................. 5
OPERATIONS
Basic operations ........................................... 6
• Using the control panel ............................... 6
• Using the remote controller (RM-RK50) ...... 7
Listening to the radio ................................... 8
Disc operations ............................................. 10
Listening to the USB device .......................... 12
Using the Bluetooth
• Using the Bluetooth cellular phone ............ 15
• Using the Bluetooth audio player ............... 18
EXTERNAL DEVICES
Listening to the HD Radio ™ Broadcast ......... 19
Listening to the CD changer ......................... 20
Listening to the satellite radio ..................... 21
Listening to the iPod .................................... 24
Listening to the other external
components .............................................. 27
SETTINGS
Selecting a preset sound mode .................... 28
General settings — PSM .............................. 31
Bluetooth settings ....................................... 36
Title assignment .......................................... 37
REFERENCES
More about this unit .................................... 38
Troubleshooting ........................................... 43
Maintenance ................................................ 49
Specifications ............................................... 50
® devices ....................... 13
ENGLISH
3
How to use the M MODE and SEL
buttons
If you use M MODE or SEL (select), the display and some
controls (such as the number buttons,
4 /¢ buttons, 5/∞ buttons, and the
ENGLISH
control dial) enter the corresponding control mode.
Ex.: When you press number button 1 after pressing
M MODE, to operate the FM tuner.
To use these controls for original functions, press
M MODE again.
• However, pressing SEL makes the unit enters a
different mode.
• Waiting for about 15 seconds without pressing any of
these buttons will automatically cancels the control.
Detaching the control panel
Avoid touching the connectors.
Attaching the control panel
Caution:
If the temperature inside the car is below 32°F (0°C),
the movement of animation and text scroll will be
halted on the display to prevent the display from being
blurred. appears on the display.
When the temperature increases, and the operating
temperature is resumed, these functions will start
working again.
4
Warning:
If you need to operate the unit while driving, be sure to
look around carefully or you may be involved in a traffic
accident.
Caution on volume setting:
Digital devices (CD/USB) produce very little noise
compared with other sources. Lower the volume before
playing these digital sources to avoid damaging the
speakers by sudden increase of the output level.
Preparation
Cancel the display demonstration and set the clock
• See also pages 31 and 32.
1
2
Turn on the power.
Enter the PSM settings.
ENGLISH
3
4
Changing the display information and pattern
When the power is turned off: Check the current clock time
Ex.: When tuner is selected as the source
Source operation display
• If a station has been assigned a title, station
title appears after about 5 seconds.
• To assign a title to a station, see page 37.
Cancel the display demonstrations
Select “Demo,” then “Off.”
Set the clock
Select “Clock Hr” (hour), then adjust the hour.
Select “Clock Min” (minute), then adjust the minute.
Select “24H/12H,” then “24Hours” or “12Hours.”
Finish the procedure.
Audio level meter display
(see “LevelMeter” on page 31)
5INTRODUCTIONS
Basic operations
Using the control panel
ENGLISH
1 • TUNER: Select preset station.
• HD RADIO: Select channel.
• SIRIUS/XM: Select category.
• CD/USB/CD-CH: Select folder.
• USB-iPod: Enter the main menu [Hold].
• iPod: Enter the main menu/Pause playback/
Confirm selection.
2 • Turn on the power.
• Turn off the power [Hold].
• Attenuate the sound (if the power is on).
• Bluetooth: Switch the conversation media
during a phone call conversation.
3 Display window
4 • Enter/exit Bluetooth menu.
• Display the dialed list [Hold].
5 Flip down the control panel.
• To eject the disc, flip down the control panel
then press 0 on the unit.
6 AUX (auxiliary) input jack
7 • TUNER/HD RADIO/SIRIUS/XM: Search for
station/channel.
• CD/USB/CD-CH/USB-iPod/iPod: Select track.
• BT-AUDIO: Reverse skip/forward skip.
8 • Volume control [Turn].
• Select the source [Press] .
TUNER *1/HD RADIO *2 = SIRIUS *2/XM *2 =
CD *2 = USB *2 (or USB-iPod) *2 = CD-CH *2/
iPod *2 (or EXT IN) = BT-AUDIO = AUX IN
= (back to the beginning)
9 • Select/adjust the sound mode.
• Enter the PSM settings [Hold].
p • TUNER/SIRIUS/XM: Select preset station/
channel.
• CD/USB/CD-CH: Select folder/track/disc (for CD
changer).
• USB-iPod: Select preset top menu items.
• Bluetooth: Dial preset phone number *3.
q • Enter functions mode.
• Bluetooth: Activate Voice Dialing [Hold].
w Change the display information and pattern.
e • TUNER: Select the bands.
• USB-iPod: Start/pause playback.
• BT-AUDIO: Start/pause playback.
*1 When the HD Radio tuner box is connected, the
built-in tuner of this unit will be disable. To listen
to the HD Radio broadcast, refer to “Listening to the
radio” on page 8. For more features, see pages 19 and
20.
2
*
You cannot select these sources if they are not ready
or not connected.
*3 For storing preset phone number, see page 17.
6
Using the remote controller (RM-RK50)
Installing the lithium coin battery (CR2025)
ENGLISH
Caution:
Battery shall not be exposed to excessive heat such as
sunshine, fire, or the like.
If the effectiveness of the remote controller
decreases, replace the battery.
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
Remote sensor
Warning (to prevent accidents and damage):
• Do not install any battery other than CR2025 or its
equivalent.
•
Do not leave the remote controller in a place (such as
dashboards) exposed to direct sunlight for a long time.
• Store the battery in a place where children cannot
reach.
• Do not recharge, short, disassemble, heat the battery,
or dispose of it in a fire.
• Do not leave the battery with other metallic
materials.
•
Do not poke the battery with tweezers or similar tools.
• Wrap the battery with tape and insulate when
throwing away or saving it.
For USA-California Only:
This product contains a CR Coin Cell Lithium Battery
which contains Perchlorate Material—special
handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
1 • Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
• Switches the conversation media during a phone
call conversation.
2 • Changes the FM/AM bands with 5 U.
• Changes the preset stations with D ∞.
• Changes the folder of the MP3/WMA/AAC/WAV.
• While playing an MP3 disc on an
MP3-compatible CD changer:
– Changes the disc if pressed briefly.
– Changes the folder if pressed and held.
• While listening to the satellite (SIRIUS or XM)
radio:
– Changes the categories.
• While listening to an Apple iPod:
Connected to KS-PD100:
– Pauses or resumes playback with D ∞.
– Enters the main menu with 5 U.
(Now 5 U/D ∞/2 R/F 3 work as the menu
selecting buttons.)*
* 5 U : Returns to the previous menu.
D ∞ : Confirms the selection.
Connected to the USB cable:
– Enter the main menu if pressed and held.
– Select the desired menu if pressed briefly.
– Fast skip in every layer of the main menu if
pressed and held.
Continued on the next page
7OPERATIONS
3 Adjusts the volume level.
4 Selects the sound mode (iEQ: intelligent equalizer).
5 Selects the source.
6 For Bluetooth cellular phone:
– Answers calls if pressed briefly.
– Rejects calls if pressed and held.
ENGLISH
– Holds calls if pressed briefly during phone call
conversation.
7 • Searches for stations if pressed briefly.
• Fast-forwards or reverses the track if pressed and
held.
• Changes the tracks if pressed briefly.
• While listening to the satellite (SIRIUS or XM)
radio:
– Changes the channels if pressed briefly.
Listening to the radio
– Changes the channels rapidly if pressed and
held.
• While listening to an iPod (in menu selecting
mode):
Connected to KS-PD100:
– Selects an item if pressed briefly. (Then, press
∞ to confirm the selection.)
D
– Skips 10 items at a time if pressed and held.
Connected to the USB cable:
– By holding F 3, you can start play back the
selected item directly.
– By holding R 2, you can go back to the main
display.
• Reverse skip/forward skip for Bluetooth audio.
1
2
3
Select “TUNER.”
Select the bands.
Search for a station to listen—Auto Search.
Manual Search: Hold either one of the buttons until “M” lights up on the display, then
press it repeatedly.
• When receiving an FM stereo broadcast with sufficient signal strength, lights up
on the display.
When an FM stereo broadcast is
hard to receive
1
2
Reception improves, but stereo effect will be lost.
• lights up on the display.
8
3 Exit from the setting.
FM station automatic presetting
— SSM (Strong-station Sequential
Memory)
You can preset up to six stations for each band.
1 While listening to a station...
2
Using the Preset Station list
• When is shown on the display, you can
move back to the previous screen by pressing number
button 3.
1 Follow steps 1 and 2 of “Using the number
buttons” on the left column.
• By holding
also appear (go to step 4).
5 / ∞, the Preset Station List will
2
ENGLISH
3
Local FM stations with the strongest signals are
searched and stored automatically in the selected
FM band.
• If an HD Radio tuner box is connected, you
can also search and store the AM station
automatically.
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset number
4 of the FM1 band.
Using the number buttons
1
2
3
Preset number flashes for a while.
3
Display the Preset Station List.
4 Select the preset number you want to store
into.
• You can move to the lists of the other FM bands
by pressing number button 5 ( ) or
6 ( ) repeatedly.
5 Store the station.
Continued on the next page
9OPERATIONS
Listening to the preset station on the Preset Station List
1 Display the Preset Station List, then select the preset station you want to listen to.
2 Change to the selected station.
ENGLISH
Disc operations
All tracks will be played repeatedly until you change the
source or eject the disc.
To stop play and eject the disc
• Press SOURCE to listen to another playback source.
Pressing (or holding) the following buttons allows you
to...
[Press] Select track
[Hold] Reverse/fast-forward
track
1
MP3/WMA/AAC: Select folder
*
Locate particular folder *3
(for MP3/WMA/AAC) or track
(Number buttons) *
2
directly
Prohibiting disc ejection
To cancel the prohibition, repeat the same
procedure.
1
By holding either one of the buttons, you can display
*
the Folder List (see page 11).
2
*
Press to select number 1 to 6; hold to select number
7 to 12.
*3 It is required that folders be assigned with 2-digit
numbers at the beginning of their folder names—01,
02, 03, and so on.
10
After pressing M MODE, press the following buttons to...
Skip 10 tracks
MP3/WMA/AAC: Within the same
folder
Repeat Track:
Repeat current track
Repeat Folder:
MP3/WMA/AAC: Repeat current
folder
Random Folder:
MP3/WMA/AAC: Randomly play all
tracks of current folder, then tracks
of next folders
Random Disc:
Randomly play all tracks
• You can also cancel the playback mode by selecting
“Off” or press number button 4 (
).
Selecting a folder/track on the list
(only for MP3/WMA/AAC file)
• When is shown on the display, you can
move back to the previous screen by pressing number
button 3.
1
4 Select an item.
Ex.: When “File” is selected in step 3
• You can move to the other lists by pressing
number button 5 (
repeatedly.
) or 6 ( )
5 Change to the selected item.
A If File List is selected
The list disappears and playback
starts.
B If Folder List is selected
• If the current folder is selected, File List
appears, then repeat steps 4 and 5 A to
start playback.
• If another folder is selected, playback starts
from the 1st file of the selected folder.
ENGLISH
Select “LIST.”
2
3 Select the list type.
11OPERATIONS
Listening to the USB device
You can connect a USB mass storage class device such as a USB memory, Digital Audio Player *1, portable HDD, etc. to
the unit.
• You can also connect an Apple iPod to the USB cable from the rear of the unit. For details of the operations, see
ENGLISH
pages 24 – 26.
This unit can play MP3/WMA/WMA-DRM10 *
*1 You can connect both MTP (Media Transfer Protocol) devices and USB mass storage class devices. See also page 40.
*2 This unit can play back AAC files encoded using iTunes. This unit cannot play back FairPlay-encrypted files.
All tracks will be played repeatedly until you change the source or detach the USB device.
1
/AAC *2/WAV tracks stored in a USB device.
USB cable from the rear of the unit.
USB memory
If a USB device has been attached...
Playback starts from where it has
been stopped previously.
• If a different USB device is
currently attached, playback starts
from the beginning.
To stop play and detach the USB device
Straightly pull it out from the unit.
• Press SOURCE to listen to another playback source.
You can operate the USB device in the same way you
operate the files on a disc. (See pages 10 and 11.)
• You can listen to WAV files by following the MP3/
WMA/AAC files operations listed on pages 10 and 11.
12
Cautions:
• Avoid using the USB device if it might hinder your
safety driving.
• Do not pull out and attach the USB device repeatedly
while “Reading” is shown on the display.
• Do not start the car engine if a USB device is
connected.
• This unit may not be able to play the files depending
on the type of USB device.
• Operation and power supply may not work as
intended for some USB devices.
• You cannot connect a computer to the USB cable
from the rear of the unit.
• Make sure all important data has been backed up to
avoid losing the data.
• Do not leave a USB device in the car, expose to direct
sunlight, or high temperature to avoid deformation
or cause damages to the device.
• Some USB devices may not work immediately after
you turn on the power.
• For more details about USB operations, see page 40.
Using the Bluetooth ® devices
Bluetooth is a short-range wireless radio
communication technology for the mobile device such
as mobile phones, portable PCs, and other devices. The
Bluetooth devices can be connected without cables and
communicate with each other.
• Refer to the list (included in the box) to see the
countries where you may use the Bluetooth®
function.
Bluetooth profile
This unit supports the following Bluetooth profiles;
HFP (Hands-Free Profile) 1.5
OPP (Object Push Profile) 1.1
A2DP (Advanced Audio Distribution Profile) 1.2
AVRCP (Audio/Video Remote Control Profile) 1.3
Connecting a Bluetooth device for
the first time
Pairing and PIN code
When you connect a Bluetooth device to the unit
for the first time, make pairing between the unit
and the device. Pairing allows Bluetooth devices to
communicate with each other.
To make pairing, you may need to enter the PIN
(Personal Identification Number) code of your Bluetooth
device you want to connect.
• Once the connection is established, it is registered in
the unit even if you reset the unit. Up to five devices
can be registered in total.
• Only one device for Bluetooth phone and one for
Bluetooth audio can be connected at a time.
• To use the Bluetooth function, you need to turn on
Bluetooth function of the device.
ENGLISH
Features
You can operate Bluetooth devices through the unit as
follows:
• Receiving a call
• Making a call—from phone book, from call history
(dialed number/received call), by dialing number, by
preset numbers, by voice command
• Informing you of the arrival of a text message
• Play back a Bluetooth audio player
Refer also to the instructions supplied with the
Bluetooth device.
Preparation: Operate the device to turn on its
Bluetooth function.
• When
move back to the previous screen by pressing number
button 3.
is shown on the display, you can
1 While listening to a source...
2 Select “Device.”
3 Select “New Pairing.”
Continued on the next page
13OPERATIONS
4 Enter a PIN (Personal Identification Number)
code to the unit.
• You can enter any number you like (1-digit to
16-digit number). [Initial: 0000]
• To enter a PIN code less than 4-digit, firstly
ENGLISH
delete the initial PIN code (0000) by pressing
number button 5 (
* Some devices have their own PIN code. Enter the
specified PIN code to the unit.
1 Move to the next (or previous) number
position.
) .
The device remains registered even after you
disconnect the device. Use “Cnnct Phone“ or
“Cnnct Audio” (or activate “Auto Cnnct”) to
connect the same device from next time on. (See the
following and page 36.)
Deleting a registered device
Perform steps 1 and 2 on page 13, then...
1 Select “Del Pairing.”
2 Select a number.
3 Repeat steps 1 and 2 until you finish
entering a PIN code.
4 Confirm the entry.
5 Operate the target Bluetooth device, (while
“Open...” is flashing on the display).
On the device to be connected, enter the same PIN
code you have just entered for this unit.
“Connecting...” flashes, then “Pairing Ok” or
“Connected [Device Name]” appears on the display
when the connection is established. Now you can
use the device through the unit.
appears when the connection is established.
2 Select a device you want to delete.
3 Delete the selection.
• Press number button 3 to select “No” or return to
step 1.
Connecting a registered device
Perform steps 1 and 2 on page 13, then...
1 Select “Cnnct Phone” or “Cnnct Audio.”
2 Select a device you want.
“Connecting...” flashes, then “Connected (and
device name)” appears on the display when the
device is connected.
14
You can set the unit to connect the Bluetooth device
automatically when the unit is turned on. (See
“Auto Cnnct” on page 36.)
3 Select the method to make a call.
Disconnecting a device
Perform steps 1 and 2 on page 13, then...
Select “Discn Phone” or “Discn Audio.”
“Disconnecting...” flashes, then “Disconnected (and
device name)” appears on the display when the device
is disconnected.
Using the Bluetooth cellular
phone
Making a call
You can make hands-free calls using the unit.
The built-in microphone is
behind this corner of the unit.
The sounds comes out from the connected speakers.
ENGLISH
• Dialed *: Shows the list of the phone numbers
you have dialed. Go to the following step.
• Received *: Shows the list of the received calls.
Go to the following step.
• Phonebook: Shows the name/phone number of
the phone book of the unit. Go to the following
step. To copy the phone book memory, see page
17.
• Preset: Shows the list of preset numbers. Go to
the following step. To preset numbers, see page
17.
• Dial Number: Shows the phone number entry
screen. See “How to enter phone number” on
page 16.
• Voice Dial (Only accessible when the connected
cellular phone has the voice recognition system):
Speak the name (registered words) you want to
call.
* Displays only when the dialed or received number
is made through the unit.
4 Select the name/phone number/preset
number you want to call.
• When appears on the display, you can
move back to the previous display by pressing
number button 3.
1
2 Select “Call.”
• When the sound is stopped or interrupted during the
use of a Bluetooth device, turn off, then turn on the
unit.
– If the sound is not yet restored, connect the device
again. (See “Connecting a registered device” on
page 14.)
Continued on the next page
15OPERATIONS
When a call comes in....
The source is automatically changed to “Bluetooth.”
• Phone number appears (if acquired).
ENGLISH
When “Auto Answer” is activated....
The unit answers the incoming calls automatically, see
page 36.
• When “Auto Answer” is deactivated, press any
button (except
incoming call.
• You can adjust the microphone volume level (see
page 36).
To end the call or reject an incoming call
Hold any button (except /control dial).
• When “Auto Answer” is set to “Reject,” the unit
rejects any incoming calls.
Answering a waiting call
If your cellular phone is equipped with the call waiting
function, you can put the current call on hold and
answer the waiting call.
Press any button (except /control dial).
• To restore the on-hold call, press any button (except
/control dial) again.
• When you end one call, you can connect to the other.
When a text message comes in....
If the cellular phone is compatible with Text Message
and “MSG Notice” is set to “On” (see page 36), the unit
rings and “Received Message” appears on the display to
inform you of the message arrival.
• You cannot edit or send a message through the unit.
/control dial) to answer the
How to enter phone number
Select a number.
Move the entry position.
Confirm the entry.
How to delete phone number
1
2 Select “Call.”
3 Display the list of phone numbers using one
of the dialing method (see step 3 of “Making
a call” on page 15).
4 Select the name/phone number you want to
delete.
5 Delete the selection.
16
• Press number button 6 ( ) to delete all
the listed numbers in step 3.
How to copy phone book
You can copy the phone book memory of a cellular
phone into the unit.
• When is shown on the display, you can
move back to the previous screen by pressing number
button 3.
1
Presetting the phone number
You can preset up to six phone numbers.
• When is shown on the display, you can
move back to the previous screen by pressing number
button 3.
1 Display the phone number you want to
preset by using one of the “Call” items.
ENGLISH
2 Select “Settings.”
3 Select “PhoneBook.”
4 Enter the PIN code both for this unit and
Bluetooth phone.
• See step 4 of page 14.
5
Operate the target cellular phone. (While
“Receiving 00/50” appears on the display.) Enter
the same PIN code (as entered in step 4) on the
cellular phone, then transfer the phone book
memory to the unit. (Refer to the Instructions
manual supplied with your cellular phone.)
2 Select a phone number.
You can also enter a new phone
number (see also “How to enter
phone number” on page 16) to store.
3 Select a preset number to store.
To call a preset number
While in Bluetooth audio....
• You can also call a preset number using “Preset” of
the “Call” items (see page 15).
Switching conversation media (the unit/
cellular phone)
During a phone call conversation....
Then, continue your conversation
using the other media.
• Operations may be different according to the
connected Bluetooth device.
Continued on the next page
17OPERATIONS
Using the Bluetooth audio player
• Operations and display indications differ depending on their availability on the connected audio player.
Select “BT-AUDIO.”
If playback does not start automatically, operate the Bluetooth audio player to start playback.
ENGLISH
[Press] Reverse skip/forward skip
[Hold] Reverse search/forward
search
Select group/folder
Start/pause playback
• Refer also to pages 14 and 15 for connecting/
disconnecting/deleting a registered device.
Bluetooth Information:
If you wish to receive more information about
Bluetooth, visit the following JVC web site: <http://
www.jvc-victor.co.jp/english/car/>.
After pressing M MODE, press the following buttons to...
Repeat Track:
Repeat current track
Repeat All:
Repeat all tracks
Repeat Group:
Repeat all tracks of current group
Random All:
Randomly play all tracks
Random Group:
Randomly play all tracks of the
current group
• You can also cancel the playback mode by selecting
“Off.”
18 OPERATIONS
Listening to the HD Radio ™ Broadcast
Before operating, connect HD Radio tuner box, KT-HD300 (separately purchased) to the CD changer jack on the
rear of the unit.
What is HD Radio Technology?
HD Radio Technology can deliver high-quality digital sound—AM digital will have FM-like quality (in stereo) and FM
digital will have CD-like quality—with static-free and clear reception. Furthermore, stations can offer text and data,
such as artist names and song titles.
• When the HD Radio tuner box is connected, it can also receive conventional analog broadcasts.
• Many HD Radio stations also offer more than one channel of programming. This service is called multicasting.
• To find HD Radio stations in your area, visit www.hdradio.com <http://www.hdradio.com/>.
Refer also to pages 8 – 10 for basic radio operations.
ENGLISH
When receiving an HD Radio
station...
Station Call Sign appears.
When receiving HD Radio multicast
channels...
Channel numberFirst four letters of Call Sign
Select your desired channel.
Searching for HD Radio stations
only
1
2
Changing HD Radio reception
mode
While receiving an HD Radio broadcast, the unit tunes
to digital or analog audio automatically due to the
receiving condition.
1 While listening to an HD Radio station...
Continued on the next page
EXTERNAL DEVICES
19
2
ENGLISH
[Lights up] When holding the digital reception
[Flashes] When holding the analog reception
Auto: [Initial] Switch between digital and
analog audio automatically
Digital: Tuning to digital audio only
Analog: Tuning to analog audio only
• If no sound can be heard from the selected setting,
change the setting to “Analog” or “Digital.”
• The setting automatically changes to “Auto” if you
tuned in to or change to another station, or if you
turned off the power.
• This setting cannot take effect for the conventional
FM/AM stations.
• If the radio station forces the reception mode to
digital or analog, the DIGI or ANA indicator lights up.
Listening to the CD changer
It is recommended to use a JVC MP3-compatible CD changer with your unit. You can connect a CD changer to the
CD changer jack on the rear of the unit.
• You can only play conventional CDs (including CD Text) and MP3 discs.
Preparation: Make sure “Changer” is selected for the external input setting, see page 33.
1
Select “CD-CH.”
2
[Press] Select track
[Hold] Reverse/fast-forward track
MP3: Select folders
*
* By holding either one of the buttons, you can display
the Disc List (see page 11).
Select a disc to start playing.
[Press] For selecting disc number 1 – 6.
[Hold] For selecting disc number 7 – 12.
20
To select a disc/folder/track on the list
See “Selecting a folder/track on the list (only for MP3/
WMA/AAC file)” on page 11.
Select “Disc” in step 3 to display the Disc List of the CD
changer.
After pressing M MODE, press the following buttons to...
Skip 10 tracks
MP3: Within the same folder
Repeat Track:
Repeat current track
Repeat Folder:
MP3: Repeat all tracks of current
folder
Repeat Disc:
Repeat all tracks of the current disc
• You can also cancel the playback mode by selecting
“Off” or press number button 4 (
Random Folder:
MP3: Randomly play all tracks of
the current folder, then tracks of the
next folder
Random Disc:
Randomly play all tracks of current
disc
Random All:
Randomly play all tracks of the discs
in the magazine
).
Listening to the satellite radio
Before operating, connect either one of the following (separately purchased) to the CD changer jack on the rear of
this unit.
• JVC SIRIUS Satellite radio interface, KS-SRA100, for listening to the SIRIUS Satellite radio.
• JVC Smart Digital Adapter, XMDJVC100, for listening to the XM Satellite radio.
GCI (Global Control Information) update
• If channels are updated after subscription, updating starts automatically.
The following appears and no sound can be heard:
– For SIRIUS Satellite radio: “Updating XX%* Completed”
– For XM Satellite radio: “UPDATING”
• Update takes a few minutes to complete.
• During update, you cannot operate your satellite radio.
* Changes every 20% of update is completion (ex. 20%, 40%, 60%)
ENGLISH
Activate your SIRIUS subscription after
connection
1
2
SIRIUS Satellite radio starts updating all the SIRIUS
channels.
Once completed, SIRIUS Satellite radio tunes in to
the preset channel, CH184.
3 Check your Sirius ID, see page 33.
4 Contact SIRIUS on the internet at
<http://activate.siriusradio.com/> to
activate your subscription, or you can call
SIRIUS toll-free at 1-888-539-SIRIUS (7474).
“Sub Updated Press Any Key” scrolls on the display
once subscription has been completed.
Continued on the next page
EXTERNAL DEVICES
21
Activate your XM subscription after
connection
• Only Channel 0, 1, and 247 are available before
activation.
1
ENGLISH
2
XMDirect ™ Universal Tuner Box starts updating
all the XM channels. “Channel 1” is tuned in
automatically.
3 Check your XM Satellite radio ID labelled on
the casing of the XMDirect ™ Universal Tuner
Box, or tune in to “Channel 0” (see page 23).
4 Contact XM Satellite radio on the internet
at <http://xmradio.com/activation/> to
activate your subscription, or you can call
1-800-XM-RADIO (1-800-967-2346).
Once completed, the unit tunes in to one of the
available channels (Channel 4 or higher).
1
2
3
4
Select “SIRIUS” or “XM.”
Select the bands.
SIRIUS:
XM:
Select a category.
SIRIUS: If you select “ALL,” you can tune in to all the channels of all categories.
Select a channel to listen.
• Holding the button changes the channels rapidly.
• While searching, invalid and unsubscribed channels are skipped.
XM: If you do not select a channel within 15 seconds, category selected in step 3
is canceled. You can select all channels of all categories now (including noncategorised channels).
22
Checking the XM Satellite radio ID
While selecting “XM1,” “XM2,” or “XM3,” select
“Channel 0.”
3 Select “LIST.”
The display alternately shows “RADIO ID” and the
8-digit (alphanumeric) ID number.
To cancel the ID number display, select any channel
other than “Channel 0.”
To change the display information while
listening to a channel
Category name = Channel name = Artist/
composer * name
Audio level meter
* Only for SIRIUS Satellite radio.
= Song/program name =
= (back to the beginning)
Storing channels in memory
You can preset six stations for each band.
• When is shown on the display, you can
move back to the previous screen by pressing number
button 3.
• When
you can move to the other lists by pressing number
button 5 or 6 repeatedly.
/ is shown on the display,
4 Select “Preset.”
5 Select a preset number you want to store
into.
6 Store the channel.
Listening to a user channel
1 Display the Preset Channel list, then select
the preset number you want to listen to.
ENGLISH
Ex.: Storing a SIRIUS channel into preset number 4 of
the SR1 band.
1 Tune in to a channel you want to listen to.
• By holding BAND button, the Preset Channel List
will appear (go to step 5).
2
2 Change to the selected channel.
Continued on the next page
EXTERNAL DEVICES
23
Selecting a category/channel on
the list
• When is shown on the display, you can
move back to the previous screen by pressing number
button 3.
ENGLISH
• When
you can move to the other lists by pressing number
button 5 or 6 repeatedly.
Ex.: When listening to the SIRIUS Satellite radio.
/ is shown on the display,
1 To select a category
1 Follow steps 2 to 4 of “Storing channels in
memory” on page 23.
• In step 4, select “Category.”
The first channel of the selected category is
tuned in.
• Holding 5 / ∞ can also show the Category
List while listening to a channel.
2 Select a category.
To select a channel
1 Follow steps 2 to 4 of “Storing channels in
memory” on page 23.
• In step 4, select “Channel.”
2 Select a channel.
2 Change to the selected item.
Listening to the iPod
You can play songs in an Apple iPod by:
– Connecting it with the USB cable supplied with your iPod to the USB cable from the rear of the unit.
– Connecting the Interface adapter for iPod, KS-PD100 (separately purchased) to the CD changer jack on the rear of
the unit.
Preparation: Make sure “Changer” is selected for the external input setting, see page 33.
• You can control playback from the unit.
• Disconnecting the iPod will stop playback. Press SOURCE to listen to another playback source.
• For details, refer also to the manual supplied for your iPod.
24
Caution:
• Avoid using the iPod if it might hinder your safety while driving.
• Make sure all important data has been backed up to avoid losing the data.
1
—
2
Connect an iPod to the USB cable or through KS-PD100.
Playback starts automatically from where it had been paused previously.
• If an iPod has been connected, press SOURCE to select “USB-iPod” or “iPod” as
the playback source.
Select a track.
ENGLISH
3
—
Adjust the volume and sound as you want. (See pages 28 – 30.)
Playback control from the unit
Button For iPod connected through KS-PD100 For iPod connected to the USB cable
[Press] Go to the next or previous track
[Hold] Fast-forward or reverse the track
during playback
[Press] Enter main menu when you press 5.
Pause/resume playback when ∞ is
pressed.
— [Press] Pause/resume playback.
[Press] Go to the next or previous track
[Hold] Fast-forward or reverse the track
during playback
[Hold] Enter main menu
[Press] Go to the top menu of “Playlists,”
“Artists,” “Albums,” “Songs,”
“Podcasts,” “Genres,” “Composers,” or
“Audiobooks” in the main menu.
• Pressing the number buttons (1 – 6)
or holding 1 (7) and 2 (8) can also
select the preset top menus.
Continued on the next page
EXTERNAL DEVICES
25
Selecting a track from the menu
No. Operation For iPod connected through
KS-PD100
Enter the main
1
ENGLISH
menu.
Select the desired
2
menu.
For iPod connected to the USB
cable
Playlists Ô Artists Ô Albums Ô
Songs Ô Genres Ô Composers
Confirm the
3
selection.
• By holding 4 /¢ , you
can fast skip during song search in
the main menu.
• If a track is selected, playback starts automatically.
• If the selected item has another layer, you will enter the layer. Repeat steps 2
and 3 until the desired track is played.
After pressing M MODE, press the following buttons to...
Repeat One:
Same as “Repeat One.”
Repeat All:
Same as “Repeat All.”
Repeat Off:
Cancels.
Random Album *:
Same as “Shuffle Albums.”
Random Song:
Same as “Shuffle Songs.”
Random Off:
Cancels.
* Functions only if you select “All Albums” or “All” in
“Albums” of the main “MENU.”
Playlists Ô Artists Ô Albums Ô
Songs Ô Podcasts Ô Genres Ô
Composers Ô Audiobooks
• By holding ¢ , you can start
play back the selected item directly.
• By holding 4 , you can go
back to the main display.
• By holding 5/∞, you can fast skip
in every layer of the main menu.
The menu selecting mode will be canceled:
• If no operations are performed for about:
– 5 seconds for iPod connected through KS-PD100.
– 15 seconds for iPod connected to the USB cable.
• When you confirm the selection of a track.
26
Listening to the other external components
You can connect an external component to:
• CD changer jack on the rear of this unit using the following adapters:
– Line Input Adapter, KS-U57
– AUX Input Adapter, KS-U58
Preparation: Make sure “Ext In” is selected for the external input setting, see page 33.
• AUX (auxiliary) input jack on the control panel.
1
Select “EXT IN” or “AUX IN.”
ENGLISH
2
—
3
4
Connecting an external component to the AUX input jack
—
Turn on the connected component and start playing the source.
Adjust the volume.
Adjust the sound as you want (see pages 28 – 30).
3/16” (3.5 mm) stereo mini plug
(not supplied)
Portable audio player, etc.
EXTERNAL DEVICES
27
Selecting a preset sound mode
You can select a preset sound mode suitable to the music genre (iEQ: intelligent equalizer).
1
ENGLISH
2
Enter sound mode setting.
Select “EQ.”
3
4
Preset value setting for each sound mode
Sound mode
USER 00000
ROCK +3 +2 0 +1 +1
CLASSIC +2 +2 0 +1 0
POPS 0 +1 0 +1 +2
HIP HOP +4 +1 –2 0 +1
JAZZ +3 +2 +1 +2 +2
Band 1
(100 Hz)
Band 2
(320 Hz)
Select “On.”
• If “Bypass” is selected, you can listen to the original
sound mode recorded. lights up on the
display.
Select a preset sound mode.
Preset value
Band 3
(1 kHz)
Band 4
(3.2 kHz)
Band 5
(10 kHz)
28
Adjusting the sound
You can adjust the sound characteristics to your
preference.
• When is shown on the display, you can
move back to the previous screen by pressing number
button 3 or 6.
1
2
• For “EQ” setting, see page 28.
3 Adjust the selected setting item.
A Fad/Bal (Fader/Balance)
1 Press number button 1 ( )
to move to the “Fad/Bal” adjustment
display.
2 Adjust the speaker output balance by
pressing:
5 / ∞: between the front and rear
speakers. [F6 to R6]
4 /¢ : between the left and
right speakers. [L6 to R6]
B Subwoofer
1 Press number button 1 ( ) to
move to the “Subwoofer” adjustment
display.
2 Use 4 /¢ to select the cutoff
frequency to the subwoofer.
• Off *: All signals are sent to the
subwoofer.
• 55Hz: Frequencies higher than 55 Hz
are cut off.
• 85Hz: Frequencies higher than 85 Hz
are cut off.
• 120Hz: Frequencies higher than 120 Hz
are cut off.
3 Turn the control dial to adjust the
subwoofer output level. [0 to 8]
4 Press number button 1 ( ) to
move to another setting level.
4 /¢ : select the quality of
LPF. [–12dB/oct or –24dB/oct]
Control dial: Turn the control dial to select
the subwoofer phase. [0deg (normal) or
180deg (reverse)]
* If “Off” is selected in step
adjust the subwoofer phase.
C Hi Pass (Hi Pass Filter)
Turn the control dial to select the cutoff
frequency to the front/rear speakers. Set this
to match the LPF setting.
• Off: All signals are sent to the front/rear
speakers.
• 62Hz: Frequencies lower than 62 Hz are
cut off.
• 95Hz: Frequencies lower than 95 Hz are
cut off.
• 135Hz: Frequencies lower than 135 Hz are
cut off.
D VolAdjust, [–5 to +5]
Turn the control dial to adjust the input level
of each source (except FM).
Adjust to match the input level of the FM
sound level.
• Before making an adjustment, select the
source you want to adjust.
E Loudness, [Off or On]
Turn the control dial to select “Off” or
“On.” When “On” is selected, low and high
frequencies sound are boosted to produce a
well-balanced sound at low volume level.
2, you can only
4 Exit from the setting.
ENGLISH
29SETTINGS
Storing your own sound modes
You can adjust the sound modes and store your own
adjustments in memory.
• When is shown on the display, you can
move back to the previous screen by pressing number
ENGLISH
button 6.
1
2
5 Adjust the sound elements of the selected
frequency range.
1 Press 4 /¢ to select the
frequency band, then press 5 / ∞ to
enhanced level for the selected frequency
band. [–6 to +6]
2 Press number button 5 ( ), then turn
the control dial to select the frequency.
3 Press number button 5 ( ), then turn
the control dial to select the quality slope (Q).
6 Repeat steps 3 and 4 to adjust the other
frequency bands.
3 Select a sound mode.
7 Store the adjustments.
4 Select a frequency range to adjust.
Adjustable sound elements
Range/selectable items
Sound elements
Frequency 68 Hz
Level –6 to +6 –6 to +6 –6 to +6 –6 to +6 –6 to +6
Q (Q-slope) Q0.7
Band 1
(100 Hz)
100 Hz
150 Hz
Q1.0
Q1.4
Q2.0
(320 Hz)
210 Hz
320 Hz
460 Hz
Q0.7
Q1.0
Q1.4
Q2.0
Band 2
Band 3
(1 kHz)
680 Hz
1 kHz
1.5 kHz
Q0.7
Q1.0
Q1.4
Q2.0
Band 4
(3.2 kHz)
2.1 kHz
3.2 kHz
4.6 kHz
Q0.7
Q1.0
Q1.4
Q2.0
(10 kHz)
6.8 kHz
10 kHz
15 kHz
Q0.7
Q1.0
Q1.4
Q2.0
Band 5
30
Loading...
