JVC HV-28D40BK, HV-32D40BK Parts List

PARTS LIST

CAUTION

J The parts identified by the  symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the

safety.

J The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied.

J P.W. BOARD Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.

ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES

RESISTORS CAPACITORS

CR Carbon Resistor C CAP. Ceramic Capacitor

FR Fusible Resistor E CAP. Electrolytic Capacitor

PR Plate Resistor M CAP. Mylar Capacitor

VR Variable Resistor CH CAP. Chip Capacitor

HV R High Voltage Resistor HV CAP. High Voltage Capacitor

MF R Metal Film Resistor MF CAP. Metalized Film Capacitor

MG R Metal Glazed Resistor MM CAP. Metalized Mylar Capacitor

MP R Metal Plate Resistor MP CAP. Metalized Polystyrol Capacitor

OM R Metal Oxide Film Resistor PP CAP. Polypropylene Capacitor

CMF R Coating Metal Film Resistor PS CAP. Polystyrol Capacitor

UNF R Non-Flammable Resistor TF CAP. Thin Film Capacitor

CH V R Chip Variable Resistor MPP CAP. Metalized Polypropylene Capacitor

CH MG R Chip Metal Glazed Resistor TAN. CAP. Tantalum Capacitor

COMP. R Composition Resistor CH C CAP. Chip Ceramic Capacitor

LPTC R Linear Positive Temperature Coefficient Resistor BP E CAP. Bi-Polar Electrolytic Capacitor

CH AL E CAP. Chip Aluminum Electrolytic Capacitor

CH AL BP CAP. Chip Aluminum Bi-Polar Capacitor

CH TAN. E CAP. Chip Tantalum Electrolytic Capacitor

CH AL BP E CAP. Chip Tantalum Bi-Polar Electrolytic Capacitor

RESISTORS

FGJ KMNRHZP

±1% ±2% ±5% ±10% ±20% ±30%

+30%

-10%

+50%

-10%

+80%

-20%

+100%

-0%

(No.YA087)3-1

CONTENTS

USING P.W. BOARD & REMOTE CONTROL UNIT ................................................................................................... 3-3

EXPLODED VIEW PARTS LIST -1 ............................................................................................................................. 3-3

EXPLODED VIEW -1 ................................................................................................................................................... 3-3

EXPLODED VIEW PARTS LIST -2 ............................................................................................................................. 3-4

EXPLODED VIEW -2 ................................................................................................................................................... 3-5

PRINTED WIRING BOARD PARTS LIST [HV-28D40BK] .......................................................................................... 3-6

MAIN P.W. BOARD ASS'Y (SMM-1011A-U2) ................................................................................................... 3-6

POWER&DEF P.W. BOARD ASS'Y (SMM-2012A-U2) ..................................................................................... 3-8

CRT SOCKET P.W. BOARD ASS'Y (SMM-3012A-U2) ................................................................................... 3-10

FRONT CONTROL P.W. BOARD ASS'Y (SMM-8011A-U2) ........................................................................... 3-11

SIDE CONTROL SW P.W. BOARD ASS'Y (SMM-8111A-U2) ........................................................................ 3-11

LINE FILTER P.W. BOARD ASS'Y (SMM-9011A-U2) ..................................................................................... 3-11

TUNER POWER P.W. BOARD ASS'Y (SMM-9111A-U2) ............................................................................... 3-11

SOUND DELAY P.W. BOARD ASS'Y (SMM0A201A-U2) ............................................................................... 3-12

EHT P.W. BOARD ASS'Y (SMM0E011A-U2) .................................................................................................. 3-12

DEF OSC P.W. BOARD ASS'Y (SMM0H012A-U2) ......................................................................................... 3-13

MI-COM P.W. BOARD ASS'Y (SMM0M011A-U2) ........................................................................................... 3-14

AV SW P.W. BOARD ASS'Y (SMM0S011A-U2) ............................................................................................. 3-15

DIST P.W. BOARD ASS'Y (SMM0Z001A-U2) ................................................................................................. 3-18

PRINTED WIRING BOARD PARTS LIST [HV-32D40BK] ........................................................................................ 3-25

MAIN P.W. BOARD ASS'Y (SMM-1011A-U2) ................................................................................................. 3-25

POWER&DEF P.W. BOARD ASS'Y (SMM-2011A-U2) ................................................................................... 3-25

CRT SOCKET P.W. BOARD ASS'Y (SMM-3011A-U2) ................................................................................... 3-26

FRONT CONTROL P.W. BOARD ASS'Y (SMM-8011A-U2) ........................................................................... 3-27

SIDE CONTROL SW P.W. BOARD ASS'Y (SMM-8111A-U2) ........................................................................ 3-27

LINE FILTER P.W. BOARD ASS'Y (SMM-9011A-U2) ..................................................................................... 3-27

TUNER POWER P.W. BOARD ASS'Y (SMM-9111A-U2) ............................................................................... 3-27

SOUND DELAY P.W. BOARD ASS'Y (SMM0A201A-U2) ............................................................................... 3-27

EHT P.W. BOARD ASS'Y (SMM0E011A-U2) .................................................................................................. 3-27

DEF OSC P.W. BOARD ASS'Y (SMM0H011A-U2) ......................................................................................... 3-27

MI-COM P.W. BOARD ASS'Y (SMM0M011A-U2) ........................................................................................... 3-28

AV SW P.W. BOARD ASS'Y (SMM0S011A-U2) ............................................................................................. 3-28

DIST P.W. BOARD ASS'Y (SMM0Z001A-U2) ................................................................................................. 3-28

REMOTE CONTROL UNIT PARTS LIST (RM-C1805-1C) ....................................................................................... 3-29

PACKING ................................................................................................................................................................... 3-29

PACKING PARTS LIST ............................................................................................................................................. 3-29

3-2(No.YA087)

USING P.W. BOARD & REMOTE CONTROL UNIT

P.W.B ASS'Y HV-28D40BK HV-32D40BK

MAIN P.W.B SMM-1011A-U2 ←

POWER&DEF P.W.B SMM-2012A-U2 SMM-2011A-U2

CRT SOCKET P.W.B SMM-3012A-U2 SMM-3011A-U2

FRONT CONTROL P.W.B SMM-8011A-U2 ← SIDE CONTROL P.W.B SMM-8111A-U2 ← LINE FILTER P.W.B SMM-9011A-U2 ← TUNER POWER P.W.B SMM-9111A-U2 ← SOUND DELAY P.W.B SMM0A201A-U2 ← EHT P.W.B SMM0E011A-U2 ←

DEF OSC P.W.B SMM0H012A-U2 SMM0H011A-U2

MI-COM P.W.B SMM0M011A-U2 ← AV SW P.W.B SMM0S011A-U2 ← DIST P.W.B SMM0Z001A-U2 ← REMOTE CONTROL UNIT RM-C1805-1C ←

EXPLODED VIEW PARTS LIST -1

 Ref.No. Part No. Part Name Description Local

1 LC41780-001A JVC MARK 2 LC32570-001B WINDOW 3 AEM3029-030-E STICK SHEET 4 QAS0200-001 SPEAKER SP01/SP02(x2) 5 QYSBSAG4016N TAP SCREW 4.0mm x 16mm(x8)

 100 LC11831-004A-U FRONT CABINET ASSY Inc.No.101-103 HV-28D40BK  100 LC11832-004A-U FRONT CABINET ASSY Inc.No.101-103 HV-32D40BK

101 LC32569-001B-U POWER KNOB 102 LC32668-001A SPRING 103 LC21424-001B-U SPEAKER PANEL HV-28D40BK 103 LC11744-001B-U SPEAKER PANEL HV-32D40BK

EXPLODED VIEW -1

103

101

102



100

(No.YA087)3-3

EXPLODED VIEW PARTS LIST -2

 Ref.No. Part No. Part Name Description Local

 V01 W66ERF072X044 ITC Inc.DEF YOKE/PC MAGNET HV-28D40BK  V01 W76ERF062X044 ITC Inc.DEF YOKE/PC MAGNET HV-32D40BK  L01 QQW0181-001 DEG COIL HV-28D40BK  L01 QQW0154-001 DEG COIL HV-32D40BK  L03 QQW0130-001 ROTATION COIL  T551 QQH0185-001 FB TRANSF

3 LC30628-002A DEG CLAMP (x4) 4 WJY0024-003A BRAIDED ASSY HV-28D40BK 4 WJY0024-002B BRAIDED ASSY HV-32D40BK 5 WJY0013-002A E-BRAIDED ASSY HV-28D40BK 5 WJY0013-003A E-BRAIDED ASSY HV-32D40BK

 6 LC11854-001B-U LINE FILTER BASE HV-28D40BK  6 LC11854-002C-U LINE FILTER BASE HV-32D40BK  7 LC11795-001C-U CONTROL BASE HV-28D40BK  7 LC11795-002C-U CONTROL BASE HV-32D40BK  8 LC11643-001A-U CHASSIS BASE

9 LC32516-001B-U HVT HOLDER

 10 LC11647-003B-U AV BOARD

11 LC41840-001A-U SLOT COVER 12 QYSBSF3012M TAP SCREW 3.0mm x 12mm 13 QYSBSG3006ZA TAP SCREW M3 x 6mm(x3) 14 QNB0081-001 HEX SCREW (x2) 15 QNB0112-002 ANTENNA TERMINAL 16 QYSBSF3012M TAP SCREW 3.0mm x 12mm(x7)

 17 QMPN130-185-JC POWER CORD(EK) 1.85m BLACK  18 LC21383-001C-U POWER CORD CLAMP

19 LC21388-001A-C SHIELD COVER 20 LC32584-003A-C CONTROL SHEET 21 LC11825-001B-U SIDE CONTROL BASE 22 QYSBSFG3010Z TAP SCREW M3 x 10mm(x2) HV-28D40BK 22 QYSBSF3010Z TAP SCREW 3mm x 10mm(x2) HV-32D40BK 23 QYSBSAG4016N TAP SCREW 4.0mm x 16mm 24 QYSBSAG4016N TAP SCREW 4.0mm x 16mm(x8)

 25 LC11707-002C-U REAR COVER HV-28D40BK  25 LC11770-002B-U REAR COVER HV-32D40BK

26 QYSBSAG4016N TAP SCREW 4.0mm x 16mm(x15)

 27 LC11364-062A-U RATING LABEL HV-28D40BK  27 LC11364-061A-U RATING LABEL HV-32D40BK  28 QQR0491-001 FERRITE CORE (GRAY)(x2)  29 QQR1193-001 CORE FILTER  30 QQR0491-001 FERRITE CORE (GRAY)

 41 SMM-3012A-U2 CRT SOCKET PWB HV-28D40BK  41 SMM-3011A-U2 CRT SOCKET PWB HV-32D40BK  42 SMM-9011A-U2 LINE FILTER PWB  43 SMM-8011A-U2 FRONT CONTROL PWB  44 QAU0358-001 DIGITAL TUNER UNIT  45 SMM-9111A-U2 TUNER POWER PWB  46 SMM0E011A-U2 EHT PWB  47 SMM-2012A-U2 POWER&DEF PWB HV-28D40BK  47 SMM-2011A-U2 POWER&DEF PWB HV-32D40BK  48 SMM0H012A-U2 DEF OSC PWB HV-28D40BK  48 SMM0H011A-U2 DEF OSC PWB HV-32D40BK  49 SMM0S011A-U2 AV SW PWB  50 SMM0Z001A-U2 DIST PWB  51 SMM-1011A-U2 MAIN PWB  52 SMM0A201A-U2 SOUND DELAY PWB  53 SMM0M011A-U2 MI-COM PWB  54 SMM-8111A-U2 SIDE CONTROL PWB

3-4(No.YA087)

EXPLODED VIEW -2



L01



V01



L03



T551



(No.YA087)3-5

PRINTED WIRING BOARD PARTS LIST [HV-28D40BK]



MAIN P.W. BOARD ASS'Y (SMM-1011A-U2)



Ref No. Part No. Part Name Description Local

IC101 MSP3411GQAC1201 IC IC201 TA1370FG-X IC IC202 SN74AHC1G08V-X IC IC251 AN15851A-W IC IC252 MM1503XN-X IC IC281 SN74LVC74APW-X IC IC282 SN74AHC2G08T-X IC IC283 SN74AHC2GU04T-X IC IC284 SN74LVC74APW-X IC IC401 SN74HC08NS-X IC IC402 SN74HC14NS-X IC IC551 LA6515 IC IC601 HA17558AF-X IC IC641 AN5277 IC IC701 CXA1875AM-X IC IC721 BU2098F-X IC IC781 AT24C25628D40BK IC (SERVICE) IC901 BA12T IC IC902 BA09T IC IC903 SI-8050JD-W IC IC904 SI-8033JD-W IC IC906 AN77L08-T IC

Q101 2SC3928A/QR/-X TRANSISTOR Q103 2SC3928A/QR/-X TRANSISTOR Q104 UN2213-X DIGI TRANSISTOR Q257 2SC3928A/QR/-X TRANSISTOR Q258 2SC3928A/QR/-X TRANSISTOR Q259 2SC3928A/QR/-X TRANSISTOR Q266 2SC3928A/QR/-X TRANSISTOR Q267 2SC3928A/QR/-X TRANSISTOR Q268 2SC3928A/QR/-X TRANSISTOR Q281 UN2213-X DIGI TRANSISTOR Q282 UN2213-X DIGI TRANSISTOR Q283 UN2213-X DIGI TRANSISTOR Q351 2SC3928A/QR/-X TRANSISTOR Q361 2SC3928A/QR/-X TRANSISTOR Q561 2SA1530A/QR/-X TRANSISTOR Q562 2SC3928A/QR/-X TRANSISTOR Q563 2SA1530A/QR/-X TRANSISTOR Q652 2SA1530A/QR/-X TRANSISTOR Q654 UN2226-X DIGI TRANSISTOR Q655 UN2226-X DIGI TRANSISTOR Q659 UN2210-X DIGI TRANSISTOR Q660 UN2212-X TRANSISTOR Q681 2SA1530A/QR/-X TRANSISTOR Q751 2SC3928A/QR/-X TRANSISTOR Q752 2SC3928A/QR/-X TRANSISTOR Q753 2SC3928A/QR/-X TRANSISTOR Q754 2SC3928A/QR/-X TRANSISTOR Q755 2SA1530A/QR/-X TRANSISTOR Q756 2SA1530A/QR/-X TRANSISTOR

D401 MA8039/H/-X Z DIODE D421 MA8039/H/-X Z DIODE D422 MA111-X SI DIODE D561 MA8220/M/-X Z DIODE D562 MA111-X SI DIODE D601 MA8047/L/-X Z DIODE D609 MA111-X SI DIODE D641 MA8330/M/-X Z DIODE D643 MA8330/M/-X Z DIODE D656 MA111-X SI DIODE D657 MA111-X SI DIODE D662 MA111-X SI DIODE D663 MA111-X SI DIODE D681 MA111-X SI DIODE D682 MA111-X SI DIODE D683 MA111-X SI DIODE D684 MA111-X SI DIODE D685 MA111-X SI DIODE D701 MA8033/H/-X Z DIODE D702 MA8039/H/-X Z DIODE D751 MA8068/M/-X Z DIODE D752 MA111-X SI DIODE D771 MA8056/M/-X Z DIODE D772 MA8056/M/-X Z DIODE D773 MA8056/M/-X Z DIODE D774 MA8056/M/-X Z DIODE D903 EC30HA03L-X SB DIODE D904 EC30HA03L-X SB DIODE D905 PTZ6.8B-X Z DIODE

Ref No. Part No. Part Name Description Local

D991 MA111-X SI DIODE D992 MA111-X SI DIODE D993 MA111-X SI DIODE D994 MA111-X SI DIODE

C001 NCB31HK-222X C CAPACITOR 2200pF 50V K C002 QETN1HM-106Z E CAPACITOR 10uF 50V M C004 NCB31CK-104X C CAPACITOR 0.1uF 16V K C005 QETN1CM-108Z E CAPACITOR 1000uF 16V M C006 NCB31HK-103X C CAPACITOR 0.01uF 50V K C007 QETN1HM-106Z E CAPACITOR 10uF 50V M C009 NCB31CK-104X C CAPACITOR 0.1uF 16V K C010 QETN1HM-106Z E CAPACITOR 10uF 50V M C012 NCB31CK-104X C CAPACITOR 0.1uF 16V K C013 QETN1HM-106Z E CAPACITOR 10uF 50V M C014 NDC31HJ-470X C CAPACITOR 47pF 50V J C015 NDC31HJ-470X C CAPACITOR 47pF 50V J C016 NDC31HJ-330X C CAPACITOR 33pF 50V J C101 NCB31HK-103X C CAPACITOR 0.01uF 50V K C102 NCB31HK-103X C CAPACITOR 0.01uF 50V K C104 NCB31HK-103X C CAPACITOR 0.01uF 50V K C107 QETN1HM-106Z E CAPACITOR 10uF 50V M C110 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J C111 NCB31HK-103X C CAPACITOR 0.01uF 50V K C112 NCB31HK-103X C CAPACITOR 0.01uF 50V K C113 NCB31HK-103X C CAPACITOR 0.01uF 50V K C114 QETN1HM-106Z E CAPACITOR 10uF 50V M C115 NCB31CK-104X C CAPACITOR 0.1uF 16V K C116 QETN1HM-106Z E CAPACITOR 10uF 50V M C117 NDC31HJ-2R0X C CAPACITOR 2pF 50V J C118 NDC31HJ-2R0X C CAPACITOR 2pF 50V J C119 NCB31CK-104X C CAPACITOR 0.1uF 16V K C120 QETN1CM-107Z E CAPACITOR 100uF 16V M C121 NCB31HK-103X C CAPACITOR 0.01uF 50V K C122 NDC31HJ-102X C CAPACITOR 1000pF 50V J C123 NDC31HJ-102X C CAPACITOR 1000pF 50V J C124 NDC31HJ-102X C CAPACITOR 1000pF 50V J C125 NDC31HJ-102X C CAPACITOR 1000pF 50V J C126 NDC31HJ-102X C CAPACITOR 1000pF 50V J C127 QETN1HM-106Z E CAPACITOR 10uF 50V M C130 NCB31CK-104X C CAPACITOR 0.1uF 16V K C131 QETN1HM-106Z E CAPACITOR 10uF 50V M C132 NCB31CK-104X C CAPACITOR 0.1uF 16V K C133 QETN1HM-106Z E CAPACITOR 10uF 50V M C140 NCB31CK-104X C CAPACITOR 0.1uF 16V K C141 QETN1HM-106Z E CAPACITOR 10uF 50V M C142 NCB21AK-105X C CAPACITOR 1uF 10V K C201 NCB31HK-123X C CAPACITOR 0.012uF 50V K C202 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C203 QETN1CM-107Z E CAPACITOR 100uF 16V M C204 NCB31HK-103X C CAPACITOR 0.01uF 50V K C205 QENC1HM-105Z BP E CAPACITOR 1uF 50V M C206 QENC1HM-105Z BP E CAPACITOR 1uF 50V M C207 NCB31HK-104X C CAPACITOR 0.1uF 50V K C251 NCB31HK-103X C CAPACITOR 0.01uF 50V K C252 NCB31HK-103X C CAPACITOR 0.01uF 50V K C253 NCB31HK-103X C CAPACITOR 0.01uF 50V K C254 NCB31HK-103X C CAPACITOR 0.01uF 50V K C255 NCB31HK-103X C CAPACITOR 0.01uF 50V K C256 QENC1HM-105Z BP E CAPACITOR 1uF 50V M C257 QENC1HM-105Z BP E CAPACITOR 1uF 50V M C258 QENC1HM-105Z BP E CAPACITOR 1uF 50V M C259 NCB31HK-103X C CAPACITOR 0.01uF 50V K C260 NCB31HK-103X C CAPACITOR 0.01uF 50V K C261 QETN1HM-105Z E CAPACITOR 1uF 50V M C262 QETN1HM-105Z E CAPACITOR 1uF 50V M C263 QETN1HM-105Z E CAPACITOR 1uF 50V M C264 NCB31HK-103X C CAPACITOR 0.01uF 50V K C265 NCB31HK-103X C CAPACITOR 0.01uF 50V K C266 QETN1HM-105Z E CAPACITOR 1uF 50V M C267 QETN1HM-105Z E CAPACITOR 1uF 50V M C268 QETN1HM-105Z E CAPACITOR 1uF 50V M C269 NCB31HK-103X C CAPACITOR 0.01uF 50V K C270 NCB31HK-103X C CAPACITOR 0.01uF 50V K C271 NCB31HK-103X C CAPACITOR 0.01uF 50V K C272 QETN1CM-107Z E CAPACITOR 100uF 16V M C273 QETN1CM-107Z E CAPACITOR 100uF 16V M C274 NCB31HK-103X C CAPACITOR 0.01uF 50V K C275 QENC1CM-106Z BP E CAPACITOR 10uF 16V M C276 QENC1CM-106Z BP E CAPACITOR 10uF 16V M C277 NCB31HK-104X C CAPACITOR 0.1uF 50V K C278 NCB31HK-104X C CAPACITOR 0.1uF 50V K C279 NCB31HK-104X C CAPACITOR 0.1uF 50V K C280 QETN1CM-476Z E CAPACITOR 47uF 16V M

3-6(No.YA087)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C281 NCB31HK-104X C CAPACITOR 0.1uF 50V K C282 NCB31HK-104X C CAPACITOR 0.1uF 50V K C352 NDC31HJ-271X C CAPACITOR 270pF 50V J C362 NCB31HK-682X C CAPACITOR 6800pF 50V K C405 NCB31HK-104X C CAPACITOR 0.1uF 50V K C406 NCB31HK-104X C CAPACITOR 0.1uF 50V K C407 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M C411 NDC31HJ-150X C CAPACITOR 15pF 50V J C421 NCB31HK-102X C CAPACITOR 1000pF 50V K C433 QETN1CM-108Z E CAPACITOR 1000uF 16V M C434 NCB31CK-104X C CAPACITOR 0.1uF 16V K C435 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M C439 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M C440 NCB31HK-104X C CAPACITOR 0.1uF 50V K C551 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z C552 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z C553 QETN1EM-476Z E CAPACITOR 47uF 25V M C554 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z C555 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z C560 QETN1CM-107Z E CAPACITOR 100uF 16V M C602 QENC1HM-105Z BP E CAPACITOR 1uF 50V M C603 QENC1HM-105Z BP E CAPACITOR 1uF 50V M C604 QETN1CM-107Z E CAPACITOR 100uF 16V M C605 QETN1CM-107Z E CAPACITOR 100uF 16V M C606 NCB31HK-153X C CAPACITOR 0.015uF 50V K C607 NCB31HK-153X C CAPACITOR 0.015uF 50V K C608 NCB31HK-122X C CAPACITOR 1200pF 50V K C609 NCB31HK-122X C CAPACITOR 1200pF 50V K C610 NCB31HK-223X C CAPACITOR 0.022uF 50V K C611 NCB31HK-223X C CAPACITOR 0.022uF 50V K C612 QENC1HM-106Z BP E CAPACITOR 10uF 50V M C613 QENC1HM-106Z BP E CAPACITOR 10uF 50V M C641 QETN1HM-106Z E CAPACITOR 10uF 50V M C642 QETN1HM-106Z E CAPACITOR 10uF 50V M C645 QETN1HM-107Z E CAPACITOR 100uF 50V M C649 QETM1VM-228 E CAPACITOR 2200uF 35V M C654 QETN1VM-108Z E CAPACITOR 1000uF 35V M C655 QETN1VM-108Z E CAPACITOR 1000uF 35V M C662 QETN1HM-335Z E CAPACITOR 3.3uF 50V M C666 QETN1HM-106Z E CAPACITOR 10uF 50V M C681 QETM1EM-228 E CAPACITOR 2200uF 25V M C721 QETN1HM-106Z E CAPACITOR 10uF 50V M C722 NCB31CK-563X C CAPACITOR 0.056uF 16V K C741 NDC31HJ-100X C CAPACITOR 10pF 50V J C742 NDC31HJ-270X C CAPACITOR 27pF 50V J C744 NCB31HK-104X C CAPACITOR 0.1uF 50V K C751 NCB31HK-104X C CAPACITOR 0.1uF 50V K C753 NCB31HK-104X C CAPACITOR 0.1uF 50V K C754 QETN1CM-476Z E CAPACITOR 47uF 16V M C781 NCB31HK-104X C CAPACITOR 0.1uF 50V K C901 QETN1EM-107Z E CAPACITOR 100uF 25V M C902 QETN1CM-227Z E CAPACITOR 220uF 16V M C903 QETN1CM-107Z E CAPACITOR 100uF 16V M C905 QETN1CM-227Z E CAPACITOR 220uF 16V M C906 QETN1CM-227Z E CAPACITOR 220uF 16V M C907 QETM1EM-228 E CAPACITOR 2200uF 25V M C909 QEZ0256-128 E CAPACITOR 1200uF 10V M C911 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M C912 QETM1EM-228 E CAPACITOR 2200uF 25V M C914 QEZ0256-128 E CAPACITOR 1200uF 10V M C916 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M C919 QETN1CM-107Z E CAPACITOR 100uF 16V M C920 QETN1CM-107Z E CAPACITOR 100uF 16V M

Ω

R002 NRSA63J-0R0X MG RESISTOR 0 R004 NRSA63J-101X MG RESISTOR 100 R005 NRSA63J-101X MG RESISTOR 100 R012 NRSA63J-101X MG RESISTOR 100 R013 NRSA63J-0R0X MG RESISTOR 0 R101 NRSA63J-102X MG RESISTOR 1k R106 NRSA63J-0R0X MG RESISTOR 0 R108 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R109 NRSA63J-681X MG RESISTOR 680 R110 NRSA63J-331X MG RESISTOR 330 R111 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R112 NRSA63J-102X MG RESISTOR 1k R113 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R118 NRSA63J-101X MG RESISTOR 100 R119 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R120 NRSA63J-103X MG RESISTOR 10k R121 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R122 NRSA63J-0R0X MG RESISTOR 0 R123 NRSA63J-0R0X MG RESISTOR 0 R201 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R202 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R203 NRSA63J-682X MG RESISTOR 6.8k R204 NRSA63J-272X MG RESISTOR 2.7k

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R205 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R206 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R207 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R208 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R209 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R210 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R211 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R212 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R216 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R251 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R252 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R253 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R257 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R258 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R259 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R260 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R261 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R262 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R266 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R267 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R268 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R269 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R270 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R271 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R281 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R282 NRSA63J-472X MG RESISTOR 4.7k R283 NRSA63J-151X MG RESISTOR 150 R351 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R352 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R353 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R361 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R362 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R401 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R402 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R404 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R405 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R407 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R418 NRSA63J-820X MG RESISTOR 82Ω 1/16W J R421 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R422 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R551 QRK126J-100X UNF C RESISTOR 10Ω 1/2W J R552 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J R553 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J R554 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R555 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R556 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R557 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R558 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R559 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J R560 QRK126J-100X UNF C RESISTOR 10Ω 1/2W J R562 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R563 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R564 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R565 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R566 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R567 NRSA63J-562X MG RESISTOR 5.6k R568 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R601 NRSA63J-333X MG RESISTOR 33k R602 NRSA63J-333X MG RESISTOR 33k R603 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R605 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R606 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R607 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R608 NRSA63J-102X MG RESISTOR 1k R609 NRSA63J-332X MG RESISTOR 3.3k R610 NRSA63J-332X MG RESISTOR 3.3k R611 NRSA63J-102X MG RESISTOR 1k R612 NRSA63J-102X MG RESISTOR 1k R613 NRSA63J-221X MG RESISTOR 220 R614 NRSA63J-221X MG RESISTOR 220 R615 NRSA63J-472X MG RESISTOR 4.7k R616 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R618 NRSA63J-104X MG RESISTOR 100k R619 NRSA63J-104X MG RESISTOR 100k R641 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R643 NRSA63J-103X MG RESISTOR 10k R647 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J R653 NRSA63J-472X MG RESISTOR 4.7k R655 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R657 NRSA63J-0R0X MG RESISTOR 0 R658 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R664 NRSA63J-103X MG RESISTOR 10k R665 NRSA63J-473X MG RESISTOR 47k R666 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R667 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R669 NRSA63J-0R0X MG RESISTOR 0 R681 NRSA63J-104X MG RESISTOR 100k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.YA087)3-7



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R682 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R701 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R703 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R704 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R705 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R706 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R707 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R708 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R709 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R710 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R711 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R712 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R721 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R722 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R723 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R724 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R725 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R726 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R727 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R728 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R730 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R737 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R738 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R751 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R752 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R753 NRSA63J-103X MG RESISTOR 10k R754 NRSA63J-273X MG RESISTOR 27k R755 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R756 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R757 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R758 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R759 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R760 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R761 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R762 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R763 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R764 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R765 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R772 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R773 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R774 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R775 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R776 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R781 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R782 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R783 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R784 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R907 QRK126J-220X UNF C RESISTOR 22Ω 1/2W J R908 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R910 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R911 QRK126J-5R6X UNF C RESISTOR 5.6Ω 1/2W J R912 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R914 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

L001 QQL244K-270Z PEAKING COIL 27uH K L002 QQL244K-100Z PEAKING COIL 10uH K L003 QQL244K-100Z PEAKING COIL 10uH K L103 QRN143J-0R0X C RESISTOR 0Ω 1/4W J L104 QQL244K-4R7Z PEAKING COIL 4.7uH K L201 QRN143J-0R0X C RESISTOR 0 L281 QRN143J-0R0X C RESISTOR 0Ω 1/4W J L432 QQL26AK-100Z COIL 10uH K L433 QQL26AK-100Z COIL 10uH K L903 QQL50AK-330Z COIL 33uH K L905 QQR1401-001 CHOKE COIL L906 QQL26AK-220Z CHOKE COIL 22uH K L907 QQL26AK-820Z CHOKE COIL 82uH K L908 QQR1401-001 CHOKE COIL L909 QQL50AK-100Z COIL 10uH K

CN001 QGB1506L1-16 CONNECTOR B-B (1-16) CN002 QGB1506L1-16 CONNECTOR B-B (1-16) CN003 QGB1506L1-16 CONNECTOR B-B (1-16) CN004 QGB2023M1-30 CONNECTOR B-B (1-30) CN005 QGB2023M1-30 CONNECTOR B-B (1-30) CN006 QGB1505J1-25 CONNECTOR B-B (1-25) CN007 QGB1505J1-35 CONNECTOR B-B (1-35) CN008 QGB1509J1-55 CONNECTOR B-B (1-55) CN009 QGB1509J1-55 CONNECTOR B-B (1-55) CN00B QJK002-061401 SIN CR C-B WIRE CN012 QGB1505J1-25 CONNECTOR B-B (1-25) CN0U2 QJK002-043614 SIN CR C-B WIRE HS641 LC32265-001A HEAT SINK/AL-F/ HS901 CEHT11B-002QS HEAT SINK HS902 CEHT11B-002QS HEAT SINK K001 NQR0389-003X FERRITE BEADS K101 NQR0389-003X FERRITE BEADS

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

K102 NQR0389-003X FERRITE BEADS K901 QRN143J-0R0X C RESISTOR 0Ω 1/4W J K903 QRN143J-0R0X C RESISTOR 0Ω 1/4W J K904 QQR0582-001Z FERRITE BEADS LC101 NQR0431-001X EMI FILTER 0.22uF 50V Z TU001 QAU0363-001 TUNER X101 QAX0773-001Z CRYSTAL 18.432000MHz X201 CSB503F30-T2 C RESONATOR

POWER&DEF P.W. BOARD ASS'Y (SMM-2012A-U2)



Ref No. Part No. Part Name Description Local

IC401 LA78041 IC IC901 STR-F6268S-F7 IC IC951 SE140N IC

Q401 KTC3199/YG/-T TRANSISTOR Q402 KTC3199/YG/-T TRANSISTOR Q461 2SC1959/Y/-T TRANSISTOR Q462 2SA562TM/Y/-T TRANSISTOR Q463 2SK2417 POWER MOS FET Q501 KTC3199/YG/-T TRANSISTOR Q502 2SC1627A/Y/-T TRANSISTOR



Q522 2SC5909-RL POW TRANSISTOR H.OUT Q523 KTC3199/YG/-T TRANSISTOR Q551 2SK2655-01R POWER MOS FET Q553 2SC1959/Y/-T TRANSISTOR Q554 2SA562TM/Y/-T TRANSISTOR Q941 KTC3199/YG/-T TRANSISTOR Q942 KTA1267/YG/-T TRANSISTOR Q943 KTC3199/YG/-T TRANSISTOR Q951 2SA1371/EF/Z1-T SI TRANSISTOR Q952 KTC3199/YG/-T TRANSISTOR Q953 2SC1627A/Y/-T TRANSISTOR Q954 DTC124ESA-T DIGI TRANSISTOR

D401 RD100E/B/-T2 Z DIODE D402 1SR35-400A-T2 SI DIODE D404 1SS133-T2 DIODE D405 1SS133-T2 DIODE D406 MTZJ6.8C-T2 Z DIODE D407 MTZJ6.8C-T2 Z DIODE D461 RGP10J-04TS-T3 SI DIODE D501 1SS133-T2 DIODE D522 V11CA-C1 SI DIODE D523 FMV-3FU-F1 SI DIODE D524 RG2A-LFC4 SI DIODE D525 1SS81-T5 SI DIODE D526 MTZJ12C-T2 Z DIODE D527 MTZJ15B-T2 Z DIODE D528 MTZJ15B-T2 Z DIODE D550 RU4DS-F1 SI DIODE D551 1SR124-400A-T2 SI DIODE D553 RGP10J-04TS-T3 SI DIODE D554 QRE141J-0R0Y C RESISTOR 0Ω 1/4W J D555 RU1P-T3 SI DIODE D556 1SR35-400A-T2 SI DIODE D557 MTZJ9.1B-T2 Z DIODE D701 RH1S-T3 SI DIODE D702 RU3AM-LFC4 SI DIODE D703 RU3AM-LFC4 SI DIODE D901 D3SB60 BRIDGE DIODE D902 RG1C-LFA1 SI DIODE D904 RGP10J-04TS-T3 SI DIODE D905 RGP10J-04TS-T3 SI DIODE D906 MTZJ39C-T2 Z DIODE D907 1SS133-T2 DIODE D911 MTZJ15B-T2 Z DIODE D942 1SS133-T2 DIODE D944 1SS133-T2 DIODE D951 RU4B-F1 SI DIODE D952 RU4B-F1 SI DIODE D953 RGP10J-04TS-T3 SI DIODE D954 FMB-G16L SI DIODE D955 RU3YX-LFC4 SI DIODE D956 FMX-G12S SI DIODE D958 MTZJ7.5S-T2 Z DIODE D959 MTZJ33B-T2 Z DIODE D960 MTZJ15B-T2 Z DIODE D961 1SS133-T2 DIODE D962 1SS133-T2 DIODE D963 1SS133-T2 DIODE D964 MTZJ9.1B-T2 Z DIODE

3-8(No.YA087)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

D965 1SS133-T2 DIODE D966 1SS133-T2 DIODE D968 1SS133-T2 DIODE D969 1SS133-T2 DIODE

C401 QENC1EM-106Z BP E CAPACITOR 10uF 25V M C402 QFLC1HJ-392Z M CAPACITOR 3900pF 50V J C403 QCS32HJ-180Z C CAPACITOR 18pF 500V J C404 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J C405 QFLB2AJ-224 M CAPACITOR 0.22uF 100V J C406 QETN1VM-108Z E CAPACITOR 1000uF 35V M C407 QETN1VM-337Z E CAPACITOR 330uF 35V M C409 QETN1HM-105Z E CAPACITOR 1uF 50V M C412 QCB31HK-222Z C CAPACITOR 2200pF 50V K C413 QETN1HM-106Z E CAPACITOR 10uF 50V M C461 QCB32HK-561Z C CAPACITOR 560pF 500V K C463 QFM72DJ-122Z M CAPACITOR 1200pF 200V J C464 QFM72DK-472Z M CAPACITOR 4700pF 200V K C501 QETN1EM-476Z E CAPACITOR 47uF 25V M C502 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J C503 QEM61HK-475Z E CAPACITOR 4.7uF 50V K C504 QCB32HK-561Z C CAPACITOR 560pF 500V K C505 QCB32HK-391Z C CAPACITOR 390pF 500V K C506 QETN1HM-105Z E CAPACITOR 1uF 50V M C522 QFZ0196-113 MPP CAPACITOR 0.011uF 1.5kV H C524 QFP32JJ-183 PP CAPACITOR 0.018uF 630V J C525 QEZ0414-226 BP E CAPACITOR 22uF 50V M C526 QFZ0128-254 MPP CAPACITOR 0.25uF DC400V H C527 QFZ0197-124 MPP CAPACITOR 0.12uF 250V J C528 QFZ0128-154 MPP CAPACITOR 0.15uF DC400V H C529 QCS32HJ-561 C CAPACITOR 560pF 500V J C530 QCZ0340-681 C CAPACITOR 680pF 2kV K C531 QCZ0340-681 C CAPACITOR 680pF 2kV K C532 QFLC2AJ-682Z M CAPACITOR 6800pF 100V J C533 QCB31HK-682Z C CAPACITOR 6800pF 50V K C534 QCS31HJ-470Z C CAPACITOR 47pF 50V J C535 QFP42JJ-682 PP CAPACITOR 6800pF 630V J C536 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J C537 QFZ0197-684 MPP CAPACITOR 0.68uF 250V J C551 QETN1HM-106Z E CAPACITOR 10uF 50V M C552 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C554 QFZ0196-352 MPP CAPACITOR 3500pF 1.5kV H C556 QEZ0203-107 E CAPACITOR 100uF 160V M C559 QTMN1HM-475Z E CAPACITOR 4.7uF 50V M C560 QFVF1HJ-334Z MF CAPACITOR 0.33uF 50V J C701 QEZ0203-107 E CAPACITOR 100uF 160V M C702 QETN2EM-475Z E CAPACITOR 4.7uF 250V M C703 QETN1EM-108Z E CAPACITOR 1000uF 25V M C704 QETN1EM-108Z E CAPACITOR 1000uF 25V M C705 QFLC2AJ-393Z M CAPACITOR 0.039uF 100V J



C903 QCZ9054-472 C CAPACITOR 4700pF AC250V Z



C904 QCZ9054-472 C CAPACITOR 4700pF AC250V Z



C905 QCZ9054-472 C CAPACITOR 4700pF AC250V Z C906 QEZ0649-337 E CAPACITOR 330uF 400V M C907 QCB32HK-103 C CAPACITOR 0.01uF 500V K C908 QCZ0340-391 C CAPACITOR 390pF 2kV K C909 QCB32HK-152Z C CAPACITOR 1500pF 500V K C910 QETN1HM-476Z E CAPACITOR 47uF 50V M C911 QCZ0340-561 C CAPACITOR 560pF 2kV K C912 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J C913 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J C914 QCS31HJ-221Z C CAPACITOR 220pF 50V J C915 QETN1HM-475Z E CAPACITOR 4.7uF 50V M



C916 QFZ9072-473 MM CAPACITOR 0.047uF AC250V K C943 QETN1HM-106Z E CAPACITOR 10uF 50V M C951 QCZ0325-821 C CAPACITOR 820pF 2kV K C952 QEZ0203-227 E CAPACITOR 220uF 160V M C953 QCB32HK-152Z C CAPACITOR 1500pF 500V K C954 QETN1HM-227Z E CAPACITOR 220uF 50V M C955 QCB32HK-561Z C CAPACITOR 560pF 500V K C956 QEZ0257-228 E CAPACITOR 2200uF 25V M C957 QCB32HK-152Z C CAPACITOR 1500pF 500V K C958 QETN1EM-477Z E CAPACITOR 470uF 25V M C959 QCB32HK-152Z C CAPACITOR 1500pF 500V K C960 QETM1VM-338 E CAPACITOR 3300uF 35V M C963 QFVF1HJ-684Z MF CAPACITOR 0.68uF 50V J C966 QETN1HM-105Z E CAPACITOR 1uF 50V M C967 QETN1CM-107Z E CAPACITOR 100uF 16V M C968 QETN1EM-476Z E CAPACITOR 47uF 25V M C969 QETN1EM-476Z E CAPACITOR 47uF 25V M C970 QETN1CM-107Z E CAPACITOR 100uF 16V M C999 QCZ9079-101 C CAPACITOR 100pF AC250V K

R401 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R402 QRA14CF-5601Y CMF RESISTOR 5.6kΩ 1/4W F R403 QRA14CF-1002Y CMF RESISTOR 10k R404 QRE121J-180Y C RESISTOR 18

Ω

1/4W F

Ω

1/2W J

R405 QRA14CF-6801Y CMF RESISTOR 6.8kΩ 1/4W F R406 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R407 QRA14CF-3301Y CMF RESISTOR 3.3kΩ 1/4W F R408 QRA14CF-8200Y CMF RESISTOR 820Ω 1/4W F R409 QRA14CF-8200Y CMF RESISTOR 820Ω 1/4W F R410 QRL029J-151 OMF RESISTOR 150Ω 2W J R411 QRX029J-2R2 MF RESISTOR 2.2Ω 2W J R412 QRE121J-8R2Y C RESISTOR 8.2Ω 1/2W J R414 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R415 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R416 QRE141J-101Y C RESISTOR 100Ω 1/4W J R417 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R418 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R461 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R462 QRE141J-470Y C RESISTOR 47Ω 1/4W J R465 QRL029J-102 OMF RESISTOR 1kΩ 2W J R466 QRL029J-820 OMF RESISTOR 82Ω 2W J R467 QRL029J-820 OMF RESISTOR 82Ω 2W J R468 QRL039J-332 OMF RESISTOR 3.3kΩ 3W J R501 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R502 QRE121J-271Y C RESISTOR 270Ω 1/2W J R503 QRE141J-820Y C RESISTOR 82Ω 1/4W J R504 QRL039J-221 OMF RESISTOR 220Ω 3W J R505 QRL039J-271 OMF RESISTOR 270Ω 3W J R506 QRE121J-102Y C RESISTOR 1kΩ 1/2W J R524 QRE121J-220Y C RESISTOR 22 R525 QRL029J-821 OMF RESISTOR 820 R526 QRE141J-333Y C RESISTOR 33kΩ 1/4W J R527 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R528 QRE141J-470Y C RESISTOR 47Ω 1/4W J R529 QRE141J-822Y C RESISTOR 8.2kΩ 1/4W J R530 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R531 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R532 QRE141J-101Y C RESISTOR 100Ω 1/4W J R533 QRF054J-470 UNF WW RESISTOR 47Ω 5W J R535 QRE141J-330Y C RESISTOR 33Ω 1/4W J R537 QRE141J-102Y C RESISTOR 1kΩ 1/4W J



R551 QRZ9017-4R7 FUSI RESISTOR 4.7Ω 1/4W J R552 QRA14CF-2702Y CMF RESISTOR 27kΩ 1/4W F R554 QRA14CF-2702Y CMF RESISTOR 27kΩ 1/4W F R557 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R558 QRM059J-R15 MP RESISTOR 0.15Ω 5W J R564 QRE141J-274Y C RESISTOR 270kΩ 1/4W J R565 QRA14CF-1503Y CMF RESISTOR 150kΩ 1/4W F R566 QRA14CF-1503Y CMF RESISTOR 150kΩ 1/4W F R567 QRA14CF-1503Y CMF RESISTOR 150kΩ 1/4W F R568 QRA14CF-5601Y CMF RESISTOR 5.6kΩ 1/4W F



R701 QRZ9009-1R5 FUSI RESISTOR 1.5Ω 1/2W J



R702 QRZ9011-2R7 FUSI RESISTOR 2.7Ω 1/2W J



R703 QRZ9011-2R7 FUSI RESISTOR 2.7Ω 1/2W J R704 QRG01GJ-220 OMF RESISTOR 22Ω 1W J R705 QRE121J-123Y C RESISTOR 12kΩ 1/2W J R706 QRX01GJ-3R3 MF RESISTOR 3.3Ω 1W J R901 QRF154K-4R7 UNF WW RESISTOR 4.7Ω 15W K R902 QRE121J-474Y C RESISTOR 470kΩ 1/2W J R903 QRE121J-474Y C RESISTOR 470k R905 QRL039J-823 OMF RESISTOR 82kΩ 3W J R906 QRL039J-823 OMF RESISTOR 82k R907 QRL039J-683 OMF RESISTOR 68k



R908 QRZ9017-4R7 FUSI RESISTOR 4.7Ω 1/4W J R909 QRE121J-152Y C RESISTOR 1.5kΩ 1/2W J R911 QRE121J-152Y C RESISTOR 1.5kΩ 1/2W J R912 QRE121J-221Y C RESISTOR 220Ω 1/2W J R913 QRM059J-R10 MP RESISTOR 0.1 R915 QRE121J-331Y C RESISTOR 330 R917 QRE141J-154Y C RESISTOR 150k R944 QRE141J-273Y C RESISTOR 27k R945 QRE141J-123Y C RESISTOR 12k R946 QRE141J-682Y C RESISTOR 6.8k R947 QRE141J-333Y C RESISTOR 33k R951 QRL039J-681 OMF RESISTOR 680 R952 QRE121J-103Y C RESISTOR 10kΩ 1/2W J R958 QRL029J-821 OMF RESISTOR 820 R959 QRX029J-1R2 MF RESISTOR 1.2 R960 QRX029J-1R5 MF RESISTOR 1.5Ω 2W J R962 QRE121J-392Y C RESISTOR 3.9k R963 QRE121J-223Y C RESISTOR 22kΩ 1/2W J R964 QRE141J-473Y C RESISTOR 47k R965 QRE141J-333Y C RESISTOR 33kΩ 1/4W J R966 QRE141J-102Y C RESISTOR 1k R967 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R968 QRE141J-562Y C RESISTOR 5.6k R969 QRE141J-104Y C RESISTOR 100k R971 QRG01GJ-181 OMF RESISTOR 180Ω 1W J R972 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R974 QRE141J-103Y C RESISTOR 10k R975 QRE141J-683Y C RESISTOR 68k

Ω

1/2W J

Ω

1/2W J

Ω Ω

Ω

1/2W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω Ω

Ω

1/2W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

2W J

3W J 3W J

5W J

3W J

2W J 2W J

(No.YA087)3-9



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R976 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J



R999 QRZ9046-825Z C RESISTOR 8.2MΩ 1/2W K

L461 QQR1425-001 CHOKE COIL L523 QQR1425-001 CHOKE COIL L524 QQR1423-001 CHOKE COIL L525 QQR1149-006 LINEARITY COIL L553 QQLZ026-220 COIL 22uH ±7% L701 QQR1422-001 CHOKE COIL L903 QQR1200-002 CHOKE COIL L951 QQLZ026-460 COIL 46uH ±7% L952 QQL26AK-220Z CHOKE COIL 22uH K L953 QQLZ026-240 COIL 24uH ±7% T501 QQR1424-001 DRIVE TRANSF T521 QQR1188-001 PIN TRANSF



T701 QQR1427-001 DAF TRANSF



T901 QQS0230-001 SW TRANSF

CN001 QGB1506M1-16 CONNECTOR B-B (1-16) CN002 QGB1506M1-16 CONNECTOR B-B (1-16) CN003 QGB1506M1-16 CONNECTOR B-B (1-16) CN00K QUB572-26FPFX SIN TWIST WIRE CN00L CE41507-001P LV CONNECTOR CN00P QJK002-032613 SIN CR C-B WIRE CN010 QGB1505J1-35 CONNECTOR B-B (1-35) CN011 QGB1505J1-15 CONNECTOR B-B (1-15) CN0E3 CE41507-001P LV CONNECTOR CN0HV CHC802T-05N-J LV CONNECTOR



CP951 QMFZ049-4R0Z-E FUSE 4A 125V



CP953 ICP-N38-Y IC PROTECTOR 1.5A HS401 LC30416-002A HEAT SINK/AL-F/ HS461 CEHT11B-002QS HEAT SINK HS521 LC31813-001A HEAT SINK HS523 LC30521-001A HEAT SINK/AL-F/ HS551 LC21369-001A-C HEAT SINK HS901 LC30774-001A HEAT SINK/AL-F/ HS951 CEHT11B-002QS HEAT SINK HS952 CEHT11B-002QS HEAT SINK K401 QQR0621-002Z FERRITE BEADS K521 QQR0679-001 FERRITE BEADS K522 QQR0679-001 FERRITE BEADS K551 QQR0679-001 FERRITE BEADS K552 QQR0679-001 FERRITE BEADS K901 QQR0679-001 FERRITE BEADS K955 QQR0621-002Z FERRITE BEADS



PC901 PC123Y22FZ PHOTO COUPLER



RY951 QSK0099-001 RELAY



RY952 QSK0099-001 RELAY



SG551 QAF0046-242Z SURGE ABSORBER 2400V M



TH901 QAD0133-9R0 P THERMISTOR 9Ω 220V/240V

CRT SOCKET P.W. BOARD ASS'Y (SMM-3012A-U2)



Ref No. Part No. Part Name Description Local

IC3201 TDA6111Q IC IC3202 TDA6111Q IC IC3203 TDA6111Q IC

Q3701 2SC1906-T TRANSISTOR Q3702 2SA1005/MLK/-T TRANSISTOR Q3703 2SC1959/Y/-T TRANSISTOR Q3704 2SA562TM/Y/-T TRANSISTOR Q3705 2SJ584LS-CB11 POWER MOS FET Q3706 2SK2417 POWER MOS FET

D3201 EU01N-T2 SI DIODE D3202 EU01N-T2 SI DIODE D3203 EU01N-T2 SI DIODE D3204 RM2C-LFA1 SI DIODE D3205 1SR124-400A-T2 SI DIODE D3206 1SR124-400A-T2 SI DIODE D3207 1SR124-400A-T2 SI DIODE D3209 MA3130/H/-X CHIP ZENER DIODE D3210 MA3130/H/-X CHIP ZENER DIODE D3701 1SS355-X SI DIODE D3702 RH1S-T3 SI DIODE D3703 RH1S-T3 SI DIODE

C3201 NDC31HJ-8R0X C CAPACITOR 8pF 50V J C3202 NDC31HJ-8R0X C CAPACITOR 8pF 50V J C3203 NDC31HJ-8R0X C CAPACITOR 8pF 50V J C3204 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3205 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z

C3206 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3207 QETN1EM-476Z E CAPACITOR 47uF 25V M C3208 QETN1EM-476Z E CAPACITOR 47uF 25V M C3209 QETN1EM-476Z E CAPACITOR 47uF 25V M C3210 QFK62EK-104Z MM CAPACITOR 0.1uF 250V K C3211 QFK62EK-104Z MM CAPACITOR 0.1uF 250V K C3212 QFK62EK-104Z MM CAPACITOR 0.1uF 250V K C3213 NDC31HJ-681X C CAPACITOR 680pF 50V J C3214 NDC31HJ-681X C CAPACITOR 680pF 50V J C3215 NDC31HJ-681X C CAPACITOR 680pF 50V J C3218 QETN2EM-225Z E CAPACITOR 2.2uF 250V M C3219 QCZ0131-222 C CAPACITOR 2200pF 2kV K C3221 QETN2EM-106Z E CAPACITOR 10uF 250V M C3222 QETN2EM-106Z E CAPACITOR 10uF 250V M C3223 QETN2EM-106Z E CAPACITOR 10uF 250V M C3224 QETN2EM-106Z E CAPACITOR 10uF 250V M C3225 QETN1HM-226Z E CAPACITOR 22uF 50V M C3701 NCB31HK-102X C CAPACITOR 1000pF 50V K C3702 QETN1HM-106Z E CAPACITOR 10uF 50V M C3703 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z C3704 NCB31HK-472X C CAPACITOR 4700pF 50V K C3707 QFM72DK-103 M CAPACITOR 0.01uF 200V K C3708 QFM72DK-103 M CAPACITOR 0.01uF 200V K C3709 QETN2EM-106Z E CAPACITOR 10uF 250V M C3710 QETN2CM-226Z E CAPACITOR 22uF 160V M C3711 QETN2CM-226Z E CAPACITOR 22uF 160V M C3712 QFLC1HJ-222Z M CAPACITOR 2200pF 50V J C3713 QFLC1HJ-222Z M CAPACITOR 2200pF 50V J C3716 QCS32HJ-330Z C CAPACITOR 33pF 500V J C3717 QFM72DK-103 M CAPACITOR 0.01uF 200V K C3718 QFM72DK-103 M CAPACITOR 0.01uF 200V K C3719 QFZ0197-334 MPP CAPACITOR 0.33uF 250V J C3720 QCB32HK-102Z C CAPACITOR 1000pF 500V K

R3201 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R3202 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R3203 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R3211 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3212 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3213 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3218 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3219 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3220 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3222 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3223 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J R3224 QRL029J-104-F OMF RESISTOR 100kΩ 2W J R3225 QRL029J-104-F OMF RESISTOR 100kΩ 2W J R3226 QRL029J-104-F OMF RESISTOR 100kΩ 2W J R3227 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3228 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3229 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3230 QRC121K-561Z COMP RESISTOR 560Ω 1/2W K R3231 QRC121K-561Z COMP RESISTOR 560Ω 1/2W K R3232 QRC121K-561Z COMP RESISTOR 560Ω 1/2W K R3234 QRZ0107-474Z C RESISTOR 470kΩ 1/2W K R3235 QRZ0107-102Z C RESISTOR 1k R3236 QRZ0107-105Z C RESISTOR 1MΩ 1/2W K R3239 NRSA63J-182X MG RESISTOR 1.8k R3701 NRSA63J-101X MG RESISTOR 100 R3702 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R3703 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R3704 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R3705 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R3706 NRSA63J-471X MG RESISTOR 470 R3707 NRSA63J-392X MG RESISTOR 3.9k R3710 QRZ0230-182X UNF C RESISTOR 1.8k R3711 QRE121J-473Y C RESISTOR 47k R3712 QRE121J-473Y C RESISTOR 47k R3713 QRZ0230-681X UNF C RESISTOR 680 R3714 QRZ0230-470X UNF C RESISTOR 47 R3715 QRZ0230-470X UNF C RESISTOR 47 R3716 QRT029J-8R2 MF RESISTOR 8.2Ω 2W J R3719 QRG01GJ-180 OMF RESISTOR 18 R3720 QRL039J-220 OMF RESISTOR 22 R3721 QRL039J-220 OMF RESISTOR 22Ω 3W J R3722 QRL039J-100 OMF RESISTOR 10 R3723 QRL039J-220 OMF RESISTOR 22Ω 3W J R3724 NRSA63J-101X MG RESISTOR 100 R3725 QRL039J-220 OMF RESISTOR 22Ω 3W J

L3211 QQL244K-5R6Z PEAKING COIL 5.6uH K L3212 QQL244K-5R6Z PEAKING COIL 5.6uH K L3213 QQL244K-5R6Z PEAKING COIL 5.6uH K

CN300E WJK0164-001A E-SI C WIRE C-B CN30E1 CE41507-001P LV CONNECTOR CN30SC QGZ0017C1-01Z CONNECTOR (1-1)

Ω

1/2W K

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/2W J

Ω

1/2W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1W J

Ω

3W J

Ω

3W J

Ω

1/16W J

3-10(No.YA087)



Ref No. Part No. Part Name Description Local

CN30VM CHHB03-140A 3P DB WIRE ASSY H3705 CEHS12B-002Q HEAT SINK H3706 CEHS12B-002Q HEAT SINK HS3201 LC31150-002A HEAT SINK/AL-F1 HS3202 LC31150-002A HEAT SINK/AL-F1 HS3203 LC31150-002A HEAT SINK/AL-F1 K3105 QQR0621-002Z FERRITE BEADS K3202 QQR0679-001 FERRITE BEADS K3701 QQR1114-001Z FERRITE BEADS K3702 QQR0582-001Z FERRITE BEADS SG3201 QAF0056-501Z SURGE ABSORBER 500V M SG3202 QAF0056-501Z SURGE ABSORBER 500V M SG3203 QAF0056-501Z SURGE ABSORBER 500V M



SK3001 QNZ0663-001 CRT SOCKET

FRONT CONTROL P.W. BOARD ASS'Y (SMM-8011A-U2)



Ref No. Part No. Part Name Description Local

IC8851 GP1UM281QK IR DETECT UNIT 38kHz

Q8801 UN2112-X TRANSISTOR Q8802 UN2112-X TRANSISTOR

D8801 SPR-39MVWF LED POWER D8851 MA8068/M/-X Z DIODE

C8851 NCB31CK-104X C CAPACITOR 0.1uF 16V K C8852 QETN1CM-107Z E CAPACITOR 100uF 16V M



C8901 QFZ9075-474 MPP CAPACITOR 0.47uF AC275V M

R8801 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R8802 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R8851 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

CN800W WJK0050-008A E-SI C WIRE C-B



F8901 QMF51D2-3R15-J1 FUSE 3.15A AC250V



LF8901 QQR1095-003 LINE FILTER



S8901 QSW0824-001 PUSH SWITCH POWER

SIDE CONTROL SW P.W. BOARD ASS'Y (SMM-8111A-U2)



Ref No. Part No. Part Name Description Local

D8001 MA8039/H/-X Z DIODE

C8001 NCB31HK-103X C CAPACITOR 0.01uF 50V K C8002 NCB31HK-103X C CAPACITOR 0.01uF 50V K C8003 NCB31HK-102X C CAPACITOR 1000pF 50V K C8310 NCB31HK-472X C CAPACITOR 4700pF 50V K C8311 NCB31HK-472X C CAPACITOR 4700pF 50V K C8321 NCB31CK-104X C CAPACITOR 0.1uF 16V K

Ω

R8001 QRK126J-101X UNF C RESISTOR 100 R8002 QRK126J-101X UNF C RESISTOR 100Ω 1/2W J R8010 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8011 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R8012 NRSA63J-103X MG RESISTOR 10k R8021 NRSA63J-102X MG RESISTOR 1k R8022 NRSA63J-102X MG RESISTOR 1k

L8001 NQR0389-003X FERRITE BEADS L8002 QQL244K-5R6Z PEAKING COIL 5.6uH K L8003 QQL244K-5R6Z PEAKING COIL 5.6uH K L8310 QQL244K-270Z PEAKING COIL 27uH K L8311 QQL244K-270Z PEAKING COIL 27uH K L8312 NQR0389-003X FERRITE BEADS

J8001 QMS3001-C01 3.5 JACK HEADPHONE J8301 QNN0591-001 PIN JACK EXT-5 V IN J8303 QND0084-001 S JACK EXT-5 S IN S8001 QSW0619-003Z TACT SWITCH CH+ S8002 QSW0619-003Z TACT SWITCH MENU S8003 QSW0619-003Z TACT SWITCH CH-

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

LINE FILTER P.W. BOARD ASS'Y (SMM-9011A-U2)



Ref No. Part No. Part Name Description Local



IC9931 QAL0515-001 POWER MODULE

D9931 S1WB/A/60-4101 BRIDGE DIODE



C9901 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K



C9902 QFZ9072-473 MM CAPACITOR 0.047uF AC250V K



C9931 QCZ9054-472 C CAPACITOR 4700pF AC250V Z



C9932 QCZ9054-472 C CAPACITOR 4700pF AC250V Z



C9933 QCZ9054-472 C CAPACITOR 4700pF AC250V Z C9934 QEZ0632-226 E CAPACITOR 22uF 400V M C9941 QTMN1CM-477Z E CAPACITOR 470uF 16V M C9942 QETN1AM-227Z E CAPACITOR 220uF 10V M



C9991 QCZ9079-471 C CAPACITOR 470pF AC250V K



C9992 QCZ9079-471 C CAPACITOR 470pF AC250V K

R9931 QRZ0216-4R7 UNF WW RESISTOR 4.7Ω 7W K

L9941 QQL26AM-4R7Z CHOKE COIL 4.7uH M

CN900X WJK0050-005A E-SI C WIRE C-B



CP9901 QMFZ043-2R0Z-J1 FUSE 2A AC250V



LF9901 QQR1095-003 LINE FILTER

TUNER POWER P.W. BOARD ASS'Y (SMM-9111A-U2)



Ref No. Part No. Part Name Description Local

IC901 STR-A6351 IC IC951 L7812CP IC IC952 PQ025EF01SZ IC IC953 L7809CP IC IC954 PQ050RD01SZ IC IC955 PQ033RD01SZ IC

Q951 KTC3199/YG/-T TRANSISTOR Q952 KTC3199/YG/-T TRANSISTOR Q953 KTC3199/YG/-T TRANSISTOR Q954 KTC3199/YG/-T TRANSISTOR Q955 KTC3199/YG/-T TRANSISTOR Q956 2SA933AS/QR/-T TRANSISTOR

D901 S1WB/A/60-4101 BRIDGE DIODE D902 RGP10M-5010-T3 SI DIODE D904 RGP10J-04TS-T3 SI DIODE D905 MTZJ33B-T2 Z DIODE D906 MTZJ27B-T2 Z DIODE D907 1SS133-T2 DIODE D951 RGP10J-04TS-T3 SI DIODE D952 RU3YX-LFC4 SI DIODE D953 RU3YX-LFC4 SI DIODE D954 MTZJ33B-T2 Z DIODE D955 MTZJ6.2B-T2 Z DIODE D956 1SS133-T2 DIODE D957 RGP10J-04TS-T3 SI DIODE D958 1SS133-T2 DIODE D959 1SS133-T2 DIODE D962 RU3YX-LFC4 SI DIODE



C902 QFZ9075-473 MPP CAPACITOR 0.047uF AC275V M



C904 QCZ9054-472 C CAPACITOR 4700pF AC250V Z



C905 QCZ9054-472 C CAPACITOR 4700pF AC250V Z



C906 QCZ9054-472 C CAPACITOR 4700pF AC250V Z C907 QETM2GM-226 E CAPACITOR 22uF 400V M C908 QCB32HK-102Z C CAPACITOR 1000pF 500V K C910 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C911 QCZ0345-470 C CAPACITOR 47pF 3kV K C912 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J C913 QCB31HK-471Z C CAPACITOR 470pF 50V K C914 QETM2GM-226 E CAPACITOR 22uF 400V M C951 QETN1HM-476Z E CAPACITOR 47uF 50V M C952 QETN1CM-108Z E CAPACITOR 1000uF 16V M C953 QETN1AM-108Z E CAPACITOR 1000uF 10V M C954 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C955 QETN1EM-476Z E CAPACITOR 47uF 25V M C956 QETN1CM-107Z E CAPACITOR 100uF 16V M C957 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C958 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C959 QETN1CM-108Z E CAPACITOR 1000uF 16V M C960 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C961 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C962 QETN1HM-475Z E CAPACITOR 4.7uF 50V M

(No.YA087)3-11



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C963 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C964 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C966 QETN1EM-227Z E CAPACITOR 220uF 25V M C967 QETN1EM-108Z E CAPACITOR 1000uF 25V M C992 QCZ9079-152 C CAPACITOR 1500pF AC250V M

R902 QRZ0122-5R6 UNF WW RESISTOR 5.6Ω 3W K R903 QRE121J-224Y C RESISTOR 220kΩ 1/2W J R904 QRE121J-224Y C RESISTOR 220kΩ 1/2W J R908 QRL029J-104 OMF RESISTOR 100kΩ 2W J R910 QRE121J-100Y C RESISTOR 10Ω 1/2W J R911 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J R912 QRE141J-681Y C RESISTOR 680Ω 1/4W J R913 QRX01GJ-1R2 MF RESISTOR 1.2Ω 1W J R951 QRZ9011-150 FUSI RESISTOR 15Ω 1/2W J R952 QRZ9023-100 FUSIBLE RESISTOR 10Ω 2W J R955 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R956 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R957 QRE141J-563Y C RESISTOR 56kΩ 1/4W J R958 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R959 QRE141J-182Y C RESISTOR 1.8kΩ 1/4W J R960 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J R961 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J R962 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J R963 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R965 QRE141J-102Y C RESISTOR 1k R966 QRE141J-473Y C RESISTOR 47k R967 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R968 QRE141J-473Y C RESISTOR 47kΩ 1/4W J R969 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R970 QRE141J-153Y C RESISTOR 15kΩ 1/4W J R973 QRE141J-101Y C RESISTOR 100Ω 1/4W J

L951 QQL26AK-220Z CHOKE COIL 22uH K L952 QQL26AK-220Z CHOKE COIL 22uH K



T901 QQS0269-001 SW TRANSF

CN0UB QJK002-031613 SIN CR C-B WIRE



CP901 QMFZ052-2R0-E FUSE 2A AC250V



CP952 ICP-N70-T IC PROTECTOR 2.5A



CP953 ICP-N70-T IC PROTECTOR 2.5A



CP954 ICP-N50-Y IC PROTECTOR 2.0A HS952 CEHT11B-002QS HEAT SINK HS954 CEHT11B-002QS HEAT SINK HS955 CEHT11B-002QS HEAT SINK



PC901 PC123Y22FZ PHOTO COUPLER



RY901 QSK0119-001 RELAY

Ω

1/4W J

Ω

1/4W J

SOUND DELAY P.W. BOARD ASS'Y (SMM0A201A-U2)



Ref No. Part No. Part Name Description Local

IC601 HA17558AF-X IC IC602 AK4550VT-X IC IC603 MM1562FF-X IC IC604 NJU26103FR1 IC

Q601 2SC3928A/QR/-X TRANSISTOR Q602 2SK1374-X MOS FET Q603 2SK1374-X MOS FET Q604 2SC3928A/QR/-X TRANSISTOR Q605 2SC3928A/QR/-X TRANSISTOR Q606 2SC3928A/QR/-X TRANSISTOR

D601 MA8047/L/-X Z DIODE D602 MA111-X SI DIODE

C601 NEH71CM-476X E CAPACITOR 47uF 16V M C602 NDC31HJ-100X C CAPACITOR 10pF 50V J C603 NEH71HM-105X E CAPACITOR 1uF 50V M C604 NEH71CM-476X E CAPACITOR 47uF 16V M C605 NDC31HJ-100X C CAPACITOR 10pF 50V J C606 NEH71HM-105X E CAPACITOR 1uF 50V M C607 NCB11EK-105X C CAPACITOR 1uF 25V K C608 NCB11CK-225X C CAPACITOR 2.2uF 16V K C609 NDC31HJ-471X C CAPACITOR 470pF 50V J C610 NDC31HJ-100X C CAPACITOR 10pF 50V J C611 NCB31CK-104X C CAPACITOR 0.1uF 16V K C612 NCB31CK-104X C CAPACITOR 0.1uF 16V K C613 NCB31CK-104X C CAPACITOR 0.1uF 16V K C614 NCB31CK-104X C CAPACITOR 0.1uF 16V K C615 NDC31HJ-102X C CAPACITOR 1000pF 50V J C616 NDC31HJ-120X C CAPACITOR 12pF 50V J C617 NDC31HJ-100X C CAPACITOR 10pF 50V J

C618 NCB31HK-102X C CAPACITOR 1000pF 50V K C620 NEH71CM-106X E CAPACITOR 10uF 16V M C621 NCB31CK-104X C CAPACITOR 0.1uF 16V K C622 NCB31CK-104X C CAPACITOR 0.1uF 16V K C623 NEH71EM-475X E CAPACITOR 4.7uF 25V M C624 NCB31HK-102X C CAPACITOR 1000pF 50V K C626 NCB31HK-102X C CAPACITOR 1000pF 50V K C627 NCB31HK-102X C CAPACITOR 1000pF 50V K C628 NEN51CM-475X BP E CAPACITOR 4.7uF 16V M C629 NEN51CM-475X BP E CAPACITOR 4.7uF 16V M C630 NEN51AM-106X BP E CAPACITOR 10uF 10V M C631 NEN51AM-106X BP E CAPACITOR 10uF 10V M C632 NEN51AM-106X BP E CAPACITOR 10uF 10V M C633 NEN51AM-106X BP E CAPACITOR 10uF 10V M

R601 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R602 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R603 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R604 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R605 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R606 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R607 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R609 NRSA63J-470X MG RESISTOR 47Ω 1/16W J R610 NRSA63J-470X MG RESISTOR 47Ω 1/16W J R611 NRSA63J-470X MG RESISTOR 47Ω 1/16W J R612 NRSA63J-470X MG RESISTOR 47 R613 NRSA63J-470X MG RESISTOR 47 R614 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R615 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R616 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R617 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R620 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J R621 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R622 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R623 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R624 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R629 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R630 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R631 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R632 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R633 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R634 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R635 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R636 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R637 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R638 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R639 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R640 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R641 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R642 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R643 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J

L601 NQL092K-2R2X P COIL 2.2uH K

CN012 QGB1505K1-25 CONNECTOR B-B (1-25) K601 NQR0413-002X FERRITE BEADS X601 NAX0634-001X CRYSTAL

Ω

1/16W J

Ω

1/16W J

EHT P.W. BOARD ASS'Y (SMM0E011A-U2)



Ref No. Part No. Part Name Description Local

IC2501 RC4558D-X IC

Q2501 2SC3928A/QR/-X TRANSISTOR Q2502 2SA966/OY/-T TRANSISTOR

D2501 MA8150/M/-X Z DIODE D2502 MA8091/M/-X Z DIODE D2503 MA8056/M/-X Z DIODE D2504 MA111-X SI DIODE

C2501 NDC31HJ-681X C CAPACITOR 680pF 50V J C2502 QETN1HM-476Z E CAPACITOR 47uF 50V M C2503 NCB31HK-104X C CAPACITOR 0.1uF 50V K

R2501 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R2502 NRSA63J-0R0X MG RESISTOR 0 R2504 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R2505 NRSA63J-473X MG RESISTOR 47k R2506 QVP0086-502Z TRIM RESISTOR 5k R2507 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R2509 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R2510 QVP0086-204Z TRIM RESISTOR 200k

Ω

1/16W J

Ω

1/16W J

Ω

0.3W N

Ω

0.3W N

3-12(No.YA087)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R2511 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R2512 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J R2513 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R2514 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R2515 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R2516 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R2517 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R2518 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R2519 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R2520 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R2521 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R2523 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J

CN2011 QGB1505K1-15 CONNECTOR B-B (1-15) M2501 MSPAD402 PWB MODULE

DEF OSC P.W. BOARD ASS'Y (SMM0H012A-U2)



Ref No. Part No. Part Name Description Local

IC0101 LA7860M-X IC IC0102 BA12FP-X IC IC0161 AN5441SA-W IC IC0162 BA10393F-XE IC IC0163 AN7805F IC IC0212 CXA1875AM-X IC

Q0101 2SC3928A/QR/-X TRANSISTOR Q0102 2SC3928A/QR/-X TRANSISTOR Q0131 2SC3928A/QR/-X TRANSISTOR Q0132 2SC3928A/QR/-X TRANSISTOR Q0161 2SC3928A/QR/-X TRANSISTOR Q0162 2SC3928A/QR/-X TRANSISTOR Q0751 2SC3928A/QR/-X TRANSISTOR Q0752 2SC3928A/QR/-X TRANSISTOR Q0753 2SC4632 POW TRANSISTOR Q0754 2SC3928A/QR/-X TRANSISTOR

D0162 1SS355-X SI DIODE D0163 MA111-X SI DIODE D0164 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J D0222 MA8062/M/-X Z DIODE D0223 MA8062/M/-X Z DIODE D0751 ES1F-LFG2 SI DIODE D0752 ES1F-LFG2 SI DIODE

C0171 QFVF1HJ-184Z MF CAPACITOR 0.18uF 50V J C0172 QFVF1HJ-824Z MF CAPACITOR 0.82uF 50V J C0173 NCB31HK-153X C CAPACITOR 0.015uF 50V K C0174 QETN1HM-106Z E CAPACITOR 10uF 50V M C0175 NCS21HJ-152X C CAPACITOR 1500pF 50V J C0176 QFP31HJ-272Z PP CAPACITOR 2700pF 50V J C0177 NCB31HK-332X C CAPACITOR 3300pF 50V K C0178 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0179 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0180 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0181 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0182 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0212 QETN1HM-106Z E CAPACITOR 10uF 50V M C0751 QFVF1HJ-184Z MF CAPACITOR 0.18uF 50V J C0752 QETN1EM-476Z E CAPACITOR 47uF 25V M C0753 QFZ0122-752 MPP CAPACITOR 7500pF 1.8kV H C0754 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J C0761 QFZ0122-682 MPP CAPACITOR 6800pF 1.8kV H

R0101 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0103 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R0104 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0105 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R0106 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J R0107 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0109 NRSA63J-682X MG RESISTOR 6.8k R0110 NRSA63J-223X MG RESISTOR 22k R0111 NRSA63D-153X MG RESISTOR 15kΩ 1/16W D R0112 NRSA63D-182X MG RESISTOR 1.8kΩ 1/16W D R0113 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R0114 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R0116 NRSA63D-182X MG RESISTOR 1.8kΩ 1/16W D R0117 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R0120 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J R0121 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R0122 QRG01GJ-470 OMF RESISTOR 47Ω 1W J



R0123 QRK126J-101X UNF C RESISTOR 100Ω 1/2W J R0124 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R0126 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0129 NRSA63D-183X MG RESISTOR 18kΩ 1/16W D R0131 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0133 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R0134 NRSA63J-334X MG RESISTOR 330kΩ 1/16W J R0138 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0139 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R0140 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0141 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0142 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0143 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0161 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0162 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0163 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0164 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0165 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R0167 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0168 NRSA63J-102X MG RESISTOR 1k R0169 NRSA63J-181X MG RESISTOR 180Ω 1/16W J R0170 NRSA63J-222X MG RESISTOR 2.2k R0171 NRSA63J-103X MG RESISTOR 10k R0172 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R0173 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0174 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0175 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0177 NRSA63J-682X MG RESISTOR 6.8k R0178 NRSA63J-331X MG RESISTOR 330 R0179 NRSA63D-562X MG RESISTOR 5.6k R0180 NRSA63D-152X MG RESISTOR 1.5k R0183 NRSA63J-102X MG RESISTOR 1k R0187 NRSA63J-472X MG RESISTOR 4.7k R0188 NRVA02D-101X CMF RESISTOR 100 R0190 NRSA63D-473X MG RESISTOR 47k R0191 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R0216 NRSA63J-221X MG RESISTOR 220 R0217 NRSA63J-221X MG RESISTOR 220 R0223 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0224 NRSA63J-101X MG RESISTOR 100 R0225 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0751 NRSA63J-273X MG RESISTOR 27k R0752 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0753 NRSA63J-332X MG RESISTOR 3.3k R0754 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R0755 NRSA63J-333X MG RESISTOR 33k R0756 NRSA63J-392X MG RESISTOR 3.9k R0757 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R0758 QRZ0056-102Z COMP RESISTOR 1kΩ 1/2W K R0759 NRSA63J-472X MG RESISTOR 4.7k R0761 QRE121J-184Y C RESISTOR 180k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/10W D

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

(No.YA087)3-13



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R0762 QRE121J-184Y C RESISTOR 180kΩ 1/2W J R0763 QRE121J-184Y C RESISTOR 180kΩ 1/2W J R0764 QRE121J-184Y C RESISTOR 180kΩ 1/2W J R0765 QRE121J-184Y C RESISTOR 180kΩ 1/2W J R0769 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0770 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

L0101 QQL244K-470Z COIL 47uH K L0103 NQL092K-100X COIL 10uH K L0104 NQL092K-100X COIL 10uH K L0105 QQL244K-101Z PEAKING COIL 100uH K T0751 QQR1096-001 DAF TRANSF

CN000K CE41507-001P LV CONNECTOR CN000L QUB572-18FPFX SIN TWIST WIRE CN0010 QGB1505K1-35 CONNECTOR B-B (1-35)

MI-COM P.W. BOARD ASS'Y (SMM0M011A-U2)



Ref No. Part No. Part Name Description Local

IC001 SDA6000-B12 IC IC002 S-80828CNNB-W IC IC003 K4S641632F-TC75 IC(DIGITAL) IC004 MBV160T-28D40BK IC(MICRO C ROM) (SERVICE) IC191 PQ2L3252MS-X IC

Q001 UMX1N-W PAIR TRANSISTOR Q003 2SC3928A/QR/-X TRANSISTOR Q004 UN2213-X DIGI TRANSISTOR Q013 2SK1830-X MOS FET Q014 2SK1830-X MOS FET Q015 2SK1830-X MOS FET

D001 MA111-X SI DIODE D005 RSA6.1J4-W SI DIODE

C001 NEH70GM-227X E CAPACITOR 220uF 4V M C003 NCB31CK-104X C CAPACITOR 0.1uF 16V K C004 NEH70JM-107X E CAPACITOR 100uF 6.3V M C005 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C006 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C007 NEH70GM-227X E CAPACITOR 220uF 4V M C008 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C012 NCB31HK-104X C CAPACITOR 0.1uF 50V K C013 NEH71CM-476X E CAPACITOR 47uF 16V M C020 NCB31HK-104X C CAPACITOR 0.1uF 50V K C023 NCB31HK-333X C CAPACITOR 0.033uF 50V K C024 NCB31HK-104X C CAPACITOR 0.1uF 50V K C025 NDC31HJ-470X C CAPACITOR 47pF 50V J C027 NEH71CM-476X E CAPACITOR 47uF 16V M C028 NEH71CM-476X E CAPACITOR 47uF 16V M C029 NDC31HJ-151X C CAPACITOR 150pF 50V J C030 NCB31HK-104X C CAPACITOR 0.1uF 50V K C031 NCB31HK-104X C CAPACITOR 0.1uF 50V K C032 NCB31HK-104X C CAPACITOR 0.1uF 50V K C034 NCB31HK-104X C CAPACITOR 0.1uF 50V K C035 NCB31HK-104X C CAPACITOR 0.1uF 50V K C036 NCB31HK-104X C CAPACITOR 0.1uF 50V K C037 NCB31HK-104X C CAPACITOR 0.1uF 50V K C038 NCB31HK-104X C CAPACITOR 0.1uF 50V K C039 NCB31HK-104X C CAPACITOR 0.1uF 50V K C040 NDC31HJ-330X C CAPACITOR 33pF 50V J C041 NDC31HJ-330X C CAPACITOR 33pF 50V J C042 NCB31HK-104X C CAPACITOR 0.1uF 50V K C043 NCB31HK-104X C CAPACITOR 0.1uF 50V K C045 NCB31HK-104X C CAPACITOR 0.1uF 50V K C046 NCB31HK-104X C CAPACITOR 0.1uF 50V K C047 NCB31HK-104X C CAPACITOR 0.1uF 50V K C048 NEH71CM-476X E CAPACITOR 47uF 16V M C049 NCB31HK-104X C CAPACITOR 0.1uF 50V K C050 NCB31HK-104X C CAPACITOR 0.1uF 50V K C051 NEH71CM-476X E CAPACITOR 47uF 16V M C052 NCB31HK-104X C CAPACITOR 0.1uF 50V K C053 NCB31HK-104X C CAPACITOR 0.1uF 50V K C054 NCB31HK-104X C CAPACITOR 0.1uF 50V K C055 NCB31HK-104X C CAPACITOR 0.1uF 50V K C056 NCB31HK-104X C CAPACITOR 0.1uF 50V K C057 NCB31HK-104X C CAPACITOR 0.1uF 50V K C058 NCB31HK-104X C CAPACITOR 0.1uF 50V K C059 NEH71CM-106X E CAPACITOR 10uF 16V M C060 NEH71CM-106X E CAPACITOR 10uF 16V M C061 NEH71CM-106X E CAPACITOR 10uF 16V M C062 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W J

C063 NCB31HK-104X C CAPACITOR 0.1uF 50V K C067 NCB31HK-104X C CAPACITOR 0.1uF 50V K C068 NCB31AK-105X C CAPACITOR 1uF 10V K

R001 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J R002 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J R003 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J R004 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J R005 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J R006 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J R007 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J R008 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J R011 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R012 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R013 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R014 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R015 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R018 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R019 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R020 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R022 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R024 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R030 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R032 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R034 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R035 NRSA63J-0R0X MG RESISTOR 0 R036 NRSA63J-0R0X MG RESISTOR 0 R037 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R038 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R039 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R040 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R041 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R042 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R043 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R044 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R045 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R046 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R047 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R048 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R049 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R050 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R051 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R052 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R053 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R054 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R055 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R056 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R057 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R058 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R059 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R060 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R061 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R062 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R063 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R064 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R065 NRSA63J-183X MG RESISTOR 18k R066 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J R067 NRSA63J-104X MG RESISTOR 100k R068 NRSA63J-473X MG RESISTOR 47k R069 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R071 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R072 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R073 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R074 NRSA63J-102X MG RESISTOR 1k R078 NDC31HJ-100X C CAPACITOR 10pF 50V J R084 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R086 NRSA63J-0R0X MG RESISTOR 0 R087 NRSA63J-0R0X MG RESISTOR 0 R121 NRSA63J-0R0X MG RESISTOR 0 R122 NRSA63J-0R0X MG RESISTOR 0 R123 NRSA63J-0R0X MG RESISTOR 0 R124 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R125 NRSA63J-472X MG RESISTOR 4.7k R126 NRSA63J-472X MG RESISTOR 4.7k R127 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R128 NRSA63J-472X MG RESISTOR 4.7k R135 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R141 NRSA63J-103X MG RESISTOR 10k R142 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R143 NRSA63J-103X MG RESISTOR 10k R146 NDC31HJ-100X C CAPACITOR 10pF 50V J R147 NRSA63J-0R0X MG RESISTOR 0 R151 NRSA63J-221X MG RESISTOR 220 R152 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R153 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R154 NRSA63J-471X MG RESISTOR 470 R155 NRSA63J-681X MG RESISTOR 680

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-14(No.YA087)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R156 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R157 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R158 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R159 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R160 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R161 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R164 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R165 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R166 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R167 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R171 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R172 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R173 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R174 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R175 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R176 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R177 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R181 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R182 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R183 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R184 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R185 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R186 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R187 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R188 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R189 NRSA63J-472X MG RESISTOR 4.7k

L001 NQL092K-4R7X COIL 4.7uH K L002 NQL79GM-470X COIL 47uH M L003 NQL092K-4R7X COIL 4.7uH K L005 NQL092K-4R7X COIL 4.7uH K L006 NQL092K-4R7X COIL 4.7uH K L007 NQL092K-4R7X COIL 4.7uH K L008 NQL092K-4R7X COIL 4.7uH K L009 NQL79GM-4R7X COIL 4.7uH M L010 NQL092K-4R7X COIL 4.7uH K L011 NRSA02J-0R0X MG RESISTOR 0 L012 NQL092K-4R7X COIL 4.7uH K L013 NQL092K-4R7X COIL 4.7uH K L014 NQL092K-4R7X COIL 4.7uH K L015 NQL79GM-4R7X COIL 4.7uH M L016 NQL79GM-4R7X COIL 4.7uH M L017 NQL092K-1R5X COIL 1.5uH K L018 NQL092K-1R5X COIL 1.5uH K L019 NQL092K-1R5X COIL 1.5uH K L020 NQL092K-1R5X COIL 1.5uH K L021 NQL092K-1R5X COIL 1.5uH K L022 NQL092K-1R5X COIL 1.5uH K L023 NQL092K-1R5X COIL 1.5uH K L024 NQL092K-1R5X COIL 1.5uH K

CN004 QGB2023L1-30X CONNECTOR B-B (1-30) CN005 QGB2023L1-30X CONNECTOR B-B (1-30) K001 NRSA63J-390X MG RESISTOR 39Ω 1/16W J K002 NQR0389-003X FERRITE BEADS K003 NRSA63J-0R0X MG RESISTOR 0 K004 NQR0389-003X FERRITE BEADS LC001 NQR0415-003X EMI FILTER 0.47uF 16V M LC002 NQR0415-003X EMI FILTER 0.47uF 16V M X001 NAX0644-001X CRYSTAL 6MHz

Ω

1/16W J

Ω

1/10W J

Ω

1/16W J

AV SW P.W. BOARD ASS'Y (SMM0S011A-U2)



Ref No. Part No. Part Name Description Local

IC101 CXA2069Q IC IC601 NJM2777M-X IC IC701 MM1510XN-X IC IC801 TB1274AF IC IC802 TC90A69AF-X IC IC803 BA05FP-X IC

Q101 2SC3928A/QR/-X TRANSISTOR Q102 2SA1530A/QR/-X TRANSISTOR Q103 UN2226-X DIGI TRANSISTOR Q104 UN2226-X DIGI TRANSISTOR Q105 KTC3199/YG/-T TRANSISTOR Q131 2SA933AS/QR/-T TRANSISTOR Q136 UN2226-X DIGI TRANSISTOR Q137 UN2226-X DIGI TRANSISTOR Q138 2SA1530A/QR/-X TRANSISTOR Q201 2SC3928A/QR/-X TRANSISTOR Q202 2SC3928A/QR/-X TRANSISTOR Q211 2SC3928A/QR/-X TRANSISTOR

Q212 2SC3928A/QR/-X TRANSISTOR Q221 2SC3928A/QR/-X TRANSISTOR Q222 2SC3928A/QR/-X TRANSISTOR Q231 2SC3928A/QR/-X TRANSISTOR Q232 2SC3928A/QR/-X TRANSISTOR Q234 UN2213-X DIGI TRANSISTOR Q301 2SC3928A/QR/-X TRANSISTOR Q311 2SC3928A/QR/-X TRANSISTOR Q321 2SC3928A/QR/-X TRANSISTOR Q501 2SC3928A/QR/-X TRANSISTOR Q502 2SC3928A/QR/-X TRANSISTOR Q503 2SC3928A/QR/-X TRANSISTOR Q506 UN2226-X DIGI TRANSISTOR Q507 UN2226-X DIGI TRANSISTOR Q651 UN2226-X DIGI TRANSISTOR Q652 UN2226-X DIGI TRANSISTOR Q653 2SA1530A/QR/-X TRANSISTOR Q801 2SA1530A/QR/-X TRANSISTOR Q802 2SA1530A/QR/-X TRANSISTOR Q851 2SC3928A/QR/-X TRANSISTOR Q853 2SA1530A/QR/-X TRANSISTOR Q854 2SC3928A/QR/-X TRANSISTOR Q855 2SA1530A/QR/-X TRANSISTOR Q858 2SC3928A/QR/-X TRANSISTOR Q859 2SA1530A/QR/-X TRANSISTOR Q862 2SC3928A/QR/-X TRANSISTOR Q863 2SC3928A/QR/-X TRANSISTOR

D101 MA8056/M/-X Z DIODE D102 MA8056/M/-X Z DIODE D103 MA8056/M/-X Z DIODE D104 MA8056/M/-X Z DIODE D111 MA8056/M/-X Z DIODE D112 MA8056/M/-X Z DIODE D113 MA8056/M/-X Z DIODE D114 MA8039/H/-X Z DIODE D122 MA8056/M/-X Z DIODE D131 MA8120/M/-X Z DIODE D161 MA8120/M/-X Z DIODE D162 MA8120/M/-X Z DIODE D163 MA8120/M/-X Z DIODE D164 MA8120/M/-X Z DIODE D165 MA8120/M/-X Z DIODE

C101 NCB31HK-472X C CAPACITOR 4700pF 50V K C102 NCB31HK-472X C CAPACITOR 4700pF 50V K C103 NCB31HK-472X C CAPACITOR 4700pF 50V K C104 NCB31HK-472X C CAPACITOR 4700pF 50V K C105 QETN1EM-477Z E CAPACITOR 470uF 25V M C106 NCB31HK-152X C CAPACITOR 1500pF 50V K C107 NCB31HK-152X C CAPACITOR 1500pF 50V K C111 NCB31HK-472X C CAPACITOR 4700pF 50V K C112 NCB31HK-472X C CAPACITOR 4700pF 50V K C113 NCB31HK-472X C CAPACITOR 4700pF 50V K C114 NCB31HK-472X C CAPACITOR 4700pF 50V K C115 QETN1EM-477Z E CAPACITOR 470uF 25V M C116 NCB31HK-152X C CAPACITOR 1500pF 50V K C117 NCB31HK-152X C CAPACITOR 1500pF 50V K C124 NCB31HK-472X C CAPACITOR 4700pF 50V K C125 NCB31HK-102X C CAPACITOR 1000pF 50V K C131 QETN1CM-107Z E CAPACITOR 100uF 16V M C132 NCF31AZ-105X C CAPACITOR 1uF 10V Z C133 NCF31AZ-105X C CAPACITOR 1uF 10V Z C141 NCB31HK-103X C CAPACITOR 0.01uF 50V K C142 QETN1HM-106Z E CAPACITOR 10uF 50V M C143 NCF31AZ-105X C CAPACITOR 1uF 10V Z C144 NCF31AZ-105X C CAPACITOR 1uF 10V Z C145 NCB31HK-103X C CAPACITOR 0.01uF 50V K C146 QETN1HM-106Z E CAPACITOR 10uF 50V M C147 NCF31AZ-105X C CAPACITOR 1uF 10V Z C148 NCB31HK-103X C CAPACITOR 0.01uF 50V K C149 NCF31AZ-105X C CAPACITOR 1uF 10V Z C150 QETN1HM-106Z E CAPACITOR 10uF 50V M C151 NCF31AZ-105X C CAPACITOR 1uF 10V Z C152 QETN1HM-106Z E CAPACITOR 10uF 50V M C153 NCF31AZ-105X C CAPACITOR 1uF 10V Z C154 NCB31HK-103X C CAPACITOR 0.01uF 50V K C161 QETN1HM-106Z E CAPACITOR 10uF 50V M C163 NCF31AZ-105X C CAPACITOR 1uF 10V Z C165 NCF31AZ-105X C CAPACITOR 1uF 10V Z C166 NCB31HK-103X C CAPACITOR 0.01uF 50V K C167 NCF31AZ-105X C CAPACITOR 1uF 10V Z C168 QETN1HM-106Z E CAPACITOR 10uF 50V M C169 NCB21AK-105X C CAPACITOR 1uF 10V K C170 NCB21AK-105X C CAPACITOR 1uF 10V K C171 NCB21AK-105X C CAPACITOR 1uF 10V K C172 QETN1CM-107Z E CAPACITOR 100uF 16V M

(No.YA087)3-15



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C173 NCB31HK-103X C CAPACITOR 0.01uF 50V K C174 QETN1EM-477Z E CAPACITOR 470uF 25V M C175 NCF31AZ-105X C CAPACITOR 1uF 10V Z C176 NCF31AZ-105X C CAPACITOR 1uF 10V Z C177 NCB21AK-105X C CAPACITOR 1uF 10V K C178 QETN1HM-106Z E CAPACITOR 10uF 50V M C179 NCB31HK-103X C CAPACITOR 0.01uF 50V K C185 QETN1HM-476Z E CAPACITOR 47uF 50V M C190 QETN1CM-107Z E CAPACITOR 100uF 16V M C213 NCB31HK-102X C CAPACITOR 1000pF 50V K C214 NCB31HK-102X C CAPACITOR 1000pF 50V K C301 QETN1HM-106Z E CAPACITOR 10uF 50V M C311 QETN1HM-106Z E CAPACITOR 10uF 50V M C321 QETN1HM-106Z E CAPACITOR 10uF 50V M C331 QEKC1CM-107Z E CAPACITOR 100uF 16V M C341 NCB31HK-152X C CAPACITOR 1500pF 50V K C342 NCB31HK-152X C CAPACITOR 1500pF 50V K C343 NCF31AZ-105X C CAPACITOR 1uF 10V Z C344 NCF31AZ-105X C CAPACITOR 1uF 10V Z C501 QETN1HM-106Z E CAPACITOR 10uF 50V M C502 QETN1HM-106Z E CAPACITOR 10uF 50V M C503 QETN1HM-106Z E CAPACITOR 10uF 50V M C504 NCB11CK-105X C CAPACITOR 1uF 16V K C505 QEKC1CM-107Z E CAPACITOR 100uF 16V M C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K C507 QETN1CM-107Z E CAPACITOR 100uF 16V M C510 NCF31AZ-105X C CAPACITOR 1uF 10V Z C511 QETN1HM-106Z E CAPACITOR 10uF 50V M C512 NCF31AZ-105X C CAPACITOR 1uF 10V Z C514 NCB31HK-152X C CAPACITOR 1500pF 50V K C515 NCB31HK-152X C CAPACITOR 1500pF 50V K C516 NCB31HK-472X C CAPACITOR 4700pF 50V K C517 NCB31HK-472X C CAPACITOR 4700pF 50V K C518 NCB31HK-472X C CAPACITOR 4700pF 50V K C522 QETN1HM-106Z E CAPACITOR 10uF 50V M C523 QETN1AM-107Z E CAPACITOR 100uF 10V M C524 QETN1HM-106Z E CAPACITOR 10uF 50V M C525 QETN1HM-106Z E CAPACITOR 10uF 50V M C601 QETN1CM-107Z E CAPACITOR 100uF 16V M C602 QETN1CM-107Z E CAPACITOR 100uF 16V M C603 QETN1HM-106Z E CAPACITOR 10uF 50V M C604 QETN1HM-105Z E CAPACITOR 1uF 50V M C605 QETN1HM-105Z E CAPACITOR 1uF 50V M C606 QETN1EM-477Z E CAPACITOR 470uF 25V M C607 QETN1HM-105Z E CAPACITOR 1uF 50V M C611 NCF31AZ-105X C CAPACITOR 1uF 10V Z C612 NCF31AZ-105X C CAPACITOR 1uF 10V Z C651 NCB31HK-103X C CAPACITOR 0.01uF 50V K C652 NCB31HK-103X C CAPACITOR 0.01uF 50V K C654 NCB31HK-102X C CAPACITOR 1000pF 50V K C655 NCB31HK-102X C CAPACITOR 1000pF 50V K C801 NCB31HK-104X C CAPACITOR 0.1uF 50V K C802 NCB31HK-104X C CAPACITOR 0.1uF 50V K C803 NCB31HK-104X C CAPACITOR 0.1uF 50V K C804 QETN1HM-476Z E CAPACITOR 47uF 50V M C805 NCB31HK-103X C CAPACITOR 0.01uF 50V K C806 NCB31HK-103X C CAPACITOR 0.01uF 50V K C807 QETN1HM-476Z E CAPACITOR 47uF 50V M C808 NCB31HK-103X C CAPACITOR 0.01uF 50V K C809 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C810 NCB31HK-104X C CAPACITOR 0.1uF 50V K C811 NCB31HK-104X C CAPACITOR 0.1uF 50V K C812 NCB31HK-104X C CAPACITOR 0.1uF 50V K C813 QETN1HM-476Z E CAPACITOR 47uF 50V M C814 NCB31HK-103X C CAPACITOR 0.01uF 50V K C815 NCB31HK-104X C CAPACITOR 0.1uF 50V K C816 NCB31HK-104X C CAPACITOR 0.1uF 50V K C817 NCB31HK-104X C CAPACITOR 0.1uF 50V K C818 QETN1HM-106Z E CAPACITOR 10uF 50V M C819 NDC31HJ-100X C CAPACITOR 10pF 50V J C820 NCB31AK-474X C CAPACITOR 0.47uF 10V K C821 NCB31HK-103X C CAPACITOR 0.01uF 50V K C822 NCB11CK-225X C CAPACITOR 2.2uF 16V K C823 NCB31HK-153X C CAPACITOR 0.015uF 50V K C824 NCB31HK-103X C CAPACITOR 0.01uF 50V K C826 QETN1HM-226Z E CAPACITOR 22uF 50V M C827 QETN1CM-107Z E CAPACITOR 100uF 16V M C835 NCB31HK-104X C CAPACITOR 0.1uF 50V K C836 NCB31HK-104X C CAPACITOR 0.1uF 50V K C837 NCB31HK-104X C CAPACITOR 0.1uF 50V K C850 NDC31HJ-180X C CAPACITOR 18pF 50V J C851 NDC31HJ-560X C CAPACITOR 56pF 50V J C852 NDC31HJ-560X C CAPACITOR 56pF 50V J C853 QETN1CM-476Z E CAPACITOR 47uF 16V M C854 NCB31HK-104X C CAPACITOR 0.1uF 50V K C855 NCB31HK-103X C CAPACITOR 0.01uF 50V K C856 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C857 NCB31HK-103X C CAPACITOR 0.01uF 50V K C858 NCB31HK-103X C CAPACITOR 0.01uF 50V K C859 NCB31AK-474X C CAPACITOR 0.47uF 10V K C860 NCB31HK-103X C CAPACITOR 0.01uF 50V K C861 NDC31HJ-681X C CAPACITOR 680pF 50V J C862 NCB31HK-104X C CAPACITOR 0.1uF 50V K C863 NCB31HK-103X C CAPACITOR 0.01uF 50V K C864 NCB31HK-103X C CAPACITOR 0.01uF 50V K C865 NDC31HJ-560X C CAPACITOR 56pF 50V J C866 NDC31HJ-560X C CAPACITOR 56pF 50V J C868 NCB31HK-104X C CAPACITOR 0.1uF 50V K C869 NDC31HJ-560X C CAPACITOR 56pF 50V J C870 NDC31HJ-560X C CAPACITOR 56pF 50V J C872 NCB31HK-104X C CAPACITOR 0.1uF 50V K C873 NDC31HJ-330X C CAPACITOR 33pF 50V J C874 NDC31HJ-150X C CAPACITOR 15pF 50V J C875 NDC31HJ-100X C CAPACITOR 10pF 50V J C876 NCB31HK-103X C CAPACITOR 0.01uF 50V K C877 NCB31HK-103X C CAPACITOR 0.01uF 50V K C878 NCB31HK-104X C CAPACITOR 0.1uF 50V K C879 NCB31HK-104X C CAPACITOR 0.1uF 50V K C880 QETN1AM-107Z E CAPACITOR 100uF 10V M C881 QETN1AM-107Z E CAPACITOR 100uF 10V M C882 NCB31HK-103X C CAPACITOR 0.01uF 50V K C883 NCB31HK-103X C CAPACITOR 0.01uF 50V K C884 QETN1AM-107Z E CAPACITOR 100uF 10V M C885 QETN1AM-107Z E CAPACITOR 100uF 10V M C886 QETN1HM-106Z E CAPACITOR 10uF 50V M C887 NCB31HK-104X C CAPACITOR 0.1uF 50V K C888 QETN1AM-107Z E CAPACITOR 100uF 10V M C889 QETN1HM-106Z E CAPACITOR 10uF 50V M C890 QETN1HM-106Z E CAPACITOR 10uF 50V M C891 QETN1HM-476Z E CAPACITOR 47uF 50V M C892 NDC31HJ-180X C CAPACITOR 18pF 50V J C894 NDC31HJ-180X C CAPACITOR 18pF 50V J

R101 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R102 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R103 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R104 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R105 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R106 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R107 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R108 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R109 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R111 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R112 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R113 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R114 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R115 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R116 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R117 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R118 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R119 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R127 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R129 NRSA63J-750X MG RESISTOR 75 R131 QRG01GJ-101 OMF RESISTOR 100Ω 1W J R132 QRK126J-181X UNF C RESISTOR 180 R133 NRSA63J-750X MG RESISTOR 75 R134 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R135 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R136 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J R137 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R138 NRSA63J-823X MG RESISTOR 82k R139 NRSA63J-104X MG RESISTOR 100k R141 NRSA63J-221X MG RESISTOR 220 R142 NRSA63J-221X MG RESISTOR 220 R143 NRSA63J-221X MG RESISTOR 220 R144 NRSA63J-221X MG RESISTOR 220 R145 NRSA63J-221X MG RESISTOR 220 R146 NRSA63J-221X MG RESISTOR 220 R147 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R148 NRSA63J-221X MG RESISTOR 220 R149 NRSA63J-221X MG RESISTOR 220 R150 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R151 NRSA63J-221X MG RESISTOR 220 R152 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R153 NRSA63J-221X MG RESISTOR 220 R154 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R155 NRSA63J-221X MG RESISTOR 220 R156 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R157 NRSA63J-472X MG RESISTOR 4.7k R160 NRSA63J-221X MG RESISTOR 220 R161 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R162 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R163 NRSA63J-222X MG RESISTOR 2.2k R164 NRSA63J-333X MG RESISTOR 33k

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-16(No.YA087)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R165 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R166 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R167 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R168 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R169 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R170 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R171 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R172 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R173 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R174 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R175 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R176 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R177 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R178 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J R179 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R180 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J R181 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R182 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R183 QRK126J-151X UNF C RESISTOR 150Ω 1/2W J R184 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R185 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R186 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R187 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R190 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R191 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R193 NRSA63J-101X MG RESISTOR 100 R194 NRSA63J-101X MG RESISTOR 100 R195 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R201 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R202 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R203 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J R204 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R205 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R206 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R207 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R208 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R211 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R212 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R213 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J R214 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R215 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R216 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R217 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R218 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R221 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R222 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R223 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J R224 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R225 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R226 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R227 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R228 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R231 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R232 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R234 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R235 NRSA63J-333X MG RESISTOR 33k R237 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R241 NRSA63J-222X MG RESISTOR 2.2k R242 NRSA63J-222X MG RESISTOR 2.2k R301 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R302 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R303 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R304 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R311 NRSA63J-750X MG RESISTOR 75 R312 NRSA63J-223X MG RESISTOR 22k R313 NRSA63J-333X MG RESISTOR 33k R314 NRSA63J-222X MG RESISTOR 2.2k R321 NRSA63J-750X MG RESISTOR 75 R322 NRSA63J-223X MG RESISTOR 22k R323 NRSA63J-333X MG RESISTOR 33k R324 NRSA63J-222X MG RESISTOR 2.2k R341 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R342 NRSA63J-222X MG RESISTOR 2.2k R343 NRSA63J-333X MG RESISTOR 33k R344 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R501 NRSA63J-750X MG RESISTOR 75 R502 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R503 NRSA63J-750X MG RESISTOR 75 R504 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R505 NRSA63J-333X MG RESISTOR 33k R506 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R507 NRSA63J-333X MG RESISTOR 33k R508 NRSA63J-101X MG RESISTOR 100 R509 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R510 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R511 NRSA63J-222X MG RESISTOR 2.2k R512 NRSA63J-223X MG RESISTOR 22k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R513 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R514 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R515 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R525 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R526 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R527 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R529 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R530 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R531 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R532 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R533 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R534 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J R535 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J R601 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R602 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R603 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R604 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R605 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R606 QRL039J-330 OMF RESISTOR 33Ω 3W J R651 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R652 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R653 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R654 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R655 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R656 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R801 NRSA63J-222X MG RESISTOR 2.2k R802 NRSA63J-222X MG RESISTOR 2.2k R803 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R804 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R805 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R806 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R807 NRSA63J-752X MG RESISTOR 7.5kΩ 1/16W J R808 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R809 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R816 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R817 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R818 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R819 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R851 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R852 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R853 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J R854 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R855 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R856 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J R857 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R859 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R860 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R861 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R862 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R863 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R864 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R865 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R866 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R867 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R869 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R873 NRSA63J-821X MG RESISTOR 820 R874 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R875 NRSA63J-391X MG RESISTOR 390 R876 NRSA63J-0R0X MG RESISTOR 0 R877 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R879 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R883 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R884 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R885 NRSA63J-123X MG RESISTOR 12k R886 NRSA63J-562X MG RESISTOR 5.6k R887 NRSA63J-102X MG RESISTOR 1k R888 NRSA63J-102X MG RESISTOR 1k R889 NRSA63J-102X MG RESISTOR 1k R893 NRSA63J-392X MG RESISTOR 3.9k

L807 NQR0413-003X FERRITE BEADS L808 NQR0413-003X FERRITE BEADS L809 NQR0413-003X FERRITE BEADS L851 NQL092K-6R8X P COIL 6.8uH K L852 NQL092K-6R8X P COIL 6.8uH K L853 NQL092K-6R8X P COIL 6.8uH K L854 NQL092M-270X P COIL 27uH M L861 NQL79GM-220X COIL 22uH M L862 NQL034K-4R7X COIL 4.7uH K L863 NQL034K-4R7X COIL 4.7uH K L864 NQL79GM-101X COIL 100uH M L865 NQL79GM-220X COIL 22uH M L866 NQL79GM-220X COIL 22uH M L867 NQL79GM-220X COIL 22uH M L868 NRSA02J-0R0X MG RESISTOR 0

CN006 QGB1505K1-25 CONNECTOR B-B (1-25)

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/10W J

(No.YA087)3-17



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

CN007 QGB1505K1-35 CONNECTOR B-B (1-35) J001 QNZ0419-001 21P CONNECTOR EXT-1 J002 QNZ0419-001 21P CONNECTOR EXT-2 J003 QNZ0419-001 21P CONNECTOR EXT-3 J004 QNN0463-001 PIN JACK EXT-4 COMP IN J005 QNN0493-001 PIN JACK EXT-4 L/R IN J006 QNN0493-001 PIN JACK L/R OUT K101 NQR0389-003X FERRITE BEADS K102 NQR0389-003X FERRITE BEADS K103 NQR0389-003X FERRITE BEADS K104 NQR0389-003X FERRITE BEADS K105 NQR0389-003X FERRITE BEADS K501 NQR0389-003X FERRITE BEADS K502 NQR0389-003X FERRITE BEADS X801 QAX0305-001 CRYSTAL 16.2MHz

DIST P.W. BOARD ASS'Y (SMM0Z001A-U2)



Ref No. Part No. Part Name Description Local

IC005 SN74AHCT1G08V-X IC IC013 SN74AHC2G34T-X IC IC104 SN74AHC2G74T-X IC IC105 SN74AHC1G08V-X IC IC106 S-80828CLNB-W IC IC107 LP3964EMP-ADJ-X IC IC108 PQ070XZ02Z-X IC IC205 SN74LVC2G126T-X IC IC206 SN74LVC1G126V-X IC IC213 SN74AHC2G74T-X IC IC301 MM1563DF-X IC IC631 SN74AHC1G66HV-X IC IC1001 JCC5055 IC IC1002 MT46V2M32V1LG55 IC IC1003 MT46V2M32V1LG55 IC IC1004 LP2995M-X IC IC1005 MM1563DF-X IC IC1301 AN15394A IC IC1401 SN74HC32NS-X IC(DIGITAL) IC3001 TC90A92AFG IC IC3002 R1141Q151D-X IC IC3003 MM1572FN-X IC

Q1301 2SA1022/BC/-X TRANSISTOR Q1302 2SA1022/BC/-X TRANSISTOR Q1303 2SA1022/BC/-X TRANSISTOR Q1304 2SC3837K/NP/-X TRANSISTOR Q1305 2SC3837K/NP/-X TRANSISTOR Q1306 2SC3837K/NP/-X TRANSISTOR Q1307 2SC3837K/NP/-X TRANSISTOR Q1308 2SC3837K/NP/-X TRANSISTOR Q1309 2SC3837K/NP/-X TRANSISTOR Q1312 2SC3928A/QR/-X TRANSISTOR Q1313 2SC3928A/QR/-X TRANSISTOR Q1314 2SC3928A/QR/-X TRANSISTOR Q1315 2SA1022/BC/-X TRANSISTOR Q1316 2SC3928A/QR/-X TRANSISTOR Q1317 2SC3928A/QR/-X TRANSISTOR Q1717 2SK1830-X MOS FET Q1718 2SK1830-X MOS FET Q3001 UN2213-X DIGI TRANSISTOR Q3002 2SC3928A/QR/-X TRANSISTOR Q3101 2SC3928A/QR/-X TRANSISTOR Q3102 2SC3928A/QR/-X TRANSISTOR Q3103 2SA1530A/QR/-X TRANSISTOR Q3121 2SC3928A/QR/-X TRANSISTOR Q3122 2SC3928A/QR/-X TRANSISTOR Q3123 2SA1530A/QR/-X TRANSISTOR Q3141 2SC3928A/QR/-X TRANSISTOR Q3142 2SC3928A/QR/-X TRANSISTOR Q3143 2SA1530A/QR/-X TRANSISTOR Q3161 2SC3928A/QR/-X TRANSISTOR Q3162 2SC3928A/QR/-X TRANSISTOR Q3163 2SA1530A/QR/-X TRANSISTOR QB003 UMX1N-W PAIR TRANSISTOR QB007 UMX1N-W PAIR TRANSISTOR QB010 UMX1N-W PAIR TRANSISTOR QB011 2SC3837K/NP/-X TRANSISTOR QB012 2SA1022/BC/-X TRANSISTOR QB014 2SA1022/BC/-X TRANSISTOR QB015 2SC3928A/QR/-X TRANSISTOR QB017 UMX1N-W PAIR TRANSISTOR QB018 UMX1N-W PAIR TRANSISTOR QB019 2SA1022/BC/-X TRANSISTOR

QB021 2SC3837K/NP/-X TRANSISTOR QB022 2SA1022/BC/-X TRANSISTOR QB024 2SA1022/BC/-X TRANSISTOR QB025 2SC3928A/QR/-X TRANSISTOR QB027 UMX1N-W PAIR TRANSISTOR QB028 UMX1N-W PAIR TRANSISTOR QB029 2SA1022/BC/-X TRANSISTOR QB031 2SC3837K/NP/-X TRANSISTOR QB032 2SA1022/BC/-X TRANSISTOR QB034 2SA1022/BC/-X TRANSISTOR QB035 2SC3928A/QR/-X TRANSISTOR QB037 UMX1N-W PAIR TRANSISTOR QB038 UMX1N-W PAIR TRANSISTOR QB039 2SA1022/BC/-X TRANSISTOR QB211 2SA1022/BC/-X TRANSISTOR QB212 2SC3837K/NP/-X TRANSISTOR QB213 2SC3837K/NP/-X TRANSISTOR QB214 2SC3837K/NP/-X TRANSISTOR QB215 2SC3837K/NP/-X TRANSISTOR QB241 2SA1022/BC/-X TRANSISTOR QB242 2SC3837K/NP/-X TRANSISTOR QB243 2SC3837K/NP/-X TRANSISTOR QB244 2SC3837K/NP/-X TRANSISTOR QB245 2SC3837K/NP/-X TRANSISTOR QB271 2SA1022/BC/-X TRANSISTOR QB272 2SC3837K/NP/-X TRANSISTOR QB273 2SC3837K/NP/-X TRANSISTOR QB274 2SC3837K/NP/-X TRANSISTOR QB275 2SC3837K/NP/-X TRANSISTOR QB289 2SC3928A/QR/-X TRANSISTOR QB290 2SA1530A/QR/-X TRANSISTOR QB291 2SC3928A/QR/-X TRANSISTOR QB292 2SA1530A/QR/-X TRANSISTOR QB631 2SA1022/BC/-X TRANSISTOR QB632 2SC3837K/NP/-X TRANSISTOR QB633 2SC3837K/NP/-X TRANSISTOR QB634 2SC3837K/NP/-X TRANSISTOR QB635 2SC3837K/NP/-X TRANSISTOR QB636 2SA1022/BC/-X TRANSISTOR QB637 2SC3837K/NP/-X TRANSISTOR

D1301 MA111-X SI DIODE D1302 MA111-X SI DIODE D1303 MA111-X SI DIODE D1309 MA111-X SI DIODE D1310 MA111-X SI DIODE D1405 MA111-X SI DIODE D1406 MA111-X SI DIODE D3001 EC30HA03L-X SB DIODE D3002 EC30HA03L-X SB DIODE D3004 MA111-X SI DIODE

C1001 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1002 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1003 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1004 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1005 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1006 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1007 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1008 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1009 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1010 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1011 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1012 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1013 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1017 NEH71CM-106X E CAPACITOR 10uF 16V M C1018 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1019 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1020 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1021 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1022 NDC31HJ-101X C CAPACITOR 100pF 50V J C1023 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1024 NDC31HJ-101X C CAPACITOR 100pF 50V J C1025 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1026 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1027 NBZ0007-107X SP E CAPACITOR 100uF 6.3V M C1028 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1029 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1030 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1031 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1032 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1033 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1034 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1035 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1036 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1037 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1038 NCB31CK-104X C CAPACITOR 0.1uF 16V K

3-18(No.YA087)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C1039 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1040 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1041 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1042 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1043 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1044 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1045 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1046 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1047 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1048 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1049 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1050 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1053 NCB31HK-152X C CAPACITOR 1500pF 50V K C1054 NCB31HK-223X C CAPACITOR 0.022uF 50V K C1056 NCB31AK-334X C CAPACITOR 0.33uF 10V K C1058 NCB31AK-334X C CAPACITOR 0.33uF 10V K C1061 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1062 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1063 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1064 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1067 NEH71CM-106X E CAPACITOR 10uF 16V M C1068 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1069 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C1070 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C1071 NDC31HJ-471X C CAPACITOR 470pF 50V J C1072 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1074 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1075 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1076 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1077 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1078 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1079 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1080 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1081 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1082 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1083 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1084 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1085 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1086 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1087 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1088 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1089 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1090 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1091 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1092 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1093 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1094 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1095 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1096 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1097 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1098 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1099 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1100 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1101 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1102 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1103 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1104 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1105 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1106 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1107 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1108 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1109 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1110 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1111 N CB3 1CK -104X C CAPACITOR 0.1uF 16V K C1112 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1113 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1114 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1115 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1116 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1117 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1118 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1119 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1120 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1121 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1122 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1123 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1124 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1125 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1126 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1127 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1128 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1129 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1130 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1131 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1132 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1133 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1134 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C1135 NEH70JM-107X E CAPACITOR 100uF 6.3V M C1141 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1142 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1143 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1144 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1145 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1146 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1147 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1148 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1149 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1301 NEN51HM-105X BP E CAPACITOR 1uF 50V M C1302 NEN51HM-105X BP E CAPACITOR 1uF 50V M C1303 NEN51HM-105X BP E CAPACITOR 1uF 50V M C1304 NEH71AM-107X E CAPACITOR 100uF 10V M C1305 NCB11CK-475X C CAPACITOR 4.7uF 16V K C1306 NEH71CM-476X E CAPACITOR 47uF 16V M C1307 NCB31HK-472X C CAPACITOR 4700pF 50V K C1308 NEH71CM-476X E CAPACITOR 47uF 16V M C1309 NCB31HK-472X C CAPACITOR 4700pF 50V K C1310 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1311 NCF31AZ-105X C CAPACITOR 1uF 10V Z C1312 NCF31AZ-105X C CAPACITOR 1uF 10V Z C1313 NCF31AZ-105X C CAPACITOR 1uF 10V Z C1314 NCB30JK-105X C CAPACITOR 1uF 6.3V K C1315 NCB30JK-105X C CAPACITOR 1uF 6.3V K C1316 NCB30JK-105X C CAPACITOR 1uF 6.3V K C1317 NEH71HM-335X E CAPACITOR 3.3uF 50V M C1318 NEH71HM-335X E CAPACITOR 3.3uF 50V M C1319 NEH71HM-335X E CAPACITOR 3.3uF 50V M C1320 NEH71CM-106X E CAPACITOR 10uF 16V M C1321 NEH71EM-475X E CAPACITOR 4.7uF 25V M C1323 NEH71HM-105X E CAPACITOR 1uF 50V M C1324 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1325 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1326 NCF11EZ-105X C CAPACITOR 1uF 25V Z C1327 NCF11EZ-105X C CAPACITOR 1uF 25V Z C1328 NCF11EZ-105X C CAPACITOR 1uF 25V Z C1329 NCB31HK-332X C CAPACITOR 3300pF 50V K C1330 NCB31HK-332X C CAPACITOR 3300pF 50V K C1331 NCB31HK-332X C CAPACITOR 3300pF 50V K C1332 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1333 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1336 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1337 NCB31CK-563X C CAPACITOR 0.056uF 16V K C1338 NEH71HM-335X E CAPACITOR 3.3uF 50V M C1339 NEH71AM-107X E CAPACITOR 100uF 10V M C1340 NCB31HK-472X C CAPACITOR 4700pF 50V K C1341 NEH71HM-225X E CAPACITOR 2.2uF 50V M C1342 NEH71HM-335X E CAPACITOR 3.3uF 50V M C1343 NCF31AZ-105X C CAPACITOR 1uF 10V Z C1344 NDC31HJ-220X C CAPACITOR 22pF 50V J C1401 NCF31AZ-105X C CAPACITOR 1uF 10V Z C1404 NDC31HJ-100X C CAPACITOR 10pF 50V J C3001 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3002 NEH71EM-226X E CAPACITOR 22uF 25V M C3003 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3004 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3005 NCB31HK-152X C CAPACITOR 1500pF 50V K C3006 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3007 NEH71CM-106X E CAPACITOR 10uF 16V M C3008 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3009 NDC31HJ-220X C CAPACITOR 22pF 50V J C3010 NDC31HJ-180X C CAPACITOR 18pF 50V J C3011 NDC31HJ-102X C CAPACITOR 1000pF 50V J C3012 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3013 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3014 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3015 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3016 NEH71CM-106X E CAPACITOR 10uF 16V M C3017 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3018 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3019 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3020 NEH71CM-476X E CAPACITOR 47uF 16V M C3021 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3022 NEH71CM-476X E CAPACITOR 47uF 16V M C3023 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3024 NEH71CM-476X E CAPACITOR 47uF 16V M C3025 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3026 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3027 NEH71CM-106X E CAPACITOR 10uF 16V M C3028 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3029 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3030 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3031 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3032 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3033 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3034 NDC31HJ-151X C CAPACITOR 150pF 50V J

(No.YA087)3-19



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C3035 NDC31HJ-680X C CAPACITOR 68pF 50V J C3036 NEH70JM-107X E CAPACITOR 100uF 6.3V M C3037 NCB31HK-104X C CAPACITOR 0.1uF 50V K C3038 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3039 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3040 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3041 NEH71EM-226X E CAPACITOR 22uF 25V M C3042 NCB31HK-104X C CAPACITOR 0.1uF 50V K C3043 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3044 NEH71EM-226X E CAPACITOR 22uF 25V M C3045 NCB31HK-104X C CAPACITOR 0.1uF 50V K C3046 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3047 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3048 NEN51HM-474X BP E CAPACITOR 0.47uF 50V M C3049 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3050 NEN51HM-474X BP E CAPACITOR 0.47uF 50V M C3051 NEN51HM-474X BP E CAPACITOR 0.47uF 50V M C3052 NCB30JK-105X C CAPACITOR 1uF 6.3V K C3053 NEH71CM-476X E CAPACITOR 47uF 16V M C3054 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3055 NEH71CM-476X E CAPACITOR 47uF 16V M C3056 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3057 NCB30JK-105X C CAPACITOR 1uF 6.3V K C3058 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3059 NEH71CM-476X E CAPACITOR 47uF 16V M C3060 NDC31HJ-4R0X C CAPACITOR 4pF 50V J C3101 NEN51AM-336X BP E CAPACITOR 33uF 10V M C3102 NDC31HJ-330X C CAPACITOR 33pF 50V J C3103 NDC31HJ-560X C CAPACITOR 56pF 50V J C3104 NDC31HJ-330X C CAPACITOR 33pF 50V J C3105 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C3106 NCB31HK-104X C CAPACITOR 0.1uF 50V K C3107 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3108 NEH71CM-476X E CAPACITOR 47uF 16V M C3121 NCB31AK-334X C CAPACITOR 0.33uF 10V K C3122 NDC31HJ-330X C CAPACITOR 33pF 50V J C3123 NDC31HJ-560X C CAPACITOR 56pF 50V J C3124 NDC31HJ-330X C CAPACITOR 33pF 50V J C3125 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C3126 NCB31HK-104X C CAPACITOR 0.1uF 50V K C3141 NEN51AM-336X BP E CAPACITOR 33uF 10V M C3142 NDC31HJ-330X C CAPACITOR 33pF 50V J C3143 NDC31HJ-560X C CAPACITOR 56pF 50V J C3144 NDC31HJ-330X C CAPACITOR 33pF 50V J C3145 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C3146 NCB31HK-104X C CAPACITOR 0.1uF 50V K C3161 NEN51AM-336X BP E CAPACITOR 33uF 10V M C3162 NDC31HJ-330X C CAPACITOR 33pF 50V J C3163 NDC31HJ-560X C CAPACITOR 56pF 50V J C3164 NDC31HJ-330X C CAPACITOR 33pF 50V J C3165 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C3166 NCB31HK-104X C CAPACITOR 0.1uF 50V K CB002 NDC31HJ-6R0X C CAPACITOR 6pF 50V J CB005 NDC31HJ-680X C CAPACITOR 68pF 50V J CB006 NDC31HJ-270X C CAPACITOR 27pF 50V J CB008 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB009 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB012 NDC31HJ-6R0X C CAPACITOR 6pF 50V J CB014 NDC31HJ-270X C CAPACITOR 27pF 50V J CB015 NDC31HJ-680X C CAPACITOR 68pF 50V J CB016 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB017 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB019 NDC31HJ-6R0X C CAPACITOR 6pF 50V J CB021 NDC31HJ-270X C CAPACITOR 27pF 50V J CB022 NDC31HJ-680X C CAPACITOR 68pF 50V J CB023 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB024 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB046 NEH71CM-106X E CAPACITOR 10uF 16V M CB051 NEN51AM-336X BP E CAPACITOR 33uF 10V M CB052 NEN51AM-336X BP E CAPACITOR 33uF 10V M CB053 NEN51AM-336X BP E CAPACITOR 33uF 10V M CB070 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB111 NEH71CM-106X E CAPACITOR 10uF 16V M CB112 NEN51AM-106X BP E CAPACITOR 10uF 10V M CB113 NEH71CM-106X E CAPACITOR 10uF 16V M CB114 NDC31HJ-820X C CAPACITOR 82pF 50V J CB115 NDC31HJ-820X C CAPACITOR 82pF 50V J CB116 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB117 NDC31HJ-331X C CAPACITOR 330pF 50V J CB119 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB120 NBE71CM-476X TA E CAPACITOR 47uF 16V M CB121 NDC31HJ-560X C CAPACITOR 56pF 50V J CB141 NEH71CM-106X E CAPACITOR 10uF 16V M CB142 NEN51AM-106X BP E CAPACITOR 10uF 10V M CB143 NEH71CM-106X E CAPACITOR 10uF 16V M CB144 NDC31HJ-820X C CAPACITOR 82pF 50V J CB145 NDC31HJ-820X C CAPACITOR 82pF 50V J

CB146 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB147 NDC31HJ-331X C CAPACITOR 330pF 50V J CB149 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB150 NBE71CM-476X TA E CAPACITOR 47uF 16V M CB151 NDC31HJ-560X C CAPACITOR 56pF 50V J CB171 NEH71CM-106X E CAPACITOR 10uF 16V M CB172 NEN51AM-106X BP E CAPACITOR 10uF 10V M CB173 NEH71HM-106X E CAPACITOR 10uF 50V M CB174 NDC31HJ-820X C CAPACITOR 82pF 50V J CB175 NDC31HJ-820X C CAPACITOR 82pF 50V J CB176 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB177 NDC31HJ-331X C CAPACITOR 330pF 50V J CB179 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB180 NBE71CM-476X TA E CAPACITOR 47uF 16V M CB181 NDC31HJ-560X C CAPACITOR 56pF 50V J CB190 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB302 NBZ0007-107X SP E CAPACITOR 100uF 6.3V M CB303 NBZ0007-107X SP E CAPACITOR 100uF 6.3V M CB321 NEH71CM-106X E CAPACITOR 10uF 16V M CB322 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K CB323 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K CB324 NEH71CM-476X E CAPACITOR 47uF 16V M CB325 NDC31HJ-471X C CAPACITOR 470pF 50V J CB357 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB359 NDC31HJ-221X C CAPACITOR 220pF 50V J CB360 NCB31HK-103X C CAPACITOR 0.01uF 50V K CB361 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB364 NBE71CM-476X TA E CAPACITOR 47uF 16V M CB365 NBE71CM-476X TA E CAPACITOR 47uF 16V M CB371 NCB30JK-105X C CAPACITOR 1uF 6.3V K CB375 NDC31HJ-101X C CAPACITOR 100pF 50V J CB376 NCF31AZ-105X C CAPACITOR 1uF 10V Z CB379 NDC31HJ-101X C CAPACITOR 100pF 50V J CB381 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB382 NBZ0007-107X SP E CAPACITOR 100uF 6.3V M CB421 NEH71CM-106X E CAPACITOR 10uF 16V M CB422 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB428 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB429 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB511 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB512 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB513 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB515 NEH71CM-476X E CAPACITOR 47uF 16V M CB517 NDC31HJ-5R0X C CAPACITOR 5pF 50V J CB519 NDC31HJ-5R0X C CAPACITOR 5pF 50V J CB521 NDC31HJ-8R0X C CAPACITOR 8pF 50V J CB522 NEH71CM-476X E CAPACITOR 47uF 16V M CB523 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB524 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB541 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB542 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB543 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB545 NEH71CM-476X E CAPACITOR 47uF 16V M CB547 NDC31HJ-5R0X C CAPACITOR 5pF 50V J CB549 NDC31HJ-5R0X C CAPACITOR 5pF 50V J CB551 NEH71CM-476X E CAPACITOR 47uF 16V M CB552 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB553 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB571 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB572 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB573 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB575 NEH71CM-476X E CAPACITOR 47uF 16V M CB577 NDC31HJ-5R0X C CAPACITOR 5pF 50V J CB579 NDC31HJ-5R0X C CAPACITOR 5pF 50V J CB581 NEH71CM-476X E CAPACITOR 47uF 16V M CB582 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB583 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB631 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB632 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB633 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB635 NEH71CM-476X E CAPACITOR 47uF 16V M CB636 NDC31HJ-5R0X C CAPACITOR 5pF 50V J CB638 NDC31HJ-5R0X C CAPACITOR 5pF 50V J CB640 NCB31HK-103X C CAPACITOR 0.01uF 50V K CB641 NEH71CM-476X E CAPACITOR 47uF 16V M CB642 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB643 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB644 NCB31CK-104X C CAPACITOR 0.1uF 16V K CB645 NDC31HJ-8R0X C CAPACITOR 8pF 50V J CB646 NDC31HJ-390X C CAPACITOR 39pF 50V J CB647 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z CB1231 NDC31HJ-560X C CAPACITOR 56pF 50V J CB1232 NDC31HJ-560X C CAPACITOR 56pF 50V J

R1001 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1002 NRSA63J-0R0X MG RESISTOR 0 R1003 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W J

Ω

1/16W J

3-20(No.YA087)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R1004 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1005 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1007 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1008 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1009 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1010 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R1013 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R1014 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1015 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R1017 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R1018 NRSA63J-201X MG RESISTOR 200Ω 1/16W J R1019 NRSA63J-201X MG RESISTOR 200Ω 1/16W J R1020 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R1021 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R1024 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1025 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1026 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R1028 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R1030 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R1032 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R1034 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J R1038 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1039 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1040 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1041 NRSA63J-0R0X MG RESISTOR 0 R1043 NRSA63J-5R6X MG RESISTOR 5.6 R1044 NRSA63D-392X MG RESISTOR 3.9kΩ 1/16W D R1045 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R1046 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1048 NRSA63J-3R3X MG RESISTOR 3.3Ω 1/16W J R1049 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R1050 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R1051 NRSA63D-332X MG RESISTOR 3.3kΩ 1/16W D R1052 NRSA63D-332X MG RESISTOR 3.3kΩ 1/16W D R1053 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R1054 NRSA63D-151X MG RESISTOR 150Ω 1/16W D R1055 NRSA63J-3R3X MG RESISTOR 3.3Ω 1/16W J R1056 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R1057 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1060 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1061 NRSA63J-3R3X MG RESISTOR 3.3Ω 1/16W J R1062 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R1069 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1070 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1073 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1085 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1086 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1087 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1088 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1089 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1091 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1092 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1096 NDC31HJ-150X C CAPACITOR 15pF 50V J R1101 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1102 NRSA63J-510X MG RESISTOR 51 R1103 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1104 NRSA63J-510X MG RESISTOR 51 R1105 NRSA63J-510X MG RESISTOR 51 R1106 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1107 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1108 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1109 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1110 NRSA63J-510X MG RESISTOR 51 R1111 N RSA 63J -510X MG RESISTOR 51 R1112 NRSA63J-510X MG RESISTOR 51 R1113 NRSA63J-220X MG RESISTOR 22 R1114 NRSA63J-220X MG RESISTOR 22 R1115 NRSA63J-220X MG RESISTOR 22 R1116 NRSA63J-220X MG RESISTOR 22 R1202 NRSA63J-510X MG RESISTOR 51 R1204 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1206 NRSA63J-510X MG RESISTOR 51 R1208 NRSA63J-510X MG RESISTOR 51 R1210 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1211 NRSA63J-510X MG RESISTOR 51 R1213 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1215 NRSA63J-510X MG RESISTOR 51 R1217 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1219 NRSA63J-510X MG RESISTOR 51 R1222 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R1301 NRSA63J-392X MG RESISTOR 3.9k R1308 NRSA63J-333X MG RESISTOR 33k R1309 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J R1310 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J R1311 NRSA63J-105X MG RESISTOR 1M R1312 NRSA63J-392X MG RESISTOR 3.9k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R1313 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J R1314 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R1315 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R1316 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R1317 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R1318 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R1319 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R1320 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R1321 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R1322 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R1323 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R1324 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R1325 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R1326 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R1327 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R1328 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1329 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1330 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1331 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R1332 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R1333 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R1334 NRSA63D-272X MG RESISTOR 2.7kΩ 1/16W D R1335 NRSA63D-272X MG RESISTOR 2.7kΩ 1/16W D R1336 NRSA63D-182X MG RESISTOR 1.8kΩ 1/16W D R1338 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1340 NRSA63D-472X MG RESISTOR 4.7k R1341 NRSA63J-821X MG RESISTOR 820 R1342 NRSA63D-222X MG RESISTOR 2.2kΩ 1/16W D R1343 NRSA63D-472X MG RESISTOR 4.7kΩ 1/16W D R1344 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R1345 NRSA63D-222X MG RESISTOR 2.2kΩ 1/16W D R1346 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R1347 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R1348 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R1349 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R1350 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R1351 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R1352 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R1353 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1354 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1355 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R1360 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1361 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1362 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1363 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1373 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1374 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1376 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R1377 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R1378 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R1379 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R1380 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R1381 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R1382 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R1383 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1384 NRSA63J-471X MG RESISTOR 470 R1385 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1386 NRSA63J-0R0X MG RESISTOR 0 R1387 NRSA63J-0R0X MG RESISTOR 0 R1403 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1407 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R1408 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R1409 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1410 NRSA63J-221X MG RESISTOR 220 R1411 NRSA63J-223X MG RESISTOR 22k R1429 NRSA63J-0R0X MG RESISTOR 0 R1857 NRSA63J-0R0X MG RESISTOR 0 R1859 NRSA63J-0R0X MG RESISTOR 0 R3001 NRSA63J-274X MG RESISTOR 270k R3002 NRSA63D-101X MG RESISTOR 100 R3003 NRSA63J-103X MG RESISTOR 10k R3004 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R3005 NRSA63J-103X MG RESISTOR 10k R3006 NRSA63J-101X MG RESISTOR 100 R3007 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3008 NRSA63J-221X MG RESISTOR 220 R3010 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R3011 NRSA63J-183X MG RESISTOR 18k R3012 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R3013 NRSA63J-122X MG RESISTOR 1.2k R3014 NQL093K-R47X COIL 0.47uH K R3101 NRSA63J-103X MG RESISTOR 10k R3102 NRSA63J-103X MG RESISTOR 10k R3103 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3104 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R3105 NRSA63J-561X MG RESISTOR 560 R3107 NRSA63J-391X MG RESISTOR 390

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.YA087)3-21



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R3109 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3110 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R3111 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3112 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3121 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3122 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3123 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3124 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R3125 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R3127 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R3129 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3130 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R3131 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3132 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3141 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3142 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3143 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3144 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R3145 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R3147 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R3149 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3150 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R3151 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3152 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3161 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3162 NRSA63J-103X MG RESISTOR 10k R3163 NRSA63J-101X MG RESISTOR 100 R3164 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R3165 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R3167 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R3169 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3170 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R3171 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3172 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RA015 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA016 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA017 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA018 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA019 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA020 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA1001 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J RA1002 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J RA1003 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J RA1004 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J RA1005 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J RA1006 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J RA1007 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J RA1008 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J RA1009 NRZ0040-101X NET RESISTOR 100Ω 1/16W J RA1010 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA1012 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA1101 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1102 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1103 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1104 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1105 NRZ0040-510X NET RESISTOR 51 RA1106 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1107 NRZ0040-510X NET RESISTOR 51 RA1108 NRZ0040-510X NET RESISTOR 51 RA1109 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1110 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1111 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1112 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1113 NRZ0040-510X NET RESISTOR 51 RA1114 NRZ0040-510X NET RESISTOR 51 RA1115 NRZ0040-510X NET RESISTOR 51 RA1116 NRZ0040-510X NET RESISTOR 51 RA1117 NRZ0040-220X NET RESISTOR 22 RA1118 NRZ0040-220X NET RESISTOR 22 RA1119 NRZ0040-220X NET RESISTOR 22 RA1120 NRZ0040-220X NET RESISTOR 22 RA1201 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1202 NRZ0040-510X NET RESISTOR 51 RA1203 NRZ0040-510X NET RESISTOR 51 RA1204 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1205 NRZ0040-510X NET RESISTOR 51 RA1206 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1207 NRZ0040-510X NET RESISTOR 51 RA1208 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1209 NRZ0040-510X NET RESISTOR 51 RA1210 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1211 NRZ0040-510X NET RESISTOR 51 RA1212 NRZ0040-510X NET RESISTOR 51 RA1301 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1302 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1303 NRZ0040-510X NET RESISTOR 51 RA1304 NRZ0040-510X NET RESISTOR 51

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

RA1305 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1306 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1307 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1308 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1309 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1310 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1311 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA1312 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3001 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA3002 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA3003 NRZ0040-103X NET RESISTOR 10kΩ 1/16W J RA3004 NRZ0040-101X NET RESISTOR 100Ω 1/16W J RA3005 NRZ0040-101X NET RESISTOR 100Ω 1/16W J RA3006 NRZ0040-101X NET RESISTOR 100Ω 1/16W J RA3007 NRZ0040-101X NET RESISTOR 100Ω 1/16W J RA3008 NRZ0040-101X NET RESISTOR 100Ω 1/16W J RA3009 NRZ0040-101X NET RESISTOR 100Ω 1/16W J RA3010 NRZ0040-101X NET RESISTOR 100Ω 1/16W J RB001 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J RB002 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J RB003 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB005 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB008 NRSA63J-151X MG RESISTOR 150Ω 1/16W J RB010 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB012 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J RB013 NRSA63J-223X MG RESISTOR 22k RB016 NRSA63J-273X MG RESISTOR 27k RB017 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J RB018 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB020 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB023 NRSA63J-151X MG RESISTOR 150Ω 1/16W J RB025 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB027 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J RB028 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J RB029 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J RB030 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J RB031 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB033 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB036 NRSA63J-151X MG RESISTOR 150Ω 1/16W J RB038 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB040 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J RB041 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J RB059 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB060 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB061 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB062 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB063 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB064 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB092 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB093 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB094 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB095 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB110 NRSA63J-471X MG RESISTOR 470Ω 1/16W J RB111 NRSA63J-471X MG RESISTOR 470Ω 1/16W J RB113 NRSA63J-100X MG RESISTOR 10Ω 1/16W J RB116 NRSA63J-101X MG RESISTOR 100 RB117 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB120 NRSA63J-102X MG RESISTOR 1k RB121 NRSA63J-222X MG RESISTOR 2.2k RB122 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J RB123 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB124 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB125 NRSA63J-151X MG RESISTOR 150Ω 1/16W J RB126 NRSA63J-103X MG RESISTOR 10k RB128 NRSA63J-182X MG RESISTOR 1.8k RB129 NRSA63J-472X MG RESISTOR 4.7k RB130 NRSA63J-472X MG RESISTOR 4.7k RB131 NRSA63J-0R0X MG RESISTOR 0 RB132 NRSA63J-102X MG RESISTOR 1k RB133 NRSA63J-0R0X MG RESISTOR 0 RB135 NRSA63J-222X MG RESISTOR 2.2k RB136 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB137 NRSA63J-472X MG RESISTOR 4.7k RB138 NRSA63J-0R0X MG RESISTOR 0 RB140 NRSA63J-471X MG RESISTOR 470Ω 1/16W J RB141 NRSA63J-471X MG RESISTOR 470 RB143 NRSA63J-820X MG RESISTOR 82Ω 1/16W J RB146 NRSA63J-101X MG RESISTOR 100 RB147 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB150 NRSA63J-102X MG RESISTOR 1k RB151 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J RB152 NRSA63J-472X MG RESISTOR 4.7k RB153 NRSA63J-181X MG RESISTOR 180 RB154 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB155 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB158 NRSA63J-182X MG RESISTOR 1.8k RB159 NRSA63J-472X MG RESISTOR 4.7k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-22(No.YA087)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

RB160 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J RB161 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB162 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB163 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB165 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J RB166 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB167 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J RB168 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB170 NRSA63J-471X MG RESISTOR 470Ω 1/16W J RB171 NRSA63J-471X MG RESISTOR 470Ω 1/16W J RB173 NRSA63J-820X MG RESISTOR 82Ω 1/16W J RB176 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB177 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB180 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB181 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J RB182 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J RB183 NRSA63J-181X MG RESISTOR 180Ω 1/16W J RB184 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB185 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB188 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J RB189 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J RB190 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J RB191 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB192 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB193 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB195 NRSA63J-222X MG RESISTOR 2.2k RB196 NRSA63J-101X MG RESISTOR 100 RB197 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J RB198 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB202 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB321 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB345 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB346 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB347 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB349 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB350 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB351 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB352 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB353 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB354 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J RB355 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J RB357 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB361 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J RB362 NRSA63D-682X MG RESISTOR 6.8kΩ 1/16W D RB363 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D RB364 NRSA63D-472X MG RESISTOR 4.7kΩ 1/16W D RB365 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J RB366 NRSA63D-332X MG RESISTOR 3.3kΩ 1/16W D RB367 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D RB368 NRSA63D-152X MG RESISTOR 1.5kΩ 1/16W D RB371 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J RB379 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB382 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB450 NRSA63J-220X MG RESISTOR 22Ω 1/16W J RB451 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB462 NRSA63J-0R0X MG RESISTOR 0 RB463 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB464 NRSA63J-331X MG RESISTOR 330 RB465 NRSA63J-331X MG RESISTOR 330 RB466 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J RB472 NRSA63J-331X MG RESISTOR 330Ω 1/16W J RB475 NRSA63J-331X MG RESISTOR 330Ω 1/16W J RB511 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J RB512 NRSA63J-122X MG RESISTOR 1.2k RB513 NRSA63J-242X MG RESISTOR 2.4k RB514 NRSA63J-750X MG RESISTOR 75 RB515 NRSA63J-0R0X MG RESISTOR 0 RB516 NRSA63J-222X MG RESISTOR 2.2k RB517 NRSA63J-473X MG RESISTOR 47k RB518 NRSA63J-0R0X MG RESISTOR 0 RB519 NRSA63J-563X MG RESISTOR 56k RB520 NRSA63J-561X MG RESISTOR 560Ω 1/16W J RB521 NRSA63J-331X MG RESISTOR 330 RB522 NRSA63J-182X MG RESISTOR 1.8k RB523 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB524 NRSA63J-152X MG RESISTOR 1.5k RB525 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D RB526 NRSA63J-0R0X MG RESISTOR 0 RB527 NRSA63J-681X MG RESISTOR 680Ω 1/16W J RB528 NRSA63D-182X MG RESISTOR 1.8k RB529 NRSA63J-151X MG RESISTOR 150Ω 1/16W J RB530 NRSA63D-681X MG RESISTOR 680 RB531 NRSA63J-472X MG RESISTOR 4.7k RB532 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J RB533 NRSA63J-680X MG RESISTOR 68Ω 1/16W J RB534 NRSA63J-471X MG RESISTOR 470 RB537 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

RB541 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J RB542 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J RB543 NRSA63J-242X MG RESISTOR 2.4kΩ 1/16W J RB544 NRSA63J-750X MG RESISTOR 75Ω 1/16W J RB545 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB546 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J RB547 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J RB548 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J RB549 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J RB550 NRSA63J-331X MG RESISTOR 330Ω 1/16W J RB551 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J RB552 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB554 NRSA63J-681X MG RESISTOR 680Ω 1/16W J RB555 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D RB556 NRSA63D-122X MG RESISTOR 1.2kΩ 1/16W D RB557 NRSA63J-221X MG RESISTOR 220Ω 1/16W J RB558 NRSA63D-561X MG RESISTOR 560Ω 1/16W D RB559 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J RB560 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J RB561 NRSA63J-680X MG RESISTOR 68Ω 1/16W J RB562 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB571 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J RB572 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J RB573 NRSA63J-242X MG RESISTOR 2.4kΩ 1/16W J RB574 NRSA63J-750X MG RESISTOR 75Ω 1/16W J RB575 NRSA63J-0R0X MG RESISTOR 0 RB576 NRSA63J-222X MG RESISTOR 2.2k RB577 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J RB578 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J RB579 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J RB580 NRSA63J-331X MG RESISTOR 330Ω 1/16W J RB581 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J RB582 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB584 NRSA63J-681X MG RESISTOR 680Ω 1/16W J RB585 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D RB586 NRSA63D-122X MG RESISTOR 1.2kΩ 1/16W D RB587 NRSA63J-221X MG RESISTOR 220Ω 1/16W J RB588 NRSA63D-561X MG RESISTOR 560Ω 1/16W D RB589 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J RB590 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J RB591 NRSA63J-680X MG RESISTOR 68Ω 1/16W J RB592 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB631 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J RB632 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J RB633 NRSA63J-242X MG RESISTOR 2.4kΩ 1/16W J RB634 NRSA63J-750X MG RESISTOR 75Ω 1/16W J RB635 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB636 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J RB637 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J RB638 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB639 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J RB640 NRSA63J-331X MG RESISTOR 330Ω 1/16W J RB641 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J RB642 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J RB643 NRSA63J-101X MG RESISTOR 100Ω 1/16W J RB644 NRSA63J-102X MG RESISTOR 1k RB645 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RB646 NRSA63D-102X MG RESISTOR 1k RB647 NRSA63J-680X MG RESISTOR 68 RB648 NRSA63J-681X MG RESISTOR 680Ω 1/16W J RB649 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D RB650 NRSA63J-221X MG RESISTOR 220Ω 1/16W J RB651 NRSA63D-821X MG RESISTOR 820Ω 1/16W D RB652 NRSA63J-472X MG RESISTOR 4.7k RB653 NRSA63J-182X MG RESISTOR 1.8k RB654 NRSA63J-680X MG RESISTOR 68 RB655 NRSA63J-102X MG RESISTOR 1k RB656 NRSA63J-680X MG RESISTOR 68 RB657 NRSA63J-103X MG RESISTOR 10k RB658 NRSA63J-222X MG RESISTOR 2.2k RB659 NRSA63J-122X MG RESISTOR 1.2k RB660 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J RB1864 NRSA63J-103X MG RESISTOR 10k RB1865 NRSA63J-103X MG RESISTOR 10k

L1004 NQR0489-002X FERRITE BEADS L1005 NQR0489-002X FERRITE BEADS L1006 NQR0489-002X FERRITE BEADS L1007 NQR0489-002X FERRITE BEADS L1008 NQR0489-002X FERRITE BEADS L1009 NQR0489-002X FERRITE BEADS L1012 NQR0489-002X FERRITE BEADS L1014 NQR0489-002X FERRITE BEADS L1015 NQR0489-002X FERRITE BEADS L1017 NQR0489-002X FERRITE BEADS L1301 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3001 NQL79GM-330X COIL 33uH M

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.YA087)3-23



Ref No. Part No. Part Name Description Local

L3002 NQL79GM-470X COIL 47uH M L3003 NQL092K-1R5X COIL 1.5uH K L3004 NQL79GM-100X COIL 10uH M L3005 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3006 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3007 NQL79GM-220X COIL 22uH M L3008 NQL79GM-220X COIL 22uH M L3009 NQL79GM-330X COIL 33uH M L3010 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3011 NQL79GM-470X COIL 47uH M L3101 NQL092K-6R8X P COIL 6.8uH K L3102 NQR0489-002X FERRITE BEADS L3121 NQL092K-6R8X P COIL 6.8uH K L3141 NQL092K-6R8X P COIL 6.8uH K L3161 NQL092K-6R8X P COIL 6.8uH K LB001 NQL092K-2R2X P COIL 2.2uH K LB002 NQL092K-2R2X P COIL 2.2uH K LB003 NQL092K-2R2X P COIL 2.2uH K LB021 NQR0489-002X FERRITE BEADS LB202 NQR0489-002X FERRITE BEADS LB203 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J LB211 NQL092K-2R2X P COIL 2.2uH K LB241 NQL092K-2R2X P COIL 2.2uH K LB271 NQL092K-2R2X P COIL 2.2uH K LB301 NQR0489-002X FERRITE BEADS LB302 NRSA02J-0R0X MG RESISTOR 0 LB631 NQL092K-2R2X P COIL 2.2uH K

CN008 QGB1509K1-55T CONNECTOR B-B (1-55) CN009 QGB1509K1-55T CONNECTOR B-B (1-55) K1003 NQR0489-002X FERRITE BEADS K1004 NQR0489-002X FERRITE BEADS K1005 NQR0489-002X FERRITE BEADS K1006 NQR0489-002X FERRITE BEADS K1009 NQR0489-002X FERRITE BEADS K1712 NRSA63J-0R0X MG RESISTOR 0 K3001 NQR0489-002X FERRITE BEADS K3002 NQR0489-002X FERRITE BEADS K3003 NQR0489-002X FERRITE BEADS K3004 NQR0489-002X FERRITE BEADS K3005 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J LC025 NQR0483-005X EMI FILTER 100uF 25V Z LC026 NQR0483-005X EMI FILTER 100uF 25V Z LC027 NQR0483-005X EMI FILTER 100uF 25V Z LC101 NQR0483-005X EMI FILTER 100uF 25V Z LC102 NQR0483-005X EMI FILTER 100uF 25V Z LC103 NQR0483-005X EMI FILTER 100uF 25V Z LC1015 NQR0416-001X EMI FILTER 240pF 16V M LC1016 NQR0416-001X EMI FILTER 240pF 16V M LC1720 NQR0416-001X EMI FILTER 240pF 16V M LC1721 NQR0416-001X EMI FILTER 240pF 16V M LC3101 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J LC3121 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J LC3141 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J LC3161 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J X201 NAX0526-001X CXO 74.1758MHz X1001 NAX0635-001X CXO X3001 NAX0642-001X CRYSTAL

Ω

1/10W J

Ω

1/16W J

3-24(No.YA087)

PRINTED WIRING BOARD PARTS LIST [HV-32D40BK]



MAIN P.W. BOARD ASS'Y (SMM-1011A-U2)

REFER TO PARTS LIST IN PAGE 3-6 FOR THIS P.W. BOARD.

POWER&DEF P.W. BOARD ASS'Y (SMM-2011A-U2)



Ref No. Part No. Part Name Description Local

IC401 LA78041 IC IC901 STR-F6268S-F7 IC IC951 SE140N IC



D401 RD100E/B/-T2 Z DIODE D402 1SR35-400A-T2 SI DIODE D404 1SS133-T2 DIODE D405 1SS133-T2 DIODE D406 MTZJ6.8C-T2 Z DIODE D407 MTZJ6.8C-T2 Z DIODE D461 RGP10J-04TS-T3 SI DIODE D501 1SS133-T2 DIODE D522 V11CA-C1 SI DIODE D523 FMV-3FU-F1 SI DIODE D524 RG2A-LFC4 SI DIODE D525 1SS81-T5 SI DIODE D526 MTZJ12C-T2 Z DIODE D527 MTZJ15B-T2 Z DIODE D528 MTZJ15B-T2 Z DIODE D550 RU4DS-F1 SI DIODE D551 1SR124-400A-T2 SI DIODE D553 RGP10J-04TS-T3 SI DIODE D554 QRE141J-0R0Y C RESISTOR 0 D555 RU1P-T3 SI DIODE D556 1SR35-400A-T2 SI DIODE D557 MTZJ9.1B-T2 Z DIODE D701 RH1S-T3 SI DIODE D702 RU3AM-LFC4 SI DIODE D703 RU3AM-LFC4 SI DIODE D901 D3SB60 BRIDGE DIODE D902 RG1C-LFA1 SI DIODE D904 RGP10J-04TS-T3 SI DIODE D905 RGP10J-04TS-T3 SI DIODE D906 MTZJ39C-T2 Z DIODE D907 1SS133-T2 DIODE D911 MTZJ15B-T2 Z DIODE D942 1SS133-T2 DIODE D944 1SS133-T2 DIODE D951 RU4B-F1 SI DIODE D952 RU4B-F1 SI DIODE D953 RGP10J-04TS-T3 SI DIODE D954 FMB-G16L SI DIODE D955 RU3YX-LFC4 SI DIODE D956 FMX-G12S SI DIODE D958 MTZJ7.5S-T2 Z DIODE D959 MTZJ33B-T2 Z DIODE D960 MTZJ15B-T2 Z DIODE D961 1SS133-T2 DIODE D962 1SS133-T2 DIODE D963 1SS133-T2 DIODE D964 MTZJ9.1B-T2 Z DIODE D965 1SS133-T2 DIODE D966 1SS133-T2 DIODE D968 1SS133-T2 DIODE D969 1SS133-T2 DIODE

Ω

1/4W J

Ref No. Part No. Part Name Description Local



C903 QCZ9054-472 C CAPACITOR 4700pF AC250V Z



C904 QCZ9054-472 C CAPACITOR 4700pF AC250V Z



R401 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R402 QRA14CF-5601Y CMF RESISTOR 5.6k R403 QRA14CF-1002Y CMF RESISTOR 10kΩ 1/4W F R404 QRE121J-180Y C RESISTOR 18 R405 QRA14CF-6801Y CMF RESISTOR 6.8k R406 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J

Ω

1/4W F

Ω

1/2W J

Ω

1/4W F

(No.YA087)3-25



Ref No. Part No. Part Name Description Local

R407 QRA14CF-3301Y CMF RESISTOR 3.3kΩ 1/4W F R408 QRA14CF-8200Y CMF RESISTOR 820Ω 1/4W F R409 QRA14CF-8200Y CMF RESISTOR 820Ω 1/4W F R410 QRL029J-151 OMF RESISTOR 150Ω 2W J R411 QRX029J-2R2 MF RESISTOR 2.2Ω 2W J R412 QRE121J-8R2Y C RESISTOR 8.2Ω 1/2W J R414 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R415 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R416 QRE141J-101Y C RESISTOR 100Ω 1/4W J R417 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R418 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R461 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R462 QRE141J-470Y C RESISTOR 47Ω 1/4W J R465 QRL029J-102 OMF RESISTOR 1kΩ 2W J R466 QRL029J-820 OMF RESISTOR 82Ω 2W J R467 QRL029J-820 OMF RESISTOR 82Ω 2W J R468 QRL039J-332 OMF RESISTOR 3.3kΩ 3W J R501 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J R502 QRE121J-271Y C RESISTOR 270Ω 1/2W J R503 QRE141J-820Y C RESISTOR 82Ω 1/4W J R504 QRL039J-221 OMF RESISTOR 220Ω 3W J R505 QRL039J-271 OMF RESISTOR 270Ω 3W J R506 QRE121J-102Y C RESISTOR 1kΩ 1/2W J R524 QRE121J-220Y C RESISTOR 22Ω 1/2W J R525 QRL029J-821 OMF RESISTOR 820Ω 2W J R526 QRE141J-333Y C RESISTOR 33k R527 QRE141J-103Y C RESISTOR 10k R528 QRE141J-470Y C RESISTOR 47Ω 1/4W J R529 QRE141J-822Y C RESISTOR 8.2kΩ 1/4W J R530 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R531 QRE141J-102Y C RESISTOR 1kΩ 1/4W J R532 QRE141J-101Y C RESISTOR 100Ω 1/4W J R533 QRF054J-470 UNF WW RESISTOR 47Ω 5W J R535 QRE141J-330Y C RESISTOR 33Ω 1/4W J R537 QRE141J-102Y C RESISTOR 1kΩ 1/4W J



R551 QRZ9017-4R7 FUSI RESISTOR 4.7Ω 1/4W J



R552 QRA14CF-2702Y CMF RESISTOR 27kΩ 1/4W F R554 QRA14CF-2702Y CMF RESISTOR 27kΩ 1/4W F R557 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J R558 QRM059J-R15 MP RESISTOR 0.15Ω 5W J R564 QRE141J-274Y C RESISTOR 270kΩ 1/4W J R565 QRA14CF-1503Y CMF RESISTOR 150kΩ 1/4W F R566 QRA14CF-1503Y CMF RESISTOR 150kΩ 1/4W F R567 QRA14CF-1503Y CMF RESISTOR 150kΩ 1/4W F R568 QRA14CF-5601Y CMF RESISTOR 5.6kΩ 1/4W F



R701 QRZ9009-1R5 FUSI RESISTOR 1.5Ω 1/2W J



R702 QRZ9011-2R7 FUSI RESISTOR 2.7Ω 1/2W J



R703 QRZ9011-2R7 FUSI RESISTOR 2.7Ω 1/2W J R704 QRG01GJ-220 OMF RESISTOR 22Ω 1W J R705 QRE121J-123Y C RESISTOR 12kΩ 1/2W J R706 QRX01GJ-3R3 MF RESISTOR 3.3Ω 1W J R901 QRF154K-4R7 UNF WW RESISTOR 4.7Ω 15W K R902 QRE121J-474Y C RESISTOR 470kΩ 1/2W J R903 QRE121J-474Y C RESISTOR 470kΩ 1/2W J R905 QRL039J-823 OMF RESISTOR 82kΩ 3W J R906 QRL039J-823 OMF RESISTOR 82k R907 QRL039J-683 OMF RESISTOR 68kΩ 3W J



R908 QRZ9017-4R7 FUSI RESISTOR 4.7Ω 1/4W J R909 QRE121J-152Y C RESISTOR 1.5k R911 QRE121J-152Y C RESISTOR 1.5kΩ 1/2W J R912 QRE121J-221Y C RESISTOR 220Ω 1/2W J R913 QRM059J-R10 MP RESISTOR 0.1Ω 5W J R915 QRE121J-331Y C RESISTOR 330Ω 1/2W J R917 QRE141J-154Y C RESISTOR 150k R944 QRE141J-273Y C RESISTOR 27k R945 QRE141J-123Y C RESISTOR 12k R946 QRE141J-682Y C RESISTOR 6.8k R947 QRE141J-333Y C RESISTOR 33k R951 QRL039J-681 OMF RESISTOR 680 R952 QRE121J-103Y C RESISTOR 10k R958 QRL029J-821 OMF RESISTOR 820 R959 QRX029J-1R2 MF RESISTOR 1.2Ω 2W J R960 QRX029J-1R5 MF RESISTOR 1.5 R962 QRE121J-392Y C RESISTOR 3.9k R963 QRE121J-223Y C RESISTOR 22kΩ 1/2W J R964 QRE141J-473Y C RESISTOR 47k R965 QRE141J-333Y C RESISTOR 33kΩ 1/4W J R966 QRE141J-102Y C RESISTOR 1k R967 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J R968 QRE141J-562Y C RESISTOR 5.6k R969 QRE141J-104Y C RESISTOR 100kΩ 1/4W J R971 QRG01GJ-181 OMF RESISTOR 180 R972 QRE141J-102Y C RESISTOR 1k R974 QRE141J-103Y C RESISTOR 10kΩ 1/4W J R975 QRE141J-683Y C RESISTOR 68kΩ 1/4W J R976 QRE141J-472Y C RESISTOR 4.7k



R999 QRZ9046-825Z C RESISTOR 8.2MΩ 1/2W K

Ω

1/4W J

Ω

1/4W J

Ω

3W J

Ω

1/2W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

3W J

Ω

1/2W J

Ω

2W J

Ω

2W J

Ω

1/2W J

Ω

1/4W J

Ω

1/4W J

Ω

1/4W J

Ω

1W J

Ω

1/4W J

Ω

1/4W J



Ref No. Part No. Part Name Description Local

L461 QQR1425-001 CHOKE COIL L523 QQR1425-001 CHOKE COIL L524 QQR1423-001 CHOKE COIL L525 QQR1149-006 LINEARITY COIL L553 QQLZ026-220 COIL 22uH ±7% L701 QQR1422-001 CHOKE COIL L903 QQR1200-003 CHOKE COIL L951 QQLZ026-460 COIL 46uH ±7% L952 QQL26AK-220Z CHOKE COIL 22uH K L953 QQLZ026-240 COIL 24uH ±7% T501 QQR1424-001 DRIVE TRANSF T521 QQR1188-001 PIN TRANSF



T701 QQR1427-001 DAF TRANSF



T901 QQS0230-001 SW TRANSF

CN001 QGB1506M1-16 CONNECTOR B-B (1-16) CN002 QGB1506M1-16 CONNECTOR B-B (1-16) CN003 QGB1506M1-16 CONNECTOR B-B (1-16) CN00K QUB572-26FPFX SIN TWIST WIRE CN00L CE41507-001P LV CONNECTOR CN00P QJK002-033023 SIN CR C-B WIRE CN010 QGB1505J1-35 CONNECTOR B-B (1-35) CN011 QGB1505J1-15 CONNECTOR B-B (1-15) CN0E3 CE41507-001P LV CONNECTOR CN0HV CHC802T-05N-J LV CONNECTOR



CP951 QMFZ049-4R0Z-E FUSE 4A 125V



PC901 PC123Y22FZ PHOTO COUPLER



RY951 QSK0099-001 RELAY



RY952 QSK0099-001 RELAY



SG551 QAF0046-242Z SURGE ABSORBER 2400V M



TH901 QAD0133-9R0 P THERMISTOR 9Ω 220V/240V

CRT SOCKET P.W. BOARD ASS'Y (SMM-3011A-U2)



Ref No. Part No. Part Name Description Local

IC3201 TDA6111Q IC IC3202 TDA6111Q IC IC3203 TDA6111Q IC

Q3701 2SC1906-T TRANSISTOR Q3702 2SA1005/MLK/-T TRANSISTOR Q3703 2SC1959/Y/-T TRANSISTOR Q3704 2SA562TM/Y/-T TRANSISTOR Q3705 2SJ584LS-CB11 POWER MOS FET Q3706 2SK2417 POWER MOS FET

3-26(No.YA087)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R3201 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R3202 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R3203 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R3211 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3212 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3213 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3218 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3219 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3220 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3222 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3223 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J R3224 QRL029J-104-F OMF RESISTOR 100kΩ 2W J R3225 QRL029J-104-F OMF RESISTOR 100kΩ 2W J R3226 QRL029J-104-F OMF RESISTOR 100kΩ 2W J R3227 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3228 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3229 NRSA63J-0R0X MG RESISTOR 0 R3230 QRC121K-561Z COMP RESISTOR 560Ω 1/2W K R3231 QRC121K-561Z COMP RESISTOR 560Ω 1/2W K R3232 QRC121K-561Z COMP RESISTOR 560Ω 1/2W K R3234 QRZ0107-474Z C RESISTOR 470kΩ 1/2W K R3235 QRZ0107-102Z C RESISTOR 1kΩ 1/2W K R3236 QRZ0107-105Z C RESISTOR 1MΩ 1/2W K R3239 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R3701 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3702 NRSA63J-273X MG RESISTOR 27k R3703 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R3704 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R3705 NRSA63J-391X MG RESISTOR 390 R3706 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R3707 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R3710 QRZ0230-182X UNF C RESISTOR 1.8kΩ 1/4W J R3711 QRE121J-473Y C RESISTOR 47k R3712 QRE121J-473Y C RESISTOR 47kΩ 1/2W J R3713 QRZ0230-681X UNF C RESISTOR 680Ω 1/4W J R3714 QRZ0230-470X UNF C RESISTOR 47Ω 1/4W J R3715 QRZ0230-470X UNF C RESISTOR 47 R3716 QRT029J-8R2 MF RESISTOR 8.2Ω 2W J R3719 QRG01GJ-180 OMF RESISTOR 18Ω 1W J R3720 QRL039J-220 OMF RESISTOR 22Ω 3W J R3721 QRL039J-220 OMF RESISTOR 22Ω 3W J R3722 QRL039J-100 OMF RESISTOR 10 R3723 QRL039J-220 OMF RESISTOR 22Ω 3W J R3724 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3725 QRL039J-220 OMF RESISTOR 22Ω 3W J

L3211 QQL244K-5R6Z PEAKING COIL 5.6uH K

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/4W J

Ω

3W J

L3212 QQL244K-5R6Z PEAKING COIL 5.6uH K L3213 QQL244K-5R6Z PEAKING COIL 5.6uH K

CN300E WJK0164-001A E-SI C WIRE C-B CN30E1 CE41507-001P LV CONNECTOR CN30VM CHHB03-140A 3P DB WIRE ASSY H3705 CEHS12B-002Q HEAT SINK H3706 CEHS12B-002Q HEAT SINK HS3201 LC31150-002A HEAT SINK/AL-F1 HS3202 LC31150-002A HEAT SINK/AL-F1 HS3203 LC31150-002A HEAT SINK/AL-F1 K3105 QQR0621-002Z FERRITE BEADS K3202 QQR0679-001 FERRITE BEADS K3701 QQR1114-001Z FERRITE BEADS K3702 QQR0582-001Z FERRITE BEADS SG3201 QAF0056-501Z SURGE ABSORBER 500V M SG3202 QAF0056-501Z SURGE ABSORBER 500V M SG3203 QAF0056-501Z SURGE ABSORBER 500V M SK3001 QNZ0663-001 CRT SOCKET



FRONT CONTROL P.W. BOARD ASS'Y (SMM-8011A-U2)

REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.

SIDE CONTROL SW P.W. BOARD ASS'Y (SMM-8111A-U2)

REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.

LINE FILTER P.W. BOARD ASS'Y (SMM-9011A-U2)

REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.

TUNER POWER P.W. BOARD ASS'Y (SMM-9111A-U2)

REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.

SOUND DELAY P.W. BOARD ASS'Y (SMM0A201A-U2)

REFER TO PARTS LIST IN PAGE 3-12 FOR THIS P.W. BOARD.

EHT P.W. BOARD ASS'Y (SMM0E011A-U2)

REFER TO PARTS LIST IN PAGE 3-12 FOR THIS P.W. BOARD.

DEF OSC P.W. BOARD ASS'Y (SMM0H011A-U2)



Ref No. Part No. Part Name Description Local

IC0101 LA7860M-X IC IC0102 BA12FP-X IC IC0161 AN5441SA-W IC IC0162 BA10393F-XE IC IC0163 AN7805F IC IC0212 CXA1875AM-X IC

D0162 1SS355-X SI DIODE D0163 MA111-X SI DIODE D0164 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J D0222 MA8062/M/-X Z DIODE

(No.YA087)3-27



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

D0223 MA8062/M/-X Z DIODE D0751 ES1F-LFG2 SI DIODE D0752 ES1F-LFG2 SI DIODE

C0102 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0103 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0104 NDC31HJ-561X C CAPACITOR 560pF 50V J C0106 NDC31HJ-102X C CAPACITOR 1000pF 50V J C0107 NDC21HJ-122X C CAPACITOR 1200pF 50V J C0108 QETN1HM-475Z E CAPACITOR 4.7uF 50V M C0109 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0110 NCB31HK-102X C CAPACITOR 1000pF 50V K C0111 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C0112 QETN1HM-225Z E CAPACITOR 2.2uF 50V M C0113 NDC21HJ-122X C CAPACITOR 1200pF 50V J C0114 NDC31HJ-102X C CAPACITOR 1000pF 50V J C0115 NDC31HJ-102X C CAPACITOR 1000pF 50V J C0116 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0117 QTMN1CM-477Z E CAPACITOR 470uF 16V M C0118 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0119 QEKC1EM-476Z E CAPACITOR 47uF 25V M C0120 QETN1CM-476Z E CAPACITOR 47uF 16V M C0121 QETN1CM-107Z E CAPACITOR 100uF 16V M C0122 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0123 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0124 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0131 NDC31HJ-101X C CAPACITOR 100pF 50V J C0132 QETN1HM-105Z E CAPACITOR 1uF 50V M C0133 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J C0134 NCB31HK-153X C CAPACITOR 0.015uF 50V K C0135 NDC31HJ-102X C CAPACITOR 1000pF 50V J C0136 NDC31HJ-102X C CAPACITOR 1000pF 50V J C0137 NDC31HJ-102X C CAPACITOR 1000pF 50V J C0138 NDC31HJ-151X C CAPACITOR 150pF 50V J C0161 QETN1CM-108Z E CAPACITOR 1000uF 16V M C0162 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0163 QETN1AM-477Z E CAPACITOR 470uF 10V M C0164 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0165 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0166 QETN1CM-227Z E CAPACITOR 220uF 16V M C0168 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0170 NCB31HK-103X C CAPACITOR 0.01uF 50V K C0171 QFVF1HJ-184Z MF CAPACITOR 0.18uF 50V J C0172 QFVF1HJ-824Z MF CAPACITOR 0.82uF 50V J C0173 NCB31HK-153X C CAPACITOR 0.015uF 50V K C0174 QETN1HM-106Z E CAPACITOR 10uF 50V M C0175 NCS21HJ-152X C CAPACITOR 1500pF 50V J C0176 QFP31HJ-272Z PP CAPACITOR 2700pF 50V J C0177 NCB31HK-332X C CAPACITOR 3300pF 50V K C0178 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0179 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0180 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0181 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0182 NCB31CK-104X C CAPACITOR 0.1uF 16V K C0212 QETN1HM-106Z E CAPACITOR 10uF 50V M C0751 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J C0752 QETN1EM-476Z E CAPACITOR 47uF 25V M C0753 QFZ0122-752 MPP CAPACITOR 7500pF 1.8kV H C0754 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J C0761 QFZ0122-682 MPP CAPACITOR 6800pF 1.8kV H

Ω

R0101 NRSA63J-102X MG RESISTOR 1k R0103 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R0104 NRSA63J-103X MG RESISTOR 10k R0105 NRSA63J-473X MG RESISTOR 47k R0106 NRSA63J-123X MG RESISTOR 12k R0107 NRSA63J-103X MG RESISTOR 10k R0109 NRSA63J-682X MG RESISTOR 6.8k R0110 NRSA63J-223X MG RESISTOR 22k R0111 NRSA63D-153X MG RESISTOR 15k R0112 NRSA63D-182X MG RESISTOR 1.8k R0113 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R0114 NRSA63J-222X MG RESISTOR 2.2k R0116 NRSA63D-182X MG RESISTOR 1.8k R0117 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R0120 NRSA63J-183X MG RESISTOR 18k R0121 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R0122 QRG01GJ-470 OMF RESISTOR 47



R0123 QRK126J-101X UNF C RESISTOR 100Ω 1/2W J R0124 NRSA63J-562X MG RESISTOR 5.6k R0126 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0129 NRSA63D-183X MG RESISTOR 18k R0131 NRSA63J-102X MG RESISTOR 1k R0133 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R0134 NRSA63J-334X MG RESISTOR 330kΩ 1/16W J R0138 NRSA63J-103X MG RESISTOR 10k R0139 NRSA63J-223X MG RESISTOR 22k

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W D

Ω

1/16W J

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

1W J

R0140 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0141 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0142 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0143 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0161 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0162 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0163 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0164 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0165 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R0167 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0168 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0169 NRSA63J-181X MG RESISTOR 180Ω 1/16W J R0170 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R0171 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0172 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R0173 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0174 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0175 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0177 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R0178 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R0179 NRSA63D-562X MG RESISTOR 5.6kΩ 1/16W D R0180 NRSA63D-152X MG RESISTOR 1.5kΩ 1/16W D R0183 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0187 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0188 NRVA02D-101X CMF RESISTOR 100Ω 1/10W D R0190 NRSA63D-473X MG RESISTOR 47k R0191 NRSA63D-103X MG RESISTOR 10k R0216 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0217 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0223 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0224 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0225 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0751 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R0752 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0753 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R0754 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R0755 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R0756 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R0757 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R0758 QRZ0056-102Z COMP RESISTOR 1kΩ 1/2W K R0759 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0761 QRE121J-184Y C RESISTOR 180kΩ 1/2W J R0762 QRE121J-184Y C RESISTOR 180kΩ 1/2W J R0763 QRE121J-184Y C RESISTOR 180kΩ 1/2W J R0764 QRE121J-184Y C RESISTOR 180kΩ 1/2W J R0765 QRE121J-184Y C RESISTOR 180kΩ 1/2W J R0769 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0770 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

L0101 QQL244K-470Z COIL 47uH K L0103 NQL092K-100X COIL 10uH K L0104 NQL092K-100X COIL 10uH K L0105 QQL244K-101Z PEAKING COIL 100uH K T0751 QQR1096-001 DAF TRANSF

CN000K CE41507-001P LV CONNECTOR CN000L QUB572-18FPFX SIN TWIST WIRE CN0010 QGB1505K1-35 CONNECTOR B-B (1-35)

Ω

1/16W D

Ω

1/16W D

MI-COM P.W. BOARD ASS'Y (SMM0M011A-U2)

REFER TO PARTS LIST IN PAGE 3-14 FOR THIS P.W. BOARD.

AV SW P.W. BOARD ASS'Y (SMM0S011A-U2)

REFER TO PARTS LIST IN PAGE 3-15 FOR THIS P.W. BOARD.

DIST P.W. BOARD ASS'Y (SMM0Z001A-U2)

REFER TO PARTS LIST IN PAGE 3-18 FOR THIS P.W. BOARD.

3-28(No.YA087)

REMOTE CONTROL UNIT PARTS LIST (RM-C1805-1C)



Ref No. Part No. Part Name Description Local

2AA070311 BATTERY COVER

PACKING

89 10 11

PACKING PARTS LIST

 Ref.No. Part No. Part Name Description Local

1 AEM1002-089-E PACKING CASE HV-28D40BK 1 AEM1002-090-E PACKING CASE HV-32D40BK 2 AEM1114-019-E EURO LABEL HV-28D40BK 2 AEM1114-018-E EURO LABEL HV-32D40BK 3 LC11859-001B-U CUSHION ASSY 4pcs in 1set HV-28D40BK 3 LC11861-001B-U CUSHION ASSY 4pcs in 1set HV-32D40BK 4 RM-C1805-1C REMOCON UNIT 5 ------------ BATTERY R6P/AA(x2) 6 AEM1078-001A-U POLY BAG 7 AEM3021-003B-E POLY BAG

 8 LCT1596-001A-U INST BOOK

9 LCT1456-001A-U CAUTION BOOK 10 BT-54013-7E WARRANTY CARD 11 AEM3148-001B-U REGISTRATION CARD

(No.YA087)3-29

JVC HV-28D40BK, HV-32D40BK Parts List

Specifications and Main Features

Frequently Asked Questions

User Manual

USING P.W. BOARD & REMOTE CONTROL UNIT

EXPLODED VIEW PARTS LIST -1

EXPLODED VIEW -1

EXPLODED VIEW PARTS LIST -2

EXPLODED VIEW -2

PRINTED WIRING BOARD PARTS LIST [HV-28D40BK]

MAIN P.W. BOARD ASS'Y (SMM-1011A-U2)

POWER&DEF P.W. BOARD ASS'Y (SMM-2012A-U2)

CRT SOCKET P.W. BOARD ASS'Y (SMM-3012A-U2)

FRONT CONTROL P.W. BOARD ASS'Y (SMM-8011A-U2)

SIDE CONTROL SW P.W. BOARD ASS'Y (SMM-8111A-U2)

LINE FILTER P.W. BOARD ASS'Y (SMM-9011A-U2)

TUNER POWER P.W. BOARD ASS'Y (SMM-9111A-U2)

SOUND DELAY P.W. BOARD ASS'Y (SMM0A201A-U2)

EHT P.W. BOARD ASS'Y (SMM0E011A-U2)

DEF OSC P.W. BOARD ASS'Y (SMM0H012A-U2)

MI-COM P.W. BOARD ASS'Y (SMM0M011A-U2)

AV SW P.W. BOARD ASS'Y (SMM0S011A-U2)

DIST P.W. BOARD ASS'Y (SMM0Z001A-U2)

PRINTED WIRING BOARD PARTS LIST [HV-32D40BK]

MAIN P.W. BOARD ASS'Y (SMM-1011A-U2)

POWER&DEF P.W. BOARD ASS'Y (SMM-2011A-U2)

CRT SOCKET P.W. BOARD ASS'Y (SMM-3011A-U2)

FRONT CONTROL P.W. BOARD ASS'Y (SMM-8011A-U2)

SIDE CONTROL SW P.W. BOARD ASS'Y (SMM-8111A-U2)

LINE FILTER P.W. BOARD ASS'Y (SMM-9011A-U2)

TUNER POWER P.W. BOARD ASS'Y (SMM-9111A-U2)

SOUND DELAY P.W. BOARD ASS'Y (SMM0A201A-U2)

EHT P.W. BOARD ASS'Y (SMM0E011A-U2)

DEF OSC P.W. BOARD ASS'Y (SMM0H011A-U2)

MI-COM P.W. BOARD ASS'Y (SMM0M011A-U2)

AV SW P.W. BOARD ASS'Y (SMM0S011A-U2)

DIST P.W. BOARD ASS'Y (SMM0Z001A-U2)

REMOTE CONTROL UNIT PARTS LIST (RM-C1805-1C)

PACKING

PACKING PARTS LIST
