JVC HR-XVC14B User Manual

HR-XVC14B/15S

P/N: MBM37484503

QUICK

DVD Player/Video Cassette Recorder
Tuner-Free Recording Operation

START
GUIDE

Need Help? Please call the JVC Customer Service
TOLL FREE CUSTOMER CARE HOTLINE: [phone]

http://www.jvc.com

Included Accessories

"AAA" battery x 2
(For remote control)

Remote control

Video cable

Audio cable

Easy Connection For Playback Only(DVD/VHS)

INSTRUCTIONS
pg. 10

AC Outlet

HR-XVC14B/15S

Plug to the
AC outlet.

DVD/VCR

OUT

INPUT

Video

Audio (L)

Audio (R)

TV

Connect with your TV

After connections, Power On.

LPT1148-002A

0207MNH-OT-OT

Easy Connection For Playback(DVD/VHS) &

Recording(VHS)

Cable or Satellite Box

OUTPUT

OUTPUT
(AV OUT)

Video (R) - Audio - (L)

VCR IN

LINE 1

INSTRUCTIONS pg. 11

Video (R) - Audio - (L)

DVD/VCR

OUT

INPUT

Video

Audio (L)

Audio (R)

After connections, Power On.

HR-XVC14B/15S

AC outlet

TV

Note: Please keep HR-XVC14B/15S
power on to watch TV program.

Manual Clock Set Up

Select "Month"

4

*

Select "Day"

5

INSTRUCTIONS
pg. 13

Select "VCR"

1

Select
"SETUP MENU"

2

Select "CLOCK"

3

Select "Year"

6

Select "Time"

7

"SETUP MENU"
Finish

8

Note: Need "Clock Set Up" at the beginning & end of "Summer Time".

BASIC PLAYBACK

INSTRUCTIONS
pg. 18, 24

DVD

Select "DVD"

*

1

Start Playback

1

2

Stop Playback

3

Playable Discs: DVD-Video, DVD-R, DVD+R, DVD-RW, DVD+RW, CD-R, Video CD, Audio CD

VHS

Select "VCR"

Start Playback

2

Stop Playback

3

BASIC RECORDING

Check! VHS Tape Inserted!!

Select "VCR"

*

1

Select Input

(Line 1/ 2)

2

Select Mode

3

(One-Touch Recording)

INSTRUCTIONS pg. 19

Start Recording

4

Stop Recording

5

TIMER RECORDING
(Munual Timer Programming)

Select "DAY"

INSTRUCTIONS
pg. 20

*

Check! VHS Tape Inserted!!

Select "VCR"

1

5

Select "START"

6

Select "STOP"

7

Select "INPUT"

8

"PROGRAM"
MENU

2

Select
"PROGRAM No."

3

Select "MONTH"

4

Select "SPEED"

9

Select "REPEAT"

10

"SETUP MENU"
Finish

11

INSTRUCTIONS

Timer-Link Recording

Note: Timer-Link works by using the timer function of

pg. 21

Check! VHS
Tape Inserted!!

most Cable/Satellite Boxes. Please check
whether your current box has a "Timer" function.

Note: Timer-Link doesn't work, if Cable/Satellite Box
keeps a "Screen Saver" in "Power Off".
If so, please use "Manual Timer Programming"

*

(Front of Unit)

Note: If the Timer-Link "On",
"TIMER/TIMER LINK" indicator
blinks on the JVC deck's

Set Up Timer

1

of Cable/Satellite Box

Power Off

2

3

4

Cable/Satellite Box

Power Off
HR-XVC14B/15S
after set record speed.

Hold "REC" Button
for 3 seconds

display window.

1. When your Cable/Satellite Box is powered on by the timer function, HR-XVC14B/15S is

also powered on and starts to record (It takes about 1 seconds) automatically.

2. When your Cable/Satellite Box is powered off using the timer function, HR-XVC14B/15S
also stops recording (It takes about 3 seconds) and then powers off automatically.

Timer-Link mode: Deactivate

(Front of Unit)

This operation makes "Timer­Link" been off after finishing
Timer-Link record. If you keep
"Timer-Link" on, you don't need
this step.

Power On

5

HR-XVC14B/15S
