JVC GY-HM200 User manual

Thank you for purchasing this JVC product. Before operating this unit, please read the instructions carefully to ensure the best possible performance.

In this manual, each model number is described without the last letter (U/E) which means the shipping destination. (U: for USA and Canada, E: for Europe) Only “U” models (GY-HM200U/GY-HM170U) have been evaluated by UL.

Please read the following before getting started:

For Customer Use:

Model No. Serial No.

Enter below the Serial No. which is located on the body. Retain this information for future reference.

GY-HM200U/GY-HM170U

4K MEMORY CARD CAMERA RECORDER

GY-HM200U/GY-HM200E GY-HM170U/GY-HM170E

INSTRUCTIONS

The illustration here shows how the handle unit is attached using the unit supplied with GY-HM200U/GY-HM200E. GY-HM170U/GY-HM170E do not come with a handle unit. The specifications and appearance of this product are subject to changes for further improvement without prior notice. Please check the latest version of the INSTRUCTIONS from the following Mobile User Guide. You can also download the PDF from the Mobile User Guide.

Mobile User Guide

When you are outside, you can refer to the instructions from your Android phone or iPhone.

http://manual3.jvckenwood.com/pro/mobile/global/

You can view the Mobile User Guide using the browser on your Android phone or iPhone.

IM 1.00

B5A-0573-00

Read these instructions.

Keep these instructions.

IMPORTANT SAFEGUARDS

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

These are general IMPORTANT SAFEGUARDS and certain items may not apply to all appliances.

Heed all warnings.

FOR USA

Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

10.

Only use attachments/accessories specified by the manufacturer.

11.

Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

12.

Unplug this apparatus during lightning storms or when unused for long periods of time.

13.

Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

For USA-California Only

This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material – special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate

CAN ICES-3 A / NMB-3 A

Introduction

IMPORTANT SAFEGUARDS

Safety Precautions

CAUTION

FOR USA AND CANADA

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

RISK OF ELECTRIC

SHOCK

DO NOT OPEN

This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

Introduction

Safety Precautions

POUR CANADA

RISQUE

D’ELECTROCUTION

NE PAS OUVRIR

CAUTION:

The mains plug shall remain readily operable.

 Remove the mains plug immediately if

the camera functions abnormally.

WARNING:

The battery pack, the camera with battery installed, and the remote control with battery installed should not be exposed to excessive heat such as direct sunlight, fire or the like.

ATTENTION:

POUR EVITER TOUT RISQUE D’ELECTROCUTION NE PAS OUVRIR LE BOITER. AUCUNE PIECE INTERIEURE N’EST A REGLER PAR L’UTILISATEUR. SE REFERER A UN AGENT QUALIFIE EN CAS DE PROBLEME.

ATTENTION

Le symbole de l’éclair à l’intérieur d’un triangle équilatéral est destiné à alerter l’utilisateur sur la présence d’une “tension dangereuse” non isolée dans le boîtier du produit. Cette tension est suffisante pour provoquer l’électrocution de personnes.

Le point d’exclamation à l’intérieur d’un triangle équilatéral est destiné à alerter l’utilisateur sur la présence d’opérations d’entretien importantes au sujet desquelles des renseignements se trouvent dans le manuel d’instructions.

Ces symboles ne sont utilisés qu’aux Etats-Unis.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

AVERTISSEMENT : POUR EVITER LES RISQUES D’INCENDIE OU D’ELECTROCUTION, NE PAS EXPOSER L’APPAREIL A LA PLUIE NI A L’HUMIDITE.

NOTES:

 The rating plate and safety caution are

on the bottom and/or the back of the main unit.

 The serial number plate is on the

bottom of the unit.

 The rating information and safety

caution of the AC adapter are on its upper and lower sides.

REMARQUES :

 La plaque d’identification et

l’avertissement de sécurité se trouvent sous l’appareil et/ou au dos.

 La plaque du numéro de série est

située sur la partie inférieure de l’appareil.

 Les informations d’identification et

l’avertissement de sécurité de l’adaptateur secteur sont situés sur ses côtés supérieur et inférieur.

Caution on Replaceable lithium battery

The battery used in this device may present a fire or chemical burn hazard if mistreated. Do not recharge, disassemble, heat above 100°C (212°F) or incinerate. Replace battery with Panasonic, Sanyo, Sony or Maxell CR2025. Danger of explosion or risk of fire if the battery is incorrectly replaced.

 Dispose of used battery promptly.  Keep away from children.  Do not disassemble and do not dispose

of in fire.

Introduction

Safety Precautions

When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm (3-15/16") or more on both sides, on top and at the rear). Do not block the ventilation holes. (If the ventilation holes are blocked by a newspaper, or cloth etc. the heat may not be able to get out.) No naked flame sources, such as lighted candles, should be placed on the apparatus. When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.

The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

Do not point the lens directly into the sun. This can cause eye injuries, as well as lead to the malfunctioning of internal circuitry. There is also a risk of fire or electric shock.

CAUTION!

The following notes concern possible physical damage to this unit and to the user. Carrying or holding this unit by the LCD monitor can result in dropping the unit, or in a malfunction. Do not use a tripod on unsteady or unlevel surfaces. It could tip over, causing serious damage to the unit.

CAUTION!

Connecting cables (Audio/Video, etc.) to this unit and leaving it on top of the TV is not recommended, as tripping on the cables will cause the unit to fall, resulting in damage.

When using the AC adapter in areas other than the USA

The provided AC adapter features automatic voltage selection in the AC range from 110 V to 240 V.

USING HOUSEHOLD AC PLUG ADAPTER

In case of connecting the unit’s power cord to an AC wall outlet other than American National Standard C73 series type, use an AC plug adapter called a “Siemens Plug” as shown. For this AC plug adapter, please contact the local dealers in your area.

 Remove the AC adapter from the AC

wall outlet when not in use.

 Do not leave dust or metal objects

adhered to the AC wall outlet or AC adapter (power/DC plug).

Plug Adapter

Introduction

Safety Precautions

IMPORTANT (for owners in the U.K.) Connection to the mains supply in the United Kingdom. DO NOT cut off the mains plug from this equipment.

If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or contact the local dealers in your area.

BE SURE to replace the fuse only with

an identical approved type, as originally fitted, and to replace the fuse cover. If nonetheless the mains plug is cut off be sure to remove the fuse and dispose of the plug immediately, to avoid possible shock hazard by inadvertent connection to the mains supply. If this product is not supplied fitted with a mains plug then follow the instructions given below:

DO NOT make any connection to the

Larger Terminal coded E or Green. The wires in the mains lead are coloured in accordance with the following code:

If these colours do not correspond with the terminal identifications of your plug, connect as follows: Blue wire to terminal coded N (Neutral) or coloured black. Brown wire to terminal coded L (Live) or coloured Red. If in doubt — consult a competent electrician.

CAUTIONS:



To prevent shock, do not open the cabinet. No user serviceable parts inside. Refer servicing to qualified personnel.

 When you are not using the AC

adapter for a long period of time, it is recommended that you disconnect the power cord from AC outlet.

Blue to N (Neutral) or Black Brown to L (Live) or Red

FOR EUROPE

This equipment is in conformity with the provisions and protection requirements of the corresponding European Directives. This equipment is designed for professional video appliances and can be used in the following environments:

 Controlled EMC environment (for

example, purpose-built broadcasting or recording studio), and rural outdoors

environments. In order to keep the best performance and furthermore for electromagnetic compatibility we recommend to use cables not exceeding the following lengths:

The inrush current of this apparatus is

11.0 A.

Exclusive Cable

Coaxial Cable

Shielded Cable

DC 1.8 m

1.4 m

1.2 m

1.8 m

2 m

3 m

1 m

USB Mini

AV OUT

HDMI

REMOTE

SDI OUT K

AUX

HEADPHONE

AUDIO INPUT 1/2

Port Cable Length

CAUTION:

Where there are strong electromagnetic waves or magnetism, for example near a radio or TV transmitter, transformer, motor, etc., the picture and the sound may be disturbed. In such case, please keep the apparatus away from the sources of the disturbance.

Introduction

Safety Precautions

WARNING

This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.

CAUTION:

To avoid electric shock or damage to the unit, first firmly insert the small end of the power cord into the AC Adapter until it is no longer wobbly, and then plug the larger end of the power cord in to an AC outlet.

FOR EUROPE

The plastics packaging bags may cause suffocation when they are covered over the head. Tear them open, and keep them away from the reach of infants and children by ensuring that they are disposed of properly.

Dear Customer

This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of JVC KENWOOD Corporation is: JVC Technical Services Europe GmbH Konrad-Adenauer-Allee 1-11 61118 Bad Vilbel Germany

Sehr geehrter Kunde, sehr geehrte Kundin, dieses Gerät stimmt mit den gültigen europäischen Richtlinien und Normen bezüglich elektromagnetischer Verträglichkeit und elektrischer Sicherheit überein. Die europäische Vertretung für die JVC KENWOOD Corporation ist: JVC Technical Services Europe GmbH Konrad-Adenauer-Allee 1-11 61118 Bad Vilbel Deutschland

Introduction

Safety Precautions

Battery Pack

The supplied battery pack is a lithium-ion battery. Before using the supplied battery pack or an optional battery pack, be sure to read the following cautions:

 To avoid hazards

... do not burn.

 To prevent damage and prolong

service life

... do not subject to unnecessary shock. ... charge within the temperature range

of 10°C to 30°C (50°F to 86°F). Cooler temperatures require longer charging time, or in some cases stop charging at all. Warmer temperatures prevent complete charging, or in some cases stop charging at all.

... store in a cool, dry place. Extended

exposure to high temperatures will increase natural discharge and shorten service life.

... keep a 30% battery level if the

battery pack is not to be used for a long period of time.

... remove from charger or powered unit

when not in use, as some machines use current even when switched off.

... do not drop or subject to strong

impact.

... do not short-circuit the

terminals. Keep it away from metallic objects when not in use. When transporting, carry the battery in a plastic bag.

... do not modify or

disassemble.

... do not expose the

battery to temperatures exceeding 60°C (140°F), as this may cause the battery to overheat, explode or catch fire.

... use only specified chargers.

Terminals

Para Brasil

Informação sobre eliminação de baterias

Este produto não deverá ser eliminado como lixo doméstico em geral. Devolva a bateria velha ao comerciante ou para a rede autorizada, para que seja devolvida ao fabricante ou importador. A reciclagem e eliminação de lixo em uma maneira adequada, ajudarão para preservar recursos, prevenindo, ao mesmo tempo, contra efeitos prejudiciais sobre a nossa saúde e o meio ambiente.

GY-HM200U/GY-HM200E

GY-HM170U/GY-HM170E

Empurre

Para Retirar a Bateria Recarregável

Pressione botão e puxe a bateria para fora.

Safety Precautions

Introduction

Safety Precautions

Contents .......................................................... 10

Introduction

Main Features ................................................. 12

Precautions for Proper Use ............................. 14

Operation Modes ............................................. 18

Names of Parts ................................................ 20

Side Control Panel ....................................... 21

Side Terminal Section .................................. 22

Rear Terminal .............................................. 22

LCD Monitor ................................................ 23

Handle Unit K .......................................... 24

Lens Section ................................................ 25

Basic System Diagram .................................... 26

Preparations

Settings and Adjustments Before Use ............. 27

Attaching the Handle Unit K .................... 27

Adjusting the Grip Belt ................................. 27

Attaching the External Microphone O ...... 27

Attaching/Detaching the Lens Cap .............. 28

Attaching/Detaching the Hood ..................... 28

Attaching the Tripod ..................................... 29

Power Supply .................................................. 29

Using a Battery Pack .................................... 29

Using AC Power (DC IN Power) ................... 31

Power Status Display ...................................... 31

Turning On/Off the Power ................................ 32

Initial Settings .................................................. 33

Displays on the LCD Monitor and Viewfinder .. 35

Display Screen ............................................. 35

Status Screen .............................................. 36

USB Mode Screen ....................................... 36

Remote Edit Mode Screen K ................... 36

Warning Display ........................................... 36

Adjusting the LCD Monitor and Viewfinder ...... 37

Adjusting the LCD Monitor ........................... 37

Adjusting the Viewfinder .............................. 38

Assignment of Functions to User Buttons ........ 39

Tally Lamp ....................................................... 39

SD Card ........................................................... 40

Usable Cards ............................................... 40

Formatting (Initializing) SD Cards ................ 42

Restoring the SD Card ................................. 43

Clips Recorded to SD Cards ........................ 44

Operation Lock Feature ................................... 45

Shooting

............................................ 4

Basic Shooting Procedures ............................. 46

Selecting

Format ............................................................. 47

Zoom Operation .............................................. 49

Focus Operation .............................................. 50

Adjusting the Focusing by Face Detection ...... 53

Adjusting the Brightness .................................. 54

Adjusting the Iris .............................................. 55

Setting the Gain ............................................... 57

Setting the Electronic Shutter .......................... 58

Setting the ND Filter ........................................ 59

Adjusting the White Balance ............................ 60

Adjusting the Camera Image ........................... 64

Using the Image Stabilizer ............................... 64

Audio Recording .............................................. 65

Monitoring Audio Sound During Recording Using a

Headphone ...................................................... 67

Time Code and User’s Bit ................................ 68

Setting Time Code Generator .......................... 69

Setting the User’s Bit ....................................... 71

Setting Zebra Pattern ...................................... 72

Viewing Recorded Videos Immediately (Clip

Review) ........................................................... 73

Recording Simultaneously at Two Different

Definitions ....................................................... 74

Series Rec ....................................................... 74

Dual Rec .......................................................... 74

Backup Rec ..................................................... 76

Special Recording ........................................... 78

Splitting the Clips Freely (Clip Cutter Trig) ....... 82

System Definition, File Format and Video

Pre Rec ........................................................ 78

Clip Continuous Rec .................................... 79

Frame Rec ................................................... 80

Interval Rec .................................................. 81

Playback

Playing Recorded Clips ................................... 83

Thumbnail Screen ........................................ 83

Actions ......................................................... 85

Playing back ................................................ 86

Deleting Clips .................................................. 87

Appending/Deleting OK Mark .......................... 88

Selecting and Performing Operations on Multiple

Clips ................................................................ 89

Selecting Multiple Clips Randomly ............... 89

Selecting Multiple Clips Consecutively ........ 90

Trimming Recorded Clips ................................ 91

Menu Display and Detailed Settings

Basic Operations in Menu Screen ................... 92

Display and Description of the Menu Screen

..................................................................... 93

Contents

Text Input with Software Keyboard .............. 94

Menu Screen Hierarchical Chart .....................

Camera Function Menu ................................... 96

User Switch Set Item .................................... 98

Camera Process Menu .................................. 100

Detail/Adjust Item ....................................... 102

White Balance Item .................................... 102

TC/UB Menu ................................................. 103

LCD/VF Menu ................................................ 104

Shooting Assist Item .................................. 105

Marker Settings Item .................................. 106

Display Settings Item ................................. 107

A/V Set Menu ................................................ 109

Video Set Item ........................................... 109

Audio Set Item ........................................... 110

System Menu ................................................ 113

Record Set Item ......................................... 114

Network/Settings Item K ........................ 118

Adding/Editing Frequently Used Menu Items

(Favorites Menu) ........................................... 123

Adding Menu Items to Favorites Menu ...... 123

Editing Favorites Menu .............................. 124

Display/Status Screen

Display Screen in Camera Mode ................... 127

Display Screen in Media Mode ...................... 132

Status Screen ................................................ 134

Camera Features

Marker and Safety Zone Displays (Camera Mode

Only) .............................................................. 135

Color Bar Output ........................................... 135

Configuring Setup Files ................................. 136

Saving Setup Files ..................................... 136

Loading a Setup File .................................. 137

Connecting External Devices

Connecting External Monitor ......................... 138

Connecting the Headphone ........................... 139

Connecting Wired Remote Control ................ 140

Loading Clips to the PC ................................. 140

Connecting to the Network K

Functions of Network Connection K .......... 142

Preparing Network Connection K .............. 142

Operating Environment .............................. 142

Camera Setup for Network Connection ..... 143

Connecting via Wireless LAN .................... 143

Connecting via Wired LAN ......................... 145

Connecting via Cellular Adapter ................ 145

Importing Metadata K ............................... 146

Preparing Metadata ................................... 146

Configuring the Server for Downloading .... 146

Importing Metadata ....................................

Uploading a Recorded Video Clip K ......... 148

Configuring the FTP Server for Uploading . 148

Uploading Video Clip ................................. 148

Connecting from a Web Browser K ........... 150

Editing Metadata K ................................... 151

Planning Metadata ..................................... 151

Clip Metadata ............................................ 152

Uploading a Recording Clip via a Web Browser

K ............................................................... 155

View Remote Feature K ............................ 158

Operating Procedure ................................. 158

Registering/Deleting Preset Zoom ............. 159

Camera Control Function K ...................... 161

Configuring Settings via a Browser K ........ 162

Changing View Remote Function Settings . 163

Changing Connection Setup ...................... 164

Changing Metadata Server Settings .......... 165

Changing Clip Server Settings ................... 165

Changing Streaming Settings .................... 165

Managing the Network Connection Settings File

K ............................................................... 165

Saving the Connection Settings File .......... 165

Reading the Connection Settings File ........ 166

Deleting Connection Settings .................... 167

Performing Live Streaming K .................... 167

Setting Distribution ..................................... 168

Starting Distribution ................................... 169

147

Others

Error Messages and Actions ......................... 170

List of FTP Transfer Errors K ................. 171

List of Live Streaming Error Displays K . 173

Blinking of the Tally Lamp .......................... 174

Warning Tone ............................................ 174

Troubleshooting ............................................ 174

Specifications ................................................ 176

Index ............................................................. 180

Software License Agreement ........................ 182

Important Notice concerning the Software ..... 183

Introduction

Contents

Main Features

Supports 4K high-definition recording, realizing more advanced Full HD

Introduction

recording quality

Recording and playback at 30p/25p/24p are possible in 4K resolution (3840x2160 pixels), which

contains information that is about four times larger than Full HD. And with the H.264 codec, this camera recorder supports high resolution 4K recording at 150 Mbps and high quality HD recording at 50 Mbps 4:2:2. Even when recording scenes with a lot of movements and fine details, it is possible to record high quality videos that are smooth and rich in details.

F1.2, 29.6 mm wide-angle, 12x optical zoom lens

A new lens has been developed, which boasts top-

brightness (maximum aperture of F1.2) for a

notch compact handheld camera. The bright lens allows details to be reproduced clearly even in a dimly-lit room. The 12x optical zoom supports zooming from 29.6 mm at the wide-angle end, and dynamic zoom up to 24x with the use of a high-resolution sensor (during HD/SD recording), allowing the faces of distant portrait subjects to be captured.

High-performance CMOS sensor with a sensitivity of F5.6

This camera recorder is built in with a highperformance 1/2.3-inch (effective pixels of 9.03 megapixels, 1/2.5-inch) CMOS sensor with a resolution of 12.4 megapixels, achieving a significantly enhanced sensitivity of F5.6 with the high-definition and advanced noise-reduction technology. You can produce recordings with excellent gradation even when shooting in a low-

scene or at a location where lighting cannot be

light used.

New-generation JVC image processor “FALCONBRID II”

The image processor employed supports both 4K codec developed by JVC and simultaneous dual stream encoding, achieving a high image quality that maximizes the potential of next-generation high-resolution sensors.

Enhanced network functions K

An encoding bit rate higher than existing models can be set. Also, with the “Zixi” cloud service supported, which enables highly-reliable and stable data transmission, RTMP live streaming is made possible.

Supports QuickTime and AVCHD formats

Inheriting the concept of our past memory camera recorders, this camera recorder supports QuickTime be directly edited on “Final Cut Pro”, an editing

software from Apple Inc.

(MOV) and AVCHD file formats that can

Equipped with double SD card slots allowing various recording options

The most common SDHC/SDXC card recording system is used as the memory card. This ensures high reliability and operation at low running cost. Various user friendly recording options are available. These include series recording which enables seamless long hour continuous recordings over the slots, dual recording of the same file to two slots, and backup recording of recording only the preferred scenes to one slot using the record and stop operations while the other slot is continuously recording. In addition, Web files with resolution suitable for distribution over the network can be created. HD files and Web files can also be recorded simultaneously. For GY-HM200U/GY-HM200E, it is also possible to perform streaming while the recording is ongoing.

Equipped with progressive-compatible 3G-SDI and HDMI output

[SDI OUT] and [HDMI] terminals are equipped for digital output. 3G-compatible SDI output is

supported, and external output including 4K from the [HDMI]

Full HD signals and audio signals can be output simultaneously from the [SDI OUT] and [HDMI]

terminals. * GY-HM170U/GY-HM170E come only with the

terminal is possible. Uncompressed

[HDMI] terminal. [SDI OUT] terminal is not available.

Main Features

3.5-inch 920K-pixel LCD display, 0.24inch 1.56-megapixel color viewfinder

The 3.5-inch 16:9 LCD display and 0.24-inch 16:9

color viewfinder provides support for critical

LCOS focusing during 4K shooting. Other assist functions are also available, including magnified focus on a manually selected point.

Auto focus/Optical image stabilizer

The camera recorder is equipped with a face detection screen. Switching to manual focus is also possible. A built-in optical image stabilizer feature is also available.

auto focus function that covers the entire

Professional-style switch layout and diverse video parameters

Switches for Gain and White Balance are available on the side panel to enable quick switching according to the shooting scene. Image quality parameters such as gamma and color matrix are also available in the menu for adjustment to the preferred tones.

User button/ring assignable with different functions for greater ease of use

Menu items corresponding to each of the 9 buttons

2 rings are available to assign the buttons and

and rings with different functions.

Built-in 3-position ND filter

ND filters are built into this camera recorder. You can adjust the amount of light according to the brightness during shooting by switching the 3position ND filter (OFF, 1/4, 1/16).

Detachable handle unit with 2-channel XLR audio input terminal K

The handle unit is built in with recording and zoom switches, and supports microphones for business

The recording level can also be adjusted, and

use. connection of a phantom microphone is also supported.

* GY-HM170U/GY-HM170E does not come with

the handle unit. For details on purchasing the handle unit, please contact the local dealers in your area.

Content of this manual

Symbols used

Caution : Describes precautions concerning the

Memo : Describes reference information, such as

Content of this manual

0 0

operation of this product.

functions and usage restrictions of this product.

: Indicates the reference page numbers and

reference items.

: Feature available on

GY-HM200U/GY-HM200E only.

: Feature available on

GY-HM170U/GY-HM170E only.

: Function that operates only when the handle

unit is attached.

All rights reserved by JVC KENWOOD Corporation. Unauthorized duplication or reprinting of this manual, in whole or in part, is strictly prohibited. Illustrated designs, specifications and other contents of this manual are subject to change for improvement without prior notice. AVCHD Progressive and the AVCHD Progressive logo are trademarks of Panasonic Corporation and Sony Corporation. SDXC and SDHC logos are trademarks of SD-3C, LLC. HDMI (High-Definition Multimedia Interface) and

QuickTime, Final Cut Pro, iPhone, iPad, iPod touch, iOS, Mac OS and Safari are trademarks of Apple Inc., registered in the U.S. and other countries. Android, Google Chrome and Nexus are trademarks and/or registered trademarks of Google Inc. QR Code is a registered trademark of Denso Wave Incorporated. Dolby and the double-D symbol are trademarks of Dolby Laboratories. Microsoft, Windows, Windows XP, Windows Vista, Windows 7 and Internet Explorer are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Surface is the trademarks of Microsoft Corporation in the United States and/or other countries. Mozilla and Firefox are either trademarks or registered trademarks of Mozilla Foundation in the United States and/or other countries. Intel Core 2 Duo is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. The company name of Fontworks, Fontworks, and the name of the fonts are registered trademarks of Fontworks Inc. Zixi and the Zixi logo are trademarks of Zixi LCC. Other product and company names included in this instruction manual are trademarks and/or registered trademarks of their respective companies. Marks such as ™ and ® have been omitted in this manual.

are trademarks of HDMI Licensing, LLC.

Introduction

Main Features

Precautions for Proper Use

Transportation

not drop or hit this unit against a hard object

Do when transporting.

Storage and Usage Locations

Introduction

Allowable ambient temperature and humidity Be sure to use this unit within the allowable temperature range of 0 °C to 40 °C (32 °F to 104°F) and a relative humidity of 30 % to 80 %. Using this unit at a temperature or humidity outside the allowable ranges could result not only in malfunction but also serious impact on the CMOS elements as small white spots may be

generated. Please exercise care during use.

Strong electromagnetic waves or magnetism Noise may appear in the picture or audio and/or the colors may be incorrect if this unit is used near a radio or television transmitting antenna, in places where strong magnetic fields are generated by transformers, motors, etc., or near devices emitting radio waves, such as transceivers or cellular phones. Use of wireless microphone near this unit When a wireless microphone or wireless microphone tuner is used near this unit during recording, the tuner could pick up noise.

Avoid using or placing this unit in the following places.

Places subject to extreme heat or cold

Places with excessive dirt or dust

Places with high humidity or moisture

Do not place this unit at places that are subject to occur.

Protect (Especially when shooting in the rain)

Protect on a beach. In addition, salt and sand may adhere to the body. Be sure to clean the unit after use.

Protect this unit against penetration of dust when using it in a place subject to sandy dust.

subject to smoke or vapor such as near

Places a cooking stove Places subject to strong vibrations or unstable surfaces In a parked car under direct sunlight or near a heater for long hours

radiation or X-rays, or where corrosive gases

this unit from being splashed with water.

this unit from getting wet when shooting

Power Saving

When this unit is not in use, be sure to set the [POWER ON/OFF

reduce power consumption.

] switch to “OFF” in order to

Maintenance

Turn off the power before performing any maintenance.

Wipe the external cabinet of the unit with a soft cloth. Do not wipe the body with benzene or

Doing so may cause the surface to melt

thinner. or turn cloudy. When it is extremely dirty, soak the cloth in a solution of neutral detergent, wipe the body with it, and then use a clean cloth to remove the detergent.

Rechargeable Battery

Be sure to use only the specified batteries. We do not guarantee the safety and performance of this device if an unspecified battery is used.

Charge the battery first before using.

you are not using the battery for a prolonged

If period of time, remove and keep the battery at a 30 % to 40 % charge level to prevent deterioration.

Recharge the battery to a level of 10 % to 20 % once every six months when storing the battery. Storing the battery at a fully discharged state will result in over discharging and inability to charge the battery.

the removed battery with the battery cap

Store attached in a dry place between 15 °C and 25 °C (59 °F and 77 °F).

For details, refer to the instruction manual of the battery.

ATTENTION:

The product you have purchased is powered by a rechargeable battery that is recyclable.

call 1-800-8-BATTERY for

Please information on how to recycle this battery.

Precautions for Proper Use

Regular Inspection (Maintenance)

Groove

Under normal environment, dust will accumulate on the camera recorder when it is used over a long period. Dust may enter the

recorder especially if it is used outdoors.

camera This may affect the image and sound quality of the camera recorder. Check and replace the fan after every 9000 hours (suggested guideline). You can check the usage time of the fan in [System] B [System Information] B [Fan Hour].

(A P114 [ Fan Hour ] ) If the fan is used for more than 9000 hours without replacement, “Fan Maintenance Required” will be displayed every time you turn on the power.

SDHC/SDXC Cards

SDHC/SDXC card is referred to as SD card in this manual.

This camera recorder saves the recorded images and audio sound on the SD card (sold separately) in the card slot.

the SD card contains files recorded by devices other than this camera recorder or files that are saved from a PC, the recordable time may be shorter or data may not be properly recorded. In addition, the remaining space on the card may not increase even when files are deleted using a PC.

For details on the combinations of usable SD card and format setting, refer to the following. (A P40 [Format Setting and Usable SD Card Combinations] )

* Using cards other than those from Panasonic,

TOSHIBA or SanDisk may result in recording failure or data loss.

Handling of SD Cards

The status indicator lights up in red when data on the SD card is being accessed. Do not remove the SD card during data access

as recording, playback, or formatting). Do

(such not turn off the power or remove the battery and AC adapter during access either.

Do not use or store the SD card in a place that is subject to static electricity or electrical noise.

Do not place the SD card near locations that are exposed to strong magnetic fields or radio waves.

Inserting the SD card incorrectly may result in damage of this unit or the SD card.

are not liable for any accidental loss of data

We stored on the SD card. Please back up any important data.

Make use of the SD card within the prescribed conditions of use. Do not use it at the following locations. Places that are subject to direct sunlight, high humidity or corrosion, places near thermal equipment, sandy or dusty places, or in a car under the sun with the doors and windows closed.

Do not bend or drop the SD card, or subject it to strong impact or vibration.

Do not splash the SD card with water.

Do not dismantle or modify the SD card.

Do not touch the terminals with your hands or with a metal object.

Do not allow dust, dirt, water, or foreign objects to adhere to the terminals.

Do not remove the labels or stick other labels or stickers on the SD cards.

Do not use pencils or ballpoint pens to write on the SD cards. Always use oil-based pens.

If you format (initialize) the SD card, all data recorded on the card, including video data and setup files, will be deleted.

You are recommended to use cards that are formatted (initialized) on this camera recorder.

The SD card may be damaged if the camera recorder is not operated correctly. Formatting (Initializing) the SD card may allow it to operate correctly.

SD cards that have been formatted (initialized) on other cameras, computers or peripheral equipment may not operate correctly. In this case, format (initialize) the SD card on this camera recorder.

If you want to wipe out all information by completely erasing the data, we recommend either using commercially available software that is specially designed for that purpose, or by physically destroying the SD card with a hammer, etc. When formatting or erasing data using the camera recorder, only the file administration information is changed. The data is not completely erased from the SD card.

Some

commercially available SD cards may be harder to be removed from this unit. Remove them by hooking onto the groove on the cards.

It will be easier to remove the cards after several times.

Do not stick any stickers on the cards.

Introduction

The SD card may pop out when it is being removed. Be careful not to lose the card.

Precautions for Proper Use

Others

not insert objects other than the memory card

Do into the card slot.

Do not block the vent on the unit. Blocking of the vent causes internal heating and may lead to burns and fires.

Introduction

Do not turn off the [POWER ON/OFF] switch or remove the power cable during recording

or playback.

The camera recorder may not show stable pictures for a few seconds immediately after the power is turned on, but this is not a malfunction.

When

the video signal output terminals are not in use, put on the covers to prevent damage to the terminals.

Do not drop this unit or subject it to strong impact or vibration as it is a precision equipment.

Optical performance of lens Due to the optical performance of the lens, color divergence phenomena (magnification chromatic aberration) may occur at the periphery of the image. This is not a camera malfunction.

Noise may appear in the image when switching modes.

If placed on its side, heat release efficiency will deteriorate.

Use the supplied AC adapter as the power supply. Do not use the supplied AC adapter on other devices.

When the connectors that come with connector covers are not in use, put on the covers to prevent damage to the connectors.

This camera recorder makes use of fonts by Fontworks Inc.

This camera recorder makes use of M+FONTS.

LCD Monitor and Viewfinder

The LCD monitor and viewfinder screen are manufactured using high-precision technology.

spots may appear on the LCD monitor and

Black viewfinder screen, or red, blue, and/or white spots may not disappear. However, this is not a malfunction and these spots are not recorded on the SD card.

If you use this unit continuously for a long period of time, the characters displayed in the viewfinder may temporarily remain on the screen. This is not recorded on the SD card. They will not appear after you turn the power off and then on again.

If you use this unit in a cold place, the images may appear to lag on the screen, but this is not a malfunction. Retained images are not recorded on the SD card.

Do not press against the surface with force or subject it to strong impact. Doing so may damage or break the screens.

Noise may appear in the viewfinder when switching between the live video and playback images.

Due to the characteristic of the viewfinder display device, colors may appear on the images when you blink your eyes. It does not affect the recorded images, SDI output K, or HDMI output.

Precautions for Proper Use

Any recordings made on this camera recorder that are played back for profit or public preview may infringe on the rights of the owner of the recordings. Do not use the recordings for purpose other than personal enjoyment without prior consent from the owner.

License Notices

MPEG LA AVC THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF A CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE REMUNERATION TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE

AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE

HTTP://WWW.MPEGLA.COM

MPEG LA MPEG-2 Patent ANY USE OF THIS UNIT IN ANY MANNER OTHER THAN PERSONAL USE THAT COMPLIES WITH THE MPEG-2 STANDARD FOR ENCODING VIDEO INFORMATION FOR PACKAGED MEDIA IS EXPRESSLY PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE PATENTS IN THE MPEG-2 PATENT PORTFOLIO, WHICH LICENSE IS AVAILABLE FROM MPEG LA, LLC, 6312 S. WHICH LICENSE IS AVAILABLE FROM MPEG LA, LLC, 6312 S. Fiddlers Green circle, Suite 400E, Greenwood Village, Colorado 80111 U.S.A.

Introduction

Encryption in Network Connection

Wireless LAN connections make use of an encryption function. This encryption is designed for commerciallysold equipment, and it cannot be altered.

Precautions for Proper Use

Operation Modes

MODE

Set Button

(R)

Set Button (R)

Trimming Playback

Normal Playback

[CANCEL/STOP]/[MENU/THUMB] Button

FTP in Progress

Exit FTP Operation (Successful)

Camera Input

* * Selecting a mode other than the Metadata Edit mode via the web browser, or selecting [Exit] on the [Remote Edit Mode] screen

Upon access via a web browser and selecting [Change] on the

[Change to Remote Edit Mode?] screen on the camera or the web browser

Connection to PC with USB Cable

Press and hold [MODE]

[MODE] Button

Press and hold [MODE]

[MODE] Button

Execute [FTP Upload]

Exit/Cancel FTP Operation (Successful/Failed/Stopped)

(Actions)

Execute [Delete Clips]

File Deletion in Progress

Exit/Cancel File Delete Operation (Successful/Failed/Stopped)

Trimming in Progress

Exit Trimming Operation (Successful/Failed/Stopped)

[ZEBRA/5] Button

Execute

[Trim This Clip]

Media Mode

Thumbnail Display

USB Connection (When the confirmation to change

to USB mode appears and [Change] is selected)

(USB Mass Storage Class)

USB Mode

Connection disabled on PC

Camera Mode

Remote Edit Mode

Playback

GY-HM200U/ GY-HM200E only

This camera recorder has four operation modes - Camera mode, Media mode, USB mode and Remote Edit mode.

Introduction

Operation Modes

Operation Mode Description

Camera Mode

is the camera shooting mode. The camera recorder starts up in Camera mode

This when the power is turned on.

Camera images are output on the viewfinder and LCD monitor. When a recordable SD card is inserted, the camera recorder enters the recording standby mode. “STBY” appears on the operation mode display area of the LCD monitor and

viewfinder.

Press the [REC] trigger button to start recording.

Memo :

Playback most recently recorded video clip.

(A P73 [Viewing Recorded Videos Immediately (Clip Review)] )

of SD card is not possible in Camera mode. However, you can check the

Introduction

Media Mode

USB Mode

Remote Edit Mode K

This mode allows you to play back or delete clips recorded on the SD card.

When

a playable SD card is inserted, the thumbnail or playback screen is displayed

on the viewfinder and LCD monitor.

Press and hold the [MODE] selection button to enter the Media mode when you are not shooting in the Camera mode. Once the camera recorder is in Media mode,

thumbnails of the selected media slot are displayed.

This mode allows you to connect to a PC and transfer the files on an SD card to the PC.

the camera recorder is connected to a USB cable, the message “Change to

When USB Mode?” appears. Select [Change] and press the Set button to switch to USB mode.

(A P

140 [Loading Clips to the PC] )

In USB mode, the camera recorder is recognized by the connected PC as a peripheral drive. (USB mass storage class only) Disable the connection on the PC and remove the USB cable from the camera recorder to switch to Camera mode.

(A P140 [Loading Clips to the PC] )

Memo :

When a USB cable is connected during recording, the message appears after recording stops.

If playback is in progress, the message appears once the files are closed automatically, such as when playback stops.

Files on the PC cannot be written to the SD card.

This mode enables the list display and editing of the recorded clip data through access to the clip list display page via a web browser on a smartphone, tablet terminal, or PC.

When you access via a web browser on a smartphone, tablet terminal, or PC, is necessary to change the camera mode to "Remote Edit Mode". Change the

mode.” appears on the web browser. Also, “Change to Remote Edit Mode?” is displayed on the display screen of the camera unit.

Selecting [Change] on the camera recorder and pressing the Set button switches to the Remote Edit mode, and enables display of the clip list and editing of the clip

metadata.

(A P

152 [ Clip Metadata ] )

(A P155 [Uploading a Recording Clip via a Web Browser K] )

Memo :

you access via a web browser on devices such as a smartphone, tablet terminal,

or PC while recording is in progress, the message appears after recording stops.

If playback is in progress, the message appears once the files are closed automatically, such as when playback stops.

“It

Operation Modes

Names of Parts

D E

o Bottom

Introduction

Built-in Microphone

65 [Audio Recording] )

(A P

Handle Unit K

(A P24 [Handle Unit K] )

* GY-HM170U/GY-HM170E does not come with

the handle unit. For details on purchasing the handle unit, please contact the local dealers in your area.

Memo :

The handle unit is detached from the camera recorder unit in the factory shipment. For details on attaching the handle unit, please refer to [Attaching the Handle Unit K] .

(A P

27 [Attaching the Handle Unit K] )

[MODE] Camera/Media

(A P18 [Operation Modes] )

[POWER ON/OFF] Lock Power ON/OFF Switch

Turns ON/OFF the power.

Hold

down the lock button (blue) in the center

to toggle ON/OFF.

When the power is turning OFF, “P.OFF” appears on the LCD monitor and viewfinder.

Wait for 5 seconds or more to turn on the power again.

(A P

32 [Turning On/Off the Power] )

[POWER/CHARGE] Power/Charging Display Lamp

(A P29 [Using a Battery Pack] )

[AWB/9] Auto White Balance/User 9 Button

For executing Auto White Balance and switching the registered color temperature.

P60 [Adjusting the White Balance] )

You can also use it as a user button by assigning a specific feature in the menu setting to this button.

Names of Parts

Mode Selection Button

Visibility Adjustment Lever

(A P

37 [Adjusting the LCD Monitor and

Viewfinder] )

Battery

(A P29 [Using a Battery Pack] )

Viewfinder

(A P37 [Adjusting the LCD Monitor and Viewfinder] )

Eyepiece

Prevents external light from entering the viewfinder screen and cameraman’s vision.

[REC/7] Record Trigger Button

Starts/stops recording.

You can also use it as a user button by assigning a specific feature in the menu setting to this button.

Zoom Lever at the Grip

(A P

[EXPANDED FOCUS/8] Expanded Focus Assist/User 8 Button

For switching the expanded focus ON or OFF.

You can also use it as a user button by assigning a specific feature in the menu setting to this button.

Tally Lamp

(A P (A P174 [Blinking of the Tally Lamp] )

Tripod Mounting Hole

(A P29 [Attaching the Tripod] )

[Basic Shooting Procedures] )

(A P46

49 [Using the Zoom Lever at the Grip] )

52 [Expanded Focus Function] )

(A P

39 [Tally Lamp] )

Side Control Panel

M J I HL K

[FULL AUTO] Full Auto Selection Button

Press

and hold the button to switch the Full Auto mode ON and OFF. Full Auto mode adjusts the Iris, Gain, Shutter and White Balance automatically. (A P54 [Adjusting the Brightness Automatically: Automatic Brightness Adjustment (AE) Mode] ) (A P55 [Auto Iris (Automatic Adjustment) Mode] ) (A P57 [Automatic Gain Mode (Automatic Gain Adjustment)] ) (A P58 [Automatic Shutter Mode (Automatic Shutter Adjustment)] ) (A P60 [Automatic White Balance Mode (FAW: Fulltime Auto White balance)] )

Memo :

This

camera recorder is set to Full Auto mode in

the factory default.

[AF/MF

] Focus Selection Button

(A P50 [Focus Operation] )

[ND FILTER] ND Filter Switch

(A P59 [Setting the ND Filter] )

[F.ASSIST/1] Focus Assist/User 1 Button

For

switching the focus assist function ON or

OFF.

(A P52 [Focus Assist Function] )

You can also use it as a user button by assigning a specific feature in the menu setting to this button.

(A P39 [Assignment of Functions to User Buttons] )

[TC/2] Time Code/User 2 Button

Displays the time code setting screen.

(A P69

You can also use it as a user button by assigning a specific feature in the menu setting to this button.

LCD monitor

(A P23 [LCD Monitor] )

J / K Volume Buttons/[+/-] Selection Buttons

Switches the audio monitor and adjusts the monitor speaker/headphone.

For switching the shutter speed and setting the automatic brightness adjustment (AE) level.

[SHUTTER] Shutter Speed Button

For switching the shutter speed in the Manual Shutter mode. Press and hold the button to switch between Automatic Shutter mode and Manual Shutter mode. (A P58 [Setting the Electronic Shutter] )

[AE LEVEL] Automatic Brightness Adjustment (AE) Level Setting Button

Sets the automatic brightness adjustment (AE) level. Press and hold the button to switch between “AE Level Setting Mode” and “Recommended Fixed Level (AE: ±0)”. (A P54 [Adjusting the Brightness] )

[OIS/6] Optical Image Stabilizer/User 6 Button

For switching the optical image stabilizer feature ON or OFF.

You can also use it as a user button by assigning a specific feature in the menu setting to this button.

[WHT BAL B/A/PRST] White Balance Switch

(A P60 [Adjusting the White Balance] )

[GAIN L/M/H] Gain Switch

(A P57 [Setting the Gain] )

[IRIS A/M] Auto Iris/Manual Iris Button

(A P55 [Adjusting the Iris] )

[Setting Time Code Generator] )

(A P39 [Assignment of Functions to User Buttons] )

[Monitoring Audio Sound During

(A P67 Recording Using a Headphone] )

(A P58 [Switching Shutter Speed] ) (A P54 [Adjusting the Brightness Automatically: Automatic Brightness Adjustment (AE) Mode] )

(A P

64 [Using the Image Stabilizer] )

(A P39 [Assignment of Functions to User Buttons] )

Introduction

Names of Parts

Side Terminal Section

GFEH

Introduction

[HOST] USB Host Terminal K

For connecting an USB adapter according to the

intended purpose when you are connecting the unit to a network. (A P143 [Camera Setup for Network Connection] )

[DEVICE] USB Mini Terminal

(A P140 [Loading Clips to the PC] )

[HDMI] HDMI Output Terminal

(A P138 [Connecting External Monitor] )

[SDI OUT] SDI Output Terminal K

(A P109 [ SDI Rec Trigger K ] ) (A P138 [Connecting External Monitor] )

Rear Terminal

GY-HM200U/GY-HM200E

GY-HM170U/GY-HM170E

[BATTERY] Terminal

RELEASE] Battery Lock Release Button

[BATT.

(A P30 [Removing the Battery] )

[REC] Record Trigger Button

Starts/stops recording.

P46 [Basic Shooting Procedures] )

You can change its function in the menu.

Memo :

This button is interlocked with the [REC/HOLD]

trigger button I at the top of the handle.

record

[DC] DC Input Terminal

Input terminal for DC 12 V power supply. For connecting with the supplied AC adapter. (A P31 [Using AC Power (DC IN Power)] )

[REMOTE] Remote Terminal

(A P140 [Connecting Wired Remote Control] )

[AUX] AUX Input Terminal (Φ3.5 mm)

For connecting to receiver such as wireless microphone. (A P65 [Audio Recording] )

[x] Headphone Jack (Φ3.5 mm)

(A P67 [Monitoring Audio Sound During Recording Using a Headphone] )

[AV] AV Output Terminal

(A P138 [Connecting External Monitor] )

Names of Parts

LCD Monitor

H I J

B A

L KM

LCD Monitor

(A P

37 [Adjusting the LCD Monitor and

Viewfinder] )

[CANCEL/STOP] Cancel Button

Cancels various settings and stops playback.

LCD Cross-Shaped Button (JKHI)/Set Button (R)

The function changes according to the operation status of the camera recorder.

During menu operation (all modes)

[Basic Operations in Menu

(A P92

Screen] )

During Camera mode

You can use it as a user button by assigning a specific feature in the menu setting to this button.

(A P39 [Assignment of Functions to User

Buttons] )

[MENU/THUMB] Menu/Thumbnail Button

Displays the menu screen during Camera mode.

Switches between [Main Menu [Favorites Menu] when the [MENU/THUMB] button is pressed and held down while the

menu screen is displayed.

(A P

92 [Basic Operations in Menu

Screen] )

Displays pressed during thumbnail display in the Media mode.

Stops playback and displays the thumbnail screen when the button is pressed during playback screen display in the Media mode.

[LOLUX/3] Low-light Shooting/User 3 Button

For switching the low-light shooting mode ON or OFF.

You can also use it as a user button by assigning a specific feature in the menu setting to this button.

the menu screen when the button is

[Assignment of Functions to User

(A P39

Buttons] )

] and

C.REVIEW/4] Clip Review/User 4 Button

[

For checking the most recently captured images.

(A P

73 [Viewing Recorded Videos

Immediately (Clip Review)] )

You can also use it as a user button by assigning a specific feature in the menu setting to this button.

(A P39 [Assignment of Functions to User Buttons] )

[ZEBRA/5] Zebra/User 5 Button

(A P72 [Setting Zebra Pattern] ) You can also use it as a user button by assigning a specific feature in the menu setting to this button. (A P39 [Assignment of Functions to User Buttons] )

[DISPLAY] Display Button

Press the display screen during normal screen display

(when the menu screen is not displayed).

(A P

Switches between [Main Menu] and [Favorites Menu] when the [DISPLAY] button is pressed while the menu screen is

displayed.

(A Screen] )

[STATUS] Status Screen Display Button

Press the [STATUS] button to display the status screen on the viewfinder and LCD monitor

during normal screen display (when the menu screen is not displayed). (A P36 [Status Screen] )

Monitor Speaker

(A P86 [Audio Output during Playback] )

SD Card Slot

(A P41 [Inserting an SD Card] )

Card Slot A/B Status Indicator

[SLOT SEL] Card Slot Selection Button

For switching the active card slot during shooting and playback.

[DISPLAY] button to switch to the

35 [Display Screen] )

P92 [Basic Operations in Menu

Names of Parts

Introduction

Handle Unit K

N OML

Introduction

Microphone Holder

Microphone Holder Lock Knob

Handle Tally Lamp

Accessory Mounting Screw Hole

Shoe

Handle Unit Fastening Screw

Zoom Lever on Handle

[ZOOM L/M/H] Zoom Speed Switch

[REC/HOLD] Record Trigger Button/Lock Switch

Memo :

This switch is interlocked with the C on the rear terminal.

[REC] locked.

(A P

27 [Attaching the External Microphone

O] )

(A P27 [Attaching the External Microphone O] )

(A P39 [Tally Lamp] ) (A P174 [Blinking of the Tally Lamp] )

For mounting separately sold lights and accessories.

(A P27 [Attaching the Handle Unit K] )

(A P49 [Using the Zoom Lever at the Handle O] )

(A P49 [Zoom Operation] ) For switching the zoom speed of the zoom lever 8 at the handle.

Starts/stops recording. Set the switch to [HOLD] to lock the [REC]

Trigger button.

button C on the rear terminal is not

[REC] button

[INPUT1/INPUT2

] Audio Input Terminal 1, 2

(XLR 3-pin x 2)

(A P27 [Attaching the External Microphone O] )

Handle Terminal

[CH1] CH1 Audio Input Signal Selection Switch

Select the audio input terminal to record to CH1. (A P65 [Audio Recording] )

[CH2] CH2 Audio Input Signal Selection Switch

Select the audio input terminal to record to CH2. (A P65 [Audio Recording] )

[INPUT1] Audio Input Signal Selection Switch

(A P65 [Audio Recording] )

[INPUT2] Audio Input Signal Selection Switch

(A P65 [Audio Recording] )

[CH2 AUTO/MANUAL] CH2 Audio Recording Mode Switch

(A P66 [Adjusting the Audio Recording Level O] )

[CH2] CH2 Recording Level Adjustment Knob

(A P65 [Audio Recording] )

[CH1] CH1 Recording Level Adjustment Knob

(A P65 [Audio Recording] )

[CH1 AUTO/MANUAL] CH1 Audio Recording Mode Switch

(A P66 [Adjusting the Audio Recording Level O] )

Names of Parts

Lens Section

C DB

Filter Built-In Screw

Transparent or UV filter for lens protection, or filters for various effects can be installed.

Installable filter types: Φ62 mm P0.75

Memo :

Remove the lens hood when installing the filter.

(A P28 [Attaching/Detaching the Hood] )

Focus Ring

(A P50 [Focus Operation] )

Zoom Ring

(A P49 [Zoom Operation] ) You can set different functions for the zoom ring and iris dial in [Main Menu] B [Camera Function] B [Zoom Ring]. (A P97 [ Zoom Ring ] )

Iris Dial

(A P55 [Adjusting the Iris] ) You can assign the dial for “Shutter” or “AE Level” adjustment in [Main Menu] B [Camera Function] B [Iris Dial]. (A P97 [ Iris Dial ] )

Introduction

Names of Parts

Basic System Diagram

Wireless Microphone Receiver

RCA pin

AV C abl e

HDMI Cable

[AUX]

[INPUT1/INPUT2]

[SDI OUT]

[HDMI]

[AV]

[REMOTE]

[DEVICE]

[DC]

[x]

K :

Carrying Case

Tr i p o d

SDHC/SDXC

Memory Card

SDHC/SDXC Card Reader

USB Cable

Battery

Standard Package

AC Adapter

Handle Unit

Remote Control Unit

Non-linear Editing

System

GY-HM200U/GY-HM200E/ GY-HM170U/GY-HM170E

GY-HM200U/GY-HM200E only

Microphone

Monitor

SDI Cable BNC

Headphone

[HOST]

Network Adapter

GY-HM200U/GY-HM200E only

When handle unit is attached

Battery Chager

IDX Battery Charger

M :

BN-VF823

K : SSL-JVC50

AA-VF8

Introduction

* GY-HM170U/GY-HM170E does not come with the handle unit.

For details on purchasing the handle unit, please contact the local dealers in your area.

Basic System Diagram

Settings and Adjustments

1, 3

Before Use

Attaching the Handle Unit K

The handle unit is detached from the camera recorder unit in the factory shipment.

GY-HM170U/GY-HM170E does not come with the handle unit. For details on purchasing the handle unit, please contact the local dealers in your area.

To use the handle unit, attach it by following the steps below.

* Attach or detach the handle unit when the power

is turned off.

Fit the handle terminal at the bottom of the handle unit to the handle unit mount at the top of the camera recorder.

Fit the handle unit carefully, paying attention not to damage the terminals at the bottom of the unit.

Slide the handle unit in the direction indicated shoe of the camera recorder.

Press the screw on the handle unit and turn it in the clockwise direction. Tighten it securely to fasten the unit to the camera recorder.

Caution :

Attach is turned off. Doing so when the power is turned on can result in malfunction.

by the arrow to attach it to the hot

handle unit may be unsteady if the screw

The is not securely fastened, and may fall off during use.

or detach the handle unit when the power

Adjusting the Grip Belt

Open the pad and adjust the position of the grip belt accordingly.

Caution :

If the grip is loose, the camera recorder may fall off resulting in injuries or malfunction.

Attaching the External Microphone O

You can attach a separately sold microphone to the microphone holder.

Turn the knob on the microphone holder counterclockwise to loosen and open the microphone holder.

Place the microphone in the microphone holder.

Turn the knob on the microphone holder clockwise to secure the microphone.

Connect the microphone cable to the [INPUT1]

Pin the microphone cable to the clamp.

Perform the settings for the microphone correctly.

(A P

or [INPUT2] terminal.

65 [Audio Recording] )

Preparations

Settings and Adjustments Before Use

Attaching/Detaching the Lens Cap

Before shooting, detach the lens cap.

this camera recorder is not in use, attach

When the lens cap to protect the lens.

Pinch the tabs on both sides of the lens cap to attach and detach the lens cap.

Preparations

Attaching/Detaching the Hood

Attaching the Hood

Align the markings on the camera recorder and hood; turn the hood in the direction of the arrow (clockwise) until it is locked.

Caution :

Do not press against the lens cap with force. Doing so may damage the lens or the cap.

Detaching the Hood

To detach the hood, turn the hood in the direction opposite to attaching it (counterclockwise).

Caution :

Remove the hood when attaching a filter, teleconverter

or wide converter to the front of the

lens.

Settings and Adjustments Before Use

Attaching the Tripod

o Bottom

Use the screw hole at the bottom of this camera recorder. (3/8×16UNC, 1/4×20UNC) Use the screw hole that suits the tripod. To prevent the camera recorder from falling off, which may result in injuries or damages, read the instruction manual of the tripod to be used and make sure that it is securely attached.

Caution :

Use the tripod on a stable surface.

To prevent the camera recorder from falling, attach securely using the rotation prevention hole.

screws with screw length 5 mm and below.

Use

Power Supply

To use this camera recorder, you can attach a battery pack or connect an AC adapter to it.

29 [Using a Battery Pack] )

(A P (A P31 [Using AC Power (DC IN Power)] )

Caution :

Set the [POWER ON/OFF before changing the power supply that operates

this camera recorder.

Using a Battery Pack

Charging the Battery

Charge the battery immediately after purchase or when the battery power is running low.

The battery is not charged when purchased.

] switch to “OFF”

Hold down the lock button (blue) at the center of the [POWER ON/OFF] switch to set

to “OFF”.

Attach the supplied battery.

Slide it in until you hear a click.

Connect the supplied AC adapter to the

terminal.

[DC]

Open the cover of the [DC] as shown in the diagram.

Connect the AC adapter to a power outlet.

The [POWER/CHARGE] lamp blinks during charging and will go out after charging is

complete.

Remove the AC adapter after charging is complete.

Memo :

[POWER/CHARGE] Lamp

Alternates between a blinking

orange light (4 times) and

Alternates between a blinking

orange light (3 times) and

Alternates between a blinking

orange light (2 times) and

Alternates between a blinking orange

of the [POWER/CHARGE] lamp during

Blinking charging indicates the charge level.

light off (1 second)

light (blinks once) and

light off (1 second)

Light goes out Fully charged

can charge the battery even when operating

You the camera recorder using the AC adapter.

terminal and connect

Charge Level

Less than 25 %

Less than 50 %

Less than 75 %

Less than 100 %

Preparations

Settings and Adjustments Before Use

Removing the Battery

GY-HM200U/GY-HM200E

GY-HM170U/GY-HM170E

Preparations

Hold down the lock button (blue) at the center of the [POWER ON/OFF] switch to set

to “OFF”.

While pressing and holding the [BATT. RELEASE battery in the direction of the arrow.

Caution :

Do not remove the battery when the [POWER ON/OFF

Do not insert or remove the DC cable when the battery is in use.

Leaving the camera recorder unused with the battery inside will deplete the battery power even if you set the

“OFF”. Remove the battery if you are not using the camera recorder.

Estimated Charging and Continuous Operating Times

Charging time

SSL-JVC50 (accessory) K:Approx. 4 hrs BN-VF823 (accessory) M:Approx. 3 hrs

When the [POWER ON/OFF] switch is set to “OFF”

] button, push up and remove the

] switch is “ON”.

[POWER ON/OFF] switch to

Memo :

you charge the battery immediately after using

If while the battery is still warm, it may not be fully charged.

It is recommended that you charge the battery in an environment between 10 °C and 30 °C (50 °F and 86 °F). The battery may not be fully charged or the charging time may be prolonged if charged under low temperatures (below 10 °C/ 50 °F). In addition, charging the battery under high temperature (above 30 °C/86 °F) condition may shorten the battery life.

For details, refer to the instruction manual of the battery.

Continuous operating time

SSL-JVC50 (accessory)

BN-VF823 (accessory)

When [System] is set to “4K” and all other

settings are in factory default

*2 When [System] is set to “HD” and all other

settings are in factory default

Memo :

Precautions for Batteries

operating times may differ depending on

Actual the age of the battery, charging condition, and operating environment. Operating time is shortened in cold environment. The operating time may shorten when power zoom is used, accessories are connected, or when the LCD monitor is frequently used. For purchase of spare batteries and battery charger, area.

Store the battery in a cool and dry place when not in use. Do not expose the battery to high temperatures (such as in a car under direct sunlight). Failure to do so not only shortens the battery life but also damages the battery. If the operating time shortens drastically even after charging, the battery may be reaching the end of its life. Replace the battery with a new one.

please contact the local dealers in your

Approx. 4 hrs 40 mins

(*1) Approx. 5 hrs (*2) Approx. 2 hrs (*1)

Approx. 2 hrs 20 mins (*2)

Power Supply

Using AC Power (DC IN Power)

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 :56

Jan 24 ,2015

00:00 :00.00

4030 20 10 0

5 . 6 f t

P 15000K

100min

50min

282min

3840x2160 30p 150M

Use the supplied AC adapter to operate the camera recorder with AC power.

Power Status Display

Viewfinder Screen and LCD Monitor

The power status is displayed on the display and menu screens.

Display Description

B 7.4V B 100min C 30% 4 RES

Currently powered by a battery. When the battery power runs out, the battery mark appears hollow, and “RES” (yellow) is displayed.

Memo :

You can set the display using [LCD/VF] B [Display Settings

B [Battery].

P107 [ Battery ] )

Preparations

]

Connect the DC cable of the AC adapter to the [DC]

terminal of the camera recorder.

Check that the power switch of the camera recorder is set to “OFF

Open the cover of the [DC] terminal and

”.

connect as shown in the diagram.

Hold down the lock button (blue) at the center of the [POWER ON/OFF] switch to set

to “ON”.

Power will be supplied to the camera recorder.

Caution :

Do not insert or remove the DC cable during recording.

Do not use power supply of high voltage fluctuation, containing noise such as ripple, or with insufficient capacity.

Charging the Built-In Battery

The date/time and time code data are stored using the built-in rechargeable battery.

When power is connected to the camera recorder, the built-in battery always gets charged. When the power is disconnected, the battery gradually discharges.

The battery will be totally discharged if left

for 3 months and the date/time and time

unused code data will be reset. When this happens, set the [POWER ON/OFF] switch to “ON” to display

the [Initial Setting] screen, then set the date/ time.

(A P33

[Initial Settings] )

Acquisition of battery information may fail if a genuine battery is not used.

Appears when an error occurs during battery charging.

Currently powered by an AC adapter.

P Q R S

Camera recorder battery charging in progress.

P108 [Details on charging

(A condition] )

Memo :

the supplied battery (or equivalent battery sold separately) is not used, the battery mark which indicates the battery level may not appear.

Display Screen

127 [Display Screen in Camera Mode] )

(A P (A P132 [Display Screen in Media Mode] )

Power Supply

Menu Screen

Display Settings

93 [Display and Description of the Menu

(A P Screen] )

Preparations

Warnings by Lamp and Warning Tone

Warning status is indicated by tally lamp and warning tone.

The tally lamp blinks.

Setting [Main Menu] B [A/V Set] B [Audio Set] B [Alarm Level] to “High” or “Low” sounds the

warning tone. The warning tone is output from the monitor speaker or [x] terminal.

(A P112

Memo :

Caution :

[ Alarm Level ] )

the event that the battery level runs low while

In it is being used, the camera recorder will stop operating automatically.

The remaining battery power and time are displayed as they are from the battery information. depending on the battery condition. Replace the battery as soon as possible when the remaining battery power and time are low.

Accurate data may not be displayed

Turning On/Off the Power

Turning On the Power

Hold down the lock button (blue) at the center of the [POWER ON/OFF] switch to set

to “ON”.

The camera recorder starts up in Camera mode and is ready for shooting.

Memo :

The camera recorder always start up in Camera mode when the [POWER ON/OFF] switch is set to

“ON”. Use the [MODE] button at the side of the camera recorder to switch mode.

(A P18 [Operation Modes] )

If the battery is not fully charged, the battery will be charged at the same time.

Even when a fully charged battery is used, charge the battery briefly to confirm the remaining battery power.

(A P29 [Power Supply] ) (A P31 [Power Status Display] )

Turning Off the Power

Sets the camera recorder to the recording standby or stop mode.

Hold down the lock button (blue) at the center of the [POWER ON/OFF] switch to set

to “OFF”.

Remove the battery and the power to the [DC] terminal (when not in use for a long time).

Caution :

Do not set the [POWER ON/OFF] switch to “OFF” during recording. Check that the operation mode

display is “STBY” or “STOP” before you turn off the power.

If you have mistakenly set the [POWER ON/OFF] switch to “OFF” during recording, wait for 5 seconds or more before you turn on the power

again.

When turning off the power, first set the [POWER ON/OFF] switch of the camera recorder to “OFF”. Do not remove the battery or turn off the AC power

while the [POWER ON/OFF] switch is set to “ON”.

Power Status Display

Initial Settings

Español

Français

English

Language

Pусский

Español

Italiano

Deutsch

Français

English

Language

the power is first turned on, the Initial Setting

When screen for performing the initial settings in the camera recorder appears. Set the date/time of the built-in clock in the [Initial

Setting] screen. All operations are disabled until initial settings are

complete.

Memo :

is recommended to use the AC adapter as the

power supply.

Attach the lens cap.

Hold down the lock button (blue) at the center of the [POWER ON/OFF] switch to set

to “ON”.

A language selection screen appears.

For U models

Memo :

The menus and messages on the screen of the LCD monitor or viewfinder are displayed in the selected language.

Select a language using the cross-shaped button (JK), and press the Set button (R).

The Initial Setting screen appears.

Ensure the lens cap is attached, and press the Set button (R).

Self-diagnosis starts.

A progress bar appears, and “Complete Diagnosis

” appears when the diagnosis is

complete.

Preparations

For E models

Memo :

It takes about 6 minutes to complete the diagnosis.

During the diagnosis, do not operate

or turn off the camera recorder.

Initial Settings

Set

UTC-05:00

Initial Setting

Set

UTC

Initial Setting

Press the Set button (R) after confirming the exit screen.

The [Initial Setting] screen appears.

For U models

Preparations

For E models

Memo :

[Initial Setting] screen appears when the

The power is turned on for the first time and when the

power is turned on after the built-in battery is fully discharged.

The configured date/time data is saved in the built-in

rechargeable battery even if the power is

turned off.

Set the time zone and date/time.

Move the cursor with the cross-shaped button (HI) and select the setting item.

Change the values with the cross-shaped button (JK).

Press the Set button (R) after setting is complete.

The clock is set to 0 seconds of the input date/ time.

Memo :

configured date/time data can be displayed

The on the LCD monitor and viewfinder and be recorded to the SD card.

The value of the year can be set in the range of “2000” to “2099”.

Changing the Time after Initial Setting

Setting the Date/Time

114 [ Date/Time ] )

(A P

Select [System] B [Date/Time

The [Date/Time] screen appears.

Set the date and time.

Move the cursor with the cross-shaped button (HI) and select the setting item.

Change the values with the cross-shaped button (JK).

Press the Set button (R) after setting is complete.

The clock is set to 0 seconds of the input date/ time.

Changing the Display Style

You can change the display style of the date/time on the menu.

Setting the Date Display (Date Style)

108 [ Date Style ] )

(A P The date display can be changed in [LCD/VF] B [Display Settings] B [Date Style].

Setting the Time Display (Time Style)

(A P

108 [ Time Style ] ) The time display can be changed in [LCD/VF] B [Display Settings] B [Time Style].

Date/Time Display in Each Operation Mode

During Camera mode: Date/time of the built-in clock is displayed. During Media mode: Shooting date/time of the clip being played back is displayed.

Initial Settings

Displays on the LCD

100min

50min

282min

1/100

F1.6

AE+6

ND 1/16

12 :34 : 56

Jan 24 ,2015

00:00 :00.00

3840x2160 30p 150M

4030 20 10 0

5.6ft

P 15000K

1/100

F1.6

AE+6

ND 1/16

12 :34 : 56

Jan 24 ,2015

00:00 :00.00

4030 20 10 0

5.6ft

P 15000K

Display 2 screen

Display 1 screen

Display 0 screen

1000/2000

12 :34 :56

Jan 24,2015

00:00 :00.00 3840x2160 30p 150M

4030 20 10 0

1000/2000

282min

12 :34 :56

Jan 24,2015

00:00 :00.00 3840x2160 30p 150M

4030 20 10 0

1000/2000

SELECT

INFO

Display 2 screen

Display 1 screen

Display 0 screen

Monitor and Viewfinder

You can display the camera status, media information, zebra pattern, and various markers in

video image on the LCD monitor and viewfinder

the screen during shooting.

Memo :

When

[Main Menu] B [A/V Set] B [Video Set] B [Display On TV] is set to “On”, the display screen and menu screen are also displayed in the video

image from the video signal output terminal.

(A P109

Display Screen

Display Screen (VF/LCD) in Camera Mode

(A P127 [Display Screen in Camera Mode] )

[ Display On TV ] )

The display switches between three screen

with every press of the [DISPLAY] button.

types (Display 0 B 1 B 2 B 0) Press the [STATUS

] button to switch to the

status screen.

Display Screen (VF/LCD) in Media Mode

132 [Display Screen in Media Mode] )

(A P

This is the screen display during clip playback in Media Mode.

The display switches between three screen types with every press of the [DISPLAY] button.

(Display 0 B 1 B 2 B 0)

Preparations

Displays on the LCD Monitor and Viewfinder

Status Screen

-62dB

Audio

Planning Metadata

Creator

Description

Title2

Title1

Aspect Marker

Zebra

Camera 1

Safety Zone

None

Handle Zoom Speed H

Handle Zoom Speed M

Handle Zoom Speed L

GAIN H

GAIN M

GAIN L

FAW

Camera 2

USER7

USER6

USER5

USER4

USER3

USER2

USER1

Rec

OIS

Zebra

Clip Review

Lolux

TC Preset

Focus Assist

USER Switch Set

HDMI Enhance

HDMI Color

Resolution

HDMI/SDI Out

Video

WPA2

P2P

MAC Address

IP Address

Passphrase

Security Type

SSID

Typ e

Network

Format

7.5%

SDI Rec Trigger

SD Aspect SD Set Up

Squeeze

HDMI+SDI

1080i

Auto

Off

USB Mode

Exit

Remote Edit Mode

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00: 00:00.00

4030 20 10 0

5 . 6 f t

P 15000K

Warning Display Area

This screen allows you to check the current settings.

To display the status screen, press the [STATUS

The status display differs according to the operation mode (two types).

(A P18

Press the [STATUS] button to switch to the display screen.

Preparations

Press the [MENU] button at each status screen (other than the [ setting screen.

Use the cross-shaped button (HI) to switch screens as follows:

] button in the normal screen.

[Operation Modes] )

Camera 1] screen) to enter the

USB Mode Screen

This screen displays the USB mode.

Remote Edit Mode Screen K

This is a mode for accessing the page for editing the metadata that is recorded in a clip via a web browser on devices such as a smartphone, tablet terminal, or PC.

(A P152

[ Clip Metadata ] )

These are screen examples of GY-HM200U/GYHM200E. The contents displayed are different depending on the model and settings.

Displays on the LCD Monitor and Viewfinder

Warning Display

Warning display is displayed in the display screen (Camera mode, Media mode).

170 [Error Messages and Actions] )

(A P

Adjusting the LCD Monitor

Normal LCD

Inverted LCD

Tilt 90 degrees downward

Tilt 180 degrees

upward

and Viewfinder

You can monitor video images on this camera recorder using the viewfinder, LCD monitor, or both.

Displays on the LCD Monitor and Viewfinder Screen (VF)

[VF

SW] Item

Enable Pulled out ON ON ON Enable Retracted ON OFF ON

Disable - ON ON ON

ON: Display on, OFF: Display off

“LCD LCD display is inverted.

“LCD Monitor Closed” indicates the state when there is no display on the LCD monitor.

Memo :

Press and hold the [DISPLAY] button for 2 seconds to turn ON/OFF the LCD monitor.

The function to switch between LCD monitor and viewfinder displays by pressing the [DISPLAY]

button can be canceled by opening/closing or rotating the LCD monitor.

When [LCD/VF] B [VF SW] is set to “Enable”, it is necessary to pull out the viewfinder in order to

display the images on the viewfinder.

(A P104 [ VF SW ] )

* When [LCD/VF]

images will be displayed on the viewfinder if the viewfinder is pulled out, regardless of the state of the LCD monitor.

(A P104 [ VF SW ] )

State of

Viewfinder

Monitor Open” includes the state when the

LCD

Screen

LCD

Monitor

Open

[VF SW] is set to “Enable”,

LCD

Monitor

Open

Viewfinder

Screen

LCD

Monitor

Closed

Adjusting the LCD Monitor

Open the LCD cover.

Incline the LCD monitor to a position that enables easy viewing.

Rotate the LCD monitor to adjust the angle.

While the LCD monitor is open, you can rotate it 180 degrees upward or 90 degrees downward.

Rotating the LCD monitor 180 degrees upward enables you to see the screen from

lens side. To display the image when it is

the viewed from the opposite direction (mirror image), perform setting as follows. Set [Main Menu] B [LCD/VF] B [LCD

Mirror] to “Mirror” B Set button (R)

(A P

105 [ LCD Mirror ] )

Adjust the brightness, contour, and contrast of the LCD monitor.

You can change the angle and brightness of the

monitor according to your usage condition.

LCD Changing the brightness of the screen will not affect the recorded images.

Use the [LCD Bright] menu to adjust the brightness of the LCD monitor.

[Main Menu] B [LCD/VF] B [LCD Bright]

(A P105

Use the [LCD/VF Peaking] menu to adjust the contour of the LCD monitor.

(The contour of the viewfinder screen will also be adjusted at the same time.) [Main Menu] B [LCD/VF] B [LCD/VF

Peaking]

Use the [LCD Contrast] menu to adjust the contrast of the LCD monitor.

[Main Menu] B [LCD/VF] B [LCD Contrast

(A P

[ LCD Bright ] )

P105 [ LCD/VF Peaking ] )

105 [ LCD Contrast ] )

Preparations

]

Adjusting the LCD Monitor and Viewfinder

Adjusting the Viewfinder

You can change the brightness and peaking of the viewfinder screen according to your usage conditions. Changing the brightness of the screen will not affect the recorded images.

Preparations

Caution :

A high-definition viewfinder is used on this

recorder in order to provide an accurate

camera focusing environment. Due to the characteristic of the display device, colors may appear on the images when you blink your eyes. This is not a malfunction. It does not affect the recorded images, SDI output K, AV output, or HDMI output.

Pull out the viewfinder.

Incline the viewfinder vertically to a position that enables easy viewing.

Adjust the visibility using the visibility adjustment lever.

Adjust the visibility adjustment lever to sharpen the image on the viewfinder screen.

Adjust the brightness, contour, and contrast of the viewfinder screen.

Use the [VF Bright brightness of the viewfinder screen.

[Main Menu] B [LCD/VF] B [VF Bright]

(A P

105 [ VF Bright ] )

Use the [LCD/VF Peaking] menu to adjust the contour of the viewfinder.

(The contour of the LCD monitor will also be adjusted at the same time.) [Main Menu] B [LCD/VF] B [LCD/VF

Peaking]

(A P

105 [ LCD/VF Peaking ] )

Use the [VF Contrast] menu to adjust the contrast of the viewfinder screen.

[Main Menu] B [LCD/VF] B [VF Contrast]

(A P105

Memo :

If [Main Menu] B [LCD/VF “Enable”, pull out the viewfinder before making any adjustment.

(A P

104 [ VF SW ] )

Displaying in Black and White

You can display the viewfinder screen in black and white.

[Main Menu] B [LCD/VF] B [ B Press Set button (R) B Select “Off” B

Press Set button (R).

(A P

104 [ VF Color ] )

] menu to adjust the

[ VF Contrast ] )

] B [VF SW] is set to

VF Color] item

Adjusting the LCD Monitor and Viewfinder

Assignment of Functions

Tally Lamp

(Front)

Handle Tally

Lamp

to User Buttons

You can assign functions to the following buttons and use them as user buttons.

assigning functions to the buttons, the usability

By of the camera recorder can be enhanced. Perform settings in the menu items corresponding to each button.

Button Menu Item

[F.ASSIST/1] Button [USER1] [TC/2] Button [USER2] [LOLUX/3] Button [USER3] [C.REVIEW/4] Button [USER4] [ZEBRA/5] Button [USER5] [OIS/6] Button [USER6] [REC/7] Button [USER7] [EXPANDED FOCUS/8] Button [USER8] [AWB/9] Button [USER9] LCD Cross-Shaped Button (J) [LCD KEY▲] LCD Cross-Shaped Button (K) [LCD KEY▼] LCD Cross-Shaped Button (H) [LCD KEY◀] LCD Cross-Shaped Button (I) [LCD KEY▶]

Memo :

Operations of the user buttons are interlocked with the menu settings.

When the menu screen is displayed, these

function as the menu operation buttons.

buttons

(A P92 [Basic Operations in Menu Screen] )

Tally Lamp

This is the indicator lamp for recording and warning. The operation changes according to the menu settings. The lamp blinks when the battery or remaining space on the SD card is low. (Camera mode only)

Specify the setting in [Main Menu] B [System]

B [Tally Lamp].

(A P113 [ Tally Lamp ] )

Preparations

Assign functions to the buttons from the menu.

Specify each item in [Main Menu] B [Camera Function] B [User Switch Set] B [USER1][USER9], [LCD KEY▲], [LCD KEY▶], [LCD KEY▼], [LCD KEY◀]. (A P98 [User Switch Set Item] )

Menu setting

Functional information

Recording status Recording -

Lights up

Blinks four times in 1 second

Blinks once in 1 second

Paused state during special recording ([Clip Continuous]).

(A P79 [Clip Continuous Rec] )

Memo :

Blinking takes priority over lighting up.

Assignment of Functions to User Buttons

[Tally Lamp] Warning Caution -

Special recording * -

Off On

J o R R

SD Card

Write/Delete Enabled Write/Delete Disabled

Write-Protect Switch

This camera recorder saves the recorded images and audio sound on the SD card (sold separately) in the card slot.

Usable Cards

Format Setting and Usable SD Card Combinations

Preparations

System Format Bit Rate

4K - - UHS-I U3 or

HD QuickTime 50M

(YUV422), 50M (XHQ)

35M (UHQ) Class 6 or

AVCHD SD - Web - -

Caution :

Using cards other than those from Panasonic, TOSHIBA or SanDisk may result in recording failure or data loss.

If an UHS-I card with no classification indication is used, it may not be possible to perform HD recording.

Estimated Recordable Time of SD Cards

The estimated recordable time is only a guide. Differences may occur depending on the SD card in use and the battery condition.

(A P

115 [ W Resolution ] ) (A P116 [ Y Resolution ] ) (A P115 [ W Frame Rate ] ) (A P116 [ Y Frame Rate ] ) (A P115 [ W Bit Rate ] ) (A P116 [ Y Bit Rate ] )

When [Main Menu] B [System] B [Record Set] B [Record Format

] B [Format] is set to

“AVCHD”

Resolution

Bit Rate HQ HQ SP LP EP 4GB 16 19 25 46 82 50 8GB 33 39 50 95 168 103 16GB 67 78 100 190 336 209 32GB 135 156 200 380 672 420 64GB

(SDXC) 128GB

(SDXC)

1080p

270 312 400 760 1344 842

540 624 800 1520 2688 1687

1080i

Usable SD

Card

higher Class 10 or

higher

higher Class 4 or

higher

480i/

576i

(Unit: minute)

When [Main Menu] B [System] B [Record Set] B [Record Format

] B [Format] is set to

“QuickTime”

System 4K HD SD Web

Resolution 2160p 1080i/1080p 480i/

Bit Rate - XHQ UHQ - HQ LP 4GB 3 9 12 47 130 285 8GB 6 18 25 95 270 580 16GB 12 36 50 190 540 1160 32GB 25 72 100 380 1080 2320 64GB

(SDXC) 128GB

(SDXC)

50 145 200 760 2160 4720

100 290 400 1520 4320 9440

576i

960p 480p

(Unit: minute)

Memo :

the SD card contains files recorded by devices other than this camera recorder or files that are saved from a PC, the recordable time may be shorter or data may not be properly recorded.

For each file format, up to 600 clips can be recorded to one SD card on this camera recorder. When 600 clips are recorded to one card, the remaining space is displayed as 0 min regardless of the estimated recordable time, and no further recording can be performed.

When the file format is set to “AVCHD”, up to 4000 clips can be recorded to one SD card.

Write-Protect Switch on the SD Card

Slide the write-protect switch upward to enable writing or deleting.

Slide the write-protect switch downward to prevent writing or deleting. (Images in the card are protected.)

SD Card

Inserting an SD Card

SD Card Cover

SD Card

This camera recorder comes with two card slots (Slot A and B) for video/audio recording and playback.

Open the SD card cover by sliding the cover in the direction indicated by the arrow.

Insert an SD card with the notched corner pointing up.

The status indicator of the card slot to which the card was inserted lights up in red.

Close the SD card cover in the direction indicated by the arrow.

Card Slot Status Indicator

The following table shows the respective states of slot A and B.

Lamp Slot Status

Lights up in red

Lights up in green

Light goes out0SD card is not inserted.

The inserted SD card is being accessed. (writing/reading data) Do not turn off the power of the

recorder or remove the SD

camera card.

On standby. The inserted SD card can be used for recording or playback.

An unusable card is inserted.

An SD card is inserted but a different slot is selected.

Removing the SD Card

Check that the SD card to be removed is not being accessed (status indicator of the card slot lights up in red).

Slide open the SD card cover.

Push the SD card and remove it from the slot.

Close the SD card cover.

Memo :

When both slots are inserted with usable SD cards, the previously selected slot is used.

Caution :

Data may be lost if you turn off the power of the

recorder or remove the SD card when it

camera is being accessed. All data recorded on the card, including the file that is being accessed, may be corrupted. Be sure to check whether the status indicator is lit in green or turned off before you turn off the power or remove the SD card.

If you mistakenly remove the card when it is being accessed, reinsert the card only after the status indicator goes off.

The SD card may not be recognized if you insert and remove the card within a short time. When this happens, remove the card and wait for a few seconds before you reinsert.

Preparations

SD Card

Switching the SD cards

Set

Format Slot

Format Media

Set

Cancel

Format

Format Media

Formatting...

When both card slots are inserted with SD cards, you can use the

card to use. When the memory on an SD card is full during recording, data recording automatically switches to the other card.

[SLOT SEL] button to switch the

Preparations

Memo :

[SLOT SEL] button is disabled during

The recording or playback. Cards will not be

switched even if you press the button.

Formatting (Initializing) SD Cards

When the following cards are inserted, [!FORMAT] appears at the remaining media display area.

Format the card using the camera recorder menu.

Unformatted SD cards

SD cards formatted under different specifications

* For details of the menu operation, refer to

[Basic Operations in Menu Screen]

“ (A P 92)”.

Caution :

Be sure to format the SD card on this camera recorder. peripheral equipment cannot be used on this camera recorder.

[!RESTORE] appears at the remaining media display area when an SD card that requires

restoring is inserted.

SD cards formatted on a PC and other

Select [System] B [Media] B [Format

Media]

(A P

113 [ Format Media ] )

Select the slot of the SD card to be formatted and press the Set button (R).

The status of the selected SD card appears.

Select [Format] and press the Set button (R).

Formatting starts.

SD Card

Set

Restore Slot

Restore Media

Restoring...

Formatting is complete.

When formatting is complete, “

Complete” appears and the camera recorder returns to the [Format Media] screen.

Memo :

During formatting, menu operation is unavailable but you can start recording. However, this is only available when a recordable SD card is inserted in the other slot.

Formatting cases.

Recording is in progress on the SD card to be formatted.

SD card is not inserted.

Write-protect switch of the SD card is set (z

cannot be performed in the following

is displayed).

Caution :

If you format the SD card, all data recorded on the card, including video data and setup files, will be deleted.

Restoring the SD Card

It is necessary to restore the SD card if an abnormality occurs to the data in the card due to some reasons.

Memo :

[!RESTORE] appears at the remaining media display area when an SD card that requires

restoring is inserted.

Select [System] B [Media] B [Restore

Media]

(A P

113 [ Restore Media ] )

Select the SD card to be restored and press the Set button (R).

Restoring starts.

Restoring is complete.

When restoring is complete, “Complete

”

appears and the camera recorder returns to the [Restore Media] screen.

When no media that requires restoring is inserted, the camera recorder returns to the [

Media] menu screen.

Caution :

[Restore Media] can only be selected in Camera mode. However, it cannot be selected while the

camera recorder is recording. Select [Restore Media] in Camera mode when the camera recorder is not recording.

[Restore

Media] does not restore the SD card to

its original states completely. If restoring fails, replace or format the SD card. Take note that formatting erases all the information inside the SD card.

Restoring cannot be performed in the following cases.

Camera recorder is recording in progress.

SD card is not inserted.

Write-protect switch of the SD card is set (z is displayed).

Preparations

SD Card

Clips Recorded to SD Cards

ABCG0001

This is set to “xxxG” (“xxx” denotes the last 3 digits of the serial number) by default.

Clip Name Prefix (any four alphanumeric characters)

The Clip Number can be reset in the menu.*

A number in automatic ascending order is assigned in the recording order.

Clip Number

Folders in the SD Card

The captured image is recorded into different folders according to the

[YFormat] settings.

WFormat/

YFormat

QuickTime DCIM

AVCHD PRIVATE/AVCHD

Preparations

System

4K/HD/SD/

Web

HD/SD/

Web

Memo :

By formatting (initializing) the SD card from the [Format Media] menu on the camera recorder,

folders required for recording in the current [System] settings will be generated.

When the

[System] settings and [QuickTime]

settings are changed, folders required for recording in those settings will be automatically generated.

Caution :

When

a clip inside the folder is moved or deleted using the Explorer (Windows) or Finder (Mac), recording to the SD card may fail if formatting (initializing) of the card is not performed.

Clip (Recorded Data) and Clip Name

When recording is stopped, the images, audio and accompanying data which are recorded from start to stop are recorded as one “clip” on the SD card.

An 8-character clip name is automatically generated for the recorded clip. (“Clip Name Prefix

When [Main Menu] B [System] B [Record Set] B [Record Format

“AVCHD”, the clip name generated consists of only the Clip Number (5-digit number).

(A P

115 [ W Format ] )

[System] and [WFormat]/

Record Folder

” + “Clip Number”)

] B [WFormat] is set to

Example: QuickTime

* [Clip Set] B [Reset Clip Number]

118 [ Reset Clip Number ] )

(A P

Memo :

Before recording starts, you can set any characters for the clip name prefix by using [Main Menu] B [System] B [Record Set] B [Clip

Set] B [Clip Name Prefix].

(A P118

[ Clip Name Prefix ] )

Changes cannot be made after recording.

Recorded Clips

recorded materials may be split into several

The files but they can be played back continuously on the camera recorder.

Clips may be recorded across the two SD cards in card slots A and B depending on the recording time of the clip.

Caution :

A clip recorded across several cards cannot be

back continuously. Continuous playback

played is only possible when the recording is made on one card.

SD Card

Operation Lock Feature

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00: 00:00.00

4030 20 10 0

5 . 6 f t

P 15000K

You can use this feature to prevent erroneous camera operation.

While in the Camera mode (when the display screen appears), press and hold the [CANCEL]

longer.

The

operation lock turns on, and an operation

lock icon (r) appears on the display screen.

button for 5 seconds or

Operation lock does not apply to the following buttons and switches.

POWER ON/OFF] switch

[

INPUT1]/[INPUT2] Audio input signal selection

switch O

[CH1]/[CH2] Audio

input signal selection switch

[

CH1 AUTO/MANUAL]/[CH2 AUTO/MANUAL]

Audio recording mode switch O

Focus ring

Zoom

lever at the grip/Zoom lever at the handle

O/Zoom ring at the lens section

[ZOOM L/M/H] Zoom Speed Switch O

Iris Dial

[

REC/HOLD] Record Trigger Button/Lock

Switch O

[REC] button (on the grip)

Visibility Adjustment Lever

User button that has been assigned with the [

Rec] function.

Preparations

Press the [CANCEL] button again for 5 seconds or longer to turn off the operation

lock.

Memo :

The operation lock feature is only valid in the Camera mode.

[Operation Modes] )

(A P18

The power turns off and the operation lock is disengaged.

The following remote operations are possible even when the operation lock feature is turned on (“On”).

Remote operation from the wired remote control

connected to the [REMOTE] terminal.

Remote operation of the camera through access via a browser on devices such as a smartphone, tablet terminal, or PC.

Operation Lock Feature

Basic Shooting

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00:00 :00.00

4030 20 10 0

P 1500 0K

Procedures

Preparations

Shooting

Supply battery or AC adapter power to the camera recorder.

29 [Power Supply] )

(A P

Insert an SD card.

40 [SD Card] )

(A P

Turn on the power of the camera recorder.

Hold down the lock button (blue) at the center of the [POWER ON/OFF] switch to set to “ON”. The

camera recorder starts up in Camera mode and is ready for recording.

Adjust the angle of the LCD monitor and viewfinder.

37 [Adjusting the LCD Monitor and

(A P Viewfinder] )

Shooting

The [FULL AUTO] button of this camera recorder

“ON” by default, the following video items

is set to are automatically adjusted.

Iris

Gain

Shutter

White balance The audio recording level is also automatically configured, is recorded. When the [FULL AUTO] button is set to “ON”, the

v icon appears at the lower center area of the LCD.

* Press and hold the [FULL AUTO] button to

switch the Full Auto mode ON and OFF. Memo :

To set each individual video setting item

automatically or manually, and to carry out the

audio input settings and the audio recording

level adjustment, refer to the following.

and audio from the built-in microphone

[Adjusting the Brightness] (A P 54

[Adjusting the Iris] (A P 55)

[Setting the Gain] (A P 57)

[Setting the Electronic Shutter] (A P 58)

[Adjusting the White Balance] (A P 60)

[Selecting Audio to Be Recorded in Each Channel O] (A P 65)

[Adjusting the Audio Recording Level O]

)

(A P 66)

Basic Shooting Procedures

Press the [REC the SD card.

This camera recorder has two [REC] buttons. Any of the [REC stop recording by default.

The tally lamp lights up in red during recording.

Zoom Operation

(A P49

[Zoom Operation] )

Adjusting the Focus

(A P50 [Focus Operation] )

Memo :

both the slots are loaded with recordable cards

If in the factory default, pressing the [REC] button

starts recording only to the media in the selected slot. When [Main Menu] B [System] B [Record Set]

B [Slot Mode] is set to “Dual”, recording can be performed simultaneously to the cards in both

the slots.

P74 [Dual Rec] )

The tally lamp can be turned off in [System] B [Tally Lamp].

(A P

113 [ Tally Lamp ] )

Check the most recently captured images.

Press the [C.REVIEW/4] the Clip Review function. The most recently

captured images are played back on the LCD monitor and viewfinder screen.

After playback, the camera recorder returns to standby mode (STBY).

P73 [Viewing Recorded Videos

Immediately (Clip Review)] )

Memo :

[Clip Review] is assigned to the [C.REVIEW/4] button in factory default.

[Clip

Review] can also be assigned to other user

buttons.

(A P

39 [Assignment of Functions to User

Buttons] )

] button to start recording to

] buttons can be used to start/

button to activate

Selecting System Definition,

File Format and

Video Format

You can select the resolution of the recorded videos (4K, HD, SD, or Web), file format for recording/playback, and the video recording format on this camera recorder.

Setting the Record Format Menu

Set [System], [Format], [Resolution],

Frame Rate] and [Bit Rate] in [Main Menu]

[ B [System] B [Record Set] B [Record Format].

Set each of the items.

[Selecting a System Definition] (A P 47

[Selecting a File Format] (A P 48)

[Selecting a Video Format] (A P 48)

[Selecting the Aspect Ratio of SD Videos] (A P 49)

After setting is complete for all items, press the [LOLUX/3]

The recording format is switched.

“Please Wait...” message appears on the

screen during switching.

button.

Selecting a System Definition

There are four different definitions for selection.

4K:

Records in 4K resolution (3840x2160)

HD:

Records in HD (High Definition) resolution

(1920x1080 or 1280x720)

SD:

Records in SD (Standard Definition) resolution

(720x480 or 720x576)

Web:

Records in resolution (1440x1080, 960x480,

720x480,

distribution

You from the following items under [System].

4K:

Records in 4K quality for both slots A and B.

HD:

Records in HD quality for both slots A and B.

SD:

Records in SD quality for both slots A and B.

HD+Web:

Records

for slot B.

(A P74 [Recording Simultaneously at Two Different Definitions] )

720x576, or 480x270) suitable for web

can select a definition for the recorded images

in HD quality for slot A, and Web quality

)

Shooting

Basic Shooting Procedures

Selecting a File Format

Select a file format in [WFormat]/[YFormat]. There are two file formats for selection.

AVCHD: AVCHD file format

QuickTime: QuickTime file format (.MOV)

Memo :

When [System] “QuickTime”.

is set to “4K”, this item is fixed at

Selecting a Video Format

Shooting

Select a [Record Format] from the list of formats. The selectable [W Frame Rate]/[W Bit Rate]/[Y Frame Rate] and [Y Bit Rate] change according to the settings of [System]/ [WFormat]/[WResolution]/[YFormat], and

[YResolution].

List of Formats

The following is a list of file formats and video formats that can be selected on this camera recorder.

When [System] is set to

Record Format

W Format W Resolution W Frame

Quick Time

Memo :

Each item for slot B is fixed at the same setting as slot A.

3840x2160 30p

“4K”

Rate

25p 24p

Bit Rate

150M

QuickTime 1920x1080 60p

Memo :

QuickTime

Memo :

[System] is set to “HD” or “HD+Web”, the

When

options for slot A are:

FormatW ResolutionW Frame

AVCHD 1920x1080 60p 28M (HQ)

When [WFormat] is set to “Quick Time”

[WResolution] is set to “1920x1080”, the

selectable options for [WBit Rate] vary

according to the setting for [WFrame Rate].

When

B is fixed at the same setting as slot A.

When [System] is set to

“50M(YUV422)” cannot be selected.

When [System] is set to

W Format W Resolution W Frame

AVCHD

Each item for slot B is fixed at the same setting

as slot A.

Record Format

Rate

60i

50p

50i 30p 25p

1280x720 60p

[System] is set to “HD”, each item for slot

Record Format

720 x 480 60i (U model) 720 x 576 50i (E model) 720 x 480 60i (U model) 720 x 576 50i (E model)

24p

50p

60i 24M (HQ)

50p 28M (HQ)

50i 24M (HQ)

“HD+Web”,

“SD”

50M (YUV422)

50M (XHQ) 35M (UHQ)

35M (UHQ)

Rate

Bit Rate

18M (SP)

and

W Bit

Rate

Selecting System Definition, File Format and Video Format

QuickTime

Memo :

[System] is set to “HD+Web”, the options

When for slot B are:

Y Format Y Resolution Y Frame

AVCHD

The available options for [YResolution] and [YFrame slot A.

The selectable options for YResolution vary according to the [WFrame Rate] setting.

[YFrame Rate] is fixed according to the [WFrame Rate] setting.

Record Format

960 x 540 30p

720 x 480 60i 720 x 576 50i

480x270 30p

1440 x 1080 60i

720 x 480 60i 8M 720 x 576 50i

Rate] vary according to the settings for

Rate

25p 24p

50i

3M (HQ)

1.2M (LP)

9M (LP) 5M (EP)

Bit Rate

Selecting the Aspect Ratio of SD Videos

For setting the aspect ratio of the SD recording image when

You can select “16:9” or “4:3”.

Memo :

For conditions other than those above, this item is fixed at “16:9”.

[System] is set to “SD”.

Zoom Operation

Adjusts the angle of view. Optical zoom ratio: 1x to 12x Dynamic zoom ratio: 12x to 24x Set

the dynamic zoom “On”/“Off” in [Main Menu] B

[Camera Function] B [Dynamic Zoom].

(A P97 [ Dynamic Zoom ] ) Zooming can be operated using any of the three levers/rings below.

Zoom Lever at the Grip

Zoom lever at the Handle O

Zoom Ring at the Lens Section During the zoom operation, the zoom bar or number

will appear on the upper right corner of the

screen.

(A P130 [Zoom Display] )

Using the Zoom Lever at the Grip

Press the zoom lever to zoom.

The zoom speed changes according to the extent the zoom lever is being pushed.

Zooms into wide angle and increases the angle of view when

Zooms into telephoto and decreases the angle of view when

“W” is pressed.

“T” is pressed.

Shooting

Using the Zoom Lever at the Handle O

Set the zoom speed individually in [Main

] B [Camera Function] B [Handle

Menu Zoom Speed L]/[Handle Zoom Speed M]/ [Handle Zoom Speed H].

Selecting System Definition, File Format and Video Format

the zoom speed for “L”, “M” and “H” of the

Set [ZOOM L/M/H] zoom speed switch individually.

Increasing the value increases the zoom speed.

(A P97 [Handle Zoom Speed L/Handle Zoom Speed M/Handle Zoom Speed H O] )

Memo :

The zoom lever on the handle is disabled when “Off

” is selected.

Set the [ZOOM L/M/H] zoom speed switch

Shooting

to any of the settings.

Press the zoom lever at the handle to zoom.

The zoom operation is performed in the speed that has been set.

Using Zoom Ring at the Lens Section

You can adjust the preferred angle of view by turning the zoom ring.

Saving/Recalling Current Zoom Position (Preset Zoom)

This allows you to register up to three zoom positions.

Assign the “Preset Zoom1”, “Preset Zoom2”, of the user buttons.

(A P Buttons] ) (A P98 [USER1 ~ USER9, LCD KEY▲/LCD KEY▶/LCD KEY▼/LCD KEY◀] )

Save the current zoom position.

Recall the stored zoom position.

Memo :

The zoom speed to the zoom position can be set in [Main Menu] B [Camera Function] B [User

Switch Set] B [Preset Zoom Speed].

(A P

Operating other zoom maneuvers during a zoom position recall will cancel the recall.

or “Preset Zoom3” function to any

39 [Assignment of Functions to User

Press any of the user buttons assigned with the “Preset Zoom1

“Preset Zoom3” function for more than 1 second.

The current zoom position will be stored.

Press any of the user buttons assigned with the “Preset Zoom1

“Preset Zoom3” function and release within 1 second.

The camera recorder zooms to the stored zoom position.

99 [ Preset Zoom Speed ] )

”, “Preset Zoom2”, or

Focus Operation

Adjusting Focus Automatically

Press the [ Auto Focus mode.

There is no icon display in Auto Focus mode.

Memo :

[Main Menu] B [Camera Function] B [AF Assist] is set to “Area” or “Far/Near”, you can turn the focus ring to shift the auto focus point while

in the automatic focus adjustment mode.

(A P

When face detection is enabled, the Auto Focus icon e appears with the face mark.

(A P53 [Adjusting the Focusing by Face Detection] ) (A P98 [ Face Detect ] )

One Push Auto Focus

If [Push pressing the assigned user button (within 1 minute)

while in the Manual Focus mode makes the camera recorder focus on the center of the frame automatically.

Memo :

Face detection does not work during One Push Auto Focus.

AF Assist does not function.

When the operation is complete, the camera recorder returns to the Manual Focus mode automatically.

One Push Auto Focus functions with emphasis on the focusing speed. This function is not suitable during recording.

AF/MF] selection button to set to

97 [ AF Assist ] )

AF/AF Lock] is assigned to the user button,

Zoom Operation

Setting to Auto Focus Temporarily

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2014

00: 00:00.00

5 . 6 f t

4030 20 10 0

P 15000K

1/100

F1. 6

00:00 :00.00

4030 20 10 0

P 15000K

(Push Auto Focus)

If [Push AF/AF Lock

] is assigned to the user

button, the camera recorder will shift to Auto Focus mode temporarily and automatically adjusts focus when the assigned user button is held down during shooting in Manual Focus mode.

Release

the user button assigned with [Push AF/

AF Lock] to return to Manual Focus mode.

Memo :

Face

detection does not work during Push Auto

Focus.

Locking the Focus

When the [Push AF/AF Lock] function is assigned to a user button in the Auto Focus mode, pressing

this button locks the focus on the corresponding point. An icon appears when the focus is locked.

Memo :

Performing any focusing operation when the focus is locked disengages the focus lock.

Adjusting Focus Manually

Press the [ Manual Focus mode.

The manual focus icon d screen.

Memo :

The d icon [LCD/VF] B [Display Settings] B [Focus] is set to “Off”.

P107 [ Focus ] )

Turn the focus ring to adjust the focus.

AF/MF] selection button to set to

appears on the

appears even when [Main Menu] B

Memo :

Using the Focus Assist or Expanded Focus function makes it easier to focus.

[Focus Assist Function] )

(A P52 (A P52 [Expanded Focus Function] )

If [Push AF/AF Lock] is assigned to the user button, pressing the assigned user button while

in the Manual Focus mode activates the Onepush Auto Focus mode, and holding down the button activates the Push Auto Focus mode.

P50 [One Push Auto Focus] ) (A P51 [Setting to Auto Focus Temporarily (Push Auto Focus)] )

AF Assist Function

To shift the auto focus point during Auto Focus (AF), you can turn the focus ring to set the point to the left, center, right, or near and far directions.

Set [Main Menu] B [Camera Function] B [AF Assist].

Far/Near: This option allows you to shift the auto focus point

to near and far directions by turning the focus ring during AF. Focus is automatically adjusted to a focus point near the position where the focus ring stops turning.

Area: Selecting this option displays the icon in

the area. Turning the focus ring during AF displays the focus area on the left, center, and right side for about 2 seconds. Turning the focus ring within 2 seconds allows you to move the orange frame to select the focus area. After selecting the area, focus is automatically adjusted to a focus point near the selected area.

* The icons ( , , and ) change in

conjunction with the orange frame in the focus area.

Memo :

When [Face Detect] is set, the AF Assist function is not selectable.

Shooting

Focus Operation

Focus Assist Function

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 :56

Jan 24,2015

00:00 :00.00

5 . 6 f t

EXPANDED

P 1500 0K

EXPANDED

the [F.ASSIST/1] button is pressed during

When shooting, the focused area is displayed in color.

This enables easy and accurate focusing.

Select

the color (blue, red or green) in the menu.

Memo :

When [Main Menu] B [LCD/VF

] B [Shooting Assist] B [Focus Assist] B [Type] is set to “ACCU-Focus”, the depth of field becomes shallower to enable easier focusing.

Shooting

(A P105

[ Focus Assist ] ) The “ACCU-Focus” function switches automatically to “Off” after about 10 seconds. Select

the display color in [Main Menu] B [LCD/ VF] B [Shooting Assist] B [Focus Assist] B [Color].

(A P

105 [ Color ] )

If you use the zebra function and the Focus Assist function at the same time, it may be difficult to see the effect of the Focus Assist. In this case, turn off the zebra function.

Setting Focus Assist Function to a User Button

You can assign the “Focus

Assist” function to a user

button.

(A P39 [Assignment of Functions to User Buttons] )

Expanded Focus Function

You can magnify the preferred area by pressing the [

EXPANDED FOCUS/8] button; doing so enables

precise focus to be established easily. * You can also use the user button assigned with

the “Expanded Focus” function instead of the [EXPANDED FOCUS/8] button.

(A P39 [Assignment of Functions to User Buttons] ) (A P98 [USER1 ~ USER9, LCD KEY▲/LCD KEY▶/LCD KEY▼/LCD KEY◀] )

Press the [EXPANDED FOCUS/8] button.

“EXPANDED” (yellow color) appears on the screen, and the center part of the image is

enlarged if this button is pressed for the first time.

For subsequent operation of the button, the area at which the operation was last performed will be enlarged.

Use the cross-shaped button (JKH I) to magnify the preferred area.

The portion that is being magnified is displayed at the lower left corner of the screen.

Press the [CANCEL/STOP

] button to cancel

the setting.

Memo :

The display of the enlarged screen is dot by dot equivalent.

To set the operation when the button is pressed, go to [Main Menu] B [Camera Function] B [User

Switch Set] B [Expanded Focus].

(A P

99 [ Expanded Focus ] )

Pressing and holding the Center Set button (R) resets the position of magnification.

This function can be used together with the Focus Assist function.

[Main Menu] B [Camera Function] B [AF

When Assist] is set to “Area”, the center of each area (left/center/right) is enlarged.

(A P97

[ AF Assist ] )

magnification ratio varies with the format of

The the record signals.

Magnifying an image does not alter the size of the recorded image.

If the “Expanded Focus” function is assigned to the cross-shaped button, the cross-shaped

button cannot be used as user button while the area is being magnified.

This function is unavailable when

[Main Menu]

B [System] B [Record Set] B [Record Format] B [System] is set to “SD”.

Focus Operation

Adjusting the Focusing by

Detection Frame (Orange)

AE 

Face Detection

This function detects human faces and automatically adjusts focus during Auto Focus. It can also track moving objects. When several faces are detected, you can select one to focus on.

Memo :

This function can also adjust the brightness automatically face detected.

(A P98 [ Face Detect ] )

according to the brightness of the

Assign the “Face the user buttons.

(A P

39 [Assignment of Functions to User

Buttons] )

Focus the camera recorder on a person and

the user button that is assigned with

press “Face Detect”.

When Face detection is enabled, the face detection icon (q) appears.

When [Main Menu] B [Camera Function B [User Switch Set] B [Face Detect] is set

to “AF”, “q e” appears.

When [ B [User Switch Set] B [Face Detect] is set to “AF&AE”, “q AE±0” appears.

you select the person nearest to the center of the screen, an orange frame will appear on his face.

Focus will be automatically adjusted for the selected person.

Detect” function to any of

Main Menu] B [Camera Function]

]

Shooting

Memo :

If the detection frame does not appear, make sure that Auto Focus mode is selected. Also, if [Face Detect

of the iris, gain, and electronic shutter control

items to the automatic adjustment mode. (A P Automatically: Automatic Brightness Adjustment (AE) Mode] ) (A P55 [Auto Iris (Automatic Adjustment) Mode] ) (A P57 [Automatic Gain Mode (Automatic Gain Adjustment)] ) (A P58 [Automatic Shutter Mode (Automatic Shutter Adjustment)] )

Adjusting the Focusing by Face Detection

] is set to “AF&AE”, set at least one

54 [Adjusting the Brightness

Selecting Specific Person from Several

Detection Frame (Blue)

Detection Frame (Orange)

Blinking

Detection Frame (Blue)

Detection Frame (Orange)

AE+6

ND 1/ 16

12 :34 : 56

Jan 24 ,2015

00: 00:00.00

4030 20 10 0

P 150 00 K

Persons

Hold down the user button that is assigned

“Face Detect”.

with

The

camera recorder will enter face selection

mode and the face detection icon (q) will blink.

An orange frame will appear on the face of the person nearest to the center of the screen. Blue frames will appear on the faces of others.

Shooting

Adjusting the Brightness

Adjust the brightness using Iris, Gain, Shutter speed and ND filter according to the brightness of the object.

Adjusting Automatic Brightness Adjustment (AE) Mode

Iris, Gain, Shutter speed and ND filter are automatically of the object to maintain optimum brightness.

the Brightness Automatically:

adjusted according to the brightness

Select a specific person.

Use the cross-shaped button (HIJK) to select a person.

An orange frame will appear on the face of the selected person and focus will be automatically adjusted.

Press the Set button (R) to confirm the person for face detection.

Memo :

Press the [CANCEL] button to cancel the selection.

You

can specify the detection sensitivity and the operation speed after losing sight of the face using [Main Menu] B [Camera Function] B

[User Switch Set] B [Face Detect] B [Sensitivity] and [Hysteresis].

(A P98

[ Sensitivity ] )

(A P98 [ Hysteresis ] )

Adjusting the Focusing by Face Detection

To set only the Gain, Iris and Shutter to Auto mode, press

and hold the [FULL AUTO] button and set the Full Auto mode to off before setting each item to the automatic adjustment mode.

Set Gain, Iris and Shutter to Auto mode.

[Adjusting the Iris] (A P

[Setting the Gain] (A P 57)

[Setting the Electronic Shutter] (A P 58)

Set the target level (brighter/darker) to

55)

maintain optimum brightness during automatic adjustment.

AE±*” (* denotes number) appears on

When “ the screen, press the [AE LEVEL] button on the side of the camera recorder to display “AE ±*” against a white background and set using the J / K volume buttons.

Memo :

Iris Dial

Pressing and holding the to enter the Full Auto mode also activates the

automatic brightness adjustment (AE) mode. In this case, the White Balance also enters into Auto mode forcibly.

Pressing and holding the [AE LEVEL] button clears the value specified and fixes at (recommended value).

The convergence speed of the automatic adjustment (AE) can be set in the menu.

(A P96 [ AE Speed ] )

If one or more of the items (Gain, Iris and Shutter) have been set to Auto mode, the value of the corresponding items when the user button that is assigned “AE Lock” is pressed can be

fixed.

(A P

If one or more of the items (Gain, Iris and Shutter) have been set to Auto mode, the automatic brightness adjustment (AE) mode is enabled.

for automatic brightness adjustment

99 [ AE/FAW Lock ] )

[FULL AUTO] button

“AE±0”

Adjusting the Brightness Manually

Press and hold the [FULL AUTO] button to set to Full Auto mode, some or all of the items (Iris, Gain

and Shutter Speed) can be manually adjusted.

Press and hold the [FULL AUTO] button to set Full Auto mode to off.

Adjust the Iris, Gain and Shutter speed.

55 [Adjusting the Iris] )

(A P (A P57 [Setting the Gain] ) (A P58 [Setting the Electronic Shutter] )

Memo :

The brightness cannot be manually adjusted in the Full Auto mode.

If Iris, Gain and Shutter Speed are manually adjusted, the [AE Level

disabled.

] setting is temporarily

Adjusting the Iris

the aperture of the lens iris according to the

Adjust brightness of the subject.

Auto Iris (Automatic Adjustment) Mode

Press and hold the [FULL AUTO] button to set Full Auto mode to off.

Press the [IRIS A/M] button to set to the Auto Iris mode.

The iris is automatically adjusted according to the brightness of the object. The lens aperture value (F-number) is not displayed in the Auto Iris mode.

Memo :

Pressing and holding the [FULL AUTO] button to enter the Full Auto mode also activates the

Auto Iris mode. In this case, the Gain, Shutter and White Balance also enter into Auto mode forcibly.

switching operation of the [IRIS A/M] button

The is disabled in the Full Auto mode.

The iris open/close limit can be set in Menu] B [Camera Function] B [Auto Iris Limit (OPEN)]/[Auto Iris Limit (CLOSE)] during Auto Iris.

(A P96

[ Auto Iris Limit (OPEN) ] )

(A P96 [ Auto Iris Limit (CLOSE) ] )

To set the target level (brighter/darker) of the auto iris, you can press and hold the [AE

LEVEL] button on the side of the camera recorder and then change the level using the J / K volume button.

The convergence speed of the auto iris can be set in the menu.

(A P96

[ AE Speed ] )

[Main

Shooting

Adjusting the Brightness

Manual Iris (Manual Adjustment) Mode

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24 ,2015

00: 00:00.00

5 . 6 f t

4030 20 10 0

P 150 00 K

The aperture value (F-number) of the lens can be set manually.

Press and hold the [FULL AUTO] button to set Full Auto mode to off.

Press the [IRIS A/M] button to set to the Manual Iris mode.

The lens aperture value (F-number) is displayed.

One Push Auto Iris

When [One Push Iris] is assigned to the user

press this button in the Manual Iris mode to

button, adjust the iris according to the brightness of the subject.

Push Auto Iris

When [One Push Iris] is assigned to the user button, press and hold down this button in the

Manual Iris mode to change to the Auto Iris mode temporarily. The iris will be automatically adjusted according to the brightness of the subject.

Shooting

Turn the iris dial to adjust the iris manually.

Iris adjustment can be assigned to the zoom ring.

[Main Menu] B [Camera Function] B

Set [Zoom Ring] to “Iris”.

(A P

97 [ Zoom Ring ] )

The open F-number of the aperture varies according to the zoom position. Wide [W] end Tele [T] end : F3.5

F-number Description

Decrease The subject appears brighter.

Increase The subject appears darker.

Memo :

[One Push Iris] is assigned to the user button,

pressing the assigned user button while in the Manual Iris mode activates the One-push Auto Iris mode, and holding down the button activates the Push Auto Iris mode.

In addition to the [Iris] also be assigned with the [Shutter] or [AE Level] function.

(A P

97 [ Iris Dial ] )

: F1.2

The focused range becomes sharper, while the background is blurred to produce a soft image.

Background of image becomes focused as well.

function, the iris dial can

About the Iris F-number

Blurry effects due to “small aperture diffraction” may occur when the diameter of the iris becomes too small. When this phenomenon occurs, the Fnumber on the screen turns gray to warn you that the diffraction F-number of the iris has been exceeded. You

are recommended to make appropriate use of ND filters to prevent the F-number from turning gray.

Adjusting the Iris

Setting the Gain

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24 ,2015

00: 00:00.00

5 . 6 f t

4030 20 10 0

P 150 00 K

function electrically boosts the light sensitivity

This when there is insufficient illumination on the object. You can set the gain of the video amplifier according to the brightness of the object. Select the setting mode according to your shooting conditions.

Automatic Gain Mode (Automatic Gain Adjustment)

Press and hold the [FULL AUTO] button to set Full Auto mode to off.

Set [Camera Function] B [GAIN L]/[ M]/[GAIN H] to “AGC”.

(A P

97 [GAIN L/GAIN M/GAIN H] ) If an item specified with “AGC” is selected using the [GAIN L/M/H] gain switch, the Auto Gain Adjustment mode is enabled and the gain of the video amplifier is automatically set according to the brightness of the subject. The sensitivity value (dB value) is not displayed in the Auto Gain mode.

Memo :

Pressing and holding the [FULL AUTO] button to enter the Full Auto mode also activates the

Auto Gain mode. In this case, the Iris, Shutter and White Balance also enter into Auto mode forcibly.

The switching operation of the [GAIN L/M/H] switch is disabled in the Full Auto mode.

The upper limit of the gain setting value during AGC operation can be set in

[Main Menu] B

[Camera Function] B [AGC Limit].

(A P

96 [ AGC Limit ] )

GAIN

Manual Gain Mode (Manual Gain Switching)

Press and hold the [FULL AUTO] button to set Full Auto mode to off.

Select the gain level of the video amplifier using the [GAIN L/M/H]

the camera recorder.

The gain level appears on the screen.

The default positions of the switch are as follows.

[L] : 0dB [M]

: 6dB

[H] : 12dB

Select [GAIN

L/M/H] that is not set to “AGC”

to switch to the Manual Gain mode.

Memo :

can change the gain value of each position

You in the menu. Increasing the sensitivity causes the screen to appear grainier.

The camera recorder switches to the Auto Gain mode when the gain value is set to “AGC”.

(A P97

[GAIN L/GAIN M/GAIN H] )

selection switch on

Shooting

Setting the Gain

Setting the Electronic

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24 ,2015

00: 00:00.00

5 . 6 f t

4030 20 10 0

P 150 00 K

Shutter

You can change the shutter speed (time for each shooting frame) using the electronic shutter function. Electronic shutter can be adjusted manually or automatically.

Automatic Shutter Mode (Automatic Shutter Adjustment)

Shooting

Press and hold the [FULL AUTO] button to set Full Auto mode to off.

Press and hold the [SHUTTER] button to enter Automatic Shutter mode.

The shutter speed will not be displayed.

Automatic Shutter mode adjusts the shutter speed automatically according to the brightness of the object.

Set the controllable range for the Automatic Shutter in [Main Menu] B [

Function] B [EEI Limit].

(A P

96 [ EEI Limit ] )

Memo :

Pressing and holding the [FULL AUTO] button to enter the Full Auto mode also activates the

Automatic Shutter mode. In this case, the Iris, Gain and White Balance also enter into Auto mode forcibly.

Switching

of shutter speed with the J / K volume buttons at the side of the camera recorder, and switching of shutter mode with the [SHUTTER] button are disabled in the Full Auto mode.

Camera

Manual Shutter Mode (Manual Shutter Switching)

Press and hold the [FULL AUTO] button to set Full Auto mode to off.

Press and hold the [SHUTTER] button to enter Manual Shutter mode.

The shutter speed appears on the screen.

Memo :

While in Manual Shutter mode, select “Variable” in [Camera Function] B [Shutter]. “Step” is the factory default.

(A P

96 [ Shutter ] )

Switching Shutter Speed

When the [SHUTTER] button is pressed (for less than 1 second) in the Manual Shutter mode to

display the shutter speed against a white background, you can set the shutter speed using the J / K

volume buttons on the side of the camera recorder. The settable shutter speed range differs according to the video format setting.

Memo :

display Shutter in angle (DEG), set [WFrame

To Rate] to “24p” or “25p”, and set [Shutter] in [LCD/

VF] B [Display Settings] to “DEG”.

P115 [ W Frame Rate ] )

(A P108 [ Shutter ] )

“Step” or

Setting the Electronic Shutter

60p 60i 30p

50p 50i 25p

24p

1/10000

1/4000

1/2000

1/1000

1/500

1/250

1/120

1/100

1/50

1/48

1/24

1/12

1/6

1/25

1/12.5

1/6.25

1/60

1/30

1/15

1/7.5

1/48.001/50.001/60.00

1/30.00 1/25.00 1/24.00

1/9934 1/98631/10014

1/60

1/10000

1/250

1/1000

1/2000

1/4000

1/500

1/100

1/10000

1/250

1/120

1/1000

1/2000

1/4000

(Lower limit)

(Upper limit)

(Standard)

Variable

Step

Shutter Mode

Frame Rate

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00: 00:00.00

5 . 6 f t

4030 20 10 0

P 150 00 K

ND 1 / 1 6

Setting the ND Filter

Use the ND filter to keep the lens aperture in the appropriate range.

Switch according to the brightness of the object. When the position on the switch is changed, the selected LCD monitor and viewfinder screen.

Memo :

position of the ND filter is displayed on the

(A P127 [Display 2 screen] )

When [Main Menu] B [LCD/VF] B [Display Settings] B [ND

Filter] is set to “Off”, the position

of the ND filter will not be displayed.

(A P

107 [ ND Filter ] )

It is recommended to use the ND filter to set the lens aperture to less than F8.

Setting the Electronic Shutter

Shooting

ND Filter Warning Display

In order to adjust the amount of light when you are shooting of the iris may become extremely small, causing blurry effects to occur as a result. This phenomenon is known as “small aperture diffraction”. You can make appropriate use of ND filters to prevent it from occurring. This unit displays an ND filter warning when necessary to prompt you to select an appropriate ND filter.

Shooting

at a relatively bright location, the diameter

Set [Main Menu] B [LCD/VF] B [Display Settings

When the iris diameter becomes too small while adjusting the light intensity, or when an ND filter is used in a dimly-lit location, the ND filter display starts blinking.

] B [ND Filter] to “On+Assist”.

P107 [ ND Filter ] )

Adjusting the White Balance

Adjust the white balance according to the color temperature of the lighting. You can select the adjustment mode according to the shooting conditions. As the color of the light (color temperature) varies according to the light source, it is necessary to readjust the white balance when the main light source illuminating the subject changes.

Automatic White Balance Mode (FAW: Fulltime Auto White balance)

Press and hold the [FULL AUTO] button to set Full Auto mode to off.

Assign “FAW” (Full one of the three [WHT.BAL B/A/PRST] switches.

You can set the Full Auto White Balance feature to either “A”, “B”, or “PRST”

[Camera Function] B [FAW].

(A P97 [ FAW ] )

If the position assigned with “FAW” is selected using the [WHT BAL B/A/PRST switch, the Automatic White Balance mode is

enabled and an appropriate white balance is automatically adjusted according to the color temperature of the lighting on the subject.

Caution :

The accuracy of White Balance.

When the power of the camera recorder is turned

on with the [FAW] mode selected, it takes

about 15 seconds for the colors to stabilize.

Auto White Balance) to

]

[FAW] is inferior to that of Auto

Setting the ND Filter

Memo :

FAW Paint

White Balance

B Value

R Value

FAW Paint

White Balance

Pressing and holding the

[FULL AUTO] button

to enter the Full Auto mode also activates the Automatic Shutter mode. In this case, the Iris, Gain and Shutter also enter into Auto mode forcibly.

Switching of the white balance with the [WHT.BAL B/A/PRST

] switch is disabled in the

Full Auto mode.

When [

Main Menu] B [Camera Function] B [User Switch Set] B [AE/FAW Lock] is set to “AE/ FAW”, the white balance when the user button that is assigned [AE/FAW Lock] is pressed can be fixed.

(A P99

[ AE/FAW Lock ] ) If [White Balance] is assigned to the user button, pressing the assigned user button will display the FAW Paint Adjustment screen.

(A P39 [Assignment of Functions to User Buttons] )

FAW Paint Adjustment

You can fine-adjust the white balance that was automatically adjusted.

Select [Main Menu] B [Camera Process [White Balance] B [FAW Paint] and press the Set button (R).

The FAW Paint Adjustment screen appears.

] B

Press the Set button (R).

Returns to the [White Balance] screen.

Manual White Balance Mode (Manual Switching)

Press and hold the [FULL AUTO] button to set Full Auto mode to off.

Use the [WHT.BAL B/A/PRST select “PRST” (preset mode), “A” (memory A mode), or “B” (memory B mode).

Memo :

You can set the Full Auto White Balance feature to either [A], [B], or [PRST] in [Camera

Function] B [FAW].

(A P

97 [ FAW ] )

In the FAW (Full Auto White Balance) mode, the color temperature of the video is sampled constantly and automatically to obtain the most appropriate white balance level.

] switch to

Shooting

Adjust the R and B values.

Use the cross-shaped button (JK) to adjust R value and (HI) to adjust B value.

Preset Mode (PRST)

Two different color temperature settings are registered on this camera recorder. You can

between them using the [AWB/9] button.

switch

* You can also use the user button assigned with

[AWB] instead of the [AWB/9] button.

(A P98 [User Switch Set Item] )

Default setting: [Preset Temp.] : 3200K

[Alternative Temp.] : 5600K

Set the [WHT.BAL B/A/PRST] switch to

”.

“PRST

Press the [AWB/9] button.

Press the [AWB/9] button to switch to a different color temperature.

(“Preset Temp.

”1“Alternative Temp.”)

Adjusting the White Balance

Setting the [Preset Temp.] or [Alternative

Color Temperature

Detailed Selection

Screen

Color Temperature Selection Screen

Values

Temp.]

You can change both the color temperature settings in the Preset mode in the menu.

Open the [Preset Temp.] or [Alternative

menu.

Temp.]

Select [Main Menu] B [Camera Process] [White Balance] B [Preset Temp.] and [Alternative Temp.], and press the Set button (

The Color Temperature setting screen appears.

Shooting

Select the color temperature.

When selecting from a setting value (Color Temperature Selection screen), use the cross-shaped temperature. [Setting Values: 7500K, 6500K, 5600K, 5200K, 4800K, 4200K, 3200K, 3000K, 2800K]

To select detailed values (Color Temperature Detailed Selection screen)

Press the cross-shaped button (I) to display the Color Temperature Detailed Selection screen.

Use the cross-shaped button (JK) to select a color temperature. [Setting Values: 2300K to 15000K (in 100K increments)]

Memo :

Use the cross-shaped button (I) to switch between the Color Temperature Selection screen and the Color Temperature Detailed Selection screen.

If [White Balance] is assigned to the user button, pressing the assigned user button will display

the Color Temperature Selection screen.

(A P39

[Assignment of Functions to User

Buttons] )

button (JK) to select the color

Memory A Mode (A), Memory B Mode (B)

Set to the white balance saved in Memory A or Memory B.

the [WHT.BAL B/A/PRST] switch is set to

When “A” or “B”, press the [AWB/9] button to execute

white balance. The white balance will be automatically adjusted and the adjusted value will be saved in Memory A or Memory B.

* You can also use the user button assigned with

[AWB] instead of the [AWB/9] button.

(A P

98 [User Switch Set Item] )

Prepare the camera recorder.

Set the [POWER ON/OFF] switch to “ON”.

Press the [IRIS] button to set to the Auto mode.

Press and hold the [FULL AUTO] button to set to “OFF”.

Set the [ND FILTER] switch according to the lighting.

(A P59 [Setting the ND Filter] )

Set the [WHT.BAL B/A/PRST] switch to “A” or “B”.

Locate a place with similar lighting conditions as the object to be shot, place a white object near the center of the screen and zoom in to fill the screen with white.

Press the [AWB/9] button.

The white detection frame appears when Auto White Balance is activated. Fill the frame with white completely.

While Auto White is starting up, “A<

>” appears on the screen. (y mark

“B< appears blinking)

After the correct white balance is obtained, an estimated value of the current color temperature is displayed.

>” or

Adjusting the White Balance

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 :56

Jan 24,2015

00:00 :00.00

4030 20 10 0

5 . 6 f t

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 :56

Jan 24 ,2015

00:00 :00.00

4030 20 10 0

5 . 6 f t

P 15000K

100min

50min

282min

A

3840x2160 30p 150M

100min

50min

282min

3840x2160 30p 150M

Result Display

[AWB] Activating

White Detection Frame

Blinking

AWB Paint

White Balance

B Value

R Value

AWB Paint

White Balance

Caution :

Do not use highly reflective objects, such as metals. Doing so may result in improper white balance adjustment.

The Auto White function cannot provide optimum white balance with an object outside the adjustment range, for example when it contains only a single color or not enough white color.

Error Message

If the white balance adjustment is not correctly completed, one of the following messages will appear for about 3 seconds.

Message Status

Auto White　* NG: Object (*A or B)

Displayed when there is not enough white color on the object, or when the color temperature is not suitable.

another white object and

Use adjust the white balance again.

Auto White * Error: Low Light (*A or B)

Auto White * Error: Over Light (*A or B)

White Paint Adjustment

You can fine-tune the white balance saved in Memory A or Memory B.

Displayed when the lighting is dark. Increase the lighting and adjust the white balance again.

Excessive illumination. Displayed too bright. Decrease the lighting and adjust the white balance again.

when the lighting is

Select [Main Menu] B [

Camera Process] B [White Balance] B [AWB Paint] and press the Set button (R).

The White Paint Adjustment screen appears.

Adjust the R and B values.

Use the cross-shaped button (JK) to adjust R value and (HI) to adjust B value.

Press the Set button (R).

Returns to the [White Balance] screen.

Memo :

Executing

Auto White Balance will usually clear the White Paint Adjustment value. But when [Main Menu] B [Camera Process] B [White

Balance] B [Clear Paint After AWB] is set to “Off”, values will not be cleared even when Auto White Balance is executed.

(A P103

[ Clear Paint After AWB ] ) If [White Balance] is assigned to the user button, pressing the assigned user button will display the AWB Paint Adjustment screen.

P39 [Assignment of Functions to User

Buttons] )

Adjusting the White Balance

Shooting

Adjusting the Camera

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 :56

Jan 24,2015

00:00:00.00

4030 20 10 0

5 . 6 f t

P 1500 0K


The picture quality of the camera can be set using the [Camera Process

As the adjustments are shown on the screen, you can adjust the values while checking the picture quality on the camera.

Detail]

[

[Master Black]

[Black Toe

[Knee]

Shooting

[White Clip

[Gamma

[WDR]

[White Balance

[Color Matrix

[Color Gain

]

Memo :

For details of the respective items, see the [Camera Process

(A P100

[Camera Process Menu] )

] menu.

]

] menu.

Using the Image Stabilizer

Reduces blurring of images due to camera shake.

Check whether the image stabilizer feature is turned ON or OFF.

If the image stabilizer icon (i/j) does not appear on the screen display, the image stabilizer function is OFF.

Press the [OIS/6] button to turn ON the image stabilizer feature (when image

stabilizer feature is OFF).

The image stabilizer feature switches between ON and OFF with every press of the [OIS/6

button.

OFF: Use

this setting when the camera recorder is

secured, such as when using a tripod.

ON: Reduces blurring of images due to camera shake.

Memo :

Select [Main Menu] B [Camera Function] B [OIS

] B [Level] to set the correction level.

(A P96

[ Level ] ) Correction by this feature may not be sufficient when camera shake is too strong.

“OIS” is assigned to the [OIS/6] button in factory default.

“OIS” can also be assigned to other user buttons.

P39 [Assignment of Functions to User

Buttons] )

]

Adjusting the Camera Image

Audio Recording

can record audio from the two channels (CH1/

You CH2) in synchronization with video images on this camera recorder. Select from the four options below to record the audio.

Built-in Microphone

Microphone connected to

Selecting Audio to Be Recorded in Each Channel O

Select the audio to be recorded in CH1/CH2.

- Switch Setting Connected Devices

CH1 INT

INPUT1 Microphone connected to

CH2 INT

INPUT1 Microphone connected to

INPUT2 Microphone connected to

When CH1 or CH2 is set to microphone is connected to the [AUX] terminal, audio is recorded according to the setting in

[Main Menu] B [A/V Set] B [Audio Set] B [CH1 INT]/[CH2 INT].

P110 [ CH1 INT ] )

(A P110 [ CH2 INT ] )

[AUX] terminal [INPUT1] terminal

[INPUT2] terminal

Built-in Microphone

Microphone connected to [AUX] terminal

[INPUT1

] terminal

Built-in Microphone

Microphone connected to [AUX] terminal

[INPUT1

] terminal

[INPUT2] terminal

“INT” and a

Memo :

When the [AUX [Main Menu] B [A/V Set] B [Audio Set] B [CH1 INT]/[CH2 INT] is fixed at “Int. Mic L”/“Int. Mic R” respectively.

Setting Input Channel to [INPUT1]/[INPUT2]

Select the audio to input to [INPUT1] and [INPUT2] terminals with the [INPUT1]/[INPUT2] mode switch.

Setting Description

[LINE] Use this setting when connecting to

[MIC] Use this setting when connecting to

[MIC+48V] Use this setting when connecting to

Memo :

When “MIC” or “MIC+48V” is selected, set the reference input level in [Main Menu Set] B [Audio Set] B [Input1 Mic Ref.]/[Input2 Mic Ref.].

(A P110

Caution :

When

connecting a device that does not require a +48 V power supply, make sure that it is not set to the “MIC+48V” position.

When the [INPUT1]/[INPUT2] mode switch is set to “MIC”, make sure that a microphone is connected you increase the recording level when a

microphone is not connected, noise from the input terminal may be recorded.

When a microphone is not connected to the [INPUT1]/[INPUT2

[INPUT2] mode switch to “LINE” or adjust the volume with the [CH1]/[CH2] recording level adjustment knob.

] terminal is not connected,

audio device or other equipment.

an The reference input level is +4 dBu.

a dynamic microphone.

a microphone (phantom microphone) that requires a +48 V power supply.

] B [A/V

[Input1 Mic Ref./Input2 Mic Ref. O] )

to the [INPUT1]/[INPUT2] terminal. If

] terminal, set the [INPUT1]/

Shooting

Audio Recording

Adjusting the Audio Recording Level

1/100

F1. 6

AE+6

ND 1 /1 6

12: 34 :56

Jan 24 ,2015

00:00 :00.00

4030 20 10 0

5 . 6 f t

P 1500 0K

4030 20 10 0

-2dB

You can select to adjust the audio recording levels for the two channels (CH1/CH2) manually or automatically.

Shooting

Manual Adjustment Mode (Manual Adjustment)

Set the [CH1/CH2 AUTO/MANUAL] switch on the camera recorder to manual adjustment mode, and use the [CH1]/ [CH2] recording level adjustment knob to set the recording level.

You can adjust the level manually during the recording, recording standby, and stop modes.

Memo :

the [FULL AUTO] button is set to “ON” and

When [Main Menu] B [A/V Set] B [Audio Set] B [Audio On FULL AUTO] is set to “Auto”, the [CH1 AUTO/MANUAL]/[CH2 AUTO/MANUAL] selection switch is disabled.

(The above setting is the factory default.)

“MANUAL” to enter the

When the input channel is set to “

INT” for

both [CH1] and [CH2]

Set the [CH1 AUTO/MANUAL] selection switch to

Turn the [CH1] recording level adjustment

“MANUAL”.

knob to adjust the level.

When the built-in microphone and the [AUX] input terminal are used, the recording levels of

[CH1] and [CH2] are interlocked. This is also effective when the

[CH1 AUTO/

MANUAL] selection switch is set to [CH2].

Memo :

Select [Limiter Mode] or [Int. Mic Stereo Enhancer] in the menu to set the recording audio.

For the reference level to be recorded to an SD card, set

[Main Menu] B [A/V Set] B [Audio Set] B [Ref. Level] to “-20dB”, “-18dB”, or “-12dB”. (common for CH1/CH2)

(A P110

[ Ref. Level ] ) The operations of the [CH2] recording level adjustment knob and [CH2 AUTO/MANUAL] selection switch are disabled.

When

[Main Menu] B [A/V Set] B [Audio Set] B [CH1 INT] and [CH2 INT] are set to “Int. Mic L” and “AUX R” respectively, or set to “AUX L” and “Int. Mic R” respectively, the settings of the [CH1 AUTO/MANUAL] and [CH2 AUTO/MANUAL] selection switches become independent. In this

case, the recording level settings of CH1 and CH2 are also independent.

Setting Input Channel to

“INPUT1”/

“INPUT2”

Set the [CH1/CH2 AUTO/MANUAL] selection switch to

“MANUAL” for the

channel to be adjusted manually.

Turn the corresponding [CH1]/[CH2] recording level adjustment knob to adjust

the level.

Adjust such that the audio level meter does not light up at -2 dB even for loud sounds. (A

P111 [ Limiter Mode ] )

Audio Recording

Automatic Adjustment Mode

Set the [CH1/CH2 AUTO/MANUAL] selection switch to “AUTO” or press and hold the [FULL AUTO] button set to “ON” to enter Automatic Adjustment mode. The audio recording level is

set automatically according to the input level.

When the [FULL AUTO] button is set to “ON”, mode switching with the [CH1/CH2 AUTO/ MANUAL] selection switch is disabled.

Memo :

Audio Level

Manual

Auto

Set

[Main Menu] B [A/V Set] B [Audio Set] B

When [Limiter] is set to “Off” while in the automatic adjustment mode, the limiter operates at

-6 dBFS.

When [A/V AUTO] is set to “SW Set”, you can switch the audio recording mode with the [CH1/CH2 AUTO/MANUAL] selection switch on the camera recorder even if the [FULL AUTO] button is set to “ON”.

(A P

Set] B [Audio Set] B [Audio On FULL

112 [ Audio On FULL AUTO ] )

Setting the Audio recording Level in the Main Menu

* Enabled only when the handle unit is not

attached.

Select [Main Menu] B [A/V Set] B [Audio

] B [Audio Level].

Set

The

[Audio Level] screen appears.

* The contents displayed on the screen vary

depending on the various settings.

Select “Auto” or “Manual” using the [LOLUX/3]

If “Auto” will be automatically adjusted.

If “Manual on the screen. Use the cross-shaped button

(H I) to adjust the volume.

Memo :

When [Audio On FULL AUTO] in the menu is set to “Auto”, the audio recording level cannot be selected.

If both CH1 and CH2 are set to the built-in microphone or to AUX, settings for CH2 will not be

displayed, and the settings for CH1 will apply

to CH2.

button.

is selected, the audio recording level

” is selected, the volume appears

the [FULL AUTO] button is set to “On” and

Monitoring Audio Sound During Recording Using a Headphone

You can check the recorded audio using headphone.

Connect the headphone.

Select [Main Menu] B [ Set] B [Monitor].

Adjust the monitor volume using the J / K volume buttons on the side of the camera recorder.

Memo :

There is no audio output from the monitor speaker in Camera mode.

Warning tone is output when there is an abnormality battery is low.

(A P174 [Warning Tone] )

You can set the volume of the warning tone in [Main Menu] B [A/V Set] B [Audio Set] B [Alarm

Level]. (“Off”/“Low”/“High”)

(A P

in the camera recorder or when the

112 [ Alarm Level ] )

A/V Set] B [Audio

Shooting

Audio Recording

Time Code and User’s Bit

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 :56

Jan 24 ,2015

00:00 :00.00

4030 20100

5 . 6 f t

P 1500 0K

00:00:00.00

FF EE DD 20

code and user’s bit data are recorded with the

Time video in this camera recorder. The time code and user’s bit are displayed on the viewfinder and LCD monitor during playback or recording. (Display screen)

Displaying Time Code and User’s Bit

The time code and user’s bit are displayed on the viewfinder and LCD monitor during playback or recording. The

Shooting

display differs according to the menu settings.

Set [Main Menu] B [LCD/VF] B [Display Settings]

[TC/UB] to settings other than

“Off”.

(A P107 [ TC/UB ] ) When “TC” or “UB” is selected, time code or user’s bit data is displayed respectively on the display screen.

Time Code Operation Mode

Set the time code operation in [Main Menu UB] B [TC Generator].

(A P103 [ TC Generator ] )

Setting Description

Free Run The time code operates in the run

mode at all times regardless of the recording status. It continues to run even when the power of the camera recorder is turned off.

Rec Run The time code operates in the run

mode during recording. It continues

to run in the order of the recorded clips as long as the SD card is not replaced. If the SD card is removed and recording is made on another card, time code will be recorded on the new card from where it was left off in the previous card.

Regen The time code operates in the run

mode during recording. When the SD card is replaced, the last time code recorded on the card is read

recorded on a new card so that

and the time code continues in running order.

(A P69 [Setting Time Code] )

Memo :

When [Main Menu] B [System] B [Record Set B [Rec Mode] is set to “Interval Rec” or “Frame

Rec”, and [TC Generator] is set to “Free Run”, Rec Run is activated.

When [

Main Menu] B [System] B [Record Set]

B [Record Format] B [WFormat]/[YFormat] is set to “AVCHD”, and [Main Menu] B [System] B [Record Set] B [Rec Mode] is set to “Pre Rec”, Free Run is activated.

(A P115

[ W Format ] )

(A P115 [ Y Format ] )

] B [TC/

]

Time Code and User’s Bit

Setting Time Code Generator

Presetting the Time Code

Time code and user’s bit data generated from the internal time code generator are recorded. This section describes how to set

Preset].

(A P103 [ TC Preset ] )

Memo :

When [Main Menu B [Record Format] B [WFrame Rate] is set to “50p”, “50i” or “24p”, setting for “Drop” will be disabled.

(A P115

(A the Menu] )

Required Settings Before Preset

[ W Frame Rate ] )

You can configure the setting without accessing the [TC/UB] menu screen.

P70 [Setting Time Code without Opening

Set [TC/UB] B [TC Generator] Run” or “Free Run”.

P103 [ TC Generator ] )

[Rec Run] Preset data in the time code generator

operates in run mode during recording mode. Set this when recording continuous time code in connecting frames.

[Free Run Time code starts to operate in run mode from

the preset time in the time code generator.

] B [System] B [Record Set]

[TC/UB] B [TC

to “Rec

Select the framing mode for the time code generator is “60” or “30”).

Set using [Main Menu] B [ Frame]. (A P104 [ Drop Frame ] )

Memo : Drop frame/non-drop frame mode

When [Main Menu] B [System] B [Record Set] B [Record Format

“60p”, “60i”, or “30p”, the actual number of frames per second is approximately 59.94

(29.97). However, the time code processing standard is “60p”, “60i”, or “30p” frames. To

make up for the frame number discrepancy, the drop frame mode (Drop) drops the 00 frame and 01 frame every minute except for minutes that are multiples of 10. However, in the case of “60p”, the 00, 01, 02 and 03 frame are dropped.

The drop frames and ignores the discrepancy with the actual time.

Setting Time Code

(only when the frame rate setting

TC/UB] B [Drop

[Drop]: Sets

the run mode of the time code generator to drop frame mode. Use this setting when placing emphasis on the recording time. [Non Drop]

Sets the run mode of the time code generator to non-drop frame mode. Use this setting when placing emphasis on the number of frames.

non-drop frame mode (Non Drop) does not

] B [Frame Rate] is set to

Shooting

Setting Time Code Generator

TC Preset

00:00:00:00

TC/U B

During drop frame

During non-drop frame

Cursor

TC Preset

00:00:00:00

TC/U B

TC Preset

During drop frame

During non-drop frame

Cursor

Select [Main Menu] B [

TC/UB] B [TC

Preset] and press the Set button (R).

(A P

103 [ TC Preset ] )

The [TC Preset] screen appears.

Setting Time Code without Opening the Menu

Shooting

Memo :

When [TC/UB] B [TC Generator] is set to “Regen”,

the parameter is displayed as “Regen”

and cannot be selected.

(A P

103 [ TC Generator ] )

Set the time code (hour, minute, second, frame).

Use the cross-shaped button (HI) to place the cursor at the item to set, then use the crossshaped button (JK) to change the values.

Memo :

Press the

[C.REVIEW/4] button to reset each digit to “0”. The cursor moves to the time digit (left).

Check the values and press the Set button (R).

The time code is set and the screen returns to [TC/UB].

To cancel the setting, press the [CANCEL] button.

Press the [MENU] button.

Returns to the normal screen.

Memo :

Settings

cannot be made in the following cases.

[TC/UB] B [TC Generator] has been set to “Regen”.

Menu screen is displayed.

The camera recorder is not in the Camera mode.

Setting Time Code

Set [TC/UB] B [

TC Generator] to “Rec

Run” or “Free Run”.

(A P

103 [ TC Generator ] )

Press the [TC/2] button.

The [TC Preset] setting screen appears.

Set the time code (hour, minute, second, frame).

Use the cross-shaped button (HI) to place the cursor at the item to set, then use the crossshaped button (JK) to change the values.

Memo :

Press the

[C.REVIEW/4] button to reset each digit to “0”. The cursor moves to the time digit (left).

Setting Time Code Generator

Check the values and press the Set button (R).

The time code is set and the screen returns to the normal screen.

To cancel the setting, press the button.

Caution :

When

the camera recorder is switched to Media mode during editing, editing will be canceled and the screen will close.

When editing the time code, operation of the buttons that are set in [Main Menu] B [Camera

Function] B [User Switch Set] is disabled. [C.REVIEW/4] functions as the number reset button.

P98 [User Switch Set Item] )

[CANCEL]

Recording Time Code in Continuation of the Recorded Time Code on SD Card

This camera recorder is equipped with the time code reader.

Set [TC/UB] B [

When the camera recorder enters from recording standby mode to recording mode, it reads the time code already recorded on the SD card and records the new time code in continuation of that value.

The same data as the user’s bit already recorded on the SD card is recorded.

Memo :

When [TC/UB] B [TC Generator “Regen”, the framing mode of the time code follows the settings in [TC/UB] B [Drop Frame] instead of the clip settings.

(A P104

[ Drop Frame ] )

TC Generator] to “Regen”.

] is set to

Setting the User’s Bit

You can add the date, time or an 8-digit hexadecimal number as the user’s bit to the recorded image.

Selecting a Recording Mode

Recording date/time information to the user’s bit

Set [Main Menu] B [ “Date” or “Time”, and press the Set button (R).

(A P

103 [ UB Mode ] ) The date or time information is recorded to the user’s bit.

Memo :

When “Date as “-” and cannot be set.

“Time

” or “Time” is set, [Preset] appears

” is displayed in the 24-hour format.

Presetting the User’s Bit

Recording arbitrary information (8-digit hexadecimal) to the user’s bit

TC/UB] B [UB Mode] to

Shooting

Setting Time Code Generator

TC/U B

UB Mode

Preset

TC/U B

Cursor

Set [Main Menu] B [

TC/UB] B [UB Mode] to

“Preset”, and press the Set button (R).

(A P

103 [ UB Mode ] )

The [UB Mode] setting screen appears.

Shooting

Memo :

When [TC/UB] B [TC Generator] is set to “Regen”, and cannot be selected.

(A P

Select [Main Menu] B [TC/UB] B “Preset and press the Set button (R).

The [Preset] setting screen appears.

Use the cross-shaped button (HI) the cursor at the item to set, then use the cross-shaped button (JK) to change the values.

Numbers between 0 and 9 or alphabets between A and F can be specified for the user’s bit.

the parameter is displayed as “Regen”

103 [ TC Generator ] )

”

to place

Setting Zebra Pattern

When the luminance level range for displaying zebra patterns is specified, diagonal lines (zebra pattern) are displayed at areas with the specified luminance levels during shooting.

Set the zebra display pattern.

Select the display pattern in [LCD/VF] B [Shooting Assist] B [Zebra].

Specify the brightness (luminance) level range for displaying zebra pattern.

Specify the upper and lower limits of the luminance level in

Assist] B [Zebra] B [Top] and [Bottom].

Item Settings Options

Top Upper luminance

limit for displaying [Zebra]

Bottom Lower luminance

limit for displaying [Zebra]

Display the zebra pattern.

Press the [ZEBRA/5] pattern in the specified range.

[LCD/VF] B [Shooting

5% - 100%, Over

5 % increments)

(in

0% - 100% (in 5 % increments)

button to display the zebra

Memo :

Press the [C.REVIEW/4] button to reset each digit to “0”. The cursor moves to the left.

Check the values and press the Set button (R).

user’s bit is set and the screen returns to

The [TC/UB].

To cancel the setting, press the button.

Press the [MENU] button.

Returns to the normal screen.

Setting the User’s Bit

[CANCEL]

Memo :

“Zebra”

is assigned to the [ZEBRA/5] button in

factory default.

“Zebra”

can also be assigned to other user

buttons.

(A P

39 [Assignment of Functions to User

Buttons] )

Viewing Recorded Videos Immediately

You can check (review) the last recorded video clip on the screen. However, the video clip cannot be played back if the settings of the camera recorder are different from the video format (Resolution/Frame Rate/Bit Rate/SD Aspect) of the clip.

(A P115 [ W Resolution ] ) (A P115 [ W Frame Rate ] ) (A P115 [ W Bit Rate ] ) (A P116 [ SD Aspect ] )

Memo :

use this function, assign “Clip Review” to any of the user buttons. “Clip Review” is assigned to the [C.REVIEW/4] button in factory default.

“Clip

Review” can also be assigned to other user

buttons.

(A P39 [Assignment of Functions to User Buttons] )

(Clip Review)

Caution :

During Clip Review, only the [REC] buttons are enabled. Press the [CANCEL] button to cancel clip review and return to “STBY” (recording standby) mode. Press the [REC] button to cancel clip review and enter recording mode. It will take some time to

start recording after the button is pressed.

When the last clip is less than 5 seconds, the whole clip is played back.

Only

video clips in the currently selected slot can

be reviewed.

When there are no clips in the selected slot, Clip Review function is disabled.

Clip Review is unavailable when Clip Continuous Rec is paused (“STBYC”, yellow text). To operate Clip Review, use the [CANCEL] button to set to “STBYC” (white text)

first.

(A P

79 [Clip Continuous Rec] )

Clip Review is unavailable when the camera recorder and the equipment is in recording state.

Clip Review is unavailable when operating View Remote via network connection.

(A P158 [View Remote Feature K] )

Clip Review does not function during live streaming. K

Clip Review does not function while SDI Rec Trigger is in the REC state. K

is connected to an external equipment

[CANCEL] and

Shooting

Press the user button assigned with the “Clip Review

(“STBY” is displayed).

Playback of the configured section starts.

Memo :

The video clip is played back according to the setting in [Main Menu] B [Camera Function] B

[User Switch Set setting (Last 5sec), the last 5 seconds of the clip

is played back.

(A P98

When playback is complete, the camera recorder exits Clip Review and returns to “STBY” (recording standby) mode.

” function during standby

] B [Clip Review]. By default

[ Clip Review ] )

Viewing Recorded Videos Immediately (Clip Review)

Recording

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00: 00:00.00

4030 20 10 0

5 . 6 f t

P 15000K

DUAL

Simultaneously at Two Different Definitions

By setting [System simultaneously at two different definitions.

When HD+Web is selected: Records a high-definition (HD) file to slot A and a web file to slot B at the same time.

files can be used as a proxy file for the HD

Web file.

Memo :

Shooting

a recordable SD card is inserted into only one

of the slots, files will only be recorded to that slot.

The [Rec Mode] is fixed at “Normal”.

Clip Cutter Trig is disabled.

[Slot Mode

Clip Review can only be performed for slot A. (“No Media

while a card is inserted into slot B.)

Playback of web files is only possible from slot B when “HD+Web

] to “HD+Web”, you can record

] cannot be selected.

” appears if there is no card in slot A

” is selected.

Series Rec

Series Rec mode is specified in the factory default.

Menu] B [System] B [Record Set] B [Slot

([Main Mode] is set to “Series”.)

(A P117

[ Slot Mode ] ) If both the slots are loaded with recordable cards, pressing the [REC] button starts recording only to the media in the selected slot. When the remaining space in the selected media runs out, recording continues by automatically activating the media in the other slot. There is no indication on the display screen when the Series Rec mode is set.

Dual Rec

both the slots are loaded with recordable cards

If in the Dual Rec mode ([Slot Mode] is set to

“Dual”), pressing the [REC] button starts recording simultaneously to the media in both

the slots.

The

clips recorded to the media in both the slots are identical, and two clips of the same content can be created only on this camera recorder.

(A P117 [ Slot Mode ] )

Setting to Dual Rec Mode

Set [Main Menu] B [System] B [Record

] B [Slot Mode] to “Dual”.

Set

P117 [ Slot Mode ] )

“DUAL” appears on the display screen.

Recording Simultaneously at Two Different Definitions

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00:00 :00.00

4030 20 10 0

5 . 6 f t

P 15000K

100min

50min

REC

Lit in red

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00: 00:00.00

4030 20 10 0

5 . 6 f t

P 15000K

100min

50min

White

Start recording.

Insert recordable media in both slots, and press the [REC] button.

the Dual Rec mode, recording to the media

in both slots starts at the same time.

Both the card slot marks turn red, and the status indicators of both the card slots also light up in red.

Stop recording.

Press the [REC] button again.

Recording to both slots stops, and both the card slot marks turn white.

The same clips are recorded to both cards.

Memo :

Available when

[System] is set to “4K”, “HD” or

“SD”.

(A P

115 [ System ] )

During recording in the Dual Rec mode, both the card slot marks light up in red.

During recording in the Dual Rec mode to two cards with a different amount of remaining space, if the space of one card runs out, recording to both slots will stop automatically. After recording stops, recording automatically resumes for the card with remaining space. Although

the clips are separated in this case, the clips can be seamlessly joined by arranging them on the timeline of the editing software since they are recorded seamlessly.

If the last clip on the cards that are inserted in the two slots are different from each other, and the time code operating mode is set to “Regen”, the

Regen mode for the selected card slot will be enabled in the next recording.

Caution :

perform recording in the Dual Rec mode, it is

To recommended that you start recording by making use of two cards with the same capacity and from the formatted state.

You can combine the use of the Dual Rec mode with a special recording mode. While in the Dual Rec mode, you can also set [Rec Mode] to

“Normal”, “Pre Rec”, “Clip Continuous”, “Interval Rec”, or “Frame Rec”. When [Main Menu]

[System] B [Record Set] B [Record Format] [WFormat] is set to “AVCHD”, “Clip Continuous”

cannot be selected. (A P78 [Special Recording] ) (A P116 [ Rec Mode ] ) (A P115 [ W Format ] )

When both slots are inserted with recordable

cards, the Dual Rec (simultaneous recording)

operation can be performed. If a recordable

media is only inserted in one of the slots, you can

also start recording with one card.

In the Dual Rec mode, continuous recording by

switching from one slot to another cannot be

performed. Continuous recording will not be

performed if a recordable media is inserted in a

slot after recording to the other slot has started.

When recording to one slot is in progress with

the recorder set to the Dual Rec mode, inserting

a recordable media to the other slot does not

enable the Dual Rec operation. To perform the

Dual Rec operation, stop recording temporarily

(excluding pausing recording in the Clip

Continuous Rec mode), and start again.

When one of the cards is accidentally removed

while recording is in progress in the Dual Rec

mode, recording to the card in the other slot will

continue. However, repair of the accidentally

removed card by the recovery function may fail.

If an error occurs on one of the cards while

recording is in progress in the Dual Rec mode,

recording of the erroneous card stops, while that

of the other card continues.

Operations on clips recorded in the Dual Rec

mode, such as clip deletion in the Media mode

or appending of OK marks, can only be

performed on the card in the selected slot.

Shooting

Dual Rec

Backup Rec

Slot B

Slot A

Clip 3

Clip 2

Clip 1

Clip 2

Slot B stops

recording

Slot A stops

recording

Slot A starts recording

Slot B starts

recording

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00: 00:00.00

4030 20 10 0

5 . 6 f t

P 15000K

BACKUP

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00: 00:00.00

4030 20 10 0

5 . 6 f t

P 15000K

100min

50min

100min

50min

Red (selected)

Red

The Backup Rec mode allows you to make use of the media in slot B for backup recording by controlling in slot B without using the [REC] button.

Start [System] B [Record Set] B [Slot Mode] B [Backup Rec] or press the user button that is

assigned with “Backup Trig”. (A P (A P98 [User Switch Set Item] )

Shooting

Memo :

Available when

“SD”. (A P

During the Backup Rec mode (when [Slot

Mode] is set to “Backup”), you can control

recording to the 2 slots at different timings, and

backup recording can only be performed on this

camera recorder. (A P117

You can record without worrying about missing

the important scenes by setting slot B to be

always recording (backup recording) and using

the [REC] button to start/stop recording of only

the required scenes in slot A.

It is recommended to use a media with high

capacity in slot B.

the starting and stopping of recording

or stop the recording using [Main Menu] B

117 [ Slot Mode ] )

[System] is set to “4K”, “HD” or

115 [ System ] )

[ Slot Mode ] )

Set [Main Menu] B [

System] B [Record

Set] B [Slot Mode] to “Backup”.

(A P

117 [ Slot Mode ] )

“BACKUP” appears on the display screen.

Start backup recording. (Backup recording into slot B)

Select “REC” in [Main Menu

] B [System] B [Record Set] B [Slot Mode] B [Backup Rec] and press the Set button (R).

(A P117

[ Slot Mode ] )

You can also press the user button that is assigned with “Backup Trig”.

(A P98

[User Switch Set Item] )

Backup recording into slot B starts. (The characters “BACKUP” appear in red.)

The card slot mark of slot B turns red (selected state), and the status indicator of slot B also blinks in red.

Backup Rec

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00: 00:00.00

4030 20 10 0

5 . 6 f t

P 15000K

100min

50min

100min

50min

Red (not selected)

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00: 00:00.00

4030 20 10 0

5 . 6 f t

P 15000K

100min

50min

100min

50min

White (not selected)

1/100

F1. 6

AE+6

ND 1 /1 6

12 :34 : 56

Jan 24,2015

00: 00:00.00

4030 20 10 0

5 . 6 f t

P 15000K

100min

50min

100min

50min

White

Start normal recording (normal recording into slot A)

Press any of the

Recording into the media in slot A starts.

[REC] buttons.

(The characters “RREC” appear in red.)

The

card icon of slot A turns red (unselected state), and the status indicator of slot A blinks in red.

Stop normal recording.

Press any of the

Recording to slot A stops, and the card slot mark

of slot A turns white (unselected state).

The characters “RREC” (red) changes back

[REC] buttons again.

to “STBY” (white).

The status indicator of slot A goes out.

Stop backup recording.

Select [STBY] in [Main Menu

] B [System] B [Record Set] B [Slot Mode] B [Backup Rec] and press the Set button (R).

(A P117

[ Slot Mode ] )

You can also press the user button that is assigned with “Backup Trig”.

(A P98

[User Switch Set Item] )

Recording to slot B stops, and the card slot mark of slot B turns white (unselected state).

The characters “BACKUP” changes back to white.

The status indicator of slot B lights up in green.

Memo :

During backup recording, if the space of one card runs out, recording stops only for the card that is full.

When recording to both slots is stopped, recording

in the Regen mode will be enabled for

the card slot in which recording started.

When recording is started in the other slot while recording to one slot, the clip being recorded is split and simultaneous recording to the other card starts.

When

recording is stopped for either slot A or B while recording to both slots, the clip on the slot which is still recording is split.

Although the clips are separated during recording

the clips can be seamlessly joined by arranging them on the timeline of the editing software since they are recorded seamlessly.

Clip Cutter Trig cannot be performed during backup recording.

(A P82 [Splitting the Clips Freely (Clip Cutter Trig)] )

When [Slot Mode] is set to “Backup”, [Rec Mode] can only be set to “Normal”.

(A P116

[ Rec Mode ] )

Shooting

Backup Rec

Special Recording

(Recording stops)

Press [REC]

(Recording starts)

Press [REC]

Recording starts a

number of seconds

earlier based on the

[Pre Rec Time] setting

(Recorded video and audio)

Completed Clip

Besides the normal recording mode, four special recording methods are available in this camera recorder. They are Pre Rec, Clip Continuous, Frame Rec and Interval Rec. Select a mode from

[Record Set] B [Rec Mode].

(A P116 [ Rec Mode ] )

Memo :

When [Main Menu] B [System] B [Record Set] [Record Format] B [WFormat] is set to “AVCHD”, “Clip Continuous” cannot be selected.

Shooting

(A P115 [

When [Main Menu] B [System] B [Record Set] [Record Format] B [System] is set to “HD+Web”, special recording cannot be selected

Pre Rec

setting the number of seconds in the [Pre Rec

By Time], you can start recording video and audio before actual recording starts based on the [Pre Rec Time] setting.

When

starting actual recording while the camera

recorder is in Recording Standby (STBYP) mode, you can start recording a few seconds earlier based on the [Pre Rec Time] setting.

Using Pre Rec allows you to record a complete event without missing the initial scenes even if you start the recording late.

Memo :

Pre Rec Time can be set in [System] B [Record Set] B [Rec Mode] B [Pre Rec Time]. The following values can be selected depending

on the setting of [Main Menu] B [System] B [Record Set] B [Record Format] B [System].

When [System] is set to Fixed at “5sec”

When [ “5sec”, “10sec” or “15sec”

(A P116

[ Pre Rec Time ] )

[Main Menu] B [System] B

Format ] )

[Main Menu] B

“4K”:

System] is set to “HD” or “SD”:

Set [Rec Mode] to “Pre Rec”.

(A P

116 [ Rec Mode ] )

Set [Main Menu] B [System] B [Record Set] B [Rec Mode] to “Pre Rec”.

The display changes (

Press the [REC] button to start recording in Pre Rec mode.

The display changes (“STBYP” B “RRECP”) lights up in red.

Press the [REC] button again to pause

and the card slot status indicator

“STBY” B “STBYP”).

recording. The display changes (“RRECP” B “STBYP”) and the card slot status indicator lights up in green.

Caution :

When the interval between start and stop recording is short, “STBYP” may not be displayed immediately after recording is complete. “RRECP” B “STBYP”

(“STBY” blinks in red) B

“STBYP” is displayed.

When the SD card becomes full during recording, recording stops and

displayed.

In the following cases, video and audio before the

specified Pre Rec time may not be recorded

even if recording starts.

Immediately after power on

Immediately after recording stops

Immediately after switching from Media mode to Camera mode

Immediately after setting

Immediately after the end of Clip Review

Immediately after changing file format

Immediately after changing video format

“STOP” is

[Rec Mode]

Special Recording

Clip Continuous Rec

(Recorded video and audio)

Completed Clip

Recording 3

Recording 2

Recording 1

Recording 3

Recording 2

Recording 1

(Recording stops)

Press and hold [REC]

(Recording pauses)

Press [REC]

(Recording pauses)

Press [REC]

(Recording resumes)

Press [REC]

(Recording resumes)

Press [REC]

(Recording starts)

Press [REC]

In normal recording, when the recording stops,

image, audio, and accompanying data from

the the start till the end of the recording are recorded as one “clip” on the SD card.

This mode allows you to consolidate several

rounds of “startstop recording” into one clip. Example: In normal recording, three clips are generated as Recording 1, Recording 2, and Recording 3. However, recording in this mode generates only one clip.

Set “Rec Mode” to “Clip Continuous”.

116 [ Rec Mode ] )

(A P

Set [Main Menu] B [System] B [Record Set] B [Rec Mode] to “Clip Continuous”.

The display changes (

Start recording. (Recording 1)

Press the

[REC] button to start recording in

Clip Continuous mode.

The display changes (“STBYC” B “RRECC”)

and the card slot status indicator

lights up in red.

“STBY” B “STBYC”).

Pause recording.

Press the

[REC] button again to pause

recording. The display changes (“RRECC”

B “STBYC” (yellow text)).

card slot status indicator remains lighted

The in red.

Memo :

the [CANCEL] button is pressed while the

When camera recorder is paused (STBYC), the display changes (“STBYC” (yellow text) B “STBYC” (blinking yellow text) B “STBYC” (white text)), and a “clip” is generated. The card

slot status indicator lights up in green.

Resume recording. (Recording 2)

Press the

[REC] button again to resume

recording. The display changes (“STBYC” (yellow text) B “RRECC”).

The

card slot status indicator remains lighted

in red.

Pause recording.

Press the [REC] button again to pause recording. The display changes (“RRECC”

B “STBYC” (yellow text)).

card slot status indicator remains lighted

The in red.

Resume recording. (Recording 3)

Press the

[REC] button again to resume

recording. The display changes (“STBYC” (yellow text) B “RRECC”).

The

card slot status indicator remains lighted

in red.

Press and hold the [REC] button.

Recording stops and the display changes (“RRECC” B “STBYC”). A “clip” is generated.

The card slot status indicator lights up in green.

Press the [REC] button again.

The display changes (“STBYC” B “RRECC”)

and the card slot status indicator

lights up in red.

A new “clip” is generated from here.

Shooting

Special Recording

Memo :

Specific amount of data

Actual clips recorded to the media

Records number of frames specified in [Rec Frames]

(Padding data)

Normal recording

Paus ePaus ePause

Recording resumes

Press [REC]Press [REC]

(Frame Rec stops)(Frame Rec starts)

Press and hold [REC]Press [REC]

Clip Continuous Rec cannot be used in the

following cases.

When [Main Menu

] B [System] B [Record Set] B [System] is set to “HD” or “SD”, and [Format] is set to “AVCHD”

When [

Main Menu] B [System] B [Record

Set] B [System] is set to “HD+Web”

The following operations cannot be performed while

recording is paused (STBYC, yellow text).

Clip Review operation

(A P73 [Viewing Recorded Videos Immediately (Clip Review)] )

Shooting

Switching SD card slots

Switching operation mode

(A P18 [Operation Modes] )

Files are split into sizes of 4 GB (or 30 minutes) regardless of the menu settings.

Caution :

Do not remove the SD card during recording (RRECC, red text) or recording pause (STBYC, yellow text).

To remove the SD card in the Continuous” mode, press the [CANCEL] button, check that “STBYC” (white text) is displayed and the card slot status indicator lights up in

green before you remove the card.

When the SD card becomes full during recording, recording stops and

displayed.

When

the [POWER ON/OFF] switch is turned off

during recording or recording pause, recording stops and power is cut off after a clip is generated.

If the power is cut off due to low battery power, a proper clip may not be generated.

When [WFormat]/[YFormat] in the [ Menu] B [System] B [Record Set] B [Record Format] menu is set to “AVCHD”, Clip Continuous Rec cannot be performed.

(A P

115 [ W Format ] )

(A P115 [ Y Format ] )

“Clip

“STOP” is

Main

Frame Rec

In normal recording, when the recording stops, the

and accompanying data from the start till the

image end of the recording are recorded as one “clip” on the SD card. In this mode, recording starts with every press of the [REC] button, and only the specified number of

frames is recorded. The recording can be written to the media as a single clip until it is stopped.

Memo :

Audio will not be recorded.

Until a specified amount of recordings is accumulated, the file cannot be written to the media.

If the specified amount is not reached when recording is stopped, normal recording is performed and frames are added to the ending of

the clip until the amount is reached. (Padding)

After the specified number of frames is recorded and written to the media, recording will be performed until the same number is accumulated again.

Set [Rec Mode] to “Frame Rec”.

Set [Main Menu Set] B [Rec Mode] to “Frame Rec”.

(A P

116 [ Rec Mode ] )

The display changes (“STBY” B “STBYM”).

] B [System] B [Record

Special Recording

Specific amount of data

Actual clips recorded to the media

Records number of frames specified in [Rec Frames]

(Padding data)

Normal recordin g

Paus ePaus ePa use

[Rec Interval][Rec Interval]

Recording resumes

(Interval Rec stops)(Interval Rec starts)

Press [REC]Press [REC]

Set the number of frames to record in [Rec

Frames

Set

using [Main Menu] B [System] B [Record

Set] B [Rec Mode] B [Rec Frames].

(A P116

Start recording.

Repeat Frame Rec.

Press and hold the [REC] button.

Caution :

Do not remove the SD card during recording (“RRECM”, red text) or recording pause (“STBYM”, yellow text).

To the [CANCEL] button, check that “STBYM”

(white text) is displayed and the card slot status indicator lights up in green before you remove the card.

When [Main Menu Generator] is set to “Free Run”, the time code will be recorded in “Rec Run”.

Audio cannot be recorded. The audio level meter is grayed out.

(A P128

[ Rec Frames ] )

Press the [REC] button to record only the number of frames specified in [Rec Frames] and pause.

The display changes (“STBYM” B “RRECM” B “STBYM” (yellow text)).

The card slot status indicator lights up in green.

Press the [REC] button again to record only the number of frames specified in [Rec Frames]

and pause.

The display changes (“STBYM” B “RRECM” B “STBYM” (yellow text)). Frame Rec continues until the recording is stopped (step 5).

The card slot status indicator lights up in green.

remove the SD card during Frame Rec, press

] B [TC/UB] B [TC

[Audio Level Meter] )

Interval Rec

In normal recording, when the recording stops, the

and accompanying data from the start till the

image end of the recording are recorded as one “clip” on the SD card. In this mode, recording and pause are performed repeatedly at the specified time interval. Only the specified number of frames is recorded. The recording can be written to the media as a single clip until it is stopped.

Memo :

Audio will not be recorded.

Until a specified amount of recordings is accumulated, the file will not be written to the media.

the specified number of frames is recorded

After and written to the media, recording will be performed until the same number is accumulated again.

If the specified amount is not reached when recording is stopped, normal recording is performed and frames are added to the ending of the clip until the amount is reached. (Padding)

Set [Rec Mode] to “Interval Rec”.

Set [Main Menu] B [System] B [Record Set] B [Rec Mode] to “Interval Rec”.

(A P

116 [ Rec Interval ] )

The display changes (“STBY” B “STBYN”).

Set the number of frames to record in [Rec

Frames

Set using [Main Menu] B [System] B [Record Set] B [

Rec Mode] B [Rec Frames].

(A P116 [ Rec Frames ] )

Shooting

Special Recording

1/100

F1. 6

AE+6

ND 1/16

12 :34 : 56

Jan 24 ,2015

00:00:00.00

4030 20 10 0

5 . 6 f t

P 1 50 00 K

Set the time interval to start recording in [Interval Rec].

Set using [Main Menu] B [System Set] B [Rec Mode] B [Rec Interval]. (A P116 [ Rec Interval ] )

Start recording.

Press the

[REC] button to record only the number of frames specified in [Rec Frames] and pause.

After the specified time in [Rec Interval] has passed,

recording starts again to record only

the number of frames specified in [Rec

Shooting

Frames] and pause.

Interval Rec continues until the recording is stopped. The display changes (“STBYN” B “RRECN” B “STBYN” (red text) B “RRECN” B “STBYN” (red text)).

The

card slot status indicator blinks in green.

Press and hold the [REC] button.

The card slot status indicator lights up in green.

The display becomes “STBYN”.

Caution :

Do not remove the SD card during recording (RRECN,

red text) or recording pause (STBYN,

yellow text).

To remove the SD card during Interval Rec, press the [CANCEL] button, check that “STBYN”

(white text) is displayed and the card slot status indicator lights up in green before you remove the card.

When [Main Menu] B [TC/UB] B [TC Generator] is set to “

Free Run”, the time code

will be recorded in “Rec Run”.

Audio cannot be recorded. The audio level meter is grayed out.

P128 [Audio Level Meter] )

] B [Record

Splitting the Clips Freely (Clip Cutter Trig)

can split the clips freely without having to stop

You recording during shooting.

Assign the “Clip Cutter Trig” function to any of the user buttons.

39 [Assignment of Functions to User

(A P Buttons] )

Press the user button that is assigned with “Clip Cutter Trig

A clip cut icon (Q) appears on the display screen for 3 seconds, and the clip is split.

Memo :

Clips cannot be split again for a few seconds after the operation is performed.

This item cannot be used when set to “Backup”.

Available when “SD”.

(A P115

[ System ] ) This item cannot be used when [Rec Mode] is set to a value other than “Normal” or “Pre Rec”.

(A P

116 [ Rec Mode ] )

The split clips are recorded seamlessly without interruptions in the video.

” during shooting.

[Slot Mode] is

[System] is set to “4K”, “HD” or

Special Recording

Playing Recorded Clips

B C D

E F G H I

218G0005

2015-01-07 07:08:43

USER3

USER4

USER5

Actions

Select

OK Mark

A B

play back clips recorded on SD cards, switch to

To the Media mode. Press and hold the [MODE] selection button in

Camera mode to enter Media mode. A thumbnail screen of the clips recorded on the SD card is displayed. You can play back the selected clip on the thumbnail screen.

Memo :

When an SD card without any clips is inserted, “No Clips

Operation Buttons

Use the operation buttons, on the side control panel of the camera recorder or the LCD monitor, to operate the thumbnail screen.

[MENU/THUMB]

Cross-Shaped Button (JKHI)

Moves the cursor.

Set (Play) Button

[CANCEL] (Stop) Button

Cancels settings and returns to the previous screen.

[LOLUX/3] Button

” is displayed.

Displays the menu.

Press this button to close the menu screen during menu display and return to the thumbnail screen.

Sets the values and items. (Confirm)

Plays back the selected clip.

Switches the cursor.

If an OK mark has been appended, it will be deleted. Otherwise, an OK mark will be appended.

Button

the OK mark of the clip selected by

C.REVIEW/4] Button

[

Switches the selection status of the clip selected by the cursor.

Clips being selected are displayed with check mark.

[ZEBRA/5] Button

Enters the action selection screen.

[DISPLAY] Button

Switches between the “Standard Screen” and “Detailed Screen”.

[STATUS] Button

Displays the media information screen.

Thumbnail Screen

“Standard Screen” and “Detailed Screen” are available.

the [DISPLAY] button to switch between the

Use screens.

Thumbnails are displayed in order of recording from the oldest to most recent.

Standard screen

SD Card Information

Displays the status of the inserted SD card, selected SD card, write-protect switch, and the need for restoring.

Use the [SLOT A/B] switch to switch slots. Clips in slot A and B cannot be displayed at

the same time. W z:Write-protect switch of the SD card

in slot A is set.

SD card in slot B needs to be

restored or formatted, or is an unsupported SD card.

Clip Mark

Displays the clip information (properties).

Playback

OK Mark

Clip is appended with OK mark.

Playing Recorded Clips

Memo :

A B

Clips appended with OK marks cannot be deleted on the camera recorder.

Playback

Main Menu] B [System] B [Record Set]

When [ B [Record Format] B [WFormat] is set to “AVCHD”, the OK mark indicates that the clip is protected.

(A P

115 [ W Format ] )

Continued From Mark

This mark indicates that the current clip is continued from another SD card when recording is divided and made on several SD cards.

Uneditable Mark

This mark indicates that an OK mark cannot

appended to or deleted from the clip, and

be the clip cannot be deleted.

When [Main Menu Set] B [Record Format] B [WFormat] is set to “AVCHD”, clips that are not recorded on this camera recorder cannot be edited.

Continue Mark

This

mark indicates that recording of the current clip is continued to another SD card when recording is divided and made on several SD cards.

Check Mark

A green check mark is displayed when the clip is selected.

Magenta and gray check marks are displayed in multiple selection mode.

[Selecting and Performing

(A P89 Operations on Multiple Clips] )

Cursor

Clip to be worked on. Use the cross-shaped button (JKHI) to move the cursor.

Thumbnail Substitution Display

A clip with corrupted management information. It cannot be played back even if you press the Set (Play) button.

clip that cannot be played back nor displayed

A in thumbnail with the current video format settings. It cannot be played back even if you press the Set (Play) button.

] B [System] B [Record

Memo :

Dependent on the settings for [ [System] B [Record Set] B [Record Format] B [System]/[WResolution]/[YResolution]/ [WFrame Rate]/[YFrame Rate]/[WBit Rate],

and [YBit Rate].

(A P115 (A P115 [ W Resolution ] ) (A P116 [ Y Resolution ] ) (A P115 [ W Frame Rate ] ) (A P116 [ Y Frame Rate ] ) (A P115 [ W Bit Rate ] ) (A P116 [ Y Bit Rate ] )

Memo :

(A P (A P108 [ Time Style ] )

[ System ] )

When [Record Format “AVCHD”, you may not be able to play back files recorded on a camera recorder other than the

GY-HM200 and GY-HM170 series. If a file cannot be played back, the above thumbnail substitution display 2 is displayed.

Clip Name

file name (clip number) of the selected clip

The is displayed.

Operation Guide

Displays a guide for the current operation buttons.

The action selection screen is displayed when the User 5 ([ZEBRA/5]) button is

pressed.

85 [Actions] )

(A P

Recording Start Time

Displays the recording start time of the clip.

The

date/time display is dependent on the [LCD/ VF] B [Display Settings] B [Date Style]/[Time Style] settings in the [Main Menu] screen.

108 [ Date Style ] )

Scroll Bar

Indicates the scroll position.

Black space below the scroll bar (white) indicates that there are more pages.

When the scroll bar (white) is at the bottom, this indicates the last page.

Remaining Battery Power

31 [Power Status Display] )

(A P

Number of Clips

none of the clips are selected, the “running

If number/total number of clips” of the clip to be displayed appears.

Even if only one clip is selected, the number of selected clips in the current slot is displayed.

Main Menu] B

] B [WFormat] is set to

Playing Recorded Clips

Jan 24, 2015 12:34:56AM

Normal

Rec Mode

Audio

Video

Format

Network Connection Icon K

The network connection status is displayed when [Main Menu] B [System] B [Network]

is set to

“On”. This icon is not displayed when “Off” is selected.

(A P

130 [Network Connection Icon K] )

Detailed screen

* Items

that are common with the Standard screen will not be described. Refer to “[Standard screen] (A P 83)”.

Thumbnail

Thumbnail of the clip selected by the cursor.

the cross-shaped button (HI) to move the

Use cursor.

Scroll Mark (DE)

If there are previous clips, D appears on the left.

there are more clips, E appears on the right.

The marks will not be displayed if there are no clips before and after the current clip.

Metadata

Metadata of the clip pointed by the cursor. You can use the cross-shaped button (JK) to scroll.

Actions

The action selection screen is displayed when the User 5 ([ZEBRA/5]) button is pressed.

The following operations can be performed.

Item Description Select All Clips Selects all clips. Select OK

Marked Select Range Specifies the range when

Deselect All Clears all clip selections. Add OK Mark Appends an OK mark.

Delete OK Mark Deletes the OK mark.

Selects all clips appended with OK mark.

selecting multiple clips.

89 [Selecting Multiple

(A P Clips Randomly] )

This Clip: Appends an OK mark to the clip pointed by the cursor.

Selected Clips: Appends an OK mark to the clips selected (appended with check mark).

All Clips: Appends an OK mark to all clips.

This Clip: Deletes the OK mark of the clip pointed by the cursor.

Selected Clips: Deletes the OK mark of the clips selected (appended with check mark).

All Clips: Deletes the OK mark of all clips.

Playback

Playing Recorded Clips

Item Description

FTP Upload Uploads a clip to the FTP server.

Delete Clips Deletes clip. However, clips with

Playback

Trim This Clip Trims the clip pointed by the

Memo :

object of action is the clip of the current slot

The being displayed.

[Selected Clips] cannot be performed if there are no selected (appended with check mark) clips.

[This

Clip] cannot be performed if there are more

than one selected (appended with check mark) clips.

If the write-protect switch of an SD card is set, OK mark cannot be appended or deleted, and the clips cannot be deleted and trimmed.

This Clip: Uploads the clip pointed by the cursor.

Selected Clips: Uploads the clips selected (appended with check mark).

All Clips: Uploads all clips.

OK mark cannot be deleted.

This Clip: Deletes the clip pointed by the cursor.

Selected Clips: Deletes the clips selected (appended with check mark).

All Clips: Deletes all clips.

cursor.

Playing back

Use the operation buttons on the side control panel of the camera recorder to play back.

Set Button (R)

Plays back/pauses the clip pointed by the cursor.

You

can press the cross-shaped button (HI) to perform frame-by-frame forward playback during pause mode.

Cross-shaped Button (JKH I)

[J/K] Button: Skips in the reverse or forward direction.

[H/I] Button:

During Playback: Fast forwards in the reverse or forward direction.

While paused: Frame-by-frame playback in the reverse or forward direction.

[CANCEL/STOP

Stops playback.

In the thumbnail screen, move the cursor to the clip to be played back.

Move the cursor to the clip to be played back using the cross-shaped button (JKH I).

Press the Set button (R).

Playback of the selected clip starts.

] Cancel Button

Playing Recorded Clips

Audio Output during Playback

You can confirm the playback sound from the monitor speaker, or the headphone connected to the [x] terminal. When a headphone is connected output from the monitor speaker.

(A P139 [Connecting the Headphone] )

Adjust the volume of the monitor speaker and headphone using the J / K volume buttons on the side of the camera recorder.

to the [x] terminal, sound cannot be

Time Code Playback

P 13000K

1/100

F1. 6

Camera Information Display

218G0005

2015-01-07 07:08:43

code or user’s bit recorded on an SD card can

Time be displayed on the LCD monitor and viewfinder.

Memo :

The time code is also superimposed on the

signal output from the [SDI OUT] terminal.

video

a section without time code is played back, the time code will stop. However, playback will continue.

Displaying Information during Shooting

Pressing the [DISPLAY] button during playback displays the display screen.

Pressing shooting information displayed (camera

information display and hide display).

Memo :

the [OIS/6] button each time changes the

Camera information display displays only information of Gain, Iris, Shutter and White Balance that have been recorded.

When [System] B [Record Set] B [ Format] B System is set to “HD+Web”, only SD or web files can be played back from slot B.

In this case, files up-converted into the HD size are played back in the simple mode. Trimming information is displayed while trimming [OIS/6] button does not switch the display.

is in progress. In this case, pressing the

Record

Deleting Clips

Delete clip.

Memo :

Clips appended with OK marks cannot be deleted on the camera recorder.

Read-only clips can be deleted on a PC.

Deleting One Clip

Delete the clip (one clip) pointed by the cursor in [Delete Clips

Memo :

Clips with OK mark cannot be deleted.

During Thumbnail Screen

Move the cursor to the clip to be deleted.

Move the cursor to the clip to be deleted using the cross-shaped button (JKH I).

Press the [ZEBRA/5] button.

The action selection screen is displayed.

] B [This Clip] in the menu.

Playback

Playing Recorded Clips

All Clips

Selected Clips

This Clip

Stop

Deleting...

Cancel

Delete

Delete This Clip?

OK Mark

Select [Delete the Set button (R).

A screen to confirm deletion appears.

Select [Delete] using the cross-shaped button (JK), and press the Set button (R).

Deleting starts.

Playback

Clips] B [This Clip] and press

Appending/Deleting OK Mark

You can append OK marks to the clips for important scenes.

Clips appended with OK marks cannot be deleted, thus protecting the important clips.

When the camera recorder is in Media mode, you can delete the OK marks appended during recording, or append/delete OK marks after shooting.

During Thumbnail Screen

Press the [LOLUX/3] button.

If the clip does not have an OK mark, an OK mark will be appended.

If the clip is appended with an OK mark, the OK mark will be deleted.

Selecting and Deleting Multiple Clips

To select and delete multiple clips, refer to “[Selecting

and Performing Operations on Multiple

Clips] (A P 89)”.

Deleting All Clips

Delete all clips that are displayed.

Press the [ZEBRA/5] button.

The action selection screen is displayed.

Select [Delete Clips] B [

A screen to confirm deletion appears.

Select [Delete] and press the Set button (R).

Deleting starts.

Memo :

The time taken to delete clips depends on the number of clips to be deleted.

Deleting Clips

All Clips].

During Playback or Pause Screen

12:34:56

Jan 24,2015

00:00:00.00

x5x5x5

3840x2160

16.4V

2/4

30p 150M

30p 15 0M

USER3

USER4

USER6

OK Mark

Press [LOLUX/3] button during clip playback.

If the clip does not have an OK mark, an OK mark will be appended.

If the clip is appended with an OK mark, the OK mark will be deleted.

Memo :

clip pauses when an OK mark is appended

The or deleted during playback.

Appending/Deleting OK Mark of Multiple Clips

To select and append/delete OK mark for multiple clips, refer to “[Selecting and Performing Operations on Multiple Clips] (A P

89)”.

Selecting and Performing Operations on Multiple Clips

Selecting Multiple Clips Randomly

Move the cursor to a clip without a check mark, and press the

A green check mark appears on the clip.

Repeat Step 1 to select multiple clips.

Multiple clips can be selected.

Press the multiple clips are selected.

[ZEBRA/5] button while the

Appends OK mark together: [Add OK Mark] B [Selected Clips

Deletes OK mark together: [Delete OK Mark

Uploading together: [FTP Upload] B [Selected Clips]

Deletes selected clips together: [Delete Clips

Memo :

Selecting clips appended with check mark and pressing the [C.REVIEW/4

the selection.

the operation is performed on multiple clips at the same time, a progress bar appears. You can stop the operation by pressing the Set button (R) while the operation is in progress. However, it is not possible to undo operations that are completed.

[C.REVIEW/4] button.

]

] B [Selected Clips]

selected clips to the FTP server

] B [Selected Clips]

] button will cancel

Playback

Multiple clips can be selected during thumbnail screen or playback screen display.

After selecting multiple clips, perform appending/deleting

of OK mark, deleting of clips

using the action selection screen.

After selecting multiple clips, the selections will be canceled by the following operations.

When [Deselect All] in the action menu is selected

When

exiting Media mode from the thumbnail

screen

When removing the SD card

When switching the slot in use

Appending/Deleting OK Mark

Selecting Multiple Clips Consecutively

FTP Upload...

Delete OK Mark...

Add OK Mark...

Deselect All

Select Range

Select OK Marked

Select All Clips

Selected Range:

End Position

Start Position

Press the [ZEBRA/5] button.

Select “Select Range” in the action selection screen, and press the Set button

(R).

Move the cursor to the beginning (or end)

Playback

of the range for multiple selection, and press the Set button (R).

Move the cursor to the other end of the range.

Magenta check marks appear on the clips within the range. (Including clips that were already selected.)

Gray check marks appear on selected clips that are outside the range.

Press the Set button (R) to confirm the range.

The check marks change from magenta to green.

Pressing the

[ZEBRA/5] button while the

multiple clips are selected displays the action selection screen. The following operations can be performed.

Appends OK mark together: [Add OK Mark

Deletes OK mark together: [Delete OK Mark

Uploading

] B [Selected Clips]

selected clips to the FTP server together: [FTP Upload] B [Selected Clips]

Deletes selected clips together: [Delete Clips

] B [Selected Clips]

Memo :

Selecting clips appended with check mark and pressing the [C.REVIEW/4

] button will cancel

the selection.

Selecting and Performing Operations on Multiple Clips

Trimming Recorded Clips

30min 11:22: 33.00 11:23: 44.00 00: 08:22

282min

12 :34 : 56

Jan 24,2015

00: 00:00.00

3840x2160

30p 150M

4030 20 10 0

1000/2000

TRIM

OUT

Trim This Clip

Delete Clips...

FTP Upload...

Delete OK Mark...

Add OK Mark...

Deselect All

Select Range

can extract (trim) the necessary parts of a clip

You recorded in the SD card. The trimmed clip is saved as a new file on the same SD card as the original clip. No changes are made to the original clip.

Switch to Media mode.

Switch the mode using the [MODE] selection button on the side control panel.

Move the cursor to the clip to be trimmed.

Move the cursor to the clip to be trimmed using the cross-shaped button (JKH I).

Press the [ZEBRA/5] button.

The action selection screen is displayed.

Select [Trim This Clip], and press the Set button (R).

Playback of the selected clip starts.

Guide

Operation guide

Position bar

Current position of the video

: Position to start trimming (in point)

: Position to end trimming (out point)

Trimming information

W or Y :

Indicates the available space in the storage media (W or Y)

: Indicates the time code of the in

point

: Indicates the time code of the out

point

: Indicates the duration from the in

point to the out point

Memo :

trimmed clip will be saved to the same card

The slot as that of the original clip.

[Duration] appears in yellow in the following durations. Trimming cannot be performed in this

case.

When [Main

Menu] B [System] B [Record Set] B [Record Format] B [System] is set to “4K”: 3 minutes or longer; setting other than “4K”: 10 minutes or longer.

[Duration] appears in yellow if the duration is longer than the recordable time on the storage

media. Trimming cannot be performed in this case.

When trimming starts, the display switches to the Media Display 2 screen.

Specify the in point.

Operate buttons such as H/I or J/K to move the video to the in point.

(A P86 [Playing back] )

Specify the in point by pressing the [LOLUX/ 3] button at the point you want to start trimming.

Specify the out point.

Operate

buttons such as H/I or J/K to move

the video to the out point.

(A P86 [Playing back] )

Specify the out point by pressing the [C.REVIEW/4

] button at the point you want to

end trimming.

Perform trimming.

Press the [ZEBRA/5] button to perform trimming.

Memo :

While

trimming is in progress, you can press the

[CANCEL] button to return to the thumbnail screen.

While

trimming is in progress, you can press the

[DISPLAY] button to switch the display, but the trimming information is displayed at all times.

When trimming the in and out point, the in point trimmed may be up to one second before the specified

in point and the out point trimmed may be up to one second behind the specified out point.

Playback

Trimming Recorded Clips

Basic Operations in Menu

B C D

E F G H

Screen

Press the [MENU/THUMB] button on the LCD monitor to display the menu screen on the LCD

monitor and viewfinder.

Various settings for shooting and playback can be configured on the menu screen.

There are two types of menu screens Menu] and [Favorites Menu].

[Main Menu camera recorder, classified according to

functions and uses, while [Favorites Menu] allows users to customize the menu items freely.

P123 [Adding/Editing Frequently Used

Menu Items (Favorites Menu)] )

The operating procedures and main screen displays are the same for both menus.

The menu screen can also be displayed on external

Menu Display and Detailed Settings

output terminal.

(A P109 [ Display On TV ] )

Operation Buttons

Use the operation buttons on the side control panel of the camera recorder or the buttons on the LCD monitor to operate the menu.

] contains all the setting items of the

monitors connected to the video signal

[Main

[MENU/THUMB]

Displays the menu screen. The Menu] screen is displayed by default.

During normal usage, displayed if the previous menu operation

ended at [Main Menu], and [Favorites Menu] if the previous menu operation ended at [Favorites Menu].

Press this button to close the menu screen during screen.

Pressing and holding down the button while the menu is displayed switches the [Main

Menu] screen to the [Favorites Menu] or vice versa.

Cross-shaped Button (JKH I)

Moves the cursor upward.

: Moves the cursor downward.

: Moves back to the previous item.

: Moves forward to the next item.

Set Button (R)

Sets the values and items.

[CANCEL] Button

Cancels settings and returns to the previous screen.

[LOLUX/3] Button

Adds the selected menu or submenu item to the [Favorites Menu].

(A P123 [Adding/Editing Frequently Used Menu Items (Favorites Menu)] )

[C.REVIEW/4] Button

Resets settings in the [TC Preset] or [UB Preset] setting screen. This button is disabled in other screens.

[DISPLAY] Button

Switches between the [Main Menu] and [Favorites Menu] screens.

[STATUS] Button

Displays a simple Help menu. Simple Help appears only when the selected menu item supports this function.

Button

[Main

[Main Menu] is

menu display and return to the normal

Basic Operations in Menu Screen

Display and Description of the Menu

AddFavo rite s

SECShutter

24hourTime Style

YMDDate Style

OnDate/Time

TimeBattery

OffAudio Meter

Display Settings

CancelSet

Off

SECShutter

24hourTime Style

YMDDate Style

Date/Time

Battery

Audio Meter

Display Settings

Screen

Selecting Menu Items

Cursor

Indicates the selected item. Use the crossshaped button (JK) to move the cursor

Menu Item

Displays the names of the menu item and sub-menu.

items with [...] after them indicates that

Menu there is a sub-menu to access.

Fixed Item

Items that cannot be changed are displayed in gray and cannot be selected.

Operation Guide

Guide for the current operation buttons.

Setting Value

Setting values for the menu items. For menus with sub-menus, values are not displayed.

Scroll Bar

Indicates the scroll position.

Header

Indicates the current menu type with the line color.

Blue Green : [Favorites Menu] (Operation

Magenta : [Favorites Menu] (Editing screen)

Remaining Battery Power

(A P31 [Power Status Display] )

Memo :

the supplied battery (or equivalent battery sold separately) is not used, the battery mark which indicates the battery level may not appear.

: [Main Menu] Screen

screen)

Changing Setting Values

Menu Item to Change

Menu item to be changed. A list of setting values F appears in a pop-up.

Operation Guide

Guide for the current operation buttons.

Setting Values Before Change

Setting values before changing. The background of the item is displayed in blue.

Scroll Bar

Indicates the scroll position.

Cursor

Indicates the selected item. Use the crossshaped button (JK) to move the cursor

List of Setting Values

pop-up displaying a list of setting values for

A selection.

The height of the pop-up depends on the number of settings available. Use the scroll bar D to confirm the current display status.

Menu Display and Detailed Settings

Menu Title

Title of the currently displayed menu.

Basic Operations in Menu Screen

Text Input with Software Keyboard

Cancel

Set

Use the software keyboard to enter the [Setup

] subname, [Clip Name Prefix], and the settings

File under [Network] B [Settings].

Entering a subname

(A P136

Entering the [Clip Name Prefix]

Menu Display and Detailed Settings

(A P

Settings under [Network] B [Settings]

The keyboard displayed varies according to the settings.

(A P

[Configuring Setup Files] )

118 [ Clip Name Prefix ] )

118 [Network/Settings Item K] )

Character Entry Field

Field for entering the title.

You can enter up to 8 characters for the [Setup File] subname or up to 4 characters

for the [Clip Name Prefix

Character Cursor

Select

a character using the key cursor D, and

press the Set button (R) to input the selected character at the position of the character cursor. The character cursor moves to the next position on the right each time a character is input. The cursor can be moved using the arrow keys

Character Keys

Use the cross-shaped button (JKHI) to move the key cursor D to the character you want to enter.

Key Cursor

Indicates the currently selected character or item. Use the cross-shaped button (JKHI) to move the cursor.

Confirmation Buttons

[Set]/[Store] and press the Set button

Select (R) to confirm the title.

Select

[Cancel] and press the Set button (R)

on the side control panel of the camera recorder to abort character input and return to the previous screen.

[SP] Space Key

[SP] and press the Set button (R) on the

Select side control panel of the camera recorder to

enter a space at the current position of the character cursor B.

[3 ] Backspace Key

Select [3 ] and press the Set button (R) on the side control panel of the camera recorder to delete the character on the left of the character cursor B.

Arrow Keys

Moves the position of the character cursor B.

Character Switch Button

Switches the character buttons C to the upper case, lower case, and symbols.

Basic Operations in Menu Screen

Menu Screen Hierarchical Chart

[Main Menu...]

- [Camera Function...

Bars] ............................................. (A P 96)

- [

- [OIS] .............................................. (A P 96)

- [Flicker Correction] ........................ (A P 96)

- [Shutter] ......................................... (A P 96)

- [AE Speed] .................................... (A P 96)

- [AGC Limit] .................................... (A P 96)

- [Auto Iris Limit (OPEN)] ................. (A P 96)

- [Auto Iris Limit (CLOSE)] ............... (A P 96)

- [EEI Limit] ...................................... (A P 96)

- [Smooth Trans] .............................. (A P 96)

- [FAW] ............................................ (A P 97)

- [GAIN L] ......................................... (A P 97)

- [GAIN M] ........................................ (A P 97)

- [GAIN H] ........................................ (A P 97)

- [Dynamic Zoom] ............................ (A P 97)

- [Handle Zoom Speed L] ................ (A P 97)

- [Handle Zoom Speed M] ............... (A P 97)

- [Handle Zoom Speed H] ................ (A P 97)

- [Zoom Ring] ................................... (A P 97)

- [Iris Dial] ........................................ (A P 97)

- [AF Speed] .................................... (A P 97)

- [AF Assist] ..................................... (A P 97)

- [User Switch Set...] ........................ (A P 97)

- [Camera Process...] ........................

- [

Detail] ......................................... (A P 100)

- [

Master Black] ............................. (A P 100)

- [Black Toe] .................................. (A P 100)

- [Knee] .......................................... (A P 100)

- [White Clip] .................................. (A P 101)

- [Gamma] ..................................... (A P 101)

- [WDR] .......................................... (A P 101)

- [White Balance...] ........................ (A P 101)

Memo :

Some items are displayed in gray, and they cannot be selected.

Setting value with the R mark is the factory default.

....................................... (A P 95)

] .......................... (A P 96)

(A P 100)

- [Adjust...

] ............................... (A P 100)

menus cannot be set depending on the operating mode or status of the camera recorder. These

Color Matrix] ............................... (A P 102)

- [

- [Color Gain] ................................. (A P 102)

- [Reset Process] ........................... (A P 102)

- [TC/UB...

- [LCD/VF...

- [A/V Set...

- [System...] .......................................

] ........................................ (A P 103)

TC Generator] ............................ (A P 103)

- [

- [TC Preset] .................................. (A P 103)

- [UB Mode] ................................... (A P 103)

- [Drop Frame] ............................... (A P 104)

] ...................................... (A P 104)

- [

Shooting Assist...] ....................... (A P 104)

- [Marker Settings...] ...................... (A P 104)

- [Display Settings...] ...................... (A P 104)

- [VF SW] ....................................... (A P 104)

- [VF Color] .................................... (A P 104)

- [VF Bright] ................................... (A P 105)

- [VF Contrast] ............................... (A P 105)

- [LCD Bright] ................................. (A P 105)

- [LCD Contrast] ............................. (A P 105)

- [LCD Backlight] ........................... (A P 105)

- [LCD Mirror] ................................. (A P 105)

- [LCD/VF Peaking] ........................ (A P 105)

] ....................................... (A P 109)

Video Set...] ................................ (A P 109)

- [

- [Audio Set...] ................................ (A P 109)

(A P 113)

- [

Record Set...] ............................. (A P 113)

- [Media] ........................................ (A P 113)

- [Setup File] .................................. (A P 113)

- [Tally Lamp] ................................. (A P 113)

- [Language] .................................. (A P 113)

- [Network] K ............................. (A P 113)

- [Settings] ...............................

- [

Reset All] .................................... (A P 114)

- [Date/Time] .................................. (A P 114)

- [Time Zone] ................................. (A P 114)

- [System Information] .................... (A P 114)

(A P 114)

Menu Display and Detailed Settings

Menu Screen Hierarchical Chart

Camera Function Menu

Menu screen for specifying operation settings during shooting. This item can only be selected in the Camera mode.

Bars

For setting whether to output color bars. [Setting Values: On, ROff]

Memo :

The audio test signals (1 kHz) can be output simultaneously with the color bar output.

(A P112

OIS

For setting whether to enable image stabilizer. When “On

[Setting Values: ROn, Off]

Menu Display and Detailed Settings

For setting the level of the image stabilizer. [Setting Values: High, RNormal]

Memo :

(A P128 [Image Stabilizer Mark] )

Flicker Correction

For setting whether to adjust image flicker that occurs under a fluorescent light. [Setting Values: On, ROff]

Shutter

For specifying shutter-related settings. Set to “Step”

operating with the J / K volume buttons on the side of the camera recorder.

[Setting Values: Variable, RStep]

[ Test Tone ] )

” is selected, set the Level.

Level

The icon changes according to the level set.

When “High” is selected, correcting severe camera shake may cause the area surrounding

the image to darken.

(fixed value) or “Variable” when

Variable: Sets to variable scan. Use this setting when shooting a PC monitor. Step: Sets to step shutter, which switches the shutter speed by a fixed value.

AE Speed

setting the convergence speed during AE (Auto

For Exposure). [Setting Values: RFast, Middle, Slow]

AGC Limit

For setting the maximum gain value of which electrically boosts the sensitivity level

according to the brightness automatically. [Setting Values: 24dB, R18dB, 12dB, 6dB]

Auto Iris Limit (OPEN)

For setting the limit value of the OPEN end when auto iris is enabled. [Setting Values: F4, F2.8, RF2, F1.8, F1.6, F1.4, F1.2]

Auto Iris Limit (CLOSE)

For setting the limit value of the CLOSE end when auto iris is enabled. [Setting Values: F11, F8, RF5.6, F4]

EEI Limit

For setting the shutter speed control range when the Automatic Shutter mode (EEI) is enabled. [Setting Values: 4F-stop, R3F-stop, 2F-stop]

Smooth Trans

For setting the shock reduction function, which slows down the sudden change when switching with the [

[Setting Values: ROff, Slow, Middle, Fast]

Memo :

GAIN] or [WHT.BAL B/A/PRST] switch.

This

function is disabled when AGC is operating.

“AGC”,

Camera Function Menu

FAW

setting the position in the white balance switch

For [WHT.BAL B/A/PRST] to assign the FAW (Full

Auto White Balance) function. [Setting Values: RNone, PRST, A, B]

GAIN L/GAIN M/GAIN H

For setting the gain value of each position on the [GAIN] selection switch.

setting is fixed at “AGC” in the Full Auto mode.

The In addition, the sensitivity setting in Lolux is used.

(A P98 [ Lolux ] ) [Setting Values: 24dB, 21dB, 18dB, 15dB, 12dB, 9dB, 6dB, 3dB, 0dB, AGC] (Default values GAIN L: 0dB, GAIN M: 6dB, GAIN H: 12dB)

Dynamic Zoom

For setting whether to enable the dynamic zoom function.

Off: Enables only the optical zoom (1x to 12x).

On: Enables the dynamic zoom (12x to 24x) in addition to the optical zoom.

[Setting Values: ROff, On]

Memo :

When [

System] is set to “4K”, this item is fixed at

“Off” and cannot be selected.

Handle Zoom Speed L/Handle Zoom Speed M/Handle Zoom Speed H O

setting the zoom speed for each position on the

For [ZOOM L/M/H] zoom speed selection switch.

The larger the value the faster the zoom speed. Selecting “Off” disables the zoom operation on the

handle. [Setting Values: Off, 1 to 7] (Default Values Handle Zoom Speed L: 1, Handle Zoom Speed M: 4, Handle Zoom Speed H: 7)

Zoom Ring

For assigning the zoom or iris adjustment to the zoom ring. [Setting Values: RZoom, Iris]

Iris Dial

For assigning the iris, shutter or AE level adjustment to the iris dial. [Setting Values: RIris, Shutter, AE Level]

AF Speed

For setting the AF operation speed. [Setting Values: Fast, RMiddle, Slow]

AF Assist

For setting whether to shift the auto focus point when the focus ring is turned during Auto Focus (AF).

Off: Sets the AF Assist function to “Off

Far/Near: This option allows you to shift the auto focus point to near and far directions by turning the focus ring during AF.

Area: This option allows you to shift the auto focus point to the left, center, right, or near and far directions by turning the focus ring during AF. Selecting this option displays the

the area.

[Setting Values: ROff, Far/Near, Area]

51 [AF Assist Function] )

(A P

Memo :

This setting is effective only when the switch is set to “AUTO”.

The manual focus adjustment mode is temporarily the AF mode. If the focus ring is not operated for a certain time, the camera recorder returns to the AF mode.

User Switch Set...

For specifying user button related settings.

(A P

activated by turning the focus ring in

98 [User Switch Set Item] )

”.

icon in

[FOCUS]

Menu Display and Detailed Settings

Camera Function Menu

User Switch Set Item

USER1 ~ USER9, LCD KEY▲/LCD KEY▶/LCD KEY▼/LCD KEY◀

assigning one of the following functions to each

of the [F.ASSIST/1], [TC/2], [LOLUX/3], [C.REVIEW/4], [ZEBRA/5], [OIS/6], [REC/7], [EXPANDED FOCUS/8], [AWB/9] buttons or the cross-shaped buttons on the LCD monitor, these

buttons can be used to control the assigned function (on/off, start, switch). Set according to the shooting conditions. Usable only in the Camera mode. [Setting Values: None, Zebra, Marker, Bars, Focus Assist, OIS, LCD Backlight, Lolux, AE/FAW Lock, Face Detect, OK Mark, Clip Cutter Trig, Backup Trig, Clip Review, Load Picture File, White Balance, TC Preset, AWB, Rec, Preset Zoom1, Preset Zoom2, Preset Zoom3, Push AF/AF Lock, One Push Iris, Expanded Focus, Live Streaming K]

Menu Display and Detailed Settings

Memo :

“Rec” can only be assigned to the [REC/7], [EXPANDED FOCUS/8] and [AWB/9] buttons.

Lolux

To increase the sensitivity when in dim surroundings, set a value in the Lolux mode. [Setting Values: 36dB, R30dB]

Clip Review

For specifying the operation when any of the [USER1]-[

[LCD KEY▼], or [LCD KEY◀] items is set to “Clip Review”.

[Setting Values: RLast 5sec, Top 5sec, Clip]

USER9], [LCD KEY▲], [LCD KEY▶],

Last 5sec: Views about 5 seconds of the clip from the ending. Top 5sec: Views about 5 seconds of the clip from the beginning. Clip: Views the entire clip.

Face Detect

For specifying the operation when any of the [USER1]-[

[LCD KEY▼], or [LCD KEY◀] items is set to “Face Detect”. Select the control to track results of face detection.

[Setting Values: RAF&AE, AF]

Memo :

For setting the level of ease of face detection. [Setting Values: Low, Middle, RHigh]

For setting the margin to maintain status when the face that is being tracked is lost. Set to “Fast” to select another object immediately

if the face on the screen is lost. Set to “Slow

some time even if the face on the screen is lost. [Setting Values: Fast, RMiddle, Slow]

USER9], [LCD KEY▲], [LCD KEY▶],

AF&AE: Sets auto focus and exposure control for the face that is being tracked. AF: Sets

auto focus for the face that is being tracked.

(A P53 [Adjusting the Focusing by Face Detection] )

detection does not function when the “MF”

Face mode is enabled using the [AF/MF] selection button.

When “AF activated only when the “AF” mode is enabled using the [AF/MF] selection button. When “AF&AE operate when the “AF” mode is enabled using the [AF/MF] selection button, and when one or more of the items (Gain, Iris and Shutter) is set

to Auto mode.

Sensitivity

Hysteresis

” is specified, this function will be

” is specified, this function will

” to operate at the same position for

Camera Function Menu

AE/FAW Lock

For specifying the operation when any of the [USER1]-[

[LCD KEY▼], or [LCD KEY◀] items is set to “AE/FAW Lock”.

[Setting Values: FAW, RAE, AE/FAW]

Memo :

Preset Zoom Speed

For setting the speed to shift to the preset zoom position that is assigned to a user button. [Setting Values: 1 to 21 (R 11)]

USER9], [LCD KEY▲], [LCD KEY▶],

FAW: Fixes the FAW (Full-time Auto White Balance) setting to the value at the point the user button assigned with “

AE: Use

this feature to fix a value to the Auto function of Gain, Iris, or Shutter when the user button that is assigned “AE/FAW Lock” is pressed.

AE/FAW: Use this feature to fix the setting for the FAW (Full-time Auto White Balance) and the Auto function of Gain, Iris, or Shutter to the value at the

point the user button assigned with “AE/FAW

Lock” is pressed.

feature only works when Iris, Shutter, Gain

This or White Balance is set to Auto mode. “AE/FAW Lock” is canceled when the user

button assigned with “AE/FAW Lock” is pressed, or when any of the functions that can

be locked is operated regardless of the mode (Manual or Auto).

AE/FAW Lock” is pressed.

Expanded Focus

For specifying the operation when any of the [USER1]-[

[LCD KEY▼], or [LCD KEY◀] items is set to “Expanded Focus”.

[Setting Values: RToggle, Momentary, Limited Time]

USER9], [LCD KEY▲], [LCD KEY▶],

Toggle: Pressing the user button assigned with “Expanded Focus

“Expanded Focus” function to on or off. Momentary:

The

“Expanded Focus” function is enabled

during the interval while the user button assigned with “Expanded Focus” is pressed.

Limited Time: Activates the timer. During

autofocus, the [Expanded Focus] feature

turns off about 3 seconds after it is turned on. During manual focus, the [Expanded Focus]

feature turns off about 3 seconds after you stop operating the focus ring.

” each time switches the

Menu Display and Detailed Settings

Camera Function Menu

Camera Process Menu

Menu screen for adjusting the quality of camera images. This item cannot be selected in the Media mode.

Detail

For adjusting the contour (detail) enhancement level. Increasing the value increases the sharpness of the contour. [Setting Values: -10 to +10, Off (R0)]

Adjust...

For specifying the detailed settings of the contour (detail).

(A P102

Memo :

Menu Display and Detailed Settings

Master Black

For serves as the reference black. Increasing the value increases the pedestal. [Setting Values: -50 to +50 (R0)]

Black Toe

Process bright and dark areas in the image to adjust the overall balance of contrast. For altering the gain of dark areas. Adjust this item according to the condition of the captured video signals.

[Setting Values: Stretch, RNormal, Compress]

Memo :

[Detail/Adjust Item] )

This

item cannot be selected when [Detail] is set

to “Off”.

adjusting the pedestal level (master black) that

the dark areas according to the balance of

Stretch: Increases the gain of dark areas in an image to stretch the signals of these areas only, thereby showing the contrast between bright and dark areas more clearly. Specify the amount of stretch with [Stretch

Level Normal:

Normal condition. Compress: Compresses the gain of dark areas to increase the contrast when the entire image appears bright and contrast is weak. Specify the compression amount with [Compress Level

When [WDR] is set to other than “Off”, this item appears as

“---” and cannot be selected.

Stretch Level

Stretch amount increases when a larger value is specified. [Setting Values: 1 to 5 (R 3)]

Memo :

This item is displayed only when set to “Stretch”. Otherwise, this item appears as “---” and cannot be selected.

Compress Level

Compression amount increases when a larger value is specified. [Setting Values: 1 to 5 (R 3)]

Memo :

This item is displayed only when set to “Compress”. Otherwise, this item appears as “---” and cannot be selected.

Knee

For specifying the “Knee” operation, which compresses

show the gradation of the highlighted portion. To check the gradation of a bright area, set to “Manual”

and adjust the knee point (starting point of knee operation) manually.

Manual: Enables [Level].

Auto: Adjusts the knee point automatically according to the luminance level.

[Setting Values: Manual, RAuto]

Memo :

When [WDR] is set to other than appears as “---” and cannot be selected.

Level

For setting the starting point (knee point) of knee compression when [Knee] is set to “Manual

[Setting Values: R100.0%,97.5%,95.0%,92.5%,

90.0%,87.5%,85.0%] Memo :

When [Knee] is set to other than “Auto”, or [WDR] is set to other than “Off”, this item

appears as

video signals beyond a certain level to

manual adjustment of knee point using

“---” and cannot be selected.

[Black Toe] is

“Off”, this item

”.

Camera Process Menu

100

JVC GY-HM200 User manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Safety Precautions

Contents

Main Features

Precautions for Proper Use

Operation Modes

Names of Parts

Side Control Panel

Side Terminal Section

Rear Terminal

LCD Monitor

Handle Unit K

Lens Section

Basic System Diagram

Attaching the Handle Unit K

Adjusting the Grip Belt

Attaching the External Microphone O

Preparations

Settings and Adjustments Before Use

Attaching/Detaching the Lens Cap

Attaching/Detaching the Hood

Attaching the Tripod

Power Supply

Using a Battery Pack

Using AC Power (DC IN Power)

Power Status Display

Turning On/Off the Power

Initial Settings

Display Screen

Displays on the LCD Monitor and Viewfinder

Status Screen

USB Mode Screen

Remote Edit Mode Screen K

Warning Display

Adjusting the LCD Monitor

Adjusting the LCD Monitor and Viewfinder

Adjusting the Viewfinder

Tally Lamp

Assignment of Functions to User Buttons

SD Card

Usable Cards

Formatting (Initializing) SD Cards

Restoring the SD Card

Clips Recorded to SD Cards

Operation Lock Feature

Shooting

Basic Shooting Procedures

Zoom Operation

Focus Operation

Adjusting the Focusing by Face Detection

Adjusting the Brightness

Adjusting the Iris

Setting the Gain

Setting the Electronic Shutter

Setting the ND Filter

Adjusting the White Balance

Using the Image Stabilizer

Adjusting the Camera Image

Audio Recording

Monitoring Audio Sound During Recording Using a Headphone

Time Code and User’s Bit

Setting Time Code Generator

Setting the User’s Bit

Setting Zebra Pattern

Viewing Recorded Videos Immediately (Clip Review)

Series Rec

Dual Rec

Recording Simultaneously at Two Different Definitions

Backup Rec

Special Recording

Pre Rec

Clip Continuous Rec

Frame Rec

Interval Rec

Splitting the Clips Freely (Clip Cutter Trig)

Playing Recorded Clips
