JVC GR-DVX10EG, GR-DVX10EK, GR-DVX8EG, GR-DVX8EK, GR-DVX9EG Parts List

...

Download

SECTION 5

P ARTS LIST

SAFETY PRECAUTION

Parts identified by the ! symbol are critical for safety. Replace only with specified part numbers.

5.1 PACKING AND ACCESSORY ASSEMBLY <M1> The instruction manual to be provided with this product will differ according to the destination.

39 38

37 32 31

FINAL ASSY <M2>

5 (Refer to sec.6)

LABEL

(SERIAL)

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

P ACKING AND ACCESSOR Y ASSEMBLY

1 LY31717-004A PACKING CASE,B

LY31717-006A PACKING CASE,D L Y31717-020A PACKING CASE,F LY32032-001A PACKING CASE,C LY32032-002A PACKING CASE,A

LY32032-003A PACKING CASE,E 2 LY20588-001A CUSHION 3 LY30023-003A POLY BAG

4 LY31174-003B BATTERY PACK,BN-V507U-E

5 LY20603-002B

! !

6 LY20590-004A DOCKING STATION,CU-V502E,C,D,E,F

7 LY20543-002A REMOTE CONTROL UNIT,RM-V716U 8 LY31133-013A CD ROM,C,D,E,F

9 QAM0262-002 MULTIMEDIA CARD,C,D,E,F 10 L Y31176-005B DC CORD 15 QAM0120-001 CABLE ASSY,AUDIO/VIDEO CABLE 16 QQR0918-002 CORE FILTER 17 QAM0084-001 PC CONNECTION CABLE 18 QQR0918-002 CORE FILTER 19 QAM0214-001 RM(EDITING)CABLE 20 QQR0491-002 CORE FILTER 23 – BATTERY,AAA(R03),X2 24 QAM0129-001 JLIP CABLE 25 QQR0491-002 CORE FILTER,C,D,E,F

26 QPGA017-03005 POLY BAG 27 QPA02003006 POLY BAG,A,C,E

28 YQ43558 CLEANING CLOTH

30 LYT0629-001A IB(EN),C,D,E,F

! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! !

LY20603-003B

LY20590-005A DOCKING STATION,CU-V503E,A,B

L Y31133-015A CD ROM,A,B

QQR0855-003 NOISE FILTER,A,B

YQM30061-3 POLY BAG,B,D,F

LYT0629-002B IB(GE),C,E

LYT0629-003B IB(FR),C,E

LYT0629-004A IB(DU),C,E

LYT0629-005A IB(SP),C,E

LYT0629-006A IB(IT),C,E

LYT0629-007A IB(DA),C,E

LYT0629-008A IB(FI),C,E

LYT0629-009A IB(SW),C,E

LYT0629-010A IB(NO),C,E

LYT0629-011A IB(RU),C,E

LYT0629-012A IB(CZ),C,E

LYT0629-013A IB(PO),C,E

LYT0629-014A IB(HU),C,E

LYT0633-001A IB(EN),A,B

LYT0633-002A IB(GE),A

LYT0633-003A IB(FR),A

LYT0633-004A IB(DU),A

LYT0633-005A IB(SP),A

LYT0633-006A IB(IT),A

LYT0633-007A IB(DA),A

LYT0633-008A IB(FI),A

LYT0633-009A IB(SW),A

LYT0633-010A IB(NO),A

LYT0633-011A IB(RU),A

AC ADAPTER CHARGER,AA-V51EG,A,C,E AC ADAPTER CHARGER,AA-V51EK,B,D,F

<M1>

! ! !

31 LYT0584-004A IB(PRINTER.EN),C,D,E,F

32 LYT0500-001A IB(SOFT.SETUP),A

! ! !

33 LYT0378-003A SHEET(AGREMENT) 34 BT-54008-2 GUARANTY CARD,B,D,F

35 PEMC1000-01-02 CONNECTOR,CABLE ADAPTER 36 QQR0918-002 CORE FILTER,X2 37 LYT0194-001A Q.CARD(JUK),B,D,F 38 YU30878 REGIST.CARD,B,D,F 39 LYT0162-022A ACC. LEAFLET

LYT0633-012A IB(CZ),A LYT0633-013A IB(PO),A LYT0633-014A IB(HU),A

LYT0584-005A IB(PRINTER.FR),C,E LYT0584-006A IB(PRINTER.SP),C,E LYT0629-016A IB(PRINTER.GE),C,E LYT0629-018A IB(PRINTER.DU),C,E LYT0629-020A IB(PRINTER.IT),C,E LYT0629-021A IB(PRINTER.DA),C,E LYT0629-022A IB(PRINTER.FI),C,E LYT0629-023A IB(PRINTER.SW),C,E LYT0629-024A IB(PRINTER.NO),C,E LYT0629-025A IB(PRINTER.RU),C,E LYT0629-026A IB(PRINTER.CZ),C,E LYT0629-027A IB(PRINTER.PO),C,E LYT0629-028A IB(PRINTER.HU),C,E

LYT0501-001A IB(SOFT.SETUP),B LYT0589-001A IB(SOFT.SETUP),C,E LYT0643-001A IB(SOFT.SETUP),D,F

BT-54013-1 WARRANTY CARD,A,C,E

MODEL MARK GR-DVX8EG A GR-DVX8EK B GR-DVX9EG C

GR-DVX9EK D GR-DVX10EG E GR-DVX10EK F

• INSTRUCTIONS

EN....... ENGLISH

GE ...... GERMANY

FR .......FRENCH

DU ...... DUTCH

SP .......SPANISH

IT ........ ITALIAN

DA....... DANISH

FI ........ FINNISH

SW...... SWEDISH

NO ...... NORWEGIAN

RU ...... RUSSIAN

CZ .......CZECH

PO ...... POLISH

HU ...... HUNGARIAN

5-1 5-2

5.2 FINAL ASSEMBLY <M2>

123

198

154

169

201

j j

162

117

107

103

j j

199

200

224

223

225

169

161

115

197

163

173

101A

197

RATING

LABEL

222

163

122

102

129

101B

183

169

ONLY USE FOR

153

182

175

101

STROBE

<07>

176

C,D,E,F

152

146D

151

171

146E

170

172

AUDIO VF

<08>

210

146C

146A

146B

146F

170

227

146

215

212

135

170

f f

172

170

116

214

121E

146G

121F

180

226

146H

ONLY USE FOR

C,D,E,F

121D

181

180

111

157

109

164

147

164

165

JACK <09>

181

MMC <06>

121D

106D

106A

181

106F

181

177

251E

251J

121

121B

EJECT

<12>

121C

106J

121A

181

106H

251C

205

203

133

ELECTRONIC

VIEWFINDER

<M4>

193

MAIN

<01>

136

f f

130

132

209

204

130

127

204

125

137

174

216

ONLY USE FOR

A,B

141

138

134

139

217

ONLY USE FOR

C,D,E,F

242

156

241

184

242

178

114

178

158

106

106B

106E

106G

OPTICAL BLOCK

251E

251C

251F

251C

140

197

SECTION

251

251B

251G

179

112

108

113

229A

CCD <03>

251H

251K

251C

251A

196

110

MDA <02>

195

179

229

155

244

231

245

192

166

W/B

<11>

MECHANISM

<M3>

221

126A

166

167

207

168

126

197

191

128

124

202

191

208

211

MONITOR

206

213

<M5>

242

243

194

228

230

131

232

5-3 5-4

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

FINAL ASSEMBLY <M2>

101 LY20576-004B LOWER CASE ASSY,A,B

101A LY42536-001A SHEET(LOWER) 101B LY42259-001A SHEET(MIC C) 102 LY31764-001A BKT(TOP) 103 LY41675-001B RUBBER 106 LY20601-001B ARM ASSY 106A LY20594-001A BRACKET(ARM) 106B LY30001-023A TENSION SPRING 106D LY30018-056A SPECIAL SCREW,X2 106E LY42268-001A SPACER(SPK) 106F LY31678-001A BRACKET(HOOK) 106G LY31676-001A KNOB(EJECT) 106H LY31665-001A PLATE(LOCK) 106J L Y30018-015A SPECIAL SCREW 107 LY30029-083A SPACER(A) 108 QAS0053-001 SPEAKER 109 LY30029-084A SPACER(A) 110 LY31762-001A HOLDER(SPK) 111 LY30029-085A SPACER(A) 112 LY40301-001A SPACER(SPK) 113 LY30029-086A SPACER(A) 114 LY31680-001B ZOOM UNIT,C,D

115 LY31671-001B MICROPHONE 116 LY30029-083A SPACER(A) 117 LY30029-094A SPACER(A) 121 LY20602-001A CASS.COVER ASSY,C,D,E,F

121A LY31675-001A PLATE(HINGE),C,D,E,F 121B LY42261-001A BRACKET(HINGE),C,D,E,F 121C LY30014-009A SHAFT(C),C,D,E,F 121D LY30018-026A SPECIAL SCREW,X2 121E LY20599-001A COVER(C.C),C,D,E,F

121F LY42434-001A SHEET(COVER) 122 LY41588-001A HOOK(OPE) 123 LY31745-001B GRIP BELT 124 LY10236-001A UPPER CASE 125 LY30029-091A SPACER(A),X2 126 LY42270-001A BATT.LOCK ASSY 126A LY30002-015A COMPRES. SPRING 127 LY31102-001A KNOB(LOCK) 128 LY41397-001A PLATE(KNOB) 129 LY42326-001A BRACKET(L/U) 130 LY42350-001A FOOT,X2 131 LY42272-001A SHEET(UPPER) 132 LY31682-001B LOCK(MONITOR)

133 LY41605-003A LABEL(UPPER) 134 LY31684-001A SUB OPE ASSY,C,D,E,F 135 LY20600-001A CAMERA OPE UNIT,C,D

136 LY31906-001A DECK OPE ASSY 137 LY41393-004A COVER(JIG CONN) 138 LY41701-002A SHEET(CAUTION)1 139 LY42163-003A SHEET(CAUTION)2 140 LY30029-099A SPACER(A) 141 LY42406-001A SHEET,A,B

146 LY20581-004E FRONT COVER ASSY,A,B

! !

146A LY42276-001B INDICATOR 146B LY42277-001A WINDOW(IR) 146C LY42278-001A WINDOW(STB),C,D,E,F 146D LY31687-001A PAD 146E LY42280-001A SHEET(DF) 146F LY42281-001A COVER(DV)ASSY 146G LY42286-001A HINGE(AV) 146H LY42285-001A COVER(AV),E,F

147 LY31761-002B FRONT COVER2 151 LY31767-001A HOOD ASSY,C,D

152 LY31691-001B HOOK 153 LY42287-001A STUD(HOOK) 154 LY42404-001A SHEET 155 LY40698-002A LABEL(HOUSING) 156 LY40699-002A LABEL(PUSH) 157 LY30016-0H5A SPACER-A 158 LY30029-074A SPACER(A) 161 QYSPSPT1740R SCREW

LY20576-005B LOWER CASE ASSY,C,D,E,F

L Y31680-002B ZOOM UNIT,A,B LY31680-003B ZOOM UNIT,E,F

L Y20602-003A CASS.COVER ASSY,A,B

LY20599-002A COVER(C.C),A,B

LY20600-002A CAMERA OPE UNIT,E,F LY20600-003A CAMERA OPE UNIT,A,B

LY20581-005E FRONT COVER ASSY,C,D LY20581-008A FRONT COVER ASSY,E,F

LY42285-002A COVER(AV),A,B,C,D

L Y31767-001B HOOD ASSY,A,B,E,F

162 LY30018-063A SPECIAL SCREW 163 QYSPSPT1740R SCREW,X2 164 QYSPSGT1740Z SCREW,X4 165 QYSPSGT1740Z SCREW 166 QYSPSPT1725Z SCREW,X2 167 LY30018-068A SPECIAL SCREW 168 LY30018-0B9A SPECIAL SCREW 169 LY30018-032A SPECIAL SCREW,X3 170 LY30018-020A SPECIAL SCREW,X4 171 LY30018-020A SPECIAL SCREW 172 LY30019-007B SPECIAL SCREW,X2 173 LY30018-060A SPECIAL SCREW 174 LY30018-093A SPECIAL SCREW 175 LY30018-026A SPECIAL SCREW 176 LY30018-060A SPECIAL SCREW,C,D,E,F 177 LY30018-043B SPECIAL SCREW 178 LY30018-032A SPECIAL SCREW,X2 179 LY30018-096A SPECIAL SCREW,X2 180 QYSPSPT1720R SCREW,X3 181 LY30018-066A SPECIAL SCREW,X6 182 LY30018-0B5A SPECIAL SCREW,X2 183 QYSPSPT1720R SCREW 184 LY30018-0B5A SPECIAL SCREW 191 LY30019-026A SPECIAL SCREW,X2 192 YQ43893-4 MINI SCREW 193 QYSPSPT1735R SCREW 194 YQ43893-4 MINI SCREW 195 QYSPSPT1735R SCREW 196 LY30018-070A SPECIAL SCREW 197 LY30018-049A SPECIAL SCREW,X5,A,B

LY30018-070A SPECIAL SCREW,X5,C,D,E,F 198 LY30019-023A SPECIAL SCREW 199 QYSPSPT1735R SCREW 200 QYSPSPT1720R SCREW 201 LY30018-070A SPECIAL SCREW 202 QYSPSPT1735R SCREW 203 QYSPSPT1735R SCREW 204 QYSPSPT1730R SCREW,X2,C,D

QYSPSPT1735R SCREW,X2,A,B,E F 205 LY30018-060A SPECIAL SCREW,A,B,C,D

LY30018-0B7A SPECIAL SCREW,E,F 206 LY30018-060A SPECIAL SCREW,A,B,C,D

LY30018-0B7A SPECIAL SCREW,E,F 207 QYSPSPT1735R SCREW 208 QYSPSPT1735R SCREW 209 LY30018-0B8A SPECIAL SCREW 210 LY30018-0B7A SPECIAL SCREW 211 QYSPSGT1780R SCREW,X2 212 LY30018-0B8A SPECIAL SCREW 213 QYSPSGT1712R SCREW 214 QYSPSPT1735R SCREW 215 LY30019-022A SPECIAL SCREW 216 QYSPSPT1735R SCREW,X2 217 LY30018-070A SPECIAL SCREW 221 LY20582-001A BRACKET(MECHA) 222 LY31758-001A FPC ASSY(M.CN) 223 LY31693-001A BASE(T.P.) 224 LY42290-001A BRACKET(BASE)1 225 LY42291-001A BRACKET(BASE)2,A,B,E,F

LY42291-001B BRACKET(BASE)2,C,D 226 QAL0240-001 FPC,MDA CN208-MMC CN601 227 WJT0034-001A E-CARD WIRE,AU/VF CN803-D.OPE 228 LY42756-001B HEAT TAPE 229 LY42748-001B SHIELD ASSY 229A LY42677-001A SHEET(CCD) 230 LY31696-001A SHIELD PLATE 231 LY30029-095A SPACER(A) 232 LY42770-001A SPACER(OP.M) 241 LY30483-001Q CASSETTE HOUSING ASSY 242 YQ43893-4 MINI SCREW,X3 243 LY41430-005A SPACER 244 LY30029-090A SPACER(A) 245 LY41430-004A SPACER

– OPTICAL BLOCK SECTION –

251 LYH20156-002A OPTICAL BLOCK ASSY 251A LY31572-001A ZOOM MOTOR 251B LY31571-001A FOCUS MOTOR 251C LY30727-002A SCREW,X5 251E LY30727-001A SCREW,X2 251F LY42110-001A OPTICAL LPF 251G LY30721-001A SPACER RUBBER 251H QYSPSGU1750Z SCREW,X2 251J LY31573-001A IRIS MOTOR UNIT 251K YS40168H CCD BASE ASSY

5-5

5.3 MECHANISM ASSEMBLY

418

419

<M3>

405

BEWARE OF BOGUS PARTS

Parts that do not meet specifications may cause trouble in regard to safety and performance. We recommend that genuine JVC parts be used.

475

407

449

448

439

436

437

414

413

414

469

476

469

406 480

406

408

406

438

463

442

426

450

465

443

452

423

417

451

466

422

458

424

446

459

453

465

447

457

421

445

456

467

455

420

454

444

457

425

440

416

415

472

478

462

428

427

401

460

411

441

461

411

470

411

410

409

473

429

435

474

430

404

431

434

468

403

402

432

433

5-6

464

Classification Part No. Symbol in drawing Grease KYODO-SH-P AA Oil YTU94027 BB

471

NOTE:The section marked in AA and BB indicate

lubrication and greasing areas.

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

MECHANISM ASSEMBLY <M3>

401 LY10077-001L MAIN DECK ASSY 402 LY30436-001F SLANT P.ARM AS 403 YQ44246 SLIT WASHER 404 LY30438-001B CLEANER ARM ASSY 405 LY10080-001V RAIL ASSY 406 YQ44246 SLIT WASHER,X3 407 LY40353-001D GUIDE ROLLER(S)ASSY 408 LY30002-006C COMPRES. SPRING 409 QAR0026-002 CAPSTAN MOTOR 410 LY30504-001C CATCHER(T)ASSY 411 YQ43893 MINI SCREW,X4 413 LY30448-001G MOT OR BKT ASSY 414 YQ43893 MINI SCREW,X2 415 LY30449-001C WORM WHEEL 416 YQ44246 SLIT WASHER 417 LY40496-001C ROTARY ENCODER 418 YQ43893 MINI SCREW 419 YQ44246 SLIT WASHER 420 LY40614-001B GEAR HOLDER 421 YQ43893-6 MINI SCREW 422 LY30450-001C MAIN CAM 423 LY30840-001A BRAKE CTL PLATE 424 YQ43893 MINI SCREW 425 LY40373-001C TC LEVER ASSY 426 LY30452-001G SLIDE LEVER ASSY 427 LY30454-001A CONNECT GEAR 428 YQ44246 SLIT WASHER 429 LY30455-001B SUB CAM 430 YQ43893 MINI SCREW 431 LY30456-001F PINCHROLLER ARM ASSY 432 YQ44246 SLIT WASHER 433 LY30459-001A CHARGE ARM ASSY 434 YQ44246 SLIT WASHER 435 LY40387-001D BC LEVER ASSY 436 LY40389-001D R.D.PULLEY ASSY 437 YQ44246-2 SLIT WASHER 438 LY40391-001G CENTER GEAR ASSY 439 LY40396-001A TIMING BELT 440 LY40413-001A COLLAR,X2 441 LY30468-001E GUIDE ARM ASSY 442 LY30618-001C SLIDE GUIDE PLATE ASSY 443 YQ43893-2 MINI SCREW 444 LY40420-001J TENSION ARM ASSY 445 YQ44246 SLIT WASHER 446 LY30471-001D P AD ARM ASSY 447 YQ44246 SLIT WASHER 448 LY40432-001H IDLER ARM ASSY 449 YQ44246-2 SLIT WASHER 450 LY30476-001A GUIDE PIN(S) 451 YQ43893 MINI SCREW 452 LY40441-001B REEL DISK(SUPPLY)ASSY 453 YQ44246 SLIT WASHER 454 LY40443-001B REEL DISK(TAKE-UP)ASSY 455 YQ44246 SLIT WASHER 456 LY30477-001F CTL PLATE ASSY 457 YQ44246 SLIT WASHER,X2 458 LY40444-001E LOADING BRAKE ASSY 459 YQ44246 SLIT WASHER

460 LY40452-001C SUB BRAKE ASSY 461 YQ44246 SLIT WASHER 462 LY30479-001E RELEASE GUIDE ASSY 463 YQ44246 SLIT WASHER 464 LY20146-001H REEL COVER ASSY 465 YQ43893-4 MINI SCREW,X2 466 YQ43893 MINI SCREW 467 YQ44246 SLIT WASHER 468 YDV2086I DRUM ASSY 469 YQ43893 MINI SCREW,X3 470 LY20138-001D PWB HOLDER 471 YQ43893 MINI SCREW,X2 472 LY10082-001K SLIDE DECK ASSY 473 LY30462-001B LOADING GUIDE 474 YQ43893 MINI SCREW 475 YMA0025M MECHA(A)ASSY 476 LY30016-0M1A SPACER-A 478 LY30496-001T DECK ASSY 480 LY41573-001A WASHER

5-7

5.4 ELECTRONIC VIEWFINDER ASSEMBLY

<M4>

300

301

303

314

312

313

310

309

311

302

308

305

307

306

304

302B

302A

302B

308

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

ELECTRONIC VIEWFINDER ASSEMBLY <M4>

300 LY31749-001C VF UNIT 301 PTY31749-001 EYE CUP 302 PTY31749-011 CASE/CAP ASSY 302A PTY31749-012 CAP(VF) 302B LY30029-027A SCREW,X2 303 PTY31749-021 FRAME(VF) 304 PTY31749-031 GUIDE(VF)

5-8

305 PTY31749-015 LEVER(VF) 306 LY30018-037A SCREW 307 LY30018-019A SCREW 308 LY30018-055A SCREW,X2 309 PTY31749-041 EYE PIECE SUB ASSY 310 PTY31749-051 HOLDER(LCD) 311 PTY31749-081 SCREW 312 QLD0117-001 LCD MODULE 313 PTY31749-061 B/L SUB ASSY 314 PTY31749-071 FFC

5.5 MONITOR ASSEMBLY

<M5>

500

516

506

507

516

504

504C

514

504C

514

504A

504E

519

517

504B

504D

MONITOR

<04>

512

515

505

508

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

MONITOR ASSEMBLY <M5>

500 LYH20164-004C MONITOR ASSY,A,B

! !

501 LY20584-001B MONITOR CASE 502 LY30029-046B SPACER(A) 503 LY30029-048A SPACER(A)

504 LY20585-004A MONITOR COVER ASSY,C,D

! !

504A LY31699-001A BRACKET(MON.) 504B LY40162-001A BKT 504C LY30018-057A SPECIAL SCREW,X2

L YH20164-005B MONITOR ASSY,C,D L YH20164-008A MONITOR ASSY,E,F

LY20585-006A MONITOR COVER ASSY,A,B LY20585-008A MONITOR COVER ASSY,E,F

513

518

511

502

520

501

504D LY30029-047A SPACER(A) 504E LY42295-001A PLATE(MON.) 505 LY31701-001B HINGE ASSY 506 LY31702-001A HINGE COVER(U) 507 LY40663-002A MAGNET 508 LY31703-001A HINGE COVER(L) 511 QLD0138-001 LCD MODULE 512 QLL0087-001 BACK LIGHT 513 LY31756-001A FPC ASSY(MONI) 514 LY30018-0B1A SPECIAL SCREW,X2 515 QYSPSPT1730R SCREW 516 LY30018-060A SPECIAL SCREW,X2 517 QYSPSPT1735R SCREW 518 LY30029-076A SPACER(A) 519 LY30029-093A SPACER(A) 520 LY30029-0A1A SPACER(A)

503

5-9

MODEL MARK MODEL MARK

5.6 ELECTRICAL PARTS LIST

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

IC8004 MBV800TA90PBA02 IC(MICRO C ROM),C,D

GR-DVX8EG A GR-DVX9EK D GR-DVX8EK B GR-DVX10EG E GR-DVX9EG C GR-DVX10EK F

MBV800TA90PBA08 IC(MICRO C ROM),E,F

MAIN BOARD ASSEMBLY <01>

IC8005 TC7S00FU IC,C,D,E,F

or SN74AHC1G00K IC,C,D,E,F

PW YB10284D-01 MAIN BOARD ASSY,C,D

YB10284E-02 MAIN BOARD ASSY,A,B

YB10284H-01 MAIN BOARD ASSY,E,F IC1001 YQ44860A CSP IC ASSY IC1002 MB90097PFV133 IC(MICRO C ROM) IC1003 NM25C160LZEM8 IC

or X25170S8I-2.5-X IC or X25330S8I-2.5-X IC

or AT25160N-10SC-X IC IC1004 RS5C314 IC IC1005 TC7W08FK IC IC1006 TC7W04FK IC IC1008 TC7W66FK IC IC1009 TC7W08FK IC IC1101 TA75W01FU IC IC1401 YQ44872A CSP IC ASSY IC1402 TC7W14FK IC IC1403 TC7W66FK IC IC1405 TC4W53FU IC IC2701 SN74AHC1G66K IC IC2751 TC74HC4052AFT IC IC3001 JCY0106-2 IC IC3002 M51V18165D-50LS IC IC3004 TC7SL00FU IC(DIGITAL) IC3005 SN74AHC1G04K IC IC3101 PDI1394P11AEC IC IC3201 JCY0107-2 IC IC3202 TC7SH00FU IC(DIGITAL) IC3203 MM1385UN IC IC3301 JCY0108 IC IC3501 AN3731FHQ IC(DIGITAL) IC3701 NJM2538V IC IC3702 MM1385HN IC IC3801 JCP8019 IC,E,F IC3851 MM1504XN IC,E,F IC4201 HD49325BHF IC IC4202 RH5RZ31CA IC IC4301 YQ44827A IC IC4302 MM1385PN IC IC4303 SN74AHC1G08K IC,E,F IC4304 TC7WH123FK IC,A,B,C,D IC4305 TC7W04FK IC,A,B,C,D IC4401 M62366GP IC

IC5001 JCY0138 IC IC5002 MM1385DN IC IC5004 W194-70G-X IC IC6001 S-80842ANNP-W IC IC6002 S-81233SG-QF-X IC IC6003 S-81330HG-KB-X IC IC6004 S-80826ANNP-W IC IC6101 BD9712KU IC IC6401 MM1385XN IC IC6601 TC7W74FK IC,C,D,E,F

or TC7WH74FK IC,C,D,E,F IC8001 JCY0121-4 IC,C,D,E,F IC8002 MSM56V16160D1LS IC,C,D,E,F IC8003 M32310D5WG IC,C,D,E,F

IC8006 MM1385NN IC,C,D,E,F IC8007 MM1385EN IC,C,D,E,F IC8008 TC7WHU04FK IC,C,D,E,F IC8009 TC7WH34FK IC,C,D,E,F IC8101 TMS320DA050-G IC,C,D,E,F IC8102 TC7MA2244FK IC,C,D,E,F IC8103 TC7S04FU IC,C,D,E,F Q1401 DTA114EE TRANSISTOR

or RN2102 TRANSISTOR Q1402 UMC3N TRANSISTOR Q1403 UMC3N TRANSISTOR Q1405 DTC143EE TRANSISTOR Q1406 2SC4738FT/G/-X TRANSISTOR Q1407 DTC124EE TRANSISTOR Q1408 RN1104FT TRANSISTOR Q2701 RN1104FT TRANSISTOR Q2703 2SC4738FT/G/-X TRANSISTOR Q2704 2SC4738FT/G/-X TRANSISTOR Q2705 2SC4738FT/G/-X TRANSISTOR Q2751 RN1104FT TRANSISTOR Q2752 2SA1832FT/G/-X TRANSISTOR Q2753 2SA1832FT/G/-X TRANSISTOR Q2754 2SC4738FT/G/-X TRANSISTOR Q2755 UMX1N PAIR TRANSISTOR Q2756 2SA1832FT/G/-X TRANSISTOR Q2757 RN2104FT TRANSISTOR Q2758 RN1104FT TRANSISTOR Q2759 RN1104FT TRANSISTOR Q2760 2SC4738FT/G/-X TRANSISTOR Q3501 2SC4226/4/-X TRANSISTOR Q3502 2SD1979/S/-X TRANSISTOR Q3503 2SD1979/S/-X TRANSISTOR Q3504 2SC4226/4/-X TRANSISTOR Q3551 2SA1577/QR/-X TRANSISTOR Q3552 RN1104FT TRANSISTOR Q3701 RN1104FT TRANSISTOR Q3705 2SC4738FT/G/-X TRANSISTOR,E,F Q3706 RN1104FT TRANSISTOR,E,F Q3707 UMT2N PAIR TRANSISTOR Q3708 2SA1832FT/G/-X TRANSISTOR Q3709 2SA1832FT/G/-X TRANSISTOR Q3710 2SA1832FT/G/-X TRANSISTOR Q3711 2SC4738FT/G/-X TRANSISTOR Q3712 UMA2N TRANSISTOR Q3713 RN1104FT TRANSISTOR Q3714 RN1104FT TRANSISTOR,E,F Q3731 2SA1832FT/G/-X TRANSISTOR Q3801 HN1B04FU/YG/-X PAIR TRANSISTOR,E,F Q3851 UMC4N TRANSISTOR,E,F Q3852 HN1B04FU/YG/-X PAIR TRANSISTOR,E,F Q3853 2SC4738FT/G/-X TRANSISTOR,E,F Q3855 2SA1832FT/G/-X TRANSISTORE,F Q3856 HN2C01FU/YG/-X PAIR TRANSISTOR,E,F Q3857 HN1B04FU/YG/-X PAIR TRANSISTOR,E,F Q3858 DTC114EE TRANSISTOR,E,F Q4351 2SA1832FT/G/-X TRANSISTOR Q4352 UMT2N PAIR TRANSISTOR

5-10

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

Q4353 UMT2N PAIR TRANSISTOR Q4354 2SA1832FT/G/-X TRANSISTOR Q6001 2SJ501 MOS FET Q6002 2SK3019 MOS FET

or 2SK1830 MOS FET Q6003 2SJ347 MOS FET Q6004 2SK3019 MOS FET

or 2SK1830 MOS FET Q6005 RN1104FT TRANSISTOR Q6006 2SJ501 MOS FET Q6007 RN47A3 TRANSISTOR Q6103 NDS352AP MOS FET Q6104 NDS352AP MOS FET Q6105 NDS352AP MOS FET Q6106 NDS352AP MOS FET Q6107 NDS352AP MOS FET Q6108 NDS352AP MOS FET Q6109 NDS351AN MOS FET Q6110 NDS352AP MOS FET Q6112 NDS352AP MOS FET Q6113 NDS351AN MOS FET Q6201 HN1C01FU/G/-X PAIR TRANSISTOR Q6202 2SA1577/QR/-X TRANSISTOR Q6203 2SC4617/QR/-X TRANSISTOR Q6204 HN1A01FU/G/-X PAIR TRANSISTOR Q6205 2SC4617/QR/-X TRANSISTOR Q6206 2SA1774/QR/-X TRANSISTOR Q6207 DTC144EE TRANSISTOR Q6601 RN1104FT TRANSISTOR,C,D,E,F Q6602 2SA1873/YG/-X PAIR TRANSISTOR,C,D,E,F Q6611 2SA1832FT/G/-X TRANSISTOR,C,D,E,F Q6612 2SA1873/YG/-X PAIR TRANSISTOR,C,D,E,F Q6613 2SC4738FT/G/-X TRANSISTOR,C,D,E,F Q6614 RN1702 TRANSISTOR,C,D,E,F Q6615 UMC4N TRANSISTOR,C,D,E,F D1002 1SS357 SB DIODE D1401 DA221 DIODE D2751 DAN222 DIODE D2752 DA221 DIODE D2753 DA221 DIODE D4101 1SS355 DIODE

D6001 RB706D-40-X SB DIODE D6002 RB715F SB DIODE D6101 EP10LA03 SB DIODE D6102 EP10LA03 SB DIODE D6103 EP10LA03 SB DIODE D6106 EP10LA03 SB DIODE D6107 EP10LA03 SB DIODE D6108 EP10LA03 SB DIODE D6109 EP10LA03 SB DIODE D6201 1SS383 SB DIODE D6202 1SS383 SB DIODE D6203 MA8091/L/-X ZENER DIODE R1002 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1003 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1004 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1005 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1006 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1007 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1009 NRSA6AJ-393W MG RESISTOR 39kØ,1/16W R1010 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W

R1011 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1012 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R1013 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1015 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1016 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1017 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1018 NRSA6AJ-822W MG RESISTOR 8.2kØ,1/16W R1019 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1020 NRSA6AJ-123W MG RESISTOR 12kØ,1/16W R1021 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1023 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1024 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1025 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1028 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1030 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1031 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1032 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1033 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1034 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1035 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1036 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R1037 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1038 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1039 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1040 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1041 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1042 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1043 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1044 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1045 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1047 NRSA6AD-473W MG RESISTOR 47kØ,1/16W R1048 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1050 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1052 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1053 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1054 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1055 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R1056 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R1058 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1063 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1064 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1067 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1068 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1080 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1082 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1084 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1087 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1101 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R1102 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1104 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R1106 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R1107 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1108 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1109 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1401 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1402 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1403 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1404 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1408 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1409 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R1410 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W

5-11

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R1411 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1412 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R1415 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1417 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1418 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R1419 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R1420 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1422 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1423 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1424 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1425 NRSA6AJ-753W MG RESISTOR 75kØ,1/16W R1426 NRSA6AJ-334W MG RESISTOR 330kØ,1/16W R1427 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1428 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R1429 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1430 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1431 NRSA6AJ-683W MG RESISTOR 68kØ,1/16W R1432 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1433 NRSA6AJ-683W MG RESISTOR 68kØ,1/16W R1434 NRSA63J-101X MG RESISTOR 100Ø,1/16W R1436 NRSA63J-820X MG RESISTOR 82Ø,1/16W R1438 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1439 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1440 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1441 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1442 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1443 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1444 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1447 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1448 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R1449 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1450 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1451 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R1452 NRSA6AJ-334W MG RESISTOR 330kØ,1/16W R1453 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1454 NRSA6AJ-474W MG RESISTOR 470kØ,1/16W R1455 NRSA6AJ-154W MG RESISTOR 150kØ,1/16W R1456 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1457 NRSA6AJ-272W MG RESISTOR 2.7kØ,1/16W R1458 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W R1459 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1460 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1461 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1462 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1463 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1464 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1465 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1466 NRSA6AJ-474W MG RESISTOR 470kØ,1/16W R1469 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1470 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1471 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1472 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1474 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1478 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R1480 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R1481 NRSA6AJ-392W MG RESISTOR 3.9kØ,1/16W R1482 NRSA6AJ-272W MG RESISTOR 2.7kØ,1/16W R1483 NRSA6AJ-182W MG RESISTOR 1.8kØ,1/16W R1484 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R1485 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1486 NRSA6AJ-272W MG RESISTOR 2.7kØ,1/16W

R1487 NRSA6AJ-182W MG RESISTOR 1.8kØ,1/16W R1488 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R1489 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1490 NRSA6AJ-393W MG RESISTOR 39kØ,1/16W R1491 NRSA6AJ-273W MG RESISTOR 27kØ,1/16W R1495 NRSA6AJ-272W MG RESISTOR 2.7kØ,1/16W R1496 NRSA6AJ-182W MG RESISTOR 1.8kØ,1/16W R1497 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R1498 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1499 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R2701 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R2702 NRSA6AJ-100W MG RESISTOR 10Ø,1/16W R2705 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2706 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2709 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R2710 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2711 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2712 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2713 NRSA6AJ-822W MG RESISTOR 8.2kØ,1/16W R2714 NRSA6AJ-822W MG RESISTOR 8.2kØ,1/16W R2716 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2719 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2721 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2722 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2725 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2751 NRSA6AJ-820W MG RESISTOR 82Ø,1/16W R2752 NRSA6AJ-820W MG RESISTOR 82Ø,1/16W R2753 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2754 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2755 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2756 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2757 NRSA6AJ-564W MG RESISTOR 560kØ,1/16W R2758 NRSA6AJ-564W MG RESISTOR 560kØ,1/16W R2759 NRSA6AJ-821W MG RESISTOR 820Ø,1/16W R2760 NRSA6AJ-821W MG RESISTOR 820Ø,1/16W R2764 NRSA6AJ-182W MG RESISTOR 1.8kØ,1/16W R2766 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2767 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R2768 NRSA6AJ-564W MG RESISTOR 560kØ,1/16W R2769 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R2770 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2771 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2772 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2773 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2774 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3001 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R3002 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R3003 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R3004 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R3006 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3007 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3008 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3010 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3012 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3014 NRSA6AJ-124W MG RESISTOR 120kØ,1/16W R3015 NRSA6AJ-124W MG RESISTOR 120kØ,1/16W R3016 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3017 NRSA6AJ-272W MG RESISTOR 2.7kØ,1/16W R3018 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3019 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R3021 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W

5-12

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R3022 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3024 NRSA6AJ-100W MG RESISTOR 10Ø,1/16W R3026 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3031 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R3032 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R3033 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R3036 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R3037 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R3038 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3039 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3040 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3041 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3101 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R3102 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3103 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R3104 NRSA6AJ-394W MG RESISTOR 390kØ,1/16W R3105 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R3106 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R3107 NRSA6AJ-560W MG RESISTOR 56Ø,1/16W R3108 NRSA6AJ-560W MG RESISTOR 56Ø,1/16W R3109 NRSA6AJ-560W MG RESISTOR 56Ø,1/16W R3110 NRSA6AJ-560W MG RESISTOR 56Ø,1/16W R3111 NRSA6AJ-512W MG RESISTOR 5.1kØ,1/16W R3112 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3113 NRSA6AJ-474W MG RESISTOR 470kØ,1/16W R3114 NRSA6AJ-512W MG RESISTOR 5.1kØ,1/16W R3201 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3202 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3203 NRSA6AJ-272W MG RESISTOR 2.7kØ,1/16W R3204 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R3208 NRSA6AJ-820W MG RESISTOR 82Ø,1/16W R3209 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R3211 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R3303 NRSA6AJ-823W MG RESISTOR 82kØ,1/16W R3305 NRSA6AJ-121W MG RESISTOR 120Ø,1/16W R3306 NRSA6AJ-391W MG RESISTOR 390Ø,1/16W R3308 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R3310 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3312 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R3315 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3316 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3317 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R3318 NRSA6AJ-562W MG RESISTOR 5.6kØ,1/16W R3319 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3320 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3322 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R3323 NRSA6AJ-823W MG RESISTOR 82kØ,1/16W R3324 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R3325 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3326 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3327 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3328 NRSA6AJ-822W MG RESISTOR 8.2kØ,1/16W R3329 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R3330 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R3331 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R3332 NRSA6AJ-823W MG RESISTOR 82kØ,1/16W R3333 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R3334 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R3335 NRSA6AJ-822W MG RESISTOR 8.2kØ,1/16W R3336 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3337 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W

R3338 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R3339 NRSA6AJ-273W MG RESISTOR 27kØ,1/16W R3340 NRSA6AJ-393W MG RESISTOR 39kØ,1/16W R3341 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R3342 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3344 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R3349 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3350 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R3351 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3352 NRSA6AJ-562W MG RESISTOR 5.6kØ,1/16W R3353 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R3502 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R3503 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3504 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R3505 NRSA6AJ-680W MG RESISTOR 68Ø,1/16W R3506 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R3507 NRSA6AJ-123W MG RESISTOR 12kØ,1/16W R3508 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3509 NRSA6AJ-181W MG RESISTOR 180Ø,1/16W R3510 NRSA6AJ-181W MG RESISTOR 180Ø,1/16W R3511 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3512 NRSA6AJ-123W MG RESISTOR 12kØ,1/16W R3513 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R3514 NRSA6AJ-680W MG RESISTOR 68Ø,1/16W R3515 NRSA6AJ-100W MG RESISTOR 10Ø,1/16W R3516 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R3517 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3551 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R3552 NRSA6AJ-392W MG RESISTOR 3.9kØ,1/16W R3554 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R3555 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3556 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3701 NRSA6AJ-225W MG RESISTOR 2.2MØ,1/16W R3702 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3703 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3704 NRSA6AJ-121W MG RESISTOR 120Ø,1/16W R3705 NRSA6AJ-121W MG RESISTOR 120Ø,1/16W R3706 NRSA6AJ-821W MG RESISTOR 820Ø,1/16W R3707 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R3708 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3709 NRSA6AJ-680W MG RESISTOR 68Ø,1/16W R3710 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3711 NRSA6AJ-680W MG RESISTOR 68Ø,1/16W R3712 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3713 NRSA6AJ-680W MG RESISTOR 68Ø,1/16W R3714 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3718 NRSA6AJ-101W MG RESISTOR,E,F 100Ø,1/16W R3719 NRSA6AJ-472W MG RESISTOR,E,F 4.7kØ,1/16W R3720 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R3721 NRSA6AJ-203W MG RESISTOR 20kØ,1/16W R3722 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3723 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3724 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3725 NRSA6AJ-100W MG RESISTOR 10Ø,1/16W R3726 NRSA6AJ-100W MG RESISTOR 10Ø,1/16W R3727 NRSA6AJ-680W MG RESISTOR 68Ø,1/16W R3728 NRSA6AJ-821W MG RESISTOR 820Ø,1/16W R3731 NRVA6AD-681W CMF RESISTOR 680Ø,1/16W R3732 NRVA6AD-472W CMF RESISTOR 4.7kØ,1/16W R3733 NRVA6AD-332W CMF RESISTOR 3.3kØ,1/16W R3734 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W

5-13

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R3801 NRSA6AJ-101W MG RESISTOR,E,F 100Ø,1/16W R3802 NRSA6AJ-103W MG RESISTOR,E,F 10kØ,1/16W R3803 NRSA6AJ-103W MG RESISTOR,E,F 10kØ,1/16W R3804 NRSA6AJ-101W MG RESISTOR,E,F 100Ø,1/16W R3805 NRSA6AJ-472W MG RESISTOR,E,F 4.7kØ,1/16W R3806 NRSA6AJ-103W MG RESISTOR,E,F 10kØ,1/16W R3809 NRVA6AD-681W CMF RESISTOR,E,F 680Ø,1/16W R3810 NRVA6AD-102W CMF RESISTOR,E,F 1kØ,1/16W R3811 NRVA6AD-153W CMF RESISTOR,E,F 15kØ,1/16W R3812 NRVA6AD-123W CMF RESISTOR,E,F 12kØ,1/16W R3813 NRSA6AJ-222W MG RESISTOR,E,F 2.2kØ,1/16W R3814 NRVA6AD-820W CMF RESISTOR,E,F 82Ø,1/16W R3851 NRVA6AD-102W CMF RESISTOR,E,F 1kØ,1/16W R3852 NRSA6AJ-273W MG RESISTOR,E,F 27kØ,1/16W R3853 NRVA6AD-112W CMF RESISTOR,E,F 1.1kØ,1/16W R3854 NRSA6AJ-223W MG RESISTOR,E,F 22kØ,1/16W R3855 NRSA6AJ-223W MG RESISTOR,E,F 22kØ,1/16W R3856 NRSA6AJ-681W MG RESISTOR,E,F 680Ø,1/16W R3857 NRSA6AJ-821W MG RESISTOR,E,F 820Ø,1/16W R3858 NRSA6AJ-821W MG RESISTOR,E,F 820Ø,1/16W R3859 NRSA6AJ-102W MG RESISTOR,E,F 1kØ,1/16W R3861 NRVA6AD-102W CMF RESISTOR,E,F 1kØ,1/16W R3863 NRVA6AD-112W CMF RESISTOR,E,F 1.1kØ,1/16W R3869 NRSA6AJ-102W MG RESISTOR,E,F 1kØ,1/16W R3870 NRSA6AJ-471W MG RESISTOR,E,F 470Ø,1/16W R3871 NRSA6AJ-332W MG RESISTOR,E,F 3.3kØ,1/16W R3873 NRSA6AJ-102W MG RESISTOR,E,F 1kØ,1/16W R3874 NRSA6AJ-332W MG RESISTOR,E,F 3.3kØ,1/16W R3875 NRSA6AJ-0R0W MG RESISTOR,E,F 0Ø,1/16W R3876 NRSA6AJ-0R0W MG RESISTOR,E,F 0Ø,1/16W R4101 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R4208 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R4209 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4211 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4212 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4213 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4214 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4215 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4216 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4217 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4218 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4219 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4220 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4302 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R4303 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R4304 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R4305 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R4306 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R4308 NRSA6AJ-0R0W MG RESISTOR,A,B,C,D 0Ø,1/16W R4310 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4313 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4314 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4315 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4316 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4317 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4318 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R4320 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4321 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4322 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R4323 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R4327 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W

R4328 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4329 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4334 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4335 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4336 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4338 NRSA6AJ-470W MG RESISTOR 47Ø,1/16W R4339 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4340 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4341 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4342 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4345 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4347 NRSA6AJ-123W MG RESISTOR,A,B,C,D 12kØ,1/16W R4348 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R4351 NRSA6AJ-0R0W MG RESISTOR,A,B,C,D 0Ø,1/16W R4352 NRSA6AJ-0R0W MG RESISTOR,A,B,C,D 0Ø,1/16W R4353 NRSA6AJ-0R0W MG RESISTOR,A,B,C,D 0Ø,1/16W R4354 NRSA6AJ-0R0W MG RESISTOR,A,B,C,D 0Ø,1/16W R4355 NRVA6AD-333W CMF RESISTOR,A,B,C,D 33kØ,1/16W R4356 NRSA6AJ-272W MG RESISTOR,E,F 2.7kØ,1/16W

NRVA6AD-333W CMF RESISTOR,A,B,C,D 33kØ,1/16W

R4358 NRSA6AJ-272W MG RESISTOR,E,F 2.7kØ,1/16W

NRVA6AD-163W CMF RESISTOR,A,B,C,D 16kØ,1/16W R4359 NRVA6AD-363W CMF RESISTOR,A,B,C,D 36kØ,1/16W R4360 NRSA6AJ-272W MG RESISTOR,E,F 2.7kØ,1/16W

NRVA6AD-163W CMF RESISTOR,A,B,C,D 16kØ,1/16W R4361 NRVA6AD-333W CMF RESISTOR,A,B,C,D 33kØ,1/16W R4362 NRSA6AJ-272W MG RESISTOR,E,F 2.7kØ,1/16W

NRVA6AD-163W CMF RESISTOR,A,B,C,D 16kØ,1/16W R4363 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R4364 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4365 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4367 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4369 NRVA6AD-101W CMF RESISTOR,E,F 100Ø,1/16W

NRVA6AD-181W CMF RESISTOR,A,B,C,D 180Ø,1/16W R4370 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4371 NRVA6AD-680W CMF RESISTOR,A,B,C,D 68Ø,1/16W

NRVA6AD-750W CMF RESISTOR,E,F 75Ø,1/16W R4372 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R4373 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R4374 NRVA6AD-560W CMF RESISTOR 56Ø,1/16W R4375 NRVA6AD-271W CMF RESISTOR 270Ø,1/16W R4376 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R4377 NRVA6AD-270W CMF RESISTOR 27Ø,1/16W R4378 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R4379 NRSA6AJ-333W MG RESISTOR,E,F 33kØ,1/16W

NRVA6AD-273W CMF RESISTOR,A,B,C,D 27kØ,1/16W R4381 NRSA6AJ-333W MG RESISTOR,E,F 33kØ,1/16W

NRVA6AD-273W CMF RESISTOR,A,B,C,D 27kØ,1/16W R4382 NRSA6AJ-333W MG RESISTOR,E,F 33kØ,1/16W

NRVA6AD-273W CMF RESISTOR,A,B,C,D 27kØ,1/16W R4383 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4384 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4385 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4386 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4387 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4388 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4389 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4390 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R5005 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5006 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5007 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W

5-14

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R5009 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R5010 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5011 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5012 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5013 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R5014 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5015 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5016 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R5018 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5020 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5021 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5022 NRSA6AJ-121W MG RESISTOR,A,B,E,F 120Ø,1/16W

NRSA6AJ-181W MG RESISTOR,C,D 180Ø,1/16W R5024 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5025 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5026 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5027 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5028 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R6001 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6002 NRVA6AD-183W CMF RESISTOR 18kØ,1/16W R6003 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6004 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R6005 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R6006 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6007 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6009 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R6010 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6011 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6012 NRVA6AD-823W CMF RESISTOR 82kØ,1/16W R6013 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W

R6017 NRSA63J-102X MG RESISTOR 1kØ,1/16W R6018 NRSA63J-471X MG RESISTOR 470Ø,1/16W R6019 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R6101 NRVA6AD-183W CMF RESISTOR 18kØ,1/16W R6102 NRVA6AD-183W CMF RESISTOR 18kØ,1/16W R6103 NRVA6AD-273W CMF RESISTOR 27kØ,1/16W R6104 NRVA6AD-302W CMF RESISTOR 3kØ,1/16W R6105 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6106 NRVA6AD-242W CMF RESISTOR 2.4kØ,1/16W R6107 NRVA6AD-432W CMF RESISTOR 4.3kØ,1/16W R6109 NRVA6AD-822W CMF RESISTOR 8.2kØ,1/16W R6110 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6111 NRVA6AD-243W CMF RESISTOR 24kØ,1/16W R6112 NRVA6AD-182W CMF RESISTOR 1.8kØ,1/16W R6114 NRVA6AD-243W CMF RESISTOR 24kØ,1/16W R6115 NRVA6AD-302W CMF RESISTOR 3kØ,1/16W R6117 NRVA6AD-512W CMF RESISTOR 5.1kØ,1/16W R6118 NRVA6AD-472W CMF RESISTOR 4.7kØ,1/16W R6120 NRVA6AD-153W CMF RESISTOR 15kØ,1/16W R6122 NRVA6AD-623W CMF RESISTOR 62kØ,1/16W R6123 NRVA63D-682X CMF RESISTOR 6.8kØ,1/16W R6124 NRVA6AD-223W CMF RESISTOR 22kØ,1/16W R6125 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6126 NRVA63D-682X CMF RESISTOR 6.8kØ,1/16W R6127 NRVA6AD-223W CMF RESISTOR 22kØ,1/16W R6128 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W R6129 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6131 NRVA6AD-272W CMF RESISTOR 2.7kØ,1/16W R6132 NRVA6AD-302W CMF RESISTOR 3kØ,1/16W R6134 NRVA6AD-562W CMF RESISTOR 5.6kØ,1/16W R6135 NRVA6AD-102W CMF RESISTOR 1kØ,1/16W

R6136 NRVA6AD-562W CMF RESISTOR 5.6kØ,1/16W R6138 NRVA6AD-333W CMF RESISTOR 33kØ,1/16W R6139 NRVA6AD-272W CMF RESISTOR 2.7kØ,1/16W R6140 NRVA6AD-302W CMF RESISTOR 3kØ,1/16W R6142 NRVA6AD-562W CMF RESISTOR 5.6kØ,1/16W R6143 NRVA6AD-682W CMF RESISTOR 6.8kØ,1/16W R6144 NRVA6AD-392W CMF RESISTOR 3.9kØ,1/16W R6146 NRVA6AD-472W CMF RESISTOR 4.7kØ,1/16W R6147 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6148 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6151 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6152 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6155 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R6156 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6157 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R6158 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R6159 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R6163 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R6171 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R6201 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R6202 NRVA6AD-273W CMF RESISTOR 27kØ,1/16W R6203 NRVA6AD-153W CMF RESISTOR 15kØ,1/16W R6204 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6205 NRVA6AD-823W CMF RESISTOR 82kØ,1/16W R6206 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6207 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R6209 NRVA6AD-563W CMF RESISTOR 56kØ,1/16W R6210 NRVA6AD-683W CMF RESISTOR 68kØ,1/16W R6211 NRVA6AD-333W CMF RESISTOR 33kØ,1/16W R6212 NRVA6AD-333W CMF RESISTOR 33kØ,1/16W R6213 NRVA6AD-333W CMF RESISTOR 33kØ,1/16W R6214 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R6215 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R6216 NRVA6AD-104W CMF RESISTOR 100kØ,1/16W R6217 NRVA6AD-823W CMF RESISTOR 82kØ,1/16W R6301 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R6601 NRSA6AJ-822W MG RESISTOR,C,D,E,F 8.2kØ,1/16W R6603 NRVA6AD-683W CMF RESISTOR,C,D,E,F 68kØ,1/16W R6604 NRVA6AD-104W CMF RESISTOR,C,D,E,F 100kØ,1/16W R6605 NRSA6AJ-184W MG RESISTOR,C,D,E,F 180kØ,1/16W R6606 NRSA6AJ-823W MG RESISTOR,C,D,E,F 82kØ,1/16W R6611 NRSA6AJ-335W MG RESISTOR,C,D,E,F 3.3MØ,1/16W R6612 NRSA6AJ-474W MG RESISTOR,C,D,E,F 470kØ,1/16W R6613 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R6614 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R6615 NRSA6AJ-684W MG RESISTOR,C,D,E,F 680kØ,1/16W R6616 NRSA6AJ-333W MG RESISTOR,C,D,E,F 33kØ,1/16W R8001 NRSA6AJ-103W MG RESISTOR,C,D,E,F 10kØ,1/16W R8002 NRSA6AJ-101W MG RESISTOR,C,D,E,F 100Ø,1/16W R8003 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8004 NRSA6AJ-103W MG RESISTOR,C,D,E,F 10kØ,1/16W R8011 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8012 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8015 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8016 NRVA6AD-133W CMF RESISTOR,C,D,E,F 13kØ,1/16W R8017 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8018 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8021 NRSA6AJ-103W MG RESISTOR,C,D,E,F 10kØ,1/16W R8022 NRSA6AJ-101W MG RESISTOR,C,D,E,F 100Ø,1/16W R8023 NRSA6AJ-101W MG RESISTOR,C,D,E,F 100Ø,1/16W R8049 NRSA6AJ-105W MG RESISTOR,C,D,E,F 1MØ,1/16W

5-15

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R8050 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8051 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8064 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8065 NRSA6AJ-101W MG RESISTOR,C,D,E,F 100Ø,1/16W R8069 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8076 NRSA6AJ-103W MG RESISTOR,C,D,E,F 10kØ,1/16W R8077 NRSA6AJ-101W MG RESISTOR,C,D,E,F 100Ø,1/16W R8101 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8102 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8104 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8105 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8106 NRSA6AJ-221W MG RESISTOR,C,D,E,F 220Ø,1/16W R8107 NRSA6AJ-221W MG RESISTOR,C,D,E,F 220Ø,1/16W R8108 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8109 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8110 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8111 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8112 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8113 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8115 NRSA6AJ-221W MG RESISTOR,C,D,E,F 220Ø,1/16W R8116 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8117 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8118 NRSA6AJ-221W MG RESISTOR,C,D,E,F 220Ø,1/16W R8119 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R8120 NRSA6AJ-221W MG RESISTOR,C,D,E,F 220Ø,1/16W R8121 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8122 NRSA6AJ-105W MG RESISTOR,C,D,E,F 1MØ,1/16W R8124 NRSA6AJ-472W MG RESISTOR,C,D,E,F 4.7kØ,1/16W R8128 NRSA6AJ-472W MG RESISTOR,C,D,E,F 4.7kØ,1/16W R8129 NRSA6AJ-105W MG RESISTOR,C,D,E,F 1MØ,1/16W R8130 NRSA6AJ-101W MG RESISTOR,C,D,E,F 100Ø,1/16W R8131 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8132 NRSA6AJ-680W MG RESISTOR,C,D,E,F 68Ø,1/16W R8133 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8134 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R8135 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W RA1001 NRZ0034-102W NETWORK RESISTOR 1kØ RA1002 NRZ0034-102W NETWORK RESISTOR 1kØ RA1003 NRZ0034-104W NETWORK RESISTOR 100kØ RA1004 NRZ0034-104W NETWORK RESISTOR 100kØ RA1005 NRZ0034-102W NETWORK RESISTOR 1kØ RA1401 NRZ0034-473W NETWORK RESISTOR 47kØ RA1402 NRZ0034-102W NETWORK RESISTOR 1kØ RA1403 NRZ0034-102W NETWORK RESISTOR 1kØ RA1404 NRZ0034-102W NETWORK RESISTOR 1kØ RA1405 NRZ0034-102W NETWORK RESISTOR 1kØ RA4301 NRZ0034-221W NETWORK RESISTOR,C,D,E,F 220Ø RA4302 NRZ0034-221W NETWORK RESISTOR,C,D,E,F 220Ø RA4303 NRZ0034-221W NETWORK RESISTOR,C,D,E,F 220Ø RA4304 NRZ0034-221W NETWORK RESISTOR,C,D,E,F 220Ø RA4307 NRZ0034-221W NETWORK RESISTOR 220Ø RA4308 NRZ0034-221W NETWORK RESISTOR 220Ø RA8001 NRZ0034-100W NETWORK RESISTOR,C,D,E,F 10Ø RA8002 NRZ0034-100W NETWORK RESISTOR,C,D,E,F 10Ø RA8003 NRZ0034-100W NETWORK RESISTOR,C,D,E,F 10Ø RA8004 NRZ0034-100W NETWORK RESISTOR,C,D,E,F 10Ø C1003 NCBA1AK-104W CAPACITOR 0.1µF,10V C1005 NDCA1HJ-330W CAPACITOR 33pF,50V C1006 NDCA1HJ-150W CAPACITOR 15pF,50V C1007 NCBA1AK-104W CAPACITOR 0.1µF,10V C1008 NCBA1CK-103W CAPACITOR 0.01µF,16V

C1009 NCBA1AK-104W CAPACITOR 0.1µF,10V C1010 NCBA1AK-104W CAPACITOR 0.1µF,10V C1011 NCBA1AK-104W CAPACITOR 0.1µF,10V C1012 NCBA1AK-104W CAPACITOR 0.1µF,10V C1013 NDCA1HJ-130W CAPACITOR 13pF,50V C1015 NCBA1CK-103W CAPACITOR 0.01µF,16V C1017 NCBA1AK-104W CAPACITOR 0.1µF,10V C1019 NCBA1AK-104W CAPACITOR 0.1µF,10V C1020 NCBA1AK-104W CAPACITOR 0.1µF,10V C1022 NBM90JM-226X T CAPACITOR 22µF,6.3V C1023 NBM90JM-226X T CAPACITOR 22µF,6.3V C1101 NCBA1AK-104W CAPACITOR 0.1µF,10V C1102 NCBA1CK-223W CAPACITOR 0.022µF,16V C1103 NCBA1CK-223W CAPACITOR 0.022µF,16V C1111 NCB30JK-105X CAPACITOR 1µF,6.3V C1112 NBE90JM-106X T CAPACITOR 10µF,6.3V C1113 NBE90JM-106X T CAPACITOR 10µF,6.3V C1401 NBE90JM-106X T CAPACITOR 10µF,6.3V C1402 NBE90JM-106X T CAPACITOR 10µF,6.3V C1403 NCBA1CK-103W CAPACITOR 0.01µF,16V C1405 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1406 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1408 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1409 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1410 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1411 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1412 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1413 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1414 NCBA1CK-103W CAPACITOR 0.01µF,16V C1415 NCBA1CK-103W CAPACITOR 0.01µF,16V C1416 NCBA1CK-103W CAPACITOR 0.01µF,16V C1420 NCBA1CK-103W CAPACITOR 0.01µF,16V C1421 NCBA1CK-103W CAPACITOR 0.01µF,16V C1422 NCBA1CK-103W CAPACITOR 0.01µF,16V C1423 NCBA1CK-103W CAPACITOR 0.01µF,16V C1424 NCBA1CK-103W CAPACITOR 0.01µF,16V C1425 NCBA1CK-103W CAPACITOR 0.01µF,16V C1426 NCBA1CK-103W CAPACITOR 0.01µF,16V C1427 NCBA1CK-223W CAPACITOR 0.022µF,16V C1428 NCBA1CK-223W CAPACITOR 0.022µF,16V C1429 NCBA1CK-223W CAPACITOR 0.022µF,16V C1430 NCBA1CK-223W CAPACITOR 0.022µF,16V C1431 NCB30JK-105X CAPACITOR 1µF,6.3V C1440 NCBA1CK-103W CAPACITOR 0.01µF,16V C1441 NCBA1CK-103W CAPACITOR 0.01µF,16V C2704 NCB31CK-473X CAPACITOR 0.047µF,16V C2705 NCBA1AK-104W CAPACITOR 0.1µF,10V C2751 NBE20JM-106X T CAPACITOR 10µF,6.3V C2752 PECA1172 E CAPACITOR 47µF,6.3V C2753 NCB30JK-105X CAPACITOR 1µF,6.3V C2754 NCB30JK-105X CAPACITOR 1µF,6.3V C2756 NCB31HK-102X CAPACITOR 0.001µF,50V C2757 NCB31HK-822X CAPACITOR 0.0082µF,50V C2758 NBE81AM-106X T CAPACITOR 10µF,10V C2762 NCF31AZ-105X CAPACITOR 1µF,10V C2763 NBE40JM-476X T CAPACITOR 47µF,6.3V C2764 NCBA1AK-104W CAPACITOR 0.1µF,10V C2765 NDCA1HJ-101W CAPACITOR 100pF,50V C3001 NBE90GM-226X T CAPACITOR 22µF,4.0V C3003 NCB30JK-105X CAPACITOR 1µF,6.3V C3004 NBE90JM-106X T CAPACITOR 10µF,6.3V

5-16

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C3005 NDCA1HJ-8R0W CAPACITOR 8pF,50V C3006 NDCA1HJ-8R0W CAPACITOR 8pF,50V C3007 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3010 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3011 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3012 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3013 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3014 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3015 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3016 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3017 NCBA1CK-103W CAPACITOR 0.01µF,16V C3018 NCBA1AK-104W CAPACITOR 0.1µF,10V C3019 NCBA1CK-103W CAPACITOR 0.01µF,16V C3021 NCB21CK-474X CAPACITOR 0.47µF,16V C3032 NCBA1AK-104W CAPACITOR 0.1µF,10V C3041 NCBA1CK-103W CAPACITOR 0.01µF,16V C3042 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3046 NCBA1CK-103W CAPACITOR 0.01µF,16V C3047 NCBA1AK-104W CAPACITOR 0.1µF,10V C3101 NCBA1AK-104W CAPACITOR 0.1µF,10V C3104 NDCA1EJ-271W CAPACITOR 270pF,25V C3105 NCB30JK-105X CAPACITOR 1µF,6.3V C3106 NCB30JK-105X CAPACITOR 1µF,6.3V C3107 NCB30JK-105X CAPACITOR 1µF,6.3V C3108 NCBA1AK-104W CAPACITOR 0.1µF,10V C3109 NCBA1AK-104W CAPACITOR 0.1µF,10V C3110 NCBA1CK-103W CAPACITOR 0.01µF,16V C3111 NBE90JM-106X T CAPACITOR 10µF,6.3V C3112 NBE90JM-106X T CAPACITOR 10µF,6.3V C3201 NBE90JM-106X T CAPACITOR 10µF,6.3V C3202 NCB30JK-105X CAPACITOR 1µF,6.3V C3203 NBZ0001-106X T CAPACITOR 10µF C3205 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3206 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3207 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3208 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3209 NCBA1AK-104W CAPACITOR 0.1µF,10V C3210 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3211 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3212 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3213 NCBA1CK-103W CAPACITOR 0.01µF,16V C3214 NCBA1AK-104W CAPACITOR 0.1µF,10V C3215 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3216 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3217 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3218 NCBA1AK-104W CAPACITOR 0.1µF,10V C3221 NCBA1CK-103W CAPACITOR 0.01µF,16V C3222 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3301 NCB30JK-105X CAPACITOR 1µF,6.3V C3302 NBE90JM-106X T CAPACITOR 10µF,6.3V C3303 NBE90JM-106X T CAPACITOR 10µF,6.3V C3304 NCB30JK-105X CAPACITOR 1µF,6.3V C3305 NCBA1CK-103W CAPACITOR 0.01µF,16V C3306 NCBA1CK-103W CAPACITOR 0.01µF,16V C3308 NCBA1CK-103W CAPACITOR 0.01µF,16V C3309 NCBA1HK-102W CAPACITOR 0.001µF,50V C3310 NDCA1HJ-151W CAPACITOR 150pF,50V C3311 NCBA1CK-103W CAPACITOR 0.01µF,16V C3312 NCBA1CK-103W CAPACITOR 0.01µF,16V C3313 NCBA1AK-104W CAPACITOR 0.1µF,10V C3314 NCBA1CK-103W CAPACITOR 0.01µF,16V

C3315 NCBA1CK-103W CAPACITOR 0.01µF,16V C3316 NCB20JK-225X CAPACITOR 2.2µF,6.3V C3317 NCBA1AK-104W CAPACITOR 0.1µF,10V C3318 NCBA1AK-683W CAPACITOR 0.068µF,10V C3319 NCB20JK-225X CAPACITOR 2.2µF,6.3V C3320 NCBA1AK-333W CAPACITOR 0.033µF,10V C3321 NCBA1CK-103W CAPACITOR 0.01µF,16V C3322 NCBA1AK-104W CAPACITOR 0.1µF,10V C3324 NCBA1CK-103W CAPACITOR 0.01µF,16V C3325 NCBA1CK-103W CAPACITOR 0.01µF,16V C3326 NCBA1AK-104W CAPACITOR 0.1µF,10V C3327 NCBA1AK-104W CAPACITOR 0.1µF,10V C3328 NCBA1AK-104W CAPACITOR 0.1µF,10V C3329 NCBA1CK-103W CAPACITOR 0.01µF,16V C3330 NDCA1HJ-100W CAPACITOR 10pF,50V C3331 NCBA1AK-104W CAPACITOR 0.1µF,10V C3332 NCBA1CK-103W CAPACITOR 0.01µF,16V C3501 NCBA1CK-103W CAPACITOR 0.01µF,16V C3502 NCB30JK-105X CAPACITOR 1µF,6.3V C3503 NCBA1CK-103W CAPACITOR 0.01µF,16V C3504 NCBA1CK-103W CAPACITOR 0.01µF,16V C3505 NCBA1CK-103W CAPACITOR 0.01µF,16V C3506 NCBA1HK-152W CAPACITOR 0.0015µF,50V C3507 NBE90JM-106X T CAPACITOR 10µF,6.3V C3508 NDCA1HJ-330W CAPACITOR 33pF,50V C3509 NCBA1CK-103W CAPACITOR 0.01µF,16V C3510 NCBA1CK-103W CAPACITOR 0.01µF,16V C3511 NDCA1HJ-220W CAPACITOR 22pF,50V C3512 NBE90JM-106X T CAPACITOR 10µF,6.3V C3513 NCBA1CK-103W CAPACITOR 0.01µF,16V C3514 NBE90JM-106X T CAPACITOR 10µF,6.3V C3515 NDCA1HJ-220W CAPACITOR 22pF,50V C3516 NCBA1CK-103W CAPACITOR 0.01µF,16V C3517 NCBA1CK-103W CAPACITOR 0.01µF,16V C3518 NDCA1HJ-330W CAPACITOR 33pF,50V C3519 NBE90JM-106X T CAPACITOR 10µF,6.3V C3520 NCBA1HK-152W CAPACITOR 0.0015µF,50V C3521 NCBA1HK-122W CAPACITOR 0.0012µF,50V C3522 NCBA1CK-103W CAPACITOR 0.01µF,16V C3523 NCBA1CK-103W CAPACITOR 0.01µF,16V C3524 NDCA1HJ-470W CAPACITOR 47pF,50V C3525 NCBA1HK-681W CAPACITOR 680pF,50V C3526 NBE90JM-106X T CAPACITOR 10µF,6.3V C3527 NBE90JM-106X T CAPACITOR 10µF,6.3V C3528 NBE90JM-106X T CAPACITOR 10µF,6.3V C3529 NCBA1AK-104W CAPACITOR 0.1µF,10V C3551 NBE40JM-476X T CAPACITOR 47µF,6.3V C3552 NCBA1CK-103W CAPACITOR 0.01µF,16V C3702 NCBA1CK-103W CAPACITOR 0.01µF,16V C3703 NCBA1CK-103W CAPACITOR 0.01µF,16V C3704 NBE90JM-106X T CAPACITOR 10µF,6.3V C3705 NBE40GM-107X T CAPACITOR 100µF,4.0V C3706 NBE90GM-226X T CAPACITOR 22µF,4.0V C3707 NBZ0002-227X T CAPACITOR 220µF C3708 NBZ0002-227X T CAPACITOR 220µF C3709 NCBA1CK-103W CAPACITOR 0.01µF,16V C3710 NCBA1AK-104W CAPACITOR 0.1µF,10V C3711 NCBA1AK-104W CAPACITOR 0.1µF,10V C3712 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V

NRSA6AJ-0R0W MG RESISTOR,A,B,C,D 0Ø,1/16W

C3713 NCBA1CK-103W CAPACITOR 0.01µF,16V

5-17

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C3714 NCBA1CK-103W CAPACITOR 0.01µF,16V C3715 NBE90JM-106X T CAPACITOR 10µF,6.3V C3717 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3721 NBE20JM-226X T CAPACITOR 22µF,6.3V C3722 NCB30JK-105X CAPACITOR 1µF,6.3V C3723 NBE90JM-106X T CAPACITOR 10µF,6.3V C3724 NCBA1CK-103W CAPACITOR 0.01µF,16V C3731 NDCA1HJ-120W CAPACITOR 12pF,50V C3732 NDCA1HJ-150W CAPACITOR 15pF,50V C3733 NDCA1HJ-470W CAPACITOR 47pF,50V C3734 NDCA1HJ-390W CAPACITOR 39pF,50V C3735 NCBA1CK-103W CAPACITOR 0.01µF,16V C3736 NCB31CK-104X CAPACITOR 0.1µF,16V C3801 NBE90JM-106X T CAPACITOR,E,F 10µF,6.3V C3802 NCBA1AK-104W CAPACITOR,E,F 0.1µF,10V C3803 NBE90JM-106X T CAPACITOR,E,F 10µF,6.3V C3804 NCBA1AK-104W CAPACITOR,E,F 0.1µF,10V C3805 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3806 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3807 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3808 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3809 NCBA1AK-104W CAPACITOR,E,F 0.1µF,10V C3811 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3812 NBE90JM-106X T CAPACITOR,E,F 10µF,6.3V C3813 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3815 NCBA1AK-104W CAPACITOR,E,F 0.1µF,10V C3816 NCBA1AK-104W CAPACITOR,E,F 0.1µF,10V C3817 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3818 NBE90JM-106X T CAPACITOR,E,F 10µF,6.3V C3819 NCBA1AK-104W CAPACITOR,E,F 0.1µF,10V C3820 NCBA1AK-104W CAPACITOR,E,F 0.1µF,10V C3821 NCBA1AK-104W CAPACITOR,E,F 0.1µF,10V C3822 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3823 NDCA1HJ-680W CAPACITOR,E,F 68pF,50V C3824 NDCA1HJ-680W CAPACITOR,E,F 68pF,50V C3851 NBE20JM-226X T CAPACITOR,E,F 22µF,6.3V C3852 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3853 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3855 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3856 NCB30JK-105X CAPACITOR,E,F 1µF,6.3V C3857 NCB30JK-105X CAPACITOR,E,F 1µF,6.3V C3858 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C3861 NCB20JK-225X CAPACITOR,E,F 2.2µF,6.3V C3862 NCBA1CK-103W CAPACITOR,E,F 0.01µF,16V C4101 NCF31EZ-104X CAPACITOR 0.1µF,25V C4102 NBP41EM-475X T CAPACITOR 4.7µF,25V C4103 NCF31EZ-104X CAPACITOR 0.1µF,25V C4104 NCBA1AK-104W CAPACITOR 0.1µF,10V C4105 NBE41AM-476X T CAPACITOR 47µF,10V C4106 NCBA1AK-104W CAPACITOR 0.1µF,10V C4107 NCBA1AK-104W CAPACITOR 0.1µF,10V C4109 NCF31EZ-104X CAPACITOR 0.1µF,25V C4111 NBP21VM-105X T CAPACITOR 1µF,35V C4201 NBE40JM-476X T CAPACITOR 47µF,6.3V C4202 NBE20GM-476X T CAPACITOR 47µF,4.0V C4203 NCBA1CK-103W CAPACITOR 0.01µF,16V C4204 NCBA1AK-104W CAPACITOR 0.1µF,10V C4205 NBE20GM-476X T CAPACITOR 47µF,4.0V C4207 NBE90JM-106X T CAPACITOR 10µF,6.3V C4208 NBE41AM-476X T CAPACITOR 47µF,10V C4209 NBE41AM-476X T CAPACITOR 47µF,10V

C4210 NCBA1AK-104W CAPACITOR 0.1µF,10V C4211 NCF31EZ-104X CAPACITOR 0.1µF,25V C4212 NBP41DM-106X T CAPACITOR 10µF,20V C4215 NCBA1AK-104W CAPACITOR 0.1µF,10V C4216 NCBA1AK-104W CAPACITOR 0.1µF,10V C4217 NCBA1CK-123W CAPACITOR 0.012µF,16V C4218 NCBA1AK-104W CAPACITOR 0.1µF,10V C4219 NCB30JK-474X CAPACITOR 0.47µF,6.3V C4220 NCB30JK-105X CAPACITOR 1µF,6.3V C4221 NCB30JK-105X CAPACITOR 1µF,6.3V C4222 NCB30JK-105X CAPACITOR 1µF,6.3V C4223 NCBA1AK-104W CAPACITOR 0.1µF,10V C4224 NCB30JK-105X CAPACITOR 1µF,6.3V C4225 NCB30JK-105X CAPACITOR 1µF,6.3V C4226 NCBA1AK-104W CAPACITOR 0.1µF,10V C4227 NCBA1AK-104W CAPACITOR 0.1µF,10V C4228 NCBA1CK-103W CAPACITOR 0.01µF,16V C4229 NCBA1CK-103W CAPACITOR 0.01µF,16V C4230 NCBA1CK-103W CAPACITOR 0.01µF,16V C4231 NCBA1CK-103W CAPACITOR 0.01µF,16V C4233 NCBA1CK-103W CAPACITOR 0.01µF,16V C4301 NCB30JK-105X CAPACITOR 1µF,6.3V C4302 NBE90JM-106X T CAPACITOR 10µF,6.3V C4303 NCBA1AK-104W CAPACITOR 0.1µF,10V C4304 NBE90JM-106X T CAPACITOR 10µF,6.3V C4305 NBE90JM-106X T CAPACITOR,A,B,C,D 10µF,6.3V C4306 NCB30JK-105X CAPACITOR 1µF,6.3V C4307 NBE90JM-106X T CAPACITOR 10µF,6.3V C4308 NCBA1AK-104W CAPACITOR 0.1µF,10V C4309 NCBA1AK-104W CAPACITOR 0.1µF,10V C4310 NBG40GM-226X T CAPACITOR 22µF,4.0V C4312 NCBA1AK-104W CAPACITOR 0.1µF,10V C4313 NCBA1AK-104W CAPACITOR 0.1µF,10V C4315 NCBA1AK-104W CAPACITOR 0.1µF,10V C4316 NCBA1AK-104W CAPACITOR 0.1µF,10V C4317 NCBA1AK-104W CAPACITOR 0.1µF,10V C4318 NCBA1AK-104W CAPACITOR 0.1µF,10V C4319 NCBA1AK-104W CAPACITOR 0.1µF,10V C4320 NCBA1AK-104W CAPACITOR 0.1µF,10V C4321 NCBA1AK-104W CAPACITOR 0.1µF,10V C4323 NCBA1AK-104W CAPACITOR,A,B,C,D 0.1µF,10V C4324 NCBA1HK-331W CAPACITOR,A,B,C,D 330pF,50V C4351 NCBA1AK-104W CAPACITOR 0.1µF,10V C4352 NCBA1AK-104W CAPACITOR 0.1µF,10V C4353 NCB30JK-105X CAPACITOR 1µF,6.3V C4355 NCB30JK-105X CAPACITOR 1µF,6.3V C4357 NCB30JK-105X CAPACITOR 1µF,6.3V C4359 NCB30JK-105X CAPACITOR 1µF,6.3V C4361 NCBA1AK-104W CAPACITOR 0.1µF,10V C4362 NCBA1AK-104W CAPACITOR 0.1µF,10V C4363 NCBA1AK-104W CAPACITOR 0.1µF,10V C4364 NCBA1AK-104W CAPACITOR 0.1µF,10V C4365 NBE90JM-106X T CAPACITOR 10µF,6.3V C4401 NBE90GM-226X T CAPACITOR 22µF,4.0V C4402 NCBA1CK-103W CAPACITOR 0.01µF,16V C5001 NCBA1AK-104W CAPACITOR 0.1µF,10V C5002 NCBA1AK-104W CAPACITOR 0.1µF,10V C5003 NBE40JM-476X T CAPACITOR 47µF,6.3V C5004 NCBA1AK-104W CAPACITOR 0.1µF,10V C5005 NCBA1AK-104W CAPACITOR 0.1µF,10V C5006 NCBA1AK-104W CAPACITOR 0.1µF,10V

5-18

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C5007 NCB30JK-105X CAPACITOR 1µF,6.3V C5008 NBE90JM-106X T CAPACITOR 10µF,6.3V C5009 NCBA1AK-104W CAPACITOR 0.1µF,10V C5011 NCBA1AK-104W CAPACITOR 0.1µF,10V C5012 NCBA1AK-104W CAPACITOR 0.1µF,10V C5013 NCBA1AK-104W CAPACITOR 0.1µF,10V C5014 NBE90JM-106X T CAPACITOR 10µF,6.3V C5017 NCBA1AK-104W CAPACITOR 0.1µF,10V C5018 NCB30JK-105X CAPACITOR 1µF,6.3V C5019 NCB30JK-105X CAPACITOR 1µF,6.3V C5214 NBE41AM-476X T CAPACITOR 47µF,10V C5215 NBE41AM-476X T CAPACITOR 47µF,10V C5216 NBE41AM-476X T CAPACITOR 47µF,10V C5217 NCF31EZ-104X CAPACITOR 0.1µF,25V C5218 NCBA1AK-104W CAPACITOR 0.1µF,10V C5219 NCBA1AK-104W CAPACITOR 0.1µF,10V C5220 NCBA1AK-104W CAPACITOR 0.1µF,10V C5221 NBE20JM-106X T CAPACITOR 10µF,6.3V C6001 NCBA1AK-104W CAPACITOR 0.1µF,10V C6002 NCBA1CK-103W CAPACITOR 0.01µF,16V C6003 NCBA1AK-104W CAPACITOR 0.1µF,10V C6004 NBE90JM-106X T CAPACITOR 10µF,6.3V C6005 NBP21CM-685X T CAPACITOR 6.8µF,16V C6006 NCF31AZ-105X CAPACITOR 1µF,10V C6007 NBE90JM-106X T CAPACITOR 10µF,6.3V C6008 NCBA1AK-104W CAPACITOR 0.1µF,10V C6009 NCBA1CK-103W CAPACITOR 0.01µF,16V C6101 NCB31AK-474X CAPACITOR 0.47µF,10V C6102 NCB31AK-224X CAPACITOR 0.22µF,10V C6103 NCB31CK-104X CAPACITOR 0.1µF,16V C6104 NCBA1AK-104W CAPACITOR 0.1µF,10V C6106 NCBA1AK-104W CAPACITOR 0.1µF,10V C6108 NCBA1AK-104W CAPACITOR 0.1µF,10V C6110 NCBA1AK-104W CAPACITOR 0.1µF,10V C6112 NCB31AK-224X CAPACITOR 0.22µF,10V C6114 NDCA1HJ-100W CAPACITOR 10pF,50V C6115 NDCA1HJ-121W CAPACITOR 120pF,50V C6116 NCBA1AK-104W CAPACITOR 0.1µF,10V C6117 NCBA1AK-104W CAPACITOR 0.1µF,10V C6118 NBP41CM-106X T CAPACITOR 10µF,16V C6119 NCB31EK-103X CAPACITOR 0.01µF,25V C6120 NCBA1AK-104W CAPACITOR 0.1µF,10V C6122 NCBA1AK-104W CAPACITOR 0.1µF,10V C6124 NCBA1AK-104W CAPACITOR 0.1µF,10V C6126 NCBA1AK-104W CAPACITOR 0.1µF,10V C6128 NCB21AK-105X CAPACITOR 1µF,10V C6129 NCB21AK-105X CAPACITOR 1µF,10V C6130 NCB21AK-105X CAPACITOR 1µF,10V C6131 NCB21AK-105X CAPACITOR 1µF,10V C6132 NBG41AM-106X T CAPACITOR 10µF,10V C6133 NCB21AK-105X CAPACITOR 1µF,10V C6134 NCB11AK-225X-A CAPACITOR 2.2µF,10V C6135 NCB21AK-105X CAPACITOR 1µF,10V C6136 NCB11AK-475X CAPACITOR 4.7µF,10V C6138 NCB21AK-105X CAPACITOR 1µF,10V C6145 NCB21AK-105X CAPACITOR 1µF,10V C6146 NBG41AM-106X T CAPACITOR 10µF,10V C6147 NBG41AM-106X T CAPACITOR 10µF,10V C6148 NCB11AK-475X CAPACITOR 4.7µF,10V C6150 NCB21AK-105X CAPACITOR 1µF,10V C6151 NCB10JK-106X CAPACITOR 10µF,6.3V

C6153 NCB21AK-105X CAPACITOR 1µF,10V C6154 NCB10JK-106X CAPACITOR 10µF,6.3V C6156 NCB21AK-105X CAPACITOR 1µF,10V C6157 NCB11AK-475X CAPACITOR 4.7µF,10V C6158 NCB20JK-225X CAPACITOR 2.2µF,6.3V C6159 NCB20JK-225X CAPACITOR 2.2µF,6.3V C6163 NCB21AK-105X CAPACITOR 1µF,10V C6201 NCB21CK-105X CAPACITOR 1µF,16V C6202 NCB11EK-105X CAPACITOR 1µF,25V C6203 NCBA1CK-103W CAPACITOR 0.01µF,16V C6204 NCB21CK-105X CAPACITOR 1µF,16V C6205 NCB21CK-105X CAPACITOR 1µF,16V C6206 NCB11CK-105X CAPACITOR 1µF,16V C6207 NCB11EK-105X CAPACITOR 1µF,25V C6208 NCB21CK-105X CAPACITOR 1µF,16V C6209 NCB21CK-105X CAPACITOR 1µF,16V C6210 NCB21CK-105X CAPACITOR 1µF,16V C6401 NCBA1CK-103W CAPACITOR 0.01µF,16V C6402 NBE91CM-105X T CAPACITOR 1µF,16V C6601 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C6602 NBE90JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V C6603 NCBA1HK-102W CAPACITOR,C,D,E,F 0.001µF,50V C6604 NCBA1AK-473W CAPACITOR,C,D,E,F 0.047µF,10V C6611 NCBA1CK-153W CAPACITOR,C,D,E,F 0.015µF,16V C6612 NDCA1EJ-221W CAPACITOR,C,D,E,F 220pF,25V C6613 NDCA1EJ-121W CAPACITOR,C,D,E,F 120pF,25V C8001 NBE90JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V C8002 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8003 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8004 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8006 NCBA1AK-104W CAPACITOR,C,D,E,F 0.1µF,10V C8007 NBE90JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V C8008 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C8009 NCBA1AK-104W CAPACITOR,C,D,E,F 0.1µF,10V C8010 NBE90JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V C8011 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C8017 NCBA1AK-104W CAPACITOR,C,D,E,F 0.1µF,10V C8020 NBE90JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V C8021 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8022 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8023 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8024 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8025 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8026 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8027 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8028 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8029 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8030 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8031 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8032 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8033 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8034 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8035 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8036 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8037 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8038 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8039 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8040 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8041 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8042 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8043 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V

5-19

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C8044 NBE20GM-476X T CAPACITOR,C,D,E,F 47µF,4.0V C8045 NBE20JM-226X T CAPACITOR,C,D,E,F 22µF,6.3V C8046 NBE90JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V C8048 NBE20GM-476X T CAPACITOR,C,D,E,F 47µF,4.0V C8049 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8050 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8051 NBE20GM-476X T CAPACITOR,C,D,E,F 47µF,4.0V C8052 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8054 NCB31HK-392X CAPACITOR,C,D,E,F 0.0039µF ,50V C8056 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8057 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8058 NCBA1AK-104W CAPACITOR,C,D,E,F 0.1µF,10V C8059 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8060 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8101 NBE90JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V C8102 NBE90JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V C8103 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8104 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8105 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8106 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8107 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8108 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8109 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8110 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8111 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8112 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8113 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8114 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8115 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8116 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V C8117 NDCA1HJ-5R0W CAPACITOR,C,D,E,F 5pF,50V C8118 NDCA1HJ-5R0W CAPACITOR,C,D,E,F 5pF,50V C8119 NCBA1CK-103W CAPACITOR,C,D,E,F 0.01µF,16V L1001 NQR0265-001X FERRITE BEAD L1002 NQR0265-001X FERRITE BEAD L1003 NQL085J-390X COIL 39µH L1101 NQL402M-100X COIL 10µH L1401 NQL302N-100X COIL 10µH L1402 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W L2701 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2702 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L3001 NQR0305-001X FERRITE BEAD L3002 NQR0006-001X FERRITE BEAD L3003 NQR0305-001X FERRITE BEAD L3005 NQR0305-001X FERRITE BEAD L3101 NQR0305-001X FERRITE BEAD L3102 NQR0006-001X FERRITE BEAD L3103 NQR0384-003X COIL L3104 NQR0384-003X COIL L3201 NQR0006-001X FERRITE BEAD L3202 NQR0305-001X FERRITE BEAD L3301 NQR0006-001X FERRITE BEAD L3302 NQL04DK-100X COIL 10µH L3303 NQL04DK-100X COIL 10µH L3304 NQR0006-001X FERRITE BEAD L3501 NQL04DK-220X COIL 22µH L3502 NQL04DK-220X COIL 22µH L3503 NQL302N-100X COIL 10µH L3504 NQL302N-100X COIL 10µH L3551 NQR0006-001X FERRITE BEAD L3701 NQL302N-100X COIL 10µH

L3731 NQL085J-120X COIL 12µH L3732 NQL085J-270X COIL 27µH L3801 NQR0305-001X FERRITE BEAD,E,F L3802 NQR0006-001X FERRITE BEAD,E,F L3851 NQL302N-100X COIL,E,F 10µH L4101 NQR0129-002X FERRITE BEAD L4102 NQL045K-100X COIL 10µH L4103 NQR0129-002X FERRITE BEAD L4104 NQL045K-100X COIL 10µH L4201 NQR0265-001X FERRITE BEAD L4202 NQL402M-100X COIL 10µH L4203 NQR0265-001X FERRITE BEAD L4204 NQL402M-100X COIL 10µH L4205 NQL402M-100X COIL 10µH L4301 NQR0265-001X FERRITE BEAD L4302 NQR0265-001X FERRITE BEAD L4303 NQR0265-001X FERRITE BEAD L4304 NQL045K-100X COIL,A,B,C,D 10µH L4305 NQR0265-001X FERRITE BEAD L4306 NQR0129-002X FERRITE BEAD L4351 NQL402M-100X COIL 10µH L4401 NQR0006-001X FERRITE BEAD L5001 NQR0129-002X FERRITE BEAD L5002 NQL045K-100X COIL 10µH L5003 NQR0129-002X FERRITE BEAD L5004 NQR0129-002X FERRITE BEAD L5005 NQR0129-002X FERRITE BEAD L5201 NQR0129-002X FERRITE BEAD L5202 NQR0129-002X FERRITE BEAD L5203 NQL045K-100X COIL 10µH L5204 NQL045K-100X COIL 10µH L5205 NQL045K-100X COIL 10µH L5206 NQR0129-002X FERRITE BEAD L6001 NQL402M-100X COIL 10µH L6101 NQLZ011-4R7X COIL 4.7µH L6102 NQLZ011-4R7X COIL 4.7µH L6103 NQLZ011-4R7X COIL 4.7µH L6104 NQL32CM-220X COIL 22µH L6105 NQL32CM-220X COIL 22µH L6106 NQL32CM-100X COIL 10µH L6110 NQLZ011-390X COIL 39µH L6112 NQL32CM-220X COIL 22µH L6114 NQL32CM-220X COIL 22µH L6116 NQL32CM-100X COIL 10µH L6117 NQL35BK-100X COIL 10µH L6118 NQL35BK-100X COIL 10µH L6201 NQLZ011-221X COIL 220µH L6601 NQL402M-100X COIL,C,D,E,F 10µH L8001 NQR0129-002X FERRITE BEAD,C,D,E,F L8002 NQR0129-002X FERRITE BEAD,C,D,E,F L8003 NQR0129-002X FERRITE BEAD,C,D,E,F L8005 NQR0129-002X FERRITE BEAD,C,D,E,F L8006 NQR0129-002X FERRITE BEAD,C,D,E,F L8007 NQR0129-002X FERRITE BEAD,C,D,E,F L8008 NQR0129-002X FERRITE BEAD,C,D,E,F L8010 NQR0129-002X FERRITE BEAD,C,D,E,F L8011 NQR0129-002X FERRITE BEAD,C,D,E,F L8101 NQR0006-001X FERRITE BEAD,C,D,E,F L8102 NQR0006-001X FERRITE BEAD,C,D,E,F X1001 NAX0279-001X C OSCILLATOR X1002 NAX0267-001X CRYSTAL RESONATOR

5-20

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

X3001 NAX0206-001X CRYSTAL RESONATOR X3301 NAX0296-001X C OSCILLATOR X4301 NAX0332-001X CXO X8002 NAX0354-001X RESONATOR,C,D,E,F X8101 NAX0402-001X CRYSTAL RESONATOR,C,D,E,F S1001 NSW0132-001X DETECT SWITCH S1401 NSW0128-001X LEVER SWITCH TB1 LY31799-001A BATT.TERMINAL WR1 QAL0246-001 FPC WR2 QAL0239-001 FPC WR3 WJR0016-001B E-SH C WIRE C-F,C,D

WJR0016-001C E-SH C WIRE C-F,A,B,E,F J101 NNZ0028-001 D CONNECTOR CN1001 QGF0513F1-08X FPC CONNECTOR CN1002 QGB0401M1-80X CONNECTOR CN1003 QGF0513F2-20X FPC CONNECTOR CN1004 QGA1001F1-03X CONNECTOR CN1005 QGF0513F2-06X FPC CONNECTOR CN1007 QGF0301F1-45X FPC CONNECTOR CN1008 QGF0507F1-16X FPC CONNECTOR CN1009 QGA1001F1-02X CONNECTOR CN1010 QGB0506L1-20X CONNECTOR CN1011 QGF0513F1-12X FPC CONNECTOR,C,D,E,F CN1014 QGF0301F1-33X FPC CONNECTOR CN1016 QGB0401M1-A0X CONNECTOR

F6101 NMFZ007-1R6X-K FUSE T1.6A

F6102 NMFZ007-R20X-K FUSE T0.2A

F6103 NMFZ007-1R6X-K FUSE T1.6A

F6104 NMFZ007-R50X-K FUSE T0.5A FL3851 NQR0344-001X LOW PASS FILTER,E,F FL3852 NQR0344-001X LOW PASS FILTER,E,F OT1 LY30029-065B SPACER(A) OT2 LY30029-066A SPACER(A) OT3 LY42538-001A SHEET(MAIN) OT4 LY30029-078A SPACER(A),X2 OT5 LY30029-079A SPACER(A) OT6 LY30029-082A SPACER(A) OT7 LY30029-0A7A SPACER(A),X2,A,B,E,F SD1 LY31714-001A SHIELD CASE

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

MDA BOARD ASSEMBLY <02>

PW2 YB10285A1-01 MDA BOARD ASSY IC1601 BD6630KV IC IC1801 NAL0006-001X IR SENSOR UNIT IC4802 TA75W01FU IC IC4803 TA75W01FU IC IC4804 UPC358G2/5/-W IC IC4806 TC7W00FK IC IC4807 TC7W66FK IC IC4851 UPD16879GS IC Q1601 UMC3N TRANSISTOR Q1801 DTC143XE TRANSISTOR Q4801 2SC4655/BC/-X TRANSISTOR Q4802 2SC4617/RS/-X TRANSISTOR Q4803 DTC144EE TRANSISTOR Q4804 DTA144EE TRANSISTOR

Q4805 DTA143EE TRANSISTOR Q4851 2SC4617/RS/-X TRANSISTOR D1602 DAP222 DIODE D1603 DAP222 DIODE D1604 DAP222 DIODE D1801 TLSU1002/LM/-X LE DIODE R1601 NRSA6AJ-681W MG RESISTOR 680Ø,1/16W R1602 NRSA6AJ-124W MG RESISTOR 120kØ,1/16W R1603 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1604 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1605 NRV142F-R22X CMF RESISTOR 0.22Ø,1/4W R1606 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1609 NRV142F-R33X CMF RESISTOR 0.33Ø,1/4W R1610 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R1611 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R1612 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1613 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1614 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R1615 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1616 NRSA6AJ-391W MG RESISTOR 390Ø,1/16W R1617 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R1618 NRSA6AJ-154W MG RESISTOR 150kØ,1/16W R1619 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R1620 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1621 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1622 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1624 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W R1625 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1626 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1627 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1628 NRVA6AD-361W CMF RESISTOR 360Ø,1/16W R1629 NRSA6AJ-684W MG RESISTOR 680kØ,1/16W R1630 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1631 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1632 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1633 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1634 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1635 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1636 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1637 NRSA6AJ-124W MG RESISTOR 120kØ,1/16W R1642 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1644 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1801 NRSA6AJ-271W MG RESISTOR 270Ø,1/16W R1802 NRSA6AJ-470W MG RESISTOR 47Ø,1/16W R4804 NRVA6AD-331W CMF RESISTOR 330Ø,1/16W R4805 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4806 NRSA6AJ-683W MG RESISTOR 68kØ,1/16W R4807 NRSA6AJ-563W MG RESISTOR 56kØ,1/16W R4808 NRSA6AJ-243W MG RESISTOR 24kØ,1/16W R4809 NRSA6AJ-561W MG RESISTOR 560Ø,1/16W R4810 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4811 NRSA6AJ-684W MG RESISTOR 680kØ,1/16W R4812 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R4814 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R4815 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R4816 NRSA6AJ-185W MG RESISTOR 1.8MØ,1/16W R4817 NRSA6AJ-334W MG RESISTOR 330kØ,1/16W R4818 NRSA6AJ-154W MG RESISTOR 150kØ,1/16W R4819 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4820 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R4821 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W

5-21

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R4822 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R4823 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4824 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R4825 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R4826 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R4827 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4828 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4833 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R4836 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4837 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4839 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4840 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4846 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4849 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4854 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4856 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W R4857 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W R4858 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R4859 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4860 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4862 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W R4863 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W R4864 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4865 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4866 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4867 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4868 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4870 NRSA6AJ-271W MG RESISTOR 270Ø,1/16W R4871 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4874 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W C1601 NCBA1CK-103W CAPACITOR 0.01µF,16V C1602 NBE21AM-106X T CAPACITOR 10µF,10V C1603 NBE21AM-106X T CAPACITOR 10µF,10V C1605 NCBA1AK-104W CAPACITOR 0.1µF,10V C1606 NCBA1HK-152W CAPACITOR 0.0015µF,50V C1607 NCBA1AK-473W CAPACITOR 0.047µF,10V C1614 NBE21AM-106X T CAPACITOR 10µF,10V C1618 NCBA1HK-222W CAPACITOR 0.0022µF,50V C1619 NCBA1HK-222W CAPACITOR 0.0022µF,50V C1620 NCBA1HK-222W CAPACITOR 0.0022µF,50V C1621 NCB21AK-105X CAPACITOR 1µF,10V C1622 NCBA1CK-223W CAPACITOR 0.022µF,16V C1623 NCBA1AK-473W CAPACITOR 0.047µF,10V C1624 NCB31EK-103X CAPACITOR 0.01µF,25V C1625 NCBA1AK-473W CAPACITOR 0.047µF,10V C1626 NCBA1HK-331W CAPACITOR 330pF,50V C1627 NCBA1CK-822W CAPACITOR 0.0082µF,16V C1628 NCB21CK-224X CAPACITOR 0.22µF,16V C1632 NBE21AM-106X T CAPACITOR 10µF,10V C1633 NCF21CZ-684X CAPACITOR 0.68µF,16V C1635 NCBA1AK-104W CAPACITOR 0.1µF,10V C1641 NCB31AK-474X CAPACITOR 0.47µF,10V C1801 NBE21AM-106X T CAPACITOR 10µF,10V C4803 NBE90JM-106X T CAPACITOR 10µF,6.3V C4804 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4805 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4806 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4808 NCB30JK-105X CAPACITOR 1µF,6.3V C4809 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4810 NCFA1HZ-103W CAPACITOR 0.01µF,50V C4811 NCFA1HZ-103W CAPACITOR 0.01µF,50V

C4812 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4813 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4814 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4815 NCB31HK-152X CAPACITOR 0.0015µF,50V C4819 NCF31CZ-104X CAPACITOR 0.1µF,16V C4851 NBE90JM-106X T CAPACITOR 10µF,6.3V C4852 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4853 NBE91AM-335X T CAPACITOR 3.3µF,10V C4854 NBE21AM-106X T CAPACITOR 10µF,10V C4855 NCB31CK-104X CAPACITOR 0.1µF,16V C4858 NDCA1HJ-680W CAPACITOR 68pF,50V C4859 NCBA1HK-102W CAPACITOR 0.001µF,50V C4860 NCBA1HK-102W CAPACITOR 0.001µF,50V C4861 NCBA1HK-102W CAPACITOR 0.001µF,50V C4862 NCBA1HK-102W CAPACITOR 0.001µF,50V C4864 NBE90JM-106X T CAPACITOR 10µF,6.3V C4865 NCBA1AK-104W CAPACITOR 0.1µF,10V L1601 NQL315M-1R0X COIL 1µH L4802 NQL302N-100X COIL 10µH L4851 NQR0129-002X FERRITE BEAD L4852 NQL315K-100X COIL 10µH L4853 NQL315K-100X COIL 10µH CN201 QGF0505F2-06X FPC CONNECTOR CN202 QGF0517F2-11X FPC CONNECTOR CN203 QGF0505F2-18X FPC CONNECTOR CN204 QGF0507F1-15X FPC CONNECTOR CN205 QGF0507F1-24X FPC CONNECTOR CN206 QGB0401L1-80X CONNECTOR CN207 QGF0505F2-07X FPC CONNECTOR CN208 QGF0507F1-14X FPC CONNECTOR OT1 LY30016-0E6A SPACER-A

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

CCD BOARD ASSEMBLY <03>

PW YB10286A-02 CCD BOARD ASSY Q5201 2SC3935/Q/-X TRANSISTOR R5201 NRSA63J-122X MG RESISTOR 1.2kØ,1/16W C5202 NCF31EZ-104X CAPACITOR 0.1µF,25V C5203 NBEE1AM-226X T CAPACITOR 22µF,10V C5204 NCB31CK-104X CAPACITOR 0.1µF,16V C5205 NCB31CK-104X CAPACITOR 0.1µF,16V C5206 NBZ0003-475X T CAPACITOR 4.7µF C5207 NCF31EZ-104X CAPACITOR 0.1µF,25V C5208 NCB31HK-222X CAPACITOR 0.0022µF,50V C5209 NCB21EK-104X CAPACITOR 0.1µF,25V WR1 WJR0017-001A E-SH C WIRE C-F

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

MONITOR BOARD ASSEMBLY <04>

PW1 YB10289B-01 MONITOR BOARD ASSY,A,C,D,E

YB10289B-02 MONITOR BOARD ASSY,B,F IC7501 TL1451CPW IC IC7502 TC7SH04FU IC(DIGITAL)

5-22

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

or SN74AHC1G04K IC IC7601 AN2533FH IC IC7603 AT25040N-10SC-X IC IC7604 BU4053BCFV IC IC7607 TC7S04FU IC IC7608 TC7S08FU IC(DIGITAL) Q7501 UMD3N TRANSISTOR Q7502 SSM3K01F MOS FET Q7503 2SC4617/QRS/-X TRANSISTOR Q7504 XP6401 TRANSISTOR Q7601 2SA1774/QR/-X TRANSISTOR Q7602 UMC4N TRANSISTOR Q7604 DTA114YE TRANSISTOR Q7605 DTA114YE TRANSISTOR Q7606 DTA114YE TRANSISTOR Q7607 DTA114YE TRANSISTOR Q7608 UMZ1N PAIR TRANSISTOR Q7609 2SC4097/QR/-X TRANSISTOR Q7610 2SA1577/QR/-X TRANSISTOR Q7615 DTA144EE TRANSISTOR Q7616 UMC4N TRANSISTOR Q7618 DTC144EE TRANSISTOR D7501 MA142WK DIODE D7601 RB471E SB DIODE D7602 MA111 DIODE D7603 MA111 DIODE R7501 NRVA6AD-103W CMF RESISTOR 10kØ,1/16W R7502 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W R7503 NRVA63D-334X CMF RESISTOR 330kØ,1/16W R7504 NRSA6AJ-394W MG RESISTOR 390kØ,1/16W R7505 NRSA6AJ-562W MG RESISTOR 5.6kØ,1/16W R7506 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W R7507 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R7508 NRS181J-335X MG RESISTOR 3.3MØ,1/8W R7509 NRS181J-335X MG RESISTOR 3.3MØ,1/8W R7510 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R7511 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R7512 NRSA6AJ-822W MG RESISTOR 8.2kØ,1/16W R7513 NRSA6AJ-273W MG RESISTOR 27kØ,1/16W R7514 NRSA6AJ-124W MG RESISTOR 120kØ,1/16W R7515 NRSA6AJ-151W MG RESISTOR 150Ø,1/16W R7516 NRSA6AJ-151W MG RESISTOR 150Ø,1/16W R7517 NRSA6AJ-122W MG RESISTOR 1.2kØ,1/16W R7518 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R7519 NRSA6AJ-163W MG RESISTOR 16kØ,1/16W R7520 NRSA6AJ-393W MG RESISTOR 39kØ,1/16W R7521 NRVA6AD-153W CMF RESISTOR 15kØ,1/16W R7523 NRVA63D-184X CMF RESISTOR 180kØ,1/16W R7524 NRVA63D-114X CMF RESISTOR 110kØ,1/16W R7525 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R7526 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R7527 NRSA6AJ-221W MG RESISTOR,B,F 220Ø,1/16W R7602 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R7603 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R7604 NRSA6AJ-563W MG RESISTOR 56kØ,1/16W R7610 NRSA6AJ-563W MG RESISTOR 56kØ,1/16W R7611 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R7612 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R7613 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R7614 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R7615 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W

R7616 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R7617 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R7620 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R7627 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R7631 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R7635 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R7636 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R7637 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W R7638 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W R7639 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W R7640 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W R7641 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W R7642 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W R7643 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R7645 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R7646 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R7649 NRVA6AD-222W CMF RESISTOR 2.2kØ,1/16W R7650 NRVA6AD-222W CMF RESISTOR 2.2kØ,1/16W R7651 NRVA6AD-222W CMF RESISTOR 2.2kØ,1/16W R7652 NRVA6AD-222W CMF RESISTOR 2.2kØ,1/16W R7653 NRVA6AD-222W CMF RESISTOR 2.2kØ,1/16W R7654 NRVA6AD-222W CMF RESISTOR 2.2kØ,1/16W R7657 NRSA6AJ-273W MG RESISTOR 27kØ,1/16W R7658 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R7659 NRSA6AJ-394W MG RESISTOR 390kØ,1/16W R7660 NRSA6AJ-681W MG RESISTOR 680Ø,1/16W R7661 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R7662 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R7663 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R7664 NRSA6AJ-683W MG RESISTOR 68kØ,1/16W R7665 NRSA6AJ-683W MG RESISTOR 68kØ,1/16W R7666 NRSA6AJ-683W MG RESISTOR 68kØ,1/16W R7673 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R7675 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R7680 NRSA6AJ-681W MG RESISTOR 680Ø,1/16W R7681 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R7682 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W C7501 NCB31CK-104X CAPACITOR 0.1µF,16V C7502 NBE90JM-106X T CAPACITOR 10µF,6.3V C7503 NBE91AM-335X T CAPACITOR 3.3µF,10V C7504 NBP41CM-226X T CAPACITOR 22µF,16V C7505 NCBA1CK-103W CAPACITOR 0.01µF,16V C7506 NBE90JM-685X T CAPACITOR 6.8µF,6.3V C7507 NDC31HJ-331X CAPACITOR 330pF,50V C7508 NCB21EK-104X CAPACITOR 0.1µF,25V C7509 NBP41CM-226X T CAPACITOR 22µF,16V C7601 NCBA1AK-104W CAPACITOR 0.1µF,10V C7602 NBEE0JM-476X T CAPACITOR 47µF,6.3V C7603 NBE90JM-106X T CAPACITOR 10µF,6.3V C7604 NCBA1AK-104W CAPACITOR 0.1µF,10V C7605 NCBA1AK-104W CAPACITOR 0.1µF,10V C7606 NCZ1028-225X CAPACITOR 2.2µF C7607 NCF31CZ-104X CAPACITOR 0.1µF,16V C7608 NCZ1028-225X CAPACITOR 2.2µF C7609 NCZ1028-225X CAPACITOR 2.2µF C7610 NBP41CM-226X T CAPACITOR 22µF,16V C7614 NCBA1AK-104W CAPACITOR 0.1µF,10V C7615 NBE20JM-226X T CAPACITOR 22µF,6.3V C7618 NCBA1CK-822W CAPACITOR 0.0082µF,16V C7619 NBE90JM-225X T CAPACITOR 2.2µF,6.3V C7620 NBE90JM-106X T CAPACITOR 10µF,6.3V

5-23

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C7621 NDCA1HJ-151W CAPACITOR 150pF,50V C7623 NDC31HJ-471X CAPACITOR 470pF,50V C7625 NCB30JK-105X CAPACITOR 1µF,6.3V C7626 NDCA1HJ-270W CAPACITOR 27pF,50V C7627 NCBA1AK-104W CAPACITOR 0.1µF,10V C7628 NCB21AK-225X CAPACITOR 2.2µF,10V C7629 NBE90JM-106X T CAPACITOR 10µF,6.3V C7630 NCBA1AK-104W CAPACITOR 0.1µF,10V C7631 NCF31AZ-105X CAPACITOR 1µF,10V C7632 NCF31AZ-105X CAPACITOR 1µF,10V C7636 NCBA1HK-102W CAPACITOR 0.001µF,50V C7637 NCBA1HK-102W CAPACITOR 0.001µF,50V C7638 NCFA1AZ-104W CAPACITOR 0.1µF,10V C7639 NCF31CZ-104X CAPACITOR 0.1µF,16V C7640 NBE81AM-106X T CAPACITOR 10µF,10V C7641 NBE81AM-106X T CAPACITOR 10µF,10V C7642 NBE81AM-106X T CAPACITOR 10µF,10V C7646 NBP81DM-155X T CAPACITOR 1.5µF,20V C7647 NBP81DM-155X T CAPACITOR 1.5µF,20V C7648 NCF31CZ-104X CAPACITOR 0.1µF,16V C7650 NBP41EM-475X T CAPACITOR 4.7µF,25V C7652 NBE90JM-106X T CAPACITOR 10µF,6.3V C7654 NBP41EM-475X T CAPACITOR 4.7µF,25V C7656 NCF31AZ-105X CAPACITOR 1µF,10V L7501 NQLZ008-101X COIL 100µH L7502 NQL38DK-220X COIL 22µH L7503 NQL034K-100X COIL 10µH L7603 NQL38DK-220X COIL 22µH L7604 NQL38DK-220X COIL 22µH L7605 NQL38DK-220X COIL 22µH L7606 NQL013K-150X COIL 15µH L7607 NQL38DK-220X COIL 22µH L7610 NQL38DK-220X COIL 22µH L7611 NQL38DK-220X COIL 22µH T7501 NQS0040-001X SW TRANSF T7502 NAX0334-001 PIEZOELE TRANSF CN7501 QGF0304F1-39X FFC/FPC CONNECTOR CN7502 QGF0517F1-24X FPC CONNECTOR

F7501 NMFZ009-R50X-J1 FUSE T0.5A OT1 LY42526-001A SHIELD SHEET OT2 LY30029-068B SPACER(A) OT3 LY30029-092A SPACER(A) OT4 LY30016-0F6A SPACER-A,A,C,D,E OT5 LY30016-0P9A SPACER-A,A,C,D,E

–PULL DOWN BOARD ASSEMBLY, A,C,D,E –

PW2 YB20835C PULL DOWN BOARD ASSY R7527 NRSA63J-221X MG RESISTOR 220Ø,1/16W WR1 YU40017-020-1 THIN WIRE WR2 YU40017-050-4 THIN WIRE

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

MMC BOARD ASSEMBLY <06>

PW3 YB10288A3 MMC BOARD ASSY,C,D

YB10288A3-01 MMC BOARD ASSY,E,F YB10288B3-01 MMC BOARD ASSY,A,B

R8501 NRSA63J-103X MG RESISTOR,C,D,E,F 10kØ,1/16W

R8502 NRSA63J-473X MG RESISTOR,C,D,E,F 47kØ,1/16W R8503 NRSA63J-103X MG RESISTOR,C,D,E,F 10kØ,1/16W R8504 NRSA63J-104X MG RESISTOR 100kØ,1/16W R8505 NRSA63J-0R0X MG RESISTOR,A,B 0Ø,1/16W

NRSA63J-153X MG RESISTOR,C,D,E,F 15kØ,1/16W

R8506 NRSA63J-333X MG RESISTOR,A,B 33kØ,1/16W

NRSA63J-183X MG RESISTOR,C,D,E,F 18kØ,1/16W R8507 NRSA63J-103X MG RESISTOR,C,D,E,F 10kØ,1/16W R8508 NRSA63J-103X MG RESISTOR,C,D,E,F 10kØ,1/16W R8511 NRSA63J-0R0X MG RESISTOR,C,D,E,F 0Ø,1/16W R8512 NRSA63J-0R0X MG RESISTOR,C,D,E,F 0Ø,1/16W R8513 NRSA63J-0R0X MG RESISTOR,C,D,E,F 0Ø,1/16W R8515 NRSA63J-0R0X MG RESISTOR,C,D,E,F 0Ø,1/16W R8516 NRSA63J-0R0X MG RESISTOR,C,D,E,F 0Ø,1/16W R8517 NRSA63J-0R0X MG RESISTOR,C,D,E,F 0Ø,1/16W C8501 NBE20JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V L8501 NQR0129-002X FERRITE BEAD,C,D,E,F

BT8501 QAB0020-001 LI BATTERY CN601 QGF0505F1-14X FPC CONNECTOR CN602 QGF0505F1-06X FPC CONNECTOR CN604 NNZ0035-001X MMC CONNECTOR,C,D,E,F

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

STROBE BOARD ASSEMBLY <07>,C,D,E,F

PW YB10249C STROBE BOARD ASSY IC6502 TC7SET08FU IC(DIGITAL) Q6501 2SB1462J/RS/-X TRANSISTOR Q6502 UN9211J TRANSISTOR

or DTC114EE TRANSISTOR

Q6503 2SB1124/ST/-X TRANSISTOR Q6504 2SD1628/FG/-X TRANSISTOR Q6506 CT25ASJ-8-X POW TRANSISTOR D6501 F1F16 DIODE D6502 DA121 DIODE D6503 F1SN4 DIODE D6504 CRG02 DIODE R6501 NRSA63J-3R9X MG RESISTOR 3.9Ø,1/16W R6502 NRSA63J-4R7X MG RESISTOR 4.7Ø,1/16W R6504 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R6505 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R6506 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R6507 NRSA02J-106X MG RESISTOR 10MØ,1/10W R6508 NRVA63D-184X CMF RESISTOR 180kØ,1/16W R6511 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R6514 NRSA02J-105X MG RESISTOR 1MØ,1/10W R6515 NRS181J-220X MG RESISTOR 22Ø,1/8W R6516 NRSA02J-104X MG RESISTOR 100kØ,1/10W R6519 NRSA02J-106X MG RESISTOR 10MØ,1/10W R6520 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R6527 NRSA6AJ-391W MG RESISTOR 390Ø,1/16W C6501 NBE41AM-336X T CAPACITOR 33µF,10V C6502 NBE41AM-226X T CAPACITOR 22µF,10V C6503 NCBA1CK-103W CAPACITOR 0.01µF,16V C6506 NCZ1008-333X CAPACITOR 0.033µF C6507 NCZ1019-273X CAPACITOR 0.027µF C6508 NCBA1CK-103W CAPACITOR 0.01µF,16V C6509 NCZ1024-103X CAPACITOR 0.01µF C6512 QEZ0450-326 E CAPACITOR 32µF L6501 NQS0042-001X SW TRANSF

5-24

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

L6502 NQL302N-100X COIL 10µH L6503 NQL044K-470X COIL 47µH HD1 LY31715-001A HOLDER(STROBE) UN1 LY31121-001D STROBE ASSY WR1 WJT0033-001A E-CARD WIRE J6501 QUB490-02A2A2 WIRE J6502 QUB499-02A2A2 WIRE CN6501 QGF0513F1-12X FPC CONNECTOR OT1 LY30016-0F6A SPACER-A OT2 LY30018-037A SPECIAL SCREW OT3 LY41409-002A SPACER(STROBE)

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

AUDIO VF BOARD ASSEMBLY <08>

PW1 YB10285B2-02 AUDIO VF BOARD ASSY,C,D

YB10285C2-02 AUDIO VF BOARD ASSY,A,B

YB10285D2 AUDIO VF BOARD ASSY,E,F IC2101 AK4550VT IC IC2102 AK4550VT IC,C,D,E,F IC2103 JCY0137 IC IC2201 LA74202W IC IC2301 NJM2100V IC,C,D,E,F IC2302 NJM2100V IC,C,D,E,F Q2101 2SC5585 TRANSISTOR Q2102 2SC5585 TRANSISTOR Q2201 2SC4617/QR/-X TRANSISTOR Q2301 2SC4617/QR/-X TRANSISTOR,C,D,E,F Q2401 2SC4617/QR/-X TRANSISTOR Q2403 2SD1511/R/-X TRANSISTOR Q2602 NRSA6AJ-563W MG RESISTOR 56kØ,1/16W

or NRVA6AD-563W CMF RESISTOR 56kØ,1/16W Q2603 2SC4617/QR/-X TRANSISTOR Q2604 2SC4617/QR/-X TRANSISTOR Q2755 UMX1N PAIR TRANSISTOR Q7401 UMZ1N PAIR TRANSISTOR D2001 TLSU1002/LM/-X LE DIODE D2751 DAN222 DIODE R2001 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R2002 NRVA6AD-103W CMF RESISTOR 10kØ,1/16W R2003 NRVA6AD-152W CMF RESISTOR 1.5kØ,1/16W R2004 NRVA6AD-182W CMF RESISTOR 1.8kØ,1/16W R2005 NRVA6AD-272W CMF RESISTOR 2.7kØ,1/16W R2101 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R2102 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R2103 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2104 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2105 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2111 NRSA6AJ-471W MG RESISTOR,C,D,E,F 470Ø,1/16W R2112 NRSA6AJ-471W MG RESISTOR,C,D,E,F 470Ø,1/16W R2113 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R2114 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R2117 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2118 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2119 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2120 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2121 NRSA6AJ-564W MG RESISTOR,C,D,E,F 560kØ,1/16W R2122 NRSA6AJ-564W MG RESISTOR,C,D,E,F 560kØ,1/16W

R2131 NRSA6AJ-100W MG RESISTOR 10Ø,1/16W R2132 NRSA6AJ-100W MG RESISTOR 10Ø,1/16W R2133 NRSA6AJ-100W MG RESISTOR 10Ø,1/16W R2134 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2135 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2136 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2137 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2138 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2139 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2141 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2202 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2203 NRSA6AJ-2R7W MG RESISTOR 2.7Ø,1/16W R2204 NRSA6AJ-2R7W MG RESISTOR 2.7Ø,1/16W R2205 NRSA6AJ-823W MG RESISTOR 82kØ,1/16W R2206 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2208 NRSA6AJ-392W MG RESISTOR 3.9kØ,1/16W R2210 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2220 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2221 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2224 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R2228 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2229 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2234 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2301 NRSA6AJ-560W MG RESISTOR,C,D,E,F 56Ø,1/16W R2302 NRSA6AJ-560W MG RESISTOR,C,D,E,F 56Ø,1/16W R2303 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R2305 NRSA6AJ-183W MG RESISTOR,C,D,E,F 18kØ,1/16W R2306 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R2307 NRSA6AJ-183W MG RESISTOR,C,D,E,F 18kØ,1/16W R2308 NRSA6AJ-473W MG RESISTOR,E,F 47kØ,1/16W R2309 NRSA6AJ-184W MG RESISTOR,C,D 180kØ,1/16W

NRSA6AJ-224W MG RESISTOR,E,F 220kØ,1/16W R2310 NRSA6AJ-393W MG RESISTOR,C,D 39kØ,1/16W R2311 NRSA6AJ-473W MG RESISTOR,C,D,E,F 47kØ,1/16W R2312 NRSA6AJ-183W MG RESISTOR,C,D,E,F 18kØ,1/16W R2313 NRSA6AJ-473W MG RESISTOR,E,F 47kØ,1/16W R2314 NRSA6AJ-183W MG RESISTOR,C,D,E,F 18kØ,1/16W R2315 NRSA6AJ-393W MG RESISTOR,C,D 39kØ,1/16W R2316 NRSA6AJ-224W MG RESISTOR,E,F 220kØ,1/16W

NRSA6AJ-184W MG RESISTOR,C,D 180kØ,1/16W R2317 NRSA6AJ-104W MG RESISTOR,C,D,E,F 100kØ,1/16W R2318 NRSA6AJ-104W MG RESISTOR,C,D,E,F 100kØ,1/16W R2319 NRSA6AJ-104W MG RESISTOR,C,D,E,F 100kØ,1/16W R2320 NRSA6AJ-104W MG RESISTOR,C,D,E,F 100kØ,1/16W R2321 NRSA6AJ-104W MG RESISTOR,C,D,E,F 100kØ,1/16W R2322 NRSA6AJ-104W MG RESISTOR,C,D,E,F 100kØ,1/16W R2323 NRSA6AJ-104W MG RESISTOR,C,D,E,F 100kØ,1/16W R2324 NRSA6AJ-104W MG RESISTOR,C,D,E,F 100kØ,1/16W R2325 NRSA6AJ-104W MG RESISTOR,C,D,E,F 100kØ,1/16W R2326 NRSA6AJ-104W MG RESISTOR,C,D,E,F 100kØ,1/16W R2327 NRSA6AJ-102W MG RESISTOR,C,D,E,F 1kØ,1/16W R2328 NRSA6AJ-103W MG RESISTOR,C,D,E,F 10kØ,1/16W R2329 NRSA63J-0R0X MG RESISTOR,C,D,E,F 0Ø,1/16W R2330 NRSA63J-0R0X MG RESISTOR,C,D,E,F 0Ø,1/16W R2333 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R2334 NRSA6AJ-0R0W MG RESISTOR,C,D,E,F 0Ø,1/16W R2401 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2402 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R2412 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R2413 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2415 NRSA6AJ-560W MG RESISTOR 56Ø,1/16W

5-25

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R2429 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2601 NRSA6AJ-182W MG RESISTOR 1.8kØ,1/16W R2602 NRSA6AJ-182W MG RESISTOR 1.8kØ,1/16W R2603 NRSA6AJ-123W MG RESISTOR 12kØ,1/16W R2604 NRSA6AJ-123W MG RESISTOR 12kØ,1/16W R2609 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2610 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2613 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2614 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2615 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R2616 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R2619 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2620 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2621 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2622 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2623 NRSA6AJ-5R6W MG RESISTOR 5.6Ø,1/16W R2624 NRSA6AJ-5R6W MG RESISTOR 5.6Ø,1/16W R2627 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2628 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2629 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R2630 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R2631 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R2632 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R2633 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R2634 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R2635 NRSA6AJ-0R0W MG RESISTOR,A,B 0Ø,1/16W R2636 NRSA6AJ-0R0W MG RESISTOR,A,B 0Ø,1/16W R2640 NRSA6AJ-182W MG RESISTOR 1.8kØ,1/16W R2641 NRSA6AJ-182W MG RESISTOR 1.8kØ,1/16W R2642 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2643 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R2715 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2756 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2757 NRSA6AJ-564W MG RESISTOR 560kØ,1/16W R2758 NRSA6AJ-564W MG RESISTOR 560kØ,1/16W R2759 NRSA6AJ-821W MG RESISTOR 820Ø,1/16W R2760 NRSA6AJ-821W MG RESISTOR 820Ø,1/16W R2775 NRSA6AJ-473W MG RESISTOR,E,F 47kØ,1/16W

NRSA6AJ-223W MG RESISTOR,C,D 22kØ,1/16W

R2776 NRSA6AJ-473W MG RESISTOR,E,F 47kØ,1/16W

NRSA6AJ-223W MG RESISTOR,C,D 22kØ,1/16W R2777 NRSA6AJ-103W MG RESISTOR,C,D,E,F 10kØ,1/16W R2778 NRSA6AJ-103W MG RESISTOR,C,D,E,F 10kØ,1/16W R7427 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R7428 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R7429 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R7430 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R7442 NRVA6AD-183W CMF RESISTOR 18kØ,1/16W R7443 NRSA6AJ-334W MG RESISTOR 330kØ,1/16W R7444 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R7445 NRSA6AJ-393W MG RESISTOR 39kØ,1/16W C2101 NCB30JK-105X CAPACITOR 1µF,6.3V C2102 NCB30JK-105X CAPACITOR 1µF,6.3V C2103 NCBA1HK-222W CAPACITOR 0.0022µF,50V C2104 NCBA1HK-222W CAPACITOR 0.0022µF,50V C2105 NBE90JM-475X T CAPACITOR 4.7µF,6.3V C2106 NCB31CK-104X CAPACITOR 0.1µF,16V C2107 NCB31CK-104X CAPACITOR 0.1µF,16V C2108 NBE90JM-106X T CAPACITOR 10µF,6.3V C2111 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C2112 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V

C2113 NCBA1HK-222W CAPACITOR,C,D,E,F 0.0022µF,50V C2114 NCBA1HK-222W CAPACITOR,C,D,E,F 0.0022µF,50V C2115 NBE90JM-475X T CAPACITOR,C,D,E,F 4.7µF,6.3V C2116 NCB31CK-104X CAPACITOR,C,D,E,F 0.1µF,16V C2117 NCB31CK-104X CAPACITOR,C,D,E,F 0.1µF,16V C2118 NBE90JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V C2119 NCB31CK-104X CAPACITOR,C,D,E,F 0.1µF,16V C2120 NCB31CK-104X CAPACITOR,C,D,E,F 0.1µF,16V C2131 NBE90JM-106X T CAPACITOR 10µF,6.3V C2132 NCB31CK-104X CAPACITOR 0.1µF,16V C2134 NDCA1HJ-101W CAPACITOR 100pF,50V C2136 NDCA1HJ-101W CAPACITOR 100pF,50V C2137 NDCA1HJ-101W CAPACITOR 100pF,50V C2203 NBE90JM-475X T CAPACITOR 4.7µF,6.3V C2204 NBE90JM-106X T CAPACITOR 10µF,6.3V C2207 NCBA1AK-104W CAPACITOR 0.1µF,10V C2208 NCBA1AK-104W CAPACITOR 0.1µF,10V C2210 NBE40JM-476X T CAPACITOR 47µF,6.3V C2211 NBE40JM-476X T CAPACITOR 47µF,6.3V C2212 NBE90JM-106X T CAPACITOR 10µF,6.3V C2214 NCB31CK-104X CAPACITOR 0.1µF,16V C2215 NCB31CK-104X CAPACITOR 0.1µF,16V C2216 NCBA1CK-103W CAPACITOR 0.01µF,16V C2217 NCBA1AK-104W CAPACITOR 0.1µF,10V C2220 NCB30JK-105X CAPACITOR 1µF,6.3V C2221 NCB30JK-105X CAPACITOR 1µF,6.3V C2224 NCBA1AK-104W CAPACITOR 0.1µF,10V C2227 NCB21CK-105X CAPACITOR 1µF,16V C2230 NCB31CK-104X CAPACITOR 0.1µF,16V C2301 NBE90JM-106X T CAPACITOR,C,D,E,F 10µF,6.3V C2303 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C2304 NCB30JK-105X CAPACITOR,C,D 1µF,6.3V C2305 NCB30JK-105X CAPACITOR,C,D 1µF,6.3V C2306 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C2307 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C2308 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C2309 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C2310 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C2311 NCB31CK-104X CAPACITOR,C,D,E,F 0.1µF,16V C2312 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C2313 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C2314 NCB30JK-105X CAPACITOR,C,D,E,F 1µF,6.3V C2315 NCB31CK-104X CAPACITOR,C,D,E,F 0.1µF,16V C2316 NCB31CK-104X CAPACITOR,C,D,E,F 0.1µF,16V C2402 NBE90JM-106X T CAPACITOR 10µF,6.3V C2412 NBE40JM-476X T CAPACITOR 47µF,6.3V C2413 NBE40JM-476X T CAPACITOR 47µF,6.3V C2603 NCB31EK-472X CAPACITOR 0.0047µF,25V C2604 NCB31EK-472X CAPACITOR 0.0047µF,25V C2605 NCBA1HK-152W CAPACITOR 0.0015µF,50V C2606 NCBA1HK-152W CAPACITOR 0.0015µF,50V C2611 NCB31CK-333X CAPACITOR 0.033µF,16V C2612 NCB31CK-333X CAPACITOR 0.033µF,16V C2613 NCBA1HK-332W CAPACITOR 0.0033µF,50V C2614 NCBA1HK-332W CAPACITOR 0.0033µF,50V C2617 NCB31CK-273X CAPACITOR 0.027µF,16V C2618 NCB31CK-273X CAPACITOR 0.027µF,16V C2621 NBE90JM-475X T CAPACITOR 4.7µF,6.3V C2622 NBE90JM-475X T CAPACITOR 4.7µF,6.3V C2625 NCB31CK-104X CAPACITOR 0.1µF,16V C2626 NCB31CK-104X CAPACITOR 0.1µF,16V

5-26

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C2627 NCBA1HK-102W CAPACITOR 0.001µF,50V C2628 NCBA1HK-102W CAPACITOR 0.001µF,50V C2629 NBE20GM-336X T CAPACITOR 33µF,4.0V C2631 NCB31EK-103X CAPACITOR 0.01µF,25V C2632 NCB31EK-103X CAPACITOR 0.01µF,25V C2635 NCB30JK-105X CAPACITOR 1µF,6.3V C2636 NCB30JK-105X CAPACITOR 1µF,6.3V C2639 NCB31CK-104X CAPACITOR 0.1µF,16V C2640 NCB31CK-104X CAPACITOR 0.1µF,16V C2702 NBE90GM-226X T CAPACITOR 22µF,4.0V C2703 NBE90GM-226X T CAPACITOR 22µF,4.0V C2753 NCB20JK-225X CAPACITOR 2.2µF,6.3V C2754 NCB20JK-225X CAPACITOR 2.2µF,6.3V C2764 NCB20JK-225X CAPACITOR 2.2µF,6.3V C2765 NCB20JK-225X CAPACITOR 2.2µF,6.3V C2766 NCB21CK-474X CAPACITOR,E,F 0.47µF,16V C2767 NCB21CK-474X CAPACITOR,E,F 0.47µF,16V C2768 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W C2769 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W C7427 NBP41DM-106X T CAPACITOR 10µF,20V C7428 NCB21CK-105X CAPACITOR 1µF,16V C7429 NBE21AM-106X T CAPACITOR 10µF,10V C7431 NBE20JM-106X T CAPACITOR 10µF,6.3V L2101 NQL402M-100X COIL 10µH L2102 NQL402M-100X COIL,C,D,E,F 10µH L2131 NQL402M-100X COIL 10µH L2601 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2602 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2603 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2604 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L7403 NQL045K-100X COIL 10µH L7404 NQL045K-100X COIL 10µH S7001 NSW0129-001X PUSH SWITCH CN801 QGB0401L1-A0X CONNECTOR CN802 QGF0517F2-12X FPC CONNECTOR CN803 QGF0517F1-06X FPC CONNECTOR CN804 QGA1001F1-05X CONNECTOR CN805 QGF0507F1-20X FPC CONNECTOR OT1 LY42535-001A SHEET(AUD.PWB) OT2 LY42775-001A S.SHEET(AU/VF)

L2852 NQR0251-004X FERRITE BEAD L2853 NQR0251-004X FERRITE BEAD J2851 QNS0078-001 3.5 JACK CN901 QGF0507F1-16X FPC CONNECTOR CN902 QGF0517F2-08X FPC CONNECTOR

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

W/B BOARD ASSEMBLY <11>

PW3 YB10285A3 W/B BOARD ASSY Q1151 RPM-22PB PHOTO TRANSISTOR R1151 NRSA63J-302X MG RESISTOR 3kØ,1/16W C1151 NBE90JM-106X T CAPACITOR 10µF,6.3V C1152 NCB21EK-683X-R CAPACITOR 0.068µF,25V L1151 NQR0265-001X FERRITE BEAD WR1 WJM0144-001A E-SI C WIRE C-F

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

EJECT BOARD ASSEMBLY <12>

PW2 YB10288A2-01 EJECT BOARD ASSY S1 NSW0120-002X PUSH SWITCH WR1 WJM0145-001A E-SI C WIRE C-F

✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽

JACK BOARD ASSEMBLY <09>

PW1 YB10288C1 JACK BOARD ASSY Q2851 2SD1979/S/-X TRANSISTOR D2852 MA8068 ZENER DIODE R2851 NRSA63J-183X MG RESISTOR 18kØ,1/16W R2852 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2853 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2854 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2855 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W C2854 NCB31EK-223X CAPACITOR 0.022µF,25V C2856 NCB31EK-153X CAPACITOR 0.015µF,25V C2859 NCB31HK-332X CAPACITOR 0.0033µF,50V C2860 NCB31HK-102X CAPACITOR 0.001µF,50V L2851 NQR0251-004X FERRITE BEAD

5-27
