CONTENTS

NOTE ON USING CIRCUIT DIAGRAMS
SEMICONDUCTOR SHAPES
BLOCK DIAGRAM
CIRCUIT DIAGRAMS
PATTERN DIAGRAMS
CHANNEL CHART

COPYRIGHT 2002 VICTOR COMPANY OF JAPAN, LTD.

2-1
2-2
2-3
2-7
2-19
2-26

No.51947

May 2002

AV-32D503

STANDARD CIRCUIT DIAGRAM

NOTE ON USING CIRCUIT DIAGRAMS

1.SAFETY

The components identified by the symbol and shading are
critical for safety. For continued safety replace safety critical
components only with manufactures recommende d parts.

2.SPECIFIED VOLTAGE AND WAVEFORM VALUES

The voltage and waveform values have been measured under the
following c ondit ions.

(1)Input signal : Colour bar signal

(2)Setting positions of
each knob/button and
variable resistor

(3)Internal resistance of test er

:DC 20k

/V

(4)Oscilloscope sweeping time

:H

20µS/div

:V

5mS/div

:Others

Sweeping time is
specified

(5)Voltage values

:All DC voltage values

Since the voltage values of signal circuit vary to some extent
according to adjustments, use them as reference values.

3.INDICATION OF PARTS SYMBOL [EXAMPLE]

In the PW board

:R1209

R209

4.IND ICATIONS ON THE CIRCUIT DIAGRAM

(1)Resistors

Resistance value
No unit :[

]

K

:[K

]

M

Rated allowa ble power
No indication :1/ 16 [W]
Others :As specifi ed

Type
No indication

:Carbon resistor

OMR

:Oxide metal film resistor

MFR

:Metal film resistor

MPR

:Metal plate resistor

UNFR

:Uninflammable resistor

FR

:Fusible resistor

Composition resistor 1/2 [W] is spe cified as 1/2S or Comp.

(2)Capacitors

: Original setting position
when shipped

5.NO T E FOR REPAIR IN G S ERVI CE

This mod el's power cir cuit is pa rtly diffe rent in the GND. The
difference of the GND is shown by the LIVE : ( ) side GND and the
ISOLATED(NEUTRAL) : ( ) side GND.Therefore, care must be
taken for the following points.

(1)Do not touch the LIVE side GND or the LIVE side GND and the
ISOLATED(NEUTRAL) side GND simultaneously. If the above
caution is not respected, an electric shock may be caused.
Therefore, make sure that the power cord is surely removed from
the receptacle when, for example, the chassis is pulled out.

(2)Do not short between the LIVE side GND and ISOLATED(NEUTRAL)
side GND or never measure with a measuring apparatus measure
with a measuring apparatus ( oscilloscope, etc.) the LIVE side GND
and ISOLATED(NEUTRAL) side GND at the same time.
If the above precaution is not respected , a fuse or any parts will be broken.

Since the circuit diagram is a standard one, the ci rcuit and
circuit constants may be subject to change for i mprovement
without any notice.

NOTE
Due improvement in performance, some part numbers show
in th e ci rcui t diag ram may not agre e wi th tho se i ndic ate d i n
the part list.
When ordering parts, pl ease use t he numbers t hat appear
in the Parts List.

Type

MM

:Metalized mylar capacitor

PP

:Polypropylene capacitor

MPP

:Metalized polypropylene capacitor

MF

:Metalized film capacitor

TF

:Thin film capacitor

BP

:Bipolar electrolytic capacitor

TAN

:Tantalum capacitor

(3)Coils

No unit

:[

µ

H]

Others

:As specified

(4)Power Supply

:B1

:9V

:5V

Respective voltage values are indicated

(5)Test p oint

:T est point

:Only test point display

(6)Connecting method

:Connector

:Wrapping or soldering

:Receptacle

(7)Ground symbol

:LIVE side ground
:ISOLATED(NEUTRAL) side ground
:EARTH ground
:DIGITAL ground

:[M ]

Capacitance value

1 or higher :[pF]

less tha n 1

:[µF]
Withstand v oltage
No indication :DC50[V]

Others :DC withstand voltage [V]
AC indicated

:AC withstand voltage [V]

Electrolytic Capacitors

47/50[Example]:Capacitance value [µF]/withstand voltage[V]

No indication

:Ceramic capacitor

:B2 (12V)

AV-32D503

/M/R/Y

,AV-32D303

/M/R/Y

,AV-32D203

/M/R/Y

AV-32D303
AV-32D203

AV-32D503
AV-32D303
AV-32D203

No.51947

VP0205

DP6060

May 2002 No. 51947

AV-32D503

CHANNEL CHART (CA)

MODE CHANNEL

TV CATV

BAND

REAL DISP

.

TUNER

BAND

02
03

VL 04

05
06
07
08
09

VH 10

11
12

13
A14
B15

C16
D17

MID E 18

F19

G20
H21

I22
J23
K24
L25

M26
N27
O28

SUPER P 29

Q30
R31

S32
T33

U34

V35

W36
W+1 37
W+2 38
W+3 39
W+4 40
W+5 41
W+6 42
W+7 43
W+8 44
W+9 45

W+10 46
W+11 47
W+12 48
W+13 49
W+14 50

HYPER W+15 51

W+16 52
W+17 53
W+18 54
W+19 55
W+20 56
W+21 57
W+22 58
W+23 59
W+24 60
W+25 61
W+26 62
W+27 63
W+28 64
W+29 65
W+30 66

ULTRA W+31 67

W+32 68
W+33 69
W+34 70

MODE CHANNEL

TUNER

TV CATV REAL DISP

.

BAND

W+35 71
W+36 72
W+37 73
W+38 74
W+39 75
W+40 76
W+41 77
W+42 78
W+43 79
W+44 80
W+45 81
W+46 82
W+47 83
W+48 84
W+49 85
W+50 86
W+51 87
W+52 88
W+53 89
W+54 90
W+55 91
W+56 92
W+57 93
W+58 94
W+59 100

ULTRA W+60 101

W+61 102
W+62 103
W+63 104
W+64 105
W+65 106
W+66 107
W+67 108
W+68 109
W+69 110
W+70 111
W+71 112
W+72 113
W+73 114
W+74 115
W+75 116
W+76 117
W+77 118
W+78 119
W+79 120
W+80 121
W+81 122
W+82 123
W+83 124
W+84 125

A-8 01

SUB

A-4 96

MID

A-3 97
A-2 98
A-1 99

14

UHF

69

TOTAL 180CH

VHF 124CH
UHF 56CH

NOTE:

TO RECEIVE THE SUBSCRIPTION OR

PREMIUM PROGRAMMING FROM CERTAIN
CABLE COMPANIES.
SPECIAL ADAPTERS MAY BE REQUIRED.

BAND

AV-32D303
AV-32D203

CONTENTS

AV-32D503
AV-32D303
AV-32D203

SEMICONDUCTOR SHAPES

BLOCK DIA GRAM
CIRCUIT DIAGRAMS

MAIN PWB CIRCUIT DIAGRAM
AV SEL PWB CIRCUIT DIAGRAM
PIP PWB CIRCUIT DIAGRAM
CRT SOCKET PWB CIRCUIT DIAGRAM
FRONT CONTROL PWB CIRCUIT DIAGRAM
FRONT AV IN PWB CIRCUIT DIAGRAM

P ATTERN DIAGRAMS

MAIN PW B PAT TERN

AV SEL

CRT SOCKET PWB PATTERN
PIP PWB PAT TERN
FRONT CONTROL PWB PATTERN
FRONT AV IN PWB PATTERN

CHANNEL CHART
CHANNEL CHART

SEMICONDUCTOR SHAPES

TRANSISTOR

BOTTOM VIE W

IC

B O TT OM VI EW F R O NT VIEW TO P VI EW

CHIP IC

2-2

PWB PATTERN

OUT
E
IN

N

N

E
C

B

N

1

N

(US)
(CA)

ECB

IN OUTE

BCE

(G)(D)(S)

FRONT VI EW

1 N

TO P VI EW

ECB

1

N

ECB

1 N

CHIP TR

1

TO P VI EW

C

BE

N

2-2
2-3

2-7
2-11
2-13
2-15
2-17
2-18

2-19
2-21
2-23
2-24
2-25
2-25

2-26
2-27

No.51947No.51947

2-27

BLOCK DIAGRAM

AV-32D503
AV-32D303
AV-32D203

AV-32D503
AV-32D303
AV-32D203

VIDEO

INPUT 1

VIDEO

INPUT 2

AUDIO

OUT

VIDEO

INPUT 3

Y/C

V1
L1
R1

V2
L2
R2

L
R

V3
L3
R3

F. AV IN PWB

Y/C

V1

L1/R1

V2

L2/R2

V3

L3/R3

IC5501

AV SW

VTV

Y/C OUT

L/R OUT

MON L/R

Y
C

MPX

V

IC5201

3L DIGI

IC5001

MTSIC

PIP PWB

FRONT CONTROL

PWB

Y

C

AV SEL PWB

L/R

IC5151

BBE

L/R

TU4001

TUNER

IF

IC4101

IF DET

V PIP

IC4301

PIP

CONTROLER

PIP
R/G/B

RM LED SW

CRT SOCKET

PWB

Q3351

R/G/B

Q3353

RGB DRV

CRT

COMPO-

-NENT
INPUT

COMPU

LINK EX

VTV

PIP

TU001

TUNER

IF

IC101

MPX

Y/Pb/Pr

IF DET

Y/C OUT

Y

Pb
Pr

IC601

SW

Y
R-Y
B-Y

IC201

MICOM/V/C/DEF

R/G/B

R/G/B

L , R

L/R

IC621

AUDIO AMP

L R

L

R

SP L

SP R

IC702

COMP LINK

V

H

MEMORY

DY01

(ITC)

H

MAIN PWB

Q511

H.OUT

T921

LF901

D901

SW.

TRANSF.

IC421

VERT OUT

B1

V

No.51947

IC911

POWER IC

PC921

VOLTAGE

FEED BACK

IC921

ERROR

AMP

2-3 2-4

B1

T502

HVT

No.51947

FOCUS
SCREEN

BLOCK DIAGRAM

VIDEO

INPUT 1

VIDEO

INPUT 2

AUDIO

OUT

VIDEO

INPUT 3

V3
L3
R3

V1
L1
R1

V2
L2
R2

AV-32D503
AV-32D303
AV-32D203

AV-32D503
AV-32D303
AV-32D203

FRONT CONTROL

Y/C

L
R

Y/C

V1

L1/R1

V2

L2/R2

V3

L3/R3

IC5501

AV SW

VTV

Y/C OUT

L/R OUT

MON L/R

Y
C

MPX

V

IC5201

3L DIGI

IC5001

MTSIC

Y

C

AV SEL PWB

L/R

IC5151

BBE

L/R

R/G/B

PWB

RM LED SW

CRT SOCKET

PWB

Q3351

Q3353

RGB DRV

CRT

COMPO-

-NENT
INPUT

COMPU

LINK EX

F. AV IN PWB

TU001

TUNER

Y

Pb
Pr

LF901

D901

VTV

Y/Pb/Pr

IF

IC101

MPX

R/G/B

IF DET

Y/C OUT

L/R

IC621

AUDIO AMP

L , R

L R

L

R

SP L

SP R

IC201

MICOM/V/C/DEF

IC702

COMP LINK

V

H

MEMORY

DY01

(ITC)

H

MAIN PWB

Q511

H.OUT

T921

SW.

TRANSF.

IC421

VERT OUT

B1

V

B1

IC911

POWER IC

PC921

VOLTAGE

FEED BACK

No.51947 No.51947

IC921

ERROR

AMP

2-5 2-6

T502

HVT

FOCUS
SCREEN
