JVC AV-14A10, AV-14F10, AV-20N10, AV-21A10, AV-21D10 User Manual

...

COLOUR TELEVISION

15 cm

10 cm 15 cm

10 cm

AV-14A10 AV-14F10 AV-20N10 AV-21A10 AV-21D10 AV-21F10

INSTRUCTIONS

Thank you for purchasing this JVC colour television. To ensure your complete understanding, please read this manual thoroughly before operation.

Locations ................................

Preparation .............................

Basic operation ......................

Remote control buttons

and functions........................

Using the TV’s menus ..........

Using the button on the TV ...

Troubleshooting ...................

Specifications .......................

Contents

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION:

• TO ENSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES REGARDING THE USE OF THIS TV.

• Operate only from the power source specified on the TV.

• Avoid damaging the power plug and power cord.

• Avoid improper installation and never position this TV where good ventilation is unattainable. When installing this TV distance recommendations must be maintained between the floor and wall, as well as installment in a tightly enclosed area or piece of furniture. Adhere to the minimum distance guidelines shown for safe operation.

• Do not allow objects or liquid into the cabinet openings.

• In the event of a fault, unplug this TV and call a service technician. Do not attempt to repair it by yourself or remove the rear cover.

• When you don’t use this TV for a long period of time, be sure to disconnect the power plug from the AC outlet.

10 13 16

Locations

POWER

123

456

789

RETURN+

0-/


MODE

SYSTEM

COLOUR

TV/VIDEO

CHANNEL

SCAN

OFF

TIMER

DISPLAY

VOLUME

MUTING

SOUND

! @

CHANNEL

REMOTE CONTROL UNIT RM-C360GY

RM-C364GY RM-C360GY

1 2

ECO

SENSOR

SYSTEM

COLOUR

TV/VIDEO

SOUND

POWER


MODE

123

4 5

6 7

OFF

TIMER

CHANNEL

SCAN

DISPLAY

456

789

RETURN

0-/

MUTING

CHANNEL

VOLUME

REMOTE CONTROL UNIT RM-C364GY

1 ECO SENSOR button p.11 2 SOUND SYSTEM button p.10 3 COLOUR SYSTEM button p.10 4 TV/VIDEO button p.9 5 OFF TIMER button p.11 6 CHANNEL SCAN button p.12 7 RETURN + button p.12 8 DISPLAY button p.11 9 CHANNEL –/+ buttons p.9

~ !

0 POWER button p.5,9

- PICTURE MODE button p.10 = Number buttons p.9 ~ -/-- button p.9 ! MUTING button p.11 @ MENU buttons

• MENU / buttons

• MENU –/+ buttons

# VOLUME –/+ buttons p.9

Preparation

1. Connecting the aerial and external devices

Notes: .........................................................................................................................

• For further details, refer to the manuals provided with the devices you are connecting.

• Connecting cables are not supplied.

• The front and rear AUDIO/VIDEO input jacks are directly connected so that input to either

jack is output through both. You cannot provide input to both the front and rear jacks at the same time. Disconnect one input, or use one of the jacks as an output jack only (for monitoring or recording).

• The rod aerial is supplied with the AV-14A10 and AV-14F10.

....................................................................................................................................

■ Connecting the aerial and VCR

Connecting the aerial

To install rod aerial:

Install into the top-rear aerial holder. Once installed, it cannot be removed.

VHF/UHF outdoor aerial

VIDEO

AUDIO

OUT

Indoor aerial

Rod aerial

• Illustration of AV-14F10.

Connecting the aerial and VCR

VHF/UHF outdoor aerial

To RF output

To video output

To aerial input

VIDEO

AUDIO

OUT

To audio output

VCR

• Illustration of AV-14F10.

Preparation

■ Connecting other external devices

VIDEO

• Illustration of AV-21D10.

AUDIO

OUT

To audio output

VCR (for playing)

VCR (for recording)

To audio input

To video output

To audio output

To video output

To video input

Camcorder

TV game

VIDEO AUDIO

Headphones

• Illustration of AV-21D10.

Note: ..................................................................................................................

• Use the headphones with a stereo mini jack (3.5 mm in diameter). When you connect the headphones, the TV speakers go off.

...........................................................................................................................

Preparation

2. Connecting the power cord

Insert the Power plug into an AC outlet.

3. Inserting batteries into the remote control

Correctly insert two batteries, observing the and polarities and inserting the

end first.

CAUTION:...........................................

• Follow the cautions printed on the batteries.

............................................................

Notes: .................................................

• Use AA/R6/UM-3 dry cell batteries.

• If the remote control does not work

properly, fit new batteries. The supplied batteries are for testing, not regular use.

............................................................

4. Turning your TV on

Press the Main power button on the TV to turn the TV’s main power on.

The POWER lamp or POWER/ON TIMER lamp lights.

If image does not appear:

Your TV is in the standby mode. Press the POWER button on the remote control to turn your TV on.

• You can also turn on your TV by pressing the CHANNEL –/+ button on your TV.

To turn your TV off:

Press the POWER button on the remote control. Your TV enters the standby mode.

To turn the TV’s main power off:

Press the Main power button on the TV.

Preparation

MENU 3 AUTO CH PRESET MANUAL CH PRESET LANGUAGE ENGLISH

SELECT BY EXIT BY OPERATE BY -+

DISPLAY

5. Selecting the on-screen language

You can select the language for the on-screen display.

Press MENU then select

Press MENU –/+ to select language.

to display the

LANGUAGE

MENU 3

The on-screen displays indications are in the selected

menu,

MENU 3 AUTO CH PRESET MANUAL CH PRESET LANGUAGE ENGLISH

SELECT BY EXIT BY OPERATE BY -+

DISPLAY

language.

6. Presetting TV stations

To view a TV programme, you must first preset TV channels to channels on the TV. This TV has 100 channels (channel 1 to 99 and channel AV).

■ Auto Channel Preset

You can automatically preset all TV channels that can be received by your TV to channels.

• The Auto Channel Preset function does not preset a TV channel to the AV channel (channel number 0).

• If the TV cannot preset the TV channel you want to view, preset it manually. For details see “Manual Channel Preset” on page 7.

Press MENU then select

Press MENU –/+ to start the Auto Channel Preset function.

ON SEARCH

When you have finished presetting all TV channels that can be received on your TV, the display will go out and the Auto Channel Preset function will end.

• To stop the Auto Channel Preset, press the MENU –/+ button.

to display the

AUTO CH PRESET

is displayed on the screen.

MENU 3

menu,
