Jungheinrich EMC-110 User Manual

Flexible operation even on small ramps and uneven ground
3-phase AC drive system
Travel with upright tiller using the crawl speed button
Compact and manoeuvrable
Easy charging at the mains with integrated charger
EMC 110 with ramp comfort
Electric pedestrian stacker (1,000 kg)
The EMC 110 electric pedestrian stacker with ramp comfort feature combines performance eciency, user friendliness and operator safety. It oers a wide range of options for almost all applications. For example: Sorting goods in racking or feeding them onto a machine. The goods are simply raised to the required picking height and then deposited or removed from the pallet without straining the operator’s back. Ergonomic and technical advantages make the EMC especially easy to handle:
• The long tiller requires little steering eort and increases safety.
• The precise lowering function (optional) ensures gentle depositing of especially delicate materials in the racking or on the floor.
• The ramp comfort feature activates a simple support arm lift. This increases the ground clearance significantly - in particular around the front support arm. The advantage: Easy crossing of thresholds, uneven surfaces or small ramps without grounding.
All travel and lift functions can be con­trolled eortlessly from the multifunc­tional tiller arm. The crawl speed button allows the EMC to operate even in very
confined spaces with the tiller upright. The EMC also oers impressive features for easy power management: The main­tenance-free 70-Ah block batteries can be recharged simply by connecting the built-in charger to any standard 240 volt mains socket. The battery discharge indicator continually displays the battery charge status. The innovative 3-phase AC drive motor provides outstanding performance for this truck category, pro­viding ideal conditions for ecient and economic operation.
EMC 110 with ramp comfort
14
h
1
h
14
max.
h
14
min.
l
2
151
Wa
l
x
c
h
3
h
2
Q
m
2
s
y
l
1
h
13
b2b
e
b
b
5
11
10
a 2
(l6)
Ast
(b12)
a 2
%
Technical data in line with VDI 2198
1.1 Manufacturer (short form) Jungheinrich
1.2 Model EMC 110
1.3 Drive Electrics
1.4 Manual, pedestrian, stand-on, seated, order picker operation pedestrian
1.5 Load capacity/rated load Q t 1
1.6 Load centre distance c mm 600
Identification
1.8 Load distance x mm 784
1.9 Wheelbase y mm 1168
2.1.1 Net weight incl. battery (see row 6.5) kg 545
2.2 Axle load, w. load, front / rear kg 555 / 990
2.3 Axle load, w.o. load, front / rear kg 400 / 145
Weights
3.1 Tyres PU / Pevopur
3.2 Tyre size, at front mm Ø 230 x 70
3.3 Tyre size, at rear mm Ø 80 x 90
3.4 Additional wheels (dimensions) mm Ø 150 x 54
3.5 Wheels, number front/rear (× = driven wheels) 1x +1/2
3.6 Track width, front b
Wheels / chassis
3.7 Track width, rear b
4.2 Mast height (lowered) h1 mm 1970
4.3 Free lift h2 mm 1507
4.4 Lift h
4.5 Extended mast height h4 mm 1992
4.9 Height of tiller in drive position min. / max. h14 mm 821 / 1305
4.15 Lowered height h
4.19 Overall length l
4.20 Length incl. back of forks l
4.21 Total width b
4.22 Fork dimensions s/e/l mm 56 / 185 / 1150
Basic dimensions
4.25 Width over forks b
4.32 Floor clearance centre wheelbase m
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 1944
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 1994
4.35 Turning radius Wa mm 1378
5.1 Travel speed, w. / w.o. load km/h 4.2 / 5
5.2 Lift speed, w. / w.o. load m/s 0.09 / 0.12
5.3 Lower speed, w. / w.o. load m/s 0.11 / 0.11
data
5.7 Gradeability laden/unladen % 3.5 / 15
Performance
5.10 Service brake generated
6.1 Drive motor rating S2 60 min. kW 0.5
6.2 Lift motor rating at S3 15% kW 1.2
6.3 Battery according to DIN 43531/35/36 A,B,C, no no
6.4 Battery voltage/nominal capacity K5 V/Ah 2x 12 / 70
Electrics
6.5 Battery weight kg 63
6.6 Energy consumption according to VDI cycle kWh/h 0.55
8.1 Type of drive control AC SpeedControl
8.4
Misc.
Sound pressure level at operator’s ear according to EN 12053
mm 510
10
mm 415
11
mm 1540
3
mm 90
13
mm 1685
1
mm 535
2
mm 800
1/b2
mm 570
5
mm 30
2
dB (A) 70
Issue: 04/2008
3)
3)
3)
3)
2)
1)
1)
Diagonal in accordance with VDI: + 159 mm
2)
Diagonal in accordance with VDI: + 262 mm
3)
High mast version: + 460 mm
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may result in different values.
Benefit from the advantages
Used as a lift table Greater ground clearance with the
Safe and comfortable stacking and retrieval
All lifting and lowering functions are conveniently controlled from the multi­functional tiller arm:
• Precise and gentle depositing of loads into the racking system or on the floor. The lowering speed is electro­hydraulically and precisely controlled (in 2 stages) via a button on the tiller
ramp comfort feature
Working in very confined spaces
The EMC is an extremely compact pedestrian stacker. The particularly short chassis length and low weight allow for use in extremely confined spaces, in the lift and on mezzanines. The EMC is also equipped with a crawl speed button. A press of the button is all that’s needed for the EMC to manoeuvre safely, even with the tiller upright.
arm (optional).
• Rapid operation with high lift speed.
• Automatic adjustment of the lift height with intelligent lift positioning (optional).
Work ergonomically
The newly developed tiller head is per­fectly adapted to the ergonomic needs of the operator:
• Colour coding for intuitive operation
Ramp comfort for uneven floors and gradients
Two heavy-duty cylinders increase ground clearance below the critical support arm areas. The slight backward tilt of the truck brings the load into a safe and stable position. This allows the
and buttons with wear-resistant icons.
• Grip angle to suit the hand position of the operator.
• Rocker switch for consistent operation in all tiller positions.
• Horn button positioned in the centre of the tiller for ease of access.
EMC to negotiate thresholds, undulating gradients and uneven floors.
Reduced maintenance costs
Service-friendly components ensure lower maintenance costs in the long-
All travel and lift functions are in the ergonomic multi-functional tiller head
term:
• Maintenance-free 3-phase AC drive motor.
• Rapid access to all components via a one-piece front panel.
Long operating times
The battery, when used together with the energy-saving AC system, gives long operating times:
• Maintenance-free 24 volt /70 Ah block batteries (gel system).
• Integrated 230 volt /10 A charger for easy charging at any 13 Amp plug socket.
• Integrated 110 volt charger (optional).
Optional equipment
• CanCode for PIN activation (instead of key switch) and automatic shut-o function.
• Discharge indicator and CanDis hourmeter counter.
• ISO fork carriage with forged forks
A flexible stacker truck
