Ideal for handling quarter,
half and special pallets.
Width across forks manually
adjustable (140-585 mm)
Particularly quiet operation
Robust and reliable
Fast lift as standard
(up to 120 kg)
AM V05
Hand pallet truck for display and part load pallets (500 kg)
The AM V05 is the ideal solution for
lifting quarter and half pallets. It oers
real advantages wherever display pallets
have to be moved frequently, e.g. on the
shop floor.
Small special pallets can also be transported because the forks can be
manually adjusted in the range from 140
to 585 mm. Whatever you transport with
the AM V05:
The advantages of user-friendliness,
robustness and reliability of Jungheinrich
hand pallet trucks pay dividends. Standard Euro pallets can also be transported.
AM V05
c
h
14
l
2
Q
h
3
m
2
s
h
13
y
l
l
1
60
e
b
=100
10
a/2
Wa
x
=100
b1b
b
5
11
a/2
60
Ast = Wa + l6 – x + a
Technical data in line with VDI 2198
1.1 Manufacturer (short form) Jungheinrich
1.2 Model AM V05
1.3 Drive manual
1.4 Manual, pedestrian, stand-on, seated, order picker operation hand
1.5 Load capacity/rated load Q t 0.5
1.6 Load centre distance c mm 400
Identification
1.8 Load distance x mm 820
1.9 Wheelbase y mm 1120
2.1 Service weight kg 155
2.2 Axle load, w. load, front / rear kg 320 / 325
2.3 Axle load, w.o. load, front / rear kg 101 / 54
Weights
3.1 Tyres N;C
3.2 Tyre size, at front mm Ø 180 x 50
3.3 Tyre size, at rear mm Ø 82 x 40
3.5 Wheels, number front/rear (× = driven wheels) 2/2
3.6 Track width, front b
3.7 Track width, rear b
Wheels / chassis
4.4 Lift h3 mm 390
4.9 Height of tiller in drive position min. / max. h
4.15 Lowered height h
4.19 Overall length l
4.20 Length incl. back of forks l
4.21 Total width b
4.22 Fork dimensions s/e/l mm 50 / 50 / 955
4.25 Width over forks b
4.26 Width between support arms/loading surfaces b4 mm 640
Basic dimensions
4.32 Floor clearance centre wheelbase m
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 1805
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 2005
4.35 Turning radius W
5.3 Lower speed, w. / w.o. load m/s 0.09 / 0.05
mm 122
10
mm 700
11
mm 1210
14
mm 85
13
mm 1405
1
mm 450
2
mm 760
1/b2
mm 140
5
mm 30
2
mm 1425
a
Issue: 08/2006
1)
Perform-
ance data
1)
Manually adjustable 140-585 mm
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Benefit from the advantages
A half pallet is picked up from a
standard Euro pallet
Ergonomic operating handle Handling a Euro-pallet
Designed for many applications
Loading and unloading of small load
carriers on a Euro pallet cannot be
achieved with a standard hand pallet
truck. The AM V05 provides the solution.
Due to individually adjustable forks from
140–585 mm, non-standard load carriers
can also be picked up and transported.
Standard Euro pallets can also be transported.
Easy to handle
The easy-to-use controls are equally
suitable for both left and right-handed
operators. The special lowering valve enables loads to be lowered precisely.
Jungheinrich
Vertrieb Deutschland AG & Co. KG
Am Stadtrand 35
D-22047 Hamburg
Telephone +49 40 6948-0
Telefax +49 40 6948-1777
info@jungheinrich.com
www.jungheinrich.com
The German production
facilities in Norderstedt and
Moosburg are certified.
Jungheinrich fork lift
trucks meet European
safety requirements.
T_AM V05_012014_en_ZKW_000
