Page 1
COMPACT UTILITY TRACTORS
3000
3005 3032E 3038E 3320 3520 3720
SERIES
Page 2
The heart and soul of the
American tractor: John Deere.
There are tractors. And there are the kind John Deere makes—legendary
machines with contemporary designs, well-forged parts, and highly
sophisticated features. Ever since John Deere himself invented the self-
scouring plow in 1837, we have always focused on bringing a better
product to our customers. No piece of equipment quite defi nes John Deere
1918
1837
John Deere invented
the self-scouring plow
2
3
Introduction of
Waterloo Boy
like the tractor. Starting with the introduction of the Waterloo Boy back
in 1918, John Deere set the benchmark for the modern-day tractor for the
remainder of the 20th century. Starting with two-cylinder designs that
would be a trademark of the brand, John Deere continuously improved
and evolved its tractor line. And by the end of the 1960s, John Deere
1960
1944
Tractor with starter
4- & 6- cylinder tractors introduced
Page 3
would secure its place as the largest farm tractor company in the world.
variety of mid- to large-sized jobs. With over 125 available attachments,
We also realized that tractors were more than just for farming. That’s why, in
the early 1990s, we dedicated an entire factory in Augusta, Georgia, for the
sole purpose of producing compact utility tractors. Our fi rst tractors rolled off
the assembly line in 1993, giving folks with multiple acres the ability to do a
eHydro
™
ComfortGard™ Cabs
2001
2001
iMatch™ Quick Hitch
our 3000 Series Tractors can help you get more done than you could ever
imagine. Read on to find the tractor that’s right for you.
AutoConnect™ deck
2005
2007
iMatch™ AutoHitch
™
2008
Page 4
3000 TWENTY SERIES
3320 3520 3720
The performance you
demand, the comfort
you deserve.
It’s a difference you can tell from the moment
you sit down—this is not tractor as usual.
With the John Deere 3000 TWENTY Series,
you can see that the attention to detail is
something special. Start with AutoHST™. This
auto-like transmission option for the 3520
and 3720 makes operating these tractors as
easy as driving to the grocery store. All you
have to do is press a single foot pedal to go
forward and shift to reverse using a hand
lever. And, with the eHydro
performance is never an issue with the
Performance Tracking System. It accurately
monitors the tractor’s functions and systems,
giving you instant feedback for quick diagnosis. Throw in additional features like the
LoadMatch™ electronic power management
system, the Quik-Park™ loaders, and standard
4WD and you have three tractors that are
without peers.
™
transmission,
5
6
4
7
4
5
Page 5
1
l
tintin
tin
tin
g a
g a
nd
s
LoadMatch™ electronic power
management system maximizes
torque and virtually eliminates
the possibility of stalling.*
2
An exclusive digital
Performance Tracking
System instantly tells
you the status of the
vital systems on
your tractor.
3
Digital speedometer
is perfect for precision
tasks like seeding.*
4
Direct-injection diesel
engines are quick starting and
offer deep reserves of torque for pulling heavy loads.
Tilt steering wheel and seat adjust for your comfort.
5
ate
2
1
3
6
Standard loader joystick stays close at hand and clear
of your knee.
7
Standard 4WD digs in when doing loader work or rotary
cutting over challenging ground.
™
Quik-Park
8
minutes—without tools.
*On eHydro and AutoHST models
loaders can be attached and detached in
Transmission
™
AutoHST
• Familiar car-like control layout
• Engine speed controlled with
single pedal
• Automotive Cruise, SpeedMatch™
and MotionMatch™ customize speed
to any application
• Shift lever on the console for
forward, neutral and reverse
• Available on the 3520 and 3720
Standard Features and Options
open station tractors
™
eHydro
Effortless two-pedal automatic
transmission. With easy shifting from
forward to reverse at the touch of a
pedal, it’s ideal for everything from
loading to mowing. Automotive Cruise,
SpeedMatch™ and MotionMatch
customize speed to any application.
Plus, there’s a LoadMatch™ power
management system.
PowrReverser
Convenient dash-mounted lever
makes this manual transmission
easy to shift from forward to reverse
without clutching—a noticeable
benefit when loading.
™
™
Other options
• 3rd SCV
• A-frame front hitch
• Air ride seat
• Automotive-style cruise control
(eHydro and AutoHST)
• Canopy
• Electric diverter/2 add’l rear
hydraulic couplers
• Hydraulic mower lift
• Mid PTO
• Power beyond hydraulics
• Sunshade umbrella
• Top-and-tilt kit
• Vertical exhaust
• AutoConnect
• ComfortGard™ Cab
™
deck
8
Dimensions
HEIGHT: 93.3 in. (2370 mm)
WHEELBASE: 68 in. (1727 mm)
LENGTH: 120.2 in. (3053 mm)
HOOD HEIGHT: 57 in. (1448 mm)
MIN. WIDTH: 40.6 in. (1030 mm)
WIDTH: 68.4 in. (1737 mm)
FOLDED ROPS HEIGHT: 72 in. (1829 mm)
Page 6
3000 TWENTY SERIES CAB
3320 3520 3720
Extraordinary climate control
1
Our unique, roof-mounted system offers an
incredible 15,000 BTUs of cooling and 30,000 BTUs
of heating, (enough for a 600-square-foot room) for
guaranteed comfort whether in boiling summer heat
or the dead of winter.
Superior circulation
2
John Deere climate control reaches every corner of
the cab, thanks to an array of six adjustable vents,
and extensive computer modeling that eliminated
dead spots.
Have nothing to sneeze at
3
Unlike unsealed cabs, the John Deere ComfortGard
Cab keeps not only dust and clippings out—but
also microscopic allergens.
A safe choice for rollover protection
4
Besides undergoing extensive safety testing, the
John Deere ComfortGard Cabs have been certified to Society of Automotive Engineers, Canadian
Standards Association and the Organization for
Economic Co-operation and Development standards
for rollover protection.
1
2
5
4
3
TM
6
Integrated work-, warning- and tail-lights
5
Integrated warning lights and tail lights provide
a sleek modern look while being protected from
trees and branches.
Automotive-style comfort
6
Just like a car, there’s plenty of leg- and elbowroom, and all controls are within easy reach and
most are on the dash or a right-hand panel.
Offset Cab Mounting Technology
7
Unique offset mounting greatly reduces the
vibration and noise levels associated with
box-type structures.
7
Page 7
Room with a view.
It could be a long, hot, dusty day. Or it
could be cold, wet, or freezing. Either
way, you don’t care, since you’re sitting
in the ultimate comfort of a John Deere
TWENTY Series cab. Six adjustable vents
are strategically placed to keep you at
the optimum temperature, winter, spring,
summer, or fall. And this “room” is so
tightly sealed, even most dust particles
or allergens can’t make their way inside.
So come in, shut the door, and get ready
to work in absolute perfect conditions.
True commercial-grade backhoes mount and dismount easily.
Bucket rotation of 180 degrees is perfect for trenching without leaving
behind spillage. Now available on cab and open station models.
Standard cab features
• Air conditioning and heat
• Forward work lights
• Front windshield wiper
• Deluxe cloth seat
• Integrated radio antenna
• Sun visor
• Right-hand control center
• Exclusive raised header bar
• Available R1, R3, R3 fine turf,
Standard Features and Options
R4 tires
Not just a good view, a vista.
With a combination of high seat placement, curved sides and few
obstructions, you have a commanding 360° view to the front, either
side, and to the rear.
Other options
• Deluxe air-ride seat
• Dual external rearview mirrors
• AM/FM radio w/CD
• Cab speaker kit
• Beacon light
• Back up alarm
• Front fender kit
• Rear fender extension kit
• Rear work light kit
Deluxe air-ride seat
provides superior cushioning for a consistently
smooth, comfortable ride over the roughest terrain. Highly recommended for commercial users.
6
7
Page 8
AUTOCONNECT™ DECK
Get it on. And get on with it.
Time. You only have so much of it, especially on the weekend. So when
you want to work with an attachment, you don’t want to spend precious
time wrestling with it. So that’s why we considerably shortened the time
between starting up your tractor and getting work done with the iMatch
AutoHitch™, Quik-Park loaders, and AutoConnect™ decks.
™
In Range A with 4WD engaged,
1
lower the mid-mount hitch
Drive over the deck ramps
2
Listen for two clicks as the deck
3
attaches, and you are done
1
2
3
Page 9
iMATCH™ AUTOHITCH
™
1
iMatch™ AutoHitch
™
Stay in your seat. This exclusive, patentpending coupling system allows you to
effortlessly attach rear-mounted, PTOdriven implements without getting out of
the seat. Use your imagination. Mowing,
rotary cutting, blading and grading, tilling
or aerating—you won’t fi nd a simpler way
to get more done.
2
3
To quickly change implements with the iMatch Quick-
1
Hitch, you simply back in, hydraulically lift the unit and
secure the latches.
Once you’re connected and the unit is in place, there’s
2
an even easier way to automatically hook up PTO-driven
attachments. The iMatch
To hook up the drive shaft to the secure unit, just rotate
the handle, turn and pull AutoHitch
Drive off.
3
™
AutoHitch™ is the answer.
™
lever.
8
9
Page 10
3032E & 3038E
Quality that won’t surprise you — but the price will.
Our new 3E Series Tractors were built with the notion that, if you excel in the areas that matter the most, you’ll
exceed expectations as well. That’s why the new 3032E and 3038E have extremely effi cient diesel engines
that feature impressive torque reserves that allow you to take on punishing loads. You’ll also be surprised to
fi nd a hydrostatic transmission with Twin Touch™ pedals instead of a gear version. Power steering also comes
standard, which makes maneuvering a breeze. Standard differential lock and 4WD give you the traction you
need over rugged terrain. And a fi xed ROPS is certifi ed and easily fi ts under a seven-foot garage door.
4
3
5
10
11
7
6
Page 11
Optional iMatch™ Quick Hitch
1
makes lining up and attaching rear
implements a snap.
Fixed Roll Over Protective Structure –
2
certifi ed to ASAE standards.
Effortless Power Steering even during
2
3
loader operation.
31.4 and 37.1 HP – Yanmar Liquid-
4
Cooled Diesel Engine. Effi cient diesel
engines that offer deep reserves of
torque for handling tough loads.
305 Loader with ultimate lift capacity
5
(1,168 lb.)
Standard differential lock and 4WD
6
add traction going over challenging
ground.
Hydrostatic transmission with
7
Twin Touch
cruise control.
™
pedals w/optional
3038E
3032E
1
Dimensions
HEIGHT: 83.3 in. (2115 mm)
MIN. WIDTH: 23.9 in. (608 mm)
WIDTH: 56.5 in. (1434 mm)
WHEELBASE: 60 in. (1525 mm)
LENGTH: 111 in. (2820 mm)
HOOD HEIGHT: 51.8 in. (1315 mm)
Page 12
3005
We’re pushing
the limits of what a
standard tractor can do.
Take your notion of what a standard tractor
is supposed to be and replace it with what
it could be—the John Deere 3005. This
no-nonsense workhorse exceeds expectations at every turn, with a price that demands a double-take. A cast-iron transmission supplies the strength and durability
you need when using a loader or backhoe
attachment. Effortless power steering and
standard 4WD make for tight turns. And
logic and ergonomics go hand-in-hand with
the at-your-fi ngertips controls. No longer
does owning a standard tractor mean
having to settle for less. Not with the 3005.
3
4
5
6
12
13
Page 13
Optional iMatch™ Quick Hitch
1
makes lining up and attaching rear
implements a snap.
Fixed Roll Over Protective Structure –
2
certifi ed to ASAE standards.
Attachments
2
Effortless Power Steering even during
3
loader operation.
27.5 HP – Yanmar Liquid-Cooled Diesel
4
Engine. Effi cient diesel engines that offer
deep reserves of torque for handling
tough loads.
Quik-Park
5
be attached and detached in less than
three minutes with no tools.
Standard differential lock and 4WD
6
(optional 2WD) add traction going over
challenging ground.
™
300 Series Loader can
1
BACKHOES
BOX BLADES
BROADCAST SPREADERS
CORE AERATOR
DISK HARROW
FLAIL MOWERS
FRONT BLADES
GROOMING MOWERS
GROOMING MOWERS, REAR DISCHARGE
iMATCH AUTO HITCH
LANDSCAPE RAKES
LOADERS
MANURE SPREADERS
MATERIAL COLLECTION SYSTEMS
MID-MOUNT MOWERS
AUTO CONNECT DECK
OVERSEEDERS
PENDULAR SPREADERS
POSTHOLE DIGGERS BY ROTOMEC
PULVERIZERS
REAR BLADES
ROTARY BROOMS •
ROTARY CUTTERS
ROTARY TILLERS
SICKLEBAR MOWERS •
SNOW BLOWERS
WHEEL RAKES
WOOD CHIPPER
PLOW
3005
3032E
•
•
• • •
•
•
3038E
•
•
•
•
•
•
•
• • •
•
•
• •
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
• • •
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
3320
3520
•
•
• • •
•
•
• • •
• • •
•
• • •
•
• •
•
•
• • •
• • •
• • •
• •
• •
• •
• • •
•
•
• • •
• • •
• • •
•
• • •
• • •
•
•
• •
• •
• •
•
•
•
•
3720
•
•
•
•
•
•
•
•
Page 14
SPECS
SPECS
ENGINE
Type Yanmar 3TNV82A Yanmar 3TNV88 Yanmar 3TNV84T
HP* 27.5 (20.2 kW) 31.4 (23.1 kW) 37.1 (27.3 kW)
PTO HP 23.5 (17.5 kW) 25 (18.6 kW) 30 (22.4 kW)
Rated speed, RPM 2,700 2,500 2,500
Engine displacement 81.2 cu. in. (1.3 L) 100 cu. in. (1.64 L) 91.5 cu. in. (1.496 L)
Battery power 500 Cold Cranking Amps 500 Cold Cranking Amps 500 Cold Cranking Amps
Alternator 20 Amps 40 Amps 40 Amps
HYDRAULICS
Steering 4.2 gpm (15.9 L/min) 4.0 gpm (15.1 L/min) 4.0 gpm (15.1 L/min)
Implement 5.4 gpm (20.5 L/min) 5.3 gpm (20 L/min) 5.3 gpm (20 L/min)
Total capacity 9.6 gpm (36.4 L/min) 9.3 gpm (35.5 L/min) 9.3 gpm (35.5 L/min)
Lift capacity (24 in. behind center link) 815 lb. (370 kg) 1,356 lb. (615 kg) 1,356 lb. (615 kg)
TRANSMISSION
Standard Collar Shift 8F/2R Hydrostatic - 2 Range Hydrostatic - 2 Range
Final drive Spur gear Spur gear Spur gear
Brakes Dry Wet disk Wet disk
Steering Power Power Power
4WD Optional Standard Standard
PTO
Continuous live Independent Independent
PTO type
PTO options Mid & Rear N/A N/A
3005 3032E
3038E
REAR HITCH
Category 1 Category 1 Category 1
Type
Control type Position Position Position
WEIGHT
With all fluids 2WD 1,930 lb. (875 kg)
4WD 2,105 lb. (955 kg) 2,175 lb. (987 kg) 2,175 lb. (987 kg)
LOADER
Max Height Lift Capacity at Pivot 740 lb. (kg) 1,168 lb. (531 kg) 1,168 lb. (531 kg)
14
15
*Manufacturer’s estimate of power (ISO) per 97/68/EC.
No one builds or backs tractors better
than John Deere.
It’s the fi ne print, but a big story:
Every John Deere Compact Tractor comes
with a 3-year/2000-hour limited warranty.
See your dealer for details.
Page 15
SPECS
SPECS
ENGINE
Type Yanmar 3TNV88 Yanmar 3TNV84T Yanmar 3TNV84HT
HP* 32.8 (24.1 kW) 37.1 (27.3 kW) 43.2 (31.8 kW)
PTO HP - Gear Transmission 25.5 (19.0 kW) 30.5 (22.7 kW) N/A
PTO HP - Hydrostatic Transmission 25 (18.6 kW) 30.0 (22.4 kW) 35 (26.1 kW)
Rated Speed, RPM 2,600 2,600 2,600
Engine displacement 100.0 cu. in. (1.64 L) 91.5 cu. in. (1.5 L) 91.5 cu. in. (1.5 L)
Battery power 500 Cold Cranking Amps 500 Cold Cranking Amps 500 Cold Cranking Amps
Alternator 40 Amps 40 Amps 40 Amps
HYDRAULICS
Steering 5.3 gpm (20.0 L/min) 5.3 gpm (20.0 L/min) 5.3 gpm (20.0 L/min)
Implement 8.6 gpm (32.5 L/min) 8.6 gpm (32.5 L/min) 8.6 gpm (32.5 L/min)
Total capacity 13.9 gpm (52.5 L/min) 13.9 gpm (52.5 L/min) 13.9 gpm (52.5 L/min)
Lift capacity (24 in. behind center link) 2,200 lb. (999 kg) 2,200 lb. (999 kg) 2,200 lb. (999 kg)
TRANSMISSION
Standard PowrReverser™; 12F/12R PowrReverser™; 12F/12R N/A
Optional eHydro™ - 3 Range eHydro™ - 3 Range eHydro™ - 3 Range
Final drive Spur gear Spur gear Spur gear
Brakes Wet disk Wet disk Wet disk
Steering Power Power Power
4WD Standard Standard Standard
PTO
PTO type Independent Independent Independent
PTO options Rear standard, mid optional Rear standard, mid optional Rear standard, mid optional
35203320
3720
REAR HITCH
Type Category 1 Category 1 Category 1
Control type Position Position Position
WEIGHT
With all fluids 2,900 lb. (1316 kg) 2,900 lb. (1316 kg) 2,900 lb. (1316 kg)
LOADER (W/300CX)
Max Height Lift Capacity at Pivot 1,598 lb. (725 kg) 1,598 lb. (725 kg) 1,598 lb. (725 kg)
ROPS Folding Folding Folding
COMFORTGARD™ CAB Optional Optional Optional
CRUISE CONTROL Standard Standard Standard
LOADMATCH™ Standard Standard Standard
AUTO CRUISE / MOTION MATCH Optional Optional Optional
AIR RIDE SEAT Optional Optional Optional
**eHydro transmission.
Page 16
Total support is standard equipment.
No one can duplicate the support and knowledge of your local
John Deere dealer. From the moment you enter a John Deere
dealership, you can be sure you’re getting the very best in
customer assistance. Plus, John Deere dealers are in touch with
your local community and understand what it takes to maintain
your land. Factory-trained service and parts professionals keep
your equipment working as hard as you do. Whether in the
John Deere dealership or in the field, you can get your
equipment serviced and move on to the next task.
includes two at home annual maintenance services with genuine
John Deere parts. And an additional year of extended service
protection, the same type of coverage as your original warranty.
Exceptional Parts Support
Behind every John Deere is a parts support network to get you
the high-quality part you need fast. If your dealer does not have
a part in stock, in most cases you can order it by 5 p.m., and
have it the next day. Or, order parts online at www.JDParts.
JohnDeere.com.
Optional John Deere Maintenance Plan Plus
Peace of mind can be financed for just a few dollars a month with
the purchase of your tractor. The John Deere Maintenance Plan Plus
This literature has been compiled for worldwide circulation. While general information, pictures and descriptions are provided, some illustrations
and text may include fi nance, credit, insurance, product options and accessories NOT AVAILABLE in all regions. PLEASE CONTACT YOUR LOCAL
DEALER FOR DETAILS. John Deere reserves the right to change specifi cation, design and price of the products described in this literature without
notice. John Deere’s green and yellow color scheme, the leaping deer symbol, and JOHN DEERE are trademarks of Deere & Company.
DKA3290 (08-10) Litho in USA. Ref #: 08-3290
Flexible Available Financing
John Deere Credit has convenient and flexible financing options
designed for you. See your dealer for details.
Loading...
