JMS3
INTRODUCTION
Thank you for choosing a Jensen product. We hope you will find the instructions in this owner’s manual clear and easy to follow. If you take a few minutes to look through it, you’ll learn how to use all the features of your new Jensen receiver for maximum enjoyment.
Features
Waterproof iPx6
UV and Corrosion Resistant
Dimmable Backlit LCD Control
AM/FM Tuner (US/ EURO)
24 Programmable Presets (12 AM, 12 FM)
Weather Band Tuner
Electronic Bass, Treble, Balance and Fader Controls
USB MP3/WMA Player
Rear Auxiliary Audio Input (RCA)
Rear Auxiliary Audio Output (RCA)
4-Channel Amplified Audio Output
Bluetooth (Supports A2DP and AVRCP)
Box Content
JMS3 Radio
Radio Mounting Bracket
Screw Posts (x2)
Locking Hex Nuts (x2)
Washers (x2)
Compliance with FCC Rules
Compliance with FCC Rules (U.S.A. Only)
This device complies with Part 15 of the FCC rules. Operation is subjected to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against Harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful Interference to radio communications.
FCC WARNING
Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Proper connections must be used for connection to a host computer and/or peripherals in order to meet FCC emission limits.
1
JMS3
Safety Information
When Boating
Keep the volume level low enough to be aware of your surroundings.
Protect from Water
Do not submerge the product in water, as this can cause electric shorts, fire or other damage.
Protect from the Elements
Use the included cover to protect the wired commander from sunlight, dust, and water while not in use.
Protect from High Temperatures
Do not mount radio within close proximity of engine compartment.
Use the Proper Power Supply
This product is designed to operate with a 12 volt DC negative ground battery system.
CAUTION:
DO NOT OPEN COVERS AND DO NOT REPAIR BY YOURSELF. PLEASE REFER SERVICING TO A QUALIFIED TECHNICIAN.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND INTERFERENCE, USE ONLY THE RECOMMENDED ACCESSORIES.
2
JMS3
INSTALLATION
Mounting the Radio
1.Choose a mounting location on the dash board or instrument panel that will allow room behind to run radio cables to the power source. Consider how you will use the AUX IN, LINE OUT and USB connectors and route the appropriate extension cables to an accessible area.
2.Cut a hole in the dash board using the template provided in the back of this manual. At least 3 ¾” depth is needed to mount the radio.
IMPORTANT! Do not mount this unit where it can be submerged in water.
3.Slide the included spring washers (B) over the screw posts (A) and attach the screw posts to the back of the radio.
4.Place the radio in front of the dashboard opening so the wiring can be brought through the opening.
5.After completing the wiring connections, turn the radio on to confirm operation (vessel accessory switch must be on). If the radio does not operate, recheck all wiring until the problem is corrected. Once proper operation is achieved, turn the accessory switch off and proceed with final mounting of the radio. Refer to the “Wiring Diagram” on page 4.
NOTE: Before final installation, test the wiring connections to make sure the unit is connected properly and the system works.
6.Insert the radio into the mounting hole.
7.Place the “U” bracket (C) over the screw posts and secure the radio to the dash using the included hex nuts (D). If necessary, cut the score marks (E) on either side of the mounting bracket to custom fit the bracket length for your application. See Figure A.
Figure A - Installation
Auxiliary Input
Connect a portable audio device to the Audio Input (AUX IN RIGHT/LEFT) on the back of the unit using RCA cables.
Line Output
The Line Out connectors (LINE OUT RIGHT/LEFT) on the back of the unit output a line-level analog signal. Use this output to connect to an external amplifier.
3
