MODEL JCR-255
AM/FM DUAL ALARM AUTO TIME SET CLOCK RADIO
INSTRUCTION MANUAL
Please read and follow this instruction manual carefully
before using the unit and retain it for future reference
DEAR JENSEN ® CUSTOMER
Selecting fine audio equipment such as the unit you've just purchased is
only the start of your musical enjoyment. Now it's time to consider how you
can maximize the fun and excitement your equipment offers. This
manufacturer and the Electronic Industries Association's Consumer
Electronics Group want you to get the most out of your equipment by playing
it at a safe level. One that lets the sound come through loud and clear
without annoying blaring or distortion and, most importantly, without affecting
your sensitive hearing.
Sound can be deceiving. Over time your hearing "comfort level" adapts to
higher volumes of sound. So what sounds "normal" can actually be loud
and harmful to your hearing. Guard against this by setting your equipment
at a safe level BEFORE your hearing adapts.
To establish a safe level:
clearly,and without distortion.
Once you have established a comfortable sound level:
Taking a minute to do this now will help to prevent hearing damage or loss
in the future. After all, we want you listening for a lifetime.
We Want You Listening For a Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and
enjoyment. Since hearing damage from loud noise is often undetectable
until it is too late, this manufacturer and the Electronic Industries Association's
Consumer Electronics Group recommend you avoid prolonged exposure
to excessive noise.
Customer's Record:
The serial number of this product is found on its bottom cover. You should
note the serial number of this unit in the space provided as a permanent
record of your purchase to aid in identification in the event of theft of loss.
Start your volume control at a low setting.
Slowly increase the sound until you can hear it comfortably and
Set the dial and leave it there.
Model Number: JCR-255 Serial Number:
1
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH
AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE
BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
1. Read these instructions
2. Keep these instructions
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Ventilation – Slots and openings in the cabinet are provided for ventilation
and to ensure reliable operation of the product and to protect it from
overheating, and these openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, so
far, rug, or other similar surface. This product should not be placed in a
built-in installation such as a bookcase or rack unless proper ventilation
is provided or the manufacturer’s instructions have been adhered to.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Grounding or Polarization – This product may be equipped with a polarized
alternating-current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the outlet,
try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments / accessories specified by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long
periods of time.
2
13. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
14. This appliance shall not be exposed to dripping or splashing water and
that no object filled with liquids such as vases shall be placed on the
apparatus.
15. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
16. The MAINS plug or an appliance coupler is used as the disconnect
device, the disconnect device shall remain readily operable.
17. Battery pack or battery installed shall not be exposed to excessive heat
such as sunshine, fire or the like.
18. Caution marking and nameplate are located on bottom of product.
Remark: this is CLASS II apparatus with double insulation, and no
protective earth provided.
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
SLOT. FULLY INSERT.
3
IMPORTANT NOTES
Avoid installing the unit in locations described below:
such as electric heaters.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Radio Receiver, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which
- Consult the dealer or an experienced radio technician for help.
Caution
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
Places exposed to direct sunlight or close to heat radiating appliances
Dusty places.
Places subject to constant vibration.
Humid or moist places.
COMPLIANCE WITH FCC REGULATIONS
the receiver is connected.
4
POWER SOURCE
This unit is designed to operate on 120V/60Hz AC house current. Operating
this unit from any other power source may cause damage to the unit, and
such damage is not covered by your warranty.
The radio is also pre-loaded with 2 x “AA” batteries for the battery back-up
and for the Auto Time Set clock system.
BATTERY BACK – UP SYSTEM
The Battery Back-up System ensures the clock and alarm settings will be
retained during a power interruption or power outage (in order to preserve
the battery life the Display will not light). All clock settings will be kept in
memory, however, the clock time may require adjustment for exact accuracy
once the power returns. If the batteries are not installed, the Display will
blink”12:00” when the power is restored. This will indicate that you have to
reset the time and alarm settings.
BATTERY INSTALLATION
1. Open the battery compartment door on the bottom of the cabinet.
2. Insert 2 “AA” size batteries into the battery compartment according
to the polarity diagram engraved inside the compartment.
3. Replace the battery compartment Door.
IMPORTANT: Be sure that the batteries are installed correctly. Wrong
4. Alkaline-type batteries are recommended. For optimum performance,
these batteries should be replaced after every year or when batteries
become exhausted.
5. Old or leaking battery can cause damage to the unit and will void the
warranty.
6. Use only the size and type of batteries specified.
7. Do not mix old and new batteries.
8. Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-
cadmium) batteries.
9. Do not try to recharge batteries not intended to be recharged; they can
overheat, rupture and leak. (Follow battery manufacturer’s directions).
10. Do not dispose of batteries in fire, batteries may leak or explode.
POWER FAILURE INDICATOR
If there are no batteries installed in the unit or if the batteries installed are
weak or dead, the time and alarm settings will be lost if the AC power is
interrupted. When the AC power is restored the display will blink”12:00”. This
indicates that the time displayed is incorrect and needs to be reset.
IMPORTANT:
After you reset the time, be sure to reset your alarm settings as well.
polarity may damage the unit.
5
1 7 8
13965342
14 1110
15
1. POWER ON/OFF BUTTON
2. VOLUME CONTROL
3. CLOCK SETTING UP BUTTON
4. CLOCK SETTING DOWN BUTTON
5. ALARM1 BUTTON
6. ALARM2 BUTTON
7. SNOOZE BUTTON
8. (AM/FM)BAND / CLOCK SET BUTTON
12
9. TUNNING CONTROL
10. TIME ZONE SELECTOR
11. DAYLIGHT SAVING TIME SWITCH
12. DIMMER CONTROL
13. AUX IN JACK
14. AUX/RADIO SELECTOR
15. BATTERY COMPARMENT
6
1 3 4
2
1. ALARM 1 INDICATOR
2. ALARM 2 INDICATOR
3. MULTI FUNCTION DISPLAY
5
6
4. AM CLOCK INDICATOR
5. PM CLOCK INDICATIOR
6. SPEAKER
7
AUTO TIME SET
This unit features an Automatic Time Set system powered by 2 X “AA”
batteries (3V DC) (Included), so you do not need to set the clock time
when first plugged in. After the unit is plugged in, the LED display will
show the current time automatically after you set the time zone and
daylight saving time for desired area.
SETTING THE TIME ZONE
Change to your time zone area by sliding the TIME ZONE switch on
the back of the unit to the appropriate time zone you live in. The default
time zone is set to Eastern Standard Time (EST). Please refer to the
time zone map below when setting the switch position on the back.
1. Eastern Standard Time (EST)
2. Central Standard Time (CST)
3. Mountain Standard Time (MST)
4. Pacific Standard Time (PST)
PST MST CST EST
DAYLIGHT SAVING TIME
Slide the DST (Daylight Saving Time) switch on back of the unit to turn
Daylight saving time on/off. The clock comes with DST in the ON position
as the default. This setting is correct unless you live in Arizona or parts of
Indiana where DST is not observed.
IMPOTANT: Do not change this setting unless you live in an area which
does not observe the Daylight Saving time change.
NOTE: The batteries will become weak after time, so replace the
batteries as needed. To avoid re-program the time and alarm settings,
we recommend leaving the unit plugged in when changing the batteries.
8
SETTING THE CLOCK
In case the back-up batteries are accidentally removed. You will need
to set the clock manually.
If the LED display is blinking
1. In standby mode, press the UP button to increase or press the
DOWN button to decrease the minutes setting.
2. Press and hold the UP / DOWN button to fast forward/backward
the clock setting.
3. Press the BAND/SET button or waiting 5 seconds to confirm the
setting.
If the LED display is steady
1. In standby mode, press and hold BAND/SET button for 3 seconds,
AM or PM indicator flashes on LED display,
2. Press the UP button to increase or press the DOWN button to
decrease the minutes setting.
3. Press and hold the UP / DOWN button to fast forward/backward
the clock setting.
4. Press the BAND/SET button again to confirm.
NOTE
There are AM and PM indicators located in the left-hand corner of the clock
display. Be sure to observe the correct AM / PM indicator when setting the
alarm to make sure the wake time is set correctly for AM or PM.
1. Switch AUX IN / RADIO selector to select radio mode.
2. Press the ON/OFF button once to turn on the unit, display shows
FM or AM frequency for 5 seconds.
3. Press the BAND/SET button once to select AM / FM band.
4. Rotary the TUNING control knob to select your desired radio
broadcasting station. Display will return to show current time after
tuning control idle for 5 seconds.
5. Adjust VOLUME control to your desired listening level.
9
6. When you have finished listening, press the ON/OFF button once
to turn off the unit.
TIPS FOR BEST RADIO RECEPTION
AM - The AM antenna is built inside the radio. If AM reception is weak,
change the position of the unit until the internal antenna picks up the
strongest signal.
FM - If FM reception is weak, fully extend the wire antenna and vary the
position and location of the antenna until you find the strongest signal.
ALARM OPERATION
SETTING THE WAKE UP TIME
This unit has Dual Alarm function. Each ALARM can be set to wake
to RADIO or ALARM. To set alarm time:
1. Press and hold ALARM1 or ALARM2 button for 3 seconds to enter
the ALARM setting mode, LED shows the default alarm time 12:00
AM and the ALARM1 or ALARM2 indicator flashing on the display.
2. Press UP / DOWN button to adjust minutes of you desired ALARM
time. Press and hold the button for fast forward / backward setting
the alarm time.
3. Press ALARM1 or ALARM2 button again to confirm the ALARM
time setting.
4. Press ALARM1 or ALARM2 repeatedly to select wake to ALARM
(bUZ) , RADIO (rAd) or turn off the alarm.
CHECKING THE WAKE UP TIMES
Whenever you want to check the wake up time, simply press and hold the
ALARM 1 or ALARM 2 button for 3 seconds. The display will change from
current time to wake up time. Release the ALARM button, it will return to
current time after 5 seconds.
WAKE TO RADIO
1. To select wake to radio mode, press the ALARM button you want to set
repeatedly until display shows “rAd”.
2. Release ALARM button and waiting about 5 seconds to confirm.
NOTE: 1. Ensuring a desired radio station is tuned and proper volume
is set.
3. The radio will automatically turn on and ALARM indicator flashing when
alarm time is reached.
4. The radio alarm will keep sounding for 60 minutes and then automatically
shut off until same time on the following day.
2. If you set the AUX IN / RADIO switch to AUX IN position,
buzzer alarm will sound instead of radio.
10
5. To stop the alarm immediately, press the ON/OFF button once. The
radio will stop but the alarm remains set and will turn the unit on again
at the same time on the following day.
6. To turn off the alarm completely, press the ALARM button repeatedly
until ALARM indicator turns off.
WAKE TO BUZZER
1. To select wake to buzzer mode, press the ALARM button repeatedly
until the display shows “bUZ”.
2. Release ALARM button and wait about 5 seconds to confirm the setting.
3. The buzzer alarm will automatically turn on and the ALARM indicator
will flash when alarm time is reached. It starts softly and becomes
gradually louder.
4. The buzzer alarm will keep sounding for 60 minutes and then automatically
shut off until same time on the following day.
5. To stop the alarm immediately, press the ON/OFF button once. The
buzzer alarm will stop but the alarm remains set and will turn the unit
on again at the same time on the following day.
6. To turn off the buzzer alarm completely, press the ALARM button
repeatedly until ALARM indicator turns off.
NOTE: If you set the second alarm and it is reached while the first alarm is
sounding, the second alarm will sound and cancel the previous
alarm.
SNOOZE OPERATION
You may active the SNOOZE function manually after the alarm sounds by
pressing the SNOOZE button. The snooze time can be adjusted from 1 ~
30 minutes, the default snooze time setting is 9 minutes.
SNOOZE TIME SETTING:
1. In standby mode, press and hold SNOOZE for 3 seconds, the display
shows current snooze time and flashes.
2. Press the UP / DOWN button to increase / decrease the snooze time.
3. Press the SNOOZE button again to confirm.
SNOOZE FUNCTION
1. When the ALARM sounds, press the SNOOZE button to pause the
ALARM. The ALARM will come again after your pre-set SNOOZE time
is reached.
2. When the Snooze time starts, press the SNOOZE button again to check
remaining time left.
3. This manual snooze operation can be repeated again and again.
11
BACKLIGHT BRIGHTNESS OPERATION
You can change the LED brightness by switching the HI / LO dimmer
switch located on the side of the cabinet.
AUXILIARY INPUT
This unit features an AUX line-in jack for connecting your iPod, MP3
player or other digital music players.
1. Connect the headphone jack of your external device to the AUX
IN jack located on the back of the unit (cable not included).
2. Turn on the unit and set the FUNCTION Selector to the “AUX IN”
position.
3. Start playing your iPod, MP3 player or other external audio device.
4. Slowly adjust both volume controls on the unit and the external
device.
5. Turn off your iPod, MP3 player etc. when finish listening.
6. Turn the unit off and unplug the AUX Line-in jack.
CARE AND MAINTENANCE
1. If the cabinet becomes dusty, wipe the exterior with a soft dust cloth
only. Never use dusting sprays or polishes on the cabinet.
2. If the cabinet becomes dirty or smudged with fingerprints it may be
wiped with a soft cloth that has been slightly dampened with a mild soap
and water solution.
3. Always disconnect the power cord from the AC outlet before cleaning.
Never allow any liquid to get inside the cabinet.
NOTE
1. If there are no batteries in the battery back-up compartment, the Auto
Set Time and Alarm settings will be lost when the AC power cord is
disconnected for cleaning. You will need to reset th e clock and
alarm time(s) after reconnecting the AC power cord. Follow the
“SETTING THE CLOCK” section above if needed.
2. lf “AtS” is shown on the display during normal operation, please press
the power ON/OFF button once to return to normal operation.
12
SPECIFICATIONS
Power Requirement: AC 120V~60HZ 6W
Battery Backup For Clock: 2 X”AA” (UM-3)
Frequency Range: AM 530-1710kHz, FM 88-108MHz
SERVICE
Please refer to the instructions on the enclosed warranty card for returning
your unit for service. When returning the unit, please remove the battery to
prevent damage to the unit in transit and/or from possible battery leakage.
We are not responsible for battery returned with the product or for the cost
of replacement.
Distributed by:
Spectra Merchandising International, Inc.
Chicago Industry Tech Park
4230 North Normandy Avenue
Chicago, IL 60634, U.S.A.
Please have model number ready, for Customer Service, call 1-800-777-5331
Printed in China
13
Loading...
