JCV1640BT
AM/FM/RBDS/WB/USB/AUX-IN/BT/iPod Ready/SiriusXM Ready Heavy Duty Radio
Installation and Operation Manual
iPhone, iPod, iPod Classic, iPod Nano, iPod Shuffle, and iPod Touch are trademarks of Apple Inc., registered in the U.S. and other countries.
JCV1640BT
CONTENTS |
|
Introduction............................................................................................................................... |
1 |
Safety Information .................................................................................................................... |
2 |
Installation ................................................................................................................................ |
3 |
Wiring ....................................................................................................................................... |
4 |
Basic Operation ........................................................................................................................ |
5 |
Tuner Operation........................................................................................................................ |
8 |
USB Operation ....................................................................................................................... |
10 |
Satellite Radio Operation ......................................................................................................... |
11 |
iPod Operation........................................................................................................................ |
15 |
Bluetooth Operation................................................................................................................ |
16 |
Care and Maintenance ........................................................................................................... |
18 |
Troubleshooting ...................................................................................................................... |
18 |
Specifications ......................................................................................................................... |
19 |
ii
JCV1640BT
INTRODUCTION
System Features
Features of Jensen JCV1640BT mobile audio system include:
Full Dot Matrix LCD
AM/FM US/EURO Tuner with 30 Presets (12AM, 18FM)
RBDS (Radio Broadcast Data Service) with PTY Search
Sirius XM Radio Ready
USB Playback of MP3 and WMA files
iPod Ready (USB Interface)
Weatherband Tuner with SAME Technology
Mute
Bluetooth (Supports A2DP, AVRCP and HFP)
Pre-set Equalizer – 5 settings (User, Flat, Pop, Classical, Rock)
Electronic Bass, Treble, Balance and Fader Controls
Output Power 45W x 4
Clock 12/24 Hour Selectable
Public Announcement (PA) Feature with Optional Microphone (sold separately)
IR Wireless Remote Control Ready (sold separately)
3 Wire Power with Non-Volatile Memory and Clock/Time support
Auxiliary Audio Input (Front 3.5mm Stereo Jack)
Content List
Jensen Heavy Duty Radio
Hardware Kit
Installation Manual
Quick Reference Guide
HARDWARE KIT CONTENTS
FLANGE NUTS |
MOUNTING STRAP |
|
MOUNTING BUSHING
DIN SLEEVE REMOVAL TOOL
MOUNTING SCREW
1
JCV1640BT
SAFETY INFORMATION
When Driving
Keep the volume level low enough to be aware of the road and traffic conditions.
When Washing Your Vehicle
Do not expose the product to water of excessive moisture. Moisture can cause electrical shorts, fire or other damage.
When Parked
Parking in direct sunlight can produce very high temperatures inside your vehicle. Give the interior a chance to cool down before starting playback.
Use the Proper Power Supply
This product is designed to operate with a 12 volt DC negative ground battery system.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND ANNOYING INTERFERENCE, USE ONLY THE RECOMMENDED ACCESSORIES.
2
|
|
|
|
JCV1640BT |
|
|
|
|
|
INSTALLATION |
4. |
Place the radio in front of the dashboard opening so the wiring can be brought through the |
||
|
|
|
||
|
|
|
|
mounting sleeve. |
This unit is designed for installation in vehicle cabs with an existing 1-DIN radio opening. In |
5. |
Follow the wiring diagram carefully and make certain all connections are secure and |
||
many cases, a special installation kit will be required to mount the radio to the dashboard. See |
|
insulated with crimp connectors or electrical tape to ensure proper operation. |
||
the dealer where the radio was purchased for kit availability. Always check the kit application |
6. |
After completing the |
||
before purchasing to make sure the kit works with your vehicle. |
|
wiring connections, turn |
||
Before you Begin |
|
the unit on to confirm |
||
|
operation (vehicle |
|||
|
|
|
|
|
1. |
Disconnect Battery |
|
accessory switch must be |
|
|
Before you begin, always disconnect the battery negative terminal. |
|
on). If the unit does not |
|
2. |
Remove Transport Screws |
|
operate, recheck all |
|
Important Notes |
|
wiring until the problem is |
||
|
corrected. Once proper |
|||
|
|
|
|
|
|
Before final installation, test the wiring connections to make sure the unit is connected |
|
operation is achieved, |
|
|
properly and the system works. |
|
turn the accessory switch |
|
|
Use only the parts included with the unit to ensure proper installation. The use of |
|
off and proceed with final |
|
|
unauthorized parts can cause malfunctions. |
|
mounting of the chassis. |
|
|
Consult with your nearest dealer if installation requires the drilling of holes or other |
7. |
Carefully slide the radio |
|
|
modifications to your vehicle. |
|
into the mounting sleeve |
|
|
Install the unit where it does not interfere with driving and cannot injure passengers during |
|
making sure it is |
|
|
a sudden or emergency stop. |
|
right-side-up until it is fully seated and the spring clips lock it into place. |
|
|
If the installation angle exceeds 30° from horizontal, the unit might not give optimum |
8. |
Attach one end of the perforated support strap (supplied) to the screw stud on the rear of |
|
|
performance. |
|
the chassis using the hex nut provided. Fasten the other end of the dashboard either |
|
|
Avoid installing the unit where it will be subjected to high temperatures from direct sunlight, |
|
above or below the radio using the screw and plain washer provided. Bend the strap, as |
|
|
hot air, or from a heater, or subject to excessive dust, dirt or vibration. |
|
necessary, to position it. Some vehicle installations provide cavity for rear support. In |
|
DIN Front Mount |
|
these applications, place the rubber bushing over the screw stud and insert. |
||
|
CAUTION: The perforated rear support strap or rear rubber mounting bushing must |
|||
|
|
|
|
|
1. |
Slide the mounting sleeve off of the |
|
be used in the installation of the radio. Installation without either may result in |
|
|
chassis if it has not already been |
|
damage to the radio or the mounting surface and void the manufacturer’s warranty. |
|
|
removed. If it is locked into position, |
9. |
Test radio operation by referring to the operating instructions for the unit. |
|
|
use the removal keys (supplied) to |
Removing the Unit |
||
|
disengage it. The removal keys are |
|||
|
|
|
||
|
depicted in “Removing the Unit” on |
To remove the radio after installation, |
||
|
page 3. |
remove the plastic end caps, insert the |
||
2. |
Check the dashboard opening size by |
removal keys straight back until they |
||
|
sliding the mounting sleeve into it. If |
click, and then pull the radio out. If |
||
|
the opening is not large enough, |
removal keys are inserted at an angle, |
||
|
carefully cut or files as necessary until |
they will not lock properly to release |
||
|
the sleeve easily slides into the |
the unit. |
||
|
opening. Do not force the sleeve into the opening or cause it to bend or bow. Check that |
Reconnect Battery |
||
|
there will be sufficient space behind the dashboard for the radio chassis. |
|||
|
|
|
||
3. |
Locate the series of bend tabs along the top, bottom and sides of the mounting sleeve. |
When wiring is complete, reconnect |
||
|
With the sleeve fully inserted into the dashboard opening, bend as many of the tabs |
the battery negative terminal. |
||
|
outward as necessary to firmly secure the sleeve to the dashboard. |
|
|
3
JCV1640BT
WIRING
DETAIL A
SHOWN FROM PIN VIEW
PIN NO. |
DESCRIPTION |
A1 |
RIGHT REAR SPEAKER (+) |
A2 |
RIGHT FRONT SPEAKER (+) |
A3 |
LEFT FRONT SPEAKER (+) |
A4 |
LEFT REAR SPEAKER (+) |
|
|
A5 |
LEFT REAR SPEAKER ( ) |
A6 |
LEFT FRONT SPEAKER ( ) |
A7 |
RIGHT FRONT SPEAKER ( ) |
|
|
A8 |
RIGHT REAR SPEAKER ( ) |
B1 |
NO CONNECTION |
B2 |
NO CONNECTION |
B3 |
NO CONNECTION |
B4 |
+12V BATT UNSWITCHED |
B5 |
GROUND |
B6 |
NO CONNECTION |
B7 |
+12V ACC SWITCHED |
B8 |
NO CONNECTION |
PA |
WARNING!
Do not connect the +12VDC ACC switched wire to the battery. This wire MUST be connected to the Accessory/Ignition wire or a +12 volts switched power source.
4
JCV1640BT
BASIC OPERATION |
Mute |
Power On/Off/Radio
Press the rotary encoder POWER button (1) to turn the unit on or press and hold to turn off. The unit will resume at the last mode selected (Tuner, Auxiliary, etc.).
Volume Control
To increase the volume, turn the rotary encoder (1) to the right. To decrease the volume, turn the rotary encoder to the left. While adjusting the volume, the LCD displays a bar graph and numerical representation of the level.
The maximum volume setting is 40.
Press the MUTE button (22) to mute the audio output. Press MUTE again to restore the audio output to the previous level.
Mode
Press the MODE button (4) to select a different mode of operation, as indicated on the display panel. Available modes include the following: Tuner (AM/FM) > SXM (SiriusXM) > iPod/USB > Auxiliary > BT Audio. Tuner is the default source when a prior source is no longer available.
NOTE: iPod, USB or SiriusXM (SXM) mode will be skipped if the device is not installed.
NOTE: SiriusXM (SXM) mode will be skipped when the Region menu option is set to
“EURO”.
Reset
The reset button should be activated for the following reasons:
Initial installation of the unit when all wiring is completed
Function buttons do not operate
Error symbol on the display
Use a ball point pen or thin metal object to press the RESET button (21). This may be necessary should the unit display an error code.
Audio Menu
Press the POWER/AUDIO button (1) to access the audio menu. You can navigate through the audio menu items by pressing the POWER/AUDIO button repeatedly. Once the desired menu item appears on the display, adjust that option by turning the rotary encoder (1) within 5 seconds. The unit will automatically exit the audio menu after five seconds of inactivity. The following menu items can be adjusted.
Bass Level
Use the rotary encoder (1) to adjust the Bass level range from “-6” to “+6”.
Treble Level
Use the rotary encoder (1) to adjust the Treble level range from “-6” to “+6”.
Balance
Adjusting Balance controls the relative level between the left and right speakers in each pair. Use the rotary encoder (1) to adjust the Balance between the left and right speakers from “Left 12” to “Right 12”.
Fader
Adjusting Fade controls the relative level between the front and rear speaker pairs. Use the rotary encoder (1) to adjust the Fader between the rear and front speakers from “Rear 12” to “Front 12”.
5
