EON712
12-inch Powered PA Speaker with Bluetooth
SPEC SHEET
OVERVIEW 6
The JBL EON712 12-inch loudspeaker, part of JBL’s new
EON700 Series of powered PAs, brings brings advanced
DSP and control to portable systems for live sound and
installed applications, with class-leading volume and clarity
and comprehensive features that make setup and operation a
breeze.
PRODUCT HIGHLIGHTS 6
9 Custom-designed 12-inch woofer
9 2414H compression driver
9 Redesigned high-frequency horn
9 Power: 1,300W Peak / 650 RMS
9 Frequency response: 50Hz - 20kHz (-10)
60Hz - 20kHz (-3)
9 Max SPL: 127 dB
9 Dispersion: 100° H x 60° V
9 Audio I/Os: 2 XLR Combo, 1 XLR passthrough
9 Advanced dbx DSP: Automatic Feedback Suppression,
ducking, 100ms speaker delay, parametric EQ
www.jblpro.com
REAR PANEL CONNECTIONS
9 Built-in 3-channel digital mixer
9 Color backlit LCD screen provides easy access to functions
9 Universal JBL Pro Connect app control
9 Bluetooth 5.0 streaming and control
9 Durable polypropylene cabinet and metal grille
9 Two ergonomic handles simplify transport
9 Built-in pole mount and optional EON700 Universal Yoke Mount
expand system conguration options
9 Stackable cabinets for easy storage
9 Net Weight: 14.5 kg (32 lbs.)
EON712
12-inch Powered PA Speaker with Bluetooth
SPEC SHEET
SPECIFICATIONS 6
System Type 12IN Powered Loudspeaker
Woofer Model 712G
Woofer Size 12"
Woofer Magnet Ferrite
Woofer Voice Coil 2"
Tweeter Model 2414H Compression Driver
Tweeter Size 1''
Tweeter Magnet Neodymium
Transducer
Impedence
Max SPL 127dB @1m/4Pi
Freq Range -10 50Hz - 20kHz
Freq Range -3 60Hz - 20kHz
Hor Dispersion 100°
Vert Dispersion 60°
Power Rating 1300W peak / 650 RMS
AC Power Input 100V-120V or 220V-240V
LF 4ohm rated, HF 8ohm rated
Cooling Passive
LED Indicators
Input Impedence 50k/100k un-balanced/balanced
Input Gain
Crossover Freq 2 kHz
I/O 2 XLR Combo Jacks / BT
Cabinet PP+1 0% Ta l c
Grille
Suspension/
Mount
Handles 2, cable channel on bottom
Net Weight 14.6kg (32.19 lbs.)
Gross Weight 18.4kg (40.57 lbs.)
Product Dims HxWxL 670x381x328mm (26.38x15.0x12.91 in.)
Shipping Dims HxWxL 684x490x430mm (26.93x19.29x16.93 in.)
1 Power LED, 1 Limit LED, 1 Front LED, 2 Signal/SSM
LEDs
to +36db
-∞
1 XLR M Thru
16GA perforated steel with acoustically transparent black
cloth backing
4 M10 Suspension points, 36mm Pole Socket, universal
yoke bracket holes
www.jblpro.com
EON712
669 mm
26.34 in
382 mm
15.04 in
324 mm
12.75 in
12-inch Powered PA Speaker with Bluetooth
SPEC SHEET
FREQUENCY RESPONSE 6
PRODUCT DIMENSIONS 6
HARMAN Professional 8500 Balboa Blvd. Northridge, CA 91329 USA
© 2021 HARMAN International Industries, Incorporated. All rights reserved.
Features, specications and appearance are subject to change without notice.
www.jblpro.com
Issued: 10/2021
