Jabra STEALTH User Manual

JABRA STEALTH

User Manual

jabra.com/stealth

© 2014 GN Netcom A/S. All rights reserved. Jabra® is a registered
trademark of GN Netcom A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth
mark and logos are owned by the Bluetooth SIG, Inc. and any use

®

word

of such marks by GN Netcom A/S is under license. (Design and
specifications subject to change without notice).

MADE IN CHINA
MODEL:OTE18

Declaration of Conformity can be found on

www.jabra.com/CP/US/declarations-of-conformity

CONTENTS

1. WELCOME .......................................... 4

2. HEADSET OVERVIEW ......................... 5

3. HOW TO WEAR ..................................6

3.1 CHANGE EARGELS

3.2 ATTACHING THE EARHOOK

4. HOW TO CHARGE THE BATTERY ....... 8

5. HOW TO CONNECT ............................ 9

5.1 CONNECT TO MOBILE DEVICE

5.2 CONNECT TO MOBILE DEVICE NFC

6. HOW TO USE ................................... 11

6.1 MULTIPLE CALL HANDLING

6.2 LIST OF VOICE GUIDANCE

7. SOFTWARE .......................................15

7.1 JABRA ASSIST

8. SUPPORT ..........................................16

8.1 FAQ

8.2 HOW TO CARE FOR YOUR HEADSET

9. TECHNICAL SPECIFICATIONS ...........17

english

jabra stealth

3

1. WELCOME

Thank you for using the Jabra Stealth. We hope you
will enjoy it!

JABRA STEALTH FEATURES

 Voice guidance
 Smart phone voice controls
 Battery and pairing status display
 HD voice
 Up to 6 hours talk time
 Power Nap feature
 Wireless freedom - Up to 30m/98ft

english

jabra stealth

4

2. HEADSET OVERVIEW

On/off
switch

USB charging
port

Eargels Earhooks

NFC Zone

Answer/end
button

Voice button

Bluetooth
Indicator

Microphones

english

jabra stealth

5

3. HOW TO WEAR

The headset can be worn with or without the
earhook, on the left or right ear. Additional
earhooks and eargels are available in the pack.

3.1 CHANGE EARGELS

Choose between different ergo-designed eargels
for optimal fit and comfort.

english

jabra stealth

6

3.2 ATTACHING THE EARHOOK

The earhook can be attached to the headset if the
earhook fit is preferred.

english

jabra stealth

7

4. HOW TO CHARGE THE BATTERY

1. Pull back the charging cover on the headset to

expose the USB charging port.

2. Connect the headset to a USB port using the USB

cable.

NOTE: For safety reasons, it is recommended not to use the
headset while it is charging.

It takes approx. 2 hours to fully charge the headset.

english

jabra stealth

8

5. HOW TO CONNECT

5.1 CONNECT TO MOBILE DEVICE

1. Turn the headset on (set the On/off switch to

the On position).

2. Press and hold (3 secs) the

until the Bluetooth indicator flashes blue, and
pairing mode is announced in the headset.

3. Follow the voice-guided pairing instructions to

pair to your Bluetooth device.

Answer/end button

english

jabra stealth

9

5.2 CONNECT TO MOBILE DEVICE NFC

1. Ensure that NFC is enabled on your mobile

device.

2. Slowly slide the NFC zone of the headset against

the NFC zone of the mobile device until a
connection is confirmed.

english

jabra stealth

10

6. HOW TO USE

Answer/end button

Voice button

On/off button

FUNCTION ACTION

On/Off Slide the ON/OFF switch

Answer/end
call

Reject call

Redial last
number

Activate
voice controls
(phone
dependent)

Mute/unmute

Tap the Answer/end button, or
say ‘Answer’

Double-tap the
button, or say ‘Ignore’

Double-tap the
button when not on a call

Tap the
dialing (e.g. Siri/Google Now).
Press and hold (1 sec) the
button for voice commands

Tap the
a call

Answer/end

Answer/end

Voice button for voice

Voice button when on

english

Voice

jabra stealth

11

6.1 MULTIPLE CALL HANDLING

The headset can accept and handle multiple calls
simultaneously.

FUNCTION ACTION

End current call and
answer incoming call

Switch between held call
and active call

Put current call on hold
and answer incoming call

Reject incoming call

Tap the Answer/end
button

Press and hold (2
secs) the
end button

Press and hold (2
secs) the
end button

Double-tap the
Answer/end button

english

Answer/

Answer/

jabra stealth

12

6.2 LIST OF VOICE GUIDANCE

CLICK TO LISTEN WHAT YOU HEAR

Power on

Power off

Welcome. You are now ready for pairing

Pairing cancelled

Pairing failed

Mobile connected

PC connected

Two devices connected

Not connected

Redialing

Mute on

Mute off

Call from...

english

jabra stealth

13

CLICK TO LISTEN WHAT YOU HEAR

Unknown caller

Low battery

english

Your remaining talk time is...

Say a command

Voice on

Voice off

jabra stealth

14

7. SOFTWARE

7.1 JABRA ASSIST

Jabra Assist is a smartphone app that enables GPS
tracking of the headset, pairing assistance, and
headset battery status.

Android download - Google Play

iOS download - App Store

english

jabra stealth

15

8. SUPPORT

8.1 FAQ

View the comprehensive FAQ on Jabra.com/stealth.

8.2 HOW TO CARE FOR YOUR HEADSET

 Always store the headset with the power off

and safely protected.

 Avoid storage at extreme temperatures (above

70°C/158°F or below -10°C/14°F). This can
shorten battery life and may affect headset
operation.

 Do not expose the headset to rain or other

liquids.

english

jabra stealth

16

9. TECHNICAL SPECIFICATIONS

JABRA STEALTH SPECIFICATION

Weight: under 7.9g

Dimensions:

Microphones: Dual microphone technology

Speaker: 11 mm dynamic speaker

Operating range: 30m/98ft (phone dependent)

Bluetooth version: 4.0

Paired devices:

Supported Bluetooth
profiles:

Talk time: Up to 6 hours

Standby time: Up to 10 days

Operating temperature: -10°C to 55°C (14°F to 131°F)

Storage temperature: -20° C to 70°C (-4°F to 158°F)

Pairing passkey or PIN: 0000

L 64.9 mm x W 15.3 mm x
H 24.9 mm

Up to 8, connected to two at
the same time (MultiUse™)

A2DP(v1.2), Hands Free Profile
(v1.6), Headset profile(v1.2),
Phone book access profile (v1.0)

english

jabra stealth

17

english

www.jabra.com/stealth

jabra stealth

18

REV B
