Jabra® FREEWAY
User manual
www.jabra.com
CONTENTS
THANK YOU....................................................2
ABOUT YOUR JABRA FREEWAY.................................2
WHAT YOUR SPEAKERPHONE CAN DO .........................3
GETTING STARTED .............................................4
CHARGE YOUR SPEAKERPHONE................................4
TURNING YOUR SPEAKERPHONE ON AND OFF.................5
PAIRING IT WITH YOUR PHONE/DEVICE ........................6
PAIR A NEW OR SECOND DEVICE ...............................6
CONNECTING WITH YOUR PHONE..............................7
PLACE THE SPEAKERPHONE IN YOUR VEHICLE .................7
HOW TO .......................................................8
JABRA VOICE FEATURES.......................................10
ADDITIONAL FEATURES.......................................13
TROUBLESHOOTING & FAQ ...................................15
TAKING CARE OF YOUR SPEAKERPHONE ......................18
GLOSSARY ....................................................18
ENGLISH
JABRA FREEWAY
1
THANK YOU
Thank you for purchasing the Jabra FREEWAY Bluetooth®
speakerphone. We hope you enjoy it! This instruction manual
will get you started and ready to make the most of your
speakerphone.
ABOUT YOUR JABRA FREEWAY
A Answer/end button
Tap to answer/end call
B FM button
Tap to activate FM mode and stream music and calls to your
car radio
C Volume down
Tap to adjust volume down
D Mute button
Tap to mute/un-mute your microphone during a call
E Volume up
Tap to adjust volume up
F Voice button
Tap to initiate voice command functions
G Visor clip
H Power switch
Slide to ON position to turn the FREEWAY on
I Micro USB charging connector
Charge with the Micro USB charger
J Charging indicator light
Light red while charging and turns o when fully charged
B
C
A
F
E
D
J
ENGLISH
G
H
I
JABRA FREEWAY
2
WHAT YOUR SPEAKERPHONE CAN DO
Your Jabra FREEWAY lets you do all this:
- Make and answer calls just using your voice
- Ease of use with Jabra Voice Guidance
- Last number redialing and call back last number
- Voice dialing*
- Three way calling*
- Advanced MultiUse™ - be connected to two active Bluetooth
devices at the same time
- Tells you who is calling*
- Transfer music and calls to your car radio
- Turns on and off automatically using the builtin G-sensor
- Listen to wireless stereo music in Virtual Surround Sound*
Specifications:
- Up to 14 hours of talk time and 40 days of standby time
- Rich and crisp stereo sound and Virtual Surround Sound
- Dual microphones provides outstanding background noise
reduction
- Digital sound enhancements via DSP technology
- Clear wireless streaming of you r favorite multimedia: Music,
podcasts, video, etc. (from A2DP enabled devices*)
- Bluetooth technology – Easy pairing with Bluetooth 2.1 +
EDR & eSCO
- Supported Bluetooth profiles: HFP, HSP, A2DP, AVRCP, PBAP
- Up to 128-bit encryption
- Rechargeable battery with charging option from car charger or
PC using the supplied USB cable
- Operating range up to 10 meters (approximately)
- Weight 150 grams
- Size: L 100 mm x W 120 mm x H 20 mm
ENGLISH
* Phone dependent
JABRA FREEWAY
3
GETTING STARTED
You should follow three steps before using your speakerphone:
1 Charge your Speakerphone using the supplied USB cable and
car charger (approximately 2 hours)
2 Activate Bluetooth® on your phone or device (refer to the
manual of your device)
3 Pair your speakerphone to your phone or device
The first time you turn your Jabra FREEWAY on you will hear Voice
Guidance telling you what to do.
NOTE: Voice Guidance and Voice commands are enabled as the
default setting when you turn on your Jabra FREEWAY the first
time. You can at any time disable both by pressing the Voice
button while you slide the power switch into the On position.
You will hear ”Voice off” and FREEWAY will no longer talk to you
or listen for commands. Repeat the process to enable the voice
features again.
CHARGE YOUR SPEAKERPHONE
Make sure that your speakerphone is fully charged before you
start using it. Use the USB cable to connect Jabra FREEWAY to the
car charger. Plug the car charger into your car’s power outlet. The
charging indicator light will light up in red while charging. When
the Jabra FREEWAY is fully charged the indicator light will turn off.
A full charge takes approximately two hours.
Jabra FREEWAY can be charged outside your car using the USB
cable.
ENGLISH
JABRA FREEWAY
4
Only use the charger provided in the box – do not use chargers
from other devices as this may damage your speakerphone. Also
you should not use your supplied FREEWAY charger to charge
other devices.
NOTE: The lifetime of the battery will be signicantly reduced
if your device is left uncharged for a long period. We therefore
recommend that you recharge your device at least once a month.
TURNING YOUR SPEAKERPHONE ON AND OFF
- Slide the On/O power switch to turn the speakerphone on or
o.
- If the switch is left in the On position the Jabra FREEWAY will
automatically turn on and reconnect to your phone when you
enter your car (open the car door).
The Jabra FREEWAY will automatically turn o when your phone is
moved away from the car.
NOTE: Moving the Jabra FREEWAY will also turn it on if the power
switch is in the On position.
ENGLISH
JABRA FREEWAY
5
PAIRING IT WITH YOUR PHONE/DEVICE
Speakerphones are connected to mobile phones using a procedure
called ‘pairing’. By following a few simple steps, a phone can be
paired with a speakerphone in a matter of seconds.
1 Activate Bluetooth® on your phone/device
2 Turn the Jabra FREEWAY on
3 The rst time you turn the FREEWAY on it will automatically
enter into pairing mode. The Answer/end button will ash
with a blue light and you will be voice guided through the
pairing process. If you have disabled voice guidance go to the
Bluetooth® settings menu on your phone/device and search for
new Bluetooth® devices. Choose Jabra FREEWAY.
4 When pairing is complete you will hear ”Connected”. You are
now ready to start using your Jabra FREEWAY.
NOTE: If asked for a passkey or pin code use 0000 (four zeros)
ENGLISH
CONNECTIVITY
MobilSurf
BLUETOOTH
Infrared port
Wap options
Synchronization
Networks
SELECT
DEVICES FOUND
Jabra FREEWAY
SELECT
Jabra FREEWAY
Passkey:
****
OK
HANDSFREE
Jabra FREEWAY
added.
The handsfree is
now ready for use
SELECT
PAIR A NEW OR SECOND DEVICE
1 Ensure that the Jabra FREEWAY is turned on
2 Tap the Voice button. You will be asked to ”Say a command”
3 Say ”Pair new device” and follow the instructions
4 If this is your second device you will need to reconnect to the
rst device afterwards
JABRA FREEWAY
6
NOTE: If you have disabled Voice Guidance you can put Jabra
FREEWAY in pairing mode manually by pressing and holding the
Answer/end button while you slide the power switch into the On
position. The Answer/end button will ash blue to indicate that
you are in pairing mode.
CONNECTING WITH YOUR PHONE
Pairing is only needed the rst time a speakerphone and a phone/
device are used together. When the speakerphone and phone/
device have been paired once they will automatically reconnect
when the speakerphone is on and Bluetooth® is activated on the
phone/device.
If the devices are paired, but do not immediately reconnect tap
the Answer/end button.
PLACE THE SPEAKERPHONE IN YOUR VEHICLE
The Jabra FREEWAY sits discreetly and conveniently on the sun
visor using the attached clip. For optimal sound quality place
the Jabra FREEWAY right in front of you and speak directly
into the speakerphone.
ENGLISH
JABRA FREEWAY
7
HOW TO
The Jabra FREEWAY is easy to operate. The buttons performs
dierent functions depending on how long you press them.
Instruction Duration of press
Tap Press briey
Double tap Press briey two times within 1/2 second
Press Approx: 1-3 second
Long press Approx: 4-5 seconds
Extra long press Approx: 5-10 seconds
Answer a call
- Tap the Answer/End button
- Say “Answer” after the caller is announced.*
End a call
- Tap the Answer/End button
Reject/ignore a call*
- Double Tab the Answer/End button when the phone rings to
reject an incoming call. Depending on your phone settings, the
person who called you will either be forwarded to voice mail or
hear the busy signal
- Say “Ignore” after the caller is announced.*
Make a call*
- Tap the Voice button and you will be prompted to “Say a
command”. You can then:
- Say ”Redial” to redial last outgoing number
- Say ”Call back” to call back the last incoming number*
- Say ”Phone commands” to activate the voice dialing feature on
your phone**
ENGLISH
* Phone dependent
** Refer to phone’s user manual
JABRA FREEWAY
8
- You can also place a call directly from your phone. If your
phone is connected it will automatically transfer the call to your
Jabra FREEWAY*. If the call does not transfer, tap the Answer/
end button.
Last number redial*
- Double tap the Answer/End button
Activate Voice dialing**
- Press the Answer/end button to activate the phones voice
dialing or tap the Voice button and say “Phone commands”.*
Mute/un-mute
- Tap the Mute button during a call to mute your microphone
during a call and again to turn mute off.
Adjust sound and volume
- Tap the Vol- or Vol+ buttons to adjust the volume when on a
call or listening to wireless on your Jabra FREEWAY.
Three way calling*
- Press the Answer/end button to switch to call on hold. Press
the Answer/end button to switch back to rst call.
Play music*
- If your phone supports A2DP audio streaming then you can
transfer music or any other type of audio to the FREEWAY.
Answer a call while playing music*
- If you have an incomming cal while listening to music on the
Jabra FREEWAY the music will pause and you will hear your
ringtone or caller ID. You can then chose to aswer or ignore the
call. After the call the music will start to play again*.
ENGLISH
* Phone dependent
** Refer to phone’s user manual
JABRA FREEWAY
9
JABRA VOICE FEATURES
Typ e Definition
Voice Control Your voice in action, where you guide
the speakerphone
Voice Guidance The speakerphone plays voice
announcements to you
When you have an incoming call you can answer or ignore just
using you voice. You do not have to touch Jabra FREEWAY or you
phone. Just say “Answer” to take the call and “Ignore” to reject.
Voice control – Incoming call
Your voice to FREEWAY What it does
“Answer” The speakerphone captures your
command and directs the phone to
take the call
“Ignore” The speakerphone captures your
command and directs the phone to
reject the call
At any time when you are connected to a phone you can tap
the Voice button, wait for Jabra FREEWAY to ask you to ”Say a
command”, and then say one of the following commands.
Voice control – Outgoing calls, pairing, battery level and
start music player
Your Voice to FREEWAY What it does
”Pair new device” Puts the FREEWAY into pairing
mode
”Redial” FREEWAY redials the last outgoing
call made on the phone
”Call back” Calls back the last incoming call
recieved on the FREEWAY
ENGLISH
JABRA FREEWAY
10
”Phone commands” Activates your phone’s voice dialing
feature*
”Battery” Will tell you the battery level on
FREEWAY
”Play” Will start the music player on your
phone/device*
”What can I say?” Will tell you what your options are
”Cancel” Will cancel the current operation
and close the voice menu
When you are playing music on the Jabra FREEWAY you can at
any time tap the Voice button to remote control you music player
using your voice.
Voice control – While listening to music*
Your Voice to FREEWAY What it does
”Next track” Will skip to the next track on your
playlist
”Previous track” Will skip to the previous track on
your playlist
”Stop” Will stop the music in your music
player
”Play” Will start your music player again
”What can I say?” Will tell you what your options are
”Cancel” Will cancel your current operation
and close the voice menu
ENGLISH
* Phone dependent
JABRA FREEWAY
11
The Jabra FREEWAY is loaded with voice announcements that talks
you through setup and daily operation. In the table below you can
see the most common announcements.
Voice guidance
FREEWAY
announcements to you
“Welcome! You are now
ready for pairing. Go to
the Bluetooth menu on
your phone.
Turn on or enable
Bluetooth.
Search for devices and
select your Jabra hands
free device. Select pair
or OK. If asked for a PIN
code enter 0000”
”Pairing failed” Announced if pairing fails
“Connected” Announced when FREEWAY is
“Two devices connected” Announced when FREEWAY is
”Disconnected” Announced if a connected phone/
”Battery level is low” Announced when the battery level
”Voice on/o” Announced when voice guidance
What it means
The FREEWAY is in pairing mode.
Announced automatically when
powered on the rst time and
whenever FREEWAY is put into
pairing mode.
connected to a phone
connected to two phones/devices
device is turned o, goes out of
range or has BT disabled while in
range and while the speakerphone
is still turned on.
goes below 10%
and controls are enabled or disabled
ENGLISH
* Phone dependent
JABRA FREEWAY
12
ADDITIONAL FEATURES
Play music, podcasts and audio from GPS applications*
If your phone or device supports A2DP audio streaming you can
hear your music or any other audio through your Jabra FREEWAY.
Simply start playing your music or start your application and the
audio will automatically transfer to FREEWAY. If your phone rings
the audio will mute and you can answer or ignore the call. The
audio will resume after the call.*
You can also start your music player by tapping the Voice button.
Wait for the FREEWAY to ask you to ”Say a command” and then
say ”Play”*.
When playing music you can at any time tap the Voice button
again and:
- Say ”Next track” and ”Previous track” to skip between songs
- Say ”Stop” or ”Play” to start or stop your music
If you want to exit A2DP streaming mode or stop the music you
can:
- Tap the Voice button and say ”Stop”
- Stop the music/audio in your device
Using you Jabra FREEWAY with two mobile devices at the
same time
The Jabra FREEWAY supports Advanced MultiUse™ and is capable
of having two mobile phones (or other Bluetooth® devices)
connected at the same time. This will give you the freedom of
having only one headset to operate both of you mobile phones/
devices.
When you have two active phones/devices connected you will
hear ”Two devices connected”. In this state the phone paired last
will be used for voice dialing. When two phones are connected
you can place and answer calls on both and switch between
the two. If you are on a call and receive a second call you will be
alerted by a tone. You can then:
- Put the rst call on hold and accept the incoming call by
pressing the Answer/end button
- Switch between the two active calls by pressing the Answer/
end button again
- Tap the Answer/end button once to end the first call and
accept the new incoming call
ENGLISH
* Phone dependent
JABRA FREEWAY
13
FM Transmitter
You can transmit your calls, music and GPS directions from your
phone/device to your car stereo using the built-in FM transmitter.
Tap the FM button and set your radio to the announced frequency.
If you experience interference from a radio station on your set
frequency you can either tap the FM button to quickly redirect the
audio back to the FREEWAY or press the VOL+ button to search for
a new frequency.
If your radio supports RDS it will automatically adjust to the new
frequency. If it doesn’t you have to manually set the radio to the
new frequency.
Note: When in FM mode the volume controls on the FREEWAY are
disabled. Use the volume control on your car radio instead.
QUICK REFERENCE TABLE FOR MANUALLY CONTROLLING YOUR
JABRA FREEWAY
Function Action
Entering pairing
mode
Cancel pairing mode Tap the Answer/end button
Answer call Tap the Answer/end button
End a call Tap the Answer/end button
Reject a call Double tap the Answer/end button to
Initiate phone voice
dial*
Press and hold the Answer/end
button while sliding the Power switch
into the On position
reject an incoming call
Press the Answer/end button when
connected or not on an active call or
tap the Voice button and say “Phone
commands” to activate the voice
dialing feature on your phone.*
ENGLISH
* Phone dependent
JABRA FREEWAY
14
Enable or disable
Voice Guidance and
commands
Reset to factory
default
Night driving mode When powered on you can tap the
Download Firmware updates and additional languages
Go to jabra.com/freeway and download the latest rmware and
additional languages.
Press and hold the Voice button while
sliding the Power switch into the On
position. You will hear ”Voice on” when
you enable and ”Voice o” when you
disable the voice features.
Turn on the FREEWAY and press and
hold the Answer/end, Voice and
Mute button together for about 6
seconds. When the FREEWAY is reset
it will automatically go into pairing
mode.
Vol- and Vol+ simultaneously to
disable the LED’s. And again to enable
them again. The LED’s will be enabled
every time you reconnect or power on
the FREEWAY.
TROUBLESHOOTING & FAQ
I hear crackling noises
- Bluetooth is a radio technology, which means it is sensitive to
objects between the speakerphone and the connected device.
It is designed for the speakerphone and the connected device
to be used within 33 feet (10 meters) of each other, with no
major objects in the way (walls, etc.).
I cannot hear anything in my speakerphone
- Increase the volume in the speakerphone.
Ensure that the speakerphone is paired to a device that is playing.
-
- Make sure your phone is connected to the speakerphone by
tapping the Answer/End button.
ENGLISH
JABRA FREEWAY
15
I am having pairing problems
- You may have deleted your speakerphone pairing connection
in your mobile phone/device. Follow the pairing instruction to
pair it again.
I want to reset the pairing list in my speakerphone
- The speakerphone registers a list of up to 7 mobile phones. To
clear the pairing list and reset the Jabra FREEWAY to factory
settings you can turn the FREEWAY on while pressing the FM,
Voice and Answer/end button for about 6 seconds. The next
time you power on the Jabra FREEWAY it will automatically go
into pairing mode.
Will the Jabra FREEWAY work with other Bluetooth
equipment?
- The Jabra FREEWAY is designed to work with Bluetooth mobile
phones. It can also work with other Bluetooth devices that are
compliant with Bluetooth version 1.1 or higher and support
a headset, hands-free and/or advance audio distribution profile.
I cannot use Reject call, call on hold, Redial or voice dialing
- These features are dependent on the ability of your phone to
support a hands-free prole. Even if the handsfree prole is
implemented reject call, call hold and voice dialing are optional
features which are not supported by all devices. Please consult
your device manual for details.
Please note that some features can only be operated from the
primary device e.g. voice dial using Jabra FREEWAY with 2 mobile
phones.
I can not connect speakerphone and radio via FM transmitter
- Make sure the radio is turned on and speakerphone is in FM
mode (FM Status Icon is on).
- If your radio when searching is not able to find the FM frequency
set by your speakerphone, the FM frequency must be tuned
in manually on the radio. Please read radio manual to find out
how to manually change frequency on your radio.
- If your radio is in TA (Traffic Announcement) mode, switch TA
off and your radio should be able to find your speakerphone
when using the search function on the radio. If not tune in
manually.
ENGLISH
JABRA FREEWAY
16
- The sensitivity of the search function on your radio determines
whether it is able to find the frequency set by your speakerphone.
On some radios you are able to adjust the sensitivity thus
making it possible to find the speakerphone frequency when
searching. If not tune in manually.
- In urban areas it might be difficult to find a clear frequency.
It is therefore advisable to use a frequency in the lower or upper
end of the FM frequency band (e.g. 88.1 or 107.7 MHz) where
you will have the best chance to find a clear frequency.
My Jabra FREEWAY does not announce the caller names
during incoming calls
- Ensure that your phone supports the Bluetooth® phonebook
access prole (PBAP) and that the name of the caller is in you
phonebook.
Please note that on some Android phones a warning message
about the phonebook transfer appears in the top left corner. You
must select this message and agree to the connection in order to
get caller ID to function properly.
ENGLISH
JABRA FREEWAY
17
TAKING CARE OF YOUR SPEAKERPHONE
- Always store the Jabra FREEWAY with the power o and safely
protected.
- Avoid storage at extreme temperatures (above 45°C/113°F –
including direct sunlight – or below -10°C/14°F). This can shorten
battery life and may aect operation. High temperatures may
also degrade performance.
- Do not expose the Jabra FREEWAY to rain or other liquids.
GLOSSARY
1 Bluetooth is a radio technology that connects devices, such
as mobile phones and headsets, without wires or cords over
a short distance (approx. 10 meters/33 feet). Bluetooth is safe
to use. It is secure too, so once a connection has been made
no-one can listen in and there is no interference from other
Bluetooth devices either. Get more information at
www.bluetooth.com.
2 Bluetooth proles are the dierent ways that Bluetooth devices
communicate with other devices. Bluetooth phones support
the headset prole, the hands-free prole or both. In order to
support a certain prole, a phone manufacturer must implement
certain mandatory features within the phone’s software.
3 Pairing creates a unique and encrypted link between two
Bluetooth devices and lets them communicate with each other.
Bluetooth devices will not work if the devices have not been
paired.
4 Passkey or PIN is a code that you enter on your Bluetooth
enabled device (e.g. a mobile phone) to pair it with your Jabra
FREEWAY. This makes your device and the Jabra FREEWAY
recognize each other and automatically work together.
5 Standby mode is when the Jabra FREEWAY is passively waiting
for a call. When you ‘end’ a call on your mobile phone, the
speakerphone goes into standby mode.
ENGLISH
Dispose of the product according
to local standards and regulations.
www.jabra.com/weee
JABRA FREEWAY
18
© 2011 GN Netcom US, Inc. All rights reserved. Jabra® is a registered
trademark of GN Netcom A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth
mark and logos are owned by the Bluetooth SIG, Inc. and any use
®
word
of such marks by GN Netcom A/S is under license. (Design and
specifications subject to change without notice).
© 2011 GN Netcom A/S. All rights reserved. Jabra® is a registered
trademark of GN Netcom A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth
mark and logos are owned by the Bluetooth SIG, Inc. and any use
®
word
of such marks by GN Netcom A/S is under license. (Design and
specifications subject to change without notice).
MADE IN CHINA
TYPE: HFS100
www.jabra.com
REV D
Loading...
