Jabra® SPORT
User manual
www.jabra.com
CONTENTS
THANK YOU....................................................2
ABOUT YOUR JABRA SPORT....................................2
WHAT YOUR HEADSET DOES...................................3
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
CHARGING YOUR JABRA SPORT ...............................4
TURNING YOUR JABRA SPORT ON AND OFF....................4
PAIRING YOUR JABRA SPORT TO A PHONE OR
OTHER DEVICE .................................................4
USING YOUR JABRA SPORT.....................................5
WEARING STYLE & EARGELS ...................................7
HEADSET VISUAL AND AUDIO INDICATORS ....................7
USING YOUR JABRA SPORT WITH THE ENDOMONDO
SPORTS TRACKER APPLICATION FOR MOBILE PHONES.............9
USING YOUR JABRA SPORT WITH TWO DEVICES...............10
TROUBLESHOOTING & FAQ ...................................11
TAKING CARE OF YOUR HEADSET .............................12
GLOSSARY ....................................................13
JABRA SPORT
1
THANK YOU
R
L
A
B
R
E
C
D
F
Thank you for purchasing the Jabra SPORT Bluetooth® Stereo
Headset. We hope you enjoy it! This instruction manual will get
you started and ready to make the most of your headset.
For best possible music streaming performance, make sure to
keep your mobile phone on the right side of your body.
L
R
L
R
ABOUT YOUR JABRA SPORT
A On/O, Answer/End, Play/Pause or Endomondo Status
B Microphone
C LED indicator
D Volume Control, Skip Track, FM Auto seek
E FM On/O
F Eargels
JABRA SPORT
2
WHAT YOUR HEADSET DOES
The Jabra SPORT lets you enjoy wireless music and calls while
exercising.
Product highlights:
- Secure and comfortable t during exercise
- Rain, dust and shock protection. US Military and IP54 standard
- Powerful bass and built-in FM radio
Features and Specications
1. Wireless freedom through Bluetooth technology
2. Optimized comfort for an active life style
3. Tested against US Military and IP54 standards for rain*, dust
and shock resistance
4. Integrated FM receiver so you can listen to your favorite radio
stations
5. Advanced Multiuse™ - connect 2 Bluetooth devices at the
same time
6. AM3D Power Bass for an enhanced music experience
7. 3 dierent sets of eargels for an individual t
8. Exclusive features when used with the Endomondo Sports
Tracker**
a. Instant Feedback; get your Endomondo workout status read
aloud through your headset
b. Workout Control; pause your Endomondo workout at the
press of a button
9. Up to 4.5 hours of talk time, 4 days of standby time
10. Bluetooth prole 3.0
11. Features answer/end, play/pause music***, volume up/down***
and skip track*** buttons
* The Jabra SPORT can withstand a short rain shower but is not waterproof and
cannot be submerged in uids. If your device gets wet, it should be wiped clean of
any traces of water in order to protect it from potential damage.
** See page 9 for more details.
*** Phone dependent
JABRA SPORT
3
GETTING STARTED
Follow these three steps before using your headset:
1 Charge your headset (approximately 2 hours)
2 Activate Bluetooth® on your mobile phone (refer to the manual
for your mobile phone)
3 Pair your headset to your mobile phone
CHARGING YOUR JABRA SPORT
Make sure that your Jabra SPORT is fully charged before you start
using it for the rst time. While charging, the battery indicator
light is ashing green and when fully charged the LED indicator is
solid green. Charging time is approximately 2 hours.
Please note: The lifetime of the battery will be signicantly reduced
if your device is left uncharged for a long period. Jabra therefore
recommends that you recharge your device at least once a month.
TURNING YOUR JABRA SPORT ON AND OFF
To turn your Jabra SPORT on press the On/O button (A) until the
LED ashes Blue. To turn your Jabra SPORT o press the On/O
button until the LED ashes Blue.
PAIRING YOUR JABRA SPORT TO A PHONE OR
OTHER DEVICE
Headsets are connected to phones or other Bluetooth devices
using a procedure called ‘pairing’. By following a few simple steps,
pairing can be done in a matter of seconds.
1. Put the headset in pairing mode
1.1a: First time pairing:
Turn on your Jabra SPORT and it will automatically enter pairing
mode and is ready to pair.
1.1b: Later pairing:
1.2 Make sure the Jabra SPORT is o. Put the SPORT into pairing
mode – press and hold the Answer/End button (A) until the
indicator light ashes blue (the rst time you turn on the
Jabra SPORT it will be in pairing mode).
1.3 Search for Bluetooth devices on your phone* or other device
and select the Jabra SPORT.
JABRA SPORT
4
2. If prompted for a PIN code, please enter 0000 (4 zeros) and
conrm.
* Follow your phone’s instruction guide. First make sure that Bluetooth is
activated on your mobile phone. Then set your phone to search for the headset.
This usually involves going to a ‘setup,’ ‘connect’ or ‘Bluetooth’ menu on your
phone and selecting the option to search for or ‘add’ a Bluetooth device.
Note: All communications between your Jabra SPORT headset
and mobile phone are encrypted, so others will not be able to
intercept and understand your conversation. Establishing this
encryption is an important part of the pairing process.
USING YOUR JABRA SPORT
Main features:
Play or pause music (some phones may require you to start a
media player rst)*
Tap the Play/Pause button (A) to play and pause music.
Change between music tracks*
Change tracks by pressing for approx. 1 sec. on the Volume up
(+) button (D) to skip forward and press for approx. 1 sec. on the
Volume down (-) button to skip back.
Adjust volume
Tap the volume buttons (D) to adjust the volume up or down.
Answer or end a call
Tap the Answer/End button (A) to answer or end calls.
Using the FM receiver**
- To turn on the FM radio, rst make sure your Jabra SPORT is
turned ON.
- Tap the FM button (E) on the headset to activate the FM
receiver
- To search for the next available radio station press and hold
either the Volume up (+) or the Volume down (-) button until
you hear a short beep - then release your press.
** Please use FM outdoors for best performance
* Refer to phone’s user manual
JABRA SPORT
5
PLEASE NOTE: FM reception conditions may vary signicantly depending on
the physical environment (e.g. buildings, mountains, being inside/outside), RF
environment (e.g. Wi-Fi), proximity to broadcasting tower and other external
factors.
Endomondo features (see page 9 for more details):
Instant feedback: With your Jabra SPORT stereo headset, you
can hear instant performance updates during your workout. Tap
the Play/Pause button (A) to get status on speed, distance and
duration.
Workout control: With your Jabra SPORT stereo headset, you can
easily control the Endomondo Sports Tracker with the push of
a button. Press the Play/Pause button (A) for 1 sec. to pause or
resume workout
Other features:
Reject a call**
Double tap the Answer/End button (A) when the phone rings to
reject an incoming call. Depending on your phone settings, the
person who called you will either be forwarded to voice mail or
hear the busy signal.
Make a call**
When your Jabra SPORT is connected to your phone, all calls made
from your phone will automatically be transferred to your headset
(subject to phone settings).
Redial last number**
Double tap the Answer/End button (A).
Mute microphone when on a phone call
Tap the – and + volume button simultaneously to mute Tap either
the - or the + volume button again to unmute.
Factory reset:
To perform a factory reset, press and hold the Answer/End button
(A) and volume ‘+’ (D) simultaneously for 3 seconds
** Device dependent
JABRA SPORT
6
WEARING STYLE & EARGELS
Place each ear piece so the speaker is in front of the ear canal and
the ear hook wraps snugly around the back of the ear.
The wire should run behind the neck for optimum comfort and
freedom of movement.
Three dierent eargels are included to secure the best possible t
and comfort.
Align the guiding arrows on the speaker housing and eargels for correct
positioning. There are Left & Right indicators on the eargels also.
HEADSET VISUAL AND AUDIO INDICATORS
The Jabra SPORT provides status messages using both lights and
Voice Guidance.
The indicator light on the back side of Jabra SPORT indicates
dierent states of the product:
Indicator light What the light means
Flashing blue In pairing mode - see ‘Pair
Slow single blue ash Connected to a phone and in
Single blue ash Connected to phone and
Quick blue double ash Incoming call
Slow green ashing Charging
Solid green Fully charged - the green
Red ashing Low battery
Jabra SPORT to a phone or
other device’
standby mode
active on call
indicator light will turn o
after 60 seconds
JABRA SPORT
7
The Jabra SPORT indicator light turns o after 60 seconds of
inactivity. The headset is still active, and light will ash again after
a tap on the Answer/End button or any call activity.
Voice Guidance
Jabra SPORT announcements What it means
“Welcome! You are now ready
for pairing. Go to the Bluetooth
menu on your phone.
Turn on or enable Bluetooth.
Announced every time
pairing mode is initiated.
Repeated after 20 seconds.
Search for devices and select
your Jabra hands free device
and chose pair or OK. If asked
for a PIN code use 0000”
”Pairing failed” Announced if pairing
”Connected” Announced when the
”Disconnected” Announced If a connected
”Low battery” Low battery warning when
”Power off” Announced when
Follow instructions on your
phone.
process fails.
Jabra SPORT is connected,
but no phone name is
available.
phone is turned off, goes out
of range or has BT disabled
while in range and while the
headset is still turned on.
battery goes below 10%
charge.
To be repeated every
5minutes.
When battery is below 10%
this will be announced every
30 seconds.
Also when on a call.
Jabra SPORT is shut down.
JABRA SPORT
8
”Power on” Announced when
Jabra SPORT is turned on.
”Call ended” Announced when call is
“Battery level is low/medium/
high”
ended.
”Battery level is high” is
announced when battery
has more than 50% left.
If the battery level is
between 10% - 50%.
“Battery level is medium” is
announced. If battery level
is below 10% “Battery level is
low“ is announced.
USING YOUR JABRA SPORT WITH THE ENDOMONDO
SPORTS TRACKER APPLICATION FOR MOBILE PHONES
Track your tness
Hear your performance
Analyze your results
Track your performance on-the-go
When you have downloaded the Endomondo app to your mobile
phone you have access to two exclusive features only provided
with Jabra SPORT.
JABRA SPORT
9
Instant feedback: With your Jabra SPORT stereo headset, you
can hear instant performance updates during your workout.
Tap the Play/Pause button (A) to get status on speed, distance and
duration.
Workout control: With your Jabra SPORT stereo headset, you
can easily control the Endomondo Sports Tracker with the push
of a button. Press the Play/Pause button (A) to pause or resume
workout.
Jabra SPORT features are applicable for iPhone, Android and
BlackBerry phones with GPS only. With Jabra SPORT connected to
your phone and with the Endomondo app open while exercising
you can tap the Play/Pause button to get a status update of your
workout read aloud through the headset.
Please note, that to get Instant Feedback & Workout Control
feature to work with any Bluetooth enabled Apple product
(iPhone® 4, iPhone® 3Gs), you need the Jabra SPORT ‘Made for
iPhone’ product variant.
iPhone users may experience a slight delay in music playback when switching over to FM radio
from iTunes while using the Endomondo app. In order to avoid any lag, please pause your
current track before switching over to the FM transmitter on Jabra SPORT
How to get Endomondo Sports Tracker
Download Endomondo Sports Tracker from the app store on your
smartphone or go to www.endomondo.com.
Join the popular community at www.endomondo.com to
challenge your friends and follow their performances live.
USING YOUR JABRA SPORT WITH TWO DEVICES
The Jabra SPORT is capable of having two dierent Bluetooth
devices connected to the headset at the same time – e.g. two
mobile phones or a mobile phone and a PC for Internet telephony
(VoIP).
If you would like to pair with a second device, simply follow the
pairing process for later pairing described earlier.
JABRA SPORT
10
TROUBLESHOOTING & FAQ
What is Bluetooth Stereo/A2DP?
Bluetooth Stereo enables a wireless connection of stereo audio
between two Bluetooth Stereo devices. In order to provide a
wireless Bluetooth Stereo connection between two devices, both
devices must support the A2DP (Advanced Audio Distribution
Prole) Bluetooth prole.
What is AVRCP?
Audio Video Remote Control Prole (AVRCP) enables you to
remote control your music player from the Jabra SPORT with
functions such as Play, Pause & Skip Track (can be phone
dependent).
How can I use the Multiuse™ feature on my Jabra SPORT?
Multiuse functionality enables you to be connected to two
dierent devices at the same time (e.g. a mobile phone and a PC).
This means that for example, you can use the same headset for
both listening to music from your mobile phone and use it for
Internet telephony (e.g. Skype or Google Talk) at the same time.
I hear crackling noises
Bluetooth is a radio technology which means it is sensitive to
objects between the headset and the device it is connected to.
You should be able to have up to 10 meters (33 feet) of distance
between the headset and the connected device when there are
no major objects in the way (walls, etc.).
I cannot hear the phone call in the headset
Increase the volume on the Jabra SPORT.
Make sure your phone is connected to the headset by i.e. tapping
the Answer/End button (A), or viewing the LED indicator.
I have pairing problems
You may have deleted the pairing connection in your mobile
phone – follow the pairing instructions in ‘Pair Your Headset to a
Phone or other Device ‘ section.
JABRA SPORT
11
I cannot use Reject call, Call on hold or Redial
These features are dependent on your phone supporting them;
please consult your phone’s manual for details.
I cannot hear music in the headset
Ensure that the headset is connected to your Bluetooth enabled
device.
You may have been out-of-range (10 meters) to your Bluetooth
enabled device or the headset might have experienced an ESD
(Electrostatic discharge) incidence. Press the Answer/End Button
(A) to re-establish the Bluetooth audio link - Increase the volume
on your device.
Make sure that the Jabra SPORT is charged.
The music I hear sounds very poor
Make sure the other device supports Bluetooth 1.1 or higher
including the Advanced Audio Distribution Prole (A2DP) for
music streaming.
If the above procedure did not help then it is possible that your
phone is using the stereo audio connection in a dierent way. You
can enable this mode on Jabra SPORT by performing pairing in
the following way:
- Remove the Bluetooth connection to Jabra SPORT on your
phone
- Make sure the headset is turned o
- Press and hold the Answer/End button (A) for more than
5 seconds until the indigator light ashes blue
- Go through the regular steps in pairing the headset to a
Bluetooth device.
TAKING CARE OF YOUR HEADSET
- Always store the Jabra SPORT with the power o and safely
protected
- Avoid storage at extreme temperatures (above 45°C/113°F –
including direct sunlight – or below -10°C/14°F). This
can shorten battery life and may aect operation. High
temperatures may also degrade performance.
- Do not expose the Jabra SPORT to rain or other liquids.
JABRA SPORT
12
GLOSSARY
1 Bluetooth is a radio technology that connects devices, such
as mobile phones and headsets, without wires or cords over
a short distance (approx. 10 meters/33 feet). Bluetooth is safe
to use. It is secure too, so once a connection has been made
no-one can listen in and there is no interference from other
Bluetooth devices either. Get more information at
www.bluetooth.com.
2 Bluetooth proles are the dierent ways that Bluetooth
devices communicate with other devices. Bluetooth phones
support the headset prole, the hands-free prole or both. In
order to support a certain prole, a phone manufacturer must
implement certain mandatory features within the phone’s
software.
3 Pairing creates a unique and encrypted link between two
Bluetooth devices and lets them communicate with each other.
Bluetooth devices will not work if the devices have not been
paired.
4 Passkey or PIN is a code that you enter on your Blue tooth enabled
device (e.g. a mobile phone) to pair it with your Jabra SPORT.
This makes your device and the Jabra SPORT recognize each
other and automatically work together.
5 Standby mode is when the Jabra SPORT is passively waiting
for a call. When you ‘end’ a call on your mobile phone, the
headset goes into standby mode.
Dispose of the product according to local standards and
regulations.
www.jabra.com/weee
JABRA SPORT
13
© 2011 GN Netcom US, Inc. All rights reserved. Jabra® is a registered
trademark of GN Netcom A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth
mark and logos are owned by the Bluetooth SIG, Inc. and any use
®
word
of such marks by GN Netcom A/S is under license. (Design and
specifications subject to change without notice).
© 2011 GN Netcom A/S. All rights reserved. Jabra® is a registered
trademark of GN Netcom A/S. All other trademarks included herein
are the property of their respective owners. The Bluetooth
mark and logos are owned by the Bluetooth SIG, Inc. and any use
®
word
of such marks by GN Netcom A/S is under license. (Design and
specifications subject to change without notice).
MADE IN CHINA
MODEL: BTE4
www.jabra.com
81-03448 C
Loading...
