Jabra BT110 User Manual

English

Thank you . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1. Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. Using your Jabra BT110 headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

3. Using your Jabra BT110 with the Jabra A210 Bluetooth adapter . . . . . . . . . 6

4. LED status indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

5. Choosing wearing preference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

6. Troubleshooting and frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . 7

7. Need more help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

8. Storage of the Jabra BT110 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

9. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

10. Certification and safety approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

11. Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Español

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

1

PART NUMBER 500-000452-00

English

English

2

Thank you for purchasing the Jabra BT110 Bluetooth® Headset,we hope you will be
totally delighted with its operation.The Jabra BT110 is a simple and easy way to enjoy
hands-free use of your Bluetooth mobile phone.The Jabra BT110 is designed to be
comfortable enough to be worn all day and will provide up to 15 hours of talk time on a
single AAA battery.

Please read the instruction manual to get started.

Using a mobile phone while driving creates a distraction to the driver which may increase
the likelihood of an accident.

When using the phone while driving,keep conversations short and do not make notes or
read documents.Before answering calls consider your circumstances.Pull off the road and
park before making or answering calls when driving conditions require (e.g.bad weather,
high traffic density,presence of children in the car, difficult junctions or manoeuvres.)

Remember,driving comes first,not the call!

Abide by local laws.

Jabra BT110 Overview

4

3

2

5

1

1 Answer / end button
2 Yellow light (LED) indicating

pairing and low battery

3 Volume control
4 Battery panel
5 MiniGel™

Summary of features

The Jabra BT110 is designed to be simple to
operate with a minimum of control buttons.
The answer/end button on the headset will
provide alternative operations depending on
the length of time it is pressed.

•

Up to 15 hours talk time on single AAA battery

•

Turns off automatically to lengthen battery life

•

Total weight including battery is only 26 grams

•

Range up to 10 metres (33 feet)

•

Bluetooth1(See glossary) version 1.2

•

Headset and hands-free Bluetooth profiles

2

•

Operational features:

•

Answer call

•

Call end

•

Supports voice-dialling (subject to phone)

•

Reject call

Your Jabra BT110 is compatible with most Bluetooth mobile phones.You can check
whether your phone has Bluetooth capability by visiting your phone manufacturer’s
web site or Jabra’s website (www.jabra.com)

BEFORE USING YOUR Jabra BT110
BLUETOOTH HEADSET

Instruction: Duration of press:

Tap Press briefly

Press Approx: 1 second

Press and hold Approx: 5 seconds

1. Insert an AAA battery

Open the battery
compartment by
sliding the battery
panel off as shown
in Fig.2

Fig. 2

In order for your Jabra BT110 to function with your Bluetooth mobile phone,you need
to establish a connection between the two devices:

3

English

Thank you

Drive safely

!

Getting Started

1

Fig. 1

1

2

4 5

6 7

To Pair the Jabra BT110 with the Jabra A210

Turn on the Jabra BT110 and the Jabra A210 and place the two devices in close
proximity to each other.

Set the adapter to pairing mode to connect with the headset. Consult the adapter’s
user manual for further information.

Turning the headset on and off

If you use your Jabra BT110 with the Jabra A210 Bluetooth adapter, your headset
will not automatically turn on and off,but remain on in standby mode

5

Leaving the
device on will affect battery life.You can manually turn the headset on and off by
following the instructions below.

•

To turn the headset on,press the answer/end button

•

To turn the headset off, press and hold the answer/end button (approx. 5 sec.)

Making/answering a call

•

When you make a call from your mobile phone,the call will be automatically
transferred to the headset (if it is on) – you do not have to tap the answer/
end button

•

You can answer a call on your headset or your mobile phone. As long as
your headset is in standby mode,the call will be transferred immediately to
the headset

IMPORTANT: Avoid using keypad tones on your mobile phone when using your

Jabra A210 Bluetooth adapter.The tones will activate the adapter and thus use the
battery power.

Your Jabra BT110 has a yellow light (LED) which provides useful information.

•

When you insert or replace the battery and turn the headset on, the yellow LED
will become solid yellow.This means that the headset is in pairing mode

•

When your battery is getting low,the yellow LED will flash twice every 5 seconds.
You should then replace the battery

•

If you use the Jabra BT110 with the Jabra A210, the yellow LED will indicate ‘On’
by flashing every 3 seconds

The Jabra BT110 is ready to wear on the right ear. If you prefer the left, gently rotate the
MiniGel 180°.

For optimal performance,wear the Jabra BT110 and your mobile phone on the same
side of your body or within line of sight. In general, you will get better performance
when there are no obstructions between the headset and the mobile phone.

If you can hear crackling noises;

For the best audio quality,always wear your headset on the same side of the body
as your mobile phone.

If you cannot hear anything in your headset;

1.

Increase the volume on the headset.

2. Ensure that the headset is paired with the phone.

3. Make sure that the phone is connecting to the headset – if it does not connect

either from the phone’s Bluetooth menu or by tapping the answer/end button,
carry out the pairing procedure.

Will the Jabra BT110 work with other Bluetooth equipment?

The Jabra BT110 is designed to work with Bluetooth mobile phones.It can also
work with other Bluetooth devices that are compliant with version 1.1 or 1.2 and
support headset and/or hands-free profile.

Will my Jabra BT110 interfere with my car’s electronics,radio,or computer?

The Jabra BT110 produces significantly less power than a typical mobile phone.It
also only emits signals that are in compliance with the international Bluetooth
standard.Therefore,you should not expect any interference with standard
consumer-grade electronics equipment.

I am experiencing pairing problems even though my phone is indicating otherwise

If you have deleted your headset pairing connection in your mobile phone,the only
way to successfully pair the Jabra BT110 with your mobile phone is to follow the
pairing instructions in section 1 ‘Getting started’.

English

English

Using your Jabra BT110 with the Jabra A210 Bluetooth adapter

3

LED status indicators

4

Troubleshooting and frequently asked questions

6

Choosing wearing preference

5

8 9

1. Web: www.jabra.com/fscs (for the latest support info and online User Manuals)

2. E-mail: Tech Support: [e-mail]
Information: [e-mail]

3. Phone: [phone] (toll-free in USA and Canada)
[phone]

4. Support Hours: Monday – Friday 8 am – 5 pm, Pacific Standard Time.

Jabra limited product warranty.Jabra warrants to Purchaser that for a period of one (1) year
after the date of purchase (the “Warranty Period”) of any Jabra Product (“Product”) by
Purchaser,the Product will substantially conform to Jabra’s published specifications for the
Product on the date of Purchaser’s purchase of the Product, subject to the terms herein.
Purchaser shall notify Jabra of any nonconformance during the Warranty Period and obtain a
written return material authorization (“RMA”) and an RMA number for the nonconforming
Product from Jabra and return the nonconforming Product to Jabra at:Jabra Corporation, 9171
Towne Centre Drive, Suite 500,San Diego, California 92122 USA,freight prepaid,with a
statement describing the nonconformity.Jabra’s exclusive obligation with respect to
nonconforming Product shall be,at Jabra’s option and expense,to repair or replace such
Product so that it substantially conforms with its published specifications on the date of
Purchaser’s purchase,or, if Jabra,in Jabra’s sole discretion,determines that it is not possible to
repair or replace the Product,Jabra may,at Jabra’s option, refund to Purchaser the purchase
price paid for the Product.THE FOREGOING IS PURCHASER’S SOLE AND EXCLUSIVE REMEDY
FOR BREACH OF WARRANTY BY JABRA WITH RESPECT TO THE PRODUCT.The warranty set forth
above shall not apply to any Product which has not been properly used or handled in
accordance with the instructions supplied by Jabra, lost or misplaced for any reason, or which

1. Always store the Jabra BT110 with power off and safely protected.

2. Avoid storage at high temperatures (above 45°C / 113°F) – such as direct sunlight.

(Storage at high temperatures can degrade performance and reduce battery life).
Low temperatures (down to -10°C / 14°F will shorten battery life and may affect
operation but should not permanently damage the Jabra BT110.

3. Do not expose the Jabra BT110 to rain or other liquids.

has been modified, repaired or altered,except by Jabra or at a Jabra authorized service facility,
or which has been subjected to faulty installation, misuse,abuse, or which the Product defect is
attributable to any failure or damage which is beyond the reasonable control of Jabra.This
warranty is available only to Purchaser, and does not extend to any distributors, retailers,or
other resellers of the Product. This warranty applies only to new Jabra products purchased
from authorized retail sellers. This warranty does not apply to: “open box purchases”, resales by
private parties or any other third party purchases by unauthorized distributors. Transfer of
Jabra products through any unauthorized distributor renders our manufacturer’s warranty null
and void. BUYER BEWARE: any Jabra product sold by a private party or unauthorized distributor
and not by an authorized Jabra retail seller is sold on an “as is”or “with all faults”basis with
respect to Jabra. As such,the entire risk as to the quality and performance of such products
will be with the buyer if the unauthorized distributor will not cover the costs of repairing
defects. Should such products prove defective following their purchase, the buyer or
unauthorized distributor,and not the manufacturer or its authorized retail sellers,assumes the
entire cost of all necessary servicing or repair. Therefore, buyers are strongly encouraged to
purchase Jabra products only from Jabra authorized retail sellers. THE FOREGOING
WARRANTIES ARE THE SOLE WARRANTIES,EXPRESS OR IMPLIED, GIVEN BY JABRA IN
CONNECTION WITH THE PRODUCT,AND JABRA DISCLAIMS ALL OTHER WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY,FITNESS FOR A PARTICULAR PURPOSE AND
NONINFRINGEMENT OF THIRD PARTY RIGHTS. JABRA SHALL NOT BE LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE PRODUCT,EVEN IF
JABRA HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.THE LIABILITY OF JABRA
HEREUNDER FOR ALL CLAIMS SHALL NOT EXCEED THE AMOUNT PAID BY PURCHASER TO
JABRA FOR THE PRODUCT GIVING RISE TO JABRA’S LIABILITY.

English

English

Need more help?

7

Storage of the Jabra BT110

8

Warranty

9

10

English

11

English

Certification and safety approvals

10

FCC

This device complies with part 15 of the FCC Rules.Operation is subject to the following
two conditions: (1) This device may not cause harmful interference,and (2) this device
must accept any interference received,including interference that may cause
undesired operation.

Users are not permitted to make changes or modify the device in any way. Changes or
modifications not expressly approved by Jabra (GN Netcom) will void the user’s
authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide
reasonable protection against harmful interference in a residential installation.This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However,there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

The user must place the base 8" (20cm) or more from any personnel in order to comply
with FCC RF exposure requirements.

Industry Canada

Operation is subject to the following two conditions:(1) This device may not cause
interference and (2) This device must accept any interference,including interference
that may cause undesired operation of the device.

The term "IC:" before the certification/registration number only signifies that
registration was performed based on a Declaration of Conformity indicating that
Industry Canada technical specifications were met. It does not imply that Industry
Canada approved the equipment.

CE

This product is CE marked according to the provisions of the R & TTE Directive (99/5/EC).
Hereby,GN Netcom,declares that this product is in compliance with the essential

requirements and other relevant provisions of Directive 1999/5/EC.
For further information please consult http://www.gnnetcom.com
Please note that this product uses radio frequency bands not harmonised within EU.

Within the EU this product is intended to be used in Austria, Belgium,Denmark, Finland,
France,Germany,Greece,Ireland.Italy,Luxembourg,The Netherlands, Portugal, Spain,
Sweden, United Kingdom and within EFTA in Iceland, Norway and Switzerland.

Bluetooth

The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use
of such marks by Jabra is under license.Other trademarks and trade names are those of
their respective owners.

1

Bluetooth is a radio technology developed to connect devices, such as mobile

phones and headsets, without wires or cords over a short distance of up to 10 metres
(approx 30 feet). More information is available at www.bluetooth.com

2

Bluetooth profiles are protocols through which Bluetooth devices communicate

with other devices.Your phone needs to support either the handsfree or headset
profile to function with the Jabra BT110.

3

Pairing creates a unique and encrypted communication link between two Bluetooth

enabled devices and allows them to communicate with each other.Bluetooth devices
will not work if the devices have not been paired with each other.

4

Passkey or PIN is a code that needs to be entered on the phone in order to pair the

mobile phone with the Jabra BT110. When you have already paired your mobile
phone with the headset, the phone and the Jabra BT110 will recognize each other
and the phone will bypass the discovery and authentication process and
automatically accept the transmission.

5

Standby mode is when the Jabra BT110 is used with the Jabra A210 and is passively

waiting for a call. When you “end”the call on your mobile phone, the headset will
go into standby mode.The yellow LED will indicate standby mode by flashing every
3 seconds.

Glossary

11
