Jabra Boost OTE15 User Manual

JABRA BOOST
User Manual
jabra.com/boost
© 2014 GN Netcom A/S. All rights reserved. Jabra® is a registered trademark of GN Netcom A/S. All other trademarks included herein are the property of their respective owners. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by GN Netcom A/S is under license. (Design and specifications subject to change without notice).
MADE IN CHINA MODEL: OTE15
Declaration of Conformity can be found on
www.jabra.com/CP/US/declarations-of-conformity
CONTENTS
1. WELCOME .......................................... 4
2. HEADSET OVERVIEW ......................... 5
3. HOW TO WEAR ................................. 6
3.1 CHANGE EARGELS
3.2 ATTACHING THE EARHOOK
4. HOW TO CHARGE THE BATTERY ....... 8
4.1 CHARGE USING PC
4.2 CHARGE USING CAR CHARGER
4.3 EXTEND BATTERY LIFE POWER NAP
5. HOW TO CONNECT ...........................11
6. HOW TO USE ....................................12
6.1 CALLS
6.2 MULTIPLE CALL HANDLING
7. SOF T WARE .......................................15
7.1 JABRA ASSIST
8. SUPPORT ..........................................16
8.1 FAQ
8.2 HOW TO CARE FOR YOUR HEADSET
9. TECHNICAL SPECIFICATIONS ...........17
ENGLISH
JABRA BOOST
3
1. WELCOME
Thank you for using the Jabra Boost. We hope you will enjoy it!
JABRA BOOST FEATURES
 Voice guidance  Battery and pairing status display  HD voice  Long talk time – Up to 9 hours  Power Nap feature  New comfort pack  Wireless freedom - Up to 30m/98ft
ENGLISH
JABRA BOOST
4
2. HEADSET OVERVIEW
Multi-function button
Battery indicator
Micro-USB Port
ENGLISH
On/O switch
Bluetooth indicator
Dual USB car charger
Small EarHook
NOTE: the dual USB car charger is available for select countries only.
USB charger
Large EarHook
EarGel Left looped
JABRA BOOST
Right looped EarGel
Volume up/down buttons
Microphone
EarGel
5
3. HOW TO WEAR
The headset can be worn on the left or right ear, with or without the EarHook. Additional EarGels and EarHooks are available in the pack.
jabra
L
R
jabra
ENGLISH
JABRA BOOST
6
3.1 CHANGE EARGELS
Choose between 3 ergo-designed EarGels for optimal fit and comfort (standard, left looped, or right looped).
3.2 ATTACHING THE EARHOOK
Select between two different EarHook sizes (small or large). The EarHook can be attached to the headset for a more secure fit, and can be worn with the Standard EarGel (suitable for left or right ear).
ENGLISH
JABRA BOOST
7
4. HOW TO CHARGE THE BATTERY
Fully charge the headset before first use, and enjoy up to 9 hours talk time. It takes approx. 2 hours to charge.
4.1 CHARGE USING PC
Simply connect the headset to the PC using the supplied USB cable.
ENGLISH
JABRA BOOST
8
4.2 CHARGE USING CAR CHARGER
1. Connect the headset to the dual USB car charger
using the supplied USB cable.
2. Plug the dual USB car charger into the car’s
power outlet.
AUX CD FM
POWER
AUX USB
OUTLET
jabra
It takes approx. 2 hours to fully charge the headset.
NOTE: the dual USB car charger can charge your headset and your mobile device simultaneously.
ENGLISH
JABRA BOOST
9
4.3 EXTEND BATTERY LIFE POWER NAP
To extend batter y life the headset will automatically enter Power Nap mode when the headset is out of range of your connected mobile device for more than 60 minutes. Power Nap provides 365 days of battery readiness.
To exit Power Nap (or answer an incoming call) simply tap the Multi-function button on the headset. Your mobile device must be within range, switched on and have Bluetooth enabled.
ENGLISH
JABRA BOOST
10
5. HOW TO CONNECT
1. Turn the headset on (set the On/Off switch to
the On position).
2. Press and hold (3 secs) the Multi-function
button until the Bluetooth indicator flashes blue, and the voice guided instructions are announced.
3. Wear the headset and follow the voice-guided
instructions to connect to your Bluetooth device.
ENGLISH
JABRA BOOST
11
6. HOW TO USE
Battery indicator
On/Off switch
Bluetooth indicator
Multi-function button
Volume up
Volume down
ENGLISH
JABRA BOOST
12
6.1 CALLS
CALLS
On/off Slide the On/off switch
Answer/end call
Reject call
Redial last number
Activate Siri/Google Now voice commands
Adjust speaker volume
Mute/un-mute microphone
Tap the Multi-function button
Double-tap the Multi-function button
Double-tap the Multi-function button
Press and hold (1 sec) the Multi-function button
Tap the Volume up or Volume down button
Tap both the Volume up and Volume down at the same time
ENGLISH
JABRA BOOST
13
6.2 MULTIPLE CALL HANDLING
The headset can accept and handle multiple calls simultaneously.
MULTIPLE CALLS
End current call and answer incoming call
Switch between held call and active call
Put current call on hold and answer incoming call
Reject incoming call
ENGLISH
Tap the Multi­function button
Press and hold (2 secs) the
Multi-function
button
Press and hold (2 secs) the
Multi-function
button
Double-tap the
Multi-function
button
JABRA BOOST
14
7. SOFTWARE
7.1 JABRA ASSIST
Jabra Assist is a Smartphone app that enables GPS tracking of the headset, pairing assistance, and headset battery status.
 Android download - Google Play  iOS download - App Store
ENGLISH
JABRA BOOST
15
8. SUPPORT
8.1 FAQ
View the comprehensive FAQ on Jabra.com/Boost.
8.2 HOW TO CARE FOR YOUR HEADSET
 Always store the headset with the power off
and safely protected
 Avoid storage at extreme temperatures (above
40°C/104°F or below 0°C/32°F). This can shorten battery life and may affect headset operation
 Do not expose the headset to rain or other
liquids
ENGLISH
JABRA BOOST
16
9. TECHNICAL SPECIFICATIONS
JABRA BOOST HEADSET SPECIFICATION
Weight: 8.5 g (0.30 oz)
L 49.3 mm x W 14.5 mm x
Dimensions:
Microphones: Omni-directional microphone
Speaker: 11 mm dynamic speaker
Operating range: 30m/98ft (phone dependent)
Bluetooth version: 4.0
Paired devices:
Supported Bluetooth profiles:
Talk time: Up to 9 hours
Power nap battery time: Up to 365 days
Operating temperature: -10°C to 55°C (14°F to 131°F)
Storage temperature: 0°C to 40°C (32°F to 104°F)
USB charging cable 5V, >100 mA
Pairing passkey or PIN: 0000
H 9.5 mm L 1.94 in x W 0.57 in x H 0.37 in
Up to 8, connected to two at the same time (MultiUse™)
A2DP(v1.2), Hands Free Profile (v1.6), Headset profile(v1.2)
JABRA BOOST
ENGLISH
17
ENGLISH
www.jabra.com/boost
JABRA BOOST
18
REV C
