Jabra PRO™ 9450
Jabra PRO™ 9450 Flex
Jabra PRO™ 9450 Duo
User Manual
www.jabra.com
WELCOME
Congratulations on purchasing your new Jabra PRO 9450. We are sure you will enjoy its wide range of features,
and nd it comfortable to wear and easy to use.
Jabra PRO 9450 base features
• Desk phone and softphone connectivity.
• Headset recharge docking cradle.
• Keypad for easy call handling.
• Visual and audio indicators.
Jabra PRO 9450 headset features
• Up to 150 meters range from headset to base.
• Wideband audio for exceptional sound quality.
• Touch panel volume and mute controls.
• Intuitive headset multi-function button for easy call handling.
• LED and audio indicators.
• Advanced hearing protection with SafeTone™.
• Noise-cancelling microphone.
• Earhook or headband wearing-style (neckband accessory available).
Jabra PRO 9450 Flex headset specic features
• Flexible microphone boom arm.
Jabra PRO 9450 Duo headset specic features
• Headband wearing style with left and right speakers, and exible microphone boom arm.
english
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
2
CONTENTS
1. PRODUCT OVERVIEW ........................................................................... 5
1.1 Package Contents ..................................................................................................................................5
1.2 Headset .........................................................................................................................................................6
1.3 Headset Attachments ..........................................................................................................................8
1.4 Base .............................................................................................................................................................. 10
1.5 Preparing the Base .............................................................................................................................. 11
1.6 Optional Accessories ......................................................................................................................... 11
2. CONNECTING TO A PHONE ............................................................. 12
2.1 Connect to Power ...............................................................................................................................12
2.2 Dock Headset .........................................................................................................................................12
2.3 Connect to Softphone (PC) ........................................................................................................... 13
2.4 Select and Connect to a Desk Phone ..................................................................................... 14
3. CONFIGURING THE JABRA PRO 9450 .......................................... 16
3.1 Conguring for Desk Phones ....................................................................................................... 16
3.2 Conguring for Softphones .......................................................................................................... 17
3.3 Limited Conguration using the Base .................................................................................... 17
4. JABRA DIRECT ....................................................................................... 19
4.1 Install Jabra Direct ............................................................................................................................... 19
4.2 PC Call Manager ................................................................................................................................... 19
english
5. HEADSET AND BASE FEATURES .................................................... 20
5.1 Headset Multi-function Button ...................................................................................................20
5.2 Headset Touch Panel ......................................................................................................................... 20
5.3 Headset LED Indicator ...................................................................................................................... 21
5.4 Headset Audio Indicators ............................................................................................................... 22
5.5 Base Keypad ............................................................................................................................................23
5.6 Base Keypad Visual Indicators ...................................................................................................... 23
5.7 Base Audio Indicators ....................................................................................................................... 23
6. BASIC CALL MANAGEMENT ............................................................ 24
6.1 Desk Phone: Making Calls, Answering Calls, and Ending Calls ...............................24
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
3
6.2 Softphone: Making Calls, Answering Calls, and Ending Calls .................................. 24
6.3 Call Waiting ..............................................................................................................................................24
6.4 Call Collision............................................................................................................................................25
7. ADVANCED CALL MANAGEMENT ................................................ 26
7.1 Merging Calls ......................................................................................................................................... 26
7.2 Conference Call with Multiple Headsets ...............................................................................26
7.3 Switching between Desk Phone and Headset ................................................................. 27
7.4 Last Number Redial (Softphone only) .................................................................................... 27
7.5 Call Disconnect Prevention (Unsupported Softphones) ............................................ 27
7.6 Recording Desk Phone Calls ......................................................................................................... 27
8. ADVANCED JABRA PRO FEATURES .............................................. 28
8.1 Safetone™ Hearing Protection.....................................................................................................28
8.2 Wireless Range ...................................................................................................................................... 28
8.3 Wideband Audio .................................................................................................................................. 28
8.4 Voice Announcements .................................................................................................................... 28
8.5 Sound Settings ......................................................................................................................................28
8.6 Listening to Music or audio on PC ............................................................................................ 29
8.7 Firmware Updates ...............................................................................................................................29
8.8 Theft Protection .................................................................................................................................... 29
9. FAQS AND TROUBLESHOOTING .................................................... 30
english
10. TECHNICAL SPECIFICATIONS ......................................................... 32
10.1 Jabra PRO Headset ............................................................................................................................. 32
10.2 Jabra PRO 9450 and Jabra PRO 9450 Flex headsets ...................................................... 32
10.3 Jabra PRO 9450 Duo headset ...................................................................................................... 32
10.4 Headset Battery .................................................................................................................................... 32
10.5 Jabra PRO Base ......................................................................................................................................33
10.6 Materials and Allergies ..................................................................................................................... 34
10.7 Product Disposal .................................................................................................................................. 34
10.8 Certications and Safety Approvals ......................................................................................... 34
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
4
1. PRODUCT OVERVIEW
1.1 PACKAGE CONTENTS
Jabra PRO™ 9450
Jabra PRO™ 9450 Flex
Jabra PRO™ 9450 Duo
english
Headband Attachment
Earhook Attachment
(small, medium and large earbuds)
Jabra PRO™ 9450 Base (same base for all headsets)
Base and Headset Cradle
Headband Attachment
Microphone Foam
Earhook Attachment
(small, medium and large earbuds)
Microphone Foam
Telephone CablePower Adapter USB Cable
Quick Start Guide
Warning & Declaration
Booklet
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
5
1.2 HEADSET
Jabra PRO™ 9450
Multi-function
Button
english
Touch Panel
LED Indicator
Microphone
Boom Arm
Jabra PRO™ 9450 Flex
Multi-function
Button
Touch Panel
LED Indicator
Flexible Microphone
Boom Arm
Microphone Foam
Speaker
Mount for
Wearing-style
Attachments
Recharge Contact
Noice-cancelling
Microphone
Speaker
Mount for
Wearing-style
Attachments
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
Recharge Contact
Noise-Cancelling
Microphone
6
Jabra PRO™ 9450 Duo
Multi-function Button
Touch Panel
LED Indicator
english
Speaker
Recharge Contact
Flexible Microphone
Boom Arm
Noise-cancelling
Microphone
Microphone Foam
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
7
1.3 HEADSET ATTACHMENTS
The Jabra PRO 9450 and Jabra PRO 9450 Flex headsets can be worn in the headband, earhook or neckband
wearing-styles. The headband and earhook attachments are included in the box. The neckband attachment can
be purchased separately.
Wearing-styles can be worn on the left or right ear. Regardless of wearing style, ensure the microphone is
positioned close to the mouth to maximise noise-cancelling.
Headband Neckband Earhook
Attaching the headband
1. Align the headset and the headband wearing-style attachment, as illustrated, and press rmly together until
they click into place (snap-to-click).
2. Rotate the microphone boom arm for left or right ear use.
3. Adjust the length of the headband to t snugly against the head.
CLICK
english
Attaching the earhook
1. Assemble the earhook wearing-style attachment for left or right ear use. If necessary, remove the earbud and
replace with another size for best t.
2. Align the headset and the earhook wearing-style attachment, as illustrated, and press rmly together until
they click into place (snap-to-click).
3. Shape the earhook to t snugly around the ear.
CLICK
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
8
Attaching the neckband (optional accessory)
1. Decide on left or right ear use, and assemble the neckband attachment, as illustrated.
2. Align the headset and the neckband wearing-style attachment, and press rmly together until they click into
place (snap-to-click).
CLICK
english
R
L
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
9
1.4 BASE
Headset Cradle
Keypad
Microphone Volume Control
Clear Dial Tone Switch
Front Panel
english
Speaker
Telephone Port
Handset Port
Power Adapter Port
AUX Port USB Port
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
Busy-light
Indicator Port
10
1.5 PREPARING THE BASE
1. Remove the protective foil from the cradle and the keypad.
2. (optional) Rotate the cradle for left- or right-handed docking, as illustrated.
1.6 OPTIONAL ACCESSORIES
The following Jabra PRO accessories are available separately.
english
Jabra GN1000 Jabra LINK
Neckband Attachment
Jabra PRO 9450 and
Jabra PRO 9450 Flex
Replacement Earhook, with Earbuds
Jabra PRO 9450 and
Jabra PRO 9450 Flex
(adapter may vary from illustration)
Replacement Headband Attachment
Jabra PRO 9450 and
Jabra PRO 9450 Flex
Replacement Ear Cushions
Jabra PRO 9450 and
Jabra PRO 9450 Flex
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
11
2. CONNECTING TO A PHONE
The easiest way to connect and congure the Jabra PRO 9450 is to download and use the Interactive Setup
Wizard from jabra.com/setup. Chapters 2 and 3 of this manual are only needed if the Interactive Setup Wizard is
not used.
2.1 CONNECT TO POWER
Connect the power adapter to the base
1. Plug the supplied power adapter into the port marked
2. Connect the power adapter to the mains power socket.
on the base.
2.2 DOCK HEADSET
Dock the headset, as illustrated. When the headset is docked correctly the headset battery will begin charging, if
needed. Keep the headset docked while connecting the Jabra PRO 9450, or when not in use.
english
Note: Headset pictured may vary from actual product.
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
12
2.3 CONNECT TO SOFTPHONE PC
Connect a PC to the base
1. Plug the supplied USB cable into the port marked
2. Connect the USB cable to any free USB port on the PC.
on the base.
english
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
13
2.4 SELECT AND CONNECT TO A DESK PHONE
Select which desk phone you are connecting to from the following four options:
OPTION 1
Desk Phone with Headset
Port
This type of desk phone has a
dedicated headset port (usually
at the back of the phone). These
phones typically have a button
on the front panel for switching
between handset and headset.
1. Plug the supplied telephone
cable into the port marked
on the base.
2. Connect the telephone
cable to the headset port
on the desk phone.
OPTION 2
Desk Phone with Jabra LINK
A Jabra LINK adapter enables an
incoming call to be answered
or ended by the headset multifunction button.
Contact your local Jabra dealer
to purchase a Jabra LINK
adapter for your specic desk
phone.
1. Connect the Jabra LINK
adapter as shown in adapter
documentation supplied
with the Jabra LINK. On
some phones the telephone
cable will also need to be
connected.
2. Call your connected desk
phone using another phone
to enable the Jabra LINK
adapter. Wait 10 seconds
before answering the
phone.
Refer to Jabra LINK
documentation
or
or
or
or
OPTION 3
Desk Phone with Jabra
GN1000 remote Handset
Lifter
The Jabra GN1000 remote
handset lifter manually lifts
the desk phone handset to
make or answer a call. For
mounting instructions refer
to documentation supplied
with the Jabra GN1000.
1. On the desk phone,
unplug the handset cable
from the phone body.
2. Connect the handset cable
to the port marked
the base.
3. Plug the supplied telephone cable into the port
marked
4. Connect the telephone
cable into the handset
port on the desk phone.
5. Connect the Jabra GN1000
cable into the port marked
on the base.
on the base.
on
OPTION 4
Desk Phone without
Headset Port
This desk phone does not
have a dedicated headset
port.
1. On the desk phone,
unplug the handset cable
from the phone body.
2. Connect the handset cable
to the port marked
the base.
3. Plug the supplied telephone cable into the port
marked
4. Connect the telephone
cable into the handset
port on the desk phone.
on the base.
on
14
Jabra PrO 9450
Jabra PrO 9450
15
3. CONFIGURING THE JABRA PRO 9450
3.1 CONFIGURING FOR DESK PHONES
Before rst-time use of the Jabra PRO 9450 with a desk phone, a clear dial tone and microphone volume must be
determined for optimal sound quality. Both features are manually adjusted on the base.
Set a clear dial tone
1. Remove the front panel of the Jabra PRO 9450 base, as illustrated.
2. Put on the headset. The desk phone icon will change to
button on the base keypad.
3. Lift the desk phone handset and set aside, or press the headset button on the desk phone.
4. Rotate the clear dial tone switch from A to G, as illustrated, and listen in the headset for a clear dial tone.
5. Determine the best switch position. The dial tone should be strong, clear and undistorted.
6. Return the desk phone handset to the receiver, or press the headset button on the desk phone.
7. When nished, return the front panel to the base.
Changes made to the clear dial tone only apply to desk phones.
Set the microphone volume
1. Ensure the headset is docked, and then press and hold the desk phone button on the base keypad until the
desk phone icon changes to
2. Remove the front panel of the Jabra PRO 9450 base, as illustrated.
3. Put on the headset. The desk phone icon will change to
button on the base keypad.
.
. If the icon does not change, tap the desk phone
. If the icon does not change, tap the desk phone
english
4. Get a dial tone by pressing the headset button on the desk phone, or by lifting the desk phone handset.
5. Make a test call. Dial a friend or colleagues phone number using the desk phone.
6. If your speaking volume is too quiet or too loud, adjust the microphone volume on the base, as illustrated.
Ensure the listener does not adjust their own volume.
7. When nished, end the call and return the front panel of the Jabra PRO 9450.
Changes made to the microphone volume switch only apply to desk phones.
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
16
3.2 CONFIGURING FOR SOFTPHONES
1. Download and Install Jabra PC Direct from jabra.com/direct.
2. Open softphone software (e.g. Microsoft Lync) and set the Jabra PRO 9450 as speaker and microphone in the
audio conguration. Refer to specic softphone documentation for assistance in setting audio congurations.
For the latest list of supported softphones, please visit the Jabra website at www.jabra.com/setup.
3.3 LIMITED CONFIGURATION USING THE BASE
It is highly recommended to use the Jabra Control Center for all conguration changes. However, there are six
settings that can be congured using the base.
• Remote call control mode.
• IntelliTone level.
• Maximum DECT wireless range.
• Desk phone audio.
• Softphone audio.
• Softphone type.
Change settings using the base
1. Ensure there are no active calls.
2. Remove the front panel of the Jabra PRO 9450 base.
3. Center-press the microphone volume switch on the base to enter setup mode. The mute indicator will blink
slowly to indicate setup mode.
4. Tap the desk phone button on the keypad to cycle through the settings. The rst setting is Remote call control
mode. The current setting is indicated by the desk phone icon.
5. Tap the softphone button on the keypad to cycle through the values for each setting. The current value is
indicated by the softphone icon.
6. When nished, center-press the microphone volume switch to save settings and exit setup mode. The base
will restart.
english
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
17
Icon Setting Icon Value
Auto Detect (default)
GN1000/RHL/None
Remote call control mode
IntelliTone level
Maximum DECT wireless range
Desk phone audio
Jabra IQ EHS
Cisco
DHSG
MSH
Siemens optiPoint
Level 0 (default)
Level 1
Level 2
Level 3
Level 4
Normal (default)
Low
Very low
Ultra low
Narrowband (default)
Wideband
english
Softphone audio
Softphone type
Narrowband
Wideband (default)
Microsoft (default)
Cisco, Avaya, Siemens, IBM, Aastra, Skype
Other
None (PC Audio)
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
18
4. JABRA DIRECT
Jabra Direct is software designed to support the Jabra PRO 9450. For optimal functionality and management of
the Jabra PRO 9450, it is highly recommended to install Jabra Direct.
Jabra Direct includes drivers for various softphones. For a list of supported softphones, visit
www.jabra.com/direct.
4.1 INSTALL JABRA DIRECT
Download and install Jabra Direct from www.jabra.com/direct.
4.2 PC CALL MANAGER
PC Call Manager is PC software that replicates some of the touchscreen call handling functionality on the PC,
allowing the user to make calls, answer calls, merge calls etc using their PC. PC Call Manager is installed as part of
Jabra Direct.
Status bar
Activity window
Call control bar
english
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
19
5. HEADSET AND BASE FEATURES
5.1 HEADSET MULTIFUNCTION BUTTON
The multi-function button is located on the top of the headset, and manages calls on the target phone. You can
answer calls, end calls, switch between held calls, and more, using a combination of taps, double-taps or presses.
Multi-function button
Note: Headset pictured may vary from actual product.
List of headset multi-function button functions
Function Tap Double-tap
Answer incoming call
End current call
Put current call on hold, and accept incoming call
Open phone line on target phone
Reject incoming call
Call last number dialed
(mobile phones and supported softphones only)
Switch between target phone
Power headset on
Power headset o
Press
(hold 1-2 seconds)
(5 secs)
english
5.2 HEADSET TOUCH PANEL
The touch panel is a touch-sensitive panel located on the microphone arm of the headset. The touch panel controls the headset speaker volume and microphone mute/un-mute. Changes made to the speaker volume apply
independently to desk phone or softphone.
Touch -panel
Note: Headset pictured may vary from actual product.
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
20
Increase speaker volume Decrease speaker volume Mute/un-mute microphone
Slide nger up the touch panel
(away from mouth)
Slide nger down the touch panel
(toward the mouth)
Double-tap
5.3 HEADSET LED INDICATOR
The multi-colored LED indicator is located on the arm of the headset, and indicates headset status.
Led indicator
Note: Headset pictured may vary from actual product.
Headset state
Idle
Not connected
Out of range
Call active
Ringing
Power on
LED when battery is full
(click to play)
LED when battery is low
(click to play)
english
Power o
Pairing
Pairing succeeded
Charging
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
21
5.4 HEADSET AUDIO INDICATORS
The headset plays a variety of audio tones to indicate events.
Audio tone
Power on
Power o
Button tap
Button double-tap
Button press
Maximum speaker
volume reached
Minimum speaker
volume reached
Microphone muted Battery low
Incoming call on desk phone Conference start
Audio sample
(click to listen)
Audio tone
Target phone changed to
desk phone (voice)
Target phone changed to
desk phone (tone)
Target phone changed to
softphone (voice)
Target phone changed to
softphone (tone)
Target phone changed to
mobile phone (voice)
Target phone changed to
mobile phone (tone)
Call ended
Audio sample
(click to listen)
english
Incoming call on softphone
(PC)
Incoming call on mobile phone Out of range
Incoming call on dierent
phone while on call (call
collision)
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
Conference end
Incoming call accepted
22
5.5 BASE KEYPAD
The Jabra PRO base keypad displays information about the headset and call status, and has controls for call
handling. From here, you can change target phone, answer an incoming call, end the current call, congure base
settings, or open an audio link to the current target phone.
1 Battery icon: indicates the current battery level.
3
2
1
4
5
6
2 Headset docking icon: indicates the headset is docked.
3 Audio link icon: indicates audio link between base and headset is
active.
4 Mute icon: indicates the headset microphone is muted.
5 Mute button: mutes/un-mutes the headset microphone.
6 Group call icon: indicates desk phone and softphone calls are
merged.
7 Phone state icon: indicates desk phone or softphone call states.
8 Phone buttons: used for desk phone and/or softphone call
handling.
7
8
5.6 BASE KEYPAD VISUAL INDICATORS
Icon Event Icon Event
Battery charging
Current target phone
english
Full battery
Low battery
Very low battery
Headset docked
Unknown headset docked Group call
Headset and base pairing
Muted Searching for headset
Phone ringing
Phone on call
Phone on hold
Phone unplugged
Audio link between headset
and base is active
5.7 BASE AUDIO INDICATORS
The base speaker is located on the bottom of the base, and plays two distinct sounds.
Incoming call ringtone
Adjust the incoming call ringtone volume using the Jabra Control Center.
1. Launch Jabra Control Center, and select either ´Desk phone´ or ´Softphone´ tab.
2. Adjust the ´Base speaker ring tone level´ slider to the desired setting, and click ´Apply´.
Keypad button clicks
Tapping, double-tapping or pressing the keypad buttons will play a click sound. Adjust keypad button volume
via the Jabra Control Center. The default setting is ´o´.
1. Launch Jabra Control Center, and select either ´Desk phone´ or ´Softphone´ tab.
2. Select one of four preset keypad click settings (off, low, medium, or high), and click ´Apply´.
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
23
6. BASIC CALL MANAGEMENT
6.1 DESK PHONE: MAKING CALLS, ANSWERING CALLS, AND ENDING CALLS
Phone with Jabra Link, or GN1000
remote handset lifter
If necessary, set the desk phone as the target phone, by pressing and holding the desk phone
button on the base until the desk phone icon changes to white.
Make call
Answer call
End call
1. Lift headset from docking cradle, or
tap the multi-function button, or
tap the desk phone button on the base.
2. Dial number using desk phone.
Lift headset from docking cradle, or
tap the multi-function button, or
tap the desk phone button on the base.
Dock the headset, or
tap the multi-function button, or
tap the desk phone on the base.
6.2 SOFTPHONE: MAKING CALLS, ANSWERING CALLS, AND ENDING CALLS
Supported softphone
Make call
Answer call
End call
Dial number using supported softphone software. The base will automatically
switch to softphone.
Lift headset from docking cradle, or tap the multi-function button, or tap the softphone button on the base.
Dock headset, or tap the multi-function button, or tap the softphone button on the
base.
Phone without Jabra Link, or GN1000 remote
handset lifter
1. Lift headset from docking cradle, or
tap the multi-function button, or
tap the desk phone button on the base.
2. Lift desk phone handset and set aside.
3. Dial number using desk phone.
1. Lift headset from docking cradle, or
tap the multi-function button, or
tap the desk phone button on the base.
2. Lift desk phone handset and set aside.
1. Dock the headset, or
tap the multi-function button, or
tap the desk phone on the base.
2. Return desk phone handset to receiver.
english
6.3 CALL WAITING
Call waiting allows a current softphone call to be placed on hold, and an incoming softphone call to be answered
(supported softphones only). Check specic softphone documentation for call waiting compatibility.
Call waiting can be managed on the headset or the base.
HEADSET
Multi-function button
Accept incoming call, and put current call on hold Press (1-2 secs) Press (1-2 secs)
Accept incoming call, and end current call Tap Tap
Reject incoming call, and remain on current call Double-tap Double-tap
Switch between current call, and call on hold Press (1-2 secs) Press (1-2 secs)
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
BASE
Softphone keypad button
24
6.4 CALL COLLISION
Call collision occurs when there is a current call on one phone, and an incoming call on another phone. (Example:
you have a current call on a softphone, and an incoming call on a desk phone connected to the same base).
Call collision can be managed on the headset or the base.
HEADSET
Multi-function button
Accept incoming call, and put current call on hold Press (1-2 secs)
Accept incoming call, and end current call Tap
Reject incoming call, and remain on current call Double-tap
To switch between calls on hold, press the multi-function button, or tap the held call phone button on the base
keypad.
BASE
Keypad phone buttons
Tap incoming call´s phone
button
Tap current call´s phone
button, then tap incoming
call´s phone button
Double-tap incoming call´s
phone button
english
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
25
7. ADVANCED CALL MANAGEMENT
7.1 MERGING CALLS
Calls on a desk phone and softphone can be merged to create a group call. There are two methods for creating
a group call: merging an outgoing call with a current call, or merging an incoming call with a current call. Both
methods of merging calls are detailed below:
Merge an outgoing call with a current call
Desk phone Sof tphone
1. While on a desk phone call, dial a new number
using the softphone. The desk phone call will be
placed on hold.
2. Simultaneously press and hold the desk phone
and softphone buttons on the base for 1-3 seconds to merge the calls. When calls are merged,
the group call indicator will change to green.
Merge an incoming call with a current call
Desk phone Sof tphone
1. While on a desk phone call, tap the softphone
button to accept the incoming call. The desk
phone call will be placed on hold.
2. Simultaneously press and hold the desk phone
and softphone buttons on the base for 1-3 seconds to merge the calls. When calls are merged,
the group call indicator will change to green.
Unmerge/re-merge calls
To unmerge or re-merge calls, simultaneously press and hold the desk phone and softphone buttons on the base
keypad for 1-3 seconds.
End merged calls
To end a selected call in the group call, tap the relevant desk phone or softphone button on the base keypad. The
group call will be ended for that participant.
To end the group call for all participants, dock the headset or tap the multi-function button.
1. While on softphone call, tap the desk phone button
on the base. The softphone call will be placed on hold.
2. Dial a new number using the desk phone.
3. Simultaneously press and hold the desk phone and
softphone buttons on the base for 1-3 seconds to
merge the calls. When calls are merged, the group
call indicator will change to green.
1. While on softphone call, tap the desk phone button
to accept the incoming call. The softphone call will b e
placed on hold.
2. Simultaneously press and hold the desk
phone and softphone buttons on the base for 1-3
seconds to merge the calls. When calls are merged,
the group call indicator will change to green.
english
7.2 CONFERENCE CALL WITH MULTIPLE HEADSETS
The Jabra PRO 9450 enables up to three additional Jabra PRO headsets to be connected to the base for
conferencing. When two or more additional headsets are connected to the base, the audio is ltered from
wideband to narrowband.
Connect additional headset(s)
1. While the primary headset is undocked and on a call, dock a secondary headset with the base hosting the call.
Pairing will take a few seconds, during which the docking indicator will blink yellow. When the headsets are
successfully paired, a double-tone will sound in the primary headset.
2. Tap the multi-function button on the primary headset to accept the secondary headset. The audio is now
shared between headsets.
3. Repeat the procedure to connect additional headsets, as required.
Ending or leaving the conference
The primary headset user can end the conference by hanging up the call. The call is ended for all headsets.
Guests can leave the conference by tapping the multi-function button on their headset, or by docking the head-
set with the base. The conference call is still active for all other headsets.
All-day conference mode
When all-day conference mode is enabled, the conference call will not end when the call is ended. To end the
conference the primary headset must be docked.
1. Launch Jabra Control Center, and select the ´Headset´ tab.
2. Deselect ‘End headset conference when call ends’.
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
26
7.3 SWITCHING BETWEEN DESK PHONE AND HEADSET
Whilst on a phone call, it is possible to switch between a phone and a headset without interrupting the call.
Desk Phones
Switch from desk phone to headset
1. If necessary, press the desk phone button on the base, to set desk phone as target phone.
2. Lift headset from docking cradle.
3. Do not return desk phone handset to receiver, as this will hang up the call.
Switch from handset to desk phone (without electronic hookswitch or handset lifter)
1. Lift desk phone handset.
2. Dock headset, or tap the multi-function button, or tap the desk phone button on the base.
Switch from handset to desk phone (with electronic hookswitch or handset lifter)
1. Lift desk phone handset.
2. Refer to specic desk phone documentation. In some cases a button must be pressed on the desk phone,
while in others it will be automatic.
PC
For softphones, the headset is likely to be the only option; however you can change to other audio devices
connected to the PC, via audio preferences in Windows and/or the softphone software.
7.4 LAST NUMBER REDIAL SOFTPHONE ONLY
The Jabra PRO 9450 can redial the last number dialed (supported softphones only). Check specic softphone
documentation for last number redial compatibility.
Last number redial
1. If necessary, press the softphone button on the base to set softphone as target phone.
2. Double-tap the headset multi-function button to redial the last number called.
7.5 CALL DISCONNECT PREVENTION UNSUPPORTED SOFTPHONES
When on a call or in a web conference using an unsupported softphone, any incoming calls on a desk phone or
mobile phone will automatically disconnect the softphone call or web conference. To prevent disconnection,
double-tap the softphone button on the base keypad before making the softphone call or starting the web
conference.
For the latest list of supported softphones, please visit the Jabra website at www.jabra.com/direct.
english
7.6 RECORDING DESK PHONE CALLS
Desk phone calls can be recorded on a PC using third-party software, such as Windows Sound Recorder. To record
a desk phone call, call recording must be enabled in Jabra Control Center.
Enable call recording
1. Launch Jabra Control Center, and select the ´Audio´ tab.
2. Tick ´Forward desk phone call to PC for recording´, and click ´Apply´.
Desk phone calls can now be recorded using any third-party software on a PC.
NOTE: Recording conversations in secrecy may be illegal. Never record conversations without rst obtaining
permission.
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
27
8. ADVANCED JABRA PRO FEATURES
8.1 SAFETONE™ HEARING PROTECTION
SafeTone™ provides eective hearing protection against potential risks, such as acoustic shock and noise
exposure. SafeTone™ consists of two components, PeakStop™ and IntelliTone™.
PeakStop™ acoustic shock protection
PeakStop™ automatically suppresses sounds over 118dB(A), protecting hearing from acoustic shock.
PeakStop™ is only available from Jabra.
IntelliTone™ noise-exposure protection
IntelliTone™ oers four levels of protection against acoustic shock and noise-exposure. IntelliTone™ settings
can be changed via the Jabra Control Center, under the ´Audio´ tab. IntelliTone™ is only available from Jabra.
Protection level Criteria
Level 0 (default) Basic protection (over 118dB(A))
Level 1* Less than 4 hours on phone/day
Level 2* 4-8 hours on phone/day
Level 3* More than 8 hours on phone/day
Level 4 (TT4) Recommended Australian protection level (Telstra)
*Compliant with Directive 2003/10/EC of the European Parliament and Council of 6 February 2003.
8.2 WIRELESS RANGE
The Jabra PRO 9450 supports a maximum wireless range of up to 150 meters. Physical obstructions and
electromagnetic interference may shorten this range.
Headset sound quality may slowly deteriorate the further the headset is away from the base, and may improve
the closer the headset is to the base. When the headset is completely out of range, a unique tone (three quick
descending notes) will be played in the headset every few seconds.
If the headset is on a call when moved out of range, the audio will be lost; however the call will remain active at
the base for 120 seconds. To restore audio to the call, move the headset back in range of the base.
If the headset remains out of range of the base for more than an hour, the headset will power down to conserve
battery.
english
8.3 WIDEBAND AUDIO
The Jabra PRO 9450 supports both wideband and narrowband audio. Wideband audio oers better sound
quality at a reduced battery time.
Narrowband is default-enabled for desk phones. Wideband is default-enabled for softphones.
Change wideband audio settings
1. Launch Jabra Control Center, and select the ´Audio´ tab.
2. Tick the relevant checkbox under ´Enable wideband audio for´, and then click Apply.
8.4 VOICE ANNOUNCEMENTS
Choose to hear an English voice or a musical tone to indicate switching between a desk phone and softphone.
Select voice/tone setting
1. Launch Jabra Control Center, and select the ´Headset´ tab.
2. Tick the relevant setting under ´Target change indication´, and then click Apply.
8.5 SOUND SETTINGS
Choose between three equalizer presets available for all sounds: Treble, Normal (default) and Bass.
Select tone settings
1. Launch Jabra Control Center, and select the ´Audio´ tab.
2. Tick the relevant setting under ´Tone setting´, and then click Apply.
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
28
8.6 LISTENING TO MUSIC OR AUDIO ON PC
To listen to music or audio played on a PC, an audio link between the Jabra PRO base and the PC must be
opened. When an audio link is opened and no calls are active, any music or audio played on the PC (including
music from a media player) will play in the headset.
Open/close an audio link between base and PC
1. Launch Jabra Control Center.
2. Click the ´open/close audio link´ button in the top toolbar.
Alternatively, right-click the Jabra icon in Windows taskbar, and select ´Open Audio Link´ or ´Close Audio Link´.
8.7 FIRMWARE UPDATES
Firmware updates improve performance or add new functionality to your Jabra PRO 9450.
Update rmware
You can manually check for the latest rmware for all devices using Jabra Direct, or receive automatic
notications in Jabra DIrect when new rmware is available.
Note: If Jabra Direct has been mass deployed using Jabra Express, the rmware updater will not be included with
Jabra Direct.
8.8 THEFT PROTECTION
The base includes a Kensington Security Slot for attaching a security cable. To secure the base to your desk,
purchase any safety cable usable with the Kensington Security Slot and follow the instructions included with the
cable.
english
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
29
9. FAQS AND TROUBLESHOOTING
Q The desk phone/softphone state icon is grayed out on the base keypad. What does this mean?
A The phone is not the current target, or the phone is unplugged.
Q How do I pair my headset with the Jabra PRO 9450 base?
A Dock the headset with the base to initiate pairing. Pairing will occur automatically, unless the base can
establish a link with a primary headset.
Q Is it possible to dock my headset on another base from the Jabra PRO 9400 series?
A Yes. The headset can be docked with any Jabra PRO 9400 series base.
Q Can I pair my headset directly with a third-party DECT phone?
A No. The headset can only be paired with a Jabra PRO 9400 series base.
Q Why doesn’t my computer detect the Jabra PRO 9450 base?
A Try connecting the base to another USB port on the PC. It is recommended to have a direct connection
between the base and USB port (without a USB hub).
Q Why doesn’t my headset work with my desk phone/softphone?
A Check the following:
• Ensure the headset battery is charged. The keypad battery icon will be green when charging,
or yellow when charged.
• Ensure the headset is in range of the base. Up to 150 meters, depending on environment.
• Ensure the headset and base are paired. Dock the headset to initiate pairing.
Q Why does nothing happen when I try to use my desk phone?
A Check the following:
• Ensure the base is powered on.
• Ensure desk phone is the current target. The keypad desk phone icon will be white.
• Ensure there is an audio connection between desk phone and base.
Tap the keypad desk phone button to establish an audio connection.
• Ensure there is a dial tone. Lift the desk phone handset, or press the headset button on the desk phone,
to get a dial tone.
• Re-run the desk phone section of the Interactive Setup Wizard.
Q Why do I hear a low noise in the headset when there is silence at the other end?
A The headset speaker volume might be too high. To decrease the volume, slide your nger down the headset
touch panel.
Q How come the person on the other end cannot hear me when I am talking using my desk phone?
A The clear dial tone or microphone volume settings might be incorrectly set. Re-run the desk phone section of
the Interactive Setup Wizard, or read Section 3 of this manual.
Q Why am I getting a buzzing sound in my headset?
A Assuming the device has been set up correctly, the phone may not be fully immune to the radio signals
the headset uses. To overcome this problem, move the headset base at least 30 cm away from the phone.
Alternatively, reduce the wireless range of your unit.
Q Why can’t I hear sound or listen to music from my PC in my headset?
A Check the following
• Ensure the Jabra PRO 9450 is set as the current audio device in the Windows sound control panel,
and in your softphone software.
• Ensure the audio link to your PC is active. Right-click the Jabra Device icon in the Windows taskbar,
and select Open Audio Link.
english
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
30
Q When I try to make a call on my desk phone, the Jabra GN1000 RHL lifts, but the call is not connected.
A Ensure the base is connected to the desk phone handset port, and not the desk phone headset port.
The Jabra GN1000 cannot be used in conjunction with a headset port.
Q Is it possible to automate calling and answering on my desk phone without using a handset lifter?
A Yes, if the desk phone has an electronic hook switch feature. Check your supplier for compatibility with your
phone, and/or consult the support area at www.jabra.com.
Q Is it possible to set up an automatic dial tone for my softphone when I undock my headset?
A Yes, the Jabra PRO 9450 can be congured to automatically get a dial tone on the target desk phone or
softphone when the headset is undocked. Automatic dial tones are congured independently for desk
phones and softphones. Desk phones are default-enabled, and softphones are default-disabled.
1. Launch Jabra Control Center, and select the ´Desk phone´ tab.
2. Select/deselect the ´Open link when headset is undocked´ setting, and then click Apply.
Q Why does my desk phone’s electronic hookswitch not work with my headset?
A Please check your specic desk phone documentation for compatibility and conguration settings.
Alternatively visit www.jabra.com/PRO9400
Q Is it possible to listen in on calls with the Jabra PRO 9450?
A The risk of unauthorized access is limited. The Jabra PRO 9450 uses 64-bit encryption.
Q What is the range on the Jabra PRO 9450?
A Jabra PRO 9450 supports a maximum range of up to 150m (base to headset). Range varies according to the
environment in which the headset is used.
Q Can I make a conference call using multiple headsets?
A Yes, the Jabra PRO base is able to pair with four headsets in total: one primary and three secondary headsets.
Q Can I turn the headset o to save power when I’m away from the base?
A Yes. Press and hold the headset multi-function button for ve seconds to power the headset o. To power the
headset up again, dock the headset with the base, or press the multi-function button.
Q What is the talk time for a Jabra PRO 9450 headset?
A Approximately 8 hours for wideband talk, and approximately 10 hours for narrowband talk.
Q My headband/earhook/neckband is broken. How do I purchase another one?
A Contact your local Jabra supplier. The necessary part number can be found in the optional accessories section
of this manual.
Q Do Jabra products contain or use PCB? (polychlorinated biphenyl)
A No. Jabra products do not contain or use PCB.
Q Why do I sometimes lose audio in my headset?
A Audio is sometimes lost when touching the charging pins on the base. If this occurs:
1. Ensure your softphone call is not on hold (e.g. Skype call), or your music is not paused.
2. Restart your softphone, or PC music player.
english
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
31
10. TECHNICAL SPECIFICATIONS
10.1 JABRA PRO HEADSET
Operating Environment:
-10˚C to +55˚C (0˚C to +40˚C when charging); Up to 95% RH non condensing
Call Control:
Multi-function button support for answer call, end call, reject call, redial, swap held calls; docking operations can
also answer and end calls
Volume Control and Microphone Mute:
Controlled via touch panel on headset
Visual Indicator:
Multi-colored LED indicates call status, battery level, pairing status and other events
Audio Indicators:
Tones indicate incoming calls, low battery, volume level, microphone muting and other events; target phone can
be indicated by English voice tag or target-specic melody
Sound Quality:
DSP noise reduction; echo cancellation; tone control; narrowband and wideband audio (selectable per phone type)
Firmware Update:
Updateable via USB interface when docked in the Jabra PRO base
Recharge:
While docked in the Jabra PRO base
PC-based Conguration:
All settings can be stored and loaded from a PC for backup and mass deployment
Wireless Standard:
(CAT - iq) European DECT and U.S. DECT
DECT Range:
For European DECT; up to 150 meters from Jabra PRO base to headset
For U.S. DECT; up to 135 meters from Jabra PRO base to headset
DECT Frequencies:
US DECT: 1.92 - 1.93 GHz
EU DECT: 1.88 - 1.90 GHz
english
10.2 JABRA PRO 9450 AND JABRA PRO 9450 FLEX HEADSETS
Wearing-styles:
Earhook or headband (neckband is available as an accessory)
Speaker(s):
Wideband speaker
Microphone:
Noise-cancelling microphone
10.3 JABRA PRO 9450 DUO HEADSET
Wearing-styles:
Headband
Speaker(s):
2 (Dual Mono)
Microphone:
Noise-cancelling microphone
10.4 HEADSET BATTERY
Battery Type:
Lithium Ion
Battery Capacity:
315 mA/h, typical
Battery Talk Time:
Up to 10 hours - Narrowband audio
Up to 7 hours - Wideband audio
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
32
Battery Lifetime:
Minimum 500 charge cycles (over 3 years when used for 8 hours a day)
Battery Standby Time:
Up to 38 hours
Operating Temperature Range:
-10˚C to +60˚C
Note: The headset features a temperature-dependant charging algorithm that prevents the battery from being
charged during extreme temperatures (about 0˚ to 45˚C)
Battery Charge Time:
2 hours.
Shelf Life:
Holds a charge for at least 6 months in the o state before recharge is required
Replacement:
Battery lifetime is approximately 3 years with regular use. Contact your Jabra dealer for details on how to order
battery replacement kit.
10.5 JABRA PRO BASE
The Jabra PRO 9450 base meets the following specications
Dimensions:
160mm x 94mm x 82mm
Wireless Standard:
(CAT - iq) European DECT and U.S. DECT
DECT Range:
For European DECT; up to 150 meters from Jabra PRO base to headset
For US DECT 6.0; up to 135 meters from Jabra PRO base to headset
Operating Environment:
-10˚C to +55˚C (0˚C to +40˚C when charging); Up to 95% RH non condensing
Keypad Functions:
Call handling, partial system conguration
Recharge Cradle:
Fits supplied Jabra PRO headset; features magnetic coupling; easily replaced to accommodate future headset
upgrades
Audio:
Built-in speaker provides ring tones and/or audio feedback for keypad operation
Audio Bandwidth:
Narrowband or wideband
Desk Phone Connections:
RJ-9 for handset, RJ-9 for phone body (or headset port), RJ-45 for AUX (for electronic hookswitch or GN1000
handset lifter)
Clear Dial Tone Switch and Microphone Volume Switch:
Electromechnical switches. Clear dial tone switch set manually using Interactive Setup Wizard. Microphone
volume level determined and set automatically by Interactive Setup Wizard
Electronic-hookswitch Standards:
GN1000, Jabra IQ EHS, Cisco, DHSG and MSH. Each requires additional cabling and/or equipment available separately; more may become available in future and added via rmware upgrade. GN1000 is supported by default
and requires no additional conguration
Busy Light Indicator:
2.5mm jack connector (available as an accessory)
PC Connector:
Micro USB
Firmware Update:
Downloadable from PC
PC-based Conguration:
All settings can be stored and loaded from a PC for backup and mass deployment
Softphone Support:
Full call handling for Skype, Microsoft Oce Communicator, Avaya and Cisco IP Communicator; for other
softphones see headset as a standard sound card; support for additional softphones may be added via driver
updates for the PC. For the latest updates, see jabra.com/direct
english
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
33
Theft Protection:
Kensington Security Slot standard
10.6 MATERIALS AND ALLERGIES
The headband attachment is made of stainless steel and does not have a nickel-coated surface. Nickel release
from the headband is 0.02 g/cm2/week, which is below the 0.50 g/cm2/week limit established by EU Directive
94/27/EF. The stainless steel alloy was tested for nickel release in accordance with the European standard EN
1811:1998.
Other wearing-style attachments are made of plastic and contain no known allergens. The ear cushions do not
contain vinyl. The products contain no nickel, chrome or natural rubber that can come into contact with users’
skin.
10.7 PRODUCT DISPOSAL
Please dispose of the headset according to local regulations and recycle when possible. Do not dispose as
household waste. Do not dispose of the headset in a re as the battery may explode. Batteries may also explode
if damaged.
10.8 CERTIFICATIONS AND SAFETY APPROVALS
CE
This product is CE marked according to the provisions of the R & TTE Directive (99/5/EC). Hereby, GN declares that
this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/
EC. For further information, please consult http://www.jabra.com.
Within the EU, this device is intended for use in Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Poland, Portugal,
Slovakia, Slovenia, Spain, Sweden, The Netherlands, United Kingdom, and within EFTA in Iceland, Norway and
Switzerland.
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Users are not permitted to make changes or modify the device in any way. Changes or modications not
expressly approved by Jabra will void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The user must place the base 8” (20 cm) or more from any personnel in order to comply with FCC RF exposure
requirements.
Industry Canada
Operation is subject to the following two conditions: (1) This device may not cause interference and (2) This
device must accept any interference, including interference that may cause undesired operation of the device.
The term “IC:” before the certication/registration number only signies that registration was performed based
on a Declaration of Conformity indicating that Industry Canada technical specications were met. It does not
imply that Industry Canada approved the equipment.
Patents and design registration pending international
english
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
34
english
© 2015 GN Netcom A/S. All rights reserved. Jabra® is a registered
trademark of GN Netcom A/S. All other trademarks included herein are the
property of their respective owners. (Design and specications subject to
change without notice).
MADE IN CHINA
TYPE: 9400HS/BS
JABRA PRO™ 9450, JABRA PRO™ 9450 FLEX and
JABRA PRO™ 9450 DUO
www.jabra.com
32-00713 RevD
35
Loading...
