iRobot Mirra 530 User Manual

Mirra

Pool Cleaning Robot

Model 530 Owner’s Manual

global.irobot.com

IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL THE INSTRUCTIONS

CAUTION: Do not plug the power supply into a grounded outlet or do not switch
the pool cleaner “ON” if it is not fully immersed in water.

Operating the cleaner out of waterwill cause severe damage immediately and will
result in loss of warranty.

Allow the cleaner to remain in the pool for 15 to 20 minutes following the end of
its cleaning cycle. This will allow the motors to cool adequately. Do not leave the
cleaner in the pool all the time. Always remember to turn the power supply “OFF”
and unplug it from the power outlet before removing the cleaner from the pool.

WARNING: The cleaner must not be used when people are in the water.
For use with swimming pool only.

Safety Note

• The unit must be supplied through a residual current device (RCD or GFCI) having
a rated residual operating current not exceeding 30 mA

• The connection to the branch circuit should be consistent with the local and
national wiring rules (electrical code).

• Mishandling of the unit can result in leakage of lubricants.

• If the supply cord is damaged, it must be replaced by the manufacturer’s
service agent or a qualified and trained person in order to avoid hazards.

This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.

Registration and Warranty

Please visit www.irobot.com/register to register your product and activate
your warranty.

Components

While the appearance of your cleaner and some of its components may differ from
those shown here, the function of the cleaner, operating procedures and maintenance
practices are the same.

1

2

1) Handle

2) Cable

4

3

5

6

3) Outlet Top

4) Filter Access

5) Filter Lock Lever

6) Wheels

7) Unit Body

8) Intake Valves

9) Rolling Brush

7

8

WARNING: A Ground Fault Current Interrupter (GFCI-USA) or a Residual Current Device
(RCD-EUROPE) must be installed to protect your electric outlet and preventany possible
electric shock.

SAVE THESE INSTRUCTIONS

Please read this manual completely before operating your pool cleaner.

2 iRobot Mirra 500 Series Owner’s Manual

9

Your new automatic pool cleaner contains:

• The robotic pool cleaner with its floating cable.

• The Power Supply (transformer).

Welcome

Dear Mirra Owner,

Thank you for choosing a new generation iRobot Mirra pool cleaning robot.
You’re joining a very special community of people - 7.5 million worldwide
and growing - who are discovering just how useful, convenient and
straightforward having a home robot is. In fact, owners tend to like their
robots so much they’ve even given them nicknames.

We’re passionate about our robots too. Not surprisingly, given that making
robots is all we’ve ever done in the 20 odd years of our existence.

Now, you’re probably itching to give your Mirra a go, but it’s worth having
a quick read of this manual first. That way it will be even easier to use and
save you even more time.

I hope you will have many enjoyable experiences with your Mirra and on
behalf of all the team thank you for choosing iRobot.

Best Wishes,

Colin Angle

Chairman, CEO and Co-Founder
iRobot Corporation

global.irobot.com 3

Table of Contents

Getting Started ................................................................ 5

Maintenance and Adjustment ......................................... 6-7

Cleaning the Filter/ Changing the Rolling Brush ............. 8

Accessing and Cleaning the Propeller ............................ 9

Operating Your Pool Cleaner ........................................... 10-12

Troubleshooting ............................................................... 13

Power Supply .................................................................. 14

Declaration of Conformity ............................................... 15

iRobot Customer Care .................................................... 16

4 iRobot Mirra 500 Series Owner’s Manual

Getting Started

2

1

15min.

Soak wheels
for 15 minutes

43

56 7

3.6m/11.8ft

12 cm

(4.7 inch)

global.irobot.com 5
