Digital Audio Player
Quick Start Guide
Table of Contents
Installing Audio Management Software ................................ 3
Installing IomegaWare
Connecting the HipZip
Inserting/Ejecting PocketZip
™
HipZip
Player Overview
Controls and Connections ................................................................. 8
Menu Controls .................................................................................... 9
Menu Screens ....................................................................................10
Icons ................................................................................................... 11
Messages ...........................................................................................12
MusicMatch Jukebox™ Plus Software .................................... 13
Troubleshooting ..................................................................... 15
™
Software .......................................... 4
™
Player to Your Computer ................ 5
™
Disks ....................................... 7
1
Installing Audio Management Software
Insert the Application and User’s Manual CD to install the
audio management software provided for the HipZip
CAUTION! IomegaWare™ software must be installed before you
can transfer files to your HipZip™ player.
Windows® 95 users should read the “USB Guidelines”
section on the User’s Manual CD before installing the
IomegaWare
NOTE: Illustrations on cover may not match actual contents.
™
software.
3
™
player.
Installing IomegaWare™ Software
2
Insert the IomegaWare™ software CD. Follow the instructions
on screen to install the software.
Mac® Users: If the setup program does not start up
automatically, start it manually by double clicking on the
IomegaWare
double click on the IomegaWare install icon.
Windows
automatically, start it manually by double clicking on the
IomegaWare
™
software CD icon on your Mac desktop and
®
PC Users: If the setup program does not start up
™
software CD icon in My Computer.
4
3
4
Connecting the HipZip™ Player to Your Computer
Connect the HipZip™ mini USB cable
to the USB port* on your computer.
Connect the other end of the
™
HipZip
HipZip player.
CAUTION! Do not use USB extension
cables with your HipZip™ player. Data
loss may result.
mini USB cable to the
5
*
Connecting the HipZip™ Player to Your Computer
5
Connect the power supply into your HipZip™ player and an
electrical outlet.
You must charge the battery until the “Battery Full” icon
( ) appears (approximately 2 hours).
NOTE: You must connect the power supply to use the player
without initially charging the battery.
6
Inserting/Ejecting PocketZip™ Disks
6
Insert a PocketZip™ disk, and the HipZip™ player is now
ready to use.
햲햳햴
햲 Open a PocketZip™* disk case by squeezing the top and
bottom of the case together.
™
햳 Open the door on the top of the HipZip
insert a PocketZip
™
disk (label side up) until it clicks in
player and
place.
™
햴 Eject a PocketZip
of the HipZip
disk by opening the door on the top
™
player and gently pressing in on the disk
until it clicks. The disk will pop out and you can
remove it.
*You can also use Iomega 40MB Clik!™ disks with your HipZip™ Player
7
HipZip™ Player Overview
Controls and Connections
Headphone Jack
Connection:
Connect
headphone.
Power Supply
Connection:
Connect power
supply cable.
Rewind/Skip Track Reverse:
Press once to skip to the beginning
of current track; press twice to skip
to previous track; press and hold to
rewind within current track.
Disk Drive Door:
Open the door and
insert a PocketZip
disk.
™
Lock Button:
Slide button
down to lock all
controls. Slide
up to release.
Mini USB
Connection:
Connect Iomega
mini USB cable.
Press once to stop
Off/Stop:
playback; press and
hold to turn off player.
8
On/Play/Pause:
Press to turn on.
Press again to play.
While playing, press
to pause. Press again
to resume playback.
Fast Forward/Skip
Track Forward:
Press once to skip
to next track;
press and hold to
fast forward
within current
track.
Menu Controls
Menu Up/Down:
Use these buttons
to move up and
down within the
menu options.
Menu/Select:
Press to show
menu options;
press again to
select a
highlighted
menu item.
HipZip™ Player Overview
Reset:
Insert one end
of a paper clip,
then remove to
reset player.
Volume Up/Down:
Use these buttons to
raise or lower volume
control when not in
menu mode.
9
HipZip™ Player Overview
Menu Screens
Select mode: normal,
random, scan, repeat
all, repeat random, or
Play Mode:
repeat track.
Play List Manager:
Create and select
play lists.
Settings:
Turn the
backlight
on and off.
Player Info:
View player
information.
Equalizer: Choose standard,
rock, classical, jazz, or a
custom mode.
Disk Info: View
megabytes free, total
play time, and number
of tracks on the disk.
Song Info: View all
available information
about a song—file
name, size, location,
and more.
Exit: Exit menu.
NOTE: Press any button on the front of the player to exit from
any menu.
10
Icons
HipZip™ Player Overview
Battery Level
Artist
Play Mode
Equalizer Mode
Track Number
11
Normal
Volume Level
Song Title
Time Elapsed
Lock Button On
Play Sequence
Normal
Repeat All
Repeat Track
Scan
Repeat Random
Random
HipZip™ Player Overview
Messages
Connected—displays when the player is properly connected
Connected...
to your computer and while downloading files.
Charging
Battery Full
Insert Disk
Bad Connection
Bad Disk
Check Disk
Charging—displays while the battery is charging
Battery Full—displays when the battery is fully
charged.
Insert a Disk—displays when you need to insert a disk.
Bad Connection—displays when the player is not
properly connected to your computer. Check your USB
cable connections.
Bad Disk—displays when the current disk is not
readable; insert a different disk. (You may be able to
reformat the disk using IomegaWare
™
software. See
the User’s Manual CD for more information on
formatting.)
Check Disk—displays for three seconds when the
current track contains too many errors to play; the
player then skips to the next track. You may want to
delete the damaged track and recopy it to the disk.
12
MusicMatch Jukebox™ Plus Software
Transferring Audio Files to the HipZip™ Player
Iomega has provided audio management software,
MusicMatch Jukebox
™
Plus, that will help you create digital
audio files from your existing CD collection, download
audio files from the internet, organize the files into
playlists, transfer the playlists to your HipZip™ player, and
more.
™
For simple instructions on using MusicMatch Jukebox
, start
MusicMatch and read the “Welcome Tips” located under the
Help menu.
To transfer audio files from the computer to the HipZip
™
player, follow the operating-system specific instructions on
the following page:
NOTE: Audio files must be located on the root directory only
(not in folders or subdirectories) of the HipZip™ player. The
HipZip player will not play audio files inside folders.
13
MusicMatch Jukebox™ Plus Software
Windows
®
PC Users:
1. Connect the player to your computer and insert a mini
PocketZip
2. Start MusicMatch Jukebox
™
disk into the player.
™
(Click on Start, Programs,
MusicMatch Jukebox.)
3. Select a playlist.
4. Click on Options in the main menu.
5. Select Send to Device.
™
6. Select Download Playlist to the HipZip
®
OS Users:
Mac
1. Connect the player to your computer and insert a
PocketZip
™
disk into the player.
Player.
2. Using Finder, locate the audio file(s) (e.g.,
SongABC.mp3) you want to transfer. (If you used
MusicMatch Jukebox
™
to create the file, look in the
MusicMatch Jukebox\Music\ folder.)
3. Drag and drop the file(s) (not folders) to the HipZip
™
player icon on the desktop.
14
Troubleshooting
See the User’s Manual CD for details on the following subjects:
• Getting Started
• Installing
IomegaWare
• Connecting the
HipZip
™
Player
™
• USB Guidelines
• Using Your
• HipZip
• Using PocketZip
HipZip
™
Player
™
Tips
™
Disks
• Troubleshooting
• How to Get Help
To view the User’s Manual on the CD you must have
Microsoft
Navigator
®
Internet Explorer® 4.0 or higher or Netscape
™
4.5 or higher installed on your system.
Act now—Register online
We have made it easier and faster to register your Iomega
product. Simply enter the following web address http://
www.iomegareg.com to register online.
15
See the User’s Manual CD for more technical support numbers!
The User’s Manual includes a complete list of worldwide support options.
Iomega Web Site http://www.iomega.com
Iomega Web Support Site http://www.iomega.com/support
Customer Support (U.S. and Canada) 1-888-4-IOMEGA (1-888-446-6342)
North America
In North America, this product is intended to be supplied only with an
Iomega-approved, UL-Listed and Canadian-certified Class 2 direct plug-in
power unit, with a rated output of 5.2 Vdc, 1.0 A.
CE (European Community)
Product Name: Iomega HipZip™ Digital Audio Player
Model Number: DAP-40
The HipZip™ Digital Audio player conforms to the following European
Directive(s) and Standard(s): Application of Council Directives: 73/23/EEC,
89/336/EEC. Standards to which Conformity is declared: EN60950, EN55022,
EN50082-1. Importer’s Name: Iomega Netherlands branch of Iomega
International, S.A. Type of Equipment: Internal disk drive.
Manufacturer/Responsible Party
Iomega Corporation
1821 West Iomega Way
Roy, UT 84067 U.S.A.
801-332-1000
