Intrusion
Simon® 5”
TouchScreen
60-924-RF-TS5-2
OVERVIEW
The Simon 5” TouchScreen (60-924-RF-TS5-2) is a color LCD
screen featuring a user-friendly interface that complements Simon
security systems for safety and peace of mind. The easy to use
touch screen provides system owners with at-a-glance home
status information, allowing easy and convenient control of Simon
systems. This touch screen is the ideal solution for providing
additional points of control throughout the home. Up to four touch
screens can be installed in one home for maximum convenience.
Simon 5” TouchScreens quickly and seamlessly connect to the
Simon panel using the Interlogix wireless 319.5MHz protocol. Each
touch screen comes with both a wall plate and table top stand to
accommodate wall mounting or table top installations. They also
have a built-in rechargeable battery that provides backup power in
case of power outages. An integrated speaker provides voice,
chime and siren notifications, alerting system owners of trouble and
alarm conditions.
In addition to controlling the alarm features of the Simon system, when
installed with a Simon XTi-5i panel that is equiped with Alarm.com
Simon 5” TouchScreens offer a selectable user interface which
matches the mobile interactive service application in color, style, and
icons. It also allows for control over functions including Z-Wave
wireless lighting control devices, thermostats for home HVAC systems,
door locks, and garage doors. Alarm.com also enables additional
lifestyle-enhancing information such as the current outdoor
temperature and a four-day weather forecast right on the screen.
®
,
Classic interface
Alarm.com interface
STANDARD FE ATURES
• 5-inch color LCD screen with user interface (UI) delivers at-a-glance
status of home and property
• Uses the panel’s wireless 319.5MHz RF to interconnect to the panel
• Selectable user interface (requires Simon XTi-5i panel)
• Compatible with Simon panels for added control of security system
features
• Supports 40 Zone (Simon XT, Simon XTi, Simon XTi-5) and 80
Zone (Simon XTi-5i)
• Actionable status icons
– Identify door/window open
– Last motion detected
– “My property” icon status covers all non-window, non-door,
non-interior motion changes
• Alarm.com compatible for advanced interactive services
– Optional HVAC, lighting, and lock control devices with
programmable options help promote energy savings
– Four-day weather forecast adds value and lifestyle convenience
– Z-Wave door lock support and indicator status
– Z-Wave garage door support (requires Simon XTi-5i panel)
• Access code feature setting for “Secure” vs. “Less Secure”
touch screen location
• Built-in rechargeable NiMH battery
• Up to four touch screens may be added to a Simon system
• Regulatory listed
interlogix.com/simon
Main Screen Key Functions
Emergency Button
Window/Door,
Motions Status
Selectable User
Interface
Requires Simon XTi-5i panel
and third-party modem to be
present
Related Devices & Applications
Optional Dealer Logo
Property Status
System Arming
Status & Settings
Simon® XTi-5 or
Simon XT
Control Panels
Compatible with
Simon XTi-5 or
Simon XT
v1.3 or later.
Note: Property status and other
new Two-Way Talking Touch
Screen capabilities require v1.4
Simon XT or later.
Optimized for
Simon XTi-5i
Panel v2.1 or
later
- 80 Zone support
- Selectable user
interface (required
third-party modem
to be installed)
Remote Access
Optional, convenient
interactive services
available through
Alarm.com®.
powered by
Lighting Control
Integrated lighting
control capability
through Z-Wave
®
lighting devices.
Wireless
Thermostats
Programmable HVAC
control available
through Z-Wave
wireless thermostats.
Wireless Door
Lock Control
Z-Wave door lock
support and status.
At-A-Glance Home Status
Quick, at-a-glance home status provides a complete view of home systems including security,
indoor temperature and weather.
Optional Services
Security System Control
Via Convenient Keypad
Large keypad makes security system
operation user-friendly.
Thermostat Control
Thermostat control makes it easy to set automation
schedules in conjunction with lighting and security
events to help save energy and reduce utility bills.
Garage Door Control
Four-Day Weather Forecast
Four-day weather forecast provides helpful
information quickly and conveniently.
Simon® 5” TouchScreen
60-924-RF-TS5-2
Specifications
Compatibility
Optimized For
Power
Backup Batteries 3.6VDC, 600mAh, NiMH
Dimensions (W x H x D) 6.7 x 5.0 x 0.8 in. (170 x 127 x 20mm)
Operating Temperature 32ºF to 104ºF (0ºC to 40ºC)
Maximum Humidity 85% relative (non-condensing)
Simon XT (v1.3 and later), Simon XTi, Simon XTi-5, Simon
XTi-5i
Simon XTi-5i Panel (supports 80 zones, selectable GUI,
remote firmware upgrade)
Input: 100-120VAC, 250mA
Output: 6VDC, 1000mA
Ordering Information
60-924-RF-TS5-2 Simon 5-inch TouchScreen
60-924-BAT4SIMONTS5 Replacement 600mAh Battery for Simon 5-inch TouchScreen
interlogix.com
Specifications subject to change without notice.
© 2019 United Technologies Corporation. All rights reserved.
All trademarks are the property of their respective owne rs.
Interlogix is par t of UTC Climate, Controls & Security, a unit of
United Technologies Corporation.
2019/04 (GSP-2756)
