Document Number: 320121-008

Intel® Core™2 Extreme Quad-Core Mobile Processor, Intel

Core™2 Quad Mobile Processor,

Intel® Core™2 Extreme Mobile Processor,

Intel® Core™2 Duo Mobile Processor, Intel® Core™2 Solo Mobile Processor and

Intel® Celeron® Processor on 45-nm Process

Specification Update

December 2011

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.

UNLESS OTHERWISE AGREED IN WRITING BY INTEL, THE INTEL PRODUCTS ARE NOT DESIGNED NOR INTENDED FOR ANY APPLICATION IN WHICH THE FAILURE OF THE INTEL PRODUCT COULD CREATE A SITUATION WHERE PERSONAL INJURY OR DEATH MAY OCCUR.

Intel may make changes to specifications and product descriptions at any time, without notice. Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined." Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them. The information here is subject to change without notice. Do not finalize a design with this information.

The products described in this document may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.

Intel® processor numbers are not a measure of performance. Processor numbers differentiate featur es within each processor family, not across different processor families. See www.intel.com/products/processor_number/ for details.

45nm products are manufactured on a lead-free process. Lead-free per EU RoHS directive July, 2006. Some E.U. RoHS exemptions may apply to other components used in the product package. Residual amounts of halogens are below November, 2007 proposed IPC/JEDEC J-STD-709 standards.

Intel® Active Management Technology requires the platform to have an Intel® AMT -enabled chipset, network hardware and software, connection with a power source and a network connection.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Intel, Intel Core, Intel Centrino, Intel SpeedStep, Intel386, Intel486, Pentium, Pentium Pro, Pentium 4, MMX, and the Intel logo are trademarks of Intel Corporation in the U.S. and other countries.

*Other names and brands may be claimed as the property of others.

2 Specification Update

Contents

Preface ..................................................................................................................................5

Identification Information ........................................................................................................7

Summary Tables of Changes .................................................................................................. 13

Errata ................................................................................................................................. 21

Specification Changes ........................................................................................................... 53

Specification Clarifications ..................................................................................................... 54

Documentation Changes ........................................................................................................ 56

Specification Update 3

Revision History

Document

Number

Revision

Version

Description

Date

320121

001

1.0

Initial release

July 2008

320121

002

1.0

 Updated Title  Updated Identification Information  Updated Affected Documents  Added Erratum AZ62, AZ63, AZ64,AZ65,

AZ66

August 2008

320121

003

1.0

 Added Erratum AZ66-74

October 2008

320121

004

1.0

 Added Erratum AZ75  Added Specification Clarification AZ2

November 2008

320121

005

1.0

 Table 1 added new skus and updated E and

R step information

 Errata table added R step information

March 2009

320121

006

1.0

 S-SPEC updated for new E and R step in

Table 1

April 2009

320121

007

1.0

 Added Erratum AZ76

December 2010

320121

008

1.0

 Added Erratum AZ77

December 2011

4 Specification Update

Document Title

Document

Number/Location

Intel® Core™2 Duo Processors and Intel® Core™2 Extreme

Processors on 45-nm Process for Platforms based on Mobile Intel® 965 Express Chipset family Datasheet

316745

Processor and Intel® Celeron® Processor on 45-nm Process for Platforms based on Mobile Intel® 4 Series Express Chipset family Datasheet

320120

Intel® Core™2 Extreme Quad-Core Processor Processors and Intel® Core™2 Quad Processor on 45-nm Process for Platforms based on

Mobile Intel® 4 Series Express Chipset family Datasheet

320390

Intel® Celeron Processor Low Voltage and Ultra Low Voltage o 700 Series for Platforms based on Mobile Intel® GS45 Express Chipset

320389

Document Title

Document

Number/Location

Intel® 64 and IA-32 Architecture Software Developer's Manual Documentation Changes

252046

Intel® 64 and IA-32 Architecture Software Developer’s Manual, Volume 1: Basic Architecture

253665

Intel® 64 and IA-32 Architecture Software Developer’s Manual, Volume 2A: Instruction Set Reference, A-M

253666

Intel® 64 and IA-32 Architecture Software Developer’s Manual, Volume 2B: Instruction Set Reference, N-Z

253667

Intel® 64 and IA-32 Architecture Software Developer’s Manual,

253668

Preface

This document is an update to the specifications contained in the documents listed in the following Affected Documents/Related Documents table. It is a compilation of device and document errata, and specification clarifications and changes. This document is intended for hardware system manufacturers and for software developers of applications, operating system, and tools.

Information types defined in the Nomenclature section of this document are consolidated into this update document and are no longer published in other documents. This document may also contain information that has not been previously published.

Affected Documents

Related Documents

Specification Update 5

Document Title

Document

Number/Location

Volume 3A: System Programming Guide

Intel® 64 and IA-32 Architecture Software Developer’s Manual, Volume 3B: System Programming Guide

253669

IA-32 Intel® Architecture Optimization Reference Manual

248966

Intel Processor Identification and the CPUID Instruction Application Note (AP-485)

241618

Intel® 64 and IA-32 Architectures Application Note TLBs, PagingStructure Caches, and Their Invalidation

317080

NOTE: Contact your Intel representative for the latest revision.

Nomenclature

Errata are design defects or errors. These may cause the processor behavior to deviate

from published specifications. Hardware and software designed to be used with any given stepping must assume that all errata documented for that stepping are present on all devices.

Preface

S-Spec Number is a five-digit code used to identify products. Products are differentiated by their unique characteristics, e.g., core speed, L2 cache size, package type, etc. as described in the processor identification information table. Read all notes associated with each S-Spec number.

Specification Changes are modifications to the current published specifications. These changes will be incorporated in any new release of the specification.

Specification Clarifications describe a specification in greater detail or further highlight

a specification‟s impact to a complex design situation. These clarifications will be

incorporated in any new release of the specification.

Documentation Changes include typos, errors, or omissions from the current published specifications. These will be incorporated in any new release of the specification.

Note: Errata remain in the specification update throughout the product‟s lifecycle, or until a

particular stepping is no longer commercially available. Under these circumstances, errata removed from the specification update are archived and available upon request. Specification changes, specification clarifications and documentation changes are removed from the specification update when the appropriate changes are made to the appropriate product specification or user documentation (datasheets, manuals, etc.).

6 Specification Update

Reserved

Extended

Family1

Extended

Model2

Reserved

Processor

Type3

Family

Code4

Model

Number5

Stepping

ID6

31:28

27:20

19:16

15:14

13:12

11:8

7:4

3:0

0000000b

0001b

00b

0110b

0111b

XXXXb

Identification Information

Component Identification via Programming Interface

Intel® Core™2 Extreme Quad-Core Mobile Processor, Intel® Core™2 Quad Mobile Processor, Intel® Core™2 Extreme Mobile Processor, Intel® Core™2 Duo Mobile Processor, Intel® Core™2 Solo Mobile Processor and Intel® Celeron® Processor on 45nm Process stepping can be identified by the following register contents:

When EAX is initialized to a value of 1, the CPUID instruction returns the Extended Family, Extended Model, Type, Family, Model and Stepping value in the EAX register. Note that the EDX processor signature value after reset is equivalent to the processor signature output value in the EAX register.

NOTES:

1. The Extended Family, bits [27:20] are used in conjunction with the Family Code, specified in

bits [11:8], to indicate whether the processor belongs to the Intel386®, Intel486®, Pentium®, Pentium Pro, Pentium 4, or Intel Core processor family.

2. The Extended Model, bits [19:16] in conjunction with the Model Number, specified in bits

[7:4], are used to identify the model of the processor within the processor‟s family.

3. The Processor Type, specified in bits [13:12] indicates whether the processor is an original

OEM processor, an OverDrive processor, or a dual processor (capable of being used in a dual processor system).

4. The Family Code corresponds to bits [11:8] of the EDX register after RESET, bits [11:8] of the

EAX register after the CPUID instruction is executed with a 1 in the EAX register, and the generation field of the Device ID register accessible through Boundary Scan.

5. The Model Number corresponds to bits [7:4] of the EDX register after RESET, bits [7:4] of the

EAX register after the CPUID instruction is executed with a 1 in the EAX register, and the model field of the Device ID register accessible through Boundary Scan.

6. The Stepping ID in bits [3:0] indicates the revision number of that model. See Table 2 for the

processor stepping ID number in the CPUID information.

Cache and TLB descriptor parameters are provided in the EAX, EBX, ECX and EDX registers after the CPUID instruction is executed with a 2 in the EAX register.

Specification Update 7

Component Marking Information

MARK EXAMPLE: Group 1 Line 1: Unit Identifier Processor # Group 1 Line 2: FPO SSPEC# Group 2 Line 1: Frequency/L2 Cache/FSB Speed Group 2 Line 2: INTEL (m) © ’07

The processor stepping can be identified by the following component markings:

Figure 1. Processor S-Spec Top-side Markings (Example)

Identification Information

8 Specification Update

S-

Spec#

Processor

Package

Processor

Stepping

CPUID

Core Frequency

HFM/LFM/ SLFM

(GHz)

FSB Freq.

(MHz)

IDAT

Freq.(GHz)

HFM TDP

(W)

Cache(MB)

Notes

SLAQH

T9500

m-FCPGA

C-0

000010676h

2.6/1.2/0.8

800

2.8

35 6 2,3,4

SLAPW

T9500

m-FCBGA

C-0

000010676h

2.6/1.2/0.8

800

2.8

35 6 2,3,4

SLAQG

T9300

m-FCPGA

C-0

000010676h

2.5/1.2/0.8

800

2.7

35 6 2,3,4

SLAPV

T9300

m-FCBGA

C-0

000010676h

2.5/1.2/0.8

800

2.7

35 6 2,3,4

SLAPU

T8300

m-FCBGA

C-0

000010676h

2.4/1.2/0.8

800

2.6

35 3 2,3,4

SLAUU

T8100

m-FCPGA

C-0

000010676h

2.1/1.2/0.8

800

2.3

35 3 2,3,4

SLAPT

T8100

m-FCBGA

C-0

000010676h

2.1/1.2/0.8

800

2.3

35 3 2,3,4

SLAPA

T8300

m-FCPGA

M-0

000010676h

2.4/1.2/0.8

800

2.6

35 3 2,3,4

SLAPR

T8300

m-FCBGA

M-0

000010676h

2.4/1.2/0.8

800

2.6

35 3 2,3,4

SLAP9

T8100

m-FCPGA

M-0

000010676h

2.1/1.2/0.8

800

2.3

35 3 2,3,4

SLAPS

T8100

m-FCBGA

M-0

000010676h

2.1/1.2/0.8

800

2.3

35 3 2,3,4

SLAVJ

T8100

m-FCPGA

M-0

000010676h

2.1/1.2/0.8

800

2.3

35 3 2,3,4

SLAXG

T8100

m-FCPGA

M-0

000010676h

2.1/1.2/0.8

800

2.3

35 3 2,3,4

SLAZD

T8100

m-FCPGA

M-0

000010676h

2.1/1.2/0.8

800

2.3

35 3 2,3,4,7

SLAYZ

T8100

m-FCPGA

M-0

000010676h

2.1/1.2/0.8

800

2.3

35 3 2,3,4,7

SLAZC

T8300

m-FCPGA

M-0

000010676h

2.4/1.2/0.8

800

2.6

35 3 2,3,4,7

SLAZB

T9300

m-FCPGA

C-0

000010676h

2.5/1.2/0.8

800

2.7

35 6 2,3,4,7

SLAYY

T9300

m-FCPGA

C-0

000010676h

2.5/1.2/0.8

800

2.7

35 6 2,3,4,7

SLAZA

T9500

m-FCPGA

C-0

000010676h

2.6/1.2/0.8

800

2.8

35 6 2,3,4,7

SLAYX

T9500

m-FCPGA

C-0

000010676h

2.6/1.2/0.8

800

2.8

35 6 2,3,4,7

SLAQJ

X9000

m-FCPGA

C-0

000010676h

2.8/1.2/0.8

800

N/A

44 6 1,5,6

SLAZ3

X9000

m-FCPGA

C-0

000010676h

2.8/1.2/0.8

800

N/A

44 6 1,5,6,7

SLB47

T9600

m-FCPGA

C-0

000010676h

2.80/1.6/0.8

1066

2.93

35 6 4,6,10

SLB43

T9600

m-FCBGA

C-0

000010676h

2.80/1.6/0.8

1066

2.93

35 6 4,6,10

SLB46

T9400

m-FCPGA

C-0

000010676h

2.53/1.6/0.8

1066

2.66

35 6 4,6,10

SL3BX

T9400

m-FCBGA

C-0

000010676h

2.53/1.6/0.8

1066

2.66

35 6 4,6,10

SLB4E

P9500

m-FCPGA

C-0

000010676h

2.53/1.6/0.8

1066

2.66

25 6 6,11,12

SL3BW

P9500

m-FCBGA

C-0

000010676h

2.53/1.6/0.8

1066

2.66

25 6 6,11,12

SLB3S

P8600

m-FCPGA

M-0

000010676h

2.40/1.6/0.8

1066

2.53

25 3 6,11,12

SLB4N

P8600

m-FCBGA

M-0

000010676h

2.40/1.6/0.8

1066

2.53

25 3 6,11,12

SLB3R

P8400

m-FCPGA

M-0

000010676h

2.26/1.6/0.8

1066

2.40

25 3 6,11,12

Identification Information

Table 1. Processor Identification Information

Specification Update 9

Identification Information

S-

Spec#

Processor

Package

Processor

Stepping

CPUID

Core Frequency

HFM/LFM/ SLFM

(GHz)

FSB Freq.

(MHz)

IDAT

Freq.(GHz)

HFM TDP

(W)

Cache(MB)

Notes

SLB4M

P8400

m-FCBGA

M-0

000010676h

2.26/1.6/0.8

1066

2.40

25 3 6,11,12

SLB3Q

P8400

m-FCPGA

M-0

000010676h

2.26/1.6/0.8

1066

2.40

25 3 26,8,9

SL3BV

P8600

m-FCBGA

C-0

000010676h

2.40/1.6/0.8

1066

2.53

25 3 6,11,12

SL3BU

P8400

m-FCBGA

C-0

000010676h

2.26/1.6/0.8

1066

2.40

25 3 6,11,12

SLB48

X9100

m-FCPGA

C-0

000010676h

3.06/1.6/0.8

1066

N/A

44 6 1,5,6

SLAYS

T8300

m-FCPGA

M-0

000010676h

2.4/1.2/0.8

800

2.6

35 3 2,3,4,7

SLAYU

T8100

m-FCPGA

M-0

000010676h

2.1/1.2/0.8

800

2.3

35 3 2,3,4,7

SLAYP

T8100

m-FCPGA

M-0

000010676h

2.1/1.2/0.8

800

2.3

35 3 2,3,4,7

SLAYQ

T8300

m-FCPGA

M-0

000010676h

2.4/1.2/0.8

800

2.6

35 3 2,3,4,7

SLG8E

P7350

m-FCBGA

C-0

000010676h

2.00/1.6/0.8

1066

N/A

25 3 17,6,18

SLB45

P7450

m-FCPGA

C-0

000010676h

2.13/1.6/0.8

1066

N/A

25 3 17,6,18

SLB44

P7350

m-FCPGA

C-0

000010676h

2.00/1.6/0.8

1066

N/A

25 3 17,6,18

SLB54

P7450

m-FCPGA

M-0

000010676h

2.13/1.6/0.8

1066

N/A

25 3 17,6,18

SLB53

P7350

m-FCPGA

M-0

000010676h

2.00/1.6/0.8

1066

N/A

25 3 17,6,18

SLB5J

QX9300

m-FCPGA

E-0

00001067Ah

2.53/1.6/(n/a)

1066

2.8

14,15,16

SLB5G

Q9100

m-FCPGA

E-0

00001067Ah

2.26/1.6/(n/a)

1066

2.53

14,15,16

SLB64

SP9400

m-FCBGA

C-0

000010676h

2.40/1.6/0.8

1066

2.53

25 6 17,6,18

SLB63

SP9300

m-FCBGA

C-0

000010676h

2.26/1.6/0.8

1066

2.40

25 6 17,6,18

SLB66

SL9400

m-FCBGA

C-0

000010676h

1.86/1.6/0.8

1066

2.13

17 6 19,6,20

SLB65

SL9300

m-FCBGA

C-0

000010676h

1.60/0.8/0.8

1066

1.86

17 6 19,6,20

SLB5V

SU9400

m-FCBGA

M-0

000010676h

1.40/0.8/0.8

800

1.60

10 3 21,22,23

SLB5Q

SU9300

m-FCBGA

M-0

000010676h

1.20/0.8/0.8

800

1.40

10 3 21,22,23

SLGAR

SU3300

m-FCBGA

M-0

000010676h

1.20/0.8/(n/a)

800

N/A

5.5 3 24,13

SLGAS

723

m-FCBGA

M-0

000010676h

1.20/(n/a)/(n/a)

800

N/A

10 1 25,13

QJPQ

SU9600

m-FCBGA

R-0

00001067Ah

1.6/1.2/0.8

800

1.8

10 3 31,32,33

QJPM

SU9400

m-FCBGA

R-0

00001067Ah

1.4/1.2/0.8

800

1.6

10 3 31,32,33

QJPF

SU9300

m-FCBGA

R-0

00001067Ah

1.2/1.2/0.8

800

1.4

10 3 31,32,33

QJNG

SL9600

m-FCBGA

E-0

00001067Ah

2.13/1.6/0.8

1066

2.4

17 6 29,11,30

QJND

SL9400

m-FCBGA

E-0

00001067Ah

1.86/1.6/0.8

1066

2.13

17 6 29,11,30

QJNA

SL9300

m-FCBGA

E-0

00001067Ah

1.6/1.6/0.8

1066

1.86

17 6 29,11,30

QJNR

SP9600

m-FCBGA

E-0

00001067Ah

2.53/1.6/0.8

1066

2.66

25 6 27,11,28

QJNN

SP9400

m-FCBGA

E-0

00001067Ah

2.4/1.6/0.8

1066

2.53

25 6 27,11,28

QJNK

SP9300

m-FCBGA

E-0

00001067Ah

2.26/1.6/0.8

1066

2.4

25 6 27,11,28

10 Specification Update

S-

Spec#

Processor

Package

Processor

Stepping

CPUID

Core Frequency

HFM/LFM/ SLFM

(GHz)

FSB Freq.

(MHz)

IDAT

Freq.(GHz)

HFM TDP

(W)

Cache(MB)

Notes

QJNW

723

m-FCBGA

R-0

00001067Ah

1.2/(n/a)/(n/a)

800

N/A

10 1 35,13

QJPT

SU3300

m-FCBGA

R-0

00001067Ah

1.2/1.2/0.8

800

N/A

5.5 3 34,13

QJRU

743

m-FCBGA

R-0

00001067Ah

1.3/(n/a)/(n/a)

800

N/A

10 1 35,13

QKUS

SU3500

m-FCBGA

R-0

00001067Ah

1.4/1.2/0.8

800

N/A

5.5 3 34,13

SLGFN

SU9600

m-FCBGA

R-0

00001067Ah

1.6/1.2/0.8

800

1.8

10 3 31,32,33

SLGAK

SU9400

m-FCBGA

R-0

00001067Ah

1.4/1.2/0.8

800

1.6

10 3 31,32,33

SLGAL

SU9300

m-FCBGA

R-0

00001067Ah

1.2/1.2/0.8

800

1.4

10 3 31,32,33

SLGEQ

SL9600

m-FCBGA

E-0

00001067Ah

2.13/1.6/0.8

1066

2.4

17 6 29,6,30

SLGAB

SL9400

m-FCBGA

E-0

00001067Ah

1.86/1.6/0.8

1066

2.13

17 6 29,6,30

SLGAG

SL9300

m-FCBGA

E-0

00001067Ah

1.6/1.6/0.8

1066

1.86

17 6 29,6,30

SLGER

SP9600

m-FCBGA

E-0

00001067Ah

2.53/1.6/0.8

1066

2.66

25 6 27,6,28

SLGAA

SP9400

m-FCBGA

E-0

00001067Ah

2.4/1.6/0.8

1066

2.53

25 6 27,6,28

SLGAF

SP9300

m-FCBGA

E-0

00001067Ah

2.26/1.6/0.8

1066

2.4

25 6 27,6,28

SLGAM

723

m-FCBGA

R-0

00001067Ah

1.2/(n/a)/(n/a)

800

N/A

10 1 35,13

SLGAJ

SU3300

m-FCBGA

R-0

00001067Ah

1.2/1.2/0.8

800

N/A

5.5 3 34,13

SLGEV

743

m-FCBGA

R-0

00001067Ah

1.3/(n/a)/(n/a)

800

N/A

10 1 35,13

SLGQQ

SU3500

m-FCBGA

R-0

00001067Ah

1.4/1.2/0.8

800

N/A

5.5 3 34,13

Identification Information

NOTES:

1. Does not support Intel® Dynamic Acceleration Technology

2. Vcc core VID=1.000-1.250/0.850-1.250 V [HFM/LFM]; 0.750-0.925 V [S-LFM]

3. Vcc core VID=0.650-0.859/0.600-0.850/0.350-0.700 V [C4/DC4/C6]

4. Vcc core VID=1.000-1.300 [IDAT]

5. Vcc core VID=1.000-1.275/0.850-1.100 V [HFM/LFM]; 0.800-1.000 V [S-LFM]

6. Vcc core VID=0.650-0.850/0.600-0.850/0.35-0.70 V [C4/DC4/C6]

7. This part is screened to avoid Erratum AZ52

8. Vcc core VID=1.050-1.1625/1.000 V [HFM/LFM]; 0.825-0.950 V [S-LFM]

9. Vcc core VID=1.050-1.2125 [IDAT]

10. Vcc core VID=1.000-1.250/0.850-1.100 V [HFM/LFM]; 0.750-0.950 V [S-LFM]

11. Vcc core VID=0.900-1.250/0.850-1.025 V [HFM/LFM]; 0.750-0.950 V [S-LFM]

12. Vcc core VID=0.900-1.300 [IDAT]

13. Intel® Celeron® M processor

14. Vcc core VID=0.90-1.25/0.850-1.100 V [HFM/LFM]

15. Vcc core VID=0.65-0.85 [C4]

16. Vcc core VID=0.90-1.30 [IDAT]

17. Vcc core VID=0.900-1.2125/0.850-1.025 V [HFM/LFM]; 0.75-0.95 V [S-LFM]

18. Vcc core VID=0.900-1.275 [IDAT]

19. Vcc core VID=0.900-1.175/0.850-1.025 V [HFM/LFM]; 0.75-0.95 V [S-LFM]

20. Vcc core VID=0.90-1.25 [IDAT]

21. Vcc core VID=0.775-1.100/0.80-0.975 V [HFM/LFM]; 0.750-0.925 V [S-LFM]

22. Vcc core VID=0.65-0.80/0.60-0.80/0.35-0.60 V [C4/DC4/C6]

23. Vcc core VID=0.80-1.1625 [IDAT]

24. Vcc core VID=0.80-1.25 [VID]

25. Vcc core VID=0.775-1.10 [VID]

Specification Update 11

26. Vcc core VID=0.725-0.775/0.725-0.750/0.400-0.700 V [C4/DC4/C6]

27. Vcc core VID=0.900-1.2125/0.850-1.025 V [HFM/LFM]; 0.75-0.95 V [S-LFM]

28. Vcc core VID=0.900-1.275 [IDAT]

29. Vcc core VID=0.900-1.175/0.850-1.025 V [HFM/LFM]; 0.75-0.95 V [S-LFM]

30. Vcc core VID=0.90-1.25 [IDAT]

31. Vcc core VID=0.775-1.100/0.80-0.975 V [HFM/LFM]; 0.750-0.925 V [S-LFM]

32. Vcc core VID=0.65-0.80/0.60-0.80/0.35-0.60 V [C4/DC4/C6]

33. Vcc core VID=0.80-1.1625 [IDAT]

34. Vcc core VID=0.80-1.25 [VID]

35. Vcc core VID=0.775-1.10 [VID]

36. Vcc core VID=0.900-1.2125/0.850-1.025 V [HFM/LFM]; 0.75-0.95 V [S-LFM]

37. Vcc core VID=0.900-1.2125/0.850-1.025 V [HFM/LFM]; 0.75-0.95 V [S-LFM]

38. Vcc core VID=0.900-1.175/0.850-1.025 V [HFM/LFM]; 0.75-0.95 V [S-LFM]

Identification Information

12 Specification Update

Summary Tables of Changes

The following table indicates the Specification Changes, Errata, Specification Clarifications or Documentation Changes, which apply to the listed CPU steppings. Intel intends to fix some of the errata in a future stepping of the component, and to account for the other outstanding issues through documentation or Specification Changes as noted. This table uses the following notations:

Codes Used in Summary Table

Stepping

X: Erratum, Specification Change or Clarification that applies to

this stepping.

Status

Row

(No mark) or (Blank Box): This erratum is fixed in listed stepping or specification change

does not apply to listed stepping.

Doc: Document change or update that will be implemented.

PlanFix: This erratum may be fixed in a future stepping of the

product.

Fixed: This erratum has been previously fixed.

NoFix: There are no plans to fix this erratum.

Shaded: This item is either new or modified from the previous version

of the document.

Specification Update 13

Summary Tables of Changes

Note: Each Specification Update item is prefixed with a capital letter to distinguish the product.

The key below details the letters that are used in Intel‟s microprocessor Specification Updates:

A = Dual-Core Intel® Xeon® processor 7000 sequence

C = Intel® Celeron® processor

D = Dual-Core Intel® Xeon® processor 2.80 GHz

E = Intel® Pentium® III processor

F = Intel® Pentium® processor Extreme Edition and Intel® Pentium® D processor

I = Dual-Core Intel® Xeon® processor 5000 series

J = 64-bit Intel® Xeon® processor MP with 1-MB L2 Cache

K = Mobile Intel® Pentium® III processor

L = Intel® Celeron® D processor

M = Mobile Intel® Celeron® processor

N = Intel® Pentium® 4 processor

O = Intel® Xeon® processor MP

P = Intel® Xeon® processor

Q = Mobile Intel® Pentium® 4 processor supporting Hyper-Threading Technology on 90nm process technology

R = Intel® Pentium® 4 processor on 90 nm process

S = 64-bit Intel® Xeon® processor with 800 MHz system bus (1 MB and 2 MB L2 cache versions)

T = Mobile Intel® Pentium® 4 processor–M

U = 64-bit Intel® Xeon® processor MP with up to 8MB L3 Cache

V = Mobile Intel® Celeron® processor on .13 Micron Process in Micro-FCPGA Package

W= Intel® Celeron®-M processor

X = Intel® Pentium® M processor on 90-nm process with 2-MB L2 cache and Intel® Processors A100 and A110 with 512-KB L2 cache

Y = Intel® Pentium® M processor

Z = Mobile Intel® Pentium® 4 processor with 533 MHz system bus

AA= Intel® Pentium® D Processor 900 Sequence and Intel® Pentium® processor Extreme Edition 955, 965

AB= Intel® Pentium® 4 processor 6x1 Sequence

AC= Intel® Celeron® processor in 478 pin package

AD = Intel® Celeron® D processor on 65 nm process

AE = Intel® Core™ Duo processor and Intel® Core™ Solo processor on 65nm process

AF = Dual-Core™ Intel® Xeon® processor LV

AG = Dual-Core Intel® Xeon® processor 5100 Series

AH= Intel® Core™2 Duo mobile processor

AI = Intel® Core™2 Extreme processor X6800

and Intel® Core™2 Duo Desktop

processor E6000 and E4000 Sequence

AJ = Quad-Core Intel® Xeon® processor 5300 Series

AK = Intel® Core™2 Extreme quad-core processor QX6700 and Intel® Core™2 Quad processor Q6600

AL = Dual-Core Intel® Xeon® processor 7100 Series

14 Specification Update

Summary Tables of Changes

AM = Intel® Celeron® processor 400 sequence

AN = Intel® Pentium® Dual-Core processor

AO = Quad-Core Intel® Xeon® processor 3200 Series

AP = Dual-Core Intel® Xeon® processor 3000 Series

AQ = Intel® Pentium® Dual-Core Desktop Processor E2000 Sequence

AR = Intel® Celeron® processor 500 series

AS = Intel® Xeon® processor 7200, 7300 series

AT = Intel® Celeron® processor 200 series

AU = Intel® Celeron® Dual Core processor T1400

AV = Intel® Core™2 Extreme processor QX9000 sequence and Intel® Core™2 Quad processor Q9000 sequence processor

AW = Intel® Core™ 2 Duo

AX =Quad-Core Intel® Xeon® processor 5400 series

AY =Dual-Core Intel® Xeon® processor 5200 series

AZ = Intel® Core™2 Extreme Quad-Core Mobile Processor, Intel® Core™2 Quad Mobile

Processor, Intel® Core™2 Extreme Mobile Processor, Intel® Core™2 Duo Mobile Processor, Intel® Core™2 Solo Mobile Processor and Intel® Celeron® Processor on 45-

nm Process

AAA = Quad-Core Intel® Xeon® processor 3300 series

AAB = Dual-Core Intel® Xeon® E3110 Processor

AAC = Intel® Celeron® dual-core processor E1000 series

AAD = Intel® CoreTM2 Extreme Processor QX9775

AAE = Intel® AtomTM processor Z5xx series

AAF = Intel® AtomTM processor 200 series

AAG = Intel® Atom™ processor N series

AAH = Intel® Atom™ processor 300 series

Note: Intel processor numbers are not a measure of performance. Processor numbers

differentiate features within each processor family, not across different processor families. See http://www.intel.com/products/processor_number for details.

Specification Update 15

Errata

Number

Steppings

Status

ERRATA

C-0

M-0

E-0

R-0

AZ1

X X X X No Fix

EFLAGS Discrepancy on a Page Fault After a Multiprocessor TLB Shootdown

AZ2

X X X X No Fix

INVLPG Operation for Large (2M/4M) Pages May be Incomplete under Certain Conditions

AZ3

X X X X No Fix

Store to WT Memory Data May be Seen in Wrong Order by Two Subsequent Loads

AZ4

X X X X No Fix

Non-Temporal Data Store May be Observed in Wrong Program Order

AZ5

X X X X No Fix

Page Access Bit May be Set Prior to Signaling a Code Segment Limit Fault

AZ6

X X X X No Fix

Updating Code Page Directory Attributes without TLB Invalidation May Result in Improper Handling of Code #PF

AZ7

X X X X No Fix

Storage of PEBS Record Delayed Following Execution of MOV SS or STI

AZ8

X X X X No Fix

Performance Monitoring Event FP_MMX_TRANS_TO_MMX May Not Count Some Transitions

AZ9

X X X X No Fix

A REP STOS/MOVS to a MONITOR/MWAIT Address Range May Prevent Triggering of the Monitoring Hardware

AZ10

X X X X No Fix

Performance Monitoring Event MISALIGN_MEM_REF May Over Count

AZ11

X X X X No Fix

The Processor May Report a #TS Instead of a #GP Fault

AZ12

X X X X No Fix

Code Segment Limit Violation May Occur on 4 Gigabyte Limit Check

AZ13

X X X X No Fix

A Write to an APIC Register Sometimes May Appear to Have Not Occurred

AZ14

X X X X No Fix

Last Branch Records (LBR) Updates May be Incorrect after a Task Switch

AZ15

X X X X No Fix

REP MOVS/STOS Executing with Fast Strings Enabled and Crossing Page Boundaries with Inconsistent Memory Types may use an Incorrect Data Size or Lead to MemoryOrdering Violations.

AZ16

X X X X No Fix

Upper 32 bits of 'From' Address Reported through BTMs or BTSs May be Incorrect

AZ17

X X X X No Fix

Address Reported by Machine-Check Architecture (MCA) on Single-bit L2 ECC Errors May be Incorrect

AZ18

X X X X No Fix

Code Segment Limit/Canonical Faults on RSM May be Serviced before Higher Priority Interrupts/Exceptions

AZ19

X X X X No Fix

Store Ordering May be Incorrect between WC and WP Memory Type

Summary Tables of Changes

16 Specification Update

Number

Steppings

Status

ERRATA

C-0

M-0

E-0

R-0

AZ20

X X X X No Fix

EFLAGS, CR0, CR4 and the EXF4 Signal May be Incorrect after Shutdown

AZ21

X X X X No Fix

Premature Execution of a Load Operation Prior to Exception Handler Invocation

AZ22

X X X X No Fix

Performance Monitoring Events for Retired Instructions (C0H) May Not Be Accurate

AZ23

X X X X No Fix

Returning to Real Mode from SMM with EFLAGS.VM Set May Result in Unpredictable System Behavior

AZ24

X X X X No Fix

CMPSB, LODSB, or SCASB in 64-bit Mode with Count Greater or Equal to 248 May Terminate Early

AZ25

X X X X No Fix

Writing the Local Vector Table (LVT) when an Interrupt is Pending May Cause an Unexpected Interrupt

AZ26

X X X X No Fix

Pending x87 FPU Exceptions (#MF) Following STI May Be Serviced Before Higher Priority Interrupts

AZ27

X X X X No Fix

VERW/VERR/LSL/LAR Instructions May Unexpectedly Update the Last Exception Record (LER) MSR

AZ28

X X X X No Fix

INIT Does Not Clear Global Entries in the TLB

AZ29

X X X X No Fix

Split Locked Stores May not Trigger the Monitoring Hardware

AZ30

X X X X No Fix

Programming the Digital Thermal Sensor (DTS) Threshold May Cause Unexpected Thermal Interrupts

AZ31

X X X X No Fix

Writing Shared Unaligned Data that Crosses a Cache Line without Proper Semaphores or Barriers May Expose a Memory Ordering Issue

AZ32

X X X X No Fix

General Protection (#GP) Fault May Not Be Signaled on Data Segment Limit Violation above 4-G Limit

AZ33

X X X X No Fix

An Asynchronous MCE During a Far Transfer May Corrupt ESP

AZ34

X X X X Plan

Fix

CPUID Reports Architectural Performance Monitoring Version 2 is Supported, When Only Version 1 Capabilities are Available

AZ35

X X X X No Fix

B0-B3 Bits in DR6 May Not be Properly Cleared After Code Breakpoint

AZ36

X X X X No Fix

An xTPR Update Transaction Cycle, if Enabled, May be Issued to the FSB after the Processor has Issued a StopGrant Special Cycle

AZ37

X X X X Plan

Fix

Performance Monitoring Event IA32_FIXED_CTR2 May Not Function Properly when Max Ratio is a Non-Integer Coreto-Bus Ratio

AZ38

X X X X No Fix

Instruction Fetch May Cause a Livelock During Snoops of the L1 Data Cache

AZ39

X X X X No Fix

Use of Memory Aliasing with Inconsistent Memory Type may Cause a System Hang or a Machine Check Exception

Summary Tables of Changes

Specification Update 17

Summary Tables of Changes

Number

Steppings

Status

ERRATA

C-0

M-0

E-0

R-0

AZ40

X X X X No Fix

A WB Store Following a REP STOS/MOVS or FXSAVE May Lead to Memory-Ordering Violations

AZ41

X X X X Plan

Fix

VM Exit with Exit Reason "TPR Below Threshold" Can Cause the Blocking by MOV/POP SS and Blocking by STI Bits to be Cleared in the Guest Interruptibility-State Field

AZ42

X X X X No Fix

Using Memory Type Aliasing with Cacheable and WC Memory Types May Lead to Memory Ordering Violations

AZ43

X X X X No Fix

VM Exit Caused by a SIPI Results in Zero Being Saved to the Guest RIP Field in the VMCS

AZ44

X X X X No Fix

NMIs May Not Be Blocked by a VM-Entry Failure

AZ45

X X X X Plan

Fix

Partial Streaming Load Instruction Sequence May Cause the Processor to Hang

AZ46

X X X X Plan

Fix

Self/Cross Modifying Code May Not be Detected or May Cause a Machine Check Exception

AZ47

X X X X Plan

Fix

Data TLB Eviction Condition in the Middle of a Cacheline Split Load Operation May Cause the Processor to Hang

AZ48

X X X X Plan

Fix

Update of Read/Write (R/W) or User/Supervisor (U/S) or Present (P) Bits without TLB Shootdown May Cause Unexpected Processor Behavior

AZ49

X X X X Plan

Fix

RSM Instruction Execution under Certain Conditions May Cause Processor Hang or Unexpected Instruction Execution Results

AZ50

X X X X No Fix

Benign Exception after a Double Fault May Not Cause a Triple Fault Shutdown

AZ51

X X X X No Fix

LER MSRs May Be Incorrectly Updated

AZ52

X X X X Plan

Fix

Processor May Unexpectedly Assert False THERMTRIP# After Receiving a Warm Reset

AZ53

X X X X Plan

Fix

Short Nested Loops That Span Multiple 16-Byte Boundaries May Cause a Machine Check Exception or a System Hang

AZ54

X X X X No Fix

IA32_MC1_STATUS MSR Bit[60] Does Not Reflect Machine Check Error Reporting Enable Correctly

AZ55

X X X X No Fix

An Enabled Debug Breakpoint or Single Step Trap May Be Taken after MOV SS/POP SS Instruction if it is Followed by an Instruction That Signals a Floating Point Exception

AZ56

X X X X No Fix

Code Segment Limit/Canonical Faults on RSM May be Serviced before Higher Priority Interrupts/Exceptions and May Push the Wrong Address Onto the Stack

AZ57

X X X X No Fix

A VM Exit Due to a Fault While Delivering a Software Interrupt May Save Incorrect Data into the VMCS

AZ58

X X X X No Fix

A VM Exit Occurring in IA-32e Mode May Not Produce a VMX Abort When Expected

AZ59

X X X X No Fix

IRET under Certain Conditions May Cause an Unexpected Alignment Check Exception

18 Specification Update

Number

Steppings

Status

ERRATA

C-0

M-0

E-0

R-0

AZ60

X X X X No Fix

Thermal Interrupts are Dropped During and While Exiting Intel® Deep Power-Down State

AZ61

X X X X No Fix

VM Entry May Fail When Attempting to Set IA32_DEBUGCTL.FREEZE_WHILE_SMM_EN

AZ62

X X No Fix

VM Entry May Use Wrong Address to Access Virtual-APIC Page

AZ63

X X No Fix

INIT Incorrectly Resets IA32_LSTAR MSR

AZ64

X X No Fix

When a CPUID instruction is executed, the returned EAX, EBX, ECX, and/or EDX may be incorrect.

AZ65

X X X X No Fix

Global Instruction TLB Entries May Not be Invalidated on a VM Exit or VM Entry

AZ66

X X No Fix

XRSTOR Instruction May Cause Extra Memory Reads

AZ67

X X X X No Fix

LBR, BTS, BTM May Report a Wrong Address when an Exception/Interrupt Occurs in 64-bit Mode

AZ68

X X No Fix

When Intel® Deep Power-Down State is Being Used, IA32_FIXED_CTR2 May Return Incorrect Cycle Counts

AZ69

X X No Fix

Enabling PECI via the PECI_CTL MSR Incorrectly Writes CPUID_FEATURE_MASK1 MSR

AZ70

X X X X No Fix

Corruption of CS Segment Register During RSM While Transitioning From Real Mode to Protected Mode

AZ71

X X No Fix

The XSAVE Instruction May Erroneously Set Reserved Bits in the XSTATE_BV Field

AZ72

X X No Fix

Store Ordering Violation When Using XSAVE

AZ73

X X X X No Fix

Memory Ordering Violation With Stores/Loads Crossing a Cacheline Boundary

AZ74

X X No Fix

The XRSTOR Instruction May Fail to Cause a GeneralProtection Exception

AZ75

X X X X No Fix

B0-B3 Bits in DR6 For Non-Enabled Breakpoints May be Incorrectly Set

AZ76

X X X X No Fix

A 64-bit Register IP-relative Instruction May Return Unexpected Results

AZ77

X X X X No Fix

Intel® Trusted Execution Technology ACM Revocation

Number

SPECIFICATION CHANGES

There are no Specification Changes in this Specification Update revision

Summary Tables of Changes

Specification Update 19

Number

SPECIFICATION CLARIFICATIONS

AZ1

Clarification of Translation Lookaside Buffers (TLBS) Invalidation

AZ2

CPUID Instruction Will Return Brand String With a Missing Letter

Number

DOCUMENTATION CHANGES

There are no Documentation Changes in this Specification Update revision.

Summary Tables of Changes

20 Specification Update

Errata

AZ1. EFLAGS Discrepancy on a Page Fault after a Multiprocessor TLB

Shootdown

Problem: This erratum may occur when the processor executes one of the following read-modify-

write arithmetic instructions and a page fault occurs during the store of the memory operand: ADD, AND, BTC, BTR, BTS, CMPXCHG, DEC, INC, NEG, NOT, OR, ROL/ROR, SAL/SAR/SHL/SHR, SHLD, SHRD, SUB, XOR, and XADD. In this case, the EFLAGS value pushed onto the stack of the page fault handler may reflect the status of the register after the instruction would have completed execution rather than before it. The following conditions are required for the store to generate a page fault and call the operating system page fault handler:

1. The store address entry must be evicted from the DTLB by speculative loads from

other instructions that hit the same way of the DTLB before the store has completed. DTLB eviction requires at least three-load operations that have linear address bits 15:12 equal to each other and address bits 31:16 different from each other in close physical proximity to the arithmetic operation.

2. The page table entry for the store address must have its permissions tightened

during the very small window of time between the DTLB eviction and execution of the store. Examples of page permission tightening include from Present to Not Present or from Read/Write to Read Only, etc.

3. Another processor, without corresponding synchronization and TLB flush, must

cause the permission change.

Implication: This scenario may only occur on a multiprocessor platform running an operating system

that performs “lazy” TLB shootdowns. The memory image of the EFLAGS register on the

page fault handler's stack prematurely contains the final arithmetic flag values although the instruction has not yet completed. Intel has not identified any operating systems that inspect the arithmetic portion of the EFLAGS register during a page fault nor observed this erratum in laboratory testing of software applications.

Workaround: No workaround is needed upon normal restart of the instruction, since this erratum is

transparent to the faulting code and results in correct instruction behavior. Operating systems may ensure that no processor is currently accessing a page that is scheduled to have its page permissions tightened or have a page fault handler that ignores any incorrect state.

Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 21

Errata

AZ2. INVLPG Operation for Large (2M/4M) Pages May Be Incomplete under

Certain Conditions

Problem: The INVLPG instruction may not completely invalidate Translation Look-aside Buffer

(TLB) entries for large pages (2M/4M) when both of the following conditions exist:

“Address range of the page being invalidated spans several Memory Type Range

Registers (MTRRs) with different memory types specified “INVLPG operation is preceded by a Page Assist Event (Page Fault (#PF) or an access that results in either A or D bits being set in a Page Table Entry (PTE))

Implication: Stale translations may remain valid in TLB after a PTE update resulting in unpredictable

system behavior. Intel has not observed this erratum with any commercially available software.

Workaround: Software should ensure that the memory type specified in the MTRRs is the same for the

entire address range of the large page.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ3. Store to WT Memory Data May be Seen in Wrong Order by Two,

Subsequent Loads

Problem: When data of Store to WT memory is used by two, subsequent loads of one thread, and

another thread performs cacheable write to the same address, the first load may get the data from external memory or L2 written by another core, while the second load will get the data straight from the WT Store.

Implication: Software that uses WB to WT memory aliasing may violate proper store ordering. Workaround: Do not use WB to WT aliasing. Status: For the steppings affected, see the Summary Tables of Changes.

AZ4. Non-Temporal Data Store May Be Observed in Wrong Program Order

Problem: When non-temporal data is accessed by multiple read operations in one thread while

another thread performs a cacheable write operation to the same address, the data stored may be observed in wrong program order (i.e., later load operations may read older data).

Implication: Software that uses non-temporal data without proper serialization before accessing the

non-temporal data may observe data in wrong program order.

Workaround: Software that conforms to the Intel® 64 and IA-32 Architectures Software Developer's

Manual, Volume 3A, “Buffering of Write Combining Memory Locations” section will

operate correctly.

Status: For the steppings affected, see the Summary Tables of Changes.

22 Specification Update

Errata

AZ5. Page Access Bit May be Set Prior to Signaling a Code Segment Limit

Fault

Problem: If code segment limit is set close to the end of a code page, then due to this erratum the

memory page Access bit (A bit) may be set for the subsequent page prior to general protection fault on code segment limit.

Implication: When this erratum occurs, a non-accessed page which is present in memory and follows

a page that contains the code segment limit may be tagged as accessed.

Workaround: Erratum can be avoided by placing a guard page (non-present or non-executable page)

as the last page of the segment or after the page that includes the code segment limit.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ6. Updating Code Page Directory Attributes without TLB Invalidation May

Result in Improper Handling of Code #PF

Problem: Code #PF (Page Fault exception) is normally handled in lower priority order relative to

both code #DB (Debug Exception) and code Segment Limit Violation #GP (General Protection Fault). Due to this erratum, code #PF may be handled incorrectly, if all of the following conditions are met:

Implication: A PDE (Page Directory Entry) is modified without invalidating the corresponding TLB

(Translation Look-aside Buffer) entry.

1. Code execution transitions to a different code page such that both

2. The target linear address corresponds to the modified PDE

3. The PTE (Page Table Entry) for the target linear address has an A (Accessed) bit that

is clear

4. One of the following simultaneous exception conditions is present following the code

transition

5. Code #DB and code #PF

6. Code Segment Limit Violation #GP and code #PF

7. Software may observe either incorrect processing of code #PF before code Segment

Limit Violation #GP or processing of code #PF in lieu of code #DB.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 23

Errata

AZ7. Storage of PEBS Record Delayed Following Execution of MOV SS or STI

Problem: When a performance monitoring counter is configured for PEBS (Precise Event Based

Sampling), overflow of the counter results in storage of a PEBS record in the PEBS buffer. The information in the PEBS record represents the state of the next instruction to be executed following the counter overflow. Due to this erratum, if the counter overflow occurs after execution of either MOV SS or STI, storage of the PEBS record is delayed by one instruction.

Implication: When this erratum occurs, software may observe storage of the PEBS record being

delayed by one instruction following execution of MOV SS or STI. The state information in the PEBS record will also reflect the one instruction delay.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ8. Performance Monitoring Event FP_MMX_TRANS_TO_MMX May Not

Count Some Transitions

Problem: Performance Monitor Event FP_MMX_TRANS_TO_MMX (Event CCH, Umask 01H) counts

transitions from x87 Floating Point (FP) to MMX™ technology instructions. Due to this erratum, if only a small number of MMX instructions (including EMMS) are executed immediately after the last FP instruction, a FP to MMX technology transition may not be counted.

Implication: The count value for Performance Monitoring Event FP_MMX_TRANS_TO_MMX may be

lower than expected. The degree of undercounting is dependent on the occurrences of the erratum condition while the counter is active. Intel has not observed this erratum with any commercially available software.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ9. A REP STOS/MOVS to a MONITOR/MWAIT Address Range May Prevent

Triggering of the Monitoring Hardware

Problem: The MONITOR instruction is used to arm the address monitoring hardware for the

subsequent MWAIT instruction. The hardware is triggered on subsequent memory store operations to the monitored address range. Due to this erratum, REP STOS/MOVS fast string operations to the monitored address range may prevent the actual triggering store to be propagated to the monitoring hardware.

Implication: A logical processor executing an MWAIT instruction may not immediately continue

program execution if a REP STOS/MOVS targets the monitored address range.

Workaround: Software can avoid this erratum by not using REP STOS/MOVS store operations within

the monitored address range.

Status: For the steppings affected, see the Summary Tables of Changes.

24 Specification Update

Errata

AZ10. Performance Monitoring Event MISALIGN_MEM_REF May Over Count

Problem: Performance monitoring event MISALIGN_MEM_REF (05H) is used to count the number

of memory accesses that cross an 8-byte boundary and are blocked until retirement. Due to this erratum, the performance monitoring event MISALIGN_MEM_REF also counts other memory accesses.

Implication: The performance monitoring event MISALIGN_MEM_REF may over count. The extent of

the over counting depends on the number of memory accesses retiring while the counter is active.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ11. The Processor May Report a #TS Instead of a #GP Fault

Problem: A jump to a busy TSS (Task-State Segment) may cause a #TS (invalid TSS exception)

instead of a #GP fault (general protection exception).

Implication: Operation systems that access a busy TSS may get invalid TSS fault instead of a #GP

fault. Intel has not observed this erratum with any commercially available software.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ12. Code Segment Limit Violation May Occur on 4-Gigabyte Limit Check

Problem: Code Segment limit violation may occur on 4-Gigabyte limit check when the code stream

wraps around in a way that one instruction ends at the last byte of the segment and the next instruction begins at 0x0.

Implication: This is a rare condition that may result in a system hang. Intel has not observed this

erratum with any commercially available software, or system.

Workaround: Avoid code that wraps around segment limit. Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 25

Errata

AZ13. A Write to an APIC Register Sometimes May Appear to Have Not

Occurred

Problem: With respect to the retirement of instructions, stores to the uncacheable memory-based

APIC register space are handled in a non-synchronized way. For example if an instruction that masks the interrupt flag, e.g., CLI, is executed soon after an uncacheable write to the Task Priority Register (TPR) that lowers the APIC priority, the interrupt masking operation may take effect before the actual priority has been lowered. This may cause interrupts whose priority is lower than the initial TPR, but higher than the final TPR, to not be serviced until the interrupt enabled flag is finally set, i.e. by STI instruction. Interrupts will remain pending and are not lost.

Implication: In this example the processor may allow interrupts to be accepted but may delay their

service.

Workaround: This non-synchronization can be avoided by issuing an APIC register read after the APIC

register write. This will force the store to the APIC register before any subsequent instructions are executed. No commercial operating system is known to be impacted by this erratum.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ14. Last Branch Records (LBR) Updates May Be Incorrect after a Task

Switch

Problem: A Task-State Segment (TSS) task switch may incorrectly set the LBR_FROM value to the

LBR_TO value.

Implication: The LBR_FROM will have the incorrect address of the Branch Instruction. Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

26 Specification Update

Errata

AZ15. REP MOVS/STOS Executing with Fast Strings Enabled and Crossing Page

Boundaries with Inconsistent Memory Types May Use an Incorrect Data Size or Lead to Memory-Ordering Violations

Problem: Under certain conditions as described in the Intel® 64 and IA-32 Architectures Software

Developer's Manual, Volume 3A section “Out-of-Order Stores for String Operations in

Pentium 4, Intel Xeon, and P6 Family Processors” the processor performs REP MOVS or

REP STOS as fast strings. Due to this erratum fast string REP MOVS/REP STOS instructions that cross page boundaries from WB/WC memory types to UC/WP/WT memory types, may start using an incorrect data size or may observe memory ordering violations.

Implication: Upon crossing the page boundary the following may occur, dependent on the new page

memory type:

 UC the data size of each write will now always be 8 bytes, as opposed to the original

data size.

 WP the data size of each write will now always be 8 bytes, as opposed to the original

data size and there may be a memory ordering violation.

 WT there may be a memory ordering violation.

Workaround: Software should avoid crossing page boundaries from WB or WC memory type to UC, WP

or WT memory type within a single REP MOVS or REP STOS instruction that will execute with fast strings enabled.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ16. Upper 32 bits of “From” Address Reported through BTMs or BTSs May

Be Incorrect

Problem: When a far transfer switches the processor from 32-bit mode to IA-32e mode, the upper

32 bits of the “From” (source) addresses reported through the BTMs (Branch Trace Messages) or BTSs (Branch Trace Stores) may be incorrect.

Implication: The upper 32 bits of the 'From' address debug information reported through BTMs or

BTSs may be incorrect during this transition.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 27

Errata

AZ17. Address Reported by Machine-Check Architecture (MCA) on Single-bit

L2 ECC Errors May Be Incorrect

Problem: When correctable Single-bit ECC errors occur in the L2 cache, the address is logged in

the MCA address register (MCi_ADDR). Under some scenarios, the address reported may be incorrect.

Implication: Software should not rely on the value reported in MCi_ADDR, for Single-bit L2 ECC

errors.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ18. Code Segment Limit/Canonical Faults on RSM May be Serviced before

Higher Priority Interrupts/Exceptions

Problem: Normally, when the processor encounters a Segment Limit or Canonical Fault due to code

execution, a #GP (General Protection Exception) fault is generated after all higher priority Interrupts and exceptions are serviced. Due to this erratum, if RSM (Resume from System Management Mode) returns to execution flow that results in a Code Segment Limit or Canonical Fault, the #GP fault may be serviced before a higher priority Interrupt or Exception (e.g., NMI (Non-Maskable Interrupt), Debug break (#DB), Machine Check (#MC), etc.)

Implication: Operating systems may observe a #GP fault being serviced before higher priority

Interrupts and Exceptions. Intel has not observed this erratum on any commercially available software.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ19. Store Ordering May be Incorrect between WC and WP Memory Type

Problem: According to Intel® 64 and IA-32 Intel Architecture Software Developer's Manual,

Volume 3A “Methods of Caching Available”, WP (Write Protected) stores should drain the

WC (Write Combining) buffers in the same way as UC (Uncacheable) memory type stores do. Due to this erratum, WP stores may not drain the WC buffers.

Implication: Memory ordering may be violated between WC and WP stores. Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

28 Specification Update

Errata

AZ20. EFLAGS, CR0, CR4 and the EXF4 Signal May Be Incorrect after Shutdown

Problem: When the processor is going into shutdown due to an RSM inconsistency failure, EFLAGS,

CR0 and CR4 may be incorrect. In addition the EXF4 signal may still be asserted. This may be observed if the processor is taken out of shutdown by NMI#.

Implication: A processor that has been taken out of shutdown may have an incorrect EFLAGS, CR0

and CR4. In addition the EXF4 signal may still be asserted.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ21. Premature Execution of a Load Operation Prior to Exception Handler

Invocation

Problem: If any of the below circumstances occur, it is possible that the load portion of the

instruction will have executed before the exception handler is entered:

 If an instruction that performs a memory load causes a code segment limit violation.  If a waiting X87 floating-point (FP) instruction or MMX™ technology (MMX)

instruction that performs a memory load has a floating-point exception pending.

 If an MMX or SSE/SSE2/SSE3/SSSE3 extensions (SSE) instruction that performs a

memory load and has either CR0.EM=1 (Emulation bit set), or a floating-point Topof-Stack (FP TOS) not equal to 0, or a DNA exception pending.

Implication: In normal code execution where the target of the load operation is to write back memory

there is no impact from the load being prematurely executed, or from the restart and subsequent re-execution of that instruction by the exception handler. If the target of the load is to uncached memory that has a system side-effect, restarting the instruction may cause unexpected system behavior due to the repetition of the side-effect. Particularly, while CR0.TS [bit 3] is set, a MOVD/MOVQ with MMX/XMM register operands may issue a memory load before getting the DNA exception.

Workaround: Code which performs loads from memory that has side-effects can effectively

workaround this behavior by using simple integer-based load instructions when accessing side-effect memory and by ensuring that all code is written such that a code segment limit violation cannot occur as a part of reading from side-effect memory.

Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 29

Errata

AZ22. Performance Monitoring Events for Retired Instructions (C0H) May Not

Be Accurate

Problem: The INST_RETIRED performance monitor may miscount retired instructions as follows:

 Repeat string and repeat I/O operations are not counted when a hardware interrupt

is received during or after the last iteration of the repeat flow.

 VMLAUNCH and VMRESUME instructions are not counted.  HLT and MWAIT instructions are not counted. The following instructions, if executed

during HLT or MWAIT events, are also not counted: a) RSM from a C-state SMI during an MWAIT instruction. b) RSM from an SMI during a HLT instruction.

Implication: There may be a smaller than expected value in the INST_RETIRED performance

monitoring counter. The extent to which this value is smaller than expected is determined by the frequency of the above cases.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ23. Returning to Real Mode from SMM with EFLAGS.VM Set May Result in

Unpredictable System Behavior

Problem: Returning back from SMM mode into real mode while EFLAGS.VM is set in SMRAM may

result in unpredictable system behavior.

Implication: If SMM software changes the values of the EFLAGS.VM in SMRAM, it may result in

unpredictable system behavior. Intel has not observed this behavior in commercially available software.

Workaround: SMM software should not change the value of EFLAGS.VM in SMRAM. Status: For the steppings affected, see the Summary Tables of Changes.

30 Specification Update

Errata

AZ24. CMPSB, LODSB, or SCASB in 64-bit Mode with Count Greater or Equal to

248 May Terminate Early

Problem: In 64-bit Mode CMPSB, LODSB, or SCASB executed with a repeat prefix and count

greater than or equal to 248 may terminate early. Early termination may result in one of the following.

 The last iteration not being executed  Signaling of a canonical limit fault (#GP) on the last iteration

Implication: While in 64-bit mode, with count greater or equal to 248, repeat string operations

CMPSB, LODSB or SCASB may terminate without completing the last iteration. Intel has not observed this erratum with any commercially available software.

Workaround: Do not use repeated string operations with RCX greater than or equal to 2

Status: For the steppings affected, see the Summary Tables of Changes.

AZ25. Writing the Local Vector Table (LVT) When an Interrupt Is Pending May

Cause an Unexpected Interrupt

Problem: If a local interrupt is pending when the LVT entry is written, an interrupt may be taken

on the new interrupt vector even if the mask bit is set.

Implication: An interrupt may immediately be generated with the new vector when a LVT entry is

written, even if the new LVT entry has the mask bit set. If there is no Interrupt Service Routine (ISR) set up for that vector the system will GP fault. If the ISR does not do an End of Interrupt (EOI) the bit for the vector will be left set in the in-service register and mask all interrupts at the same or lower priority.

Workaround: Any vector programmed into an LVT entry must have an ISR associated with it, even if

that vector was programmed as masked. This ISR routine must do an EOI to clear any unexpected interrupts that may occur. The ISR associated with the spurious vector does not generate an EOI, therefore the spurious vector should not be used when writing the LVT.

Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 31

Errata

AZ26. Pending x87 FPU Exceptions (#MF) Following STI May Be Serviced

before Higher Priority Interrupts

Problem: Interrupts that are pending prior to the execution of the STI (Set Interrupt Flag)

instruction are serviced immediately after the STI instruction is executed. Because of this erratum, if following STI, an instruction that triggers a #MF is executed while STPCLK#, Enhanced Intel SpeedStep® Technology transitions or Thermal Monitor 1 events occur, the pending #MF may be serviced before higher priority interrupts.

Software may observe #MF being serviced before higher priority interrupts.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ27. VERW/VERR/LSL/LAR Instructions May Unexpectedly Update the Last

Exception Record (LER) MSR

Problem: The LER MSR may be unexpectedly updated, if the resultant value of the Zero Flag (ZF)

is zero after executing the following instructions:

1. VERR (ZF=0 indicates unsuccessful segment read verification)

2. VERW (ZF=0 indicates unsuccessful segment write verification)

3. LAR (ZF=0 indicates unsuccessful access rights load)

4. LSL (ZF=0 indicates unsuccessful segment limit load)

Implication: The value of the LER MSR may be inaccurate if VERW/VERR/LSL/LAR instructions are

executed after the occurrence of an exception.

Workaround: Software exception handlers that rely on the LER MSR value should read the LER MSR

before executing VERW/VERR/LSL/LAR instructions.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ28. INIT Does Not Clear Global Entries in the TLB

Problem: INIT may not flush a TLB entry when:

 The processor is in protected mode with paging enabled and the page global enable

flag is set (PGE bit of CR4 register)

 G bit for the page table entry is set  TLB entry is present in TLB when INIT occurs  Software may encounter unexpected page fault or incorrect address translation due

to a TLB entry erroneously left in TLB after INIT.

Workaround: Write to CR3, CR4 (setting bits PSE, PGE or PAE) or CR0 (setting bits PG or PE) registers

before writing to memory early in BIOS code to clear all the global entries from TLB.

Status: For the steppings affected, see the Summary Tables of Changes.

32 Specification Update

Errata

AZ29. Split Locked Stores May Not Trigger the Monitoring Hardware

Problem: Logical processors normally resume program execution following the MWAIT, when

another logical processor performs a write access to a WB cacheable address within the address range used to perform the MONITOR operation. Due to this erratum, a logical processor may not resume execution until the next targeted interrupt event or O/S timer tick following a locked store that spans across cache lines within the monitored address range.

Implication: The logical processor that executed the MWAIT instruction may not resume execution

until the next targeted interrupt event or O/S timer tick in the case where the monitored address is written by a locked store which is split across cache lines.

Workaround: Do not use locked stores that span cache lines in the monitored address range. Status: For the steppings affected, see the Summary Tables of Changes.

AZ30. Programming the Digital Thermal Sensor (DTS) Threshold May Cause

Unexpected Thermal Interrupts

Problem: Software can enable DTS thermal interrupts by programming the thermal threshold and

setting the respective thermal interrupt enable bit. When programming DTS value, the previous DTS threshold may be crossed. This will generate an unexpected thermal interrupt.

Implication: Software may observe an unexpected thermal interrupt occur after reprogramming the

thermal threshold.

Workaround: In the ACPI/OS implement a workaround by temporarily disabling the DTS threshold

interrupt before updating the DTS threshold value.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ31. Writing Shared Unaligned Data that Crosses a Cache Line without

Proper Semaphores or Barriers May Expose a Memory Ordering Issue

Problem: Software which is written so that multiple agents can modify the same shared unaligned

memory location at the same time may experience a memory ordering issue if multiple loads access this shared data shortly thereafter. Exposure to this problem requires the use of a data write which spans a cache line boundary.

Implication: This erratum may cause loads to be observed out of order. Intel has not observed this

erratum with any commercially available software or system.

Workaround: Software should ensure at least one of the following is true when modifying shared data

by multiple agents:

 The shared data is aligned  Proper semaphores or barriers are used in order to prevent concurrent data

accesses.

Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 33

Errata

AZ32. General Protection (#GP) Fault May Not Be Signaled on Data Segment

Limit Violation above 4-G Limit

Problem: In 32-bit mode, memory accesses to flat data segments (base = 00000000h) that occur

above the 4G limit (0ffffffffh) may not signal a #GP fault.

Implication: When such memory accesses occur in 32-bit mode, the system may not issue a #GP

fault.

Workaround: Software should ensure that memory accesses in 32-bit mode do not occur above the 4-

G limit (0ffffffffh).

Status: For the steppings affected, see the Summary Tables of Changes.

AZ33. An Asynchronous MCE during a Far Transfer May Corrupt ESP

Problem: If an asynchronous machine check occurs during an interrupt, call through gate, FAR RET

or IRET and in the presence of certain internal conditions, ESP may be corrupted.

Implication: If the MCE (Machine Check Exception) handler is called without a stack switch, then a

triple fault will occur due to the corrupted stack pointer, resulting in a processor shutdown. If the MCE is called with a stack switch, e.g., when the CPL (Current Privilege Level) was changed or when going through an interrupt task gate, then the corrupted ESP will be saved on the new stack or in the TSS (Task State Segment), and will not be used.

Workaround: Use an interrupt task gate for the machine check handler. Status: For the steppings affected, see the Summary Tables of Changes.

AZ34. CPUID Reports Architectural Performance Monitoring Version 2 Is

Supported, When Only Version 1 Capabilities Are Available

Problem: CPUID leaf 0Ah reports the architectural performance monitoring version that is available

in EAX[7:0]. Due to this erratum CPUID reports the supported version as 2 instead of 1.

Implication: Software will observe an incorrect version number in CPUID.0Ah.EAX [7:0] in comparison

to which features are actually supported.

Workaround: Software should use the recommended enumeration mechanism described in the

Architectural Performance Monitoring section of the Intel® 64 and IA-32 Architectures

Software Developer's Manual, Volume 3: System Programming Guide.

Status: For the steppings affected, see the Summary Tables of Changes.

34 Specification Update

Errata

AZ35. B0-B3 Bits in DR6 May Not Be Properly Cleared after Code Breakpoint

Problem: B0-B3 bits (breakpoint conditions detect flags, bits [3:0]) in DR6 may not be properly

cleared when the following sequence happens:

1. POP instruction to SS (Stack Segment) selector;

2. Next instruction is FP (Floating Point) that gets FP assist followed by code breakpoint.

Implication: B0-B3 bits in DR6 may not be properly cleared. Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ36. An xTPR Update Transaction Cycle, If Enabled, May Be Issued to the

FSB after the Processor has Issued a Stop-Grant Special Cycle

Problem: According to the FSB (Front Side Bus) protocol specification, no FSB cycles should be

issued by the processor once a Stop-Grant special cycle has been issued to the bus. If xTPR update transactions are enabled by clearing the IA32_MISC_ENABLES[bit 23] at the time of Stop-Clock assertion, an xTPR update transaction cycle may be issued to the FSB after the processor has issued a Stop Grant Acknowledge transaction.

Implication: When this erratum occurs in systems using C-states C2 (Stop-Grant State) and higher

the result could be a system hang.

Workaround: BIOS must leave the xTPR update transactions disabled (default). Status: For the steppings affected, see the Summary Tables of Changes.

AZ37. Performance Monitoring Event IA32_FIXED_CTR2 May Not Function

Properly When Max Ratio Is a Non-Integer Core-to-Bus Ratio

Problem: Performance Counter IA32_FIXED_CTR2 (MSR 30BH) event counts CPU reference clocks

when the core is not in a halt state. This event is not affected by core frequency changes (e.g., P states, TM2 transitions) but counts at the same frequency as the Time-Stamp Counter IA32_TIME_STAMP_COUNTER (MSR 10H). Due to this erratum, the IA32_FIXED_CTR2 will not function properly when the non-integer core-to-bus ratio multiplier feature is used and when a non-zero value is written to IA32_ FIXED_CTR2. Non-integer core-to-bus ratio enables additional operating frequencies. This feature can be detected by IA32_PLATFORM_ID (MSR 17H) bit [23].

Implication: The Performance Monitoring Event IA32_FIXED_CTR2 may result in an inaccurate count

when the non-integer core-to-bus multiplier feature is used.

Workaround: If writing to IA32_FIXED_CTR2 and using a non-integer core-to-bus ratio multiplier,

always write a zero.

Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 35

Errata

AZ38. Instruction Fetch May Cause a Livelock during Snoops of the L1 Data

Cache

Problem: A livelock may be observed in rare conditions when instruction fetch causes multiple level

one data cache snoops.

Due to this erratum, a livelock may occur. Intel has not observed this erratum with any commercially available software.

Workaround: It is possible for BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

AZ39. Use of Memory Aliasing with Inconsistent Memory Type May Cause a

System Hang or a Machine Check Exception

Problem: Software that implements memory aliasing by having more than one linear addresses

mapped to the same physical page with different cache types may cause the system to hang or to report a machine check exception (MCE). This would occur if one of the addresses is non-cacheable and used in a code segment and the other is a cacheable address. If the cacheable address finds its way into the instruction cache, and the noncacheable address is fetched in the IFU, the processor may invalidate the non-cacheable address from the fetch unit. Any micro-architectural event that causes instruction restart will be expecting this instruction to still be in the fetch unit and lack of it will cause a system hang or an MCE.

Implication: This erratum has not been observed with commercially available software. Workaround: Although it is possible to have a single physical page mapped by two different linear

addresses with different memory types, Intel has strongly discouraged this practice as it may lead to undefined results. Software that needs to implement memory aliasing should manage the memory type consistency.

Status: For the steppings affected, see the Summary Tables of Changes.

36 Specification Update

Errata

AZ40. A WB Store Following a REP STOS/MOVS or FXSAVE May Lead to

Memory-Ordering Violations

Problem: Under certain conditions, as described in the Software Developers Manual section “Out-

of-Order Stores For String Operations in Pentium 4, Intel Xeon, and P6 Family

Processors”, the processor may perform REP MOVS or REP STOS as write combining

stores (referred to as “fast strings”) for optimal performance. FXSAVE may also be internally implemented using write combining stores. Due to this erratum, stores of a WB (write back) memory type to a cache line previously written by a preceding fast string/FXSAVE instruction may be observed before string/FXSAVE stores.

Implication: A write-back store may be observed before a previous string or FXSAVE related store.

Intel has not observed this erratum with any commercially available software.

Workaround: Software desiring strict ordering of string/FXSAVE operations relative to subsequent

write-back stores should add an MFENCE or SFENCE instruction between the string/ FXSAVE operation and following store-order sensitive code such as that used for synchronization.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ41. VM Exit with Exit Reason “TPR Below Threshold” Can Cause the

Blocking by MOV/POP SS and Blocking by STI Bits to be Cleared in the Guest Interruptibility-State Field

Problem: As specified in Section, “VM Exits Induced by the TPR Shadow”, in the Intel® 64 and IA-

32 Architectures Software Developer's Manual, Volume 3B, a VM exit occurs immediately

after any VM entry performed with the “use TPR shadow”, “activate secondary controls”, and “virtualize APIC accesses” VM-execution controls all set to 1 and with the value of

the TPR shadow (bits 7:4 in byte 80H of the virtual-APIC page) less than the TPRthreshold VM-execution control field. Due to this erratum, such a VM exit will clear bit 0 (blocking by STI) and bit 1 (blocking by MOV/POP SS) of the interruptibility-state field of the guest-state area of the VMCS (bit 0 - blocking by STI and bit 1 - blocking by MOV/POP SS should be left unmodified).

Implication: Since the STI, MOV SS, and POP SS instructions cannot modify the TPR shadow, bits 1:0

of the interruptibility-state field will usually be zero before any VM entry meeting the preconditions of this erratum; behavior is correct in this case. However, if VMM software raises the value of the TPR-threshold VM-execution control field above that of the TPR shadow while either of those bits is 1, incorrect behavior may result. This may lead to VMM software prematurely injecting an interrupt into a guest. Intel has not observed this erratum with any commercially available software.

Workaround: VMM software raising the value of the TPR-threshold VM-execution control field should

compare it to the TPR shadow. If the threshold value is higher, software should not perform a VM entry; instead, it could perform the actions that it would normally take in response to a VM exit with exit reason “TPR below threshold”.

Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 37

Errata

AZ42. Using Memory Type Aliasing with Cacheable and WC Memory Types May

Lead to Memory Ordering Violations

Problem: Memory type aliasing occurs when a single physical page is mapped to two or more

different linear addresses, each with different memory types. Memory type aliasing with a cacheable memory type and WC (write combining) may cause the processor to perform incorrect operations leading to memory ordering violations for WC operations.

Implication: Software that uses aliasing between cacheable and WC memory types may observe

memory ordering errors within WC memory operations. Intel has not observed this erratum with any commercially-available software.

Workaround: None identified. Intel does not support the use of cacheable and WC memory type

aliasing, and WC operations are defined as weakly ordered.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ43. VM Exit Caused by a SIPI Results in Zero Being Saved to the Guest RIP

Field in the VMCS

Problem: If a logical processor is in VMX non-root operation and in the wait-for-SIPI state, an

occurrence of a start-up IPI (SIPI) causes a VM exit. Due to this erratum, such VM exits always save zero into the RIP field of the guest-state area of the virtual-machine control structure (VMCS) instead of the value of RIP before the SIPI was received.

Implication: In the absence of virtualization, a SIPI received by a logical processor in the wait-for-

SIPI state results in the logical processor starting execution from the vector sent in the SIPI regardless of the value of RIP before the SIPI was received. A virtual-machine monitor (VMM) responding to a SIPI-induced VM exit can emulate this behavior because the SIPI vector is saved in the lower 8 bits of the exit qualification field in the VMCS. Such a VMM should be unaffected by this erratum. A VMM that does not emulate this behavior may need to recover the old value of RIP through alternative means. Intel has not observed this erratum with any commercially-available software.

Workaround: VMM software that may respond to SIPI-induced VM exits by resuming the interrupt

guest context without emulating the non-virtualized SIPI response should (1) save from the VMCS (using VMREAD) the value of RIP before any VM entry to the wait-for SIPI state; and (2) restore to the VMCS (using VMWRITE) that value before the next VM entry that resumes the guest in any state other than wait-for-SIPI.

Status: For the steppings affected, see the Summary Tables of Changes.

38 Specification Update

Errata

AZ44. NMIs May Not Be Blocked by a VM-Entry Failure

Problem: The Intel® 64 and IA-32 Architectures Software Developer's Manual, Volume 3B: System

Programming Guide, Part 2 specifies that, following a VM-entry failure during or after

loading guest state, “the state of blocking by NMI is what it was before VM entry.” If non-maskable interrupts (NMIs) are blocked and the “virtual NMIs” VM-execution control set to 1, this erratum may result in NMIs not being blocked after a VM-entry failure during or after loading guest state.

Implication: VM-entry failures that cause NMIs to become unblocked may cause the processor to

deliver an NMI to software that is not prepared for it.

Workaround: VMM software should configure the virtual-machine control structure (VMCS) so that VM-

entry failures do not occur.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ45. Partial Streaming Load Instruction Sequence May Cause the Processor

to Hang

Problem: Under some rare conditions, when multiple streaming load instructions (MOVNTDQA) are

mixed with non-streaming loads that split across cache lines, the processor may hang.

Implication: Under the scenario described above, the processor may hang. Intel has not observed this

erratum with any commercially available software.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. However, streaming

behavior may be re-enabled by setting bit 5 to 1 of the MSR at address 0x21 for software development or testing purposes. If this bit is changed, then a read-modify-write should be performed to preserve other bits of this MSR. When the streaming behavior is enabled and using streaming load instructions, always consume a full cache line worth of data and/or avoid mixing them with non-streaming memory references. If streaming loads are used to read partial cache lines, and mixed with non-streaming memory references, use fences to isolate the streaming load operations from non-streaming memory operations.

Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 39

Errata

AZ46. Self/Cross Modifying Code May Not be Detected or May Cause a Machine

Check Exception

Problem: If instructions from at least three different ways in the same instruction cache set exist in

the pipeline combined with some rare internal state, self-modifying code (SMC) or crossmodifying code may not be detected and/or handled.

Implication: An instruction that should be overwritten by another instruction while in the processor

pipeline may not be detected/modified, and could retire without detection. Alternatively the instruction may cause a Machine Check Exception. Intel has not observed this erratum with any commercially available software.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

AZ47. Data TLB Eviction Condition in the Middle of a Cacheline Split Load

Operation May Cause the Processor to Hang

Problem: If the TLB translation gets evicted while completing a cacheline split load operation,

under rare scenarios the processor may hang.

Implication: The cacheline split load operation may not be able to complete normally, and the

machine may hang and generate Machine Check Exception. Intel has not observed this erratum with any commercially available software.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

AZ48. Update of Read/Write (R/W) or User/Supervisor (U/S) or Present (P)

Bits without TLB Shootdown May Cause Unexpected Processor Behavior

Problem: Updating a page table entry by changing R/W, U/S or P bits, even when transitioning

these bits from 0 to 1, without keeping the affected linear address range coherent with all TLB (Translation Lookaside Buffers) and paging-structures caches in the processor, in conjunction with a complex sequence of internal processor micro-architectural events and store operations, may lead to unexpected processor behavior.

Implication: This erratum may lead to livelock, shutdown or other unexpected processor behavior.

Intel has not observed this erratum with any commercially available software.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

40 Specification Update

Errata

AZ49. RSM Instruction Execution under Certain Conditions May Cause

Processor Hang or Unexpected Instruction Execution Results

Problem: Problem: RSM instruction execution, under certain conditions triggered by a complex

sequence of internal processor micro-architectural events, may lead to processor hang, or unexpected instruction execution results.

Implication: In the above sequence, the processor may live lock or hang, or RSM instruction may

restart the interrupted processor context through a nondeterministic EIP offset in the code segment, resulting in unexpected instruction execution, unexpected exceptions or system hang. Intel has not observed this erratum with any commercially available software.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

AZ50. Benign Exception after a Double Fault May Not Cause a Triple Fault

Shutdown

Problem: According to the Intel® 64 and IA-32 Architectures Software Developer's Manual,

Volume 3A, “Exception and Interrupt Reference”, if another exception occurs while

attempting to call the double-fault handler, the processor enters shutdown mode. Due to this erratum, any benign faults while attempting to call double-fault handler will not cause a shutdown. However Contributory Exceptions and Page Faults will continue to cause a triple fault shutdown.

Implication: If a benign exception occurs while attempting to call the double-fault handler, the

processor may hang or may handle the benign exception. Intel has not observed this erratum with any commercially available software.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 41

Errata

AZ51. LER MSRs May Be Incorrectly Updated

Problem: The LER (Last Exception Record) MSRs, MSR_LER_FROM_LIP (1DDH) and

MSR_LER_TO_LIP (1DEH) may contain incorrect values after any of the following:

 Either STPCLK#, NMI (NonMaskable Interrupt) or external interrupts  CMP or TEST instructions with an uncacheable memory operand followed by a

conditional jump

 STI/POP SS/MOV SS instructions followed by CMP or TEST instructions and then by a

conditional jump

Implication: When the conditions for this erratum occur, the value of the LER MSRs may be

incorrectly updated.

Workaround: None identified Status: For the steppings affected, see the Summary Tables of Changes.

AZ52. Processor May Unexpectedly Assert False THERMTRIP# after Receiving

a Warm Reset

Problem: Some processors may unexpectedly assert a false THERMTRIP# after a warm reset under

certain environmental and operating conditions. Intel has observed this on a limited number of parts when they are operating at a core-to-bus ratio different from the ratio used at power-on. The issue is due to a thermal sensor circuit timing marginality event that causes the sensor to initiate a thermal shutdown. Under these conditions, upon RESET# assertion, some processors may assert a false THERMTRIP# even though their temperature is below normal THERMTRIP# activation temperature. A warm reset is different from a cold/power-on reset in that PWRGOOD remains active throughout the assertion of RESET#.

Implication: This issue may be observed during warm reset cycle testing or during the process of

repeatedly entering and exiting the S3/S4/S5 sleep states. When this issue occurs, the processor may proceed with a thermal shutdown signaled by the assertion of processor THERMTRIP# and the platform will remove power from the CPU or the entire platform.

Workaround: A BIOS update can be implemented to address this erratum. The workaround found in

the BIOS requires that the processor transition to Low Frequency mode before a warm reset. Please contact your local Intel representative for more information.

Note: This workaround does not cover all system configurations where warm resets are

initiated by Intel® AMT.

Status: For the steppings affected, see the Summary Tables of Changes.

42 Specification Update

Errata

AZ53. Short Nested Loops That Span Multiple 16-Byte Boundaries May Cause a

Machine Check Exception or a System Hang

Problem: Under a rare set of timing conditions and address alignment of instructions in a short

nested loop sequence, software that contains multiple conditional jump instructions and spans multiple 16-byte boundaries, may cause a machine check exception or a system hang.

Implication: Due to this erratum, a machine check exception or a system hang may occur. Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

AZ54. IA32_MC1_STATUS MSR Bit[60] Does Not Reflect Machine Check Error

Reporting Enable Correctly

Problem: IA32_MC1_STATUS MSR (405H) bit[60] (EN- Error Enabled) is supposed to indicate

whether the enable bit in the IA32_MC1_CTL MSR (404H) was set at the time of the last update to the IA32_MC1_STATUS MSR. Due to this erratum, IA32_MC1_STATUS MSR bit[60] instead reports the current value of the IA32_MC1_CTL MSR enable bit.

Implication: IA32_MC1_STATUS MSR bit [60] may not reflect the correct state of the enable bit in the

IA32_MC1_CTL MSR at the time of the last update.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 43

Errata

AZ55. An Enabled Debug Breakpoint or Single Step Trap May Be Taken after

MOV SS/POP SS Instruction if it is Followed by an Instruction That Signals a Floating Point Exception

Problem: A MOV SS/POP SS instruction should inhibit all interrupts including debug breakpoints

until after execution of the following instruction. This is intended to allow the sequential execution of MOV SS/POP SS and MOV [r/e]SP, [r/e]BP instructions without having an invalid stack during interrupt handling. However, an enabled debug breakpoint or single step trap may be taken after MOV SS/POP SS if this instruction is followed by an instruction that signals a floating point exception rather than a MOV [r/e]SP, [r/e]BP instruction. This results in a debug exception being signaled on an unexpected instruction boundary since the MOV SS/POP SS and the following instruction should be executed atomically.

Implication: This can result in incorrect signaling of a debug exception and possibly a mismatched

Stack Segment and Stack Pointer. If MOV SS/POP SS is not followed by a MOV [r/e]SP, [r/e]BP, there may be a mismatched Stack Segment and Stack Pointer on any exception. Intel has not observed this erratum with any commercially available software, or system.

Workaround: As recommended in the IA32 Intel® Architecture Software Developer‟s Manual, the use

of MOV SS/POP SS in conjunction with MOV [r/e]SP, [r/e]BP will avoid the failure since the MOV [r/e]SP, [r/e]BP will not generate a floating point exception. Developers of debug tools should be aware of the potential incorrect debug event signaling created by this erratum.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ56. Code Segment Limit/Canonical Faults on RSM May be Serviced before

Higher Priority Interrupts/Exceptions and May Push the Wrong Address Onto the Stack

Problem: Normally, when the processor encounters a Segment Limit or Canonical Fault due to code

execution, a #GP (General Protection Exception) fault is generated after all higher priority Interrupts and exceptions are serviced. Due to this erratum, if RSM (Resume from System Management Mode) returns to execution flow that results in a Code Segment Limit or Canonical Fault, the #GP fault may be serviced before a higher priority Interrupt or Exception (e.g. NMI (Non-Maskable Interrupt), Debug break(#DB), Machine Check (#MC), etc.). If the RSM attempts to return to a non-canonical address, the address pushed onto the stack for this #GP fault may not match the non-canonical address that caused the fault.

Implication: Operating systems may observe a #GP fault being serviced before higher priority

Interrupts and Exceptions. Intel has not observed this erratum on any commercially available software.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

44 Specification Update

Errata

AZ57. A VM Exit Due to a Fault While Delivering a Software Interrupt May

Save Incorrect Data into the VMCS

Problem: If a fault occurs during delivery of a software interrupt (INTn) in virtual-8086 mode when

virtual mode extensions are in effect and that fault causes a VM exit, incorrect data may be saved into the VMCS. Specifically, information about the software interrupt may not be reported in the IDT-vectoring information field. In addition, the interruptibility-state field may indicate blocking by STI or by MOV SS if such blocking were in effect before execution of the INTn instruction or before execution of the VM-entry instruction that injected the software interrupt.

Implication: In general, VMM software that follows the guidelines given in the section “Handling VM

Exits Due to Exceptions” of Intel® 64 and IA-32 Architectures Software Developer’s

Manual Volume 3B: System Programming Guide should not be affected. If the erratum improperly causes indication of blocking by STI or by MOV SS, the ability of a VMM to inject an interrupt may be delayed by one instruction.

Workaround: VMM software should follow the guidelines given in the section “Handling VM Exits Due to

Exceptions” of Intel® 64 and IA-32 Architectures Software Developer’s Manual Volume

3B: System Programming Guide.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ58. A VM Exit Occurring in IA-32e Mode May Not Produce a VMX Abort

When Expected

Problem: If a VM exit occurs while the processor is in IA-32e mode and the “host address-space

size” VM-exit control is 0, a VMX abort should occur. Due to this erratum, the expected

VMX aborts may not occur and instead the VM Exit will occur normally. The conditions

required to observe this erratum are a VM entry that returns from SMM with the “IA-32e guest” VM-entry control set to 1 in the SMM VMCS and the “host address-space size” VM-

exit control cleared to 0 in the executive VMCS.

Implication: A VM Exit will occur when a VMX Abort was expected. Workaround: An SMM VMM should always set the “IA-32e guest” VM-entry control in the SMM VMCS to

be the value that was in the LMA bit (IA32_EFER.LMA.LMA[bit 10]) in the IA32_EFER MSR (C0000080H) at the time of the last SMM VM exit. If this guideline is followed, that value will be 1 only if the “host address-space size” VM-exit control is 1 in the executive VMCS.

Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 45

Errata

AZ59. IRET under Certain Conditions May Cause an Unexpected Alignment

Check Exception

Problem: In IA-32e mode, it is possible to get an Alignment Check Exception (#AC) on the IRET

instruction even though alignment checks were disabled at the start of the IRET. This can only occur if the IRET instruction is returning from CPL3 code to CPL3 code. IRETs from CPL0/1/2 are not affected. This erratum can occur if the EFLAGS value on the stack has the AC flag set, and the interrupt handler's stack is misaligned. In IA-32e mode, RSP is aligned to a 16-byte boundary before pushing the stack frame.

Implication: In IA-32e mode, under the conditions given above, an IRET can get a #AC even if

alignment checks are disabled at the start of the IRET. This erratum can only be observed with a software generated stack frame.

Workaround: Software should not generate misaligned stack frames for use with IRET. Status: For the steppings affected, see the Summary Tables of Changes.

AZ60. Thermal Interrupts are Dropped During and While Exiting Intel® Deep

Power-Down State

Problem: Thermal interrupts are ignored while the processor is in Intel Deep Power-Down State as

well as during a small window of time while exiting from Intel Deep Power-Down State. During this window, if the PROCHOT signal is driven or the internal value of the sensor reaches the programmed thermal trip point, then the associated thermal interrupt may be lost.

Implication: In the event of a thermal event while a processor is waking up from Intel Deep Power-

Down State, the processor will initiate an appropriate throttle response. However, the associated thermal interrupt generated may be lost.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

46 Specification Update

Errata

AZ61. Entry May Fail When Attempting to Set

IA32_DEBUGCTL.FREEZE_WHILE_SMM_EN

Problem: If bit 14 (FREEZE_WHILE_SMM_EN) is set in the IA32_DEBUGCTL field in the guest-state

area of the VMCS, VM entry may fail as described in Section “VM-Entry Failures During or After Loading Guest State” of Intel® 64 and IA-32 Architectures Software Developer‟s

Manual Volume 3B: System Programming Guide, Part 2. (The exit reason will be 80000021H and the exit qualification will be zero.) Note that the FREEZE_WHILE_SMM_EN bit in the guest IA32_DEBUGCTL field may be set due to a VMWRITE to that field or due to a VM exit that occurs while IA32_DEBUGCTL.FREEZE_WHILE_SMM_EN=1.

Implication: A VMM will not be able to properly virtualize a guest using the FREEZE_WHILE_SMM

feature.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Alternatively, the

following software workaround may be used. If a VMM wants to use the FREEZE_WHILE_SMM feature, it can configure an entry in the VM-entry MSR-load area for the IA32_DEBUGCTL MSR (1D9H); the value in the entry should set the FREEZE_WHILE_SMM_EN bit. In addition, the VMM should use VMWRITE to clear the FREEZE_WHILE_SMM_EN bit in the guest IA32_DEBUGCTL field before every VM entry. (It is necessary to do this before every VM entry because each VM exit will save that bit as 1.) This workaround prevents the VM-entry failure and sets the FREEZE_WHILE_SMM_EN bit in the IA32_DEBUGCTL MSR.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ62. VM Entry May Use Wrong Address to Access Virtual-APIC Page

Problem: When XFEATURE_ENABLED_MASK register (XCR0) bit 1 (SSE) is 1, a VM entry executed

with the "use TPR shadow" VM-execution control set to 1 may use the wrong address to access data on the virtual-APIC page.

Implication: An affected VM entry may exhibit the following behaviors: (1) it may use wrong areas of

the virtual-APIC page to determine whether VM entry fails or whether it induces a VM exit due to the TPR threshold; or (2) it may clear wrong areas of the virtual-APIC page.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 47

Errata

AZ63. INIT Incorrectly Resets IA32_LSTAR MSR

Problem: In response to an INIT reset initiated either via the INIT# pin or an IPI (Inter Processor

Interrupt), the processor should leave MSR values unchanged. Due to this erratum IA32_LSTAR MSR (C0000082H), which is used by the iA32e SYSCALL instruction, is being cleared by an INIT reset.

Implication: If software programs a value in IA32_LSTAR to be used by the SYSCALL instruction and

the processor subsequently receives an INIT reset, the SYSCALL instructions will not behave as intended. Intel has not observed this erratum in any commercially available software.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

AZ64. CPUID Instruction May Return Incorrect Brand String

Problem: When a CPUID instruction is executed with EAX = 8000_0002H, 8000_0003H, or

8000_0004H, the returned EAX, EBX, ECX, and/or EDX values may be incorrect.

Implication: When this erratum occurs, the processor may report an incorrect brand string. Workaround: It is possible for the BIOS to contain a workaround for this erratum. Workaround does

NOT work for SLB5J and SLGAS processors.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ65. Global Instruction TLB Entries May Not be Invalidated on a VM Exit or

VM Entry

Problem: If a VMM is using global page entries (CR4.PGE is enabled and any present page

directories or page-table entries are marked global), then on a VM entry, the instruction TLB (Translation Lookaside Buffer) entries caching global page translations of the VMM may not be invalidated. In addition, if a guest is using global page entries, then on a VM exit, the instruction TLB entries caching global page translations of the guest may not be invalidated.

Implication: Stale global instruction linear to physical page translations may be used by a VMM after a

VM exit or a guest after a VM entry.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

48 Specification Update

Errata

AZ66. XRSTOR Instruction May Cause Extra Memory Reads

Problem: An XRSTOR instruction will cause non-speculative accesses to XSAVE memory area

locations containing the FCW/FSW and FOP/FTW Floating Point registers even though the 64-bit restore mask specified in the EDX:EAX register pair does not indicate to restore the x87 FPU state.

Implication: Page faults, data breakpoint triggers, etc. may occur due to the unexpected

nonspeculative accesses to these memory locations.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

AZ67. LBR, BTS, BTM May Report a Wrong Address when an

Exception/Interrupt Occurs in 64-bit Mode

Problem: An exception/interrupt event should be transparent to the LBR (Last Branch Record), BTS

(Branch Trace Store) and BTM (Branch Trace Message) mechanisms. However, during a specific boundary condition where the exception/interrupt occurs right after the execution of an instruction at the lower canonical boundary (0x00007FFFFFFFFFFF) in 64bit mode, the LBR return registers will save a wrong return address with bits 63 to 48 incorrectly sign extended to all 1s. Subsequent BTS and BTM operations which report the LBR will also be incorrect.

Implication: LBR, BTS and BTM may report incorrect information in the event of an

exception/interrupt.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ68. When Intel® Deep Power-Down State is Being Used, IA32_FIXED_CTR2

May Return Incorrect Cycle Counts

Problem: When the processor is operating at an N/2 core to front side bus ratio, after exiting an

Intel Deep Power-Down state, the internal increment value for IA32_FIXED_CTR2 MSR (Fixed Function Performance Counter 2, 30BH) will not take into account the half ratio setting.

Implication: Due to this erratum, IA32_FIXED_CTR2 MSR will not return reliable counts after

returning from an Intel Deep Power-Down state.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

Specification Update 49

Errata

AZ69. Enabling PECI via the PECI_CTL MSR Incorrectly

Writes CPUID_FEATURE_MASK1 MSR

Problem: Writing PECI_CTL MSR (Platform Environment Control Interface Control Register) will not

update the PECI_CTL MSR (5A0H), instead it will write to the VMM Feature Flag Mask MSR (CPUID_FEATURE_MASK1, 478H).

Implication: Due to this erratum, PECI (Platform Environment Control Interface) will not be enabled

as expected by the software. In addition, due to this erratum, processor features reported in ECX following execution of leaf 1 of CPUID (EAX=1) may be masked. Software utilizing CPUID leaf 1 to verify processor capabilities may not work as intended.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Do not initialize PECI

before processor update is loaded. Also, load the processor update as soon as possible after RESET, as documented in the RS – Wolfdale Processor Family Bios Writers Guide,

Section 14.8.3 Bootstrap Processor Initialization Requirements.

Status: For the steppings affected, see the Summary Tables of Changes.

AZ70. Corruption of CS Segment Register During RSM While Transitioning

From Real Mode to Protected Mode

Problem: During the transition from real mode to protected mode, if an SMI (System Management

Interrupt) occurs between the MOV to CR0 that sets PE (Protection Enable, bit 0) and the first far JMP, the subsequent RSM (Resume from System Management Mode) may cause the lower two bits of CS segment register to be corrupted.

Implication: The corruption of the bottom two bits of the CS segment register will have no impact

unless software explicitly examines the CS segment register between enabling protected mode and the first far JMP. Intel® 64 and IA-32 Architectures Software Developer’s Manual Volume 3A: System Programming Guide, Part 1, in the section titled "Switching to Protected Mode" recommends the far JMP immediately follows the write to CR0 to enable protected mode. Intel has not observed this erratum with any commercially available software.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ71. The XSAVE Instruction May Erroneously Set Reserved Bits in the

XSTATE_BV Field

Problem: XFEATURE_ENABLED_MASK bits [63:9] of register (XCR0) are reserved and must be 0;

consequently the XSAVE instruction should not modify the corresponding bits of the XSTATE_BV field in the header of the XSAVE/XRSTOR area. Due to this erratum, a logical processor may erroneously write 1 to one or more of these reserved bits.

Implication: Software may not operate correctly if it relies on the XSAVE instruction not to modify

bits [63:9] of the XSTATE_BV field in the header of the XSAVE/XRSTOR area.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

50 Specification Update

Errata

AZ72. Store Ordering Violation When Using XSAVE

Problem: The store operations done as part of the XSAVE instruction may cause a store ordering

violation with older store operations. The store operations done to save the processor context in the XSAVE instruction flow, when XSAVE is used to store only the SSE context, may appear to execute before the completion of older store operations.

Implication: Execution of the stores in XSAVE, when XSAVE is used to store SSE context only, may

not follow program order and may execute before older stores. Intel has not observed this erratum with any commercially available software.

Workaround: None identified. Status: For the steppings affected, see the Summary Tables of Changes.

AZ73. Memory Ordering Violation With Stores/Loads Crossing a Cacheline

Boundary

Problem: When two logical processors are accessing the same data that is crossing a cacheline

boundary without serialization, with a specific set of processor internal conditions, it is possible to have an ordering violation between memory store and load operations.

Implication: Due to this erratum, proper load store ordering may not be followed when multiple

logical processors are accessing the same data that crosses a cacheline boundary without serialization.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

AZ74. The XRSTOR Instruction May Fail to Cause a General-Protection

Exception

Problem: The XFEATURE_ENABLED_MASK register (XCR0) bits [63:9] are reserved and must be 0;

consequently, the XRSTOR instruction should cause a general-protection exception if any of the corresponding bits in the XSTATE_BV field in the header of the XSAVE/XRSTOR area is set to 1. Due to this erratum, a logical processor may fail to cause such an exception if one or more of these reserved bits are set to 1.

Implication: Software may not operate correctly if it relies on the XRSTOR instruction to cause a

general-protection exception when any of the bits [63:9] in the XSTATE_BV field in the

header of the XSAVE/XRSTOR area is set to 1.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes.

AZ75. B0-B3 Bits in DR6 for Non-Enabled Breakpoints May be Incorrectly Set

Problem: Some of the B0-B3 bits (breakpoint conditions detect flags, bits [3:0]) in DR6 may be

incorrectly set for non-enabled breakpoints when the following sequence happens:

1. MOV or POP instruction to SS (Stack Segment) selector;

2. Next instruction is FP (Floating Point) that gets FP assist

3. Another instruction after the FP instruction completes successfully

Specification Update 51

Errata

4. A breakpoint occurs due to either a data breakpoint on the preceding instruction or a

code breakpoint on the next instruction.

Due to this erratum a non-enabled breakpoint triggered on step 1 or step 2 may be

reported in B0-B3 after the breakpoint occurs in step 4.

Implication: Due to this erratum, B0-B3 bits in DR6 may be incorrectly set for non-enabled

breakpoints

Workaround: Software should not execute a floating point instruction directly after a MOV SS or POP

SS instruction

Status: For the steppings affected, see the Summary Tables of Changes.

AZ76. A 64-bit register IP-relative instruction may Return unexpected Results

Problem: Under an unlikely and complex sequence of conditions in 64-bit mode, a register IP-

Relative instruction may be incorrect.

Implication: A register IP-relative instruction result may be incorrect and could cause software to read

from or write to an incorrect memory location. This may result in an unexpected page fault or unpredictable system behavior.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. Status: For the steppings affected, see the Summary Tables of Changes

AZ77. Intel Trusted Execution Technology ACM Revocation

Problem: SINT ACM GM45_GS45_PM45_SINIT_21.BIN or Earlier are revoked and will not launch

with the processor configuration information.

Implication: Due to this erratum, SINT ACM GM45_GS45_PM45_SINIT_21.BIN and earlier will be

revoked.

Workaround: It is possible for the BIOS to contain a workaround for this erratum. All Intel TXT enabled

software must use SINT ACM GM45_GS45_PM45_SINIT_51.BIN or later.

52 Specification Update

Specification Changes

There are no specification changes for this specification update revision.

Specification Update 53

Specification Clarifications

The Specification Clarifications listed in this section may apply to the following documents:

 Intel® 64 and IA-32 Architectures Software Developer’s Manual, Volume 3A:

System Programming Guide

AZ1. Clarification of Translation Lookaside Buffers (TLBS) Invalidation

Section 10.9 INVALIDATING THE TRANSLATION LOOKASIDE BUFFERS (TLBS) of the Intel® 64 and IA-32 Architectures Software Developer's Manual, Volume 3A: System Programming Guide will be modified to include the presence of page table structure caches, such as the page directory cache, which Intel processors implement. This information is needed to aid operating systems in managing page table structure invalidations properly.

Intel will update the Intel® 64 and IA-32 Architectures Software Developer's Manual, Volume 3A: System Programming Guide in the coming months. Until that time, an application note, TLBs, Paging-Structure Caches, and Their Invalidation

(http://www.intel.com/products/processor/manuals/index.htm), is available which

provides more information on the paging structure caches and TLB invalidation.

In rare instances, improper TLB invalidation may result in unpredictable system behavior, such as system hangs or incorrect data. Developers of operating systems should take this documentation into account when designing TLB invalidation algorithms.

AZ2. CPUID Instruction Will Return Brand String With a Missing Letter

The Specification Clarification listed in this section applies to the following documents:

 Intel® Core™2 Duo Processors, Intel® Core™2 Solo Processors and Intel® Core™2

Extreme Processors on 45-nm Process Datasheet for Platforms based on Mobile

Intel® 45 Express Chipset Family

When the brand strings of the Intel Core 2 Extreme Quad Core Mobile Processor, Intel Core 2 Duo Mobile Processor in SFF Package and Intel Core 2 Solo Mobile Processor in SFF Package are displayed, one less character in the processor number

will be shown. This is due to a limitation in the number of characters allowed in their onchip processor number.

Intel Core 2 Extreme Quad Core Mobile Processor on-chip brand string will show processor numbers without the letter „X‟ and both the Intel Core 2 Duo Mobile Processor in SFF Package and Intel Core 2 Solo Mobile Processor in SFF Package

will show their processor numbers without the first letter „S‟ as indicated in the table below.

54 Specification Update

Processor Number in Datasheet

Processor Number in Brand String Displayed

SP9400

P9400

SP9300

P9300

SL9400

L9400

SL9300

L9300

SU9400

U9400

SU9300

U9300

SU3300

U3300

QX9300

Q9300

Specification Clarifications

Intel collateral will continue to show the correct and full processor number (with the first letter „S‟ or letter „X‟).

Table 1. Documentation Clarification

Specification Update 55

Documentation Changes

There are no documentation changes for this specification update revision.

Documentation Changes

56 Specification Update
