Intel® Carrier Grade Server TIGI2U & Intel® IP Network Server NSI2U

Tested Hardware and Operating System List

Revision 1.3

September, 2006

Enterprise Platforms and Services Marketing

Revision History







Revision History















Revision







Date

Number

Modifications





September 2005

1.0

Initial Release















Q106

1.1

RoHS Updates















Q206

1.2

Supported OS Updates and Certifications















September 2006

1.3

Addition of Suse 9.x SP3 support













Disclaimers

THE INFORMATION IN THIS DOCUMENT IS PROVIDED "AS IS" WITH NO WARRANTIES WHATSOEVER, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY WARRANTY OTHERWISE ARISING OUT OF ANY PROPOSAL, SPECIFICATION, OR SAMPLE.

Information in this document is provided in connection with Intel® products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in medical, life saving, or life sustaining applications.

Intel retains the right to make changes to its test specifications at any time, without notice.

The hardware vendor remains solely responsible for the design, sale and functionality of its product, including any liability arising from product infringement or product warranty.

Copyright © Intel Corporation 2005. All rights reserved.

Intel, the Intel logo, and EtherExpress are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

*Other names or brands may be claimed as the property of others.

ii

Revision 1.3









Table of Contents

Table of Contents





1.

Introduction ..........................................................................................................................



1



1.1

Test Overview..........................................................................................................



1



1.1.1

Basic Installation Testing .........................................................................................



1



1.1.2

Adapter / Peripheral Compatibility and Stress Testing ............................................

2



1.2

Pass/Fail Test Criteria .............................................................................................



3

2.

Base System Definitions .....................................................................................................



4

3.

Supported Operating Systems............................................................................................



5



3.1

Operating Systems Supported but not Tested.........................................................



6



3.2

Operating System Certifications ..............................................................................



6

4.

Adapters and Peripherals....................................................................................................



8



4.1

PCI SCSI RAID......................................................................................................



10



4.2

PCI SATA RAID.....................................................................................................



10



4.3

PCI SCSI ...............................................................................................................



11



4.4

PCI MROMB ..........................................................................................................



12



4.5

PCI Fibre Channel .................................................................................................



12



4.6

PCI NIC..................................................................................................................



13



4.7

Modems .................................................................................................................



14



4.8

Keyboard/Mouse....................................................................................................



14



4.9

CDROM Drives ......................................................................................................



15



4.10

DVD Drives ............................................................................................................



16



4.11

Tape Drives .............................................................

Error! Bookmark not defined.



4.12

Removable Drives .................................................................................................



16



4.13

KVM .......................................................................................................................



17

5.

Hard Disk Drives.................................................................................................................



18

6.

Installation Guidelines & Test Notes ................................................................................



22



6.1

LSI* Add-in RAID Card Option ROM Utility Access Issue .....................................

22

Revision 1.3

iii

Introduction

1.Introduction

This document is intended to provide users of the Intel® Carrier Grade Server TIGI2U and the Intel® IP Network Server NSI2U with a list of the operating systems, adapter cards, and peripherals tested by Intel on this server platform. The Intel® Carrier Grade Server TIGI2U and the Intel® IP Network Server NSI2U are both integrated using the Intel® Server Board

SE7520JR2.

This document will continue to be updated as new adapters, peripherals, and operating systems are tested or until the Intel® Carrier Grade Server TIGI2U and the Intel® IP Network Server NSI2U are no longer in production. Each new release of the document will present updated information as well as continue to provide the information from previous releases.

The adapters and peripherals specified in this document may or may not have been tested on all available board/riser combinations that make up the TIGI2U and NSI2U product family. Intel will provide support for the adapters and peripherals listed when used within this family of products.

The Intel® Carrier Grade Server TIGI2U and the Intel® IP Network Server NSI2U product families consists of the following server building blocks and integrated systems:

Product Code

Product Description





TLIA0201

Intel® Carrier Grade Server TIGI2U, Server Board SE7520JR2 - Onboard SCSI +



DDR2 – 400 MHz + Two PCI Risers + 20 inch Chassis Depth + CDR-RW/DVD-



ROM + Two SCSI HDD Support + AC Power

TLID0201

Intel® Carrier Grade Server TIGI2U, Server Board SE7520JR2 - Onboard SCSI +



DDR2 – 400 MHz + Two PCI Risers + 20 inch Chassis Depth + CDR-RW/DVD-



ROM + Two SCSI HDD Support + DC Power + NEBS + ETSI





NSIA0100

Intel® IP Network Server NSI2U, Server Board SE7520JR2 - Onboard SATA +



DDR2 – 400 MHz + Two PCI Risers + 20 inch Chassis Depth + Two SATA HDD



Support + AC Power + Eight Ports Front NIC Support





1.1Test Overview

Testing performed on the Intel® Carrier Grade Server TIGI2U and the Intel® IP Network Server NSI2U is divided under two separate categories:

Basic Operating System Installation Testing

Adapter / Peripheral Compatibility testing, and System Stress Testing.

1.1.1Basic Installation Testing

Basic installation testing is performed with each supported operating system. Basic installation testing validates that the server board can install the operating system and that the base hardware feature set is functional. A small set of peripherals is used for installation purposes only. No add-in adapter cards are tested. Testing includes network connectivity and running of proprietary and industry standard test suites.

Revision 1.3

1

Introduction

The latest version of an operating system signifies the latest supported version at the time of the actual test run. Each new release of this document may have a newly supported release of a given operating system. Previous releases of a supported operating system may not be tested beyond the basic installation test process.

1.1.1.1Support Commitment for Basic Installation Testing

Intel commits to provide the following level of customer support for operating systems that receive only basic installation testing:

Intel will provide and test operating system drivers for each of the server board’s integrated controllers, provided that the controller vendor has a driver available upon request. Vendors will not be required by Intel to develop drivers for operating systems that they do not already support. This may limit the functionality of certain server board integrated controllers.

Intel will support customer issues that involve installation and/or functionality of operating system with the server board’s integrated controllers only if a driver has been made available.

Intel will NOT provide support for issues related to use of any add-in adapters or peripherals installed in the server system when an operating system that received basic installation testing only is in use.

Support is defined as assistance in root causing issues, and determining a customer acceptable resolution to the issue associated with the operating system. The resolution may include, but is not limited to, on-board controller driver changes, engaging the vendor for resolution, BIOS changes, firmware changes, or determining a customer acceptable workaround for the issue.

1.1.2Adapter / Peripheral Compatibility and Stress Testing

Adapter / Peripheral Compatibility and Stress testing is performed only on the most current release of a supported operating system at the time of a given validation run. The Adapter / Peripheral Compatibility and Stress testing process consists of three areas: Base Platform, Adapter Compatibility, and Stress.

Base Platform: Each base platform will successfully install a given operating system, successfully run a disk stress test, and successfully run a network stress test.

Adapter Compatibility: Adapter compatibility validation (CV) testing uses test suites to gain an accurate view of how the server performs with a wide variety of adapters under the primary supported operating systems. These tests are designed to show hardware compatibility between the add-in cards and the server platform and include functional testing only. No heavy stressing of the systems or the cards is performed for CV testing.

Stress Testing: This test sequence uses configurations that include add-in adapters in all available PCI slots for a minimum 72-hour test run without injecting errors. Each configuration passes an installation test, a Network/Disk Stress test, and tape backup test. Any fatal errors that occur will require a complete test restart.

2

Revision 1.3

Introduction

1.1.2.1Support Commitment for Adapter / Peripheral Compatibility and Stress Testing

Intel commits to provide the following level of customer support for operating systems that receive Adapter / Peripheral Compatibility and Stress testing:

Intel will provide support for customer issues with these operating systems involving installation and/or functionality of the server board with or without the adapters and peripherals listed in this document as having been tested under the particular operating system.

Support is defined as assistance in root causing issues, and determining a customer acceptable resolution to the issue associated with the operating system. The resolution may include, but is not limited to, on-board controller driver changes, engaging the vendor for resolution, BIOS changes, firmware changes, or determining a customer acceptable workaround for the issue.

Intel will provide and test operating system drivers for each onboard video, network, and storage controller.

Intel will enable vendors to provide driver support for add-in adapters using these operating systems.

Intel will go through some of the steps to achieve certification to ensure its customers do not run across any problems, but the actual certification is the responsibility of the individual customer.

For operating systems, adapter cards, and peripherals not listed in this document, there is no support commitment. Intel will consider support requests on a case-by-case basis.

1.2Pass/Fail Test Criteria

For each operating system, adapter, and peripheral configuration, a test passes if specific criteria are met. Specific configurations may have had particular characteristics that were addressed on a case-by-case basis. In general, a configuration passes testing if the following conditions are met:

The operating system installed without error.

Manufacturer’s installation instructions or Intel’s best-known methods were used for the operating system installation.

No extraordinary workarounds were required during the operating system installation.

The server system behaved as expected during and after the operating system installation.

Application software installed and executed normally.

Hardware compatibility tests ran to completion without error.

Test software suites executed successfully

Test and data files were created in the correct directories without error.

Files copied from client to server and back compare to the original with zero errors reported.

Clients remain connected to the server system.

Industry standard test suites run to completion with zero errors reported.

Revision 1.3

3

Base System Definitions

2.Base System Definitions

The following table lists the base system configurations tested for a given validation test run. Each specific product/system software combination tested is assigned a Base System Identifier Number. These numbers are used in the lists of supported adapters and peripherals referenced in the following sections.

The adapters and peripherals specified in this document may or may not have been tested on all available board/riser combinations that make up the TIGI2U and the NSI2U product family. However, Intel will provide support for the adapters and peripherals listed when used within this family of products

This table is updated when a new test run is performed and a new product/system software combination was used.

Intel will only provide support for adapters and peripherals under the specified operating systems versions with which they were tested.



Base System











BIOS





mBMC/BMC











Configuration





Product Family









Firmware





HSC Firmware Revision













Revision













Identifier #















Revision











































Intel® Server Board



Production



mBMC FW2.40



SCS1 1.06









SE7520JR2 in







1





Intel® Chassis



Release



IMM BMC FW 32



SATA 1.08









SR1400/SR2400



P07.x



































































Intel® Server Board



Production



mBMC FW2.40



SCS1 1.06









SE7520JR2 in







2





Intel® Chassis



Release



IMM BMC FW 46



SATA 1.08









SR1400/SR2400



P08.x























































3





Intel® Carrier



Production



mBMC FW2.40



SCSI 1.01





Grade Server



Release



IMM BMC FW 48











TIGI2U



P08.10

































4





Intel® Carrier



Production



mBMC FW2.40



SCSI 1.01





Grade Server



Release



IMM BMC FW 48











TIGI2U



P10







































4

Revision 1.3

Supported Operating Systems

3.Supported Operating Systems

The following table provides a list of supported operating systems for the Intel® Carrier Grade Server TIGI2U and the Intel® IP Network Server NSI2U. Each of the listed operating systems was tested for compatibility with the Intel® Server Board SE7520JR2 in the base system configurations listed in section 2 of this document. Operating systems are supported only with the specified base system configuration(s) with which they were tested.

The following table also indicates whether each operating system received Basic Installation testing, or Adapter / Peripheral Compatibility and Stress testing. For information on the support commitments for Basic Installation Testing vs. Adapter / Peripheral Compatibility and Stress Testing, please reference Section 1 of this document.

Any variations to the standard operating system installation process are documented in the Installation Guidelines section of this document. If there are no installation guidelines noted in the following table, then the operating system installed as expected using manufacturer’s installation instructions or Intel’s best-known methods.

Operating systems supported by Intel® Server Management software or LANDesk* Client Manager software may be different than the operating systems supported by the Intel® Server Board SE7520JR2. Please reference the Readme and User Guide documents that are included as part of each Intel Server Management and LANDesk* Client Manager distribution for operating systems that are supported by that release.







Base System

Notes





Operating System

Configuration Tested















& Type of Testing











Microsoft Windows Server 2003*, Enterprise

Base Config # - 1











Edition

Compatibility & Stress







































Microsoft Windows Server 2003, Enterprise

Base Config # - 2











Edition, Service Pack 1

Compatibility & Stress







































Microsoft Windows Server 2003, Enterprise x64

Base Config # - 2











Edition, Service Pack 1

Compatibility & Stress









































Red Hat* Enterprise Linux 3.0, Update 3

Base Config # - 1, 2











Compatibility & Stress







































Red Hat Enterprise Linux 3.0, Update 3 (Intel®

Base Config # - 1, 2











EM64T Edition)

Compatibility & Stress







































Microsoft Windows Server2003, Enterprise

Base Config # - 3











Edition, Service Pack 1

Compatibility & Stress







































Microsoft Windows Server2003, Enterprise x64

Base Config # - 3











Edition

Compatibility









































Red Hat Enterprise Linux 3.0, Update 4

Base Config # - 3











Compatibility & Stress







































Red Hat Enterprise Linux 3.0, Update 4 (Intel®

Base Config # - 3











EM64T Edition)

Compatibility

























Red Hat Enterprise Linux* 4.0 w/Update 1

Base Config # - 4













































Revision 1.3



5





Supported Operating Systems



Base System

Notes

Operating System

Configuration Tested





& Type of Testing





Compatibility & Stress









SuSE* Linux Enterprise Server 9, Service Pack

Base Config # - 4



1

Compatibility & Stress













SuSE* Linux Enterprise Server 9, Service Pack

Base Config # - 4



2

Compatibility & Stress













SuSE* Linux Enterprise Server 9, Service Pack

Base Config # - 4



3

Compatibility & Stress













3.1Operating Systems Supported but not Tested With THOL HW

Listed below are the operating systems that Intel has tested only to install and boot properly on the platform. No testing has been done with any of the hardware contained within this Tested Hardware and Operating System document.



Operating System



Version



Comments















Microsoft* Windows*



Service Pack 4 (SP4)



The SE7520JR2 Team Tested the OS on the Board and



2000 Advanced Server





Limited Testing has been done on the system.





















SCO Open Unix

6.0



In process













SCO UnixWare

7.1.3



Complete













SCO UnixWare

7.1.4



Complete











Monta Vista

4.0 (64-bit)

Complete













3.2Operating System Certifications

Listed below are the operating systems that Intel will certify with the Intel® Carrier Grade Server TIGI2U and the Intel® IP Network Server NSI2U. However, the customer is responsible for their own certification from the individual operating system vendors. In many cases, the customer may leverage their operating system certifications from Intel’s testing. See the “Comments” section next to each operating system in the table below for additional information. Intel’s certifications, pre-certification, and operating system testing may help reduce some of the risk in achieving customer certifications with the operating system vendors.







Operating System

Certification Listing



Comments























Microsoft Windows





OEM must request certification by Microsoft for their











specific product.







2003*, Enterprise Edition





URL - TBD





































Microsoft Windows 2003,





OEM must request certification by Microsoft for their











specific product.







Enterprise x64 Edition





URL - TBD













































Red Hat checks Intel’s results, certifies (if appropriate),







Red Hat* Enterprise





and posts the certificate on their web site.











Customer can leverage the Intel certification, if customer







Linux 3.0















product meets the operating system vendor standard.





























URL - TBD





































6







Revision 1.3









Supported Operating Systems















Operating System

Certification Listing



Comments























SE7520JR2 Board











http://bugzilla.redhat.com/hwcert/show.cgi?id=1648





Red Hat* Enterprise



44















Linux 4.0





TIGI2U Server





















http://bugzilla.redhat.com/hwcert/show.cgi?id=1802









63





SuSE* Linux Enterprise











Server 9, Service Pack 1























SuSE* Linux Enterprise











Server 9, Service Pack 2

















http://wdb1.sco.com/chwp/owa/hch_model_cert_pa





SCO Unixware 7.1.4





ge?f_model_id=98382&f_release_id=600&f_vendo











r_search_corp_id=



Revision 1.3

7

Adapters and Peripherals

4.Adapters and Peripherals

Add-in adapter card and peripheral compatibility and stress testing will only be performed with the latest version of an operating system at the time the validation testing occurred. The following table shows the operating system and base system configurations used to validate each device. The adapters are divided into categories based on their functionality. All integrated on-board devices are tested by default and are therefore not included in the following tables.

Note that not all adapter cards were tested under all operating systems. The following notations are used in the tested adapters and peripherals table below to indicate the support level that Intel provides for a particular adapter under a particular operating system:



This adapter or peripheral has been tested and is supported under the specific

Number (i.e. 1)

configuration identified in the Base System Configurations Table in Section 2 of this



document.







This adapter or peripheral has been tested, but is NOT supported under the specific

Number in brackets (i.e. [1])

configuration identified in the Base System Configurations Table in Section 2 of this



document.





NT

This adapter or peripheral has not been tested under this operating system and is not

supported under this operating system.







ND

This adapter or peripheral has not been tested under this operating system due to

limitations in IHV driver availability, and is not suported under this operating system.









This adapter is supported, but not tested. This adapter model has not been tested

SA (Similar Adapter)

with this server board, but Intel will support it based on successful testing of a similar

adapter from the same adapter family. Intel has high confidence that this adapter will

Referenced in the

function correctly with the server board. This adapter uses the same firmware and

drivers, and has a nearly identical system interface to another adapter of the same

“Comments” column for

family that has been successfully tested with this server board. In addition, Intel has

each adapter that is

secured IHV commitment to support the similar adapters equally. Customers should

supported but not tested.

always test adapters as part of the final system configuration prior to deployment. All





installation guidelines for the tested adapter also apply to the similar adapter.







This adapter or peripheral was tested according to Intel-approved guidelines and test



procedures by the Independent Hardware Vendor (IHV) that manufactured this

IHVT (IHV Tested)

adapter or peripheral. Intel provides the same level of support for all the adapters or

peripherals listed in this document, regardless of whether this adapter or peripheral





was tested in an Intel lab or not. IHV test reports remain the property of the IHV (Intel



cannot provide copies of these reports).





Any variations to the standard adapter installation process or to expected adapter functionality are documented in the Installation Guidelines section of this document. If there are installation guidelines affecting a particular adapter and operating system combination, these are referenced in the following table. If there are no installation guidelines noted in the following table, then the adapter installed and functioned as expected using manufacturer’s installation instructions or Intel’s best-known methods.

8

Revision 1.3

Adapters and Peripherals

Testing of adapters cards normally is performed with unused add-in adapters and onboard controller expansion ROMs disabled in BIOS Setup. Intel recommends that customers disable the option ROM for add-in controllers and/or the on-board controllers when not booting from the controller or needing to use its built in utilities.

Revision 1.3

9

Adapters and Peripherals



Manufacturer



Model Number



Model Name



Interface



Comments



MicrosoftWindows

/EE2003*SBS 2003

MicrosoftWindows EM64T2003*Edition

EnterpriseHat*Red 3.0Linux(Intel® Edition)EM64T

EnterpriseHat*Red 3.0Linux

EnterpriseHat*Red 4.0Linux

Et*HdRaenterprise 3.0Linux(Intel® Edition)EM64T

LinuxSuSE* EnterpriseServer 9,

LinuxSuSE* EnterpriseServer 9,







































































4.1

PCI SCSI RAID



































































































Adaptec*



ASR-2200S



ASR-2200S

PCI-64/66



FW 4.20-7439

1,2



2



2

2



































































































Adaptec



ASR-2120S

ASR-2120S

PCI-64/66



Similar Adapter



SA



SA



SA



SA



























ASR-2200S































































ICP* vortex



GDT8514RZ





GDT8514RZ



PCI-64/66



BIOS:7.0.5.D





1,2





2





1,2



1,2































FW:2.44.02-RC7B











































































ICP vortex



GDT8524RZ





GDT8524RZ



PCI-64/66



BOS:7.05b





1,2





2





1,2



1,2































FW:2.44.02-RC7B























Intel



SRCU41L

SRCU41L

PCI-64/66



BIOS: G401

1,2



2



1,2

1,2































FW:314G































































Intel





SRCU42E





Rumley



PCI-E x8



BIOS:H423





2





2





2



2































FW:514F











































































Intel



SRCU42L

SRCU42L

PCI-64/66



BIOS:7.05C

2,3



2,3



2,3

2,3































FW:2.42.02-R07A































































Intel



SRCU42X

SRCU42X

PCI-X133



BIOS:H424

1,2,3



2,3



2,3

2,3































FW:413Z































































LSI Logic*



MegaRAID 320-2



MegaRAID SCSI 320-2

PCI-64/66



BIOS:G119

1,2



2



1,2

1,2















(518)













FW:1L37



























































LSI Logic



MegaRAID 320-1



MegaRAID SCSI 320-1

PCI-64/66



Similar Adapter



































(520-1)













MegaRAID 320-2



SA



SA



SA



SA

























(518)































LSI Logic



MegaRAID SCSI 320-





MegaRAID SCSI 320-



PCI-E x8



BIOS:H423





[1],2





2





1,2



1,2

















2E





2E







FW:514F







































































LSI Logic



MegaRAID SCSI 320-





MegaRAID SCSI 320-



PCI-X133



BIOS:H424





1,2,3





2,3





1,2,3



1,2,3

















2x





2x







FW:413Z







































































LSI Logic



MegaRAID SCSI 320-



MegaRAID SCSI 320-

PCI-X133



Similar Adapter





































4x



4x





MegaRAID SCSI



SA



SA



SA



SA



























320-2x

























4.2

PCI SATA RAID































































































Adaptec





AAR2410SA





AAR2410SA



PCI-64/66



BIOS:4.20





1,2,3





2,3





1,2,3



1,2,3































FW:7348











































































AMCC*/3ware*

9500S-8

9500S-8

PCIX-66



BIOS:BE9X2.03.0

2





ND



ND

1,2



































































FW:FE9X2.06.0





























AMCC/3ware

9500S-12

9500S-12

PCI-X66



SA 9500S-8



SA



SA



SA



SA















































































































































10









































Revision 1.3



































Adapters and Peripherals





















































































Manufacturer





Model Number





Model Name





Interface





Comments





MicrosoftWindows /EE2003*SBS 2003





MicrosoftWindows EM64T2003*Edition

EnterpriseHat*Red 3.0Linux(Intel® Edition)EM64T



EnterpriseHat*Red 3.0Linux



EnterpriseHat*Red 4.0Linux

Et*HdRaenterprise 3.0Linux(Intel® Edition)EM64T

LinuxSuSE* EnterpriseServer 9,

LinuxSuSE* EnterpriseServer 9,

















































































































































AMCC/3ware

9500S-12ML



9500S-12ML

PCI-X66



SA 9500S-8



SA





SA



SA



SA









































































































































AMCC/3ware

9500S-4LP



9500S-4LP

PCI-X66



SA 9500S-8



SA





SA



SA



SA







































































































































AMCC/3ware

9500S-8ML

9500S-8ML

PCI-X66



SA 9500S-8



SA





SA



SA



SA











































































































































ICP Vortex





GDT8586RZ





GDT8586RZ





PCI-64/66





BIOS:7.05D









































































FW:2.44.02-





2







2





2





2















































RC7B

















































Intel

SRCS14L

SRCS14L

PCI-64/66



BIOS:7.05C

1,2



2



1,2



1,2



































































































FW:2.42.02-R07A



























































































Intel

SRCS16



SRCS16



PCI-64/66



BIOS:G401

2



2



1,2



1,2















































FW:713N



































































































Intel





SRCS28X





SRCS28X





PCI-X133





BIOS:H425





2







2





2





2















































FW:813G















































































































LSI Logic





MegaRAID SATA





MegaRAID SATA 150-





PCI-64/66





BIOS:G119





2,3







2,3





2,3





2,3





























150-6





6











FW:713N











































































































LSI Logic





MegaRAID SATA





MegaRAID SATA 150-





PCI-64/66





Similar Adapter























































150-4





4











MegaRAID SATA





SA







SA





SA





SA















































150-6

















































Promise*



FastTrak S150 TX4



FastTrak S150 TX4



PCI-32/66



FW 1.00.0.30

1











[1]



1























































































































































D-Link



DGE-550T



GigaExpress DGE-



PCI -66







1











1



1



































550T





















































































































4.3 PCI SCSI





























































































































Adaptec(1)





ASC-29160





ASC-29160





PCI-64/66





BIOS:3.10.0





1,2





2





1,2





1,2

































































































Adaptec





ASC-29160LP





ASC-29160LP





PCI-64/66





Similar Adapter





SA







SA





SA





SA







































































































ASC-29160

















































































































Adaptec





ASC-29160N





ASC-29160N





PCI-64/66





Similar Adapter





SA







SA





SA





SA







































































































ASC-29160

















































































































Adaptec





ASC-39160





ASC-39160





PCI-64/66





BIOS:3.10.0





1,2,3







2,3





2,3





2,3























































































Adaptec

ASC-39320-A

ASC-39320-A



PCI-X133



BIOS:4.25.0

2,3



2,3



1,2,3



1,2,3













































































































































Adaptec

ASC-39320D-R



ASC-39320D-R



PCI-X133



Similar Adapter



SA





SA



SA



SA













































ASC-39320-A





































































































Adaptec

ASC-39320-R

ASC-39320-R



PCI-X133



Similar Adapter



SA





SA



SA



SA













































ASC-39320-A





































































































Adaptec





ASC-29320ALP





ASC-29320ALP





PCI-X133





BIOS:4.30.0





1,2







2





1,2





1,2





























































































































































Revision 1.3



























































11



Adapters and Peripherals









Manufacturer





Model Number





Model Name





Interface





Comments





MicrosoftWindows /EE2003*SBS 2003



MicrosoftWindows EM64T2003*Edition

EnterpriseHat*Red 3.0Linux(Intel® Edition)EM64T



EnterpriseHat*Red 3.0Linux



EnterpriseHat*Red 4.0Linux

Et*HdRaenterprise 3.0Linux(Intel® Edition)EM64T

LinuxSuSE* EnterpriseServer 9,

LinuxSuSE* EnterpriseServer 9,









































































































































Adaptec







ASC-29320A





ASC-29320A





PCI-X133





Similar Adapter





SA





SA





SA





SA













































ASC-29320ALP





































































































Adaptec







ASC-29320LP-R





ASC-29320LP-R





PCI-X133





Similar Adapter





SA





SA





SA





SA













































ASC-29320ALP





































































































Adaptec







ASC-29320-R





ASC-29320-R





PCI-X133





Similar Adapter





SA





SA





SA





SA













































ASC-29320ALP





































































































LSI Logic



LSI20160



LSI20160



PCI-32/33



BIOS:4.19

1,2



2



1,2



1,2































































































































LSI Logic

LSI20160L



LSI20160L



PCI-32/33









SA



SA



SA



SA

























































































































LSI Logic

LSI22320-R

LSI22320-R

PCI-X133



BIOS:5.10.03

1,2,3



2,3



1,2,3



1,2,3































































































FW:1.3.39















































































































































LSI Logic

LSI20320-R



LSI20320-R



PCI-X133



Similar Adapter



SA



SA



SA



SA











































LSI22320-R

























































































LSI Logic



LSI22320E-R



LSI22320E-R



PCI Express







1









1



1











































































































































4.4

PCI MROMB





























































































































Intel







SRCZCRX





Palo Verde





PCI-X133





BIOS:H424





1,2





2





1,2





1,2









































































































FW:413Z





































































































LSI Logic



MegaRAID SCSI 320-



MegaRAID SCSI 320-0



PCI-64/66



BIOS:G119

1,2



2



2



2

























0 (520-0)































































FW:1Z37

























































































































































4.5

PCI Fibre



































































Channel



























































































































Emulex*







LP10000DC



LP10000DC



PCI-X133



BIOS:1.70A1

1,2,3



2,3



1,2,3



1,2,3













































FW:190A4

























































































Emulex







LP10000



LP10000



PCI-X133



Similar Adapter



SA



SA



SA



SA











































LP10000DC

























































































Emulex







LP1050



LP1050



PCI-X133



Similar Adapter



SA



SA



SA



SA











































LP10000DC

























































































Emulex







LP1050DC



LP1050DC



PCI-X133



Similar Adapter



SA



SA



SA



SA











































LP10000DC

























































































Emulex







LP10000ExDC



LP10000ExDC-M2



PCI-E x4



BIOS:1.70A1

1,2



2



1,2



1,2































































































FW:TS1.90A4

















































































































































Emulex





LP1050Ex



LP1050Ex-F2

PCI-E x4



Similar Adapter



SA



SA



SA



SA











































LP10000ExDC



























































































































































12

















































Revision 1.3







































Adapters and Peripherals

















































































Manufacturer





Model Number





Model Name





Interface





Comments





MicrosoftWindows /EE2003*SBS 2003



MicrosoftWindows EM64T2003*Edition

EnterpriseHat*Red 3.0Linux(Intel® Edition)EM64T



EnterpriseHat*Red 3.0Linux



EnterpriseHat*Red 4.0Linux

Et*HdRaenterprise 3.0Linux(Intel® Edition)EM64T

LinuxSuSE* EnterpriseServer 9,

LinuxSuSE* EnterpriseServer 9,









































































































































Emulex



LP9002L



LP9002L



PCI-64/66



BIOS:CB1.70A1

1,2



2



2



2













































FW: CS3.92A2





























































































Emulex



LP952L



LP952L



PCI-64/66



Similar Adapter



SA



SA



SA



SA











































LP9002L





























































































Emulex



LP9802DC



LP9802DC



PCI-X133



BIOS:HB1.70A1

1,2,3



2,3



2,3



2,3













































FW:HS1.90A4





























































































Emulex



LP9802



LP9802



PCI-X133



Similar Adapter



SA



SA



SA



SA











































LP9802DC





























































































Emulex



LP982



LP982-F2



PCI-X133



Similar Adapter



SA



SA



SA



SA











































LP9802DC





























































































LSI Logic

LSI7202XP-LC



LSI7202XP-LC



PCI-X133



BIOS:2.02.00

2



2



2



2













































FW:1.02.02





























































































LSI Logic

LSI7102XP-LC



LSI7102XP-LC



PCI-X133



Similar Adapter



SA



SA



SA



SA











































LSI7202XP-LC





























































































LSI Logic

LSI7402XP-LC



LSI7402XP-LC



PCI-X133



Similar Adapter



SA



SA



SA



SA











































LSI7202XP-LC





























































































QLogic*

QLA2200/66

QLA2200/66



PCI-64/66



Similar Adapter



SA



SA



SA



SA











































LSI7202XP-LC





























































































QLogic





QLA2342





QLA2342





PCI-X133





BIOS:1.43





1,2,3





2,3





1,2,3





1,2,3













































FW:3.02.28









































































































QLogic





QLA2340





QLA2340





PCI-X133





Similar Adapter





SA





SA





SA





SA













































QLA2342









































































































QLogic



QLE2362



QLE2362



PCI-E x4



BIOS:1.05

2



2



2



2













































FW:3.03.07





























































































QLogic



QLE2360



QLE2360



PCI-E x4



Similar Adapter



SA



SA



SA



SA











































QLE2362





























































































4.6 PCI NIC































































































































3COM*

3C905C-TX-M



EtherLink 10/100 PCI



PCI 32/33







1,2



ND

1,2



1,2





































































































































3COM

3C980C-TXM



EtherLink Server



PCI-32/33







1,2



ND

1,2



1,2

































10/100 PCI Managed







































































































Intel





PILA8470D3





PRO/100+ S Server





PCI-32/33











2,3





2,3





2,3





2,3



















































































Intel(1)





PILA8470C3





PRO/100+ S Server





PCI-32/33





Similar Adapter





SA





SA





SA





SA

































































































PILA8470D3









































































































Intel





PILA8472C3





PRO/100+ Dual Port





PCI-64/66











2





2





1,2





1,2



















































































Intel





PWLA8490MT





PRO/1000MT Gigabit





PCI-X133











1,2





2





2





2























































































Server Adapter























































































































































































Revision 1.3























































13



Adapters and Peripherals









Manufacturer





Model Number





Model Name





Interface





Comments





MicrosoftWindows /EE2003*SBS 2003



MicrosoftWindows EM64T2003*Edition

EnterpriseHat*Red 3.0Linux(Intel® Edition)EM64T



EnterpriseHat*Red 3.0Linux



EnterpriseHat*Red 4.0Linux

Et*HdRaenterprise 3.0Linux(Intel® Edition)EM64T

LinuxSuSE* EnterpriseServer 9,

LinuxSuSE* EnterpriseServer 9,









































































































































Intel







PWLA8490MF





PRO/1000MF Gigabit





PCI-X133





Similar Adapter





SA





SA





SA





SA

































Server Adapter











PWLA8490MT



































































































Intel





PWLA8490XT



PRO/1000XT Gigabit



PCI-X133







1,2,3



2,3



2,3



2,3

































Server Adapter





































































































Intel







PWLA8490XF





PRO/1000XF Gigabit





PCI-X133





Similar Adapter





SA





SA





SA





SA

































Server Adapter











PWLA8490XT



































































































Intel





PWLA8490XFL



PRO/1000XFL Gigabit



PCI-X133



Similar Adapter



SA



SA



SA



SA































Server Adapter









PWLA8490XT





















































































Intel







PWLA8490XTL





PRO/1000XTL Gigabit





PCI-X133





Similar Adapter





SA





SA





SA





SA

































Server Adapter











PWLA8490XT



































































































Intel







PWLA8492MT





PRO/1000MT Dual





PCI-X133































































Port Gigabit Server

















2,3





2,3





1,2,3





1,2,3

































Adapter





















































Intel







PWLA8492MF





PRO/1000MF Dual





PCI-X133





Similar Adapter

























































Port Gigabit Server











PWLA8492MT





SA





SA





SA





SA

































Adapter





















































Intel(1)







PWLA8494MT



PRO/1000 MT Quad



PCI-X133







1,2,3



2,3



1,2,3



1,2,3

































Port Server Adapter





































































































Syskonnect*

SK-9E21

SK-9E21

PCI-E x1







2



2



2



2































































































































Syskonnect

SK-9E21D



SK-9E21D



PCI-E x1







1,2



2



1,2



1,2



























































































































Syskonnect

SK-9E22

SK-9E22

PCI-E x4







2



2



2



2







































































































































4.7

Modems



























































































































3COM





3CP3453B



V.Everything 56K



RS-232







1,2



2



1,2



1,2



























(= 3CP3453)



Analog Corporate



















































Modem



















































3COM





USR5610B



56K V.92 Performance



PCI-32/33







1,2



NT

1



1,2

































Pro



































































































4.8

Keyboard/Mouse

























































































































Keytronic*



E06101USB-C



E06101USB-C



USB



Keyboard with 2

1,2



2



1,2



1,2































































































port USB hub



















































































































































Keytronic



PRO Pilot



PRO Pilot



PS/2



Keyboard

1,2



2



1,2



1,2























































































































Microsoft*

Intellimouse Optical

Intellimouse Optical

PS/2 and USB



Mouse

1,2



2



1,2



1,2











































































































































































































14

















































Revision 1.3





Adapters and Peripherals





Manufacturer





Model Number





Model Name





Interface





Comments



MicrosoftWindows /EE2003*SBS 2003



MicrosoftWindows EM64T2003*Edition

EnterpriseHat*Red 3.0Linux(Intel® Edition)EM64T

EnterpriseHat*Red 3.0Linux



EnterpriseHat*Red 4.0Linux

Et*HdRaenterprise 3.0Linux(Intel® Edition)EM64T

LinuxSuSE* EnterpriseServer 9,

LinuxSuSE* EnterpriseServer 9,

















































































































Rainbow*



SRB10741/ERB01221



Sentinel Duo Hardware



USB



USB Security Key

1,2



2

ND

ND































Key



















































































LOGITECH*

930582-0121





Optical mouse



PS/2 and USB



Mouse

1,2



2

1,2

1,2



















































































































LOGITECH

930582-0403





Optical mouse



PS/2 and USB



Similar Adapter

SA

SA

SA

SA









































930582-0403











































































LOGITECH

967233-0121





Internet Navigator



PS/2 and USB



Keyboard

1,2



2

1,2

1,2



















































































































LOGITECH

967233-0403





Internet Navigator



PS/2 and USB



Similar Adapter

SA

SA

SA

SA









































967233-0121











































































4.9 CDROM Drives





































































































IBM*

22P6991

24x10x24



IDE/Slimline



CD-RW / DVD-

1,2



2

1,2

1,2



























































































ROM combo





























































































































LiteOn*



SOSC-2483K



SOSC-2483K

IDE/Slimline



DVD±R/RW CD-

1,2



NT

1

1,2



























































































R/RW



























































































































Mitsumi*(1)



SR244W1

SR244W1

IDE/Slimline







1,2



2

1,2

1,2





















Panasonic*



UJDA750



UJDA750



IDE/Slimline



CD-RW / DVD-

2



2

2

2













































ROM combo































































































































Plextor*



PlexWriter/



PlexWriter/



USB











































Premium-U -



Premium-U













1,2



2

1,2

1,2

























52/32/52



















































Plextor



PX-W4012TU



PlexWriter 40/12/40S



USB







1



NT

1

1





















































































































Samsung*

SN-324B

24x10x24



IDE/Slimline



CD-RW / DVD-

1,2



NT

1

1,2













































ROM combo































































































































Sony*



CRX-835E



CRX-835E



ATA



CD-RW / DVD-

3



3

3

3



























































































ROM combo































































































































TEAC*



CDW540E/KIT/USB2



CDW540E/KIT/USB2



USB







1,2



2

1,2

1,2

























































































































Toshiba*



SD-R6112



SD-R6112



ATAPI/Slimline



CD-RW / DVD-

















































(ATA packet



1,2



2

1,2

1,2









































ROM combo









































interface)













































































































































Revision 1.3











































15



Adapters and Peripherals



Manufacturer



Model Number



Model Name



Interface



Comments



MicrosoftWindows

/EE2003*SBS 2003

MicrosoftWindows EM64T2003*Edition

EnterpriseHat*Red 3.0Linux(Intel® Edition)EM64T

EnterpriseHat*Red 3.0Linux

EnterpriseHat*Red 4.0Linux

Et*HdRaenterprise 3.0Linux(Intel® Edition)EM64T

LinuxSuSE* EnterpriseServer 9,

LinuxSuSE* EnterpriseServer 9,







































































4.10 DVD and Combo



























Drives























































Panasonic

CW-8123B

CW-8123B

ATA

1





NT

1



1















































PIONEER*

DVR-S606

DVR-S606

USB2.0

1,2



NT

1



1,2













































Sony

DRX-510UL

DRX-510UL

USB2.0

1





NT

1



1















































Sony

CRX835-L1

CRX835-L1

ATA33

















































Teac

DV-28E-BP3

DV-28E-BP3

ATA33

1,2



2



1,2



1,2















































Teac

DW-224E-C98

DW-28E-C98

ATA33



3, 4











































Teac

DV-W28EA-593

DV-W28EA-593

ATA33



3, 4







































































4.11 Tape Drives































Certance*

STD2401LW-S

SCORPION 40 DDS4

SCSI-2U

1,2

2

1,2

1,2





DAT

















Sony

SDX-700C/BM

AIT-3 Desktop

SCSI-U160

1,2

2

1,2

1,2

























Quantum*

BH2AA-YF

DLT, VS160

SCSI-U2

3

3

3

3









4.12

Removable

























Drives













































Iomega*

32324

ZIP 750MB USB 2.0

USB 2.0



1,2

2

1,2

1,2

















































Iomega

SKU 33105

Micro Mini™ 512MB

USB 2.0



2

2

2

2













Drive



































Mitsumi

D353F3

D353F3

USB

Floppy

1,2

2

1,2

1,2















































Lexar*

JD1GB-80-231

1GB USB Flash Drive

USB 2.0



2

2

2

2

















































Sony

PCGA-UFD5

VAIO External USB

USB



1,2

2

1,2

1,2













floppy



































Sandisk*

SDCZ2-256

Mini Cruzer Data

USB



1

NT

[1]

[1]













Storage



































Teac

FDO5PUB

FDO5PUB

USB

Floppy

1,2

NT

1

1,2







































































16

















Revision 1.3

Note: Blue shading indicates that the adapter or peripheral is either available or will be available in a lead-free version.

Manufacturer

Model Number

Model Name

Interface

Comments



Microsoft Windows 2003* EE / SBS 2003





Microsoft Windows 2003* EM64T Edition

Red Hat* Enterprise Linux 3.0 (Intel® EM64T Edition)



Red Hat* Enterprise Linux 3.0



Red Hat* Enterprise Linux 4.0

Red Hat* Enterprise Linux 3.0 (Intel® EM64T Edition)



SuSE* Linux Enterprise Server 9,



SuSE* Linux Enterprise Server 9,

































































4.13 KVM































Avocent*

1160ES

1160ES

PS/2

1,2

2

1,2

1,2

























Belkin*

F1DA108T

Omniview PRO2 Series

PS/2

1,2

2

[1],2

[1],2









Note: Blue shading indicates that the adapter or peripheral is either available or will be available in a lead-free version.

(1)Non-orderable End of Life (EOL) device, however still supported in platform.

Revision 1.3

17

Hard Disk Drives

5.Hard Disk Drives

The hard drives listed in the following table have been tested with the server board integrated into the Intel® Carrier Grade Server TIGI2U and the Intel® IP Network Server NSI2U by Intel in its validation labs and/or by individual drive vendors. The following operating system identifiers are used in the table to specify which OS each drive was tested under.



Identifier number /





Operating System





Base Configuration

















1







Microsoft Windows Server 2003*, Enterprise Edition











2







Microsoft Windows Server 2003, Enterprise x64 Edition











3







Red Hat* Enterprise Linux 3.0











4







Red Hat Enterprise Linux 3.0 (Intel® EM64T Edition)

5-3







Microsoft Windows Server 2003, Enterprise Edition, Service Pack 1











6-3







Microsoft Windows Server2003, Enterprise x64 Edition











7-3







Red Hat Enterprise Linux 3.0, Update 4











8-3







Red Hat Enterprise Linux 3.0, Update 4 (Intel® EM64T Edition)

Note: For the definition of the Base Configuration number see the table describing the Base System Configuration Identifier # in section two of this document.

Note that not all hard drives were tested under all operating systems. The following notation is used in the tested hard drives table below to indicate the support level that Intel provides for a particular hard drive with a particular operating system:

Number (i.e. 1)

This hard drive has been tested and is supported under the operating system

identified by the operating system identification number.







Number in brackets (i.e. [1])

This hard drive has been tested, but is NOT supported under the operating system

identified by the operating system identification number.









The hard disk drive is supported, but not tested. This hard drive model/capacity has



not been tested with this server board, but Intel will support it based on successful



testing of a larger capacity hard drive from the same hard drive family. Intel has high



confidence that this hard drive will function correctly with the server board. This drive



uses the exact same firmware and drivers as a larger capacity hard drive that has

SD (Similar Drive)

been successfully tested with this server board. The only difference between this

drive and the one that was used in testing is the storage capacity. Intel provides the





same level of support for all hard drives listed in this document, regardless of whether



the drive was tested or not. Customers should always test hard drives as part of the



final system configuration prior to deployment. Given the fact that a larger capacity



hard drive from the same drive family has successfully completed testing on this



server board, this particular hard drive capacity point will not be tested.







The hard disk drive was tested according to Intel-approved guidelines and test



procedures by the Independent Hardware Vendor (IHV) that manufactured the drive.

IHVT (IHV Tested)

Intel provides the same level of support for all hard drives listed in this document,



regardless of whether the drive was tested in an Intel lab or not. IHV test reports



remain the property of the IHV (Intel cannot provide copies of these reports).





18

Revision 1.3

Intel® Carrier Grade Server TIGI2U & Intel® IP Network Server NSI2U

Hard Disk Drives

Manufacturer

Model Number

Product Family

Interface









SCSI Hard







Drives







Fujitsu*

MAP3147NC

MAP

SCSI/U320









Fujitsu

MAP3367NC

MAP

SCSI/U320









Fujitsu

MAP3735NC

MAP

SCSI/U320









Fujitsu

MAS3735NC

MAS

SCSI/U320









Fujitsu

MAS3367NC

MAS

SCSI/U320









Fujitsu

MAS3184NC

MAS

SCSI/U320









Fujitsu

MAT3073NC

AL-9LE

SCSI/U320









Fujitsu

MAT3147NC

AL-9LE

SCSI/U320









Fujitsu

MAT3300NC

AL-9LE

SCSI/U320









Fujitsu

MAU3036NC

AL-9LX

SCSI/U320









Fujitsu

MAU3073NC

AL-9LX

SCSI/U320









Fujitsu

MAU3147NC

AL-9LX

SCSI/U320









Hitachi*

DK32EJ-14

DK32EJ

SCSI/U320









Hitachi

DK32EJ-36

DK32EJ

SCSI/U320









Hitachi

DK32EJ-72

DK32EJ

SCSI/U320









Hitachi

HUS103030EL3

Ultrastar 10K300

SCSI/U320



800





Hitachi

HUS103014EL3

Ultrastar 10K300

SCSI/U320



800





Hitachi

HUS103073EL3

Ultrastar 10K300

SCSI/U320



800





Hitachi

HUS103036EL3

Ultrastar 10K300

SCSI/U320



800





Hitachi

HUS157373EL3

Ultrastar 15K73

SCSI/U320



800



SCA

Hitachi

HUS157373EL3

Ultrastar 15K73

SCSI/U320



600



68pin

Hitachi

HUS157336EL3

Ultrastar 15K73

SCSI/U320



800



SCA

Hitachi

HUS157336EL3

Ultrastar 15K73

SCSI/U320



600



68pin

Hitachi

HUS151473VL3

Ultrastar 15K146

SCSI/U320



800



SCA

Hitachi

HUS151473VL3

Ultrastar 15K146

SCSI/U320



600



68pin

Hitachi

HUS151414VL3

Ultrastar 15K146

SCSI/U320



800



SCA

Hitachi

HUS151414VL3

Ultrastar 15K146

SCSI/U320



600



68pin

Hitachi

HUS151436VL3

Ultrastar 15K146

SCSI/U320



800



SCA

Hitachi

HUS151436VL3

Ultrastar 15K146

SCSI/U320



600



68pin

Maxtor*

8B146J0

Atlas 10K IV

SCSI/U320









Maxtor

8B074J0

Atlas 10K IV

SCSI/U320









Maxtor

8B036J0

Atlas 10K IV

SCSI/U320









Maxtor

8E147J0

Atlas 10K V

SCSI /U320









Maxtor

8D300J0

Atlas 10K V

SCSI /U320









Tested













Drive size









RPM





Operating





Notes





(GB)















Systems











































10,000



147GB



1,3



























10,000



36GB



SD



























10,000



73GB



SD









15,000



73GB



1,3



























10,000



36GB



SD



























10,000



18GB



SD



























10,000



73GB



1,3



























10,000



147GB



1,3



























10,000



300GB



1,3



























15,000



36GB



1,3



























15,000



73GB



1,3









15,000



147GB



1,3



























10,000



147GB



1,3



























10,000



35GB



SD



























10,000



72GB



SD



























10,000



300GB



1,3



























10,000



147GB



1,3



























10,000



73GB



1,3



























10,000



36GB



1,3



























15,000



73GB



1,3,4



























15,000



73GB



SD



























15,000



36GB



SD



























15,000



36GB



SD



























15,000



73GB



1,3



























15,000



73GB



SD



























15,000



146GB



SD



























15,000



146GB



SD



























15,000



36GB



SD



























15,000



36GB



SD



























10,000



146GB



1,3,4



























10,000



73GB



SD



























10,000



36GB



SD

























10,000



300GB



1,3

RSJNZ3



















10,000



300GB



1,2,3,4













































Revision 1.3

19

Hard Disk Drives

Manufacturer

Model Number

Product Family

Interface













Maxtor

8D073J0

Atlas 10K V

SCSI /U320













Maxtor

8D147J0

Atlas 10K V

SCSI /U320













Maxtor

8C073J0

Atlas 15K

SCSI/U320













Maxtor

8C036J0

Atlas 15K

SCSI/U320













Maxtor

8C018J0

Atlas 15K

SCSI/U320













Maxtor

8E147J0

Atlas 15K II

SCSI /U320













Seagate*

ST3146807LC

Cheetah 10K.6

SCSI/U320













Seagate

ST336607LC

Cheetah 10K.6

SCSI/U320













Seagate

ST373307LC

Cheetah 10K.6

SCSI/U320













Seagate

ST3300007LC

Cheeta 10K.7

SCSI/U320













Seagate

ST373207LC

Cheeta 10K.7

SCSI/U320













Seagate

ST346707LC

Cheeta 10K.7

SCSI/U320













Seagate

ST373453LC

Cheetah 15K.3

U320/SCA













Seagate

ST336753LC

Cheetah 15K.3

U320/SCA













Seagate

ST318453LC

Cheetah 15K.3

U320/SCA













Seagate

ST373454LC

Cheeta 15K.4

SCSI/U320













Seagate

ST336754LC

Cheeta 15K.4

SCSI/U320













Seagate

ST3146854LC

Cheeta 15K.4

SCSI/U320













Serial ATA







(SATA) Hard







Drives







Hitachi

HDS722525VLS

Deskstar 7K250

SATA/150







A80





Hitachi

HDS722516VLS

Deskstar 7K250

SATA/150







A80





Hitachi

HDS722512VLS

Deskstar 7K250

SATA/150







A80





Hitachi

HDS722580VLS

Deskstar 7K250

SATA/150







A80





Maxtor

6Y120M0

DiamondMax Plus

SATA/150









9



Maxtor

6Y060M0

DiamondMax Plus

SATA/150









9



Maxtor

6Y080M0

DiamondMax Plus

SATA/150









9



Maxtor

6Y160M0

DiamondMax Plus

SATA/150









9



Maxtor

6Y200M0

DiamondMax Plus

SATA/150









9



Maxtor

7B300S0/7L300

Maxline III

SATA/150







S0





Maxtor

7B250S0/7L250

Maxline III

SATA/150







S0





Seagate

ST3160023AS

Barracuda 7200.7

SATA/150













Seagate

ST3120023AS

Barracuda 7200.7

SATA/150













Seagate

ST3200822AS

Barracuda 7200.7

SATA/150













Seagate

ST380013AS

Barracuda 7200.7

SATA/150













Seagate

ST380817AS

Barracuda 7200.7

SATA/150













Western Digital*

WD740GD

WD Raptor

SATA/150

































Tested











Drive size







RPM





Operating



Notes





(GB)













Systems





















10,000



73GB



SD























10,000



147GB



SD





















15,000



73GB

1,3



QSJNZ3

















15,000



36GB



SD























15,000



18GB



SD





















15,000



147GB

1,3



RSJNZ3

















10,000



147GB

1,3,4























10,000



36GB



SD























10,000



73GB



SD























10,000



300GB

1,2,3, 4























10,000



73GB



SD























10,000



147GB



SD























15,000



73GB

1,3,4,























15,000



36GB



5-3, 7-3, SD























15,000



18GB



5-3, 7-3, SD























15,000



73GB

1,2,3,4























15,000



36GB



5-3, 7-3, SD























15,000



146GB



SD























7200

250GB

1,2,3,4







7200

160GB

SD







7200

120GB

SD







7200

80GB

SD







7200

120GB

1,2,3,4







7200

60GB

SD







7200

80GB

SD







7200

160GB

SD







7200

200GB

SD







7,200

300GB

1,2,3,4







7,200

250GB

SD







7200

160GB

1,3,4







7200

120GB

SD







7200

200GB

SD







7200

80GB

5-3, 7-3, SD







7200

80GB

5-3, 7-3







10,000

74GB

1,2,3,4







20

Revision 1.3

Intel® Carrier Grade Server TIGI2U & Intel® IP Network Server NSI2U

































Tested



































Drive size









Manufacturer





Model Number





Product Family





Interface



RPM





Operating



Notes





















(GB)





































Systems















































Western Digital

WD360GD



WD Raptor



SATA/150

10,000



36GB



SD

















































































Note: Blue shading indicates that the adapter or peripheral is either available or will be available in a lead-free version

.

Revision 1.3

21

Installation Guidelines & Test Notes

Installation Guidelines & Test Notes

5.1LSI* Add-in RAID Card Option ROM Utility Access Issue

Issue:

The system will hang when the BIOS assigns PMM segment 2FE00 and the user



tries to enter into the Ctrl-M RAID configuration utility.

Implication:

A user may be unable to access the option ROM utility (Ctrl-M) for the following



LSI adapters: MegaRAID* 320-2, MegaRAID 320-1, MegaRAID 320-0,



MegaRAID SATA 150-6, MegaRAID SATA 150-4 and older U160 SCSI



MegaRAID adapters.

Guideline:

BIOS P07.20 or later releases have corrected this issue, allowing users to



access the Option ROM utility for the above mentioned LSI add-in adapters.

Status:

LSI add-in MegaRAID 320-2, MegaRAID 320-1, MegaRAID 320-0, MegaRAID



SATA 150-6, MegaRAID SATA 150-4 and older U160 SCSI MegaRAID adapters



are only supported when using BIOS P07.20 or later releases.

22

Revision 1.3
