Intel S5520HCT, S5500HCV, S5520HC User Manual

Intel® Server Board S5520HC,
®
Intel Intel Intel Intel Intel Intel Intel
Server Board S5500HCV ,
®
Server Board S5520HCT ,
®
Workstation Board S5520SC,
®
®
®
Server System SC5650HCBRP,
®
Workstation System SC5650SCWS
I
Spares Parts List & Configuration Guide
A reference guide to assist customers in ordering the necessary components to configure the
®
Intel
Server Board S5520HC, Intel® Server Board S5520HCT, Intel® Server Board S5500HCV,
®
and Intel
Workstation Board S5520SC with appropriate Intel chassis.
2
Rev 1.09
January, 2010
~ Subject to Change ~
Disclaimer
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
Intel products are not intended for use in medical, life saving, life sustaining applications. Intel may make changes to specifications and product des criptions at any time, w ithout notice.
Intel server boards, server chassis, and processors may contain design defects or errors known as errata, which may cause the product to deviate from published specifications. Current characterized errata are available on request.
Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.
*Other names and brands may be claimed as the property of others. Copyright © 2009, Intel Corporation
3
Contents
Contents ............................................................................................. ............. 3
Production Configuration ............................................................................ . 4
Production Board SKUs ............. .......................... .......................... ............. 8
Production System ............................................... ................................ ..... 10
Production Chassis ..................................................... .......................... ..... 12
Production Spares and Accessories ......................... .......................... ..... 14
Production RAID Accessories (not including BBU) ............................ ..... 20
Production RAID Controller ....................................................................... 20
Intel Tested Memory List ........................................................................... 22
Intel THOL List ...................................................... .......................... ........... 22
Intel® System Management Software – (Upgrade SKUs) ...................... 24
Production Intel® Xeon Processor 5500 Series ........ .......................... ..... 26
Production Intel Thermal Solution STS100 Seri es .................................. 27
Heat Sink Configuration Guide ........ ................................. ........................ 27
VMware* vSphere* Virtualization Software Configuration Guide for vSphere* SKUs 28
Product Descriptions – Overview ............................................ .................. 28
VMware vSphere* and vCenter* Server SKUs ........................................ 28
Production Configuration
I
This section contains information needed to order and configure the Intel® Server System SC5650HCBRP, Intel® Workstation System SC565 0SCWS, and Intel S5520HC, S5520HCT and S5500HCV and Intel
1) Production boxed Intel Server Boards contain the following:
®
Server Chassis SC5600, SC5650 Family with Intel® Server Board
®
Workstation Board S5520SC.
One baseboard with unified back plate assembly
ATX I/O shield
Cables: Serial B (COM2), 4 SAS/SATA cables
Resource CD-ROM with utilities, drivers, documentation and technical information* (does not ship with
S5520HCT)
Quick Start User’s Guide and Quick Reference Label
ISMS 3.1 DVD * (does not ship with S5520HCT)
®
Compatible with Intel
2) Production OEM 10-packs of Intel Server Boards contain the following:
Xeon® processor 5500 series
One baseboard with unified back plate assembly
®
Compatible with Intel
3) The production SC5600LX KDK is compatible with the Intel
Xeon® processor 5500 series
®
Server Boards S5520HC and S5500HCV. it
includes:
Redundant (1+1) PMBus-compliant 750W high efficiency PFC power supply with dual line cord support (2 redundancy 750W high efficiency PFC module included)
Four redundant, hot-swap fans and ducting
Support for six tool-free non hot-swap hard drives. Upgradeable to 10 cabled or 10 (6+4 configuration) hot-
swap SAS or SATA drives.
Quick Start User’s Guide and Configuration Label
Cables (one each):
o Front Panel Cable (baseboard header to front panel) o USB Cable (USB header to chassis front panel) o COM2 Cable o Adapter Cable providing two additional SATA power connectors o AC power cords are included only in SC5600LXNA
®
Five Bumpers for installing Intel
The Intel
®
Server Chassis SC5600LX is designed to work with Intel® Xeon® processor 5500 series with
Server Board S5520HC or S5500HCV
95W maximum pow er and FXXRGTHSINK or FXXRGTHS tower heat sink accessory (required).
4) The production Intel
®
Server Chassis SC5600BRP KDK is compatible with the Intel® Server Boards S5520HC
and S5500HCV. it includes:
Redundant (1+1) PMBus-compliant 7 50W high efficiency PFC power supply with dual line cord support
nd
redundancy 750W high efficiency PFC module included)
(2
Three non-redundant fixed cooling fans with ducting
Support for six tool-free non hot-swap hard drives. Upgradeable to 10 cabled or 10 (6+4 configuration) hot-
swap SAS or SATA drives.
Quick Start User’s Guide and Configuration Label
Cables (one each):
o Front Panel Cable (baseboard header to front panel) o USB Cable (USB header to chassis front panel)
nd
5
o COM2 Cable o Adapter Cable providing two additional SATA power connectors o AC power cords are included only in SC5600BRPNA
®
Five Bumpers for installing Intel
The Intel
®
Server Chassis SC5600BRP is designed to work with Intel® Xeon® processor 5500 series with
Server Board S5520HC, S5500HCV
95W maximum power, and is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.
5) The production Intel
®
Server Chassis SC5600 Base KDK is compatible with Intel® Server Chassis S5520HC,
S5500HCV, and Intel® Workstation Board S5520SC. It includes:
Non-redundant 670W PFC power supply
Three non-redundant fixed cooling fans with ducting
Support for six tool free non hot-swap hard drives. Upgradeable to 6 hot-swap SAS or SATA.
Quick Start User’s Guide and Configuration Label
Cables (one each):
o Front Panel Cable (baseboard header to front panel) o USB Cable (USB header to chassis front panel) o COM2 Cable o Adapter Cable providing two additional SATA power connectors o AC power cord is included only with SC5600BASENA.
®
Five Bumpers for installing Intel
Server Board S5520HC, S5500HCV, and Intel® Workstation Board
S5520SC.
®
The Intel
Server Chassis SC5600BASE is designed to work with Intel® Xeon® processor 5500 series with
95W maximum power, and is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.
6) The production Intel
®
Workstation Chassis SC5650WS SKU is compatible with the Intel® Workstation Board
S5520SC. It includes:
Non-redundant 1000W high efficiency PFC power supply
Three non-redundant fixed cooling fans with ducting
Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.
Quick Start User’s Guide
Cables (one each):
o Front Panel Cable (baseboard header to front panel) o USB Cable (USB header to chassis front pan el) o Adapter Cable providing two additional SATA power connectors o AC power cord is included only with SC5650WSNA
Chassis intrusion switch assembly
Five Bumpers for installing Intel
The chassis is designed to work with Intel
®
Workstation Board S5520SC.
®
Xeon® processor 5500 series with 130W maximum power, and
is compatible with BXSTS100C (Combo) or BXSTS100A (Active) heat sink.
7) The production Intel
®
Server Chassis SC5650DP SKU is compatible with the Intel® Server Board S5520SC,
S5500HCV, and S5500BC. It includes:
Non-redundant 600W PFC power supply
Three non-redundant fixed cooling fan with ducting
Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.
Note: Check the Power budget spreadsheet for supportable hard drive, memory and PCI configurations.
Quick Start User’s Guide
6
Cables (one each):
o Front Panel Cable (baseboard header to front panel) o USB Cable (USB header to chassis front pan el) o Adapter Cable providing two additional SATA power connectors o AC power cord is only included in SC5650DPNA
Chassis intrusion switch assembly
®
Five Bumpers for installing Intel
The chassis is designed to work with Intel
Server Board S5520SC, S5500HCV, and S5500BC.
®
Xeon® processor 5500 series with 95W maximum power, and is
compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.
8) The production Intel
®
Server Chassis SC5650BRP SKU is compatible with the Intel® Server Board S5520SC,
S5500HCV, and S5500BC. It includes:
Redundant (1+0) PMBus-compliant 600W high efficiency PFC power supply with dual line cord support (full redundancy requires additional 600W module purchased separately)
Three non-redundant fixed cooling fan with ducting
Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.
Quick Start User’s Guide
Cables (one each):
o Front Panel Cable (baseboard header to front panel) o USB Cable (USB header to chassis front pan el) o Adapter Cable providing two additional SATA power connectors o AC power cord is only included in SC5650BRPNA
Chassis intrusion switch assembly
®
Five Bumpers for installing Intel
The chassis is designed to work with Intel
Server Board S5520SC, S5500HCV, and S5500BC.
®
Xeon® processor 5500 series with 95W maximum power, and is
compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.
9) The Intel
Intel
Expander-based Intel
®
Server System SC5650HCBRP includes:
®
Server Board S5520HC pre-installed in the Intel® Sever Chassis SC5650BRP
(APP3HSDBKIT) in the Intel
®
Hot Swap Drive Bay AXX6DRV3GEXP pre-installed with cooling and mounting kit
®
Server Chassis SC5650BRP (Require SAS add-in card or SAS module
purchased separately)
Redundant (1+0) PMBus-compliant 600W high efficiency PFC power supply with dual line cord support (full redundancy requires additional 600W module purchased separately)
Three non-redundant fixed cooling fan with ducting
Quick Start User’s Guide and Configuration Label
Cables (one each)
o Front Panel Cable (baseboard header to front panel, pre-routed)) o USB Cable (USB header to chassis front pan el, pre-ro uted) o Adapter Cable providing two additional SAT A power co nnectors (in cable kit) o AC power cord is only included in SC5650HCBRPNA
Chassis intrusion switch assembly (pre-routed)
®
The server system is designed to work with Intel
Xeon® processor 5500 series with 95W maximum power,
and is compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.
10) The Intel
®
Workstation System SC5650SCWS includes:
7
Intel® Workstation Board S5520SC pre-installed in the Intel® Sever Chassis SC5650WS
Support for six tool-free non hot-swap hard drives. Upgradeable to hot swap SAS/SATA 6-drive bay.
Non-redundant 1000W high efficiency PFC power supply
Three non-redundant fixed cooling fan with ducting
Quick Start User’s Guide and Configuration Label
Cables (one each)
o Front Panel Cable (baseboard header to front panel, pre-routed)) o USB Cable (USB header to chassis front panel, p re-rout ed) o Adapter Cable providing two additional SAT A power co nnectors (in cable kit) o AC power cord is only included in SC5650SCWSNA
Chassis intrusion switch assembly (pre-routed)
®
The workstation system is designed to work with Intel
Xeon® processor 5500 se ries w ith 130W maximu m
power, and is compatible with boxed STS100C (Combo) or STS100A (Active) heat sink.
11) Common accessories include:
Hot Swap Drive Bays:
AXX6DRV3GEXP: Expander-based 6-drive bay that supports SAS/SATA drives. Requires two free
SAS ports from the SAS personality module or SAS RAID card.
AXX4DRV3GEXP: Expander-based 4-drive bay that supports SAS/SATA drives. Requires two free
SAS ports from the SAS module or SAS RAID card. Only supported in Intel
®
Server Chassis
SC5600BRP, and SC5600LX.
AXX6DRV3GR: 6-drive bay that supports SAS/SATA drives. Requires six free SAS or SATA ports.
SAS hard drive support requires SAS connectors from a SAS personality module or SAS RAID Card. Support 6Gb SAS Hard Drives with compatible 6Gb SAS adapters
AXX4DRV3GR: 4-drive bay that supports SAS/SATA drives. Requires four free SAS or SATA ports.
SAS hard drive support requires SAS connectors from a SAS personality module or SAS RAID Card. Only supported in Intel
®
Server Chassis SC5600BRP and SC5600LX. Support 6Gb SAS Hard Drives
with compatible 6Gb SAS adapters.
®
AXX750WPS: Spare 750W power supply module for Intel
Server Chassis SC5600LX and SC5600BRP
ARIGRACK: Rack conversion kit (SC5600BASE, SC5600BRP and SC5600LX) APP3RACKIT: Rack conversion kit (SC5600 chassis family).
®
AXXRAKSW5: Intel
RAID Activation Key AXXRAKSW5 to enable Intel Embedded RAID technology II for SAS
and/or SATA Software RAID 5 on S5520HC, S5500HCV, and S5520SC boards.
APPT600WHPSU: Additional 600W power supply module- required for full redundancy for SC5650BRP only. APPTHSDBKIT: Cooling and mounting kit required for 6-drive hot-swap backplanes installed in the SC5650 chassis
family. This kit should be used with AXX6DRV3GR APP3HSDBKIT: Cooling and mounting kit required for 6-drive hot-swap backplanes installed in the SC5650 chassis
family. This kit should be used with AXX6DRV3GEXP. AXX25DRVADPTR: 2.5” hard drive carrier kit for installing 2.5” SATA or SAS hard drive or Solid State Drive into
3.5” hot swap drive bay
Production Board SKUs
®
®
®
®
®
®
®
®
Picture Product Code MM # UPC MOQ Description
I
S5520HC
900402
00735858207485 5 Boxed Intel
I/O shield, cables, resource CD and ISMS DVD)
S5520HCR
905721
00735858213783 5 Boxed Intel
I/O shield, cables, resource CD and ISMS DVD)
BB5520HC 901640 00735858207492 10 Bulk pack of the Intel
BB5520HCR 905718 00735858213790 10 Bulk pack of the Intel
S5520HCT 904912 00735858213776 1 Boxed Intel
I/O shield, cables)
Server Board S5520HC. (Includes
Server Board S5520HCR.(Includes
Server Board S5520HC
Server Board S5520HCR
Server Board S5520HCT. (Includes
S5500HCV 902386 00735858207508 5 Boxed Intel
I/O shield, cables, resource CD and ISMS DVD)
S5500HCVR 905723 00735858213820 5 Boxed Intel
(Includes I/O shield, cables, resource CD and ISMS DVD)
BB5500HCV 902387 00735858207515 10 Bulk pack of the Intel
Server Board S5500HCV. (Includes
Server Board S5500HCVR.
Server Board S5500HCV
9
BB5500HCVR 905720 00735858213875 10 Bulk pack of the Intel
®
®
®
®
®
S5500HCVR
Server Board
S5520SC
S5520SCR
BB5520SC 901634 00735858207539 10 Bulk pack of the Intel
BB5520SCR 905719 00735858213813 10 Bulk pack of the Intel
MOQ = Minimum Order Quantity.
900963
905722
00735858207522 5 Boxed Intel
(Includes I/O shield, cables, resource CD and ISMS DVD)
00735858213806 5 Boxed Intel
(Includes I/O shield, cables, resource CD and ISMS DVD)
S5520SC.
S5520SCR.
Workstation Board S5520SC.
Workstation Board S5520SCR.
Workstation Board
Workstation Board
Production System
®
®
®
®
®
®
Picture Product Codec MM # UPC MOQ Description
I
SC5650HCBRP 904553 00735858212557 1 Intel
(1+0) PMBus-compliant 600W Redundant power supply, 3 fixed chassis fans with ducting, rackable with optional rack kit. Supports up to 6 Hot-Swap drives (SAS or SATA, require SAS add-in card or SAS module purchased separately). Supports up to 95W processor. N o pow er cord or heat sinks included.
SC5650HCBRPR 907331 TBD 1 Intel
(1+0) PMBus-compliant 600W Redundant power supply, 3 fixed chassis fans with ducting, rackable with optional rack kit. Supports up to 6 Hot-Swap drives (SAS or SATA, require SAS add-in card or SAS module purchased separately). Supports up to 95W processor. N o pow er cord or heat sinks included.
SC5650HCBRPNA 903806 00735858213196 1 Same as Intel
with North American power cord included. No heat sinks included.
SC5650HCBRPRNA 905764 TBD 1 Same as Intel
with North American power cord included. No heat sinks included.
Server System SC5650HCBRP with
Server System SC5650HCBRPR with
System SC5650HCBRP
System SC5650HCBRPR
SC5650SCWS 904581 00735858212571 1 Intel
SC5650SCWSR 907332 TBD 1 Intel
Workstation System SC5650SCWS with 1000W fixed PSU, sup ports up to two 150W workstation graphics cards or single 300W workstation graphics card, 3 fixed chassis fans with ducting, r ackable w ith optional rack kit, supports up to 6 fixed drives, upgradeable to 6 Hot-Sw ap drives (SAS or SATA). Supports up to 130W processor. No pow er cord or heat sinks included.
Workstation System SC5650SCWSR with 1000W fixed PSU, sup ports up to two 150W workstation graphics cards or single 300W workstation graphics card, 3 fixed chassis fans with ducting, r ackable w ith optional rack kit, supports up to 6 fixed drives, upgradeable to 6 Hot-Sw ap drives (SAS or SATA). Supports up to 130W processor. No pow er cord or heat sinks included.
SC5650SCWSNA 903836 00735858213202 1 Same as Intel
®
Workstation System SC5650SCWS with Nort h Americ an pow er cord. No heat sinks included
SC5650SCWSRNA 905767 TBD 1 Same as Intel® Workstation System
SC5650SCWSR with North American power cord. No heat sinks included
MOQ = Minimum Order Quantity.
11
Production Chassis
®
®
®
®
®
Picture Product Codec MM # UPC MOQ Description
I
SC5600BASE 900403 00735858207546 1 Intel
670W fixed PSU, 3 fixed chassi s fans w ith ducting, 1 PSU fan. Supports up to 6 tool-free cabled drives, upgradeable to 6 hot-swap drives (SAS or SATA). Supports Intel S5520HC, S5500HCV and Intel board S5520SC. Supports up to 95W processor. No power cord or heat sinks included .
SC5600BASENA 900891 00735858207553 1 Same as Intel
with North American power cord included. No heat sinks included.
SC5600BRP 900877 00735858207560 1 Intel
power (BRP) version with (1+1) PMBus­compliant 750W redundant PSU. 3 fixed chassis fans with ducting, 1 PSU fan per module, includes fixed drive cage to support 6 tool-free cabled drives, upgradeable to 10 fixed, cabled drives or 10 (6+4 configuration) hot-swap SAS or SATA drives. Supports Intel Board S5520HC, S5500HCV. Supports up to 95W processor. No power cord or heat sinks included.
SC5600BRPNA 900913 00735858207577 1 Same as Intel
with North American power cord included. No heat sinks included.
Server Chassis SC5600 base version with
®
Server Board
®
workstation
Server Chassis SC5600BASE
Server Chassis SC5600 base redundant
®
Server
Server Chassis SC5600BRP
SC5600LX 900878 00735858207584 1 Intel
Server Chassis SC5600 LX Chassis with 750W PMBus-compliant (1+1) hot-swap redundant power supply, 4 hot-swap redundant fans with ducting, 1 PSU fan per module, includes fixed drive cage to support 6 tool-free cabled drives, upgradeable to 10 fixed, cabled drives or 10 (6+4 configuration) hot-swap SAS or SATA drives. Supports Intel® Server Board S5520HC, S5500HCV. Supports up to 95W processor. No power cord or heat sinks included.
Special tower heat sink FXXRGTHSINK or FXXRGTHS required and can be purchased as an accessory.
3
SC5600LXNA 900955 00735858207591 1 Same as Intel
®
®
®
®
®
®
North American power cord included. No heat sinks included. Special tower heat sink
FXXRGTHSINK or FXXRGTHS required and can be purchased as an accessory.
SC5650WS 900339 00735858207416 1 Intel
1000W fixed PSU, supports up to two 150W workstation graphics cards or single 300W workstation graphics card, 3 fixed chassis fans with ducting, rackable with optional rack kit, supports up to 6 fixed drives, upgradeable to 6 Hot-Swap drives (SAS or SATA). Supports Intel workstation board S5520SC. Supports up to 130W processor. No pow er cord or he at sinks included.
SC5650WSNA 900450 00735858207607 1 Same as Intel
with North American po wer cord. No heat sinks included
SC5650DP 900338 00735858207393 1 Intel
fixed PSU, 3 fixed chassis fans with ducting, rackable with optional rack kit, supports up to 6 fixed drives, upgradeable to 6 Hot-Swap drives (SAS or SATA). Check the Power budget
spreadsheet for supportable hard drive, memory and PCI configurations. Supports
S5520HC, S5500HCV, and S5500BC. Supports up to 95W processor. No power cord or heat sinks included.
SC5650DPNA 900453 00735858207614 1 Same as Intel
North American power cord. No heat sinks included.
Server Chassis SC5600 LX w ith
Workstation Chassis SC5650WS with
Workstation Chassis SC5650WS
Server Chassis SC5650DP with 600W
Server Chassis SC5650DP with
SC5650BRP 900340 00735858207409 1 Intel
Server Chassis SC5650BRP with (1+0) PMBus-compliant 600W Redundant power supply, 3 fixed chassis fans with ducting, rackable with optional rack kit. Supports up to 6 fixed drives, upgradeable to 6 Hot-Swap drives (SAS or SATA). Supports Intel S5520HC, S5500HCV, and S5500BC. Supports
®
Server Boards
up to 95W processor. No power cord or heat sinks included.
1
4
SC5650BRPNA 900452 00735858207621 1 Same as Intel
®
Server Chassis SC5650BRP with North American po wer cord. No heat sinks included.
MOQ = Minimum Order Quantity.
Production Spares and Accessories
Picture Product Code MM # UPC MOQ Description
AXX25DRVADPTR 904083
00735858211567 10
2.5'' Hard Disk Drive Carrier Kit, include ten 2.5” drive carriers and installation guide. The 2.5” HDD carrier is for installing 2.5” SAS, SATA, or SSD into 3.5” hot-s wap hard dis k driv e bay. Requires hot-swap backplane assembly cage kit)
Ship with 10 carriers in single package. See compatible Intel® chassis and systems at:
http://www.intel.com/support/motherboards/serv er/sb/CS-030726.htm
AXX6DRV3GEXP 877235
00735858180283 1
6-drive hot-swap, expander SATA/SAS backplane assembly cage kit for Intel
®
Server Chassis SC5600/SC5 650. Re quires 2 S AS ports from SAS personality module or RAID card and is compatible with SAS or SATA 3.5” hard drives. Includes: backplane board, 6 drive carriers, 2 Data cables, 6-drive bay, IPMB cable, common installation guide, SATA/SAS configuration label.
AXX4DRV3GEXP
877236 00735858180290 1
4-drive hot-swap expander, SATA/SAS backplane assembly cage kit for Intel
®
Server Chassis SC5650 family. Requires 2 SAS ports from SAS personality module or RAID card and is compatible with SAS or SATA 3.5” hard drives. Includes: Backplane board, 4 drive carriers, 2 data cables, 4-drive bay, IPMB cable, common installation guide, SATA/SAS configuration label.
Not supported in SC5600BASE, SC5650DP, SC5650BRP, or SC5650WS
AXX6DRV3GR
900405 00735858207638 1
6-drive hot-swap non-expanded SATA/SAS backplane assembly cage kit for Intel
®
Server Chassis SC5600 / SC5650 family. Requires 6 SAS ports from RAID card for SAS (or SATA)
3.5” hard drive support or 6 SATA ports from baseboard or RAID card for SATA 3.5” hard drive support. Includes: Backplane board, 6 drive carriers, 6 data cables, 6-drive bay, IPMB cable, SES cable and SGPIO cable, common installation guide, SATA/SA S config uratio n label.
1
5
Picture Product Code MM # UPC MOQ Description
®
®
®
®
AXX4DRV3GR
FXXRGTHSINK
FXXRGTHS
AXXRMM3
900404 00735858207645 1
4-drive hot-swap non-expanded, SATA/SAS backplane assembly cage kit for Intel Chassis SC5600 family. Requires 4 SAS ports from RAID card for SAS (or SATA) 3. 5” hard drive support or 4 SATA ports from baseboard or RAID card for SATA 3.5” hard drive support. Includes: Backplane board, 4 drive carriers, 4 data cables, 4-drive bay, IPMB cable, SES cable and SGPIO c able, co mmon ins tallat ion guide, SATA/SAS configuration label.
Not supported with Intel SC5600BASE, SC5650DP, SC5650BRP, or SC5650WS
901335 00735858206273 2
Special tower heat sinks required for Intel Server Chassis SC 5600LX , Ship w ith 2 heat sinks in single package
904992 00735858212809 2
Special tower heat sinks required for Intel Server Chassis SC5600LX. Each heat sink is individually packaged and labeled.
900961 00735858206570 1 Intel
Server Board S5520HC, S5500HCV, and Intel workstation board S5520SC.
®
Server
®
Server Chassis
®
Remote Management Module 3 for Intel®
®
ARIGRACK 885459 00735858164603 1 Pedestal to rack conversion kit for Intel
Chassis SC5600. Includes: hinge cover; rack handles, intrusion switch jumper, new rail kit assembly, rack hardware kit, icon label, installation guide
AXXCMA3U7U 862119 00735858168533 1 Universal 3U though 7U Rack Mode Cable
Management Arm (CMA). Requires ARIGRACK.
APPTHSDBKIT 901181 00735858207676 1 Hot-swap drive mounting Kit for Intel
Server Chassis SC5650, Includes 1 cooling fan, 1 fan holder and 2 Hot-swap cage brackets.
Note: This mounting kit is required when using 6-bay Hot-swap Hard Disk Cage in SC5650 Chassis. This kit should be used w ith
AXX6DRV3GR.
1
Server
6
Picture Product Code MM # UPC MOQ Description
®
®
®
®
®
APP3HSDBKIT 882456 00735858177450 1 Hot-swap drive mounting Kit for Intel
APP3RACKIT 882457 00735858177375 1 Rack conversion kit for Intel
APPT600WHPSU 900984 00735858207324 1 2
FXXSCVDCBL 901767 00735858207768 10 Internal video cable to external VGA port for
AXXLCPPED 879579
00735858167956 1
AXX4FIXDB 857882 00735858164702 1 Cabled 4 drive tool-less drive bay assembly for
Server Chassis SC5650, Includes 1 cooling fan, 1 fan holder and 2 Hot-swap cage brackets.
Note: This mounting kit is required when using 6-bay Hot-swap Hard Disk Cage in SC5650 Chassis. This kit should be used w ith AXX6DRV3GEXP.
Server Chassis SC5650 family. Includes rack rails and hardware for rack installation
nd
Redundant 600W PSU for Intel® Server Chassis SC5650BRP to enable full, hot-swap power redundancy or use as spare
Intel Workstation Board S5520SC,
Intel® Local Control Panel (LCD) for SC5600 and SC5650 pedestal chassis. Fits in unused
5.25” peripheral bay.
®
Intel
Server Chassis SC5600. Includes hardware to mount 4 additional non-hot swap drives (for total of up to 10).
AXXFHDDBRK 868171 00735858172462 1 Bracket accessory for Intel
SC5600 family to install a 3.5” HDD (cabled) or a 3.5” USB floppy in a stan dard 5.2 5” drive bay.
Remove the bracket bezel for 3.5” HDD installation.
ARIGDLTRAIL 856600 00735858164610 1 DLT Accessory Kit for Intel
SC5600 family -- left and right rails (10 Pack)
ARIGBEZPNL 860750 00735858168489 10 Intel
Permits mounting a full height 5.25” peripheral (e.g. DLT tape drive) in two half height bays.
Server Chassis SC5600 bezel branding panels- (1) upper and (1) lower bezel customization panel.
1
Server Chassis
Server Chassis
7
Picture Product Code MM # UPC MOQ Description
®
®
®
®
®
®
®
®
®
AXXRJ45DB92 881944 00735858155212 1
Contains two serial cable converter dongles (RJ45 to DB9) one for DSD and one for DCD (modem). The kit also includes one serial ribbon cable for cabling 2nd serial port from the baseboard. Note: Not use the serial ribbon cable with the Intel
AXXTIO
901685 00735858207683 50 I/O Shield for Intel
S5500HCV, S5500BC, BB5500BC, BB5520HC,
ASCIO
FRIGTPDB
901686 00735858207690 50 I/O Shield for Intel
901540 00735858207355 1 Spare Intel
and BB5500HCV.
S5520SC and BB5520SC.
LX Redundant Power Supply Power Distribution Board
FRIGTHSFANKIT
901657 00735858207652 1 Spare Intel
fan kit : Include 1 hot-sw ap 92mm fa n and 1 hot­swap 120 mm fan
FRIGTFIXFANS
901513 00735858207706 1 Spare fixed 4-w ire fan kit for Intel
Chassis SC5600BASE and SC5600BRP. Includes 1 front Fan (1 20mm), 1 rear ch assis fan (120mm, blue header), and 1 front PCI zone fan (92mm).
FXXRIGT670WPSU
901656 00735858207348 1 Spare 670W power supply for Intel
Chassis SC5600BASE
®
Server Chassis SC5600/SC5650
Server Boards S5520HC,
Workstation Board
Server Chassis SC5600BRP and
Server Chassis SC5600 hot swap
Server
Server
APP3STDBEZEL 871862 00735858177474 1 Spare bezel with door for Intel
SC5650 family.
FXXPPT600WPSU 901184 00735858207317 1 Spare 600W PSU for Intel
SC5650DP
FPPTBRPCAGE 901183 00735858207331 1 Spare Intel
Server Chassis SC5650BRP redundant power supply cage. Includes power distribution board and filler (for empty module when only 1 module i nstalled ).
Also used to upgrade Intel SC5650DP or SC5650WS to redundant power configuration. Requires 1 (or 2) APPT600WHPSU and the hot-swap
1
Server Chassis
Server Chassis
®
Server Chassis
8
Picture Product Code MM # UPC MOQ Description
®
®
redundant power supply supporting kit (provided by FPPTPMKIT) to complete upgrade.
See SC5650 chassis Service Guide for upgrade instruction.
FPPTFANKIT4W 901182 00735858207713 1 Spare 4-wire fan kit for Intel
Server Chassis SC5650 family. Includes 1 front PCI zone Fan (120mm), 1 rear chassis fan (120mm, blue header), and 1 HDD cage fan (92mm).
FXXPPTFPBRD 901360 00735858207737 1 Spare front panel board for Intel
Chassis SC5650
Server
FXXIPMBCBL 878135 00735858180085 10 Spare IPMB cables
FXXSESCBL 877945 00735858180092 10 Spare SES cables
FXXSGPIOCBL 877944 00735858180108 10 Spare SGPIO cables
FXX4DRV3GRBRD 901336 00735858206389 1 Spare board for AXX4DRV3GR (4 drive
backplane without an expander).
FXX4DRV3GEXPBRD 879633 00735858180931 1 Spare board for AXX4DRV3GEXP (4 drive
backplane with an expander).
FXX6DRV3GRBRD 901337 00735858206396 1 Spare board for AXX6DRV3GR (6 drive
backplane without an expander).
FXX6DRV3GEXPBRD 879632 00735858180948 1 Spare board for AXX6DRV3GEXP (6 drive
backplane with an expander).
1
9
Picture Product Code MM # UPC MOQ Description
®
®
®
®
®
FXX10DVCARBLK 880265 00735858181938 10 Spare hot swap drive carrier with black baffle.
FPWRCABLENA 879287 00735858180740 1 Spare North America Power cable for Intel
FXX1000WHEPS 904977 00735858213226 1 Spare 1000W PSU for Intel
AXX750WPS 901681 00735858207294 1 Spare 750W power supply module for Server
FXXRIGTFPBRD 901441 00735858208055 1 Spare front panel board for Intel
AXXLCPPED 879579
00735858167956 1
FRIGTPMKIT 901658 00735858207669 1 Chassis Preventative Maintenance kit for Intel
N/A
Server Chassis SC5600, SC5650 family
Server Chassis
SC5650WS
Chassis SC5600LX and SC5600BRP
Server
Chassis SC5600
Intel® Local Control Panel (LCD) for SC5600 and SC5650 pedestal chassis. Fits in unused
5.25” peripheral bay.
Server Chassis S C5600 f amily. Inc ludes 1 Front Panel USB Cable; 1 Serial Cable; 1 Front 92mm Fixed Fan Holder with screws; 1 Front 120mm Fixed Fan Holder with screws; 1 Rear 120mm Fixed Fan Holder with screws; 4 Hot Swap Fan Wires , 1 Bezel I ntrusion Sw itch, 2 sets / 4 pcs 5.25” tool-less bay rails, 2 sets / 4 pieces of fixed hard drive b ay rails, 4 chas sis feet, 1 Air Duct for Intel SC5600BASE/BRP, 1 Air Duct for Intel
®
Server
®
Server
Chassis SC5600 LX
FPPTPMKIT 901659 00735858207720 1 Chassis Preventative Maintenance Kit for Intel
Server Chassis SC5650 family. Includes 2 Hard Drive Bay Lockers with Screws and Spring, 1 Air Duct, (1) Intrusion Switch Assembly, 1 USB
N/A
Cable, 1 Rear 120mm Fixed Fan Holder w ith Screws, 1 Fan Holder with Screws for 92mm fan, 1 Full-length PCI Card Guide, 4 Rivets for front 120mm Fixed Fan, 1 Adapt er Plate with Screws for Fixed Power Supply, 1 Fixed Power supply tool-less locker, 4 Chassis Feet, 1 Fixed HDD Fan Plate, 1 Supporting kit for upgrading
1
0
Picture Product Code MM # UPC MOQ Description
®
®
®
to redundant power sup ply on SC5650D P/WS
MOQ = Minimum Order Quantity.
Production RAID Accessories (not including BBU)
Picture Product Code MM # UPC MOQ Description
AXX4SASMOD 900946 00735858206372 1 Intel
AXXROMBSASMR 901641 00735858208017 1 Intel
AXXRSBBU3
900954
00735858181853 1
AXXRAKSW5 878958 00735858181860
5
SAS Entry RAID Module AXX4SASMOD provides 4 port pass through SAS, entry-level RAID 0/1/1E, and optional host RAID 5.: Includes 1 AXX4SASMOD module card; 3 snap standoffs, 4 SAS/SATA cables, Configuration Label and Quick Inst allation Guide
Integrated RAID Module ROMBSASMR provides 4 ports full featured SAS/SATA RAID 0, 1, 5, 6 and striping capability for spans 10, 50,
60. 128 MB cache. Up to 16 SAS/SATA HDDs with expander enclosures. No PCI-E slot used. Optional backup battery AXXRSBBU3 should be ordered separately.
Intel® RAID Smart Battery AXXRSBBU3, optional battery back up for use with AXXROMBSASMR, AXXRAK18E and SRCSAS144E. RoHS Complaint.
Intel
RAID Activation Key AXXRAKSW5 to
enable SAS and/or SATA Software RAID 5
MOQ = Minimum Order Quantity
Production RAID Controller
Picture Product Code MM # UPC MOQ Description
RS2BL080 903493 00735858210140 5 Intel® RAID Controller RS2BL080 (Big Laurel 8)
- 6Gb/s SAS, 3Gb/S SAS/SATA, x8 PCIe 2.0, 8 internal ports, 512MB embedded memory, MD2 Low Profile, half length form factor. Includes 2
2
internal cables, Quick Start Users Guide, and CD ROM with technical documentation and software.
Picture Product Code MM # UPC MOQ Description
®
®
®
RS2BL080DE 903497 TBD 5 Intel® RAID Controller RS2BL080 “DE” (Big
Laurel 8 supporting Disk Encryption) - 6Gb/s SAS, 3Gb/S SAS/SATA, x8 PCIe 2.0, 8 internal ports, 512MB embedded memory, MD2 Low Profile, half length form factor. Provides key and management for Self-Encrypting Disks. Includes 2 internal cables, Quick Start Users Guide, and CD ROM with technical documentation and softw are.
RS2BL040 903494 TBD 5 Intel® RAID Controller RS2BL040 (Big Laurel 4)
- 6Gb/s SAS, 3Gb/S SAS/SATA, x8 PCIe 2.0, 4 internal ports, 512MB embedded memory, MD2 Low Profile, half length form factor. Includes 2 internal cables, Quick Start Users Guide, and CD ROM with technical documentation and software.
RS2PI008 903492 00735858211222 5 Intel® RAID Controller RS2PI008 - 6Gb/s SAS,
3Gb/S SAS/SATA, x8 PCIe 2.0, 8 external ports, 512MB embedded memory, MD2 Low Profile, half length form factor. Includes Quick Start Users Guide, and CD ROM with technical documentation and softw are.
RS2PI008DE TBD TBD 5 Intel® RAID Controller RS2PI008 “DE” model
(indicating Disk Encryption support) - 6Gb/s SAS, 3Gb/S SAS/SATA, x8 PCIe 2.0, 8 external ports, 512MB embedded memory, MD2 Low Profile, half length form factor. Provides key and management for Self-Encrypting Disks. Includes Quick Start Users Guide, and CD ROM with technical documentation and softw are.
SRCSASPH16I 896897 00735858201339 5 Intel
RAID Controller SRCSAS16PHI - PCIe
x8, 16P SAS RAID Controller, 256MB 667MHz memory embedded.
SRCSASJV 892602 00735858196444 5 Intel
RAID Controller SRCSASJV - PCIe x8, 8P
SAS RAID Controller with Mux (ports can be configured as internal or external), ships with
SRCSASBB8I 896943
00735858201346
512MB DIMM, supports up to 1GB ECC 7667MHz DDR2 mini-DIMM.
5 Intel
RAID Controller SRCSASBB8I - PCIe x8,
8P SAS RAID Controller, 256MB embedded memory, MD2 Low Profile, half length form factor.
21
2
Picture Product Code MM # UPC MOQ Description
®
®
®
®
®
SRCSASRB 892598
00735858196437
SRCSATAWB 892456
00735858196420
SRCSASLS4I 896952
00735858201353
SASMF8I 896960
00735858201360
SASUC8I
900176
00735858205115
SASWT4I
900267
00735858205108
5 Intel
RAID Controller SRCSASRB - PCIe x4,
8P SAS RAID Controller, and 256 MB embedded memory.
5 Intel
RAID Controller SRCSATAWB - PCIe x4,
8 port SATA RAID Controller, 128MB embedded memory, 16 physical devices, >8 requires expander backplane.
5 Intel
RAID Controller SRCSASLS4I - PCIe x8,
4P SAS RAID Controller, 128MB embedded memory, MD2 Low Profile, half length form factor.
5 Intel
RAID Controller SASMF8I - PCIe x4, 8P
SAS Controller with Intel Embedded Server RAID technology, Low Profile, half length form factor.
5 Intel
RAID Controller SASUC8I - PCIe x8, 8P
SAS Controller with entry-level HW RAID 0/1/1E/10E, low profile, half-l ength MD 2 compliant form factor.
5 Intel® RAID Controller SASWT4I - PCIe x4, 4P
SAS Controller with entry-level HW RAID 0/1/1E/10E, low profile, half-l ength MD 2 compliant form factor.
MOQ = Minimum Order Quantity.
Intel Tested Memory List
à Please visit http://www.intel.com/support/motherboards/server/s5520hc/sb/CS-030221.htm for the latest tested memory
list of Intel
à Please visit http://www.intel.com/support/motherboards/server/s5520sc/sb/CS-030229.htm
list of Intel
®
Server Boards S5520HC and S5500HCV, and Intel® Server System SC5650HCBRP
®
Workstation Board S5520SC and Intel® Workstation System SC5650SCWS
for the latest tested memory
Intel THOL List
à Please visit http://www.intel.com/support/motherboards/server/s5520sc/sb/CS-030228.htm for the latest tested hardware
list of Intel
à Please visit http://www.intel.com/support/motherboards/server/s5520sc/sb/CS-030230.htm
system list of Intel
®
Workstation Board S5520SC and Intel® Workstation System SC5650SCWS
®
Workstation Board S5520SC and Intel® Workstation System SC5650SCWS
2
for the latest tested operating
3
à Please visit http://www.intel.com/support/motherboards/server/s5520hc/sb/CS-030220.htm for the latest tested hardware
list of Intel
®
Server Boards S5520HC and S5500HCV, and Intel® Server System SC5650HCBRP
à Please visit http://www.intel.com/support/motherboards/server/s5520hc/sb/CS-030222.htm
system list of Intel
®
Server Boards S5520HC and S5500HCV, and Intel® Server System SC5650HCBRP
for the latest tested operating
2
4
Intel® System Management Software – (Upgrade SKUs)
The following Intel® System Management Software Upgrade SKUs are offered. Each SKU includes a Certificate of Authen ticity (C OA) that conta ins a produc t key for user to e nter to upgrad e:
Upgrades available to Microsoft* System Center Essentials 2007
Small Network Edition This upgrade gives the user the ability to manage up to 5 Windows-based servers OSEs and 15 Windows-
based client OSEs.
Standard Edition This upgrade gives the user the ability to manage up to 10 Windows-based servers OSEs and 50
Windows-based client OSEs.
Upgrade to add 1 or 5 Server Management license This upgrade gives the user the ability to manage 1 or 5 additional Windows-based server OSE.
Upgrade to add 5 or 20 Client Management licenses This upgrade gives the user the ability to manage 5 or 20 additional Windows-based client OSEs.
Intel® System Management Software – Upgrade Order Codes:
Product Code
SMS2SSE2SNE 7 35858 19670 3 893177 Upgrade from 90 day trial
UPC MM Description
Edition to Small Network Edition
Not included: Software CDs
are not included with upgrade.
SMS2SNE2STD 7 35858 19671 0 893221 Upgr ade from Small
Network Edition to Standard Edition
Not included: Software CDs are not included with upgrade.
SMS2SSE2STD 7 35858 19672 7 893170 Upgrade from 90 day trial
Edition to Standard Edition
Not included: Software CDs are not included with upgrade.
MOQ
1
1
1
2
5
SMS2CAL1S 7 35858 19675 8 893217 Microsoft® System Center
Essentials 2007 Server Management License (1 Pack)
Not included: Software CDs are not included with upgrade.
SMS2CAL5S 7 35858 19676 5 893218 Microsoft® System Center
Essentials 2007 Server Management License (5 Pack)
Not included: Software CDs are not included with upgrade.
SMS2CAL5C 7 35858 19673 4 893220 Microsoft® System Center
Essentials 2007 Client Management License (5 Pack)
Not included: Software CDs are not included with upgrade.
SMS2CAL20C 7 35858 19674 1 893219 Microsoft® System Center
Essentials 2007 Client Management License (20 Pack)
Not included: Software CDs are not included with upgrade.
1
1
1
1
2
Production Intel® Xeon Processor 5500 Series
I
Processor Name
Intel® Xeon® Processor W5590 BX80602W5590 903279 3.33 GHz 6.4 GT/s 8MB 1333 MHz 4 / 8 130W 7 35858 20995 3 Box Intel® Xeon® Processor W5580 BX80602W5580 901024 3.20 GHz 6.4 GT/s 8MB 1333 MHz 4 / 8 Intel® Xeon® Processor X5570 BX80602X5570 901025 2.93 GHz 6.4 GT/s 8MB 1333 MHz 4 / 8 Intel® Xeon® Processor X5560 BX80602X5560 901026 2.80 GHz 6.4 GT/s 8MB 1333 MHz 4 / 8 Intel® Xeon® Processor X5550 BX80602X5550 901027 2.66 GHz 6.4 GT/s 8MB 1333 MHz 4 / 8 Intel® Xeon® Processor E5540 BX80602E5540 901028 2.53 GHz 5.86 GT/s 8MB 1066 MHz 4 / 8 Intel® Xeon® Processor E5530 BX80602E5530 901029 2.40 GHz 5.86 GT/s 8MB 1066 MHz 4 / 8 Intel® Xeon® Processor E5520 BX80602E5520 901030 2.26 GHz 5.86 GT/s 8MB 1066 MHz 4 / 8 Intel® Xeon® Processor L5520 BX80602L5520 901033 2.26 GHz 5.86 GT/s 8MB 1066 MHz 4 / 8 Intel® Xeon® Processor L5518 AT80602002265AB 901505 2.13 GHz 5.86 GT/s 8MB 1066MHz 4 / 8 Intel® Xeon® Processor L5508 AT80602002697AC 901549 2.00 GHz 5.86 GT/s 8MB 1066MHz 2 / 4 Intel® Xeon® Processor E5506 BX80602E5506 901031 2.13 GHz 4.8 GT/s 4MB 800 MHz 4 / 4 N/A N/A 80W 7 35858 20576 4 Box Intel® Xeon® Processor L5506 BX80602L5506 901023 2.13 GHz 4.8 GT/s 4MB 800 MHz 4 / 4 N/A N/A 60W 7 35858 20579 5 Box Intel® Xeon® Processor E5504 BX80602E5504 901032 2.00 GHz 4.8 GT/s 4MB 800 MHz 4 / 4 N/A N/A 80W 7 35858 20577 1 Box Intel® Xeon® Processor E5502 BX80602E5502 901022 1.86 GHz 4.8 GT/s 4MB 800 MHz 2 / 2 N/A N/A 80W 7 35858 20578 8 Box
Boxed Product
Code
Product
MM#
Clock
Speed QPI Speed
L3
Cache
Max
Memory
Speed
# of
Cores /
Threads HT
√ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √ √
Turbo Boost Power
130W 7 35858 20568 9 Box
95W 7 35858 20569 6 Box 95W 7 35858 20570 2 Box 95W 7 35858 20571 9 Box 80W 7 35858 20572 6 Box 80W 7 35858 20573 3 Box 80W 7 35858 20574 0 Box 60W 7 35858 20575 7 Box 60W N/A Tray 38W N/A Tray
UPC Code
(Boxed Product
Only)
Shippin g media
Note: W5590 and S 5580 are only su ppor ted by Int el® Workstation Board S5520SC and Intel® Workstation System SC5650SCWS
7
Production Intel Thermal Solution STS100 Serie s
Product name Description Recommended usage
Intel® Thermal Solution STS100C
Passive/Active Combination Heat Sink with Removable Fan
With fan installed:
- Pedestal chassis that provide adequate ventilation and correct temperature air to heat sink
With fan removed:
- Pedestal chassis with ducted airflow to heat sink
- 2U or larger rack chas sis* with
ducted airflow to heat sink Intel® Thermal Solution STS100A
Active Heat Sink with Fixed Fan
Pedestal chassis that provide
adequate ventilation and correct
temperature air to heat sink
Heat Sink Configuration Guide
S5520HC S5500HCV S5520SC S5500BC Chassis SKU
Support Support Support N/A Support Support N/A N/A Support Support N/A N/A Support Support N/A Support Support Support N/A Support
N/A N/A Support N/A
SC5600Base SC5600BRP SC5600LX SC5650DP SC5650BRP SC5650WS
Maximum CPU TDP
Boxed Product Code MM# UPC Code
130W BXSTS100C 900491 7 35858 20515 3
80W BXSTS100A 900490 7 35858 20513 9
FXXRGTHSINK
Heat Sink
Includes
Intel® Thermal Solution
STS100C (w/ fan, Active
mode)
Intel® Thermal
Solution STS100A
(Active)
(Passive Tower
No Support Support N/A No Support Support N/A No N/A N/A Requir ed No Support Support N/A No Support Support N/A No Support Support N/A
Maximum CPU TDP
130W (supported in
80W 95W SC5650WS Chassis only);
95W
Boxed Product
BXSTS100C BXSTS100A FXXRGTHSINK
FXXRGTHS
Code
Or
FXXRGTHS
Heat Sink)
2
8
VMware* vSphere* Virtualization Software Con figuration Guide for vSphere* SKUs
Product Descriptions – Overview
VMware* vSphere* software is now available when ordering an Intel® Server Board or Intel® Server System. Customers can only order these SKUs at the time they are orderin g an Intel® Ser ver Board or Intel® Serv er System. These SKUs cannot be ordered individually.
VMware vSphere* and vCenter* Server SKUs
The following VMware vSphere SKUs are offered when purchasing a qualifying Intel® Server Board or Intel® Server System. Each SKU contains a software product activation code for user to en ter to do wnload software and i nstall. As direc ted on the certificate, the end u ser must register the product activation code with VMware at http://www.vmware.com/code/intel Subscription Services.
VMware vSphere* and vCenter* Server SKUs
Essentials This license activation code gives the user VMware vSphere* 4 Essentials Bundle for 3 hosts (Max 2 processors per host and 6 cores per processor), with 1 year VMware Subscription.
Essentials Plus This license activation code gives the user VMware vSphere* 4 Essentials Plus Bundle for 3 hosts (Max 2 processors per host and 6 cores per processo r), with 1 y ear VMw are Gold S upport and Subs cription.
Standard This license activation code gives the user VMware vSphere* 4 Standard for 1 Processor (Max 6 co res per CPU), with 1 year VMware Gold Support and Subscription.
Advanced This license activation code gives the user VMware vSphere* 4 Advanced for 1 Processor (Max 12 cores per CPU), with 1 year VMware Gold Support and Subscription.
Enterprise Plus This license activation code gives the user VMware vSphere* 4 Enterprise Plus for 1 Processor (Ma x 12 cores per CPU), with 1 year VMware Gold Support an d Subsc riptio n.
VMware vCenter* Server Standard for vSphere* This license activation code gives the user VMware vCenter* Server 4 Standard for vSph ere* (Includes Orchestrator and Linked Mode), with 1 year VMware Gold S upport a nd Subs cription.
2
within 30 days to access VMware Software, Support and
9
VMware vSphere* and VMware vCenter* Standard – Order Codes:
Product Code UPC MM Description MOQ
VMW4ESS
7 35858 21272 4
904791
Software license activation code certificate for VMware
1
vSphere* 4 Essentials Bundle for 3 hosts (Max 2 CPUs per host and 6 cores per CPU) with 1 year VMware Subscription.
VMW4ESSPLUS
7 35858 21273 1
904792
Software license activation code certificate for VMware
1
vSphere* 4 Essentials Plus Bundle for 3 hosts (Max 2 CPUs per host and 6 cores per CPU ) with 1 year VMware Gold Support and Subscription.
VMW4STD
7 35858 21274 8
904793
Software license activation code certificate for VMware
1
vSphere* 4 Standard for 1 Processor (Max 6 cores per CPU) with 1 year VMware Gold Support and Subscription.
VMW4ADV
7 35858 21275 5
904797
Software license activation code certificate for VMware
1
vSphere* 4 Advanced for 1 Processor (Max 12 cores per CPU) with 1 year VMware Gold Support and Subscription.
VMW4ENTPLUS
7 35858 21276 2
904800
Software license activation code certificate for VMware
1
vSphere* 4 Enterprise Plus for 1 Processor (Max 12 cores per CPU) with 1 year VMware Gold Support and Subscription.
VMWVCSTD
7 35858 21277 9
904801
Software license activation code certificate for VMware
1
vCenter* Server 4 Standard (includes Orchestrator and Linked Mode) with 1 year VMware Gold Support and Subscription.
Note:
1. Not supported with Intel
2. Please see the WMware* vSphere* 4 recipe at http://www.intel.com/g o/es aa for the tested configuration of your Intel
®
Server Board S5500HCV, Intel® Workstation Board S5520SC, or Intel® Workstation System SC5650SCWS
®
Server Board
S5520HC based system
3. At least one board or system must be ordered along with order of VMware SKU. Customers will need to join VMware System Builder
Program to get sales support from VMware
For support information please visit
2
0
http://www.vmware.com/partners/partners.html
3
Loading...
