Intel® Server Board S3000AH

Tested Hardware and Operating System List

Enterprise Platforms and Services Marketing

Revision 2.4

July, 2007

Revision History Intel® server board S3000AH

Revision History

Revision

Date

August 2006 1.0 Initial Release October 2006 2.0 Update adapters, peripherals and Hard Drives section with Q306 regression

November 2006 2.1 Corrected adapter tables for PCI-X adapters, added Hitachi hard disk

January 2007 2.2 Update adapters, peripherals section with Q406 regression test run April 2007 2.3 Update adapters, peripherals section with Q107 regression test run July 2007 2.4 Update OSs, adapters, peripherals section with Q207 regression test run

Number Modifications

test run – configuration 2, 3 and 4

drives.

Revision 2.4

ii

Intel® server board S3000AH Disclaimers

Disclaimers

THE INFORMATION IN THIS DOCUMENT IS PROVIDED “AS IS” WITH NO WARRANTIES WHATSOEVER, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY WARRANTY OTHERWISE ARISING OUT OF ANY PROPOSAL, SPECIFICATION, OR SAMPLE.

Information in this document is provided in connection with Intel to any intellectual property rights is granted by this document. Except as provided in Intel’s Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in medical, life saving, or life sustaining applications.

Intel retains the right to make changes to its test specifications at any time, without notice. The hardware vendor remains solely responsible for the design, sale and functionality of its product, including any liability arising

from product infringement or product warranty. Copyright © Intel Corporation 2006. All rights reserved. Intel, the Intel logo, and EtherExpress are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United

States and other countries. *Other names or brands may be claimed as the property of others.

®

products. No license, express or implied, by estoppel or otherwise,

Revision 2.4

iii

Table of Contents Intel® server board S3000AH

Table of Contents

1. Introduction ..........................................................................................................................1

1.1 Test Overview..........................................................................................................1

1.1.1 Basic Installation Testing.........................................................................................1

1.1.2 Adapter / Peripheral Compatibility and Stress Testing............................................2

1.2 Pass/Fail Test Criteria .............................................................................................3

2. Intel® Server Board S3000AH Base System Configurations ............................................4

3. Supported Operating Systems............................................................................................5

3.1 Operating System Certifications..............................................................................6

4. Adapters and Peripherals....................................................................................................8

Revision 2.4

iv

Intel® server board S3000AH Introduction

1. Introduction

This document is intended to provide users of the Intel® server board S3000AH with a guide to the different operating systems, adapter cards, and peripherals tested by Intel on this platform.

This document will continue to be updated as new adapters, peripherals, and operating systems are tested or until the Intel release of the document will present updated information as well as continue to provide the information from previous releases.

Intel will only provide support for those adapters and peripherals under the specified system configuration (System BIOS and Firmware revisions) and operating systems versions with which they were tested.

®

server board S3000AH is no longer in production. Each new

1.1 Test Overview

Testing performed on the Intel® server board S3000AH is classified under two separate categories: Basic Installation Testing, and Adapter / Peripheral Compatibility and Stress Testing.

1.1.1 Basic Installation Testing

Basic installation testing is performed with each supported operating system. Basic installation testing validates that the server board can install the operating system and that the base hardware feature set is functional. A small set of peripherals is used for installation purposes only. No add-in adapter cards are tested. Testing includes network connectivity and running of proprietary and industry standard test suites.

The latest version of an operating system signifies the latest supported version



at the time of the actual test run. Each new release of this document may have a newly supported release of a given operating system. Previous releases of a supported operating system may not be tested beyond the basic installation test process.

1.1.1.1 Support Commitment for Basic Installation Testing

Intel commits to provide the following level of customer support for operating systems that receive only basic installation testing:

• Intel will provide and test operating system drivers for each of the server board’s

integrated controllers, provided that the controller vendor has a driver available upon request. Vendors will not be required by Intel to develop drivers for operating systems that they do not already support. This may limit the functionality of certain server board integrated controllers.

• Intel will support customer issues that involve installation and/or functionality of

operating system with the server board’s integrated controllers only if a driver has been made available.

Revision 2.4

1

Intel® Server Board S3000AH Base System Configurations Intel® Server Board S3000AH

• Intel will NOT provide support for issues related to use of any add-in adapters or

peripherals installed in the server system when an operating system that received basic installation testing only is in use.

• Support is defined as assistance in root causing issues, and determining a customer

acceptable resolution to the issue associated with the operating system. The resolution may include, but is not limited to, on-board controller driver changes, engaging the vendor for resolution, BIOS changes, firmware changes, or determining a customer acceptable workaround for the issue.

1.1.2 Adapter / Peripheral Compatibility and Stress Testing

Adapter / Peripheral Compatibility and Stress testing is performed only on the most current release of a supported operating system at the time of a given validation run. The Adapter / Peripheral Compatibility and Stress testing process consists of three areas: Base Platform, Adapter Compatibility, and Stress.

Base Platform: Each base platform will successfully install a given operating system, successfully run a disk stress test, and successfully run a network stress test.

Adapter Compatibility: Adapter compatibility validation (CV) testing uses test suites to gain an accurate view of how the server performs with a wide variety of adapters under the primary supported operating systems. These tests are designed to show hardware compatibility between the cards and the server platform and include functional testing only. No heavy stressing of the systems or the cards is performed for CV testing.

Stress Testing: This test sequence uses configurations that include add-in adapters in all available slots, (depending on chassis used) for a minimum 72-hour test run without injecting errors. Each configuration passes an installation test, a Network/Disk Stress test, and tape backup test. Any fatal errors that occur will require a complete test restart.

1.1.2.1 Support Commitment for Adapter / Peripheral Compatibility and Stress Testing

Intel commits to provide the following level of customer support for operating systems that receive Adapter / Peripheral Compatibility and Stress testing:

• Intel will provide support for customer issues with these operating systems involving

installation and/or functionality of the server board with or without the adapters and peripherals listed in this document as having been tested under the particular operating system.

• Support is defined as assistance in root causing issues, and determining a customer

acceptable resolution to the issue associated with the operating system. The resolution may include, but is not limited to, on-board controller driver changes, engaging the vendor for resolution, BIOS changes, firmware changes, or determining a customer acceptable workaround for the issue.

• Intel will provide and test operating system drivers for each onboard video, network, and

storage controller.

• Intel will enable vendors to provide driver support for add-in adapters using these

operating systems.

Revision 2.4

2

Intel® server board S3000AH Introduction

• Intel will go through some of the steps to achieve certification to ensure its customers do

not run across any problems, but the actual certification is the responsibility of the individual customer.

For operating systems, adapter cards, and peripherals not listed in this



document, there is no support commitment. Intel will consider support requests on a case-by-case basis.

1.2 Pass/Fail Test Criteria

For each operating system, adapter, and peripheral configuration, a test passes if specific criteria are met. Specific configurations may have had particular characteristics that were addressed on a case-by-case basis. In general, a configuration passes testing if the following conditions are met:

− The operating system installed without error.

− Manufacturer’s installation instructions or Intel’s best-known methods were used for

the operating system installation.

− No extraordinary workarounds were required during the operating system installation.

− The server system behaved as expected during and after the operating system

installation.

− Application software installed and executed normally.

− Hardware compatibility tests ran to completion without error.

− Test software suites executed successfully

− Test and data files were created in the correct directories without error.

− Files copied from client to server and back compare to the original with zero errors

reported.

− Clients remain connected to the server system.

− Industry standard test suites run to completion with zero errors reported.

®

All Intel SC5295-E.

Revision 2.4

Server Board S3000AH testing was performed using the Intel® Entry Server Chassis

3

Intel® Server Board S3000AH Base System Configurations Intel® Server Board S3000AH

2. Intel® Server Board S3000AH Base System

Configurations

The following table lists the base system configurations tested. Base system configurations will change as new revisions of the Intel

®

Server Board S3000AH are released and/or new system BIOS is cut onto the board in the factory. Each base system configuration is assigned an identifier number that is referenced in the tables throughout this document. New base system configurations are added with each new release of this document.

Intel will only provide support for adapters and peripherals under the specified



base system configuration and operating systems versions with which they were tested.

Base System

Configuration

Identifier #

1 S3000AHV D52072-203 R28 2 S3000AHV D52072-204 R34 3 S3000AHLX D40858-204 R34 4 S3000AH D40859-204 R34 5 S3000AHV D52072-206 R35 6 S3000AHLX D40858-206 R35

Board Type PBA Number

BIOS

Revision

Notes

7 S3000AH D40859-206 R35 8 S3000AHV D52072-207 R39

9 S3000AH D40858-207 R39 10 S3000AHLX D40859-207 R39 11 S3000AHV D52072-207 R41 12 S3000AH D40858-207 R41 13 S3000AHLX D40859-207 R41

Revision 2.4

4

Intel® server board S3000AH Supported Operating Systems

3. Supported Operating Systems

The following table provides a list of supported operating systems for the Intel® Server Board S3000AH. Each of the listed operating systems was tested for compatibility with Intel

®

Server Board S3000AH base system configuration listed in Section 2 of this document. Operating systems are supported only with the specified base system configuration(s) with which they were tested.

The following table also indicates whether each operating system received Basic Installation Testing, or Adapter / Peripheral Compatibility and Stress Testing. For information on the support commitments for Basic Installation Testing vs. Adapter / Peripheral Compatibility and Stress Testing, please reference Section 1 of this document.

Any variations to the standard operating system installation process are documented in the Installation Guidelines section of this document. If there is no installation guidelines noted in the following table, then the operating system installed as expected using manufacturer’s installation instructions or Intel’s best-known methods.



LANDesk* Client Manager software may be different than the operating systems supported by the Intel

®

Server Board S3000AH. Please reference the

Operating systems supported by Intel® System Management software or

Readme and User Guide documents that are included as part of each Intel Server Management and LANDesk* Client Manager distribution for operating systems that are supported by that release.

Operating System

Microsoft Windows Server 2003* Enterprise Edition, SP2/ Microsoft Windows Small Business Server 2003*

Microsoft Windows Server 2003* Enterprise Edition for EM64T, SP2

SuSE* Linux Enterprise Server 9, SP3 SuSE* Linux Enterprise Server 9, EM64T, SP3

RedHat* Enterprise Linux 4.0 AS, Update 2

Base System Configuration Tested & Type of Testing

Configuration 1, 5 ,6, 7, 8, 9, 10, 11, 12, 13 – Compatibility & Stress

Configuration 1, 5, 6, 7, 8, 9, 10, 11, 12, 13 – Compatibility & Stress

Configuration 1 – Compatibility & Stress

Configuration 1 –

Notes

Intel’s testing was completed with Microsoft Windows Server 2003*. The Intel supports the operating system portion of Microsoft Windows Small Business Server 2003* only. The application portion is not tested or supported.

®

Server Board S3000AH

®

Server Board S3000AH

Revision 2.4

5

Intel® Server Board S3000AH Base System Configurations Intel® Server Board S3000AH

Compatibility & Stress

RedHat* Enterprise Linux 4.0 AS, EM64T, Update 2

Configuration 1 – Compatibility & Stress

Configuration 5, 6, 7, 8,

SuSE* Linux Enterprise Server 10

SuSE* Linux Enterprise Server 10, EM64T

RedHat* Enterprise Linux 4.0 AS, Update 4 Configuration 5, 6, 7, 8,

RedHat* Enterprise Linux 4.0 AS, EM64T, Update4

RedHat* Enterprise Linux 5.0 Configuration 11,12,13

RedHat* Enterprise Linux 5.0, EM64T Configuration 11,12,13

9, 10,11,12,13 – Compatibility & Stress

Configuration 5, 6, 7, 8, 9, 10,11,12,13 – Compatibility & Stress

9, 10 – Compatibility & Stress

Configuration 5, 6, 7, 8, 9, 10 – Compatibility & Stress

– Compatibility & Stress

Microsoft Windows XP Professional*, SP2

Microsoft Windows XP Professional*, EM64T, SP2

Novell* NetWare 6.5, SP5

Configuration 1, 5, 6, 7

–

Basic Installation

Configuration 1, 5, 6,

7–

Basic Installation

Configuration 1, 5, 6, 7, 8, 9, 10,11,12,13 –

Basic installation

Microsoft Windows 2000 Advanced Server*, SP4 /Microsoft Windows Small

Business Server 2000*

Windows Vista Enterprise

Windows Vista Enterprise EM64T

RedHat* Enterprise Linux 3.0 Update 8, EM64T

Configuration 1, 5, 6, 7, 8, 9, 10,11,12,13 – Basic Installation

Configuration 8, 9, 10,11,12,13 – Basic Installation

Configuration 11,12,13 – Basic Installation

Intel’s testing was completed with Microsoft Windows 2000 Server*. The Intel supports the operating system portion of Microsoft Windows Small Business Server 2000* only. The application portion is not tested or supported.

®

Server Board S3000AH

3.1 Operating System Certifications

Listed below are the operating systems that Intel will certify with the Intel® Server Board S3000AH. However, the customer is responsible for their own certification from the individual

Revision 2.4

6

Intel® server board S3000AH Supported Operating Systems

operating system vendors. In many cases, the customer may leverage their operating system certifications from Intel’s testing. See the “Comments” section next to each operating system in the table below for additional information. Intel’s certifications, pre-certification, and operating system testing may help reduce some of the risk in achieving customer certifications with the operating system vendors.

Operating System Certification Listing Comments

WHQL ID:

Microsoft Windows 2003*, Enterprise Edition

1211868 (S3000AHLX)

1211903 (S3000AH)

1211673 (S3000AHV)

http://developer.intel.com/design/servers/whql. htm

Microsoft Windows 2000*, Advanced Server

RedHat* Enterprise Linux 4.0 AS, Update2

RedHat* Enterprise Linus 4.0 AS Update2, EM64T

SuSE* Linux Enterprise Server 9, SP3

SuSE* Linux Enterprise Server 9, EM64T, SP3

Certified ID:

205175 (S3000AHLX)

203491 (S3000AH)

206250 (S3000AHV)

Certified ID:

205177 (S3000AHLX)

203491 (S3000AH)

206252 (S3000AHV)

Certified ID:

85836, 85837 (S3000AHLX)

85921, 85922 (S3000AH)

85724, 85723 (S3000AHV)

Certified ID:

85835, 85838 (S3000AHLX)

85919, 85920 (S3000AH)

85722, 85725 (S3000AHV)

WHQL logo for Microsoft Windows2000* is not reqiuired after Nov.1, 2004.

WHQL ID:

Microsoft Windows Server 2003* EE for EM64T

1211868 (S3000AHLX)

1211903 (S3000AH)

1211673 (S3000AHV)

http://developer.intel.com/design/servers/whql. htm

Revision 2.4

7

Intel® Server Board S3000AH Base System Configurations Intel® Server Board S3000AH

4. Adapters and Peripherals

Add-in adapter card and peripheral compatibility and stress testing will only be performed with the latest version of an operating system at the time the validation testing occurred. The following table shows the operating system and base system configurations used to validate each device. The adapters are divided into categories based on their functionality. All integrated on-board devices are tested by default and are therefore not included in the following tables.

Note that not all adapter cards were tested under all operating systems. The following notation is used in the tested adapters and peripherals table below to indicate the support level that Intel provides for a particular adapter under a particular operating system:

This adapter or peripheral has been tested and is supported under the specific

Number (i.e. 1)

Number in brackets (i.e. [1])

configuration identified in the Base System Configurations Table in Section 2 of this document.

This adapter or peripheral has been tested, but is NOT supported under the specific configuration identified in the Base System Configurations Table in Section 2 of this document.

NT

ND

SA (Similar Adapter)

This adapter or peripheral has not been tested under this operating system and is not supported under this operating system.

This adapter or peripheral has not been tested under this operating system due to limitations in IHV driver availability, and is not suported under this operating system.

This adapter is supported, but not tested. This adapter model has not been tested with this server board, but Intel will support it based on successful testing of a similar adapter from the same adapter family. Intel has high confidence that this adapter will function correctly with the server board. This adapter uses the same firmware and drivers, and has a nearly identical system interface to another adapter of the same family that has been successfully tested with this server board. In addition, Intel has secured IHV commitment to support the similar adapters equally. Customers should always test adapters as part of the final system configuration prior to deployment. All installation guidelines for the tested adapter also apply to the similar adapter.

Any variations to the standard adapter installation process or to expected adapter functionality are documented in the Installation Guidelines section of this document. If there are installation guidelines affecting a particular adapter and operating system combination, these are referenced in the following table. If there are no installation guidelines noted in the following table, then the adapter installed and functioned as expected using manufacturer’s installation instructions or Intel’s best-known methods.

Testing of adapters cards normally is performed with unused add-in adapters



and onboard controller expansion ROMs disabled in BIOS Setup. Intel recommends that customers disable the option ROM for add-in controllers and/or the on-board controllers when not booting from the controller or needing to use its built in utilities.

Revision 2.4

8

Intel® Server Board S3000AH Adapters and Peripherals

Vendor Model Description Interface Keying

Fiber Channel Cards

QLogic QLE2360 Single Channel,

2Gb

Logic QLE2362 Dual Channel,

2Gb

QLogic QLA2340 Single Channel,

2Gb

QLogic QLA2342 Dual Channel,

2Gb

PCI

Express*

PCI

Express

PCI-X* 133 Universal PCI-Short 3 3 3 3 3 3

PCI-X 133 Universal PCI-Short 3, 3 3 3 3 3

Network Interface Controllers (NICs)

Intel PILA8470D3 PRO100+ S

Server

Intel PILA8472C3 Pro/100+ Dual

Port

Intel PWLA8490MT Pro/1000MT

Gigabit Server

Intel PWLA8492MT Pro/1000MT

Dual Port

Gigabit Server

Intel EXPI9300PT 1 port, 1GbE PCI

Intel EXPI9400PT 1 port

1000Base-T,

PCI-32/33 Universal PCI-Short 1, 2, 3,

PCI-64/66 Universal PCI-Short 3, 5, 6,

PXI-X 133 Universal PCI-LP/RP 3, 5, 6,

Express

PCI

Express

Form

Factor

Microsoft

Windows

2003* EE

Microsoft

Windows

Server 2003*

EE EM64T

RedHat* EL4

Update2

RedHat* EL4

Update2

EM64T

SuSE* Linux

ES9 SP3

SuSE* Linux

ES9 SP3

EM64T

RedHat* EL4

Update4

RedHat* EL4

Update4

EM64T

RedHat* Linix

5

RedHat*

Linux 5

EM64T

SuSE* Linux

ES10

SuSE* Linux

ES 10

X4 PCI-Short 1 1 1 1 1 1 X4 PCI-Short 1 1 1 1 1 1

4,5,6, 7,11, 12,13

7, 8, 9, 10,11, 12,13

X1 PCI-Short 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

X1 PCI-Short 1, 2, 3,

4, 5, 6,

1, 2, 3, 4,5,6,7, 11,12, 13

3, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6,

1, 2, 3, 4

3 3 3 3 5, 6, 7,

1, 2, 3, 4

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9,

5, 6, 7, 8, 9, 10

5, 6, 7, 8, 9,

11,

11,12,13 5, 6, 7, 12, 13

11,

11,12,13 5, 6, 7, 12, 13

11,

11,12,13 5, 6, 7, 12, 13

11,

11,12,13 5, 6, 7, 12, 13

11,

11,12,13 5, 6, 7, 12, 13

11,

11,12,13 5, 6, 7, 12,

8, 9, 10,11, 12,13

8, 9,

5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7, 8, 9,

Revision 2.4

9

Adapters and Peripherals Intel® server board S3000AH

1Gb 7, 8, 9,

Intel EXPI9402PT 2 port

1000Base-T,

1Gb

Syskonnect* SK-9E21D 1 port

10/100/1000

LAN

Syskonnect SK-9E22 2 port

10/100/1000

LAN

PCI

Express

PCI

Express

PCI

Express

10,11, 12,13

X4 PCI-Short 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

X1 PCI-Short 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

X4 PCI-Short 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4

10 10 13 10,11,

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10

5, 6, 7, 8, 9, 10

11,

11,12,13 5, 6, 7, 12, 13

11,

11,12,13 5, 6, 7, 12, 13

11,

11,12,13 5, 6, 7, 12, 13

12,13

8, 9, 10,11, 12,13

10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

SCSI RAID Controllers

Intel SRCU42E 2 channel, U320 PCI

Express

Intel SRCU41L 1 channel, U320 PCI-64/66 Universal PCI-LP/RP 3, 5, 6,

LSI Logic MegaRAID

SCSI 320-2

LSI Logic MegaRAID

SCSI 320-1

Intel SRCU42X 2 channel, U320 PCI-X 133 Universal PCI-Short 3, 5, 6,

LSI Logic* MegaRAID 2 channel, U320 PCI X8 PCI-Med 1, 2, 3, 1, 2, 3, 1, 2, 1, 2, 3, 1, 2, 3, 1, 2, 3, 5, 6, 7, 5, 6, 7, 5, 6, 7, 5, 6, 7,

2 channel, U320 PCI-64/66 Universal PCI-Short 3, 5, 6,

1 channel, U320 PCI-64/66 Universal PCI-Short SA SA SA SA SA SA

X8 PCI-Med 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7,8,9, 10,11, 12,13

3, 5, 6, 7, 8, 9, 10,11, 12,13

3, 5, 6, 7,8,9, 10,11, 12,13

1, 2, 3, 4

3 3 3 3 5, 6, 7,

1, 2, 3, 4 1, 2, 3,4 1, 2, 3, 4 5, 6, 7,

8, 9, 10

5, 6, 7, 8, 9, 10

11,

11,12,13 5, 6, 7, 12, 13

11,

11,12,13 5, 6, 7, 12, 13

11,

11,12,13 5, 6, 7, 12, 13

11,

11,12,13 5, 6, 7, 12, 13

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

10 Revision 2.4

Intel® Server Board S3000AH Adapters and Peripherals

SCSI 320-2E Express 4, 5, 6,

7, 8, 9, 10,11, 12,13

4, 5, 6, 7,8,9, 10,11, 12,13

3, 4 4 4 4 8, 9,

10

8, 9, 10

8, 9, 10,11, 12,13

SATA RAID Controllers

Adaptec* AAR-2410SA 4-port, SATA

1.0, RAID 0, 1.

2x Silicon Image

w/Zion

Intel SRCS16 6 port, SATA

1.5G, RAID 0, 1, 10, 5, 50

Intel SRCS28X 8 port SATA

3.0G, RAID 0, 1, 10, 5, 50

LSI Logic MegaRAID

SATA 150-6

3ware **(see note2)

9650SE-2LP

6 port SATA

1.5G, RAID 0, 1,

10, 5

2 port SATA,

RAID 0, 1, and

JBOD

PCI-64/66 Universal PCI-LP 3, 5, 6,

7, 8, 9, 10,11, 12,13

PCI-64/66 Universal PCI-Med 3, 5, 6,

7, 8, 9, 10,11, 12,13

PCI-X 133 Universal PCI-Short 3, 5, 6,

7, 8, 9, 10,11, 12,13

PCI-64/66 Universal PCI-Short 3, 5, 6,

7, 8, 9, 10,11, 12,13

PCI

Express

X1 PCI-LP 11,12,

13

3, 5, 6, 7, 8, 9, 10,11, 12,13

11,12, 13

3 3 3 3 5, 6, 7,

8, 9, 10

3 3 3 3 5, 6, 7,

8, 9, 10

3 3 3 3 5, 6, 7,

8, 9, 10

3 3 3 3 5, 6, 7,

8, 9, 10

11,

5, 6, 7, 8, 9, 10

11, 12, 13

12, 13

11,12, 13

5, 6, 7, 8, 9, 10,11, 12,13

11,12,13 11,12,

5, 6, 7, 8, 9, 10,11, 12,13

13

SAS RAID Controllers

Intel SRCSAS18E SAS 3GB 8

internal ports

Intel SRCSAS144E SAS 3GB 4

internal ports

Adaptec ASR-

4805SAS

Adaptec ASC-48300 8 port SAS PCI-X 133 Universal PCI-LP/RP 3, 5, 6, 3, 5, 6, 3 3 3 3 5, 6, 7, 5, 6, 7, 11, 11,12,5, 6, 7, 5, 6, 7,

8-port SAS,

128MB DDR2

PCI

Express

PCI

Express

PCI

Express

X8 PCI-Med 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

X4 PCI-Med 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

X8 PCI-Med 1, 2, 3, 4 1, 2, 3, 4 1, 2,

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4

3, 4

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4

5, 6, 7, 8, 9, 10

11, 12, 13

11,12, 13

5, 6, 7, 8, 9, 10,11, 12,13

Revision 2.4

11

Adapters and Peripherals Intel® server board S3000AH

LSI Logic 3442x 8 port SW SAS

RAID

LSI Logic SAS3442E-R 8 port SW SAS

RAID

LSI Logic MegaRAID

SAS 8480E

LSI Logic MegaRAID

SAS

8308ELP

LSI Logic MegaRAID

SAS

8344ELP

LSI Logic MegaRAID

SAS 8408E

Brockton/1068

SAS 3GB 8

external ports

Brockton/1068

SAS 3GB 8

internal ports

Brockton/1068

SAS 3GB 4

internal / 4

external ports

Brockton/1068

SAS 3GB 8

internal ports

SCSI Controllers

LSI Logic LSI22320-R 2 channel U320

SCSI

Adaptec ASC-39320A-R 2 channel U320

SCSI,

2 external / 2

internal

connectors

Adaptec ASC-

29320ALP-R

1 channel U320

SCSI,

1 external / 1

internal

7, 8, 9, 10,11, 12,13

PCI-X 133 Universal PCI-LP/RP 3, 5, 6,

7, 8, 9, 10,11, 12,13

PCI

Express

PCI

Express

PCI

Express

PCI

Express

PCI

Express

PCI-X 133 Universal PCI-Short 3, 5, 6,

PCI-X 133 Universal PCI-LP/RP 3, 5, 6,

X4 PCI-LP/RP 5, 6, 7,

8, 9, 10,11, 12,13

X8 PCI-Med 2, 3, 4 2, 3, 4 2, 3, 4 2, 3, 4 2, 3, 4 2, 3, 4

X4 PCI-LP/RP 5, 6, 7,

8, 9, 10,11, 12,13

X4 PCI-LP/RP SA SA SA SA SA SA

X8 PCI-Med SA SA SA SA SA SA

7, 8, 9, 10,11, 12,13

3, 5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

3, 5, 6, 7, 8, 9, 10,11, 12,13

8, 9, 10

3 3 3 3 5, 6, 7,

8, 9, 10

5, 6, 7,

8, 9, 10

SA SA SA SA 5, 6, 7,

8, 9, 10

3 3 3 3 5, 6, 7,

8, 9, 10

3 3 3 3 5, 6, 7,

8, 9, 10

3 3 3 3 5, 6, 7,

8, 9, 10

5, 6, 7, 8, 9, 10

12,

13 8, 9,

13 11,

11,12,

12,

13

13 11,

11,12,

12,

13

11,

11,12,

12,

13

11,

11,12,

12,

13

13 11,

11,12,

12,

13

11,

11,12,

12,

13

10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

12 Revision 2.4

Intel® Server Board S3000AH Adapters and Peripherals

LSI Logic LSI20160 1 channel U160

SCSI, for tape

drive only

Adaptec ASC-29160 1 channel U160,

for tape drive

only

PCI-32/33 Universal PCI-LP/RP 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

PCI-64/66 Universal PCI-Short 3, 5, 6,

7, 8, 9, 10,11, 12,13

Video Controllers

ATI* RADEON

9200 128MB

DDR PCI

PCI video with

dual monitor

support

PCI-32/33 Universal PCI-Med 2, 3, 42, 3, 4 2, 3, 4 2, 3, 4 2, 3, 4 2, 3, 4

USB Drives

Maxtor* E01G300 Maxtor One

Touch II

USB 2.0 External 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

CD-ROM Drives

Mitsumi* SR244W1 SR244W1 IDE/Slimline

TEAC* CD552E/B/S CD-552E ATA 5.25x1.6 1, 2, 3,

5.25x0.5 1, 2, 3, 4, 5, 6, 7

4, 5, 6, 7, 8, 9, 10,11, 12,13

CD-RW Drives

Sony* CRX230AD/K CRX230AD/K ATA33 5.25x1.6 1, 2, 3,

4, 5, 6, 7

CD-RW / DVDROM Combo Drives

Lite On* LSC-

24082KX

Toshiba* SD-R2212 SD-R2212 IDE/Slimline 5.25x0.5 1, 2, 3,

LSC-24082KX USB 2.0 external 1, 2, 3, 4 1, 2, 3, 4 1, 2,

4, 5, 6, 7, 8, 9,

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

3, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7

1, 2, 3, 4, 5, 6, 7, 8, 9,

1, 2, 3, 4

3 3 3 3 5, 6, 7,

1, 2, 3, 4

3, 4 1, 2,

3, 4

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7 5, 6, 7 5, 6, 7 5, 6, 7

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7, 5, 6, 7 5, 6, 7 5, 6, 7

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11,

5, 6, 7, 8, 9, 10

5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11,

11,

11,12,

5, 6, 7,

12,

13

8, 9,

13

11, 12, 13

5, 6, 7,

11,12, 13

10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

8, 9, 10,11, 12,13

8, 9, 10,11, 12

8, 9, 10,11,

5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11,

Revision 2.4

13

Adapters and Peripherals Intel® server board S3000AH

10,11, 12,13

Samsung* SH-R522 SH-R522 ATA33 5.25x1.6 1, 2, 3,

4, 5, 6, 7,11, 12,13

Addonics* AEPDVRW88

8UM

AEPDVRW888UM USB 2.0 External 5, 6, 7,

8, 9, 10,11, 12,13

10,11, 12,13

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

12,13 12,13 12,13 12,13

1, 2, 3, 4

5, 6, 7,

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

DVD±R/RW CD-R/RW Drives

Plextor* PX-740UF PX-740UF USB 2.0 5.25x1.6 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

HLDS GWA-4082N GWA-4082N IDE/Slimline 5.25x0.5 2, 3, 4,

5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4

2, 3, 4 2, 3, 4 2, 3, 4 2, 3, 4 5, 6, 7,

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

DVD ROM Drives

Toshiba SD-M1912 SD-M1912 IDE 5.25x1.6 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

Sony DRX-720UL DRX-720UL USB 2.0 External 1, 2, 3,

4, 5, 6, 7

TEAC DV-28EN83 DV-28E IDE/Slimline 5.25x0.5 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7,11,12, 13

1, 2, 3, 4, 5, 6, 7

1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12,13

1, 2, 3, 4

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10, 11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7 5, 6, 7 5, 6, 7 5, 6, 7

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10, 11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

Input Devices

AOpen* KB858 KB-858 PS/2 External 1, 2, 3, 1, 2, 3, 1, 2, 1, 2, 3, 1, 2, 3, 1, 2, 3, 5, 6, 7, 5, 6, 7, 5, 6, 7, 5, 6, 7,

14 Revision 2.4

Intel® Server Board S3000AH Adapters and Peripherals

Keyboard

PS/2

AOpen O 35M Mini Optical

Mouse

Logitech* 931145-403 Logitech Optical

Mouse

Logitech 967415-0403 Logitech Media

Keyboard

Microsoft* B75-00092 Intellimouse

Optical

KVM switches

Belkin* F1DA108T Omniview Pro2

Series

Modems

3COM* USR3453B V.Everthing 56K

Analog

Corporate

Modem

Removable Media Devices

Iomega*

SKU 33136

Micro Mini™

1GB Drive

4, 5, 6, 7, 8, 9, 10,11, 12,13

PS/2 and

USB

PS/2 and

USB

PS/2 and

USB

PS/2 and

USB

PS/2 External 1, 2, 3,

RS-232 External 1, 2, 3,

USB 2.0 External 1, 2, 3,

External 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

External 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

External 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

External 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

4, 5, 6,

4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6,

3, 4 4 4 4 8, 9,

10,11, 12,13

1, 2, 3, 4

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7 5, 6, 7 5, 6, 7 5, 6, 7

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

Revision 2.4

15

Adapters and Peripherals Intel® server board S3000AH

7 7

Lexar* JD1GB-80-

231

Mitsumi D353FUE D353FUE USB External 1, 2, 3,

Sony PCGA-UFD5 VAIO External

TEAC FD-235HF FD-235HF Floppy 3.5x1 1, 5, 6, 7 1, 5, 6, 7 1 1 1 1 5, 6, 7 5, 6, 7 5, 6, 7 5, 6, 7

1GB USB Flash

Drive

USB floppy

USB 2.0 External 1, 2, 3,

4, 5, 6, 7

4, 5, 6, 7, 8, 9, 10,11, 12,13

USB External 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7 5, 6, 7 5, 6, 7 5, 6, 7

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

San Disk* SDCZ2-4096 Cruzer 4GB USB 2.0 External 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

PNY* P-

FD02GU206

2GB USB Flash

Drive

USB 2.0 External 5, 6, 7,

8, 9, 10,11, 12,13

Tape Drives

Certance* STD2401LW-S Certance DAT

40

Sony SDX-

700C/BM

Quantum CD72SH-SB DAT 72 SATA-300 3.5x1.6 5, 6, 7,

16 Revision 2.4

AIT-3 Desktop SCSI-U160 3.5x1.6 1, 2, 3,

SCSI-U2 3.5x1.6 1, 2, 3,

4, 5, 6, 7, 8, 9, 10,11, 12,13

4, 5, 6, 7

8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4, 5, 6, 7

5, 6, 7, 8, 9, 10,11, 12,13

1, 2, 3, 4

5, 6, 7,

1, 2, 3, 4

5, 6, 7,

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7,

8, 9, 10,11, 12,13

1, 2, 3, 4 1, 2, 3, 4 1, 2, 3, 4 5, 6, 7 5, 6, 7 5, 6, 7 5, 6, 7

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7,

8, 9, 10,11, 12,13

5, 6, 7, 8, 9, 10,11, 12,13

Intel® Server Board S3000AH Adapters and Peripherals

1． Notes: Blue shading indicates that device is available in a lead-free version. 2． Notes: Don’t select virtualization option on addition task with 3ware HBA populated during RHEL5 installation process. Otherwise the RHEL5

installation will not be completed

Revision 2.4

17

Intel S3000AH User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
