8XC196Lx Supplement to 8XC196Kx, 8XC196Jx, 87C196CA User’s Manual

August 2004

Order Number: 272973-003

Information in this document is provided in connection with Intel products. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel’s Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not intended for use in medical, life saving, or life sustaining applications.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined." Intel reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.

The 8XC196Lx, 8XC196Kx, 8XC196Jx and 87C196CA microprocessors may contain design defects or errors known as errata which may cause the products to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature may be obtained by calling 1-800-548-4725 or by visiting Intel’s website at http://www.intel.com.

Copyright © Intel Corporation, 2004

*Third-party brands and names are the property of their respective owners.



CONTENTS

CHAPTER 1



GUIDE TO THIS MANUAL



1.1

MANUAL CONTENTS ...................................................................................................

1-1

1.2

RELATED DOCUMENTS ..............................................................................................

1-2

CHAPTER 2



ARCHITECTURAL OVERVIEW



2.1

MICROCONTROLLER FEATURES ..............................................................................

2-1

2.2

BLOCK DIAGRAM.........................................................................................................

2-2

2.3

INTERNAL TIMING........................................................................................................

2-2

2.4

EXTERNAL TIMING ......................................................................................................

2-5

2.5

INTERNAL PERIPHERALS ...........................................................................................

2-6

2.5.1

I/O Ports ....................................................................................................................

2-7

2.5.2 Synchronous Serial I/O Port .....................................................................................

2-7

2.5.3

Event Processor Array ..............................................................................................

2-7

2.5.4

J1850 Communications Controller ............................................................................

2-7

2.6

DESIGN CONSIDERATIONS........................................................................................

2-7

CHAPTER 3



ADDRESS SPACE



3.1

ADDRESS PARTITIONS ...............................................................................................

3-1

3.2

REGISTER FILE............................................................................................................

3-2

3.3

PERIPHERAL SPECIAL-FUNCTION REGISTERS ......................................................

3-4

3.4

WINDOWING.................................................................................................................

3-6

CHAPTER 4



STANDARD AND PTS INTERRUPTS



4.1

INTERRUPT SOURCES, VECTORS, AND PRIORITIES .............................................

4-1

4.2

INTERRUPT REGISTERS.............................................................................................

4-2

4.2.1

Interrupt Mask Registers ...........................................................................................

4-3

4.2.2

Interrupt Pending Registers ......................................................................................

4-4

4.2.3 Peripheral Transaction Server Registers ..................................................................

4-6

CHAPTER 5



I/O PORTS



5.1

I/O PORTS OVERVIEW ................................................................................................

5-1

5.2

INTERNAL STRUCTURE FOR PORTS 1, 2, 5, AND 6 (BIDIRECTIONAL PORTS) ....

5-1

5.2.1 Configuring Ports 1, 2, 5, and 6 (Bidirectional Ports) ................................................

5-3

5.2.2 Special Bidirectional Port Considerations .................................................................

5-4

5.3

INTERNAL STRUCTURE FOR PORTS 3 AND 4 (ADDRESS/DATA BUS)..................

5-5

iii

8XC196LX SUPPLEMENT



CHAPTER 6



SYNCHRONOUS SERIAL I/O PORT



6.1 SSIO 0 CLOCK REGISTER...........................................................................................

6-1

6.2 SSIO 1 CLOCK REGISTER...........................................................................................

6-2

CHAPTER 7



EVENT PROCESSOR ARRAY



7.1

EPA FUNCTIONAL OVERVIEW ...................................................................................

7-1

7.1.1



EPA Mask Registers .................................................................................................

7-4

7.1.2



EPA Pending Registers ............................................................................................

7-5

7.1.3 EPA Interrupt Priority Vector Register .......................................................................

7-6

CHAPTER 8



J1850 COMMUNICATIONS CONTROLLER



8.1

J1850 FUNCTIONAL OVERVIEW.................................................................................

8-1

8.2 J1850 CONTROLLER SIGNALS AND REGISTERS.....................................................

8-3

8.3

J1850 CONTROLLER OPERATION .............................................................................

8-4

8.3.1



Control State Machine ..............................................................................................

8-4

8.3.1.1 Cyclic Redundancy Check Generator ..................................................................

8-4

8.3.1.2

Bus Contention .....................................................................................................

8-5

8.3.1.3

Bit Arbitration ........................................................................................................

8-5

8.3.1.4

Error Detection .....................................................................................................

8-5

8.3.2 Symbol Synchronization and Timing Circuitry ...........................................................

8-5

8.3.2.1

Clock Prescaler ....................................................................................................

8-6

8.3.2.2

Digital Filter ..........................................................................................................

8-6

8.3.2.3

Delay Compensation ............................................................................................

8-6

8.3.2.4 Symbol Encoding and Decoding ..........................................................................

8-6

8.3.3



Bit Arbitration Example .............................................................................................

8-7

8.4

MESSAGE FRAMES .....................................................................................................

8-8

8.4.1



Standard Messaging .................................................................................................

8-9

8.4.1.1

Header .................................................................................................................

8-9

8.4.1.2

CRC Byte .............................................................................................................

8-9

8.4.1.3

Normalization Bit ..................................................................................................

8-9

8.4.1.4 Start and End Message Frame Symbols ............................................................

8-10

8.4.2



In-frame Response Messaging ...............................................................................

8-12

8.4.2.1 IFR Messaging Type 1: Single Byte, Single Responder ....................................

8-12

8.4.2.2 IFR Messaging Type 2: Single Byte, Multiple Responders ................................

8-12

8.4.2.3 IFR Messaging Type 3: Multiple Bytes, Single Responder ................................

8-13

8.5 TRANSMITTING AND RECEIVING MESSAGES .......................................................

8-13

8.5.1



Transmitting Messages ...........................................................................................

8-13

8.5.2



Receiving Messages ...............................................................................................

8-15

8.5.3



IFR Messages .........................................................................................................

8-16

iv





CONTENTS

8.6

PROGRAMMING THE J1850 CONTROLLER ............................................................

8-16

8.6.1 Programming the J1850 Command (J_CMD) Register ..........................................

8-16

8.6.2 Programming the J1850 Configuration (J_CFG) Register ......................................

8-18

8.6.3 Programming the J1850 Delay Compensation (J_DLY) Register ...........................

8-19

8.6.4 Programming the J1850 Status (J_STAT) Register ................................................

8-21

CHAPTER 9



MINIMUM HARDWARE CONSIDERATIONS



9.1

IDENTIFYING THE RESET SOURCE...........................................................................

9-1

9.2

DESIGN CONSIDERATIONS FOR 8XC196LA, LB, AND LD .......................................

9-2

CHAPTER 10



SPECIAL OPERATING MODES



10.1

INTERNAL TIMING......................................................................................................

10-1

10.2

ENTERING AND EXITING ONCE MODE ...................................................................

10-2

CHAPTER 11



PROGRAMMING THE NONVOLATILE MEMORY



11.1

SIGNATURE WORD AND PROGRAMMING VOLTAGE VALUES.............................

11-1

11.2

OTPROM ADDRESS MAP ..........................................................................................

11-1

11.3

SLAVE PROGRAMMING CIRCUIT AND ADDRESS MAP .........................................

11-2

11.4

SERIAL PORT PROGRAMMING CIRCUIT AND ADDRESS MAP.............................

11-4

APPENDIX A



SIGNAL DESCRIPTIONS



A.1

FUNCTIONAL GROUPINGS OF SIGNALS .................................................................

A-1

A.2

DEFAULT CONDITIONS ..............................................................................................

A-7

GLOSSARY

v

8XC196LX SUPPLEMENT

FIGURES

Figure



Page

2-1

8XC196Lx Block Diagram ............................................................................................

2-2

2-2

Clock Circuitry (87C196LA, LB Only) ...........................................................................

2-3

2-3

Internal Clock Phases (Assumes PLL is Bypassed).....................................................

2-4

2-4

Effect of Clock Mode on Internal CLKOUT Frequency.................................................

2-5

2-5

Unerasable PROM 1 (USFR1) Register (LA, LB Only) ................................................

2-6

3-1

Register File Address Map ...........................................................................................

3-3

4-1

Interrupt Mask (INT_MASK) Register...........................................................................

4-3

4-2

Interrupt Mask 1 (INT_MASK1) Register......................................................................

4-4

4-3

Interrupt Pending (INT_PEND) Register ......................................................................

4-5

4-4

Interrupt Pending 1 (INT_PEND1) Register .................................................................

4-6

4-5

PTS Select (PTSSEL) Register....................................................................................

4-7

4-6

PTS Service (PTSSRV) Register .................................................................................

4-8

5-1

Ports 1, 2, 5, and 6 Internal Structure (87C196LA, LB Only) .......................................

5-3

5-2

Ports 3 and 4 Internal Structure (87C196LA, LB Only) ................................................

5-6

6-1

SSIO 0 Clock (SSIO0_CLK) Register...........................................................................

6-1

6-2

SSIO 1 Clock (SSIO1_CLK) Register...........................................................................

6-2

7-1

EPA Block Diagram (87C196LA, LB Only)...................................................................

7-2

7-2

EPA Block Diagram (83C196LD Only).........................................................................

7-3

7-3

EPA Interrupt Mask (EPA_MASK) Register .................................................................

7-4

7-4

EPA Interrupt Mask 1 (EPA_MASK1) Register ............................................................

7-4

7-5

EPA Interrupt Pending (EPA_PEND) Register.............................................................

7-5

7-6

EPA Interrupt Pending 1 (EPA_PEND1) Register........................................................

7-5

7-7

EPA Interrupt Priority Vector Register (EPAIPV)..........................................................

7-6

8-1

Integrated J1850 Communications Protocol Solution...................................................

8-1

8-2

J1850 Communications Controller Block Diagram .......................................................

8-2

8-3

Huntzicker Symbol Definition for J1850........................................................................

8-7

8-4

Typical VPW Waveform................................................................................................

8-7

8-5

Bit Arbitration Example .................................................................................................

8-8

8-6

J1850 Message Frames...............................................................................................

8-9

8-7

Huntzicker Symbol Definition for the Normalization Bit ..............................................

8-10

8-8

Definition for Start and End of Frame Symbols ..........................................................

8-11

8-9

IFR Type 1 Message Frame.......................................................................................

8-12

8-10

IFR Type 2 Message Frame.......................................................................................

8-13

8-11

IFR Type 3 Message Frame.......................................................................................

8-13

8-13

J1850 Transmit Message Structure............................................................................

8-14

8-12

J1850 Transmitter (J_TX) Register ............................................................................

8-14

8-15

J1850 Receive Message Structure.............................................................................

8-15

8-14

J1850 Receiver (J_RX) Register................................................................................

8-15

8-16

J1850 Command (J_CMD) Register ..........................................................................

8-17

8-17

J1850 Configuration (J_CFG) Register ......................................................................

8-18

8-18

J1850 Delay (J_DLY) Register ...................................................................................

8-20

8-19

J1850 Status (J_STAT) Register................................................................................

8-21

9-1

Reset Source (RSTSRC) Register ...............................................................................

9-1

10-1

Clock Circuitry (87C196LA, LB Only) .........................................................................

10-2

vi





CONTENTS



FIGURES



Figure



Page

11-1

Slave Programming Circuit.........................................................................................

11-3

11-2

Serial Port Programming Circuit .................................................................................

11-4

A-1

87C196LA 52-pin PLCC Package ...............................................................................

A-3

A-2

87C196LB 52-pin PLCC Package ...............................................................................

A-5

A-3

83C196LD 52-pin PLCC Package...............................................................................

A-7

vii

8XC196LX SUPPLEMENT

TABLES

Table



Page

1-1

Related Documents ......................................................................................................

1-2

2-1

Features of the 8XC196Lx and 8XC196Kx Product Famiies .......................................

2-1

2-2

State Times at Various Frequencies ............................................................................

2-4

2-3

Relationships Between Input Frequency, Clock Multiplier, and State Times ...............

2-5

2-4

UPROM Programming Values and Locations ..............................................................

2-6

3-1

Address Map ................................................................................................................

3-1

3-2

Register File Memory Addresses .................................................................................

3-3

3-3

8XC196Lx Peripheral SFRs .........................................................................................

3-4

3-4

Windows .......................................................................................................................

3-6

4-1

Interrupt Sources, Vectors, and Priorities.....................................................................

4-2

5-1

Microcontroller Ports.....................................................................................................

5-1

7-1

EPA Channels ..............................................................................................................

7-1

7-2

EPA Interrupt Priority Vectors.......................................................................................

7-6

8-1

J1850 Controller Signals ..............................................................................................

8-3

8-2

Control and Status Registers .......................................................................................

8-3

8-3

Relationships Between Input Frequency, PLL, and Prescaler Bits ..............................

8-6

8-4

Huntzicker Symbol Timing Characteristics .................................................................

8-11

11-1

Signature Word and Programming Voltage Values....................................................

11-1

11-2

87C196LA, LB OTPROM Address Map .....................................................................

11-2

11-3

Slave Programming Mode Address Map....................................................................

11-3

11-4

Serial Port Programming Mode Address Map ............................................................

11-5

A-1

87C196LA Signals Arranged by Functional Categories ..............................................

A-2

A-2

87C196LB Signals Arranged by Functional Categories ..............................................

A-4

A-3

83C196LD Signals Arranged by Functional Categories ..............................................

A-6

A-4

Definition of Status Symbols .......................................................................................

A-7

A-5

87C196LA, LB Default Signal Conditions....................................................................

A-8

A-6

83C196LD Default Signal Conditions ..........................................................................

A-9

viii

1

Guide to This Manual

CHAPTER 1

GUIDE TO THIS MANUAL

This document is a supplement to the 8XC196Kx, 8XC196Jx, 87C196CA Microcontroller Family User’s Manual. It describes the differences between the 8XC196Lx and the 8XC196Kx family of microcontrollers. For information not found in this supplement, please consult the 8XC196Kx, 8XC196Jx, 87C196CA Microcontroller Family User’s Manual (order number 272258) or the 8XC196Lx datasheets listed in the “Related Documents” section of this chapter.

1.1MANUAL CONTENTS

This supplement contains several chapters, an appendix, a glossary, and an index. This chapter, Chapter 1, provides an overview of the supplement. This section summarizes the contents of the remaining chapters and appendixes. The remainder of this chapter provides references to related documentation.

Chapter 2 Architectural Overview — compares the features of the 8XC196Lx microcontroller family with those of the 8XC196Kx microcontroller family and describes the 87C196LA, LB internal clock circuitry.

Chapter 3 Address Space — describes the addressable memory space of the 52-pin 8XC196Lx, lists the peripheral special-function registers (SFRs), and provides tables of WSR values for windowing higher memory into the lower register file for direct access.

Chapter 4 Standard and PTS Interrupts — describes the additional interrupts for the 87C196LB’s J1850 communications controller peripheral and the SFRs that support those interrupts.

Chapter 5 — I/O Ports — state from a “logic 1” to

describes the port differences and explains the change in the port reset a “logic 0” on the 87C196LA, LB.

Chapter 6 — Synchronous Serial I/O Port —

describes the enhanced synchronous serial I/O

(SSIO) port and explains how to program the two additional peripheral SFRs.

Chapter 7 — Event Processor Array —

describes the event processor array channel differenc-

es.





Chapter 8 — J1850 Communications Controller — describes the 87C196LB’s integrated J1850 controller and explains how to configure it.

Chapter 9 — Minimum Hardware Considerations — describes device reset options through the reset source register, and discusses hardware design considerations.

Chapter 10 Special Operating Modes — illustrates the internal clock control circuitry of the 87C196LA, LB and describes how to enter and exit on-circuit emulation (ONCE) mode.

Chapter 11 — Programming the Nonvolatile Memory — describes the memory maps and recommended circuits to support programming of the 87C196LA, LB’s 24 Kbytes of OTPROM.

1-1

8XC196LX SUPPLEMENT

Appendix A Signal Descriptions — provides reference information for the 8XC196Lx device pins, including descriptions of the pin functions, reset status of the I/O and control pins, and package pin assignments.

Glossary — defines terms with special meaning used throughout this supplement.

Index — lists key topics with page number references.

1.2RELATED DOCUMENTS

Table 1-1 lists additional documents that you may find useful in designing systems incorporating the 8XC196Lx microcontrollers.

Table 1-1. Related Documents

Title and Description

Order Number





8XC196Kx, 8XC196Jx, 87C196CA Microcontroller Family User’s Manual

272258

87C196LA-20 MHz CHMOS 16-Bit Microcontroller Automotive datasheet

272806

87C196LB-20 MHz CHMOS 16-Bit Microcontroller Automotive datasheet

272807

83C196LD CHMOS 16-Bit Microcontroller Automotive datasheet

272805

1-2

2

Architectural

Overview

CHAPTER 2

ARCHITECTURAL OVERVIEW

This chapter describes architectural differences between the 8XC196Lx (87C196LA, 87C196LB, and 83C196LD) and the 8XC196Kx (8XC196Kx, 8XC196Jx, and 87C196CA) microcontroller families. Both the 8XC196Lx and the 8XC196Kx are designed for high-speed calculations and fast I/O, and share a common architecture and instruction set with few deviations. This chapter provides a high-level overview of the deviations between the two families.

NOTE

This supplement describes two product families within the MCS® 96 microcontroller family. For brevity, the name 8XC196Lx is used when the discussion applies to all three Lx controllers. Likewise, the name 8XC196Kx is used when the discussion applies to all the Kx, Jx, and CA controllers.

2.1MICROCONTROLLER FEATURES

Table 2-1 lists the features of the 8XC196Lx and the 8XC196Kx.

Table 2-1. Features of the 8XC196Lx and 8XC196Kx Product Famiies





OTPROM/

Register

Code

I/O

EPA

SIO/







Ext.

Device

Pins

EPROM/

SSIO

A/D

CAN

J1850

Interrupt

RAM (2)

RAM

Pins

Pins





ROM (1)

Ports







Pins











































87C196LA

52

24 K

768

41

6

3

6

1

























87C196LB

52

24 K

768

41

6

3

6

1

1

























83C196LD

52

16 K

384

41

6

3

1

























8XC196JV

52

48 K

1536

512

41

6

3

6

1

























8XC196KT

68

32 K

1024

512

56

10

3

8

2

























8XC196JT

52

32 K

1024

512

41

6

3

6

1

























87C196CA

68

32 K

1024

256

51

6

3

6

1

2

























8XC196KR

68

16 K

512

256

56

10

3

8

2

























8XC196JR

52

16 K

512

256

41

6

3

6

1

























NOTES:

1.Optional. The second character of the device name indicates the presence and type of nonvolatile memory. 80C196xx = none; 83C196xx = ROM; 87C196xx = OTPROM or EPROM.

2.Register RAM amounts include the 24 bytes allocated to core SFRs and the stack pointer.

2-1

8XC196LX SUPPLEMENT

2.2BLOCK DIAGRAM

Figure 2-1 is a simplified block diagram that shows the major blocks within the microcontroller. Observe that the slave port peripheral does not exist on the 8XC196Lx.

















Core

Optional



Interrupt





(CPU, Memory

ROM/









Controller





Controller)

OTPROM





































Peripheral





Clock and



Optional









Code/Data



Transaction





Power Mgmt.











RAM



Server



























I/O

SIO

SSIO

EPA

A/D

WDT

J1850

Note:

The J1850 peripheral is unique to the 87C196LB device.

The A/D peripheral is unique to the 87C196LA, LB devices.

A5253-01

Figure 2-1. 8XC196Lx Block Diagram

2.3INTERNAL TIMING

The 87C196LA, LB clock circuitry (Figure 2-2) implements a phase-locked loop and clock multiplier circuitry, which can substantially increase the CPU clock rate while using a lower-frequen- cy input clock. The clock circuitry accepts an input clock signal on XTAL1 provided by an external crystal or oscillator. Depending on the value of the PLLEN pin, this frequency is routed either through the phase-locked loop and multiplier or directly to the divide-by-two circuit. The multiplier circuitry can double the input frequency (FXTAL1) before the frequency (f) reaches the divide-by-two circuitry. The clock generators accept the divided input frequency (f/2) from the divide-by-two circuit and produce two nonoverlapping internal timing signals, PH1 and PH2. These signals are active when high.

NOTE

This manual uses lowercase “f” to represent the internal clock frequency. For

the 87C196LA and LB, f is equal to either FXTAL1 or 2FXTAL1, depending on the clock multiplier mode, which is controlled by the PLLEN input pin.

2-2

ARCHITECTURAL OVERVIEW

FXTAL1

XTAL1

XTAL2

Disable Oscillator (Powerdown)









Disable

Phase





Filter











PLL















Comparator









(Powerdown)





















































































Phase-locked



























































































Oscillator







































XTAL1

XTAL1









PLLEN



Phase-locked Loop

































Clock Multiplier

F

2F

1















































































0













































f





































Disable Clock Input (Powerdown)





























































Divide by two

























Circuit



















































f/2



To reset logic





Disable Clocks (Idle, Powerdown)

Clock

Clock

CPU Clocks (PH1, PH2)

Failure



Generators



Detection

Peripheral Clocks (PH1, PH2)







f/2





Programmable



OSC

Divider





(CLK1:0)









0





CLKOUT





1





Disable Clocks (Powerdown)





A5290-01

Figure 2-2. Clock Circuitry (87C196LA, LB Only)

The rising edges of PH1 and PH2 generate the internal CLKOUT signal (Figure 2-3). The clock circuitry routes separate internal clock signals to the CPU and the peripherals to provide flexibility in power management. It also outputs the CLKOUT signal on the CLKOUT pin. Because of the complex logic in the clock circuitry, the signal on the CLKOUT pin is a delayed version of the internal CLKOUT signal. This delay varies with temperature and voltage.

2-3

8XC196LX SUPPLEMENT

XTAL1

t t

1 State Time



1 State Time



PH1

PH2

CLKOUT

Phase 1

Phase 2

Phase 1

Phase 2

A0805-01

Figure 2-3. Internal Clock Phases (Assumes PLL is Bypassed)

The combined period of phase 1 and phase 2 of the internal CLKOUT signal defines the basic time unit known as a state time or state. Table 2-2 lists state time durations at various frequencies.

Table 2-2. State Times at Various Frequencies

f



(Frequency Input to the

State Time

Divide-by-two Circuit)







8 MHz

250 ns





12 MHz

167 ns





16 MHz

125 ns





20 MHz

100 ns





The following formulas calculate the frequency of PH1 and PH2, the duration of a state time, and the duration of a clock period (t).

f

2

1

PH1 (in MHz) = -- = PH2

State Time (in µs) = --

t = --

2

f

f

Because the device can operate at many frequencies, this manual defines time requirements (such as instruction execution times) in terms of state times rather than specific measurements. Datasheets list AC characteristics in terms of clock periods (t; sometimes called Tosc).

Figure 2-4 illustrates the timing relationships between the input frequency (FXTAL1), the operating frequency (f), and the CLKOUT signal with each PLLEN pin configuration. Table 2-3 details the relationships between the input frequency (FXTAL1), the PLLEN pin, the operating frequency (f), the clock period (t), and state times.

2-4

ARCHITECTURAL OVERVIEW



TXHCH

XTAL1



(16 MHz)



f



PLLEN = 0

t = 62.5ns

Internal



CLKOUT



f



PLLEN = 1

t = 31.25ns

Internal



CLKOUT





A3376-01

Figure 2-4. Effect of Clock Mode on Internal CLKOUT Frequency

Table 2-3. Relationships Between Input Frequency, Clock Multiplier, and State Times

FXTAL1

PLLEN

Multiplier

f

t

State Time

(Frequency

(Input Frequency to

(Clock

on XTAL1)





the Divide-by-two Circuit)

Period)















4 MHz

0

1

4 MHz

250 ns

500 ns

8 MHz

0

1

8 MHz

125 ns

250 ns

12 MHz

0

1

12 MHz

83.5 ns

167 ns

16 MHz

0

1

16 MHz

62.5 ns

125 ns

20 MHz

0

1

20 MHz

50 ns

100 ns

4 MHz

1

2

8 MHz

125 ns

250 ns

8 MHz

1

2

16 MHz

62.5 ns

125 ns

10 MHz

1

2

20 MHz

50 ns

100 ns

2.4EXTERNAL TIMING

You can control the output frequency on the CLKOUT pin by programming two uneraseable PROM bits. Figure 2-5 illustrates the read-only USFR1, which reflects the state of the unerasable PROM bits. You can select one of three frequencies: f/2, f/4, or f/8. As Figure 2-2 on page 2-3 shows, the configurable divider accepts the output of the clock generators (f/2) and further divides that frequency to produce the desired output frequency. The CLK1:0 bits control the divisor (divide f/2 by either 1, 2, or 4).

2-5

8XC196LX SUPPLEMENT

USFR1 (read only)

Address:

1FF2H



Reset State:

XXH

The UPROM special-function register 1 (USFR1) reflects the status of unerasable, programmable read-only memory (UPROM) locations. This read-only register reflects the status of two bits that control the output frequency on CLKOUT.

7





















0









CLK1

CLK0

























Bit

Bit













Function





Number

Mnemonic

























































7:2

Reserved.

































1:0

CLK1:0

CLKOUT Control

















These bits reflect the programmed frequency of the CLKOUT signal:





CLK1 CLK0



















0

0



divide by 1 (CLKOUT = f/2)









0

1



divide by 2 (CLKOUT = f/4)









1

0



divide by 4 (CLKOUT = f/8)









1

1



divide by 1 (CLKOUT = f/2)





























Figure 2-5. Unerasable PROM 1 (USFR1) Register (LA, LB Only)

To program these bits, write the correct value to the locations shown in Table 2-4 using slave programming mode. During normal operation, you can determine the values of these bits by reading the UPROM SFR (Figure 2-5).

You can verify a UPROM bit to make sure it programmed, but you cannot erase it. For this reason, Intel cannot test the bits before shipment. However, Intel does test the features that the UPROM bits enable, so the only undetectable defects are (unlikely) defects within the UPROM cells themselves.

Table 2-4. UPROM Programming Values and Locations

To set this bit

Write this value

To this location







CLK0

0001H

0768H







CLK1

0002H

0728H







2.5INTERNAL PERIPHERALS

The internal peripheral modules provide special functions for a variety of applications. This section provides a brief description of the peripherals that differ between the 8XC196Lx and the 8XC196Kx families.

2-6

ARCHITECTURAL OVERVIEW

2.5.1I/O Ports

The I/O ports of the 8XC196Lx are functionally identical to those of the 8XC196Jx. However, on the 87C196LA and LB the reset state level of all 41 general-purpose I/O pins has changed from a weak logic “1” (wk1) to a weak logic “0” (wk0).

2.5.2Synchronous Serial I/O Port

The synchronous serial I/O (SSIO) port on the 8XC196Lx has been enhanced, implementing two new special function registers (SSIO0_CLK and SSIO1_CLK) that allow you to select the operating mode and configure the phase and polarity of the serial clock signals.

2.5.3Event Processor Array

The 8XC196Lx’s event processor array (EPA) is functionally identical to that of the 8XC196Jx, except that it has only two EPA capture/compare channels without pins instead of four. In addition the LD has no compare-only channels.

2.5.4J1850 Communications Controller

The 87C196LB microcontroller has a peripheral not found on the 8XC196Kx microcontrollers or any other Lx microcontroller, the J1850 peripheral. The J1850 communications controller manages communications between multiple network nodes. This integrated peripheral supports the 10.4 Kb/s VPW (variable pulse-width) medium-speed, class B, in-vehicle network protocol. It also supports both the standard and in-frame response (IFR) message framing as specified by the

Society of Automotive Engineering (SAE) J1850 (revised May 1994) technical standards.

2.6DESIGN CONSIDERATIONS

With the exception of a few new multiplexed functions, the 8XC196Lx microcontrollers are pin compatible with the 8XC196Jx microcontrollers. The 8XC196Jx microcontrollers are 52-lead versions of 8XC196Kx microcontrollers. For registers that are implemented in both the 8XC196Lx and the 8XC196Jx, configure the 8XC196Lx register as you would for the 8XC196Jx unless differences are noted in this supplement.

2-7

3

Address Space

CHAPTER 3

ADDRESS SPACE

This chapter describes the differences in the address space of the 8XC196Lx from that of the 8XC196Kx.

3.1ADDRESS PARTITIONS

Table 3-1 is an address map of the 8XC196Lx and 8XC196Kx microcontroller family members.

Table 3-1. Address Map



Device and Hex Address Range



























Addressing

CA

KRJR,

LD

LBLA,



KTJT,



JV

Description





Modes























































FFFF

FFFF

FFFF

FFFF



FFFF



FFFF

External device (memory

Indirect or





or I/O) connected to

A000

6000

6000

8000



A000



E000

indexed





address/data bus



































Program memory



9FFF

5FFF

5FFF

7FFF



9FFF



DFFF

(internal nonvolatile or

Indirect or

2080

2080

2080

2080



2080



2080

external memory); see

indexed

















Note 1



207F

207F

207F

207F



207F



207F

Special-purpose memory

Indirect or





(internal nonvolatile or

2000

2000

2000

2000



2000



2000

indexed





external memory)



















1FFF

1FFF

1FFF

1FFF



1FFF



1FFF

Memory-mapped SFRs

Indirect or

1FE0

1FE0

1FE0

1FE0



1FE0



1FE0

indexed























Peripheral SFRs

Indirect,

1FDF

1FDF

1FDF

1FDF



1FDF



1FDF

indexed, or





(Includes J1850 SFRs on

1F00

1F00

1F00

1F00



1F00



1F00

windowed





87C196LB)

















direct





































Indirect,

1EFF



CAN

SFRs

indexed, or

1E00



windowed



































direct

















External device (memory



1DFF

1EFF

1EFF

1EFF



1EFF



1EFF

or I/O) connected to

Indirect or





address/data bus;

1C00

1C00

1C00

0300



1C00



1E00

indexed





(future SFR expansion;



































see Note 2)





















Indirect,



1DFF

Register RAM

indexed, or



1C00

windowed



































direct

NOTES:

1.After a reset, the device fetches its first instruction from 2080H.

2.The content or function of these locations may change in future device revisions, in which case a program that relies on a location in this range might not function properly.

3-1

8XC196LX SUPPLEMENT

Table 3-1. Address Map (Continued)



Device and Hex Address Range





















Addressing

CA

KRJR,

LD

LBLA,

KTJT,

JV

Description

Modes











































1BFF

1BFF

1BFF



1BFF

1BFF

External device (memory

Indirect or

or I/O) connected to

0500

0500

0600

0600

0600

indexed



address/data bus















04FF

04FF

05FF

05FF

Internal code or data RAM

Indirect or

0400

0400

0400

0400

indexed









03FF

05FF







External device (memory

Indirect or

or I/O) connected to

0200

0180

indexed









address/data bus



























Upper register file

Indirect,

03FF

01FF

017F

02FF

03FF

03FF

indexed, or

(general-purpose register

0100

0100

0100

0100

0100

0100

windowed

RAM)













direct















00FF

00FF

00FF

00FF

00FF

00FF

Lower register file

Direct,

(register RAM, stack

indirect, or

0000

0000

0000

0000

0000

0000

pointer, and CPU SFRs)

indexed













NOTES:

1.After a reset, the device fetches its first instruction from 2080H.

2.The content or function of these locations may change in future device revisions, in which case a program that relies on a location in this range might not function properly.

3.2REGISTER FILE

Figure 3-1 compares the register file addresses of the 8XC196Lx and 8XC196Kx. The register file in Figure 3-1 is divided into an upper register file and a lower register file. The upper register file consists of general-purpose register RAM. The lower register file contains general-purpose register RAM along with the stack pointer (SP) and the CPU special-function registers (SFRs).

Table 3-2 lists the register file memory addresses. The RALU accesses the lower register file directly, without the use of the memory controller. It also accesses a windowed location directly (see “Windowing” on page 3-6). The upper register file and the peripheral SFRs can be windowed. Registers in the lower register file and registers being windowed can be accessed with register-direct addressing.

NOTE

The register file must not contain code. An attempt to execute an instruction from a location in the register file causes the memory controller to fetch the instruction from external memory.

3-2

ADDRESS SPACE



























Address



























03FFH



























(CA, JT, JV, KT)























General-purpose



























Register RAM































02FFH (LA, LB)



























01FFH (JR, KR)



























017FH (LD)





Address

















0100H







03FFH













General-purpose

00FFH







Upper













































0100H

Register File







Register RAM

001AH













































Stack Pointer

0019H







00FFH



















Lower











0018H



































Register File







CPU SFRs

0017H







0000H







0000H























































A5260-01



































Figure 3-1. Register File Address Map















Table 3-2. Register File Memory Addresses



































Device and Hex Address Range





Description



Addressing Modes



























JV



CA,JT,KT

LA, LB

JR, KR



LD

















































1DFF



Register RAM



Indirect, indexed, or

1C00





windowed direct

























03FF



03FF

02FF

01FF



017F

Upper register file (register RAM)



Indirect, indexed, or

0100



0100



0100

0100



0100



windowed direct















00FF



00FF

00FF

00FF



00FF

Lower register file (register RAM)



Direct, indirect, or

001A



001A

001A

001A



001A



indexed













0019



0019



0019

0019



0019

Lower register file (stack pointer)



Direct, indirect, or

0018



0018



0018

0018



0018



indexed















0017



0017



0017

0017



0017

Lower register file (CPU SFRs)



Direct, indirect, or

0000



0000



0000

0000



0000



indexed















3-3

8XC196LX SUPPLEMENT

3.3PERIPHERAL SPECIAL-FUNCTION REGISTERS

Table 3-3 lists the peripheral SFR addresses. Highlighted addresses are unique to the 8XC196Lx.

Table 3-3. 8XC196Lx Peripheral SFRs

Ports 3, 4, 5, and UPROM SFRs

Address

High (Odd) Byte

Low (Even) Byte

1FFEH

P4_PIN

P3_PIN

1FFCH

P4_REG

P3_REG

1FFAH

SLP_CON

SLP_CMD

1FF8H

Reserved

SLP_STAT

1FF6H

P5_PIN

USFR

1FF4H

P5_REG

P34_DRV

1FF2H

P5_DIR

USFR1 (LA, LB)

1FF0H

P5_MODE

Reserved

1FEEH

Reserved

Reserved

1FECH

Reserved

Reserved

1FEAH

Reserved

Reserved

1FE8H

Reserved

Reserved

1FE6H

Reserved

Reserved

1FE4H

Reserved

Reserved

1FE2H

Reserved

Reserved

1FE0H

Reserved

Reserved

Must be addressed as a word.

Ports 0, 1, 2, and 6 SFRs

Address

High (Odd) Byte

Low (Even) Byte

1FDEH

Reserved

Reserved

1FDCH

Reserved

Reserved

1FDAH

Reserved

P0_PIN

1FD8H

Reserved

Reserved

1FD6H

P6_PIN

P1_PIN

1FD4H

P6_REG

P1_REG

1FD2H

P6_DIR

P1_DIR

1FD0H

P6_MODE

P1_MODE

1FCEH

P2_PIN

Reserved

1FCCH

P2_REG

Reserved

1FCAH

P2_DIR

Reserved

1FC8H

P2_MODE

Reserved

1FC6H

Reserved

Reserved

1FC4H

Reserved

Reserved

1FC2H

Reserved

Reserved

1FC0H

Reserved

Reserved

3-4

ADDRESS SPACE

Table 3-3. 8XC196Lx Peripheral SFRs (Continued)

SIO and SSIO SFRs

Address

High (Odd) Byte

Low (Even) Byte

1FBEH

Reserved

Reserved

1FBCH

SP_BAUD (H)

SP_BAUD (L)

1FBAH

SP_CON

SBUF_TX

1FB8H

SP_STATUS

SBUF_RX

1FB6H

SSIO1_CLK

Reserved

1FB4H

SSIO0_CLK

SSIO_BAUD

1FB2H

SSIO1_CON

SSIO1_BUF

1FB0H

SSIO0_CON

SSIO0_BUF



A/D SFRs (LA, LB Only)

Address

High (Odd) Byte

Low (Even) Byte

1FAEH

AD_TIME

AD_TEST

1FACH

Reserved

AD_COMMAND

1FAAH

AD_RESULT (H)

AD_RESULT (L)



EPA Interrupt SFRs

Address

High (Odd) Byte

Low (Even) Byte

1FA8H

Reserved

EPAIPV

1FA6H

Reserved

EPA_PEND1

1FA4H

Reserved

EPA_MASK1

1FA2H

EPA_PEND (H)

EPA_PEND (L)

1FA0H

EPA_MASK (H)

EPA_MASK (L)

Timer 1, Timer 2, and EPA SFRs

Address

High (Odd) Byte

Low (Even) Byte

1F9EH

TIMER2 (H)

TIMER2 (L)

1F9CH

Reserved

T2CONTROL

1F9AH

TIMER1 (H)

TIMER1 (L)

1F98H

Reserved

T1CONTROL

1F96H

Reserved

Reserved

1F94H

Reserved

Reserved

1F92H

Reserved

RST_SRC

1F90H

Reserved

Reserved



EPA SFRs



Address

High (Odd) Byte

Low (Even) Byte

1F8EH

COMP1_TIME (H)

COMP1_TIME (L)

1F8CH

Reserved

COMP1_CON

1F8AH

COMP0_TIME (H)

COMP0_TIME (L)

1F88H

Reserved

COMP0_CON

1F86H

EPA9_TIME (H)

EPA9_TIME (L)

1F84H

Reserved

EPA9_CON

1F82H

EPA8_TIME (H)

EPA8_TIME (L)

1F80H

Reserved

EPA8_CON

Must be addressed as a word.

EPA SFRs (Continued)

Address

High (Odd) Byte

Low (Even) Byte

1F7EH

EPA7_TIME (H)

EPA7_TIME (L)

1F7CH

Reserved

EPA7_CON

1F7AH

EPA6_TIME (H)

EPA6_TIME (L)

1F78H

Reserved

EPA6_CON

1F76H

EPA5_TIME (H)

EPA5_TIME (L)

1F74H

Reserved

EPA5_CON

1F72H

EPA4_TIME (H)

EPA4_TIME (L)

1F70H

Reserved

EPA4_CON

1F6EH

EPA3_TIME (H)

EPA3_TIME (L)

1F6CH

EPA3_CON (H)

EPA3_CON (L)

1F6AH

EPA2_TIME (H)

EPA2_TIME (L)

1F68H

Reserved

EPA2_CON

1F66H

EPA1_TIME (H)

EPA1_TIME (L)

1F64H

EPA1_CON (H)

EPA1_CON (L)

1F62H

EPA0_TIME (H)

EPA0_TIME (L)

1F60H

Reserved

EPA0_CON



J1850 SFRs (LB Only)

Address

High (Odd) Byte

Low (Even) Byte

1F5EH

Reserved

Reserved

1F5CH

Reserved

Reserved

1F5AH

Reserved

Reserved

1F58H

Reserved

J_DLY

1F56H

Reserved

Reserved

1F54H

Reserved

J_CFG

1F52H

J_STAT

J_RX

1F50H

J_CMD

J_TX

3-5

8XC196LX SUPPLEMENT

3.4WINDOWING

Windowing maps a segment of higher memory (the upper register file or peripheral SFRs) into the lower register file. The window selection register (WSR) selects a 32-, 64or 128-byte segment of higher memory to be windowed into the top of the lower register file space. Table 3-4 lists the WSR values for windowing the upper register file for both the 8XC196Lx and 8XC196Kx.

Table 3-4. Windows





WSR Value

WSR Value

WSR Value for

Base



128-byte



for 32-byte Window

for 64-byte Window

Address



Window



(00E0–00FFH)

(00C0–00FFH)





(0080–00FFH)



















Peripheral SFRs















1FE0H



7FH (Note)





1FC0H



7EH

3FH (Note)



1FA0H



7DH





1F80H



7CH

3EH

1FH (Note)

1F60H



7BH





1F40H



7AH

3DH



1F20H



79H





1F00H



78H

3CH

1EH

CAN Peripheral SFRs (87C196CA Only)













1EE0H



77H





1EC0H



76H

3BH



1EA0H



75H





1E80H



74H

3AH

1DH

1E60H



73H





1E40H



72H

39H



1E20H



71H





1E00H



70H

38H

1CH

Register RAM (87C196JV Only)













1DE0H



6FH





1DC0H



6EH

37H



1DA0H



6DH





1D80H



6CH

36H

1BH

1D60H



6BH





1D40H



6AH

35H



1D20H



69H





1D00H



68H

34H

1AH

NOTE: Locations 1FE0–1FFFH contain memory-mapped SFRs that cannot be accessed through a window. Reading these locations through a window returns FFH; writing these locations through a window has no effect.

3-6









ADDRESS SPACE



Table 3-4. Windows (Continued)



















WSR Value



WSR Value

WSR Value for



Base



128-byte



for 32-byte Window



for 64-byte Window



Address



Window



(00E0–00FFH)



(00C0–00FFH)







(0080–00FFH)

























Register RAM (87C196JV Only; Continued)



















1CE0H

67H









1CC0H

66H



33H





1CA0H

65H









1C80H

64H



32H

19H



1C60H

63H









1C40H

62H



31H





1C20H

61H









1C00H

60H



30H

18H



Upper Register File (CA, JT, JV, KT)



















03E0H

5FH









03C0H

5EH



2FH





03A0H

5DH









0380H

5CH



2EH

17H



0360H

5BH









0340H

5AH



2DH





0320H

59H









0300H

58H



2CH

16H



Upper Register File (CA, JT, JV, KT, LA, LB)



















02E0H

57H









02C0H

56H



2BH





02A0H

55H









0280H

54H



2AH

15H



0260H

53H









0240H

52H



29H





0220H

51H









0200H

50H



28H

14H



Upper Register File (CA, JR, JT, JV, KR, KT, LA, LB)



















01E0H

4FH









01C0H

4EH



27H





01A0H

4DH









0180H

4CH



26H

13H



NOTE: Locations 1FE0–1FFFH contain memory-mapped SFRs that cannot be accessed through a window. Reading these locations through a window returns FFH; writing these locations through a window has no effect.

3-7

8XC196LX SUPPLEMENT

Table 3-4. Windows (Continued)



WSR Value

WSR Value

WSR Value for

Base

128-byte

for 32-byte Window

for 64-byte Window

Address

Window

(00E0–00FFH)

(00C0–00FFH)



(0080–00FFH)















Upper Register File (CA, JR, JT, JV, KR, KT, LA, LB, LD)











0160H

4BH





0140H

4AH

25H



0120H

49H





0100H

48H

24H

12H

NOTE: Locations 1FE0–1FFFH contain memory-mapped SFRs that cannot be accessed through a window. Reading these locations through a window returns FFH; writing these locations through a window has no effect.

3-8

4

Standard and PTS

Interrupts

CHAPTER 4

STANDARD AND PTS INTERRUPTS

The interrupt structure of the 8XC196Lx is the same as that of the 8XC196Jx. The only difference is that the slave port interrupts (INT08:06) now support the J1850 controller peripheral.

4.1INTERRUPT SOURCES, VECTORS, AND PRIORITIES

Table 4-1 lists the 8XC196Lx’s interrupts sources, default priorities (30 is highest and 0 is lowest), and vector addresses.

4-1

8XC196LX SUPPLEMENT

Table 4-1. Interrupt Sources, Vectors, and Priorities





Interrupt Controller

PTS Service









Service





















Interrupt Source

Mnemonic

























Priority





Name

Vector

Priority

Name



Vector



















Nonmaskable Interrupt

NMI

INT15

203EH

30



EXTINT Pin

EXTINT

INT14

203CH

14

PTS14



205CH

29

Reserved

INT13

203AH

13

PTS13

205AH

28

SIO Receive

RI

INT12

2038H

12

PTS12



2058H

27

SIO Transmit

TI

INT11

2036H

11

PTS11



2056H

26

SSIO Channel 1 Transfer

SSIO1

INT10

2034H

10

PTS10



2054H

25

SSIO Channel 0 Transfer

SSIO0

INT09

2032H

09

PTS09



2052H

24

J1850 Status (LB only)

J1850ST

INT08

2030H

08

PTS08



2050H

23

Reserved (LA, LD)

INT08

2030H

08

PTS08

2050H

23

Unimplemented Opcode

2012H



Software TRAP Instruction

2010H



J1850 Receive (LB only)

J1850RX

INT07

200EH

07

PTS07



204EH

22

Reserved (LA, LD)

INT07

200EH

07

PTS07

204EH

22

J1850 Transmit (LB only)

J1850TX

INT06

200CH

06

PTS06



204CH

21

Reserved (LA, LD)

INT06

200CH

06

PTS06

204CH

21

A/D Conv. Complete (LA, LB)

AD_DONE

INT05

200AH

05

PTS05



204AH

20

Reserved (LD)

INT05

200AH

05

PTS05

204AH

20

EPA Capture/Compare 0

EPA0

INT04

2008H

04

PTS04



2048H

19

EPA Capture/Compare 1

EPA1

INT03

2006H

03

PTS03



2046H

18

EPA Capture/Compare 2

EPA2

INT02

2004H

02

PTS02



2044H

17

EPA Capture/Compare 3

EPA3

INT01

2002H

01

PTS01



2042H

16

EPA Capture/Compare 6–9,

EPAx ††

INT00

2000H

00

PTS00



2040H

15

EPA 0–3, 8–9 Overrun,

















EPA Compare 0–1††† ,

















Timer 1 Overflow, &

















Timer 2 Overflow

















The NMI pin is not bonded out on the 8XC196Lx. To protect against glitches, create a dummy interrupt service routine that contains a RET instruction.

††These interrupts are individually prioritized in the EPAIPV register. Read the EPA pending registers (EPA_PEND and EPA_PEND1) to determine which source caused the interrupt.

††† 87C196LA, LB only. The 83C196LD has no EPA compare-only channels.

4.2INTERRUPT REGISTERS

This section describes the changes in the interrupt register bit definitions for the 8XC196Lx family.

4-2

STANDARD AND PTS INTERRUPTS

4.2.1Interrupt Mask Registers

Figures 4-1 and 4-2 illustrate the interrupt mask registers for the 8XC196Lx microcontrollers.

INT_MASK

Address:

0008H



Reset State:

00H

The interrupt mask (INT_MASK) register enables or disables (masks) individual interrupt requests. (The EI and DI instructions enable and disable servicing of all maskable interrupts.) INT_MASK is the low byte of the processor status word (PSW). PUSHF or PUSHA saves the contents of this register onto the stack and then clears this register. Interrupt calls cannot occur immediately following a push instruction. POPF or POPA restores it.





7























0

LA





AD

EPA0





EPA1



EPA2

EPA3



EPAx





7























0

LB





























J1850RX

J1850TX

AD

EPA0





EPA1



EPA2

EPA3



EPAx





7























0

LD

































EPA0





EPA1



EPA2

EPA3



EPAx































Bit











Function









Number































































7:0

Setting a bit enables the corresponding interrupt.

















Bit Mnemonic

Interrupt Description

















J1850RX



J1850 Receive (LB only)

















J1850TX



J1850 Transmit (LB only)

















AD



A/D Conversion Complete (LA, LB)













EPA0



EPA Capture/Compare Channel 0













EPA1



EPA Capture/Compare Channel 1













EPA2



EPA Capture/Compare Channel 2













EPA3



EPA Capture/Compare Channel 3













EPAx††



Shared EPA interrupt















††

EPA 6–9 capture/compare channel events, EPA 0–1 compare channel events†††

, EPA





0–3 and 8–9 capture/compare overruns, and timer overflows can generate this







multiplexed interrupt. The EPA mask and pending registers decode the EPAx interrupt.





Write the EPA mask registers to enable the interrupt sources; read the EPA pending





registers to determine which source caused the interrupt.











†††

87C196LA, LB only.



















































Bits 6–7 are reserved on the 87C196LA, and bits 5–7 are reserved on the 83C196LD. For compatibility with future devices, write zeros to these bits.

Figure 4-1. Interrupt Mask (INT_MASK) Register

4-3

8XC196LX SUPPLEMENT

INT_MASK1

Address:

0013H



Reset State:

00H

The interrupt mask 1 (INT_MASK1) register enables or disables (masks) individual interrupt requests. (The EI and DI instructions enable and disable servicing of all maskable interrupts.) INT_MASK1 can be read from or written to as a byte register. PUSHA saves this register on the stack and POPA restores it.



7





















0

LB



NMI



EXTINT



RI





TI

SSIO1

SSIO0

J1850ST





7





















0

LA, LD





























NMI



EXTINT



RI





TI

SSIO1

SSIO0





























Bit













Function









Number



























































7:0

Setting a bit enables the corresponding interrupt.













Bit Mnemonic Interrupt Description













NMI††

Nonmaskable Interrupt













EXTINT

EXTINT Pin



















Reserved























RI

SIO Receive



















TI

SIO Transmit



















SSIO1

SSIO1 Transfer



















SSIO0

SSIO0 Transfer



















J1850ST

J1850 Status (LB only)











†† NMI is always enabled. This nonfunctional mask bit exists for design symmetry with the





INT_PEND1 register. Always write zero to this bit.



































Bit 5 is reserved on the 8XC196Lx devices, and bit 0 is reserved on the 87C196LA and 83C196LD. For compatibility with future devices, always write zeros to these bits.

Figure 4-2. Interrupt Mask 1 (INT_MASK1) Register

4.2.2Interrupt Pending Registers

Figures 4-3 and 4-4 illustrate the interrupt pending registers for the 8XC196Lx microcontrollers.

4-4

STANDARD AND PTS INTERRUPTS

INT_PEND

Address:

0009H



Reset State:

00H

When hardware detects an interrupt request, it sets the corresponding bit in the interrupt pending (INT_PEND or INT_PEND1) registers. When the vector is taken, the hardware clears the pending bit. Software can generate an interrupt by setting the corresponding interrupt pending bit.





7



















0

LA





AD

EPA0



EPA1

EPA2

EPA3



EPAx





7



















0

LB

























J1850RX

J1850TX

AD

EPA0



EPA1

EPA2

EPA3



EPAx





7



















0

LD





























EPA0



EPA1

EPA2

EPA3



EPAx



























Bit











Function









Number















































7:0

Any set bit indicates that the corresponding interrupt is pending. The interrupt bit is cleared



when processing transfers to the corresponding interrupt vector.











Bit Mnemonic

Interrupt Description















J1850RX



J1850 Receive (LB only)















J1850TX



J1850 Transmit (LB only)















AD



A/D Conversion Complete (LA, LB)













EPA0



EPA Capture/Compare Channel 0













EPA1



EPA Capture/Compare Channel 1













EPA2



EPA Capture/Compare Channel 2













EPA3



EPA Capture/Compare Channel 3













EPAx††



Shared EPA Interrupt













††

EPA 6–9 capture/compare channel events, EPA 0–1 compare channel events†††

, EPA





0–3 and 8–9 capture/compare overruns, and timer overflows can generate this shared





interrupt. Write the EPA mask registersto enable the interrupt sources; read the EPA





pending registers to determine which source caused the interrupt.









†††

87C196LA, LB only.











































Bits 6–7 are reserved on the 87C196LA, and bits 5–7 are reserved on the 83C196LD. For compatibility with future devices, write zeros to these bits.

Figure 4-3. Interrupt Pending (INT_PEND) Register

4-5

8XC196LX SUPPLEMENT

INT_PEND1

Address:

0012H



Reset State:

00H

When hardware detects an interrupt request, it sets the corresponding bit in the interrupt pending (INT_PEND or INT_PEND1) registers. When the vector is taken, the hardware clears the pending bit. Software can generate an interrupt by setting the corresponding interrupt pending bit.



7





















0

LB



NMI



EXTINT



RI





TI

SSIO1

SSIO0

J1850ST





7





















0

LA, LD





























NMI



EXTINT



RI





TI

SSIO1

SSIO0





























Bit













Function









Number



















































7:0

Any set bit indicates that the corresponding interrupt is pending. The interrupt bit is cleared



when processing transfers to the corresponding interrupt vector.









Bit Mnemonic Interrupt Description













NMI

Nonmaskable Interrupt













EXTINT

EXTINT Pin



















Reserved























RI

SIO Receive



















TI

SIO Transmit



















SSIO1

SSIO 1 Transfer



















SSIO0

SSIO 0 Transfer



















J1850ST

J1850 Status (LB only)





































Bit 5 is reserved on the 8XC196Lx devices and bit 0 is reserved on the 87C196LA and 83C196LD. For compatibility with future devices, always write zeros to these bits.

Figure 4-4. Interrupt Pending 1 (INT_PEND1) Register

4.2.3Peripheral Transaction Server Registers

Figures 4-5 and 4-6 illustrate the PTS interrupt select and service registers for the 8XC196Lx microcontrollers.

4-6

STANDARD AND PTS INTERRUPTS

PTSSEL

Address:

0004H



Reset State:

0000H

The PTS select (PTSSEL) register selects either a PTS microcode routine or a standard interrupt service routine for each interrupt request. Setting a bit selects a PTS microcode routine; clearing a bit selects a standard interrupt service routine. In PTS modes that use the PTSCOUNT register, hardware clears the corresponding PTSSEL bit when PTSCOUNT reaches zero. The end-of-PTS interrupt service routine must reset the PTSSEL bit to re-enable the PTS channel.



15

























8

LA





EXTINT



RI





TI

SSIO1

SSIO0







7

























0









































AD



EPA0





EPA1

EPA2

EPA3



EPAx





15

























8

LB

































EXTINT



RI





TI

SSIO1

SSIO0



J1850ST





7

























0



































J1850RX



J1850TX

AD



EPA0





EPA1

EPA2

EPA3



EPAx





15

























8

LD

































EXTINT



RI





TI

SSIO1

SSIO0







7

























0











































EPA0





EPA1

EPA2

EPA3



EPAx

































Bit















Function











Number



























































14:0

Setting a bit causes the corresponding interrupt to be handled by a PTS microcode routine.



The PTS interrupt vector locations are as follows:















Bit Mnemonic

Interrupt









PTS Vector







EXTINT



EXTINT pin









205CH











Reserved















205AH











RI



SIO Receive









2058H











TI



SIO Transmit









2056H











SSIO1



SSIO 1 Transfer









2054H











SSIO0



SSIO 0 Transfer









2052H











J1850ST (LB)

J1850 Status









2050H











J1850RX(LB)

J1850 Receive









204EH











J1850TX(LB)

J1850 Transmit









204CH











AD(LA, LB)



A/D Conversion Complete



204AH











EPA0



EPA Capture/Compare Channel 0

2048H











EPA1



EPA Capture/Compare Channel 1

2046H











EPA2



EPA Capture/Compare Channel 2

2044H











EPA3



EPA Capture/Compare Channel 3

2042H











EPAx††



Multiplexed EPA









2040H









†† PTS service is not useful for shared interrupts because the PTS cannot readily







determine the source of these interrupts.











































Bit 13 is reserved on the 8XC196Lx devices and bits 6–8 are reserved on the 87C196LA and 83C196LD. For compatibility with future devices, write zeros to these bits.

Figure 4-5. PTS Select (PTSSEL) Register

4-7

8XC196LX SUPPLEMENT

PTSSRV

Address:

0006H



Reset State:

0000H

The PTS service (PTSSRV) register is used by the hardware to indicate that the final PTS interrupt has been serviced by the PTS routine. When PTSCOUNT reaches zero, hardware clears the corresponding PTSSEL bit and sets the PTSSRV bit, which requests the end-of-PTS interrupt. When the end-of-PTS interrupt is called, hardware clears the PTSSRV bit. The end-of-PTS interrupt service routine must set the PTSSEL bit to re-enable the PTS channel.



15























8

LA





EXTINT



RI





TI

SSIO1

SSIO0





7























0







































AD



EPA0





EPA1

EPA2

EPA3

EPAx





15























8

LB































EXTINT



RI





TI

SSIO1

SSIO0

J1850ST





7























0

































J1850RX



J1850TX

AD



EPA0





EPA1

EPA2

EPA3

EPAx





15























8

LD































EXTINT



RI





TI

SSIO1

SSIO0





7























0









































EPA0





EPA1

EPA2

EPA3

EPAx































Bits















Function













14:0

A bit is set by hardware to request an end-of-PTS interrupt for the corresponding interrupt



through its standard interrupt vector.

















The standard interrupt vector locations are as follows:











Bit Mnemonic

Interrupt









Standard Vector







EXTINT



EXTINT pin









203CH









Reserved















203AH









RI



SIO Receive









2038H









TI



SIO Transmit









2036H









SSIO1



SSIO 1 Transfer









2034H









SSIO0



SSIO 0 Transfer









2032H









J1850ST (LB)

J1850 Status









2030H









J1850RX (LB)

J1850 Receive









202EH









J1850TX (LB)

J1850 Transmit









202CH









AD (LA, LB)



A/D Conversion Complete



202AH









EPA0



EPA Capture/Compare Channel 0

2028H









EPA1



EPA Capture/Compare Channel 1

2026H









EPA2



EPA Capture/Compare Channel 2

2024H









EPA3



EPA Capture/Compare Channel 3

2022H









EPAx††



Multiplexed EPA









2020H







†† PTS service is not useful for shared interrupts because the PTS cannot readily





determine the source of these interrupts.







































Bit 13 is reserved on the 8XC196Lx devices and bits 6–8 are reserved on the 87C196LA and 83C196LD. For compatibility with future devices, write zeros to these bits.

Figure 4-6. PTS Service (PTSSRV) Register

4-8

5

I/O Ports

CHAPTER 5

I/O PORTS

The I/O ports of the 8XC196Lx are functionally identical to those of the 8XC196Jx. However, on the 87C196LA and LB, the reset state level of all 41 general-purpose I/O pins has changed from a weak logic “1” (wk1) to a weak logic “0” (wk0). This chapter outlines the differences between the 87C196LA, LB and the 8XC196Kx controllers.

5.1I/O PORTS OVERVIEW

Table 5-1 provides an overview of the 8XC196Lx and 8XC196Kx I/O ports.

Table 5-1. Microcontroller Ports



Port



Pins

Type

Configuration

Associated Peripheral or





Options

System Function

























Port 0



8

(Kx)

Standard

Input-only

A/D converter



6

(CA, Jx, Lx)

(not supported on LD)























Port 1



8

(Kx)

Standard

Complementary

EPA and timers



4

(CA, Jx, Lx)

Open-drain



























8

(Kx)



Complementary

J1850 (LB only), SIO,

Port 2



Standard

interrupts, bus control, clock



6

(CA, Jx, Lx)

Open-drain







gen.



























Port 3



8



Memory mapped

Complementary

Address/data bus





Open-drain



























Port 4



8



Memory mapped

Complementary

Address/data bus





Open-drain



























Port 5



8

(Kx)

Memory mapped

Complementary

Bus control, slave port



3

(CA, Jx, Lx)

Open-drain























Port 6



8

(Kx)

Standard

Complementary

EPA, SSIO



6

(CA, Jx, Lx)

Open-drain























5.2INTERNAL STRUCTURE FOR PORTS 1, 2, 5, AND 6 (BIDIRECTIONAL PORTS)

Figure 5-1 shows the logic for driving the output transistors, Q1 and Q2. Consult the datasheet for specifications on the amount of current that each port can source or sink.

In I/O mode (selected by clearing a port mode register bit), the port data output and the port direction registers are input to the multiplexers. These signals combine to drive the gates of Q1 and Q2 so that the output is high, low, or high impedance.

In special-function mode (selected by setting a port mode register bit), SFDIR and SFDATA are input to the multiplexers. These signals combine to drive the gates of Q1 and Q2 so that the output is high, low, or high impedance. Special-function output signals clear SFDIR; special-function

5-1

8XC196LX SUPPLEMENT

input signals set SFDIR. Even if a pin is to be used in special-function mode, you must still initialize the pin as an input or output by writing to the port direction register.

Resistor R1 provides ESD protection for the pin. Input signals are buffered. The standard ports use Schmitt-triggered buffers for improved noise immunity. Port 5 uses a standard input buffer because of the high speeds required for bus control functions. The signals are latched into the port pin register sample latch and output onto the internal bus when the port pin register is read.

The falling edge of RESET# turns on transistor Q3, which remains on for about 300 ns, causing the pin to change rapidly to its reset state. The active-low level of RESET# turns on transistor Q4, which weakly holds the pin low. Q4 remains on, weakly holding the pin low, until your software writes to the port mode register.

NOTE

P2.7 is an exception. After reset, P2.7 carries the CLKOUT signal (half the crystal input frequency) rather than being held low. When CLKOUT is selected, it is always a complementary output.

5-2

I/O PORTS

Internal Bus







VCC













Px_REG

0



















SFDATA

1





Q1













I/O Pin

Px_DRV

0















Q2



SFDIR









1















RESET#

VSS



Px_MODE





















Sample



150Ω to 200Ω

R1



Latch











Px_PIN

Buffer







Q

D









LE









Read Port













PH1 Clock















Medium





300ns Delay



Pullup







Q3



RESET#



























VSS











Weak





RESET#

R

Pullup









Q

Q4





Any Write to Px_MODE

S













VSS













A5265-01

Figure 5-1. Ports 1, 2, 5, and 6 Internal Structure (87C196LA, LB Only)



5.2.1Configuring Ports 1, 2, 5, and 6 (Bidirectional Ports)

Using the port mode register, you can individually configure each pin for port 1, 2, 5, and 6 to operate either as a general-purpose I/O signal (I/O mode) or as a special-function signal (specialfunction mode). In either mode, three configurations are possible: complementary output, high-

5-3

8XC196LX SUPPLEMENT

impedance input, or open-drain output. The port direction and data output registers select the configuration for each pin. Complementary output means that the microcontroller drives the signal high or low. High-impedance input means that the microcontroller floats the signal. Open-drain output means that the microcontroller drives the signal low or floats it. For I/O mode, the port data output register determines whether the microcontroller drives the signal high, drives it low, or floats it. For special-function mode, the on-chip peripheral or system function determines whether the microcontroller drives the signal high or low for complementary outputs.

The pins for ports 1, 2, 5, and 6 are weakly pulled low during and after reset. Initializing the pins by writing to the port mode register turns off the weak pull-downs. To ensure that the ports are initialized correctly, follow this suggested initialization sequence:

1.Write to Px_DIR to configure the individual pins. Clearing a bit configures a pin as a complementary output. Setting a bit configures a pin as a high-impedance input or opendrain output.

2.Write to Px_MODE to select either I/O or special-function mode. Writing to Px_MODE (regardless of the value written) turns off the weak pull-downs. Even if the entire port is to be used as I/O (its default configuration after reset), you must write to Px_MODE to ensure that the weak pull-downs are turned off.

3.Write to Px_REG.

For complementary output configurations:

In I/O mode, write the data that is to be driven by the pins to the corresponding Px_REG bits. In special-function mode, the value is immaterial because the on-chip peripheral or system function controls the pin. However, you must still write to Px_REG to initialize the pin.

For high-impedance input or open-drain output configurations:

In I/O mode, write to Px_REG to either float the pin, making it available as a high impedance input, or pull it low. Setting the corresponding Px_REG bit floats the pin; clearing the corresponding Px_REG bit pulls the pin low. In special-function mode, if the on-chip peripheral uses the pin as an input signal, you must set the corresponding Px_REG bit so that the pin can be driven externally. If the on-chip peripheral uses the pin as an output signal, the value of the corresponding Px_REG bit is immaterial because the onchip peripheral or system function controls the pin. However, you must still write to Px_REG to initialize the pin.

5.2.2Special Bidirectional Port Considerations

This section outlines special consideration for using the pins of ports 1, 2, 5, and 6.

1.After reset, your software must configure the device to match the external system. This accomplished by writing appropriate configuration data into Px_MODE. Writing to Px_MODE not only configures the pins but also turns off the transistor that weakly holds the pins low. For this reason, even if your port is to be used as it is configured at reset, you should still write data into Px_MODE.

2.P2.6/TXJ1850 is the enable pin for ONCE mode. Because a high input during reset can cause the device to enter ONCE mode or a reserved test mode, caution must be exercised

5-4

I/O PORTS

in using this pin. Be certain that your system meets the VIH specifications during reset to prevent inadvertent entry into ONCE mode or a test mode.

3.Following reset, P2.7/CLKOUT carries the strongly driven CLKOUT signal. It is not held low. When P2.7/CLKOUT is configured as CLKOUT, it is always a complementary output.

5.3INTERNAL STRUCTURE FOR PORTS 3 AND 4 (ADDRESS/DATA BUS)

Figure 5-2 shows the logic of ports 3 and 4. Consult the datasheet for specifications on the amount of current ports 3 and 4 can source and sink.

During reset, the active-low level of RESET# turns off Q1 and Q2 and turns on transistor Q4, which weakly holds the pin low. Resistor R1 provides ESD protection for the pin. During normal operation, the device controls the port through BUS CONTROL SELECT, an internal control signal.

When the device needs to access external memory, it clears BUS CONTROL SELECT, selecting ADDRESS/DATA as the input to the multiplexer. ADDRESS/DATA then drives Q1 and Q2 as complementary outputs.

When external memory access is not required, the device sets BUS CONTROL SELECT, selecting Px_REG as the input to the multiplexer. Px_REG then drives Q1 and Q2. If P34_DRV is set, Q1 and Q2 are driven as complementary outputs. If P34_DRV is cleared, Q1 is disabled and Q2 is driven as an open-drain output requiring an external pull-up resistor. With the open-drain configuration (BUS CONTROL SELECT set and P34_DRV cleared) and Px_REG set, the pin can be used as an input. The signal on the pin is latched in the Px_PIN register. The pins can be read, making it easy to see which pins are driven low by the device and which are driven high by external drivers while in open-drain mode.

5-5

8XC196LX SUPPLEMENT









Internal Bus





VCC











Px_REG

1















Address/Data

0



Q1



Bus Control Select







I/O Pin

0 = Address/Data















1 = I/O









P34_DRV





Q2









RESET#









VSS





Sample

150Ω to 200Ω

R1



Latch









Px_PIN

Buffer





Q

D







LE







Read Port











PH1 Clock











Medium









Pullup







300ns Delay



RESET#





Q3

















VSS









Weak









Pullup









Q4









VSS











A5264-01

Figure 5-2. Ports 3 and 4 Internal Structure (87C196LA, LB Only)

5-6

6

Synchronous Serial

I/O Port

CHAPTER 6

SYNCHRONOUS SERIAL I/O PORT

The synchronous serial I/O (SSIO) port on the 8XC196Lx has been enhanced, implementing two new special function registers (SSIO0_CLK and SSIO1_CLK) that allow you to select the operating mode and configure the phase and polarity of the serial clock signals.

6.1SSIO 0 CLOCK REGISTER

The SSIO 0 clock (SSIO_CLK) register selects the phase and polarity for the SC0 clock signal. In standard mode, SC0 is channel 0’s clock signal. In duplex and channel-select modes, SC0 is the common clock signal for both SSIO channels.

SSIO0_CLK

Address:

1FB5H



Reset State:

00H

The SSIO 0 clock (SSIO0_CLK) register configures the serial clock for channel 0. In standard mode, the SC0 is channel 0’s clock signal. In duplex and channel-select modes, SC0 is the common clock signal for both SSIO channels.

7



















0







PHAS

POLS























Bit

Bit









Function





Number

Mnemonic



































7:2

Reserved; for compatibility with future devices, write zeros to these bits.















1

PHAS

Phase and Polarity Select













For normal transfers, these bits determine the idle state of the serial

0

POLS







clock and select the serial clock signal edge on which the SSIO samples







incoming data bits or shifts out outgoing data bits. These bits are ignored







for handshaking transfers. Use SSIO0_ CON to select the type of data







transfer (normal or handshaking) for channel 0.











For transmissions



















PHAS

POLS



















0

0

low idle state; shift on falling edges









0

1

high idle state; shift on rising edges









1

0

low idle state; shift on rising edges









1

1

high idle state; shift on falling edges









For receptions



















PHAS

POLS



















0

0

low idle state; sample on rising edges









0

1

high idle state; sample on falling edges









1

0

low idle state; sample on falling edges









1

1

high idle state; sample on rising edges

























Figure 6-1. SSIO 0 Clock (SSIO0_CLK) Register

6-1

8XC196LX SUPPLEMENT

For transmissions, SSIO0_CLK determines whether the SSIO shifts out data bits on rising or falling clock edges. For receptions, SSIO0_CLK determines whether the SSIO samples data bits on rising or falling clock edges.

6.2SSIO 1 CLOCK REGISTER

SSIO1_CLK selects the SSIO mode of operation (standard, duplex, or channel-select), enables the channel-select master contention interrupt request, and selects the phase and polarity for the serial clock (SC1) for channels. In standard mode, use this register to configure the serial clock for channel 1.

SSIO1_CLK

Address:

1FB7H



Reset State:

00H

The SSIO 1 clock (SSIO1_CLK) register selects the SSIO mode of operation (standard, duplex, or channel-select), enables the channel-select master contention interrupt request, and selects the phase and polarity for the serial clock (SC1) for channel 1.

7

























0



CHS





DUP



CONINT

CONPND

PHAS



POLS





























Bit

Bit













Function







Number

Mnemonic















































7:6

Reserved; for compatibility with future devices, write zeros to these bits.













5

CHS

These bits determine the SSIO operating mode.











CHS

DUP















4

DUP

standard mode













0



0















0



1



duplex mode













1



0



channel-select half-duplex mode (uses SD1 only)









1



1



channel-select full-duplex mode (uses both SD0 and SD1)













3

CONINT

Master Contention Interrupt













For channel-select master operations, the SSIO sets the master









contention interrupt pending bit (CONPND) when the CHS# pin is







externally activated. In a system with multiple masters, an external







master activates the CHS# signal to request control of the serial clock.







CONINT determines whether the SSIO sets both CONPND and the







SSIO0 interrupt pending bit or only CONPND when the CHS# pin is







externally activated.



















0

= SSIO sets only CONPND













1

= SSIO sets both CONPND and the SSIO0 interrupt pending bit







This bit is valid for channel-select master operations and ignored for all







other operations.









































Figure 6-2. SSIO 1 Clock (SSIO1_CLK) Register

6-2

SYNCHRONOUS SERIAL I/O PORT

SSIO1_CLK (Continued)

Address:

1FB7H



Reset State:

00H

The SSIO 1 clock (SSIO1_CLK) register selects the SSIO mode of operation (standard, duplex, or channel-select), enables the channel-select master contention interrupt request, and selects the phase and polarity for the serial clock (SC1) for channel 1.

7



















0



CHS

DUP



CONINT

CONPND



PHAS

POLS























Bit

Bit







Function





Number

Mnemonic





































2

CONPND

Master Contention Interrupt Pending











For channel-select master operations, the SSIO sets this bit when the







CHS# pin is externally activated. In a system with multiple masters, an







external master activates the CHS# signal to request control of the serial







clock.





















This bit is valid for channel-select master operations and ignored for all







other operations.























1

PHAS

Phase and Polarity Select









For normal transfers, these bits determine the idle state of the serial

0

POLS







clock and select the serial clock signal edge that the SSIO samples







incoming data bits or shifts out outgoing data bits.











For transmissions



















PHAS

POLS



















0

0

low idle state; shift on falling edges









0

1

high idle state; shift on rising edges









1

0

low idle state; shift on rising edges









1

1

high idle state; shift on falling edges









For receptions



















PHAS

POLS



















0

0

low idle state; sample on rising edges









0

1

high idle state; sample on falling edges









1

0

low idle state; sample on falling edges









1

1

high idle state; sample on rising edges









These bits are ignored for duplex and channel-select modes; these







modes use SC0 as the common clock signal. The SSIO0_CLK register







contains the phase and polarity select bits for the SC0 clock signal.







These bits are also ignored for handshaking transfers. Use SSIO1_ CON







to select the type of data transfer (normal or handshaking) for channel 1.























Figure 6-2. SSIO 1 Clock (SSIO1_CLK) Register (Continued)

For transmissions, SSIO1_CLK determines whether the SSIO shifts out data bits on rising or falling clock edges. For receptions, SSIO1_CLK determines whether the SSIO samples data bits on the rising or falling clock edges.

6-3

7

Event Processor

Array

CHAPTER 7

EVENT PROCESSOR ARRAY

The EPA on the 8XC196Lx is functionally identical to that of the 8XC196Jx; however, the 8XC196Lx has only two capture/compare channels without pins instead of four. In addition, the 83C196LD has no compare-only channels.

7.1EPA FUNCTIONAL OVERVIEW

Table 7-1 lists the capture/compare (with device in the 8XC196Lx and 8XC196Kx

and without pins) and compare-only channels for each families.

Table 7-1. EPA Channels

Device

Capture/Compare

Capture/Compare

Compare-only

Channels With Pins

Channels Without Pins

Channels











8XC196LA, LB

EPA3:0 and EPA9:8

EPA7:6

COMP1:0









8XC196LD

EPA3:0 and EPA9:8

EPA7:6









87C196CA, 8XC196Jx

EPA3:0 and EPA9:8

EPA7:4

COMP1:0









8XC196Kx

EPA9:0

COMP1:0









The 8XC196Lx’s EPA performs input and output functions associated with two timer/counters, timer 1 and timer 2, as depicted in Figures 7-1 and 7-2.

7-1

8XC196LX SUPPLEMENT









Timer-Counter Unit





























































TIMER1

































































































TIMER2







































































































































Capture/Compare





EPA 3:0 Interrupts































EPA 3:0



















Channel 0–3





























































































































Capture/Compare































































Channel 6–7



































































































Capture/Compare











































EPA8 / COMP0



















Channel 8











EPAx



























































































Indirect



Interrupt





















Compare-only































Interrupt





















































Channel 0





Processor



























































Logic





















































































Capture/Compare











































EPA9 / COMP1



















Channel 9









































































Compare-only

Channel 1

A5269-01

Figure 7-1. EPA Block Diagram (87C196LA, LB Only)

7-2

EVENT PROCESSOR ARRAY







Timer-Counter Unit













































TIMER1











































































TIMER2







































































































Capture/Compare





EPA 3:0 Interrupts





EPA 3:0













Channel 0–3































































































Capture/Compare

























Channel 6–7









































































Capture/Compare











EPA8













Channel 8









EPAx





































































Indirect



Interrupt





















Interrupt

























Processor

























Logic









































Capture/Compare











EPA9













Channel 9



















































































A5281-01

Figure 7-2. EPA Block Diagram (83C196LD Only)

7-3

8XC196LX SUPPLEMENT

7.1.1EPA Mask Registers

Figures 7-3 and 7-4 illustrate the EPA mask registers, EPA_MASK and EPA_MASK1, for the 8XC196Lx microcontroller family.

EPA_MASK

Address:

1FA0H



Reset State:

0000H

The EPA interrupt mask (EPA_MASK) register enables or disables (masks) interrupts associated with the shared EPAx interrupt.





15

















8





Lx



EPA6

EPA7



EPA8

EPA9



OVR0

OVR1









7

















0





































0VR2

OVR3





OVR8

OVR9

































Bit









Function













Number























































15:0

Setting a bit enables the corresponding interrupt as a EPAx interrupt source. The shared







EPAx interrupt is enabled by setting its interrupt enable bit in the interrupt mask register







(INT_MASK.0 = 1).















































Bits 2–5 and 14–15 are reserved on the 8XC196Lx device family. For compatibility with future





devices, write zeros to these bits.





































Figure 7-3. EPA Interrupt Mask (EPA_MASK) Register





























EPA_MASK1













Address:

1FA4H





















Reset State:

00H



The EPA interrupt mask 1 (EPA_MASK1) register enables or disables (masks) interrupts associated with the multiplexed EPAx interrupt.

7







0



COMP0

COMP1

OVRTM1

OVRTM2



















Bit









Function

Number





























7:4

Reserved; for compatibility with future devices, write zeros to these bits.





3:0

Setting a bit enables the corresponding interrupt as a multiplexed EPAx interrupt source.



The multiplexed EPAx interrupt is enabled by setting its interrupt enable bit in the



interrupt mask register (INT_MASK.0 = 1).



87C196LA, LB only; reserved on 83C196LD.

Figure 7-4. EPA Interrupt Mask 1 (EPA_MASK1) Register

7-4

EVENT PROCESSOR ARRAY

7.1.2EPA Pending Registers

Figures 7-5 and 7-6 illustrate the EPA pending registers, EPA_PEND and EPA_PEND1, for the 8XC196Lx microcontroller family.

EPA_PEND

Address:

1FA2H



Reset State:

0000H

When hardware detects a pending EPA6–9 or OVR0–3, 8–9 interrupt request, it sets the corresponding bit in the EPA interrupt pending register (EPA_PEND or EPA_PEND1). The EPAIPV register contains a number that identifies the highest priority, active, shared interrupt source. When EPAIPV is read, the EPA interrupt pending bit associated with the EPAIPV priority value is cleared.







15



















8





Lx



EPA6

EPA7



EPA8

EPA9



OVR0



OVR1











7



















0











































0VR2

OVR3





OVR8



OVR9





































Bit











Function















Number

































































15:0



Any set bit indicates that the corresponding EPAx interrupt source is pending. The bit is









cleared when software reads the EPA interrupt priority vector register (EPAIPV).

































Bits 2–5 and 14–15 are reserved on the 8XC196Lx device family. For compatibility with future





devices, write zeros to these bits.











































Figure 7-5. EPA Interrupt Pending (EPA_PEND) Register

































EPA_PEND1

















Address:

1FA6H























Reset State:

00H



When hardware detects a pending EPAx interrupt, it sets the corresponding bit in the EPA interrupt pending register (EPA_PEND or EPA_PEND1). The EPAIPV register contains a number that identifies the highest priority, active, multiplexed interrupt source. When EPAIPV is read, the EPA interrupt pending bit associated with the EPAIPV priority value is cleared.

7







0



COMP0

COMP1

OVRTM1

OVRTM2



















Bit









Function

Number







































7:4

Reserved; always write as zeros.















3:0

Any set bit indicates that the corresponding EPAx interrupt source is pending. The bit is



cleared when the EPA interrupt priority vector register (EPAIPV) is read.



87C196LA, LB only; reserved on 83C196LD.

Figure 7-6. EPA Interrupt Pending 1 (EPA_PEND1) Register

7-5

8XC196LX SUPPLEMENT

7.1.3EPA Interrupt Priority Vector Register

Figure 7-7 illustrates the EPA interrupt priority vector (EPAIPV) register for the 8XC196Lx microcontroller family.

EPAIPV

Address:

1FA8H



Reset State:

00H

When an EPAx interrupt occurs, the EPA interrupt priority vector (EPAIPV) register contains a number that identifies the highest priority, active, multiplexed interrupt source (see Table 7-2).

EPAIPV allows software to branch via the TIJMP instruction to the correct interrupt service routine when EPAx is activated. Reading EPAIPV clears the EPA pending bit for the interrupt associated with the value in EPAIPV. When all the EPA pending bits are cleared, the EPAx pending bit is also cleared.

7



















0



PV4



PV3



PV2

PV1

PV0























Bit

Bit









Function





Number

Mnemonic



































5:7

Reserved; for compatibility with future devices, write zeros to these bits.



















4:0

PV4:0

Priority Vector



















These bits contain a number from 01H to 14H corresponding to the







highest-priority active interrupt source. This value, when used with the







TIJMP instruction, allows software to branch to the correct interrupt







service routine.



































Figure 7-7. EPA Interrupt Priority Vector Register (EPAIPV)



Table 7-2. EPA Interrupt Priority Vectors



Value

Interrupt



Value

Interrupt



Value

Interrupt

















14H



0DH

OVR1



06H

OVR8

















13H



0CH

OVR2



05H

OVR9

















12H

EPA6



0BH

OVR3



04H

COMP0

11H

EPA7



0AH



03H

COMP1

10H

EPA8



09H



02H

OVRTM1

















0FH

EPA9



08H



01H

OVRTM2

















0EH

OVR0



07H



00H

None

















87C196LA, LB only; reserved on 83C196LD.

7-6

8

J1850

Communications

Controller

CHAPTER 8 J1850 COMMUNICATIONS CONTROLLER

The J1850 communications controller manages communications between multiple network nodes. This integrated peripheral supports the 10.4 Kb/s VPW (variable pulse width) mediumspeed class B in-vehicle network protocol. It also supports both the standard and in-frame response (IFR) message framing as specified by the Society of Automotive Engineering (SAE) J1850 (revised May 1994) technical standards. Its lower cost per node makes it suitable for diagnostics and non-real-time data sharing in applications with high numbers of nodes. This chapter details the integrated J1850 controller and explains how to configure it.

8.1J1850 FUNCTIONAL OVERVIEW

The integrated J1850 communications controller transfers messages between network nodes according to the J1850 protocol. The complete J1850 communications protocol solution includes an on-chip, J1850 digital-logic controller working with an external analog bus transceiver circuit. Figure 8-1 illustrates the J1850 protocol with the J1850 controller integrated on the 87C196LB 16-bit microcontroller and a standalone J1850 bus transceiver device. The example uses the Harris HIP7020 as the remote transceiver device.



TXJ1850

TX

J1850





HIP7020

Bus



RXJ1850

RX





87C196LB







Microcontroller





Clock

PLL/





CLKOUT

















A5168-01

Figure 8-1. Integrated J1850 Communications Protocol Solution

The benefit of an integrated, J1850 protocol solution is threefold:

Minimizes CPU overhead for reception and transmission of J1850 messages.

Frees up serial and parallel communications ports for other purposes.

Offers significant printed-circuit board area savings when compared with conventional standalone protocol devices.

8-1

8XC196LX SUPPLEMENT

The J1850 controller can handle network protocol functions including message frame sequencing, bit arbitration, in-frame response (IFR) messaging, error detection, and delay compensation.

The J1850 communications controller (Figure 8-2) consists of a control state machine (CSM), symbol synchronization and timing (SST) circuitry, six control and status registers, transmit and receive buffers, and an interrupt handler.

J1850ST



Bus Error

J1850 Communications Controller











J1850RX

Interrupt

RX







J1850TX

Handler

TX

















J_DLY











J_STAT









OVR



Error









Detection







UNDR







Circuitry







Bus

J_TX















Delay



Data





Symbol

Compensator

TXJ1850







JTX_BUF

Bit

Encoder



Peripheral





Arbitration









Symbol





JRX_BUF

Circuitry

Digital



Decoder







Filter





Cyclic



RXJ1850



















Redundancy









J_RX

Check Circuitry

Prescaler







J_CMD

CSM



SST















J_CFG









Internal Clocking





















A5169-01

Figure 8-2. J1850 Communications Controller Block Diagram

8-2

J1850 COMMUNICATIONS CONTROLLER

8.2J1850 CONTROLLER SIGNALS AND REGISTERS

Table 8-1 describes the J1850 controller’s pins, and Table 8-2 describes the control and status registers.





Table 8-1. J1850 Controller Signals

Signal

Type

Description







RXJ1850

I

Receive





Carries digital symbols from a remote transceiver to the J1850 controller.







TXJ1850

O

Transmit





Carries digital symbols from the J1850 controller to a remote transceiver.







Table 8-2. Control and Status Registers





Mnemonic

Address

Description











J_CFG

1F54H

J1850 Configuration









Program this byte register to specify the oscillator prescaler









divisor, mode of operation, and normalization bit format. You must









write to this register during the initialization sequence.











J_CMD

1F51H

J1850 Command









Program this byte register to specify the number of bytes to be









transmitted in the next message frame. This register also









monitors the status of the message transmission in progress, and









it can abort, ignore, or retry a message if necessary. Read this









register to determine the status of transmissions in progress.











J_DLY

1F58H

J1850 Delay Compensation









Program this byte register to define the length of the delay time









through the external transceiver to compensate for the inherent









propagation delays and to accurately resolve bus contention









during arbitration. You must write to this register during the









initialization sequence.











J_RX

1F52H

J1850 Receiver









Read this byte register to receive data in byte increments from the









J1850 bus to the microcontroller CPU. This register is buffered to









allow for reception of a second data byte while the first data byte









is being read.











J_STAT

1F53H

J1850 Status









Read this byte register to determine the current status of the









receive and transmit buffers and the J1850 interrupt sources. You









can also determine bus status and in-frame response messaging









status. All bits of this register are cleared when read, with the









exception of the BUS_STAT bit.











J_TX

1F50H

J1850 Transmitter









Program this byte register to transmit data in byte increments to









the J1850 bus from the microcontroller CPU. This register is









buffered to allow for writing of a second data byte while the first









data byte is being shifted out.



















8-3



















8XC196LX SUPPLEMENT

Table 8-2. Control and Status Registers (Continued)

Mnemonic

Address

Description







INT_MASK

0008H

Interrupt Mask





Bits 6 and 7 in this register enable and disable the J1850 receive





and transmit interrupt requests, respectively.







INT_MASK1

0013H

Interrupt Mask 1





Bit 0 in this register enables and disables the J1850 bus error





interrupt request.







INT_PEND

0009H

Interrupt Pending





Bits 6 and 7 in this register, when set, indicate pending J1850





receive and transmit interrupt requests, respectively.







INT_PEND1

0012H

Interrupt Pending 1





Bit 0 in this register, when set, indicates a pending J1850 bus





error interrupt request.







PTSSEL

0004H

PTS Select





Bits 6, 7, and 8 of this word register select either a PTS service





request or a standard interrupt service request for J1850TX,





J1850RX, and J1850ST interrupts, respectively.







PTSSRV

0006H

PTS Service





Bits 6, 7, and 8 of this word register are set by hardware to





request an end-of-PTS interrupt for the J1850.







8.3J1850 CONTROLLER OPERATION

This section describes the control state machine (which contains the cyclic redundancy check generator) and the symbol synchronization and timing circuitry for J1850 transmissions and receptions.

8.3.1Control State Machine

The control state machine (CSM) represents the engine of the digital circuitry portion of the J1850 communications controller. The CSM handles all message framing for standard and inframe response (IFR) messaging, data validation, bus contention, bit arbitration, and error detection.

8.3.1.1Cyclic Redundancy Check Generator

The cyclic redundancy check (CRC) generator circuitry calculates and checks the CRC byte generated for both transmitted and received standard messages as specified by SAE J1850 protocol specification for class B in-vehicle networks. The CRC calculation is a code byte of information that verifies the proper reception or transmission of your message. The calculated CRC code byte is always appended as the last byte of your transmitted message. On reception, the calculated CRC checksum byte always results in a value of C4H for valid messages. An invalid CRC checksum during reception signals the presence of an error in your incoming message, which immediately sets the J1850 bus error (J1850BE) bit in the J_STAT register (Figure 8-19 on page 8-21).

8-4

J1850 COMMUNICATIONS CONTROLLER

8.3.1.2Bus Contention

Bus contention arises when multiple nodes attempt to access and transmit message frames across the J1850 bus simultaneously. This creates a conflict on the bus. The recognition of conflicting symbols or bits on the bus is referred to as contention detection. For example, if a node observes a difference between a symbol it transmits to the J1850 bus and the symbol that it detects on the bus, that node has detected contention to the transmission of its message frame. Only one message frame from one node vying for the bus wins arbitration on each symbol or bit of its frame. This winning message frame does not experience or detect contention. The message frames that were not awarded arbitration will experience contention.

8.3.1.3Bit Arbitration

A bit arbitration scheme is used to resolve such conflicts as bus contention. The J1850 protocol uses the carrier sense multiple access (CSMA) bit arbitration scheme. Bit arbitration is the process of settling conflicts that occur when multiple nodes attempt to transmit one bit or symbol at a time across a single bus. A symbol is simply a timing-level formatted bit. By definition, a node that detects contention has lost arbitration and will discontinue transmitting any further symbols remaining in its message frame. Remaining nodes vying for the bus will continue to send their symbols until the next instance of contention is detected or arbitration is awarded. This process continues until a complete message frame from one node has been transmitted. For details on this arbitration scheme, refer to the “Bit Arbitration Example” on page 8-7.

8.3.1.4Error Detection

The J1850 controller’s error detection logic monitors the bus for four error conditions, and sets the J1850BE interrupt pending bit in the J_STAT register if an error occurs. The following list describes each error type:

CRC error — the calculated CRC checksum received on incoming messages has a value other than C4H (the expected value for all received message frames).

bus symbol timing error — the symbol stream on the J1850 bus contains an invalid symbol. An invalid symbol is any signal that is between 8 µs and 34 µs in duration.

incomplete byte error — an EOD/EOF symbol occurred,but was not on a byte boundary; the number of bits recieved was not a multiple of eight.

no echo — the message is transmitted; however, the transmission’s echo back through the feedback loop to the receiver has not been detected within the allowable 60 µs window.

8.3.2Symbol Synchronization and Timing Circuitry

The symbol synchronization and timing (SST) circuitry consists of a clock prescaler, digital filter, delay compensation circuitry, and synchronization and symbol encoding/decoding circuitry. The SST supports Huntzicker encoding of symbols, which entails 10.4 Kb/s variable pulse-width (VPW) operation for valid edge detection on message receptions.

8-5

8XC196LX SUPPLEMENT

8.3.2.1Clock Prescaler

Because the 87C196LB microcontroller can operate at a variety of input frequencies (FXTAL1), the clock prescaler circuitry is used to provide a single, internal clock frequency (f/2) to ensure that the J1850 peripheral is clocked at the proper operating frequency. This is accomplished through the programmable clock prescaler bits, PRE1:0 in the J_CFG register (Figure 8-17 on page 8-18). The prescale bits support input frequencies of 8, 12, 16, and 20 MHz on the XTAL1 pin. With the phase-locked loop (PLL) circuitry enabled, the prescale bits can support input frequencies of 4, 6, 8, and 10 MHz on the XTAL1 pin.

Table 8-3 details the relationships between the input frequency, the configuration of PLL, the internal clock frequency, and the prescaler bits.

Table 8-3. Relationships Between Input Frequency, PLL, and Prescaler Bits

FXTAL1



Internal Clock Frequency





PLL



PLL

(f/2)

PRE1

PRE0







Disabled



Enabled



















8 MHz



4 MHz

4 MHz

0

0













12 MHz



6 MHz

6 MHz

0

1













16 MHz



8 MHz

8 MHz

1

0













20 MHz



10 MHz

10 MHz

1

1













8.3.2.2Digital Filter

To automatically reject noise spikes of 8 µs or less in duration, the J1850 controller uses a digital filter between the RXJ1850 input pin and the symbol synchronization logic.

A noise spike is defined as an active or passive state pulse that is shorter in duration than a valid receive symbol at that state. A valid receive symbol is at least 34 µs in duration. Any symbol captured on the bus between 8 µs and 34 µs in duration is considered invalid and is flagged by the J_STAT register as a bus-symbol timing error.

8.3.2.3Delay Compensation

Because the digital portion of the J1850 protocol is integrated onto the microcontroller and physically separated from the transceiver and J1850 bus, control over critical timing parameters of various manufacturers’ remote transceivers is required. The delay compensation circuitry addresses this requirement by providing the flexibility to compensate for propagation delay and pulse-width variations among various transceivers. The compensation circuitry synchronizes itself to the leading edge of each input symbol, which allows for accurate detection of bus contention during bit arbitration. The delay compensation is programmable through the J_DLY register (Figure 8-18 on page 8-20).

8.3.2.4Symbol Encoding and Decoding

The J1850 protocol supports the Huntzicker encoding method, which is based on variable pulsewidth (VPW) bus modulation. VPW modulation is a forced high/low symbol transition formatting scheme that tracks the duration between two consecutive transitions and the level of the bus, active or passive (Figure 8-3).

8-6

J1850 COMMUNICATIONS CONTROLLER

1









1





64µS







128µS



























or

0







"passive 1"

0





"active 1"

























1









1





128µS







64µS

























or

0







"passive 0"

0





"active 0"





















A5219-01

Figure 8-3. Huntzicker Symbol Definition for J1850

A symbol is defined as a timing-level formatted bit. The VPW symbol timing requirements stipulate that there is one symbol per transition and one transition per symbol. This ensures that a message frame will always result in a uniform square waveform of varying level durations. Figure 8-4 depicts a typical Huntzicker formatted data byte of hex value CCH.

"1"

"1"

"0"

"0"

"1"

"1"

"0"

"0"

B7

B6

B5

B4

B3

B2

B1

B0

A5222-01

Figure 8-4. Typical VPW Waveform

Bits 7 and 3 carry logic level 1 data; however, they are represented by a passive-level symbol in keeping with the VPW requirements. Bits 4 and 0 carry logic level 0 data and are represented by an active-level symbol.

8.3.3Bit Arbitration Example

The drive capacity of each symbol establishes the priority for arbitration. By definition, an active bus level is a driven state, and a passive bus level is a non-driven, or idle, state. A driven bus state is always given priority over an idle bus in arbitration. An “active 0” state has priority over an “active 1” state in arbitration, because the “active 0” state is driven over a longer duration, 128 µs versus the “active 1” state’s drive time of 64 µs. Similarly, a “passive 0” state has priority over

a “passive 1” state, because the “passive 0” state comes out of its idle state in a shorter period of time, 64 µs versus the “passive 1” state’s idle time of 128 µs.

For example, Figure 8-5 illustrates four nodes vying for the bus. Node B is the first node to discontinue transmitting when it attempts to transmit a “passive 1” symbol onto the bus. At the point

8-7

8XC196LX SUPPLEMENT

of arbitration, nodes A, C, and D are all transmitting an “active 0” symbol, thus the idle state of the “passive 1” symbol is overruled in favor of the driven state of the “active 0” symbol.

Node C is the next node to discontinue transmitting when it attempts to take control of the bus by transmitting an “active 1” symbol. However, nodes A and D maintain control by continuing to drive the bus with an “active 0” symbol.

Finally, node D discontinues transmitting when its attempt to hold the bus in an idle state is overruled by the driven state of the “active 1” symbol on node A. Thus, node A is awarded arbitration.

The busline signal, detected on the bus by the receiver, reflects node A’s message, as this is the only node that did not experience contention.

"0"

"0"

"0"

"0"

"1"

"0"

"0"

"1"

Node A

"0" "0" "1"

Node B

Point of

Arbitration

"0"

"0"

"0"

"0"

"1"

"1"

Point of

Node C











Arbitration

"0"

"0"

"0"

"0"

"1"

"0"

"1"

Node D

Point of

Arbitration

Busline

A5223-01

Figure 8-5. Bit Arbitration Example

8.4MESSAGE FRAMES

A message transmission or reception is transferred within a message frame that adds control and error-detection bits to the content of the message. The frame for an IFR message differs slightly from that for a standard message, but they contain similar information (Figure 8-6).

8-8

J1850 COMMUNICATIONS CONTROLLER

Standard Frame







S

1-3 Bytes



1-11 Bytes

1 Byte



O



Header



Data

CRC

F











In-frame Response (IFR) Frame



S

1-3 Bytes



1-11 Bytes

1 Byte



O



Header



Data

CRC

F











E

E

I













O

O

F













D

F

S













E

N

1-32 Bytes

0-1 Byte

E



E



I





O

B

IFR Data

CRC

O



O



F

D







D



F



S



















The number of data bytes to be transferred is unspecified if 0EH is written to J_CMD3:0.

A5225-01

Figure 8-6. J1850 Message Frames

A standard message frame is initiated by the responder and contains no more than 11 data bytes to be transmitted. An IFR message is a request initiating the recipient(s) to respond by transmitting data within the same frame. The following subsections describe each of the messaging forms.

8.4.1Standard Messaging

A standard message frame can best be described as a “send mode only” format that is initiated by the responder either to request information or to reply to a received message from a remote node. In addition to the actual data that is being transmitted, the standard message is composed of a header (1–3 bytes), a CRC byte, and a series of start and end symbols.

8.4.1.1Header

The header provides general information on the physical network and the necessary interface requirements. For a complete description of the header, refer to the Society of Automotive Engineering (SAE) J1850 specifications (revised May 1994).

8.4.1.2CRC Byte

The CRC byte, calculated through the cyclic redundancy check generator, is a checksum value that verifies the accuracy of the data message transmitted onto the bus. The CRC byte is appended to all data messages and optionally appended to IFR response messages. Upon reception, the CRC byte is compared with the value C4H. If the values match, the transmitted message is valid; otherwise, it is invalid, and an error flag in the J_STAT register is set.

8.4.1.3Normalization Bit

The normalization bit (NB), found only in IFR messaging, defines the start of the IFR message response data. The NB is triggered by bit J_CMD.6 and is transmitted after an end-of-data (EOD) symbol is detected on the bus. The timing format of the NB is assigned by the J_CFG register

8-9

8XC196LX SUPPLEMENT

(J_CFG.7) and considers whether the IFR message response has a CRC byte appended. Figure 8-7 depicts the SAE preferred, active-level state bit format timing for the NB.

1





64µS

1





128µS





















or

0







0









NB for IFR with CRC

NB for IFR without CRC





A5220-01

Figure 8-7. Huntzicker Symbol Definition for the Normalization Bit

8.4.1.4Start and End Message Frame Symbols

Five symbols are used to mark the start and end of a message frame and to allow the J1850 bus to properly recognize the interruption of a message transmission or reception. Figure 8-8 illustrates the formats and their respective timing.

The following is a description of each symbol:

start of frame (SOF) — this symbol signals the start of a message frame. This is an activelevel state symbol only and appears once per frame.

end of data (EOD) — this symbol signals the end of the data transmission. This is a passivelevel state symbol only. It appears twice in IFR messaging: at the end of the initial request data field and at the end of the IFR data field.

end of frame (EOF) — this symbol signals the end of a message frame and returns the bus to an idle state. This is a passive-level state symbol only. It appears once per frame.

in-frame separation (IFS) — the timing of this symbol allows for proper synchronization of multiple nodes during back-to-back transmissions. Nodes contending for the bus must comply with one of two conditions before transmitting:

wait for the IFS minimum timing to expire

wait for a rising edge on the bus after the EOF minimum timing has expired

break (BRK) — this symbol signals an interruption during a bus transmission. At the point of termination, all nodes are reset. This is an active-level state symbol.

8-10

J1850 COMMUNICATIONS CONTROLLER

200µS

1













0





"Start of Frame (SOF)"









1







0





200µS





"End of Data (EOD)"









1





280µS





0









"End of Frame (EOF)"











1





300µS+



0









"In-frame Separation (IFS)"









1





768µS+





"Break Signal (BRK)"





0









A5221-01

Figure 8-8. Definition for Start and End of Frame Symbols

Table 8-4 details the symbol timing characteristics supported by the 87C196LB.

Table 8-4. Huntzicker Symbol Timing Characteristics

Name

Symbol

Bus Level

TTXmin

TTXnom

TTXmax

TRXmin

TRXmax

Units



















Logic Level 0

0

Passive

60

64

68

34

<96

µs















Active

122

128

134

96

<163

µs























Logic Level 1

1

Passive

122

128

134

96

<163

µs















Active

60

64

68

34

<96

µs























Start of Frame

SOF

Active

193

200

207

163

<239

µs



















End of Data

EOD

Passive

193

200

207

163

<239

µs



















End of Frame

EOF

Passive

271

280

289

239

<300

µs



















In-frame Separation

IFS

Passive

>300

>300

µs



















Break

BRK

Active

768

>239

µs



















NOTE: Timings are based on the standard bus rate of 10.4 Kb/s. When operating in 4x mode, the bus rate becomes 41.6 Kb/s and all symbol timings are one fourth that shown.

8-11

8XC196LX SUPPLEMENT

8.4.2In-frame Response Messaging

There are three types of in-frame response (IFR) message framings: type 1 (a single byte from a single responder), type 2 (a single byte from multiple responders), and type 3 (multiple bytes from a single responder). Like the standard message frame, the IFR frame is composed of header, data, and CRC bytes, and a series of start and end symbols. Unlike the standard message frame, the actual length of the IFR message frame will differ based on the desired response.

Consider the following example: a system’s controller (the requestor) requests an information update from each of four nodes (the responders) in the system. With type 1 messaging, the controller can receive a limited information update if it sends out four separate transmissions. With type 2 messaging, the controller can receive a limited information update by sending one message. With type 3 messaging, the controller can receive unlimited information; however, it will require four separate transmissions. The following subsections detail this example for the three IFR messaging types.

8.4.2.1IFR Messaging Type 1: Single Byte, Single Responder

No IFR messaging type carries a distinct advantage or disadvantage over the other messaging types. IFR messaging type 1 (Figure 8-9) is ideal for use when requesting small amounts of information from a single source in your system. In the above example, suppose you want to know how many pounds of pressure each of the four remote node sites experienced after the controller sent out a request to each node sensor to exert a given amount of pressure. If you use type 1 messaging, the controller will send four separate serial messages to the remote node sites in the system and wait for their responses. Keeping the data timing a constant, the CPU overhead of transmitting these messages alone amounts to a minimum of 4.96 ms (refer to Table 8-4 on page 8-11 for all symbol timings).

In-frame Response (IFR) Frame





















S

1-3 Bytes



1-11 Bytes

1 Byte

E

N

1Byte

0-1 Byte

E



E



I







O



O

O



O



F



CRC

IFR Data

CRC





F

Header



D

B

D



F



S



Data







































The number of data bytes to be transferred is unspecified if 0EH is written to J_CMD3:0.

A5229-01

Figure 8-9. IFR Type 1 Message Frame

8.4.2.2IFR Messaging Type 2: Single Byte, Multiple Responders

When response time is the highest consideration, IFR messaging type 2 is desirable. IFR type 2 messaging can monitor up to 32 remote nodes on a given request (see Figure 8-10). While it allows only one byte of information per response, in many cases a single byte of information is more than adequate. In our example, suppose that each node sensor detected a pressure of 75 P.S.I. (pounds per square inch). The response (the value 75) would take a single byte, 46H, to communicate the reply. The maximum overhead required is 1.24 ms, or one fourth the time it would take type 1 messaging to achieve the same results.

8-12

J1850 COMMUNICATIONS CONTROLLER

In-frame Response (IFR) Frame









IFR Data Field††











S

1-3 Bytes



1-11 Bytes

1 Byte

E

N

D

D ..........

D

0-1 Byte

E

E

I

O



O

O

O

F

F

Header



Data

CRC

D

B

0

1

31

CRC

D

F

S















































The number of data bytes to be transferred is unspecified if 0EH is written to J_CMD3:0.

†† Each DX block in the IFR data field represents a byte of data from a different remote node.

A5227-01

Figure 8-10. IFR Type 2 Message Frame

8.4.2.3IFR Messaging Type 3: Multiple Bytes, Single Responder

IFR messaging type 3 (Figure 8-11) is ideal for requesting large amounts of information from a single source in your system. You can compile up to 12 bytes of data from a remote node on a single request. In our example, for the same amount of CPU overhead as IFR type 1 messaging exhausted (4.96 ms), you can gather up to twelve times as much information.

In-frame Response (IFR) Frame























S

1-3 Bytes



1-11 Bytes

1 Byte

E

N

1-12 Bytes

0-1 Byte

E



E



I







O



O

O



O



F

F

Header



Data

CRC

D

B

IFR Data

CRC

D



F



S













































The number of data bytes to be transferred is unspecified if 0EH is written to J_CMD3:0.

A5228-01

Figure 8-11. IFR Type 3 Message Frame

8.5TRANSMITTING AND RECEIVING MESSAGES

The J1850 controller can transmit and receive messages in either standard or IFR form.

8.5.1Transmitting Messages

To transmit a standard message, prepare the message in register RAM and then write it to the J1850 transmit (J_TX) register (Figure 8-12) one byte at a time.

8-13

8XC196LX SUPPLEMENT

J_TX

Address:

1F50H



Reset State:

00H

The J1850 transmitter (J_TX) register transfers data in byte increments to the J1850 bus from the microcontroller CPU. This register is buffered to allow for transmission of a second data byte while the first data byte is being shifted out. This byte register can be read or written, and is addressable through windowing.

7



0





Transmit Byte







Bit

Bit

Function

Number

Mnemonic









7:0

DB7:0

Data Bits





These eight bits compose the data byte to be transmitted to the J1850 bus.







Figure 8-12. J1850 Transmitter (J_TX) Register

Transmitting the message requires that you first program the J1850 command (J_CMD) register to specify the number of bytes you want to transfer across the J1850 bus. The number of bytes specified must include the header byte(s). After the start of frame (SOF) symbol is put on the bus, the first header byte is transferred to J_TX for transmission. This byte will automatically be transferred into the J1850 transmit buffer (JTX_BUF) and the second byte of the message frame will be written to J_TX. The transfer of the first byte to JTX_BUF triggers the transmission process and generates the J1850 transmission (J1850TX) interrupt (if it is enabled), signaling that J_TX is available for another byte (Figure 8-13).

CPU





J_TX











Message transmit interrupt (J1850TX) set

JTX_BUF



J1850 Bus









A5235-01

Figure 8-13. J1850 Transmit Message Structure

After the byte in JTX_BUF is transmitted, the byte residing in J_TX is automatically shifted into JTX_BUF, freeing J_TX for another byte. This process continues until the CSM has resolved the number of message bytes (MSG3:0) programmed into the J_CMD register.

If the last message byte being transmitted is shifted out before the MSGx count expires, a J1850ST core interrupt is generated and the OVR_UNDR (J_STAT.3) bit records a transmitter underflow error in the J_STAT register.

8-14

J1850 COMMUNICATIONS CONTROLLER

NOTE

An overrun condition can occur on transmission if the transmit buffer,

JTX_BUF, is overwritten.

8.5.2Receiving Messages

For a message reception, after a SOF is detected on the bus, the controller starts to shift data symbols into the J1850 receive buffer (JRX_BUF) until an entire data byte has been received. This byte is automatically transferred into the J1850 receive (J_RX) register (Figure 8-14) and the subsequent byte is written into the empty JRX_BUF.

J_RX

Address:

1F52H



Reset State:

00H

The J1850 receiver (J_RX) register transfers received data in byte increments from the J1850 bus to the microcontroller CPU. This register is buffered to allow for reception of a second data byte while the first data byte is being read. This byte register can be read or written, and is addressable through windowing.

7



0





Receive Byte







Bit

Bit

Function

Number

Mnemonic









7:0

DB7:0

Data Bits





These eight bits compose the last data byte received from the J1850 bus.







Figure 8-14. J1850 Receiver (J_RX) Register

The transfer of the first byte to J_RX triggers the reception process and generates the J1850 reception (J1850RX) interrupt (if it is enabled), signaling that JRX_BUF is available for another byte (Figure 8-15).

JRX_BUF



J1850 Bus



Message receive interrupt (J1850RX) set

CPU



J_RX









A5236-01

Figure 8-15. J1850 Receive Message Structure

After J_RX is read, the byte residing in JRX_BUF is automatically shifted into J_RX, freeing JRX_BUF for another reception. This process continues until an end of data (EOD) symbol is encountered.

8-15

8XC196LX SUPPLEMENT

If a third byte is received before J_RX is read, a J1850ST core interrupt is generated and the OVR_UNDR (J_STAT.3) bit records a receiver overrun error in the J_STAT register.

8.5.3IFR Messages

In-frame response (IFR) messaging is identical in setup to standard messaging for both transmission and reception. It uses the same registers to configure, communicate, and control data. The difference is that the requestor initiating the IFR message sequence writes the message specifying a response from either one or more nodes in the system. Framing a message in this manner bypasses needless CPU overhead that can result from lengthy EOF symbols, and it gives you a faster response to the information you are accessing from remote sites in your system. (Refer to “Inframe Response Messaging” on page 8-12 for a detailed explanation).

8.6PROGRAMMING THE J1850 CONTROLLER

This section explains how to configure the J1850 controller. Several registers combine to control the configuration: the command register, the configuration register, the delay compensation register, and the status register.

Programming the J1850 controller requires that you first program the configuration and delay registers during initialization. You need to program these two registers only once per initialization sequence.

After initialization, you must first program the command register, followed by either the receive or transmit register, and then the status register.

8.6.1Programming the J1850 Command (J_CMD) Register

The J1850 command register (Figure 8-16) determines the messaging type, specifies the number of bytes to be transmitted in the next message frame, and updates the status of the message transmission in progress.

8-16

J1850 COMMUNICATIONS CONTROLLER

J_CMD

Address:

1F51H



Reset State:

00H

The J1850 command (J_CMD) register determines the messaging type, specifies the number of bytes to be transmitted in the next message frame, and updates the status of the message transmission in progress. This byte register can be directly addressed through windowing. You must write to this register prior to transmitting every message.

7

























0

AUTO

IFR

IGNORE

ABORT





MSG3



MSG2

MSG1



MSG0





























Bit

Bit













Function







Number

Mnemonic































































7

AUTO

Automatic Transmit Retry



















This bit, when arbitration is lost on the first byte of your message, prompts





the transmitter to automatically retry until the byte is successfully







transmitted. Automatic retry applies only to the first byte.







0

= normal operation



















1

= enable automatic retry

































6

IFR

In-frame Response Indicator

















This bit signals that a normalization bit (NB) is to be sent after an end-of-





data symbol is detected on the bus and that the subsequent byte written to





the J1850 transmitter (J_TX) register is an in-frame response (IFR).







0

= standard messaging



















1

= next byte written to J_TX is an IFR





























5

IGNORE

Ignore Incoming Message



















This bit instructs the bus to ignore the incoming message until an EOF





symbol is detected. The bit is cleared after an EOF symbol is detected.





0

= normal operation



















1

= ignore incoming message

































4

ABORT

Abort Transmission



















This bit aborts any transmission in progress and flushes the transmit buffer





(JTX_BUF). To prevent another node from mistakenly assuming that the





last byte was a CRC byte, two extra ‘1’s are appended.







0

= normal operation



















1

= abort transmission in progress



































3:0

MSG3:0

Message

























These four bits specify the number of bytes to be transmitted in the next





message frame. This number includes the header, but not the CRC byte. In





normal messaging, the maximum number of bytes you can transmit in a





message frame is eleven.



















MSG3:0

Operation



Purpose











FH

Termination byte

Terminate block transmission







EH

Block transmission

Transmit unspecified number of bytes





DH

Reserved















CH

Reserved















B:0H

Normal messaging

Transmit specified number of bytes





























Figure 8-16. J1850 Command (J_CMD) Register

8-17

8XC196LX SUPPLEMENT

8.6.2Programming the J1850 Configuration (J_CFG) Register

The J1850 configuration register (Figure 8-17) selects the proper oscillator prescaler, initiates a transmission break for debugging, invokes clock quadrupling operation, and selects the normalization bit format.

J_CFG

Address:

1F54H



Reset State:

00H

The J1850 configuration (J_CFG) register selects the proper oscilator prescaler, initiates transmission break for debug, invokes clock quadrupling operation, and selects the normalizartion bit format. This byte register can be directly addressed through windowing. All J1850 bus activity is ignored until you first write to this register.

7



























0

NBF

IFR3



4XM

TXBRK





RXPOL





PRE1



PRE0































Bit

Bit













Function











Number

Mnemonic





































































7

NBF

Normalization Bit Format



















This bit specifies which normalization bit (NB) format is to be used.











IFR with CRC Byte

IFR without CRC Byte







0

=

active long NB

0 = active short NB











1

=

active short NB

1 = active long NB



























6

IFR3

Type 3 IFR Messaging



















This bit selects type 3 IFR messaging, which supports the in-frame transfer





of an unspecified number of data bytes.















0

= normal operation



















1

= type 3 IFR messaging































5

4XM

Oscillator Quadruple (4x) Mode















This bit allows the J1850 peripheral to operate at four times the normal bit





transfer rate (41.6 Kb/s versus 10.4 Kb/s).















0

= normal operation



















1

= 4x mode operation



































4

TXBRK

Transmission Break



















This bit will terminate any transmission in progress by writing a break (BRK)





symbol to the bus.



















0

= normal operation



















1

= transmit BRK symbol onto bus































3

RXPOL

Receive Polarity



















This bit changes the polarity of the receive symbol.











0

= normal operation – Rx input inverted















1

= receive polarity enabled – Rx input non-inverted





































Figure 8-17. J1850 Configuration (J_CFG) Register

8-18

J1850 COMMUNICATIONS CONTROLLER

J_CFG

Address:

1F54H



Reset State:

00H

The J1850 configuration (J_CFG) register selects the proper oscilator prescaler, initiates transmission break for debug, invokes clock quadrupling operation, and selects the normalizartion bit format. This byte register can be directly addressed through windowing. All J1850 bus activity is ignored until you first write to this register.

7

























0

NBF

IFR3

4XM



TXBRK





RXPOL



PRE1



PRE0





























Bit

Bit













Function









Number

Mnemonic





















































2

Reserved; for compatibility with future devices, write zero to this bit.





















1:0

PRE1:0

J1850 Oscillator Prescaler

















These bits ensure proper operation of the J1850 peripheral at the supported





input frequencies (FXTAL1).

















PRE1

PRE0

FXTAL1

















0

0

8 MHz

















0

1

12 MHz













1

0

16 MHz













1

1

20 MHz





































Figure 8-17. J1850 Configuration (J_CFG) Register (Continued)

8.6.3Programming the J1850 Delay Compensation (J_DLY) Register

The J1850 delay compensation register (Figure 8-18) allows you to program the necessary delay time through the external transceiver to compensate for the inherent propagation delays and to accurately resolve bus contention during arbitration.

8-19

8XC196LX SUPPLEMENT

J_DLY

Address:

1F58H



Reset State:

00H

The J1850 delay (J_DLY) register allows you compensate for the inherent propagation delays and to accurately resolve bus contention during arbitration. This byte register can be directly addressed through windowing.

7

















0

DLY4



DLY3



DLY2

DLY1

DLY0









































Bit

Bit







Function







Number

Mnemonic



































7:5

Reserved; for compatibility with future devices, write zeros to these bits.





















4:0

DLY4:0

Delay Time



















These five bits specify the desired propagation delay between the J1850





controller circuitry and the off-chip transceiver device, in units of







microseconds (µs).

































Figure 8-18. J1850 Delay (J_DLY) Register

8-20

J1850 COMMUNICATIONS CONTROLLER

8.6.4Programming the J1850 Status (J_STAT) Register

The J1850 status register (Figure 8-19) provides the current status of the message and the four interrupt sources associated with the J1850 protocol.

J_STAT

Address:

1F53H



Reset State:

00H

The J1850 status (J_STAT) register provides the current status of the message transfer, the receive and transmit buffers, and the four interrupt sources associated with the J1850 protocol. This byte register can be directly addressed through windowing. You must write to this register before transmitting each message. Reading this register clears all bits except BUS_STAT.

7



















0

IFR_RCV

BUS_CONT

BUS_STAT

BRK_RCV





OVR_UNDR

MSG_TX

MSG_RX

J1850BE























Bit

Bit











Function





Number

Mnemonic











































7

IFR_RCV

In-frame Response Received









This bit indicates whether the IFR byte has been received and is ready to





be read from the J1850 receiver (J_RX) register.









0

= no action













1

= IFR byte received























6

BUS_CONT

J1850 Bus Contention













This bit indicates whether bus contention has been detected and arbitration





has been lost.













0

= no action













1

= bus contention























5

BUS_STAT

J1850 Bus Status













This bit indicates whether a transmission or reception is in progress on the





J1850 bus.













0

= J1850 bus idle













1

= J1850 bus busy























4

BRK_RCV

Break Received













This bit indicates whether a BRK symbol has been detected on the J1850





bus.













0

= no action













1

= BRK symbol detected
