QUICK START GUIDE
GW INSTEK PART NO. 82SP-73000MC1
ISO-9001 CERTIFIED MANUFACTURER
SAFETY INSTRUCTIONS
This section contains the basic safety symbols that may
appear on the accompanying user manual CD or on the
instrument. For detailed safety instructions and
precautions, please see the Safety Instructions chapter
in the user manual CD.
Safety Symbols
These safety symbols may appear in the user manual or
on the instrument.
Warning: Identifies conditions or
practices that could result in injury or
Warning
Caution
loss of life.
Caution: Identifies conditions or
practices that could result in damage
to the instrument or to other
DANGER High Voltage
Attention Refer to the Manual
Protective Conductor Terminal
Earth (ground) Terminal
Do not dispose electronic equipment
as unsorted municipal waste. Please
use a separate collection facility or
contact the supplier from which this
Power Cord for the United Kingdom
When using the instrument in the United Kingdom,
make sure the power cord meets the following safety
instructions.
NOTE: This lead/appliance must only be wired by
competent persons.
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in this lead are coloured in
accordance with the following code:
Green/ Yellow: Earth
Blue: Neutral
Brown: Live (Phase)
As the colours of the wires in main leads may not correspond with
the coloured marking identified in your plug/appliance, proceed as
follows:
The wire which is coloured Green & Yellow must be connected to
the Earth terminal marked with either the letter E, the earth symbol
or coloured Green/Green & Yellow.
The wire which is coloured Blue must be connected to the terminal
which is marked with the letter N or coloured Blue or Black.
The wire which is coloured Brown must be connected to the terminal
marked with the letter L or P or coloured Brown or Red.
If in doubt, consult the instructions provided with the equipment or
contact the supplier.
This cable/appliance should be protected by a suitably rated and
approved HBC mains fuse: refer to the rating information on the
equipment and/or user instructions for details. As a guide, a cable of
2
should be protected by a 3A or 5A fuse. Larger conductors
0.75mm
would normally require 13A types, depending on the connection
method used.
Any exposed wiring from a cable, plug or connection that is engaged
in a live socket is extremely hazardous. If a cable or plug is deemed
hazardous, turn off the mains power and remove the cable, any
fuses and fuse assemblies. All hazardous wiring must be
immediately destroyed and replaced in accordance to the above
standard.
GETTING STARTED
This chapter provides a brief overview of the GSP-730,
the package contents, instructions for first time use and
an introduction to the front panel, rear panel and GUI.
Main Features
Performance
Features
Interface
• 150kHz~3GHz bandwidth
• 100kHz resolution
• Autoset with automatic floor level
and span.
• Marker table function
• Limit line testing
• Split window display
• ACPR measurement
• OCBW measurement
• Automatic resolution bandwidth
mode.
• 480x640 color LCD display
• On-screen menu icons
• VGA video output
• RS-232C
• USB 2.0 Host port for data storage
• USB 2.0 Device port for the virtual
com port communication
Package Contents
Please the package contents to ensure you have all of
the following items:
Part Number Description
User Manual CD
Quick Start Guide (this document)
Region Dep. Power cord x1
Cal. Certificate
Display and Panel Overview
Display Overview
Description
1. Reference level 2. Marker information
3. Function menu 4. Soft menu keys
5. Trace icons 6. Entry/Message area
7. Frequency /
Bandwidth settings
8. Trace and waveforms
