Insignia NS-42L550A11, NS-37L550A11, NS-32L550A11 User Manual

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 0 Thursday, January 21, 2010 10:20 AM

User Guide

32"/37"/42" LCD, 120 Hz 1080p

NS-32L550A11/NS-37L550A11/NS-42L550A11

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page ii Thursday, January 21, 2010 10:20 AM

Contents

CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Install the stand or wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Using the remote control holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Programming your universal Insignia remote control . . . . . . . . . . . . 10

Programming a different universal remote control . . . . . . . . . . . . . . . 13

Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connecting the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connecting an antenna or cable TV (no box) . . . . . . . . . . . . . . . . . . . . . 14

Connecting a cable or satellite box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Connecting an HDMI device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting a component video device . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting an S-Video device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting a camcorder or game console . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting a VCR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connecting a digital sound system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Connecting an analog sound system . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Turning on your TV for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Displaying additional information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page iii Thursday, January 21, 2010 10:20 AM

Contents

Adjusting component video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Turning Game Mode on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Adjusting sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Viewing a favorite channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Adding or changing a channel label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Checking the digital signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Locking control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Downloading rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Selecting the closed captioning mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Customizing digital closed captioning styles . . . . . . . . . . . . . . . . . . . . . 34

Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Adjusting the menu transparency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Turning Auto Input Sensing on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Labeling an input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Using INlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Restoring settings to the defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Using USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Switching to USB mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Browsing photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Setting up a favorite photos list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Viewing favorite photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Viewing all photos in a slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Viewing favorite photos in a slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Customizing slideshow settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Cleaning the TV cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Cleaning the TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Manufacturers’ codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Two-year limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

www.insigniaproducts.com

iii

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page iv Thursday, January 21, 2010 10:20 AM

US and Canada Markets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Mexico Market . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Contents

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 1 Thursday, January 21, 2010 10:20 AM

CHILD SAFETY

It makes a difference how and where you use

your flat panel display

As you enjoy your new product, keep these

safety tips in mind

The issue

The home theater entertainment experience is a growing trend, and larger TVs are popular purchases. However, TVs are not always supported on the proper stands or installed according to the manufacturer’s recommendations. We and the consumer electronics industry are committed to making home entertainment enjoyable and safe.

TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or carts may fall over and cause injury.

Tune into safety

• One size of TV stand does not fit all. Use only a TV stand

rated for the weight of your TV.

• Carefully read and understand all enclosed instructions

for proper use of this product.

• Don’t let children climb on or play with entertainment

system furniture and TVs.

• Don’t place TVs on furniture that can easily be used as

steps, such as a crate or chest of drawers.

• Remember that children can become excited while

watching a program, especially on a “larger-than-life” TV. Make sure that you place or install the TV where it cannot be pushed, pulled over, or knocked down.

• Make sure that you route all cords and cables so that they

cannot be pulled or grabbed by curious children.

Wall mounting

If you decide to wall mount your TV, always remember:

• One size of wall mount does not fit all. Use only a wall mount rated for the weight of

your TV and that has been recommended by this TV manufacturer, listed in this manual, or otherwise listed by an independent laboratory as suitable for your TV.

• Follow all instructions supplied by the TV and wall mount manufacturers.

• If you have any doubts about your ability to safely wall mount your TV, get help from a

professional installer.

• Make sure that the wall where you are mounting the TV is

appropriate. Some wall mounts are not designed to be mounted to walls backed with steel studs or cinder blocks. If you are unsure, ask a professional installer.

• TVs can be heavy. At least two people are required for safe wall mount installation.

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 2 Thursday, January 21, 2010 10:20 AM

NS-32L550A11/NS-37L550A11/NS-42L550A11

Important safety instructions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your TV. This label is located on the back of your TV.

This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your TV.

1 Read these instructions. 2 Keep these instructions. 3 Heed all warnings. 4 Follow all instructions. 5 Do not use this apparatus near water. 6 Clean only with a dry cloth. 7 Do not block any ventilation openings. Install in

accordance with the manufacturer's instructions.

8 Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9 Do not defeat the safety purpose of the

polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10 Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11 Only use attachments/accessories specified by

the manufacturer.

12 Use only with a cart, stand, tripod,

bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13 Unplug this apparatus during lightning storms

or when unused for long periods of time.

14 Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

S3125A

15 The wall plug is the disconnecting device. The

plug must remain readily operable.

16 An apparatus with three-prong, grounding-type

plug is a Class I apparatus which needs to be grounded to prevent possible electric shock. Make sure that you connect the Class I apparatus to a grounding-type, three-prong outlet.

17 Remote control batteries should not be exposed

to excessive heat such as sunshine, fire, or the like.

18 The apparatus should not be exposed to

dripping or splashing, and no objects filled with liquids, such as vases, should be placed on the apparatus.

Warnings

Electric shock hazard

To reduce the risk of fire or electric shock, do not remove any cover or expose the device to rain or moisture. No user-serviceable parts are inside. Refer servicing to qualified service technicians.

Lightning

For added protection for your device receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the power outlet and disconnect any antenna or cable system. This helps prevent property damage and personal injury from lightning and power line surges.

Power lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

Handling the LCD panel

• Your TV’s screen is made of glass. Do not drop your TV or hit, jolt, or press hard against the LCD panel. If the screen breaks, be careful of broken glass.

• If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause skin inflammation.

• If the liquid gets in your mouth, immediately gargle, rinse, and consult with your doctor. Also, if the liquid gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.

Replacement parts

When replacement parts are required, make sure that the service technician uses replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, personal injury, or other hazards.

Safety check

After completing any service or repair to this device, ask the service technician to perform routine safety checks to determine that your TV is in correct operating condition.

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 3 Thursday, January 21, 2010 10:20 AM

Power source

Operate your TV only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult an electrician or your local power company.

Cautions

Damage requiring service

Unplug this TV from the power outlet and refer servicing to qualified service personnel under the following conditions:

• When the power supply cord or plug is damaged or frayed.

• If liquid has been spilled or objects have fallen into your TV.

• If your TV has been exposed to rain or water.

• If your TV does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions because incorrect adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore your TV to its normal operation.

• If your TV has been dropped or damaged in any way.

• When your TV exhibits a distinct change in performance.

Outdoor antenna grounding

If an outside antenna or cable system is connected to your TV, make sure that the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to correct grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of the antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

Note to CATV system installer

Article 820 of the National Electrical Code, ANSI/NFPA No. 40 provides guidance for correct grounding. Specifically, it states that the cable ground must be connected to the grounding system of the building as close to the point of cable entry as practical.

Condensation

Moisture will form on the TV if the TV is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, the TV's performance may be impaired. To prevent this, let the TV stand in its new surroundings for about an hour before switching it on, or make sure that the room temperature rises gradually.

Condensation may also form during the summer if the TV is exposed to the breeze from an air conditioner. In such cases, change the location of the TV.

Mobile telephone warning

To avoid interference with your TV picture and sound, operating problems, or even damage, keep your cordless and cellular telephones away from the TV.

End of life directives

Your TV contains tin-lead solder and a fluorescent lamp containing a small amount of mercury. Disposal of these materials may be regulated for environmental reasons. Your TV also contains material that can be recycled and reused. For disposal or recycling information, contact your local authorities or the Electronic Industries Alliance at www.eia.org to find a recycler in your area.

Non-active pixels

The LCD panel contains almost 3 million thin film transistors, which provide exceptionally sharp video quality. Occasionally, a few non-active pixels may appear on the screen as a fixed blue, green, or red point. These non-active pixels do not adversely affect the performance of your TV, and are not considered defects.

Antenna lead-in wire

Grounding clamp

Antenna discharge unit

Grounding conductors

Ground clamps

Power service grounding electrode system

Electric service equipment

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 4 Thursday, January 21, 2010 10:20 AM

NS-32L550A11/NS-37L550A11/NS-42L550A11 32"/37"/42" LCD, 120 Hz 1080p

32"/37"/42" LCD, 120 Hz 1080p

Introduction

Congratulations on your purchase of a high-quality Insignia product. Your NS-32L550A11, NS-37L550A11, or NS-42L550A11 represents the state of the art in LCD TV design and is designed for reliable and trouble-free performance.

AUDYSSEY Dynamic Volume plus Dynamic EQ:

Have you ever caught yourself wishing that you didn't constantly need to adjust the volume: wishing that the commercials wouldn't blare and that you could better hear whispering during a movie scene? Audyssey Dynamic Volume is a feature that lets you put the remote control down and enjoy your show while Audyssey adjusts the sound levels for you automatically. Audyssey Dynamic EQ is a feature that automatically finds the richest sound settings-including enhanced bass-for each scene, even when the volume level is held steady, making the sound coming from your TV speakers sound more lifelike. See page 25 for instructions on how to adjust the audio settings to take advantage of Audyssey.

SRS TruSurround HD:

At Insignia, providing you with superior audio quality is just as important as exceptional picture quality. That's why we added SRS TruSurround HD, which provides you with a theater-like surround-sound experience, with the clearer dialog and the enhanced bass sounds that movie viewers and gamers crave.

Insignia Motion 120Hz:

With a 120 Hz screen refresh rate twice the rate of a 60 Hz screen, a screen with 1,080 lines of resolution (up from 720 lines in the last generation of HDTVs), and special motion-detection technology, you will be experiencing a picture with clearer detail and brightness, smoother transitions, and reduced motion blurring, particularly when watching fast-motion sports and action scenes. (See page 22 for instructions on how to adjust the TV picture)

SupraHD by Zoran:

An advanced-design microprocessor enables the exceptional picture and sound quality that you expect from today's home theater.

Game mode:

Video games generally require adjustments to the television picture settings to get the maximum experience. By simply pressing a button on your remote control, your television settings will automatically adjust for video games. It couldn't be easier. (See page 24 for instruction on how to turn Game Mode on and off)

INlink:

Enjoy the benefit of having HDMI CEC compatible products plug and play! No setup is needed! CEC technology lets different components discover and communicate with each other. (See page 38 for instructions on how to use INlink)

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 5 Thursday, January 21, 2010 10:20 AM

32"/37"/42" LCD, 120 Hz 1080p

Install the stand or wall-mount bracket

Installing the stand

To install the stand:

1 Carefully place your TV screen face-down on a

cushioned, clean surface to protect the screen from damages and scratches.

2 Secure the stand to the screen with the four

provided screws.

Installing a wall-mount bracket

Warning

This apparatus is intended to be supported by a UL Listed wall mount bracket.

To attach your TV to a wall-mount bracket:

1 Carefully place your TV screen face-down on a

cushioned, clean surface to protect the screen from damages and scratches.

2 Remove the four screws that secure the base to

the stand, then remove the base.

3 Remove the four screws that secure the stand

column, then remove the column.

4 Attach the wall-mount bracket with thread ISO

www.insigniaproducts.com

M6 type screws only (not included). Make sure that the insertion length (B) of the M6 screws is between 0.39 ~ 0.47 inches (10 ~ 12mm). A shorter length might make the TV wall-mounting insecure. A longer length might create a space between the wall-mount bracket and TV.

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 6 Thursday, January 21, 2010 10:20 AM

NS-32L550A11/NS-37L550A11/NS-42L550A11 32"/37"/42" LCD, 120 Hz 1080p

NS-32L550A11 (32-inch) NS-37L550A11 (37-inch)

7.84 in. (200 mm)

NS-42L550A11 (42-inch)

15.75 in. (400 mm )

Wall mount brackets

Front

7.84 in. (200 mm)

# Item Description

VOL+/VOL– Press to increase or decrease the volume.

Press to go to the next or previous channel in the

CH /CH

INPUT

7.84 in. (200 mm )

(power)

channel list. For more information, see “Selecting a channel” on page 21.

Press to open the on-screen menu. For more information, see “Navigating the menus” on page 21.

Press to open the Source List, then press or to select a video input source.

In menu mode, press to confirm selections. Press to turn your TV on or off (Standby mode). When

your TV is off, power still flows into it. To disconnect power, unplug the power cord.

TV components

Accessories

Remote control and batteries (2 AA) Stand with screws Power cord Component cable Audio cable Remote control holder Cleaning cloth

Quick Setup Guide

Wall mount brackets

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 7 Thursday, January 21, 2010 10:20 AM

32"/37"/42" LCD, 120 Hz 1080p

Back Side

9 8

# Item Description

AUDIO OUT

AV I N S-VI DEO

AV I N VIDE O

AV IN L/R audio

PC/DVI AUDIO IN

VGA

ANT/CABLE IN

COMPONENT L/R audio

COMPONENT Y/P

Connect an external sound system to these jacks. For more information, see “Connecting an analog sound system” on page 18.

Connect the video for an S-Video device to this jack. For more information, see “Connec ting an S-Video device” on page 16.

Connect the video for a stan dard AV device to this jack. For more information, see “Connecting a VCR” on page 17.

Connect the audio for an S-Video or standard AV device to these jacks. For more information, see “Connecting an S-Video device” on page16 or “Connecting a VCR” on page 17.

Connect the audio for a computer or a DVI device to this jack. For more information, see “Connecting a computer” on page 17 or “Connecting an HDMI device” on page 15.

Connect the video (VGA) for a computer to this jack. For more information, see “Connecti ng a computer” on page 17.

Connect an antenna or cable TV to this jack. For more information, see “Connecting an antenna or cable TV (no box)” on page 14.

Connect the audio for a component video device to these jacks. For more information, see “Connecting a component video device” on page 15.

Connect the video for a component video device to these jacks. For more information, see “Connecting a

B/PR

component video device” on page 15.

5 6 7

# Item Description

Connect headphones to this jack. For more

USB

HDMI1/HDMI2/

HDMI3/HDMI4

SPDIF

(headphone)

information, see “Connecting headphones” on page 18.

Connect a USB device, such as USB flash drive, to this jack.

Connect an HDMI devices to these jacks. An HDMI cable car ries both vi deo and sound. You do no t need to make an audio connection for an HDMI device.

For more information, see “Connecting an HDMI device” on page 15.

When connecting a DVI device using an HDMI-DVI adapter, connect the device to the HDMI1 jack.

Connect an audio amplifier to this jack. For more information, see “Connecting a digital sound system” on page 18.

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 8 Thursday, January 21, 2010 10:20 AM

NS-32L550A11/NS-37L550A11/NS-42L550A11 32"/37"/42" LCD, 120 Hz 1080p

Remote control

# Item Description

Press to turn your TV on or off (Standby mode). When

(power)

SET

BD/DVD

TV Press to control your TV.

MENU Press to open the on-screen menu.

OK/ENTER Press to confirm selections or changes.

GUIDE

(stop)

your TV is off, power still flows into it. To disconnect power, unplug the power cord.

Press to program the remote control to control connected devices. For more information, see “Programming your universal Insignia remote control” on page 10.

Press to control a connec ted Blu-ray or DVD player. You must program the remote control before this button works. For more information, see “Programming your universal Insignia remote control” on page 10.

Press to display the program guide. For more information, see “Displaying additional information” on page 22.

Press to stop playback on DVD, DVR, PVR, or CD devices. You need to program the remote control to control connected devices. For more information, see “Programming your universal Insignia remote control” on page 10.

# Item Description

Press to start playback on DVD, DVR, PVR, or CD devices. You need to program the remote control to

(play)

(fast reverse)

/ (skip back)

RECALL

VOL+/VOL–

Numbers

INPUT

FAV

AUDIO

SLEEP

DYN VO L

STB

AUX

INFO

EXIT

Video input selection

control connected devices. For more information, see “Programming your universal Insignia remote control” on page 10.

Press to fast reverse on DVD, DVR, PVR, or CD devices. You need to program the remote control to control connected devices. For more information, see “Programming your universal Insignia remote control” on page 10.

In DVD, DVR, PVR, or CD mode, press to skip back to the previous title or track. You need to program the remote control to control connec ted devices. For more information, see “Programming your universal Insignia remote control” on page 10.

In DVR mode, the behavior of this button depends on how you programmed your remote control.

In TV mode, press to return to the previous channel. In USB mode, press to switch back to a higher level

folder.

Press to increase or decrease the volume. Press to enter channel numbers and the parental

control password. When programming the remo te control, press to enter

device and programming codes. Press to open the Source List, then press or to

cycle through the available input sources. For more information, see “Selecting the video input source” on page 20.

Press to open the Favorite Channel list. For more information, see “Setting up a favorite channel list” on page 27.

Press to select SRS, Bass, Tre ble, Balance, or Reset Audio Settings. For more information, see “Adjusting sound settings” on page 25.

Press to set the sleep timer. You can select Off, 5, 10, 15, 30, 60, 90, 120, 180, or 240 minutes. For more information, see “Setting the sleep timer” on page 36.

Press to select the level of Audyssey Dynamic Volume. You can s elec t Heavy, Medium, Light, or Off. For information see “Adjusting sound settings” on page 25.

Press to control a connected set-top box. You need to program the remote control to control connected devices. For more info rmation, see “Programming yo ur universal Insignia remote control” on page 10.

Press to control a connected device. You need to program the remote control to control connected devices. For more info rmation, see “Programming yo ur universal Insignia remote control” on page 10.

Press to display TV status information, such as the channel number, channel name (if available), o r signal source. For more information, see “Displaying additional information” on page 22.

Press to move left, right, up, or down in on-screen menus.

Press to close the on-screen menu.

TV—Press to select TV as the video source. VIDEO— Press to select the device connected to the

AV IN jacks. COMP—Press to select the device connected to the

COMPO NENT video jacks. HDMI—Press one or more times to select the device

connected to the HDMI 1 , HDMI 2, HDMI 3, or HDMI 4 jack.

For more information, see “Selecting the video input source” on page 20.

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 9 Thursday, January 21, 2010 10:20 AM

32"/37"/42" LCD, 120 Hz 1080p

# Item Description

In DVD, DVR, PVR, or CD mode, press to begin record ing. You need to program the remo te control to

(record)

PVR/LIST

(fast forward)

/ (skip

forward)

(pause)

CH /CH

MUTE

—

GAME

ZOOM

PICT

control connected devices. For more information, see “Programming your universal Insignia remote control” on page 10.

Press to list all the recorded programs in a PVR/STB. You need to program the remote control to control connected devices. For more information, see “Programming your universal Insignia remote control” on page 10.

Press to fast forward on DVD, DVR, PVR, or CD devices. You need to program the remote control to control connected devices. For more information, see “Programming your universal Insignia remote control” on page 10.

In DVR mode, the behavior of this button depends on how you pro grammed your remo te control.

In DVD, DVR, PVR, or CD mode, press to ski p forward to the next title or track. You need to program the remote control to control connected devices. For more information, see “Programming your universal Insignia remo te control” on page 1 0.

Press to pause playback on DVD, DVR, PVR, or CD devices. You need to program the remote control to control connected devices. For more information, see “Programming your universal Insignia remote control” on page 10.

Press to change TV channels. For more information, see “Selecting a channel” on page 21.

Press to mute the sound. Press again to restore the sound.

Press to enter a digital sub-channel number. For more information, see “Selecting a channel” on page 21.

Press to turn closed c aptioning on or off. You can select CC Off, CC On, or CC On when Mute. For more information, see “Selecting the closed captioning mode” on page 33.

Press to display the Game mode status. Press this button again to turn Game mode On or Off. For more information, see “Turning Game Mode on or off” on page 24.

Press to select the aspect ratio. For more information, see “Adjusting the TV picture” on page 22.

Press to select the video modes. You can select Vivid,

Standard, Energy Savings, Theater, Sports, or Custom. For more information, see “Adjusting the TV

picture” on page 22.

Using the remote control

Installing remote control batteries

To install the remote control batteries:

1 Remove the battery cover.

2 Insert two AA batteries into the battery

compartment. Make sure that you match the + and – symbols on the batteries with the + and – symbols in the battery compartment.

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 10 Thursday, January 21, 2010 10:20 AM

NS-32L550A11/NS-37L550A11/NS-42L550A11 32"/37"/42" LCD, 120 Hz 1080p

3 Replace the battery cover.

Cautions

• Batteries should not be exposed to excessive heat, such as sunshine, heat registers, or fire.

• Battery chemicals can cause a rash. If the batteries leak, clean the battery compartment with a cloth. If chemicals touch your skin, wash immediately.

• Make sure that batteries are disposed of correctly. Do not burn or incinerate.

Notes

• Do not mix batteries of different types.

• Do not mix old and new batteries.

• Remove batteries when the charge is depleted.

• If the remote control is not going to be used for an extended period of time, remove the batteries.

Aiming the remote control

To aim the remote control:

• Point the remote control towards the remote sensor on the front of your TV.

Notes

• Do not expose the remote control to shock or liquids.

• Do not use the remote control in an area with high humidity.

• Do not place the remote control in direct sunlight.

• Do not place objects, such as furniture, between the remote control and the remote sensor.

• The remote control may not work if direct sunlight or bright light shines on the remote sen sor. Eit her move yo ur TV or cha nge the angle at which you use the remote control.

Using the remote control holder

Your TV comes with a remote control holder you can put the remote control in when you are not using it. You can put the holder on a table or mount it on a wall.

Screws (not included)

Tips

• Different types of walls may require different types of screws. If you want to wall mount the remote control holder, make sure that you use the correct screws for the type of wall. (Screws are not provided.)

• The remote control holder is shipped with separate adhesive tape for wall mounting. This tape may not work with all types of walls. Make sure that you use the correct tape for the type of wall.

Tape

Programming your universal Insignia remote control

To program your remote control:

1 Find the codes for the devices you want to

program in “Manufacturers’ codes” on page 46 and write them down or highlight them.

2 Turn on the device (for example, a DVD player)

and, if needed, load media such as a DVD.

3 Press the device button on the TV remote for the

device that you want to program (TV, DVD, STB, or AUX).

4 Press and hold SET until the red LED blinks

twice, then release.

5 Enter the first five-digit code for the device and

brand that you want to program. The LED blinks once as each digit is entered. If the code is valid, the LED blinks twice.

Note

If the LED does not blink twice, repeat steps 2 to 4 and try entering the code again.

6 Aim the remote at the device and press

(power). The device should turn off. If it does not, repeat Steps 3 through 5, trying each code for your brand until you find one that works. If you cannot find a code that works, see “Searching for your code” below.

7 Repeat Steps 1 to 5 for the other devices you

want to control. For future reference, write down each working device code.

Searching for your code

If your device does not respond to the remote control after trying all codes listed for your brand, or if your brand is not listed, try searching for your code.

To search for your code:

1 Turn on the device you want to control. 2 Press the device button on your TV remote

control (TV, DVD, STB, or AUX) once.

3 Press and hold SET until the red LED blinks

twice, then release.

4 Enter 9 9 1. The LED blinks twice. 5 Press the number that matches your device

type.

• 0—Cable converters, video accessories,

satellite receivers

• 1—TVs

• 2—VCRs, DVD players, Blu-ray Disc players

• 3—Audio amplifiers, audio amplifiers/tuners,

CD players

6 Aim the remote at the device and press

(power). The remote sends IR codes from its library to the selected device, starting with the most popular code first. If the device responds, go to Step 8.

7 If the device does not respond, press CH and

the remote tests the next code for that device type. Continue to press CH until the device turns off.

Note

Press CH to try the previous code.

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 11 Thursday, January 21, 2010 10:20 AM

32"/37"/42" LCD, 120 Hz 1080p

8 Now that you have found the correct code, press

SET to save the code that worked for your

device. The LED blinks twice to indicate that the code has been saved.

9 To search for other device codes, repeat Steps 1

to 8.

Checking the codes

If you have set up the remote using the procedure in “Searching for your code” on page 10, you may need to find out which five-digit code is operating your equipment.

To find out which code is assigned to your TV (for example):

1 Press TV once. 2 Press and hold SET until the red LED blinks

twice, then release.

3 Enter 9 9 0. The LED blinks twice. 4 To view the code for the first digit, press 1.

Count the red LED blinks (for example, three blinks = 3), then write down the number in the appropriate code listing at the top of this column.

Note

If the LED does not blink, the code digit is 0.

5 Repeat Step 4 for the four remaining digits,

using 2 for the second digit, 3 for the third digit,

4 for the fourth digit, and 5 for the fifth digit.

6 To check for other device codes, repeat Steps 1

through 5, substituting the device button for the device you would like to check.

Using learning

This universal remote control includes a learning feature so you can add functions that are unique to your home entertainment devices (such as VCR Tracking Up or Down). However, there are some considerations to keep in mind.

Precautions

• Your original remote controls must be in working order for learning to work properly.

• Learned buttons are mode-specific, so each one can store a unique function for each mode.

• Do not use the following buttons for learning: Device buttons, SET, or (record).

• Learning capacity is approximately 42 to 75 buttons, depending on the code being learned.

• Certain device functions are not learnable, including multi-frequency types, some high frequency functions, and other unusual formats.

• For optimum learning, avoid high levels of ambient light such as natural sunlight or energy-efficient fluorescent lights.

Note

Have your original remote controls handy before programming learning.

2 Locate the button on your original remote

control that you want the Insignia remote control to learn. Press the mode button you want to learn functions on.

3 Press and hold SET until the LED blinks twice,

then release.

4 Enter 9 7 5. The LED blinks twice.

Note

If more than 10 seconds pass between button presses, the remote exits programming.

If the LED displays one long flash instead, replace the batteries. If the remote control continues to display one long flash, the remote control cannot learn a new button.

5 Press the button on your TV’s remote control

that you want to program. The feedback LED stays lit for three seconds, indicating that the remote is ready to learn.

6 On the original remote, press and hold the

button to be learned. Continue holding the button on the original remote until the Insignia’s LED blinks twice.

Note

If the red LED displays one long blink, a learning error has occurred. Try repeating this step again until a successful capture occurs. If the function is still not captured, press and hold SET to exit programming and review the Precautions” above. After reviewing, start programming again at Step 1.

7 Repeat Steps 4 and 5 to program another

button. Once you have completed programming all the buttons you want, press and hold SET until the LED blinks twice to save all data learned.

Deleting a single learning button

This process returns the button to its original programming for the mode you select. You can also delete learned programming by teaching a different function to the button (see “Programming a Learned button” above).

Note

If more than 10 seconds pass between button presses, the remote exits programming.

If the LED displays one long flash instead, replace the batteries. If the remote control continues to display one long flash, the remote control cannot learn a new button.

Programming a learned button

To program a learned button:

1 Place your Insignia remote control

head-to-head (about 2" apart) from your original remote control (the one that came with the device).

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 12 Thursday, January 21, 2010 10:20 AM

NS-32L550A11/NS-37L550A11/NS-42L550A11 32"/37"/42" LCD, 120 Hz 1080p

To delete a single learned button:

1 Press the mode button that you want to remove

the learned button from.

2 Press and hold SET until the LED blinks twice,

then release.

3 Enter 9 7 6. The LED blinks twice. 4 Press the button containing the learned

function to be deleted, twice. The LED blinks twice and programming ends.

Deleting all learned buttons in a specific mode

Note

If more than 10 seconds pass between button presses, the remote exits programming.

If the LED displays one long flash instead, replace the batteries. If the remote control continues to display one long flash, the remote control cannot learn a new button.

To delete all learned buttons in a specific mode:

1 Press and hold SET until the LED blinks twice,

then release.

2 Press 9 7 6. The LED blinks twice. 3 Press a mode button twice (for example, TV,

DVD, STB, or AUX) to clear all the learned

buttons for that mode. The LED blinks twice and programming ends.

Changing volume lock

Volume Lock sets the volume and mute buttons to the device you select, regardless of what mode you are in. For example, if you lock the volume to your DVD player and then go to TV mode, when you press the volume button on your Insignia remote, the volume will change on the DVD player and not on your TV.

To lock volume control:

1 Press and hold SET until the red LED blinks

twice, then release.

2 Enter 9 9 3, the LED blinks twice. 3 Press the mode button for the device you want

to control (for example, TV).

4 The LED blinks twice. Now when you press

VOL+, VOL–, or Mute, the selected device

controls the volume regardless of the current mode.

To unlock all volume control:

1 Press and hold SET until the red LED blinks

twice, then release.

2 Enter 9 9 3, the LED blinks twice. 3 Press VOL+. The LED blinks four times. Volume is

independently controlled for all programmed devices.

To unlock a single device’s volume control:

1 Press the device mode button (TV, DVD, STB, or

AUX).

2 Press and hold SET until the red LED blinks

twice, then release.

3 Enter 9 9 3

. The LED blinks twice.

4 Press VOL-. The red LED blinks four times.

Volume is independently controlled for the selected devices.

Programming channel lock

Channel control can be locked so that the Insignia remote controls a single device’s channel-changing functions, regardless of operating mode. This is often enabled by users who watch all broadcast TV through one device, such as a cable set-top box. The affected buttons are 1 through 0, CH , CH , and RECALL.

To lock all channel controls to one device:

1 Press the mode button for the device that you

want to use for changing channels, such as STB for your cable set top box.

2 Press and hold SET until the mode LED blinks

twice, then release.

3 Enter 9 7 3.The mode LED blinks twice. 4 Press CH once. The mode LED blinks twice.

Now, regardless of what mode you select, the channel buttons will only change channels on the assigned device.

To unlock channel locks:

1 Press and hold SET until the mode LED blinks

twice, then release.

2 Enter 9 7 3. The mode LED blinks twice. 3 Press CH once. The mode LED blinks four

times. Now the channel functions will correlate to the

active mode (for example, press CH in TV mode and the TV changes channel accordingly).

Using buttonmover

Your Insignia universal remote control includes a buttonmover feature that lets you copy buttons from one mode (such as source mode) to another mode (such as destination mode) or to a different button in the same mode.

Note

Do not use any of the Device buttons, (power),

RECORD, or SET as a source or destination button.

To move buttons in the same device mode:

1 Press the device button (TV, DVD, STB, or AUX). 2 Press and hold SET until the LED blinks twice,

then release.

3 Press 9 9 4. The LED blinks twice. 4 Press the button you want to move. 5 Press the new button that should perform the

function. The LED blinks twice.

6 Repeat Steps 1-5 to move additional buttons.

To move buttons to a different device mode:

1 Press and hold

SET until the LED blinks twice,

then release.

2 Press 9 9 4. The LED blinks twice. 3 Press the device button that contains the

function you want to move (for example, DVD).

4 Press the button you want to move (such as

Play).

5 Press the device button that you want to move

the function to (such as TV).

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 13 Thursday, January 21, 2010 10:20 AM

32"/37"/42" LCD, 120 Hz 1080p

6 Press the button in the new mode that should

perform the function (for example, Play). The LED blinks twice.

7 Repeat Steps 1-6 to move additional buttons.

To restore all buttonmoved data in a specific mode:

1 Press and hold SET until the LED blinks twice,

then release.

2 Press 9 9 4. The LED blinks twice. 3 Press the device button you want to remove all

buttonmoved data from twice. The LED blinks twice.

4 Repeat for each device you want to restore.

To restore original button function:

1 Press the device button for which you want to

remove the buttonmoved data from a specific button.

2 Press and hold SET until the LED blinks twice,

then release.

3 Enter 9 9 4. The LED blinks twice. 4 Press the button you want to remove the

buttonmoved data from twice. The LED blinks twice.

5 Repeat Steps 1-4 for additional buttons you

want to remove.

Programming macros

Your Insignia universal remote control includes the ability to program any button (other than the SET button) with a macro function. Each one can be set up to perform a pre-programmed set of sequential button presses with the press of a single button. A macro can be used to control a home theater operation, to set a favorite channel, or for other functions you would like to control with one button press. Each macro button can hold up to 15 button presses, total.

Note

Programming a new macro over an existing one erases the original macro.

To program a mode-independent macro:

1 Press and hold SET until the red LED blinks

twice, then release.

2 Press 9 9 5. The LED blinks twice. 3 Press the button you want to assign to a macro. 4 Enter the series of commands you want the

macro to execute (up to 15 commands).

5 Press and hold SET until the red LED blinks

twice, then release. Now, when you press the preset macro button,

the remote sends the series of commands you have entered, regardless of what mode you are in. For example, you could program a macro button to turn on both your TV and cable box and select a particular channel.

Note

To clear the macro, repeat Steps 1-5, but do not enter a series of commands at Step 4.

To program a mode-dependent macro:

1 Press the device mode button (TV, DVD, STB, or

AUX).

2 Press and hold SET until the LED blinks twice,

then release.

3 Press 9 7 8. The LED blinks twice. 4 Press the button you want to assign to a macro. 5 Enter the series of commands you want the

macro to execute (up to 15 commands).

6 Press and hold SET until the red LED blinks

twice, then release. Now, when you press the macro button, the

remote sends the series of commands you have entered, but only if you are in the mode you selected in Step 1. For example, you could program the macro button to turn on both your TV and cable box and select a particular channel, but only if you are in TV mode. If you are in DVD mode, this button does not execute the macro you set up in TV mode.

Note

To clear the macro, repeat Steps 1-6, but do not enter a series of commands at Step 5.

Programming a different universal remote control

You can operate your Insignia TV with a new or existing universal remote control.

To program a different universal remote control:

1 See the table below for common codes. If you

have problems programming your remote or need a different remote control code, visit www.insigniaproducts.com for the latest remote control code information.

Insignia TV codes for universal remote controls

(for all Insignia TVs manufac tured after Jan. 1, 2007)

Universal remote control makes and models

Philips PHDVD5,

PH5DSS,

PMDVR8, PDVR8

115 135 0464 8043

Comcast

M1057

0463 720 0463 0091 10463

RCA

RCU807

One for All URC-6690

Sony

RM-VL600

Set-top box makes and models

Dish Network

VIP508, VIP622

Motorola

DRC800

TIVO

Series 3, HD

DirectTV

RC23

Codes for other remote controls are available online at: www.insigniaproducts.com

Tips

• The brand name is often visible on the front of the universal remote control, and the model number is often visible on the back.

• If your universal remote control isn’t listed on the chart, refer to your universal remote control’s instructions and try codes for the brands Orion, Emerson, Memorex, Sansui, Sylvania, or Zenith. You may need to try several codes before finding a match.

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 14 Thursday, January 21, 2010 10:20 AM

NS-32L550A11/NS-37L550A11/NS-42L550A11 32"/37"/42" LCD, 120 Hz 1080p

2 Follow your universal remote control’s

instructions to enter the TV code you found in Step 1.

Tips

• If your universal remote control has a code search feature, run a code search to identify a code that matches your T V. See your universal remote control’s instructions for details.

• If your universal remote control has a “Learn” feature, you can manually program it using the Insignia TV remote to “teach” the commands one at a time. See your universal remote control’s instructions for details.

3 If all else fails, you must use a different universal

remote control that can operate both your set-top box and your TV. Four such remotes are listed on the chart, but many other compatible models are available in the market.

For more help, go to insigniaproducts.com or call technical support for your universal remote control or set-top box manufacturer, or call the Insignia Customer Care Center. For US and Canada markets, call 1-877-467-4289. For Mexico markets, call 01 800-926-3000.

Making connections

Connecting a cable or satellite box

Many cable or satellite TV boxes have more than one connection type. To get the best video, you should use the best connection type available.

Connection type Video quality

HDMI Best

Component Better than composite, S-Video, or coaxial

S-Video Better than composite or coaxial

Composite Better than coaxial

Coaxial Good

To connect a cable or satellite box:

1 Connect the incoming cable from the cable TV

or satellite TV wall jack to the cable-in jack on the cable box.

Connecting the power

To connect the power:

• Plug the power cord into the AC IN jack on the back of your TV, then plug the other end of the cord into a power outlet.

Connecting an antenna or cable TV (no box)

To connect an antenna or cable TV (no box):

1 Turn off your TV and all connected equipment. 2 Connect a coaxial cable to the ANT/CABLE IN

jack on the back of your TV and to the antenna or cable TV wall jack.

ANT/CABLE IN

Notes

• Use a coaxial cable to eliminate interference and noise from radio waves.

• Do not bundle the coaxial cable with the power cord or other cables.

• If the antenna is not installed correctly, contact qualified service personnel to correct the problem.

HDMI

Composite

S-Video Component

2 Depending on the jacks available on the cable

or satellite TV box, connect a cable from the outgoing jacks on the cable or satellite TV box to the corresponding jacks on the back or side of your TV. The connection can be to an HDMI jack, COMPONENT Y/P

B/PR jacks, AV IN

S-VIDEO, or AV IN VIDEO jack.

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 15 Thursday, January 21, 2010 10:20 AM

32"/37"/42" LCD, 120 Hz 1080p

3 If you use the COMPONENT Y/PB/PR jacks,

connect an audio cable (provided) to the

COMPONENT L/R audio jacks. Or,

If you use the AV IN S-VIDEO or AV IN VIDEO jack, connect an audio cable (not provided) to the AV IN L/ R audio jacks.

Note

If the cable or satellite TV box does not have an HDMI, component, S-Video, or composite jack, connect the cable or satellite TV box to the ANT/CABLE IN jack on the back of your TV. For more information, see “Connecting an antenna or cable TV (no box)” on page 14.

Connecting an HDMI device

Note

If your device has an HDMI connection, we recommend that you use the HDMI connection to get the best quality possible.

To connect an HDMI device:

1 Make sure that your TV’s power cord is

unplugged and the HDMI device is turned off.

2 Connect an HDMI cable (not provided) to the

HDMI 1, HDMI 2, HDMI 3, or HDMI 4 jack on

the side of your TV and to the HDMI OUT jack on the HDMI device.

HDMI device

Connecting a component video device

To connect a component video device:

1 Make sure that your TV’s power cord is

unplugged and the component video device is turned off.

2 Connect a component video cable to the

COMPONENT Y/P

TV and to the COMPONENT OUT video jacks on the component video device.

Back of TV

3 Connect an audio cable to the

COMPONENT L/R audio jacks on the back of

your TV and to the COMPONENT AUDIO OUT jacks on the component video device.

4 Turn on your TV, then turn on the component

video device.

5 Press INPUT to open the Source List. 6 Press or to highlight COMPONENT, then

press OK/ENTER.

B/PR jacks on the back of your

Component video device

Side of TV

3 Turn on your TV, then turn on the HDMI device. 4 Press INPUT to open the Source List. 5 Press or to highlight HDMI 1, HDMI 2,

HDMI 3, or HDMI 4, then press OK/ENTER.

Notes

To connect a DVI device, you need an HDMI-DVI adapter (not included) and a 3.5 mm audio cable (not included). Connect the adapter to the DVI device and the HDMI 1 jack on the side of your TV. Connect the audio cable to the DVI device and to the PC/DVI AUDIO IN jack on the back of your TV.

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 16 Thursday, January 21, 2010 10:20 AM

NS-32L550A11/NS-37L550A11/NS-42L550A11 32"/37"/42" LCD, 120 Hz 1080p

Connecting an S-Video device

Note

The AV IN S-VI DEO jack and the AV IN VIDEO jack share the same audio jacks. You cannot connect both types of devices at the same time.

To connect an S-Video device:

1 Make sure that your TV’s power cord is

unplugged and the S-Video device is turned off.

2 Connect an S-Video cable (not included) to the

AV IN S-V IDE O jack on the back of your TV and the S-VIDEO OUT jack on the S-Video device.

Back of TV

S-Video device

Connecting a camcorder or game console

Note

The AV IN VID EO jack and the AV IN S -VID EO jack share the same audio jacks. You cannot connect both types of devices at the same time.

To connect a camcorder or game console:

1 Make sure that your TV’s power cord is

unplugged and the camcorder or game console is turned off.

2 Connect the video connector on a composite

cable (not included) to the AV IN VI DEO jack on the back of your TV and the VIDEO OUT jack on the camcorder or game console.

Back of TV

Cables are often color-coded to match color- coded jacks. Connec t yellow to yellow, red to red, and white to white.

3 Connect an audio cable (not included) to the

AV IN L/ R audio jacks on the back of your TV

and to the AV OU T audio jacks on the S-Video device.

4 Turn on your TV, then turn on the S-Video

device.

5 Press INPUT to open the Source List. 6 Press or to highlight AV, then press

OK/ENTER.

Camcorder or game console

3 Connect the left and right audio connectors on

the composite cable to the AV I N L /R audio jacks on the back of your TV and to the AUDI O

OUT jacks on the camcorder or game console.

4 Turn on your TV, then turn on the camcorder or

game console.

5 Press INPUT to open the Source List. 6 Press or to highlight AV, then press

OK/ENTER.

Note

To turn Game Mode on or off, press GAME.

www.insigniaproducts.com

NS-32L_37L_42L550A11_09-1120_MAN_V2_English.book Page 17 Thursday, January 21, 2010 10:20 AM

32"/37"/42" LCD, 120 Hz 1080p

Connecting a VCR

Note

The AV IN VI DEO jack and the AV IN S -V IDEO jack share the same audio jacks. You cannot connect both types of devices at the same time.

To connect a VCR:

1 Make sure that your TV’s power cord is

unplugged and the VCR is turned off.

2 Connect the video connector on a composite

cable (not included) to the AV IN VI DEO jack on the back of your TV and the VIDEO OUT jack on the VCR.

Back of TV

Cables are often color-coded to match color- coded jacks. Connect yellow to yel low, red to red, and white to white.

Connecting a computer

To connect a computer:

1 Make sure that your TV’s power cord is

unplugged and the computer is turned off.

2 Connect a VGA cable (not included) to the VGA

jack on the back of your TV and to the VGA jack on the computer.

Back of TV

VCR

3 Connect the left and right audio connectors on

the composite cable to the AV IN L /R audio jacks on the back of your TV and to the AU DIO

OUT jacks on the VCR. 4 Turn on your TV, then turn on the VCR. 5 Press INPUT to open the Source List. 6 Press or to highlight AV, then press

OK/ENTER. 7 Insert a videotape into the VCR, then press the

play button.

3 Connect an audio cable to the

PC/DVI AUDIO IN jack on the back of your TV

and to the AUDIO O UT jack on the computer. 4 Turn on your TV, then turn on the computer. 5 Press INPUT to open the Source List. 6 Press or to highlight VGA, then press

OK/ENTER.

Note

When the computer enters Standby mode, your TV turns off. If your TV does not turn on when you “wake” your computer, press (power) on your TV or remote control.

For HDMI-DVI input from PC, the TV will enter Standby mode after one minute if no signal is detected.

www.insigniaproducts.com
