Indesit IDL 735, IDL 730 User Manual
IDL 730
IDL 735
Dishwasher
Installation and use
Safety Is a Good Habit to Get Into
NOTICE
Carefully read the instructions contained in this manual, as
they provide important information which is essential to safe
and proper installation, use and maintenance of the appliance.
This appliance complies with the following EEC
directives:
- 73/23/EEC of 19/02/73 (Low Voltage) and subsequent
modifications;
- 89/336/EEC of 03/05/89 (Electromagnetic Compatibility)
and subsequent modifications.
- 97/17/EEC Labelling
1.Carefully dispose of the packing material.
2.After removing the packing, check to make sure that the
appliance is not damaged. If in doubt, contact a qualified
professional.
3.The dishwasher must only be used by adults for the washing
of household dishes and cooking utensils.
4.Fundamental rules to follow when using the appliance:
- Never touch the dishwasher when barefoot or with wet
hands or feet;
- We discourage the use of extension cords and multiple
sockets;
- During installation, the power supply cord must not be
excessively or dangerously bent or flattened;
- If the appliance is not operating properly or maintenance
must be performed, disconnect the appliance from the power
supply .
5.Keep detergents out of the reach of children, who must also
be kept away from the dishwasher when it is open.
6.This appliance cannot be installed outdoors, not even if the
area in which it is installed is covered by a roof; it is also very
dangerous to leave it exposed to the rain and elements.
7.Do not touch the heating element during or after a wash
cycle.
8.Do not lean or sit on the door when it is open, as this could
overturn the dishwasher .
9.If the appliance malfunctions, turn off water supply to the
appliance and disconnect the plug from the wall socket. Then,
consult the section entitled, "T roubleshooting." If you cannot
resolve the problem, contact a service centre.
10.Appliances which are no longer being used must be made
inoperable by cutting the power supply cord and removing the
door lock.
To maintain the EFFICIENCY and SAFETY of this
appliance, we recommend:
l call only the Service Centers authorized
by the manufacturer
l always use original Spare Parts
Close-up View (control panel)
G
L
A: ON - OFF Button
B: ON - OFF Light
C: Handle For Opening Door
D: Knob For Selecting Cycles
I
F
E
H
C
G: Cycle phase and 3-in-1 indicator lights
H: "1/2 Load" Button
I: "1/2 Load" Indicator Light
L:
R
3-in1 activation Button
D
A
B
E: Low Salt Indicator Light
F: Low Rinse Aid Indicator Light
R: Start/Reset Button
1
GB
Close-up View (Interior)
G
J
I
E
F
H
K
L
Upper Rack
T op Sprayer Arm
Rack Height Adjustor
Lower Rack
7HFKQL FDO FKDUD FWHULVWLFV
Width cm. 60
Depth cm. 60
Height cm. 85
Capacity 12 standard place settings
Mains water pressure 4,3 psi - 145 psi (30 KPa÷ 1MP a) (0,3 ÷10 bar)
Power voltage See data plate
Total absorber power See data plate
Fuse See data plate
Bottom Sprayer Arm
Salt Container Cap
Washing Filter
Detergent and Rinse Aid Dispenser
GB
2
Salt ......
Salt
The hardness of the water varies from place to place. If
hard water is used in the dishwasher, deposits will form on
the dishes and utensils.
The appliance is equipped with a special softener that uses
a salt specifically designed to eliminate lime and minerals
from the water.
Loading the Salt into the Softener
Always use salt intended
for use with dishwashers.
The salt container is
located beneath the
lower rack and should be
filled as follows:
1. Remove the lower rack
and then unscrew and
remove the cap from the
salt container;
2. If you are filling the
container for the first time,
fill it with water;
3. Place the end of the funnel (supplied) into the hole and
introduce about 2 kg of salt. It is normal for a small amount
of water to come out of the salt container .
4. Carefully screw the cap back on.
The salt container should be filled up when the low
salt indicator light "E" flashes.
Once you have loaded the salt for the first time, it is normal
that the low salt indicator light stays on or flashes for about
5 consecutive cycles.
Adjusting Salt Consumption
The dishwasher is designed to allow for adjusting the amount
of salt consumed based on the
harness of the water used. This
is intended to optimize and customize the level of salt consumption so that it remains at a
minimum.
Your Local Water Board can
supply the degree of hardness
of the water
in your area.
T o adjust salt consumption, proceed as follows:
1) Unscrew the cap from the salt container.
2) There is a ring on the container with an arrow on it (see
figure to the side), if necessary, rotate the ring in the anticlockwise direction from the "_" setting towards the "+"
sign, based on the hardness of the water being used.
It is recommended that adjustments be made in accordance with the following schema:
Water Hardness
Salt
Clarke
degrees
0 - 14 0 - 17 0 -1,7 / 0 /
14 - 36 18 - 44 1,8 - 4,4 "-" 20 60
°fH mmol/l
Selector
position
consumption
(grams/cycle)
Autonomy
(cycles\2kg)
Warning: To prevent rust from forming, we advise you to
load the salt before starting a wash cycle.
36 - 71 45 - 89 4,5 - 8,9 MED 40 40
>71 > 89 > 8,9 "+" 60 25
3-in-1 products:
if you use these products we recommend that you press the
3-in-1 button but still put salt in the dishwasher , turning the
dosage regulator to the “ - ” position. For water of a degree
of hardness greater than 60 °fH, turn the dosage regulator to
the “+” position.
3
GB
