Instruction manual

TUMBLE DRYER

English,1

IDCA 835 IDCA 835 S

Contents

Important information, 2-3 Installation, 4

Where to install the tumble dryer Ventilation Electrical connections Preliminary information

Description of the tumble dryer, 5-6

Features Control panel

How to carry out a drying cycle, 7

Starting and selecting a programme

Programmes and options, 8-9-10

Programme chart Special programmes Options Opening the door

Laundry, 11-12

Sorting laundry Care labels Special items Drying times

 This symbol reminds you to read this instruction

manual.

 Keep this manual at hand for immediate reference

whenever necessary. Always store this manual close to the tumble dryer and remember to pass it on to any new owners when selling or transferring the appliance, so they may familiarise with the warnings and suggestions herein contained.

 Read these instructions carefully: the following pages

contain important information on installation and useful suggestions for operating the appliance.

Warnings and suggestions, 13

General safety Information on recycling and disposal Saving energy and respecting the environment

Care and maintenance, 14

Disconnecting the power supply Cleaning the filter after each cycle Checking the drum after each cycle Emptying the water container after each cycle Cleaning the condenser unit Cleaning the tumble dryer

Troubleshooting, 15 Assistance and Guarantee, 16-17-18

Spare parts

Important information

To ensure that the condenser dryer functions efficiently, the following routine maintenance

procedures must be carried out:

Fluff filter  CLEAN off any fluff build-up on the filter after each drying cycle.

Step 1 Open the dryer door by pressing it as shown in the picture.

Failure to clean the filter after each drying cycle can undermine drying performance as the machine takes longer to dry and thus consumes more energy.

Water container  empty the water container after each drying cycle.

Step 1 Pull the water container towards you and remove it completely from the dryer.

Step 2 Empty all the water in the water container.

Step 2 Pull out the filter (using two fingers).

Step 3 Clean off any fluff build-up on the internal surface of the filter.

Step 4 Replace the filter  never operate the dryer without the filter in place.

Step 3 Replace the water container making sure that it is securely fixed.

Failure to empty the water container may cause the following:

- The dryer stops heating (thus the load may still be damp at the end of the drying cycle).

- The Empty water container LED activates to show that the water container is full.

Filling of the Water Container

When the dryer is first used water will not immediately enter the water container as the pump needs to be primed. This is done automatically and will take a few minutes, during this period the efficiency of the drying process is not affected.

Condenser unit - remove any fluff build-up from the condenser on a monthly basis.

Step 1 Open the condenser cover

- grip the handle and pull towards you.

Step 2 Remove the condenser by turning the 3 catches, then pull the condenser towards you. (It is normal for some residual water to be left in the tubes).

Step 3 Clean the condenser with running water over the rear side to remove any fluff deposits.

Step 4 Replace the condenser unit; make sure that the unit is securely in place, that all 3 catches are fixed and that the position arrows on the front end of the condenser are pointing upwards.

Failure to clean the condenser unit may cause premature failure of the dryer.

Installation

Where to install the tumble dryer

 Install the dryer far from gas ranges, stoves, radiators or hobs, as flames may damage it. If the dryer is installed below a

m 1

worktop, ensure there are 10 mm between the upper panel of the dryer and any objects above it, and 15 mm between the sides of the machine and the walls or furniture units adjacent to it. This ensures adequate air circulation.

Ventilation

 The room must be adequately ventilated while the dryer is running. Make sure that the dryer is installed in a room free of humidity and with adequate air circulation. The flow of air around the dryer is essential to allow water to condense during drying; the dryer will not function properly if it is placed in an enclosed space or inside a cabinet.

 Some condensation may form if the dryer is used in a

small or cold room.

 We do not recommend that the dryer is installed in a

cupboard but the dryer must never be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the dryer door.

Electrical connections

Before plugging the appliance into the socket, check the following:  Make sure your hands are dry.  The socket must have an earth connection.  The socket must be able to withstand the machines maximum power output as indicated on the data plate (see

Description of the tumble dryer).

 The power supply voltage must fall within the values indicated on the data plate (see Description of the tumble dryer).  The socket must be compatible with the dryers plug. Should this not be the case, replace the plug or the socket.

 Do not use extension cords.  The dryer must not be installed outdoors, even if the space is

sheltered. It can be very dangerous if exposed to rain or storms.

 Once installed, the dryers electrical wire and plug must

be within reach.

 The power cord must not be bent or squashed.  The power cord is supplied fitted with a BS1363 plug

and with a 13 amp BS1362 fuse. If it is necessary to fit a replacement fuse, it must be a 13 Amp ASTA approved to BS1362 type. WARNING: The plug must not be used without a fuse cover. If a replacement fuse holder/cover is required, it must be of the same colour coding or wording as shown on the base of the plug. Replacements are available from authorised dealers.

Moulded plug

Water drain

If your dryer is installed next to a drain the water can be plumbed into this drain. This does away with the need to empty the water container. If the dryer is stacked onto or installed next to a washing machine it can share the same drain. The height of the drain must be less than 3' (1 m) from the bottom of the dryer. Remove existing hose from position shown in picture A and fit a suitable length of hose and connect as shown in picture B.

 Make sure that the hose is not squashed or kinked

when the dryer is in its final location.

Picture A

Less than 1m

Picture B

Changing the plug

The wires in the power cord are coloured in accordance with the following.

Green and Yellow (Earth) wire to terminal marked E, symbol x, or coloured green and yellow.

Blue (Neutral) wire to terminal marked N or coloured black.

GREEN & YELLOW

BROWN

BLUE

13 ampere fuse

CROSS-BAR CORD GRIP

13A ASTA approved fuse to BS 1362.

Brown (live) wire to teminal marked L or coloured red.

 If the plug being replaced is a non-rewirable type, then the

cut-off plug must be disposed of safely. DO NOT leave it where it can be inserted into a socket and create a shock hazard.

 The power cord should be checked periodically and replaced

by a cord specially prepared for this dryer and fitted only by authorized technicians (see Service). New or longer power cords are supplied at an extra charge by authorized dealers.

 The manufacturer denies any responsibility should any

of these rules not be followed.

 If in doubt about any of the above consult a qualified electrician.

Preliminary information

Once the tumble dryer is installed, clean the inside of the drum before operating it and remove any dirt accumulated during transportation.

Description of the tumble dryer

Opening the door

Press the

door

Condenser

unit (cover

open)

Features

Water container

Filter

Rating plate

Model &

Serial

Numbers

Air

intake

grille

Condenser cover

handle (pull to

open)

Control panel

On/Off

button

Programme

selection knob

Options

and indicator

lights

buttons

Start/Pause

Maintenance

indicator lights

and indicator light

button

Drying phase or Delay timer

indicator lights

ON/OFF/Reset button

Pressing the button normally will cause the machine to switch on or off. If the button is pressed for 3 seconds while the dryer is in

function, the machine will switch off and the running cycle will reset.

Programme selection knob

Allows for setting the programme: turn until the indicator points towards the desired programme (see Starting and selecting a programme).

Options buttons

Allow for selecting the options available for the selected programme. The relative indicator lights turn on when the option has been selected (see Programmes and options).

START/PAUSE button and indicator light

When the green light flashes slowly, press the button to start the programme. When the cycle is under way, the indicator light remains on. To put the programme into pause mode, press the button again; the indicator light will turn orange and start flashing again. To resume the programme from the point it was interrupted, press the button again (see Start and programme selection).

Indicator lights

Maintenance indicator lights

The indicator lights provide important information. They indicate the following:

The Empty water container indicator light If the water container fills during the course of the programme, the LED lights up. The dryer automatically starts a cold air cycle and the START/PAUSE LED flashes orange. Press the START/PAUSE button to resume the cycle from the point it was interrupted.

In order to avoid this procedure, always empty the water container after using the tumble dryer (see Care and maintenance). Before each programme, the Clean filter indicator light

dryer (see Care and maintenance). The Clean condenser unit indicator light signals that it is essential to clean the condenser regularly (see Care and maintenance).

Drying phases indicator lights

The indicator light signals that the drying phase is running. The

indicator light signals that the cooling phase is running.

The END indicator light signals that the programme has ended.

Delay timer indicator light

If the Delay timer option has been activated (see Programmes and options), after the programme has started, the indicator light corresponding to the chosen delay time will start flashing:

signals that the water container must be emptied.

signals that it is essential to clean the filter each time before using the tumble

As time passes, the remaining delay will be displayed and the corresponding indicator light will flash:

Once the set delay time ends, the flashing LED will turn off and the set programme will start.
